Download LiteratureIcom IC-M424G 21 VHF Fixed Mount RadiosM424G Fixed Mount VHF Marine Transceiver with Built-In GPS - BlackActive Noise Cancelling Technology & Built-In GPS for Simple InstallationIntuitive User Interface and White Backlit LCD and KeypadIncorporating Icom's common Marine Family User Interface designed for simple, intuitive operation. A rotary selector and directional keypad provide quick and easy access to the intended functions. The high contrast white backlit LCD and laser-cut keypad match well with modern boat designs. Active Noise CancellingThe built-in active noise cancelling provides superb performance. It reduces background noise up to 90% in the received signal and 30% in the transmits signal. 10W Loud Audio, Public Address & Foghorn The IC-M424G has a built-in 10W amplifier that increases the audio output to an external PA speaker. The public address function allows you to make an announcement from the microphone like a loud speaker, the foghorn can also be emitted from the external PA speaker. Built-in Class D DSC The built-in DSC watch function monitors Ch. 70 (DSC channel) activity, even while you are receiving another channel. DSC functions include: distress, individual, group, all ships, urgency, safety, position request/report, polling request and DSC test calls. Built-In GPS Receiver The built-in GPS receiver shows your current position, date/time and can be used for DSC calls. The GPS data source is selectable from internal and external GPS. Optional White Backlit COMMANDMICT HM-195GB/GWThe optional white backlit COMMANDMIC makes it convenient for using the IC-M424G from a separate cabin or tower. All functions of the IC-M424G can be controlled from the COMMANDMIC and can be used as an intercom with the IC-M424G.AIS Target Call with MA-500TRWhen connected to the optional MA-500TR Class B AIS transponder, the AIS target call function allows you to make an individual DSC call without having to manually input an MMSI number.Features: Simple remote control speaker-microphone, HM-205B/SW NMEA 0183 connectivity MarineCommander™ compatible AquaQuake™ draining function IPX7 submersible protection (1m depth for 30 minutes) Weather channels with alert function Dual/tri-watch function Priority and normal scan Black and super white versions available Specifications:Weather Alert = NONE Waterproof Rating = Waterproof Scrambler Capable = NONE Remote Mic Capable = NONE Power - Output (Watts) = 25W, 1W Hailer/Intercom = NONE DSC Class = D Channels - Available = NONENormalized SKU: ICM424G21UPC Code: 731797021588Icom IC-M424G 21 Literature Download  Owners Manual  Product Brochure

Icom M422SW MMB VHF Fixed Mount RadiosMounting BracketFeatures: Color: Super White Specifically for use with Icom's M412 and M422 Specifications:Weather Alert = NONE Waterproof Rating = NONE Scrambler Capable = NONE Remote Mic Capable = NONE Power - Output (Watts) = NONE Hailer/Intercom = NONE DSC Class = NONE Channels - Available = NONENormalized SKU: M422SWMMB

Icom M422 MMB VHF Fixed Mount RadiosMounting BracketFeatures: Color: Black Specifically for use with Icom's M412 and M422 Specifications:Weather Alert = NONE Waterproof Rating = NONE Scrambler Capable = NONE Remote Mic Capable = NONE Power - Output (Watts) = NONE Hailer/Intercom = NONE DSC Class = NONE Channels - Available = NONENormalized SKU: M422MMB

