Digital Yacht ZDIGIKREATE Network AccessoriesDigital Yacht NMEA 2000 Simulator Software & iKreateModel: ZDIGIKREATE Create individual NMEA 2000 PGNs from drop down list populated with the data you enter or play back a NMEA 2000 log file captured by a Digital Yacht NMEA 2000 product etc from an on-board system Multiple PGN groups can be created and even saved for future use Data variance function can synthesise changing values No complicated software to install — just a simple file for Chrome, Edge, Opera or Chromium Functions on PC, MAC and Linux platforms — simple USB connection Set SRC address and instance Integrated 0.8m NMEA 2000 and 0.8m USB cable For anyone involved in designing, manufacturing or installing marine electronics, the ability to simulate or replay NMEA2000 data is a real advantage and can accelerate software development, demonstrate NMEA2000 devices or help diagnose network issues.With more and more modern boats having an NMEA2000 network at the heart of their navigation system, it is really important that you have the tools to investigate the devices and data on the network should things not work as planned.Consisting of a new iKreate USB interface and an HTML5 based web app, the iKreate simulator can generate any number of NMEA2000 PGNs or replay saved log files of real life network data from any NMEA2000 system, regardless of brand.Just like our NMEA2000 Display App, our new iKreate SImulator takes a new approach and is the World’s first multi-platform, browser based NMEA2000 Simulator App that will run on Windows, LINUX, Mac OSX and Raspbian. There is no installation and if you can save a file and find it again, then that is as complex as it gets with just a single HTML5 file to worry about (less than 0.5MB in size).You need to use the app with a browser that supports the Web Serial API, which currently includes Chrome, Chromium, MS Edge and Opera. We also plan to support Firefox going forward (with its WebSerial Extension) but this was not possible for the first release of the app.What's in the Box: iKreate USB Interface Software to download via link Normalized SKU: ZDIGIKREATEUPC Code: 703791696949

Maretron CLMD16-R Network AccessoriesMaretron M-Power CLMD16-R DC Load Module 28 Channel N2KModel: CLMD16-R NMEA 2000® Interface IP67 Rated Ignition Protected Opto-isolated from NMEA 2000®, eliminating potential ground loops Sixteen (16) dimmable Electronic Circuit Breakers (ECBs) for On/Off Control over NMEA 2000® network. 4 breakers capable of carrying up to 25 Amps. 12 breakers capable of carrying up to 12 Amps Individual breaker electrical current monitoring Breakers can have Power-Up states defined (ON, OFF or previous states) Breakers can be Locked against inadvertent actuation. Capacitive touch switches for local control of all loads All inputs and outputs protected against short to Power and short to Ground Automatic ECB overcurrent shutdown Automatic ECB thermal shutdown (Overtemperature Protection) Eight (8) discrete digital input channels capable of sensing +ve or ground signals Two (2) resistive analog input channels One (1) 4-20mA current loop input channel For larger breakers and more circuits, the MPower® CLMD16 is a 16-Channel DC Load Controller Module. Four of the 16 breakers handle a maximum of 25 amps and twelve breakers handle a maximum of 12 amps with a total current capacity of 125 Amps. Additionally, circuits can be paralleled.The CLMD16 also supports two H-Bridge reversing polarity circuits that can be used for loads such as engine hatches, passerelles, trim tabs, etc. The CLMD16 has 8 inputs for hard-wired switches that can be used to switch breaker states, or as inputs for other data such as bilge alarms or hatch positions, etc. There are 3 inputs capable of monitoring tank levels.The CLMD16 handles many DC load types such as lights, pumps, motors, and electronics. An added benefit of the CLMD16 is that it reports the current through each of the 16 breakers. This allows you to determine if loads are drawing too much or too little electrical current. This information can be used to report overcurrent faults and under-current conditions such as burnt-out bulbs.Remote control of navigation lights and boarding lights. Control of area lights with dimming. Burnt out bulb alerts.What's in the Box: CLMD16 Load Module with a 1m mating connector for both the J1 and J2 connectors and a 1m I/O harness kit for the J3 connector. Normalized SKU: CLMD16RUPC Code: 873804004365

Download Literature Watch VideoActisense WGX-1-ISO Network AccessoriesNMEA 0183 to NMEA2000 Gateway with WiFi and PC Interface - ISO ConnectionThe WGX-1 is an intelligent NMEA 0183 and NMEA 2000 WiFi Gateway with bi-directional conversion capability.Transfer data from an NMEA 2000 backbone to any device (e.g, laptop, tablet, or smartphone) connected to the WGX-1 via Wi-Fi and additionally convert data bi-directionally between NMEA 0183 and NMEA 2000 using Actisense’s renowned conversion engine. The WGX also acts as a wired gateway, allowing for the transfer or conversion of data between existing NMEA 0183/NMEA2000 instruments.The WGX-1 has built-in conversion of NMEA 2000 messages into NMEA 0183 sentences and vice versa. Allowing a wide variety of vessel data (e.g., position, speed, course, wind speed, depth, engine data, AIS messages, etc.) to be shared with connected devices and applications, both wired and wireless.Stream NMEA 0183 and NMEA 2000 data over Wi-Fi with ease, making it simple to integrate with your favorite boating apps.Data can be logged to an internal micro SD card (not supplied) for post voyage analysis. This is very useful for analyzing race data, generating logbooks, diagnosing problems, or even sharing your voyage details.Actisense-i comes included as standard. Benefit from our full suite of diagnostic tools to help check and diagnose potential issues on a boat’s electronics network, including voltage issues, and the working status of all devices attached to the network. Actisense-i has been designed to save installers and boaters time and ultimately, money, by giving them confidence in their electronics onboard.The WGX-1 has the legendary Actisense “Reliability Built-In” along with useful diagnostic LEDs, internal antenna, enhanced password security, full certification, and all packaged in an extremely rugged IP67 case.Features: OPTO-isolated input and ISO-Drive output for safely interfacing with NMEA 0183 or RS232 / RS422. Up to 230,400 baud rate data transfer rate. Integrated 0.75m ISO cable. Advanced configuration using the Actisense Toolkit allows Tx and Rx lists and Tx rates to be set. Supports fast-heading at 10Hz. Actisense-i network health checker provides valuable feedback on the status of the NMEA 2000 network. Supports both TCP and UDP data streaming over Wi-Fi. Wide range of support for various mobile apps. Remote Firmware upgradability ensures the device is future-proof. IP67 rugged case Vital NMEA 2000 diagnostic tool Diagnostic LEDs on both input and output Technical Specifications:Power Supply Supply Voltage (NMEA 2000 Port) - 9 to 30V DC Supply Current (NMEA 2000 Port) - 78mA @ 9V DC, Max 220mA Load Equivalent Number (LEN) - 2 NMEA 2000 Port Speed / Baud Rate - 250kbps Connectivity - M12 Male (A coded) ISO Port Compatibility - Full NMEA 0183, RS232 & RS422 compatible. RS-485 Listener compatible Speed/Baud Rate - 4800 to 230400 Baud Output Voltage Drive - >= 2.1V (differential) into 100Ω Output Current Drive - 20mA max. Output Protection - Short circuit and ESD Input Voltage Tolerance - -15V to +15V continuous -35V to +35V short term (< 1 second) Input Protection - Current limited and overdrive protection to 40VDC Connectivity - 5mm stripped and tinned wire Cable Length - 0.75m IsolationNMEA 2000 Port to ISO Port - Uses IsoDriveTM, Hi-Pot tested to 1000VWi-Fi Radio Compatibility - IEEE 802.11 b/g/n Speed - 802.11n up to 150Mbps Frequency Band - Wi-Fi: 2412 -2484MHz, Wi-Fi: 19.14dBm (802.11b) Max Output power - 19.22dBm (802.11g), 19.12dBm (802.11n) Antenna - Integrated internal antenna, 3.4dBi Range (Open space) - approx. 30 meters Security - WPA_PSK,  WPA2_PSK,  WPA_WPA2_PSK Configuration IP support - Supports TCP & UDP broadcast Data protocols - NMEA 0183 & Five proprietary Security - Unique SSID and unique default Password per device. (Password is user configurable) Mechanical Housing Material Body - Flame-retardant Polycarbonate Housing Material End Caps - Flame-retardant PBT Weight - 112g Approvals and Certifications Environmental Protection - IP67 Operating Temperature - -25°C to +70°C Storage Temperature - -30°C to +70°C Recommended Humidity - 0 to 93% RH @ 40°C Guarantee - 5 years upon registration This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: WGX1ISOUPC Code: 5060998710768Actisense WGX-1-ISO Literature Download Quick Reference Guide Owners Manual Product BrochureActisense WGX-1-ISO Video

