Webasto Truck Freight - Not Qualified for Free Shipping Webasto V77 T BlueCool Variable Speed Chiller 230v #2510596A

Webasto V77 T BlueCool Variable Speed Chiller 230v #2510596A

$16,349.20 $17,392.69 -6% OFF

Webasto V77 T BlueCool Variable Speed Chiller 230v #2510596A

$16,349.20 $17,392.69 -6% OFF

Webasto V77 T BlueCool Variable Speed Chiller 230v #2510596A

$16,349.20 $17,392.69 -6% OFF
Brand: Webasto

SKU: WEB-2510596A

Category: Air Conditioning

More about this item

Webasto 2510596A Air Conditioning

This BlueCool V77 T variable speed chiller provides a cooling capacity of 8,500 to 77,000 BTU ensuring maximum comfort and minimal energy consumption. The V-Series units operate on inverter-driven variable speed compressors which eliminates electrical peaks at startup and ensures smooth and silent operation throughout. The V-Series is compatible with 230 volts at 50 Hz and 240 volts at 60 Hz making it ideal for global cruising.

  • 8,500 -64,000 BTU/hr cooling capacity
  • 8,500 -64,000 BTU/hr heating capacity
  • 230 volts at 50/60 Hz
  • Line fuse protection: inverter and PC board (maximum 25 amp), cold water pump (maximum 16 amp), sea water pump (maximum 16 amp), compressor 2 (maximum 16 amp)
  • Rated current: 2.5-30.5 amp (maximum of 32.5 amp)
  • Maximum draw in Eco 1 mode: 2.5-19 amp (maximum of 21 amp)
  • Maximum draw in Eco 2 mode: 2.5-10 amp (maximum of 14 amp)
  • Maximum draw in Eco 3 mode: 2.5-6 amp (maximum of 8 amp)
  • Maximum starting current: 2.5 amp
  • Cold water connections: 1-1/4 inch female BST
  • Sea water connections: 1-1/4 inch female BST
  • Minimum cold water flow rate 13.74 gallons per minute (825 GPH) or 52 l/min
  • Minimum sea-water flow rate 15.06 gallons per minute (904 GPH) or 57 l/min
  • 1825 GPH pump recommended for cold water loop
  • 1825 GPH pump recommended for sea-water loop
  • Maximum permissible ambient temperature: 140 degrees Fahrenheit/60 degrees Celsius
  • Operating pressure: high pressure 575 - 475 psi (40-33 bar), low pressure: 60 - 70 psi (4-5 bar)
  • Length of wiring harness from the chiller to the electrical box: 2 meters (6.56 feet)
  • R410A refrigerant (875 + 770 grams)
  • Minimum sea water temperature in heating mode: 42.8 degrees Fahrenheit/6 degrees Celsius
  • Maximum sea water temperature in cooling mode: 95 degrees Fahrenheit/35 degrees Celsius
  • Chiller unit: 20.08 inch (510mm) Height x 28.35 inch (720mm) Width x 22.05 inch (560mm) Depth
  • Chiller unit with electrical box: 20.08 inch (510mm) Height x 29.93 inches (760mm) Width x 29.53 inches (750mm) Depth
  • Electric box: 18.31 inch (465mm) Height x 22.05 inch (560mm) Width x 7.48 inch (190mm) Depth
  • Chiller unit weight: 198.42 lbs/90kg
  • Electric box weight: 33.07 lbs/15kg
  • Combined weight: 231.49 lbs/105kg
  • Installation of a seawater strainer is mandatory between the seacock and pump (sold Separately)
  • The electric box features a USB diagnosis port enabling qualified tech direct access via the unique BlueCool Expert Tool. Expert tool offers access to stored fault codes by hourly runtime which will allow a qualified technician to accurately and efficiently troubleshoot any problems that may arise.
  • Compatible with MyTouch display (WBCL151002C)
  • MyTouch control is compatible with the popular Vimar bezels allowing you to maintain a consistent style throughout your yacht (Vimar Eikon, Eikon EVO, Plana, and Bitcino Axolute)
  • Optional BlueCool Connect System allows for remote operation and monitoring via the BlueCool Connect application: WEBASTO-2510219B
  • This unit is equipped with high-pressure and low-pressure service ports

Normalized SKU: 2510596A