  Download LiteratureRaymarine E70243 VHF Fixed Mount RadiosRay50 VHF RadioCompact VHF to mount just about anywhere!The Ray50 VHF packs a powerful communication system into a case that is small enough to mount just about anywhere. With 25W of power, Class D Digital Selective Calling, and simple integration with other onboard electronics, the Ray50 is the perfect solution when space is at a premium.Full of Features, Ultra-Compact DimensionsThe Ray50 features a large display with easy-to-read digits and icons that are visible day or night. The Ray50 features both a noise-cancelling microphone as well as a premium quality speaker. The Ray50 is equipped with Class D Digital Selective Calling (DSC) with simple to use controls and an intuitive menu system. You'll be a Ray50 expert in no time!The Ray50 features standard NMEA2000 and NMEA0183 networking for simple connection to onboard systems and it integrates seamlessly with Raymarine LightHouse II Multifunction Displays for advanced DSC functions. The Ray50 offers flexible mounting too. Use the included trunnion bracket to attach the radio to any console, bulkhead or overhead. The radio can also be flush-mounted using its convenient front-mount attachment points. The Ray50 boasts a wide array of standard features including NOAA weather alert, dual-watch, tri-watch, scanning, selective scanning, and much more.Features: Compact, space-saving design saves space on crowded helms No compromises; full power transmitter and robust VHF features Full-sized controls and LCD are easy to see and operate Sleek, black bezel looks great with Raymarine MFDs and Glass Bridge displays Standard NMEA2000 and NMEA0183 networking for simple connection to onboard systems Can install in the same console mounting holes as the Ray49 Specifications: Weight: 1.7kg (3.74 lbs) Water Integrity: Complies with IPX6 & IPX7 Operating Temp Range: -20 C to +60 C Storage Temp Range: -25 C to +70 C Humidity: up to 95% Communications Port: NMEA0183 and NMEA2000 Antenna Port Impedance: 50 ohms typical External Speaker Impedance: 4 ohms Power: 12 VDC (Operational: Minimum 9V, Maximum 16V) Reverse polarityand over voltage protected Dimensions: 192.5mm (7.6") x 121mm (4.8") with bracket 156mm (6.1") x 88.5mm (3.5") unit only Specifications:Weather Alert = Yes Waterproof Rating = Waterproof Scrambler Capable = No Remote Mic Capable = No Power - Output (Watts) = 25W Hailer/Intercom = N/A DSC Class = D Channels - Available = All US, Canadian, InternationalNormalized SKU: E70243UPC Code: 723193786833Raymarine E70243 Literature Download  Owners Manual

  Download LiteratureRaymarine E70251 VHF Fixed Mount RadiosRay70 All-In-One VHF Radio w/AIS Receiver, Loudhailer & IntercomThe Ultimate All-In-One Communications SolutionHear, be heard and be seen! The new Ray70 from Raymarine is the ultimate all-in-one communications solution for Captains who demand the very best. The multifunction Ray70 VHF comes as standard with a full-function VHF radio, AIS receiver, Loudhailer output, and is dual-station and intercom capable too!Premium, All-In-One Communications SolutionThe Ray70 starts with a powerful, 25W VHF radio with a detachable, noise-cancelling fist-mic and premium audio. Standard VHF features include hi/lo power selection, dual-watch, tri-watch, NOAA Weather Alert, channel scanning, and more. Of course, Ray70 supports Class D Digital Selective Calling and integrates seamlessly with Raymarine multifunction displays thanks to its standard NMEA2000 and NMEA0183 Networking.Built-In GPSRay70 also features a built-in 72 channel GPS receiver ensuring you'll always have a position fix for emergency calls.Built-In AISThe Ray70's integral Automatic Identification System (AIS) receiver simplifies installation and delivers critical vessel traffic information to compatible navigation displays. Built-In LoudhailerFor communications on-deck and in noisy environments, the Ray70 also has a built-in 30W loudhailer output with listen-back capability. This makes it simple to interact with crew on deck, on the dock or with nearby vessels. Simply connect the Ray70 to Raymarine's optional weatherproof hailing horn. In inclement weather you can also use the Ray70's loudhailer to generate fog signals for vessels underway or at anchor as required by the nautical rules-of-the-road. Flexible Mounting OptionsThe Ray70 includes a trunnion mounting bracket kit and can also be flush-mounted using its convenient front-mount attachment points. The gunmetal silver bezel matches Raymarine multifunction displays for a premium look. An optional black bezel kit is also available.Optional Second Station KitThe Ray70 VHF Radio also supports the optional RayMic second station handset for remote locations. This gives you full-function VHF and intercom capability from a second location onboard.The RayMic features an oversized LCD display and high contrast text and graphics that are visible day or night.In addition to providing full access to all of the VHF capabilities, you'll also enjoy the convenience of station-to-station intercom calling between the RayMic and main radio.Features: Built-in AIS Receiver and 72 channel WAAS GPS 30W Loudhailer output with listen-back and automatic fog signals Dual-station and intercom capable with optional RayMic Accessory Oversized LCD display for better viewing Detachable fist-mic with built-in controls and mic relocation capability Detachable gunmetal silver bezel and optional black bezel Specifications: Weight: 2.1kg (4.62 lbs) Water Integrity: Complies with IPX6 & IPX7 Operating Temp Range: -20 C to +60 C Storage Temp Range: -25 C to +70 C Humidity: up to 95% Communications Port: NMEA0183 and NMEA2000 Antenna Port Impedance: 50 ohms typical External Speaker Impedance: 4 ohms Power: 12 VDC (Operational: Minimum 9V, Maximum 16V) Reverse polarityand over voltage protected Handset Audio Output Power: 5W typical Hailer Auto Output Power: 30W typical Hailer Impedance: 4 ohms GPS Sensitivity: High Sensitivity - acquisition down to - 166 dBm AIS Class Type: AIS Receiver Dimensions: 226mm (8.9") x 133mm (5.2") with bracket 199mm (7.8") x 98.5mm (3.9") unit only Specifications:Weather Alert = Yes Waterproof Rating = Waterproof Scrambler Capable = NONE Remote Mic Capable = Yes Power - Output (Watts) = 30W Hailer/Intercom = Both DSC Class = D Channels - Available = All US, Canadian, InternationalNormalized SKU: E70251UPC Code: 723193786918Raymarine E70251 Literature Download  Owners Manual