Download LiteratureActisense W2K-2 Network AccessoriesNMEA2000 to WiFi GatewayThe W2K-2 is a rugged and reliable NMEA 2000 to Wi-Fi Gateway with built-in data logger and Actisense-i diagnostic tools.Transfer data from an NMEA 2000 backbone to any device (e.g, laptop, tablet, or smartphone) connected to the W2K-2 via Wi-Fi and additionally convert this data to NMEA 0183 using Actisense’s renowned conversion engine. Actisense-i is a suite of diagnostic tools and a health checker for your network.Fully compatible with the industry’s most popular apps.The W2K-2 has built-in conversion of NMEA 2000 messages into NMEA 0183 sentences, thus allowing a wide variety of vessel data (e.g., position, speed, course, wind speed, depth, engine data, AIS messages, etc.) to be shared with NMEA 0183 compatible software applications running on connected devices.All the data received (or a selected subset) can be logged to an internal micro SD card for later downloading to use for analyzing the voyage. This is very useful for analyzing race data, generating logbooks, diagnosing problems, or even sharing your voyage details. Data can be stored on any micro SD card (up to 128GB), giving weeks or more of storage for all onboard NMEA data.The W2K-2 has adopted the latest WPA3 standards for password protection. Whilst most wireless gateways still use WPA2, WPA3 adds an extra layer of security.Actisense-i comes included as standard. Benefit from our full suite of diagnostic tools to help check and diagnose potential issues on a boat’s electronics network, including voltage issues, and the working status of all devices attached to the network. Actisense-i has been designed to save installers and boaters time and ultimately, money, by giving them confidence in their electronics onboard.The W2K-2 has the legendary Actisense “Reliability Built-In” along with useful diagnostic LEDs, an internal antenna, enhanced password security, full certification, and all packaged in an extremely rugged IP67 case.Features: Converts NMEA 2000 to/from NMEA 0183 (streamed over Wi-Fi) Supports both TCP and UDP, streams data using up to three separate data servers Data protocols are selectable to be compatible with a huge range of navigation software and apps Voyage data recording (install SD card up to 128GB) Diagnostic LEDs for NMEA 2000 bus activity and Wi-Fi Status Works as an access point and a client simultaneously Remote Firmware Upgradability Low power- 2 LEN (100 mA) Supports 802.11 b/g/h (up to 150Mbps) Automatically measures and reports the NMEA 2000 bus voltage User Manual embedded on the device, easily accessible via browser Each device has a unique default SSID and Password for enhanced security Actisense-i diagnostic tools Two-in-one NMEA 2000 to Wi-Fi Gateway and data logger Enables the use of mobile devices and laptops without the hassle of a physical connection Allows compatibility with a wide range of NMEA 2000 & NMEA 0183 applications Ruggedized IP67 casing suitable for wet and harsh environments Works out of the box – just install your choice of SD card for logging data An integrated antenna has less chance of physical damage Quick and easy to install Technical Specifications:Power Supply Supply Voltage (NMEA 2000 Port) - 9 to 30V DC     Supply Current (NMEA 2000 Port) - 70mA (avg.) @ 12V DC, 100mA (avg.) @ 9V DC Load Equivalent Number (LEN) - 2     Supply protection - Continuous reverse polarity protection and transient overvoltage protection to 40V Wi-Fi Radio Compatibility - IEEE 802.11 b/g/n     Speed - 802.11n up to 150Mbps     Frequency Band - 2.4GHz 2.5GHz     Max Output power - 20 dBm     Antenna - Integrated internal antenna     Range (Open space) - 30 meters     Security - WPA_PSK,  WPA2_PSK,  WPA_WPA2_PSK Configuration IP support - Supports TCP and UDP broadcast     Data servers - Three separate data servers     Data protocols - NMEA 0183 & Five proprietary     Security - SSID and Password configurable (Unique defaults per device) Diagnostics Power LED - Blue     NMEA 2000 Tx LED - Orange     NMEA 2000 Rx LED - Green     Status LED - Yellow     Micro SD card - Not supplied – customer to install as required. Mechanical  Housing Material (body) - Polycarbonate     Housing Material (endcaps) - PBT     NMEA 2000 Connector - M12 Male (A polarized) connector molded into the case     NMEA 2000 Connector Material - Nickel-plated brass     Weight - 80g     Dimensions - 106mm (L) x 73mm (W) x 24mm (H) Environmental Environmental Protection - IP67     Operating Temperature - -20°C to +55°C     Storage Temperature - -40°C to +85°C     Recommended Humidity - 0 – 93% RH Approvals and CertificationsGuarantee - 5 yearsThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: W2K2UPC Code: 5060998710829Actisense W2K-2 Literature Download Quick Reference Guide Owners Manual Product Brochure

Actisense USBKIT-PRO Network AccessoriesUSB to Serial Adapter for PRO Range & EMU-1 ProductsSerial to USB cable assembly.*Note: this accessory is only suitable for use with Actisense PRO range products. To safely transfer NMEA 0183 data to a PC from another manufacturer's device, the Actisense USG-2 is recommended.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: USBKITPROUPC Code: 5060998710461

Actisense STNG-A06045 Network AccessoriesSeaTalkNG to NMEA2000 Adapter CableAdapter cable to convert SeaTalkNG data to NMEA2000.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: STNGA06045UPC Code: 5060998710621

Download Literature Watch VideoActisense PRO-NDC-1E Network AccessoriesPRO NMEA 0183 Multiplexer - 5 Inputs & 2 ISO-Drive Outputs, Ethernet & Serial ConnectionsThe PRO-NDC-1E is more than just an NMEA 0183 Multiplexer…Rugged, Robust, type-approved multiplexer with powerful, advanced features enables baud rate adjustments, auto-switching, and sentence-level filtering.Features: Auto-switching between inputs to allow for a primary, secondary, and tertiary priority input. Configurable baud rates to allow 38400 and 4800 baud devices to operate through the same multiplexer. Sentence filtering to block unwanted sentences from specific outputs helps to limit bandwidth consumption. Easy to configure using the web-based UI, no need to manually enter and edit strings of text. RINA type-approved device means the multiplexer is fit for leisure, commercial, and class/type installations. Multiple LEDs allow for ‘quick glance’ diagnostics to ensure everything is operating correctly. NMEA 0183 data streaming over Ethernet enables connectivity to existing Ethernet devices and systems. 5 OPTO-Isolated NMEA 0183 inputs and 2 ISO-Drive NMEA 0183 outputs provide protection for all connected instruments. Dedicated bi-directional Serial port (fully isolated utilising ISO-Drive technology) A serial port can be used as an additional input/output Ethernet port supports direct and network connections NMEA 0183 streaming via Ethernet Configurable input and output baud rates Allows Data combining and rate conversion 2 independent Autoswitch virtual inputs with priority Isolation from battery supply Diagnostic LED’s Optional DIN rail mount Type Approved Quick and easy to install Configuration using a standard web browser, no PC operating system compatibility issues Advanced features solve NMEA 0183 data routing problems Fully isolated with ISO-Drive technology for peace of mind Easy firmware updates make the device future-proof Technical Specifications:Power Supply Input supply voltage - 9 to 35 V DC     Input supply current - 150mA max @ 12V DC (all outputs @ full drive into 100 ohm loads)     Input protection - Continuous reverse polarity, transient overvoltage, and ESD protection     Power indicator - LED, Blue – indicates unit is functioning correctly     Input Supply connector - Pluggable 2-way screw terminal, 5.08mm pitch (12 to 30 AWG) NMEA 0183 Port – Listener & Talker Number of Listener / Input Ports - 5 isolated NMEA 0183 Listeners     Number of Talker / Output Ports - 2 isolated NMEA 0183 Talkers     Compatibility - Fully NMEA 0183, RS422 & RS232 compatible. RS-485 Listener compatible     Speed/baud rate - 4800 to 38400 bps     Talker Output Voltage Drive - >= 2.2V (differential) into 100 ohm     Talker Output Current Drive - 20 mA maximum per output     Talker Output Protection - Short circuit and ESD     Talker Data Indicator - LED, Orange (Flashes with data rate)     Listener Input Voltage Tolerance - -15 V to +15 V continuous, -35 V to +35 V short term (< 1 second)     Listener Input Protection - Current limited, overdrive protection to 40 VDC, and ESD protection     Listener Data Indicator - LED, Green (Flashes with data rate)     Connectors - Pluggable 2/3 way screw terminals, 5.08mm pitch (12 to 30 AWG) Serial Port Compatibility - RS422 & RS232 compatible. RS-485 Listener compatible     Speed/baud rate - 115200 bps     Output voltage drive - >= 2.1V (differential) into 100 ohms     Output current drive - 20 mA max     Output protection - Short circuit and ESD     Input voltage tolerance - -15 V to +15 V continuous, -35 V to +35 V short term (< 1 second)     Input protection - Current limited, overdrive protection to 40 VDC, and ESD protection     Data Indicators - LED’s: Green = Receive, Orange = Transmit     Connectors - Pluggable 3-way screw terminals, 5.08mm pitch (12 to 30 AWG) Ethernet Port Host interface - 10/100BaseT, automatic polarity detection     Supported protocols - TCP/IP for configuration and firmware updating, TCP/IP and UDP for NMEA 0183 comms     Connector - RJ45     Indicators - Green – Link, Yellow – 100 Mbps Isolation NMEA 0183 Listener - Uses IsoDriveTM, Hi-Pot tested to 1000V     NMEA 0183 Talker - Uses IsoDriveTM, Hi-Pot tested to 1000V     Serial Port - Uses IsoDriveTM, Hi-Pot tested to 1000V     Ethernet Port - 2kv for 60s Mechanical Housing Material - 316 Stainless Steel     Dimensions - 139mm (W) x 98mm (H) x 26mm (D)     Weight - 360g     Mounting - Bulkhead mount or DIN rail mount (DIN kit 1) Approvals and Certifications EMC - IEC 60945:2002-08, DNVGL-CG-0339:2019 & IACS UR E10 Rev7     Compass Safe Distance - 300mm     Type Approval Certificate - RINA     Operating Temperature - -25 to +70°C     Storage Temperature - -40 to +85°C     Relative Humidity (RH) - 95% @ 55°C     Environmental Protection - IP40     Guarantee - 3 years (5 Years if registered) This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: PRONDC1EUPC Code: 5060998710577Actisense PRO-NDC-1E Literature Download Quick Reference Guide Owners Manual Product BrochureActisense PRO-NDC-1E Video