Icom UX231 VHF Fixed Mount RadiosAIS Receive BoardFor use with M506 Specifications:Weather Alert = NONE Waterproof Rating = NONE Scrambler Capable = NONE Remote Mic Capable = NONE Power - Output (Watts) = NONE Hailer/Intercom = NONE DSC Class = NONE Channels - Available = NONENormalized SKU: UX231UPC Code: 731797019790

  Download LiteratureSimrad 000-11226-001 VHF Fixed Mount RadiosHS90 Handset & Speaker KitBuild or expand your RS90 modular VHF system with an extra HS90 wired handset and external speaker. Up to four handsets and speakers can be connected to a single system, supporting vessel-to-vessel communication from anywhere on board and allowing crew to keep in touch with the RS90’s convenient intercom.Stay In Touch with the HS90 HandsetA large graphical display and alphanumeric keypad offer easy one-handed operation, while shortcut keys provide direct access to advanced functions including AIS plot, waypoints, navigation, and MOB. Rubber-moulded sides ensure a solid grip, and each handset is rated IPX7 waterproof for reliable operation in any conditions. An integrated speaker lets you use the HS90 like a telephone handset, or it can be used like a conventional VHF handset with the included external speaker. A 5-metre (16.5-foot) handset cable is included, and an optional 20-metre (65-foot) cable is available to enable installation almost anywhere on board.Stay Aware with the RS90 SpeakerThe RS90 speaker is rated IPX7 waterproof, and designed to match the low-profile design of Simrad glass bridge displays and instruments. In this fully integrated system, it’s easy to control speaker volume and switch speakers on or off from the corresponding handset. Any handset can make vessel-wide announcements to all external speakers (and other handsets), offering a convenient way to address crew no matter where they are on board. Up to four external speakers can be installed in total, one paired with each HS90 handset in the system.A Modular System to Fit Any BoatThe RS90 is a modular VHF system that’s expandable and customisable to suit any boat and any on-water communication needs. A single RS90 system can run up to six separate stations: four wired, and two wireless. Multiple stations can be used as a vessel-wide intercom system, keeping crewmembers in contact wherever they are on board. Every RS90 system requires at least one HS90 wired handset, which provides complete access to all functions and features. Key Features Wired handset and speaker for RS90 VHF radios Add up to four wired handsets to one RS90 system Large graphical display Alphanumeric keypad with shortcut keys Intercom function between handsets Access advanced features including AIS plot, waypoints, navigation, and MOB External headset support Comes with 5M(16.5') Cable Specifications:Weather Alert = NONE Waterproof Rating = NONE Scrambler Capable = NONE Remote Mic Capable = NONE Power - Output (Watts) = NONE Hailer/Intercom = NONE DSC Class = NONE Channels - Available = NONENormalized SKU: 00011226001UPC Code: 9420024126745Simrad 000-11226-001 Literature Download  Owners Manual