Download Literature Watch VideoActisense PRO-NBF-1 Network AccessoriesPRO NMEA Buffer - 1 OPTO Input, 6 ISO-Drive Outputs, Serial Port, Pluggable Screw TerminalsSafely connect one Talker to six Listeners with full isolation.The Type-approved NMEA Buffer PRO-NBF-1 Buffer isolates and buffers NMEA 0183 data, with the power to drive multiple devices.Able to distribute up to six identical, amplified streams of data from one source, the NMEA signals are buffered to ensure that each Listener receives the data at the required voltage levels, providing consistent data quality.Isolation of the input and outputs ensures the protection of the source Talker device and Listener devices.The NMEA Buffer has ISO-Drive™ technology on the outputs and OPTO-isolation on the input, which enables you to connect the NMEA 0183 Buffer with complete peace of mind.The stainless steel housing makes the device rugged, sturdy, and gives it increased durability. The metal case also acts as an RF Shield, making the device an ideal addition to commercial installations.To make installation quick and simple, the PRO-NBF-1 features 2-part pluggable connectors that allow use of screw terminals*, and a professional DIN Rail mounting system (DIN Rail not included). The device can also be mounted directly to the bulkhead.The optional strain relief brackets can be provided to ensure reliable professional cable management.Helpful LEDs indicate power, input, and output operation.Features: One Opto-Isolated Input Six ISO-Drive™ outputs Outputs automatically track the input baud rate RS-232, RS-422 and RS-485 Listener compatible ISO-Drive separates the Listener from the Talker to protect both the PRO-NBF-1 and each connected device Wide compatibility means simplified installation Simple installation saves time and money and provides peace of mind Type Approved (RINA) Technical Specifications:Power Supply Input Supply Voltage - 9 to 35V DC Input Supply Current - 150mA max @ 12V DC (all outputs @ full drive into 100Ω loads) Input Protection - Continuous reverse polarity and ESD protection Power Indicator - LED, Blue – Indicates unit is functioning correctly Input Supply Connector - Pluggable 2-way screw terminal, 5.08mm pitch NMEA 0183 Port – Listener & Talkers Number of Listener / Input Ports - One isolated NMEA 0183 Listener Number of Talker / Output Ports - Six isolated NMEA 0183 Talkers Compatibility - Fully NMEA 0183, RS422 & RS232 compatible. RS-485 Listener compatible Speed/baud rate - 4800 to 115200 bps Talker Output Voltage drive - >= 2.2V (differential) into 100Ω Talker Output Current drive - 20mA max. Talker Output Protection - Short circuit and ESD Talker Data Indicator - LED, Orange (Flashes at data rate) Listener Input Voltage Tolerance - -15V to +15V continuous, -35V to +35V short term (<1 second) Listener Input Protection - Current limited, overdrive protection to 40V DC, and ESD protection Listener Data Indicator - LED, green (Flashes to indicate valid input) Connectors - Pluggable 2/3-way screw terminals, 5.08mm pitch Isolation NMEA 0183 Listener - OPTO-Isolated, Hi-Pot tested to 1000V NMEA 0183 Talker - Uses IsoDriveTM, Hi-Pot tested to 1000V Mechanical Housing Material - 316 Stainless Steel Dimensions - 139mm (L) x 128mm (W) x 27mm (H) Weight - 335g Mounting - Bulkhead mount or DIN rail mount (DIN kit 1) Approvals and Certifications EMC - EN 60945:2002 (Fourth Edition – 2002), DNVGL-CG-0339:2019 Compass safe distance - 600mm Type Approval Certificate - RINA Operating Temperature - -25 to +70°C Storage Temperature - -40 to +85°C Maximum Relative Humidity (RH) - 95% @ 55°C Environmental Protection - IP40 Guarantee - 5 Years Normalized SKU: PRONBF1UPC Code: 5060998710546Actisense PRO-NBF-1 Literature Download Quick Reference Guide Owners Manual Product BrochureActisense PRO-NBF-1 Video

Download LiteratureActisense PRO-MUX-2 Network AccessoriesPRO NMEA 0183 MultiplexerEight OPTO-isolated inputs and six ISO-Drive™isolated outputs. Offering device protection and excellent flexibility, all in one product.Introducing the Actisense® PRO-MUX-2, the intelligent, type-approved PRO range multiplexer.The PRO-MUX-2 is rugged, with a stainless steel housing, and provides isolation on all inputs and outputs. With eight NMEA 0183 inputs, six NMEA 0183 outputs, a bi-directional serial port and an Ethernet port, the PRO-MUX-2 is a perfect solution for larger leisure vessels, commercial shipping and is a great addition for systems that require type-approved devices.The PRO-MUX-2 is designed to suit the majority of NMEA 0183 systems, from leisure through to class vessels.Features: 8 OPTO-isolated NMEA 0183 inputs 6 ISO-Drive NMEA 0183 outputs Bi-directional isolated serial port (can be used for additional NMEA 0183 input/ output) 0183 streaming via Ethernet Alarm output (N/O and N/C contacts) Designed for 12- and 24-Volt supply Isolation to battery supply Configurable input and output baud rates for rate conversion Data combining from any input to any output 2 independent Autoswitch virtual inputs with priority Advanced sentence-based filtering / routing Diagnostic LEDs on all inputs and outputs Alarm, mode and Bi-colour Status LED’s 2-part pluggable connector system supports both screw and screwless terminals DIN rail or Panel mountable Advanced statistics are available via a Web Browser Quick and easy to install Configuration using standard web browser, no PC operating system compatibility issues Advanced features solve NMEA 0183 data routing problems Fully isolated with ISO-Drive technology for peace of mind Easy firmware updates makes the device future-proof Technical Specifications:Power Supply Input Supply Voltage - 9 to 35 V DC Input Supply Current - 220mA max @ 12V DC (all outputs @ full drive into 100 ohm loads) Input Protection - Continuous reverse polarity, transient overvoltage and ESD protection Power Indicator - LED, Blue – indicates unit is functioning correctly Input Supply Connector - Pluggable 2-way screw terminal, 5.08mm pitch (12 to 30 AWG) NMEA 0183 Port – Listener & Talker Number of Listener / Input Ports - 8 isolated NMEA 0183 Listeners Number of Talker / Output Ports - 6 isolated NMEA 0183 Talkers Compatibility - Fully NMEA 0183, RS422 & RS232 compatible. RS485 Listener compatible Speed / baud rate - 4800 to 38400 bps Talker Output Voltage Drive - >= 2.2V (differential) into 100 ohm Talker Output Current Drive - 20 mA maximum per output Talker Output Protection - Short circuit and ESD Talker Data Indicator - LED, Orange (Flashes at data rate) Listener Input Voltage Tolerance - -15 V to +15 V continuous, -35 V to +35 V short term (< 1 second) Listener Input Protection - Current limited, overdrive protection to 40 VDC and ESD protection Listener Data Indicator - LED, Green (Flashes to indicate valid input) Connectors - Pluggable 2/3-way screw terminals, 5.08mm pitch (12 to 30 AWG) Serial Port Compatibility - RS422 & RS232 compatible. RS485 Listener compatible Speed / baud rate - 4800 to 115200 bps Output Voltage Drive - >= 2.1V (differential) into 100 ohm Output Current Drive - 20 mA max. Output Protection - Short circuit and ESD Input Voltage Tolerance - -15 V to +15 V continuous, -35 V to +35 V short term (< 1 second) Input Protection - Current limited, overdrive protection to 40 VDC and ESD protection Data Indicators - LED’s: Green = Receive, Orange = Transmit Connectors - Pluggable 3-way screw terminals, 5.08mm pitch (12 to 30 AWG) Ethernet Port Host Interface - 10/100BaseT, automatic polarity detection Supported Protocols - TCP/IP for configuration and firmware updating, TCP/IP and UDP for NMEA 0183 comms Indicators - Green = Link/Activity, Yellow = 100 Mbps Connector - RJ45 Isolation NMEA 0183 Listener - OPTO-Isolated, Hi-Pot tested to 1000V NMEA 0183 Talker - Uses IsoDrive™, Hi-Pot tested to 1000V Serial Port - Uses IsoDrive™, Hi-Pot tested to 1000V Alarm Relay - Hi-Pot tested to 1000V Ethernet Port - 2kV for 60s Mode Inputs Input Voltage Range - 0 to 35V DC Protection - Transient overvoltage and ESD protection Connectors - Pluggable 2-way screw terminals, 5.08mm pitch (12 to 30 AWG) Alarm Output Contacts - Common, Normally Open and Normally Closed Alarm Indicator - LED, Red indicates a valid alarm condition Contact Ratings - 35VAC / 50VDC Connectors - Pluggable 3-way screw terminals, 5.08mm pitch (12 to 30 AWG) Mechanical Housing Material - 316 Stainless Steel Dimensions - 210mm (W) x 128mm (H) x 27mm (D) Weight - 540g Mounting - Bulkhead mount or DIN rail mount (DIN kit 1) Approvals and Certifications Compass Safe Distance - 175mm Type Approval Certificate - RINA Operating Temperature - -25 to +70°C Storage Temperature - -40 to +85°C Relative Humidity (RH) - 95% @ 55°C Environmental Protection - IP40 Guarantee - 5 Years This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: PROMUX2UPC Code: 5060998710584Actisense PRO-MUX-2 Literature Download Quick Reference Guide

Download Literature Watch VideoActisense PRO-BUF-2 Network AccessoriesPRO NMEA 0183 Buffer - 2 OPTO Inputs, 12 ISO-Drive Outputs, Serial Port, Ethernet Port, Pluggable Screw TerminalTwo OPTO-isolated inputs and twelve ISO-Drive™ isolated outputs. Offering device protection and excellent flexibility, all in one product - the Actisense® PRO-BUF-2, the intelligent, type-approved PRO range buffer.The PRO-BUF-2 is rugged, with a stainless steel housing, and provides isolation on all inputs and outputs. With two NMEA 0183 inputs, twelve NMEA 0183 outputs, a bi-directional serial port, and an Ethernet port, the PRO-BUF-2 is a perfect solution for larger leisure vessels, commercial shipping, and is a great addition for systems that require type-approved devices.The PRO-BUF-2 is designed to suit the majority of NMEA 0183 systems and is ready to go ‘out of the box’ by simply hard-wiring the two-mode inputs as required.The Intelligent NMEA 0183 Buffer's manually configurable basic modes of operation include variations of buffer modes, intelligent auto-switch, and combine modes.For all other configurations, leaving the mode inputs floating selects the ‘User Configuration Mode’. The web-based configuration tool allows full customisation of the PRO-BUF-2, and is compatible across all popular Operating Systems. Using the web-based configuration tool allows for fine-tuning of the data available on each output.To make installation quick and simple, the PRO-BUF-2 features 2-part pluggable connectors that allow the use of screw terminals*, and a professional DIN Rail mounting system (DIN Rail not included). The device can also be mounted directly to the bulkhead.Helpful LEDs indicate power, data in, data out, and the alarm status to aid diagnostics.Data statistics and load indication via the web tool provide a real-time view of data.Features: 2 Opto-Isolated inputs 12 ISO-Drive NMEA 0183 outputs Ethernet Port Flexible operating modes Automatic Baud Rate matching on inputs Alarm output options Web-based configuration tool Diagnostic LEDs Advanced Data Filtering and Routing 2 virtual Autoswitch modules Data statistics and load indication via a web tool Designed for a 12 / 24 Volt supply Future-proofing with easily upgradable firmware 2-part pluggable connector system Stainless Steel Housing with DIN rail mount option Type Approved Flexible configuration options to buffer autoswitch or combine NMEA data ISO-Drive separates the Listener from the Talker to protect both the PRO-BUF and each connected device. Fast bi-directional data connection to a monitor and control software application PRO-BUF can be configured using any web browser on any Operating system Works out-of-the-box without configuration for basic installations, or can be easily user-configured as required Relay output is compatible with on-board alarm systems, and the NMEA Alarm sentence can be displayed and actioned on an MFD Easy to access via network, doesn’t require the device to be moved or have a serial connection to the PC. A quick visual check gives the user confidence that each input and output is passing data Features can be utilised to fine-tune data, avoiding data overloads on the outputs and connected listeners Allows automatic data priority selection between two devices of the same type of data (e.g., GPS) Shows the NMEA 0183 on each I/O Port, and how frequently it arrives, great for low-level diagnostics Allows use on large vessel 24V DC power supply systems Additional features in future firmware revisions are accessed using a simple update process via Actisense Toolkit over Ethernet Fast installations and supports both screw and screwless terminal types. Ideal for quick diagnostic swapping Increased durability, ease of installation, and high performance Can be installed on vessels governed by Class Society Rules Type Approved (RINA) Technical Specifications:Power Supply Input Supply Voltage - 9 to 35 V DC Input Supply Current - 325mA max @ 12V DC (all outputs @ full drive into 100 ohm loads) Input Protection - Continuous reverse polarity, transient overvoltage, and ESD protection Power Indicator - LED, Blue – indicates unit is functioning correctly Input Supply Connector - Pluggable 2-way screw terminal, 5.08mm pitch NMEA 0183 Port – Listener & Talker Number of Listener / Input Ports - 2 isolated NMEA 0183 Listeners Number of Talker / Output Ports - 12 isolated NMEA 0183 Talkers Compatibility - Fully NMEA 0183, RS422 & RS232 compatible. RS-485 Listener compatible Speed/baud rate - 4800 to 38400 bps Talker Output Voltage Drive - >= 2.2V (differential) into 100 ohm Talker Output Current Drive - 20 mA maximum per output Talker Output Protection - Short circuit and ESD Talker Data Indicator - LED, Orange (Flashes at data rate) Listener Input Voltage Tolerance - -15 V to +15 V continuous, -35 V to +35 V short term (< 1 second) Listener Input Protection - Current limited, overdrive protection to 40 VDC, and ESD protection Listener Data Indicator - LED, Green (Flashes to indicate valid input) Connectors - Pluggable 2/3-way screw terminals, 5.08mm pitch Serial Port Compatibility - RS422 & RS232 compatible. RS-485 Listener compatible Speed/baud rate - 4800 to 115200 bps Output Voltage Drive - >= 2.1V (differential) into 100 ohms Output Current Drive - 20 mA max. Output Protection - Short circuit and ESD Input Voltage Tolerance - -15 V to +15 V continuous, -35 V to +35 V short term (< 1 second) Input Protection - Current limited, overdrive protection to 40 VDC, and ESD protection Data Indicators - LED’s: Green = Receive, Orange = Transmit Connectors - Pluggable 3-way screw terminals, 5.08mm pitch Ethernet Port Host Interface - 10/100BaseT, automatic polarity detection Supported Protocols - TCP/IP for configuration and firmware updating, TCP/IP and UDP for NMEA 0183 comms Indicators - Green = Link/Activity, Yellow = 100 Mbps Connector - RJ45 Isolation NMEA 0183 Listener - OPTO-Isolated, Hi-Pot tested to 1000V NMEA 0183 Talker - Uses IsoDriveTM, Hi-Pot tested to 1000V Serial Port - Uses IsoDriveTM, Hi-Pot tested to 1000V Alarm Relay - Hi-Pot tested to 1000V Ethernet Port - 2kV for 60s Mode Inputs Input Voltage Range - 0 to 35V DC Protection - Transient overvoltage and ESD protection Connectors - Pluggable 2-way screw terminals, 5.08mm pitch Alarm Output Contacts - Common, Normally Open and Normally Closed Alarm Indicator - LED, Red indicates a valid alarm condition Contact Ratings - 35VAC / 50VDC Connectors - Pluggable 3-way screw terminals, 5.08mm pitch Mechanical Housing Material - 316 Stainless Steel Dimensions - 210mm (W) x 128mm (H) x 27mm (D) Weight - 530g Mounting - Bulkhead mount or DIN rail mount (DIN kit 1) Approvals and Certifications EMC - IEC 60945:2002-08, DNVGL-CG-0339:2019 & IACS UR E10 Rev7 Compass Safe Distance - 750mm Type Approval Certificate - RINA Operating Temperature - -25 to +70°C Storage Temperature - -40 to +85°C Relative Humidity (RH) - 95% @ 55°C Environmental Protection - IP40 Guarantee - 5 Years This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: PROBUF2UPC Code: 5060998710522Actisense PRO-BUF-2 Literature Download Quick Reference Guide Owners Manual Product BrochureActisense PRO-BUF-2 Video