  Download Literature  Watch VideoIcom M506 41 VHF Fixed Mount RadiosM506 VHF Fixed Mount with Rear Mic, AIS & NMEA 0183/2000® - BlackOne Platform - Five Real World Solutions. A Fit For Every Need. Simplythe Best.The Rear Mic model includes an integrated AIS receiver and NMEA0183/2000®. Other built-in M506 features include: 2 minute last call voice recording Active noice cancelling 25W two-way hailer and foghorn Large dot-matrix display Intuitive user interface Built-in Class D DSC IPX8 (advance waterproof rating) COMMANDMICIV™ compatible Integrated AIS ReceiverWith an integrated AIS receiver, the IC-M506 can show AIS vessel trafficinformation on the display. The AIS target call function allows you toeasily set up an individual DSC call. The Plotter, Target list and Dangerlist can be toggled on the display.NMEA 2000® and NMEA 0183 ConnectivityWith the plug-and-play functionality of NMEA 2000, the IC-M506 can easily connect to a NMEA 2000 network and interconnect with other equipment. Also the NMEA 0183 input/output can be used for external GPS/NAV interface.Last Call Voice RecordingThe last call voice recording function automatically saves the last two minutes of the last incoming call. You can also start recording manually.Active Noise CancellingThe built-in bidirectional active noise cancelling reduces background noise to up to 90% and improves both your transmitted voice and incoming call.25W Two-Way HailerWhen connected to an external hailer horn, you can talk to people on the deck or shore from the radio's microphone and can hear people's reply via the hailer horn. Foghorn and RX speaker functions are also available.Optional COMMANDMIC™ HM-195B/SWThe optional COMMANDMIC, HM-195B/SW provides 2nd station capability for using the IC-M506 from a separate cabin or tower. Most functions including DSC and AIS functions can be controlled from the COMMANDMIC and can be used as an intercom between the IC-M506 and the COMMANDMIC.Large LCD & Intuitive User InterfaceThe IC-M506 is equipped with 132x96 pixels dot-matrix display which is larger than the IC-M504 (132x64 pixels). Reading GPS, AIS, DSC and radio menus are easier than ever. The bottom line of the display shows the software key functions and the functions can be toggled with the left and right buttons.Features: 80dB (typical) IMD and channel selectivity MA-500TR AIS transponder and Marine-Commander™ compatible IPX8 submersible plus protection (1m depth for 60 minutes) Rear panel microphone version Optional voice scrambler Specifications:Channels - Available = All US, Canadian, International DSC Class = D Hailer/Intercom = Hailer Power - Output (Watts) = 25W/1W Remote Mic Capable = Yes Scrambler Capable = Yes Waterproof Rating = Submersible Weather Alert = YesNormalized SKU: M50641UPC Code: 731797017642Icom M506 41 Literature Download  Quick Reference Guide  Owners Manual  Product BrochureIcom M506 41 Video

  Download Literature  Watch VideoIcom M506 21 VHF Fixed Mount RadiosM506 VHF Fixed Mount with Front Mic, AIS & NMEA 0183/2000®One Platform - Five Real World Solutions. A Fit For Every Need. Simplythe Best.The Front Mic model includes an integrated AIS receiver and NMEA 0183/2000®. Other built-in M506 features include: 2 minute last call voice recording Active noice cancelling 25W two-way hailer and foghorn Large dot-matrix display Intuitive user interface Built-in Class D DSC IPX8 (advance waterproof rating) COMMANDMICIV™ compatible Integrated AIS ReceiverWith an integrated AIS receiver, the IC-M506 can show AIS vessel traffic information on the display. The AIS target call function allows you to easily set up an individual DSC call. The Plotter, Target list and Danger list can be toggled on the display.NMEA 2000® & NMEA 0183 ConnectivityWith the plug-and-play functionality of NMEA 2000, the IC-M506 can easilyconnect to a NMEA 2000 network and interconnect with other equipment. Alsothe NMEA 0183 input/output can be used for external GPS/NAV interface.Last Call Voice RecordingThe last call voice recording function automatically saves the last two minutes of the last incoming call. You can also start recording manually.Active Noise CancellingThe built-in bidirectional active noise cancelling reduces background noise to up to 90% and improves both your transmitted voice and incoming call.25W Two-Way HailerWhen connected to an external hailer horn, you can talk to people on the deck or shore from the radio's microphone and can hear people's reply via the hailer horn. Foghorn and RX speaker functions are also available.Optional COMMANDMIC™ HM-195B/SWThe optional COMMANDMIC, HM-195B/SW provides 2nd station capability for using the IC-M506 from a separate cabin or tower. Most functions including DSC and AIS functions can be controlled from the COMMANDMIC and can be used as an intercom between the IC-M506 and the COMMANDMIC.Large LCD & Intuitive User InterfaceThe IC-M506 is equipped with 132x96 pixels dot-matrix display which is larger than the IC-M504 (132x64 pixels). Reading GPS, AIS, DSC and radio menus are easier than ever. The bottom line of the display shows the software key functions and the functions can be toggled with the left and right buttons.Features: 80dB (typical) IMD and channel selectivity MA-500TR AIS transponder and Marine-Commander™ compatible IPX8 submersible plus protection (1m depth for 60 minutes) Front panel microphone version Optional voice scrambler Specifications:Channels - Available = All US, Canadian, International DSC Class = D Hailer/Intercom = Hailer Power - Output (Watts) = 25W/1W Remote Mic Capable = Yes Scrambler Capable = Yes Waterproof Rating = Submersible Weather Alert = YesNormalized SKU: M50621UPC Code: 731797017666Icom M506 21 Literature Download  Quick Reference Guide  Owners Manual  Product BrochureIcom M506 21 Video