Actisense DB9-F Network Accessories9-Pin, D-Type Molded Cable Assembly - Female9-pin, D-type molded cable assembly.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: DB9FUPC Code: 5060998710614

Download LiteratureActisense A2K-TER-U Network AccessoriesNMEA2000 Smart Universal Micro TerminatorTerminate your NMEA 2000 network – regardless of whether a male or female connection is required – and use the TER-U’s smart functionality to easily diagnose any power or voltage issues on your NMEA 2000 bus.The TER-U can be fitted directly at the end of your network or used as an in-line terminator in difficult-to-access locations.The TER-U acts as an intelligent diagnostic terminator, providing instant feedback on the state of the NMEA 2000 bus onboard. It is also a universal terminator which can be used as an inline terminator or else as either a Male or Female terminator, as it comes supplied with blanking caps.It has a built-in high-accuracy voltage monitoring circuit, which continuously monitors the bus voltage, and will illuminate its internal LEDs when it detects that the bus voltage is of the correct polarity. If it detects that the voltage is within the minimum required range, it will indicate ‘GREEN’ immediately, providing continuous, valuable feedback as to the state of the bus.If the voltage falls below the minimum required level of 9.0V, then the LEDs will illuminate ‘RED’, showing there is a potential problem with the NMEA 2000 bus power. Similarly, if the LEDs do not illuminate at all, this would indicate that there was no power or that the polarity was incorrect. This monitoring function happens continuously and remains permanent.Because these terminators are illuminated, they instantly provide feedback that the terminator is actually present (i.e., able to identify that there are two terminators present) – especially helpful in difficult-to-reach locations.This smart universal micro-terminator can be used as either a male or female terminator or even as a feed-through terminator for applications at the top of masts, making it truly universal.Technical Specifications:Electrical Rated Current - 4A Rated Voltage - 36VDC Terminator Resistance - 120Ω 1% Features Green LED - NET-S ≥ 9.05V ±  1% Red LED - NET-S < 9.05V ± 1% Mechanical Male Contact - Brass, gold plated Female Contact - Phosphor bronze, gold plated Male Contact Carrier - PA66 (30% Glass-filled), black Female Contact Carrier - PA66 (30% Glass-filled), black Male Contact Polarization - Standard M12 -“A”- polarization Female Contact Polarization - Standard M12 -“A”- polarization Male Mating Thread - M12 Female Mating Thread - M12 Male Screw Cap - Brass, nickel plated Female Screw Cap - Brass, nickel plated Housing - PVC black Weight - 23.6g Flammability Rating - UL94 V0  Approvals and Certifications Protection - IP67 (when mated) Operating Temperature - -20°C to +70°C Storage Temperature - -40°C to +85°C This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: A2KTERUActisense A2K-TER-U Literature Download Quick Reference Guide Owners Manual Product Brochure

Download LiteratureActisense A2K-TER-F Network AccessoriesNMEA2000 Micro Terminator - FemaleActisense terminators are exceptionally robust, designed to withstand the harsh conditions of the marine environment, and are easy to install.Each NMEA 2000 installation must have precisely two termination resistors installed, one at each end of the backbone, to ensure proper operation and signal integrity.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledgeTechnical Specifications:Electrical Rated Voltage (power pair) - 60VDC Rated Current - 4A Internal Termination Resistors - 120 Ω ± 1% 500mW Mechanical Female Contact - Phosphor bronze, gold plated Contact Carrier - PA66 (30% Glass filled), black Contact Polarization - Standard M12 -“A”- polarization Mating Thread - M12 Screw Cap - Brass, nickel plated O-Ring Seal - Rubber, Black Housing - PVC, black Weight - 15g Approvals and Certifications Protection - IP67 (when mated) Operating Temperature - -25°C to +70°C Storage Temperature - -40°C to +85°C This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: A2KTERFActisense A2K-TER-F Literature Download Owners Manual Product Brochure

Download LiteratureActisense A2K-TER-M Network AccessoriesNMEA2000 Micro Terminator - MaleActisense terminators are exceptionally robust, designed to withstand the harsh conditions of the marine environment, and are easy to install.Each NMEA 2000 installation must have precisely two termination resistors installed, one at each end of the backbone, to ensure proper operation and signal integrity.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledgeTechnical Specifications:Electrical Rated Voltage (power pair) - 60VDC Rated Current - 4A Internal Termination Resistors - 120 Ω ± 1% 500mW Mechanical Male Contact - Brass, gold plated Contact Carrier - PA66 (30% Glass filled), black Contact Polarization - Standard M12 -“A”- polarization Mating Thread - M12 Screw Cap - Brass, nickel plated O-Ring Seal - Rubber, Black Housing - PVC, black Weight - 15g Approvals and Certifications Protection - IP67 (when mated) Operating Temperature - -25°C to +70°C Storage Temperature - -40°C to +85°C This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: A2KTERMActisense A2K-TER-M Literature Download Owners Manual Product Brochure

Download LiteratureActisense A2K-TDC-6M Network AccessoriesA2K-TDC-6M NMEA2000 Micro Cable Assembly - 6MAvailable in various lengths, the cable assemblies can be used as either drop cable from a NMEA 2000 backbone or to extend the length of the backbone cable.Actisense Lite cable assemblies allow quick installation and come with quality reassurance as only the Actisense UL-certified cable is used.NMEA 2000 cable includes five wires within a single waterproof cable: power and ground wires, two signal (data) wires, and a drain wire. The drain wire connects to the cable shield, which protects the signal, power, and ground wires from external Radio Frequency Interference (RFI) and helps reduce RFI emission from the cable.NMEA 2000 Lite cable can be used to create a backbone up to 100 meters in length. If the backbone length required exceeds 100 meters, the center of the bus can be extended with an NMEA 2000 mini cable to keep the outer Lite sections to the 100-meter maximum.The maximum length of a drop cable (distance from the backbone) is 6 meters. It is important to limit each drop length to the minimum required, as the total of all drop lengths must not exceed 72 meters.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.Technical Specifications: Rated Current - 3A Rated Voltage - 60VDC Male Contact - Brass, gold-plated Female Contact - Phosphor bronze, gold plated Contact Carrier - PBT, black Contact Polarization - Standard M12 -“A”- polarization Mating Thread - M12 Screw Cap - Brass, nickel plated O-Ring Seal - Rubber, black Housing - PVC, black Power Pair - 22 AWG (19-strand tinned copper) Data Pair - 24 AWG (19-strand tinned copper) Drain - 22 AWG (19-strand tinned copper) Braid - 37 AWG (tinned copper) Jacket Material - 0.8mm Nom. PVC, black Jacket Outer Diameter - 6.85mm ±0.254mm Weight -  430g Protection - IP67 (when mated) Operating Temperature - -20°C to +70°C Storage Temperature - -40°C to +85°C This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: A2KTDC6MActisense A2K-TDC-6M Literature Download Owners Manual Product Brochure

Download LiteratureActisense A2K-TDC-5M Network AccessoriesA2K-TDC-5M NMEA2000 Micro Cable Assembly - 5MAvailable in various lengths, the cable assemblies can be used as either a drop cable from a NMEA 2000 backbone or to extend the length of the backbone cable.Actisense Lite cable assemblies allow quick installation and come with quality reassurance as only the Actisense UL-certified cable is used.NMEA 2000 cable includes five wires within a single waterproof cable: power and ground wires, two signal (data) wires, and a drain wire. The drain wire connects to the cable shield, which protects the signal, power, and ground wires from external Radio Frequency Interference (RFI) and helps reduce RFI emission from the cable.NMEA 2000 Lite cable can be used to create a backbone up to 100 meters in length. If the backbone length required exceeds 100 meters, the center of the bus can be extended with an NMEA 2000 mini cable to keep the outer Lite sections to the 100-meter maximum.The maximum length of a drop cable (distance from the backbone) is 6 meters. It is important to limit each drop length to the minimum required, as the total of all drop lengths must not exceed 72 meters.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.Technical Specifications: Rated Current - 3A Rated Voltage - 60VDC Male Contact - Brass, gold plated Female Contact - Phosphor bronze, gold plated Contact Carrier - PBT, black Contact Polarization - Standard M12 -“A”- polarization Mating Thread - M12 Screw Cap - Brass, nickel plated O-Ring Seal - Rubber, black Housing - PVC, black Power Pair - 22 AWG (19-strand tinned copper) Data Pair - 24 AWG (19-strand tinned copper) Drain - 22 AWG (19-strand tinned copper) Braid - 37 AWG (tinned copper) Jacket Material - 0.8mm Nom. PVC, black Jacket Outer Diameter - 6.85mm ±0.254mm Weight -  370g Protection - IP67 (when mated) Operating Temperature - -20°C to +70°C Storage Temperature - -40°C to +85°C This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: A2KTDC5MActisense A2K-TDC-5M Literature Download Owners Manual Product Brochure

Download LiteratureActisense A2K-TDC-4M Network AccessoriesA2K-TDC-4M NMEA2000 Micro Cable Assembly - 4MAvailable in various lengths, the cable assemblies can be used as either a drop cable from a NMEA 2000 backbone or to extend the length of the backbone cable.Actisense Lite cable assemblies allow quick installation and come with quality reassurance as only the Actisense UL-certified cable is used.NMEA 2000 cable includes five wires within a single waterproof cable: power and ground wires, two signal (data) wires, and a drain wire. The drain wire connects to the cable shield, which protects the signal, power, and ground wires from external Radio Frequency Interference (RFI) and helps reduce RFI emission from the cable.NMEA 2000 Lite cable can be used to create a backbone up to 100 meters in length. If the backbone length required exceeds 100 meters, the center of the bus can be extended with an NMEA 2000 mini cable to keep the outer Lite sections to the 100-meter maximum.The maximum length of a drop cable (distance from the backbone) is 6 meters. It is important to limit each drop length to the minimum required, as the total of all drop lengths must not exceed 72 meters.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.Technical Specifications: Rated Current - 3A Rated Voltage - 60VDC Male Contact - Brass, gold plated Female Contact - Phosphor bronze, gold plated Contact Carrier - PBT, black Contact Polarization - Standard M12 -“A”- polarization Mating Thread - M12 Screw Cap - Brass, nickel plated O-Ring Seal - Rubber, black Housing - PVC, black Power Pair - 22 AWG (19-strand tinned copper) Data Pair - 24 AWG (19-strand tinned copper) Drain - 22 AWG (19-strand tinned copper) Braid - 37 AWG (tinned copper) Jacket Material - 0.8mm Nom. PVC, black Jacket Outer Diameter - 6.85mm ±0.254mm Weight -  287g Protection - IP67 (when mated) Operating Temperature - -20°C to +70°C Storage Temperature - -40°C to +85°C This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: A2KTDC4MActisense A2K-TDC-4M Literature Download Owners Manual Product Brochure

Download LiteratureActisense A2K-TDC-3M Network AccessoriesA2K-TDC-3M NMEA2000 Micro Cable Assembly - 3MAvailable in various lengths, the cable assemblies can be used as either a drop cable from a NMEA 2000 backbone or to extend the length of the backbone cable.Actisense Lite cable assemblies allow quick installation and come with quality reassurance as only the Actisense UL-certified cable is used.NMEA 2000 cable includes five wires within a single waterproof cable: power and ground wires, two signal (data) wires, and a drain wire. The drain wire connects to the cable shield, which protects the signal, power, and ground wires from external Radio Frequency Interference (RFI) and helps reduce RFI emission from the cable.NMEA 2000 Lite cable can be used to create a backbone up to 100 meters in length. If the backbone length required exceeds 100 meters, the center of the bus can be extended with an NMEA 2000 mini cable to keep the outer Lite sections to the 100-meter maximum.The maximum length of a drop cable (distance from the backbone) is 6 meters. It is important to limit each drop length to the minimum required, as the total of all drop lengths must not exceed 72 meters.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.Technical Specifications: Rated Current - 3A Rated Voltage - 60VDC Male Contact - Brass, gold plated Female Contact - Phosphor bronze, gold plated Contact Carrier - PBT, black Contact Polarization - Standard M12 -“A”- polarization Mating Thread - M12 Screw Cap - Brass, nickel plated O-Ring Seal - Rubber, black Housing - PVC, black Power Pair - 22 AWG (19-strand tinned copper) Data Pair - 24 AWG (19-strand tinned copper) Drain - 22 AWG (19-strand tinned copper) Braid - 37 AWG (tinned copper) Jacket Material - 0.8mm Nom. PVC, black Jacket Outer Diameter - 6.85mm ±0.254mm Weight -  228g Protection - IP67 (when mated) Operating Temperature - -20°C to +70°C Storage Temperature - -40°C to +85°C This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: A2KTDC3MActisense A2K-TDC-3M Literature Download Owners Manual Product Brochure

Download LiteratureActisense A2K-TDC-2M Network AccessoriesA2K-TDC-2M NMEA2000 Micro Cable Assembly - 2MAvailable in various lengths, the cable assemblies can be used as either a drop cable from a NMEA 2000 backbone or to extend the length of the backbone cable.Actisense Lite cable assemblies allow quick installation and come with quality reassurance as only the Actisense UL-certified cable is used.NMEA 2000 cable includes five wires within a single waterproof cable: power and ground wires, two signal (data) wires, and a drain wire. The drain wire connects to the cable shield, which protects the signal, power, and ground wires from external Radio Frequency Interference (RFI) and helps reduce RFI emission from the cable.NMEA 2000 Lite cable can be used to create a backbone up to 100 meters in length. If the backbone length required exceeds 100 meters, the center of the bus can be extended with an NMEA 2000 mini cable to keep the outer Lite sections to the 100-meter maximum.The maximum length of a drop cable (distance from the backbone) is 6 meters. It is important to limit each drop length to the minimum required, as the total of all drop lengths must not exceed 72 meters.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.Technical Specifications: Rated Current - 3A Rated Voltage - 60VDC Male Contact - Brass, gold-plated Female Contact - Phosphor bronze, gold plated Contact Carrier - PBT, black Contact Polarization - Standard M12 -“A”- polarization Mating Thread - M12 Screw Cap - Brass, nickel plated O-Ring Seal - Rubber, black Housing - PVC, black Power Pair - 22 AWG (19-strand tinned copper) Data Pair - 24 AWG (19-strand tinned copper) Drain - 22 AWG (19-strand tinned copper) Braid - 37 AWG (tinned copper) Jacket Material - 0.8mm Nom. PVC, black Jacket Outer Diameter - 6.85mm ±0.254mm Weight -  166g Protection - IP67 (when mated) Operating Temperature - -20°C to +70°C Storage Temperature - -40°C to +85°C This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: A2KTDC2MActisense A2K-TDC-2M Literature Download Owners Manual Product Brochure

Download LiteratureActisense A2K-TDC-1M Network AccessoriesA2K-TDC-1M NMEA2000 Micro Cable Assembly - 1MAvailable in various lengths, the cable assemblies can be used as either drop cable from a NMEA 2000 backbone or to extend the length of the backbone cable.Actisense Lite cable assemblies allow quick installation and come with quality reassurance as only the Actisense UL-certified cable is used.NMEA 2000 cable includes five wires within a single waterproof cable: power and ground wires, two signal (data) wires, and a drain wire. The drain wire connects to the cable shield, which protects the signal, power, and ground wires from external Radio Frequency Interference (RFI) and helps reduce RFI emission from the cable.NMEA 2000 Lite cable can be used to create a backbone up to 100 meters in length. If the backbone length required exceeds 100 meters, the center of the bus can be extended with an NMEA 2000 mini cable to keep the outer Lite sections to the 100-meter maximum.The maximum length of a drop cable (distance from the backbone) is 6 meters. It is important to limit each drop length to the minimum required, as the total of all drop lengths must not exceed 72 meters.The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.Technical Specifications: Rated Current - 3A Rated Voltage - 60VDC Male Contact - Brass, gold-plated Female Contact - Phosphor bronze, gold plated Contact Carrier - PBT, black Contact Polarization - Standard M12 -“A”- polarization Mating Thread - M12 Screw Cap - Brass, nickel plated O-Ring Seal - Rubber, black Housing - PVC, black Power Pair - 22 AWG (19-strand tinned copper) Data Pair - 24 AWG (19-strand tinned copper) Drain - 22 AWG (19-strand tinned copper) Braid - 37 AWG (tinned copper) Jacket Material - 0.8mm Nom. PVC, black Jacket Outer Diameter - 6.85mm ±0.254mm Weight -  105g Protection - IP67 (when mated) Operating Temperature - -20°C to +70°C Storage Temperature - -40°C to +85°C This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: A2KTDC1MActisense A2K-TDC-1M Literature Download Owners Manual Product Brochure