  Download Literature  Watch VideoIcom M506 11 VHF Fixed Mount RadiosM506 VHF Fixed Mount with Front Mic & NMEA 0183/2000® - BlackOne Platform - Five Real World Solutions. A Fit For Every Need. Simplythe Best.The Front Mic model includes NMEA 0183/2000®. Other built-in M506 features include: 2 minute last call voice recording Active noice cancelling 25W two-way hailer and foghorn Large dot-matrix display Intuitive user interface Built-in Class D DSC IPX8 (advance waterproof rating) COMMANDMICIV™ compatible NMEA 2000® & NMEA 0183 ConnectivityWith the plug-and-play functionality of NMEA 2000, the IC-M506 can easily connect to a NMEA 2000 network and interconnect with other equipment. Also the NMEA 0183 input/output can be used for external GPS/NAV interface.Last Call Voice RecordingThe last call voice recording function automatically saves the last twominutes of the last incoming call. You can also start recording manually.Active Noise CancellingThe built-in bidirectional active noise cancelling reduces background noiseto up to 90% and improves both your transmitted voice and incoming call.25W Two-Way HailerWhen connected to an external hailer horn, you can talk to people on the deck or shore from the radio's microphone and can hear people's reply via the hailer horn. Foghorn and RX speaker functions are also available.Optional COMMANDMIC™ HM-195B/SWThe optional COMMANDMIC, HM-195B/SW provides 2nd station capability for using the IC-M506 from a separate cabin or tower. Most functions including DSC and AIS functions can be controlled from the COMMANDMIC and can be used as an intercom between the IC-M506 and the COMMANDMIC.Large LCD & Intuitive User InterfaceThe IC-M506 is equipped with 132x96 pixels dot-matrix display which is larger than the IC-M504 (132x64 pixels). Reading GPS, AIS, DSC and radio menus are easier than ever. The bottom line of the display shows the software key functions and the functions can be toggled with the left and right buttons.Features: 80dB (typical) IMD and channel selectivity MA-500TR AIS transponder and Marine-CommanderT compatible IPX8 submersible plus protection (1m depth for 60 minutes) Front panel microphone version Optional voice scrambler Specifications:Channels - Available = All US, Canadian, International DSC Class = D Hailer/Intercom = HAILER Power - Output (Watts) = 25W/1W Remote Mic Capable = Yes Scrambler Capable = Yes Waterproof Rating = Submersible Weather Alert = YesNormalized SKU: M50611UPC Code: 731797017673Icom M506 11 Literature Download  Quick Reference Guide  Owners Manual  Product BrochureIcom M506 11 Video

  Download Literature  Watch VideoIcom M506 01 VHF Fixed Mount RadiosM506 VHF Fixed Mount with NMEA 0183 - BlackOne Platform - Five Real World Solutions. A Fit For Every Need. Simply the Best.The basic model comes with NMEA 0183 installed and includes the same built-in features as the other models. Other built-in M506 features include: 2 minute last call voice recording Active noice cancelling 25W two-way hailer and foghorn Large dot-matrix display Intuitive user interface Built-in Class D DSC IPX8 (advance waterproof rating) COMMANDMICIV™ compatible NMEA 0183 ConnectivityThe NMEA 0183 input/output can be used for external GPS/NAV interface.Last Call Voice RecordingThe last call voice recording function automatically saves the last two minutes of the last incoming call. You can also start recording manually.Active Noise CancellingThe built-in bidirectional active noise cancelling reduces background noise to up to 90% and improves both your transmitted voice and incoming call.25W Two-Way HailerWhen connected to an external hailer horn, you can talk to people on the deck or shore from the radio's microphone and can hear people's reply via the hailer horn. Foghorn and RX speaker functions are also available.Optional COMMANDMIC™ HM-195B/SWThe optional COMMANDMIC, HM-195B/SW provides 2nd station capability for using the IC-M506 from a separate cabin or tower. Most functions including DSC and AIS functions can be controlled from the COMMANDMIC and can be used as an intercom between the IC-M506 and the COMMANDMIC.Large LCD & Intuitive User InterfaceThe IC-M506 is equipped with 132x96 pixels dot-matrix display which is larger than the IC-M504 (132x64 pixels). Reading GPS, AIS, DSC and radio menus are easier than ever. The bottom line of the display shows the software key functions and the functions can be toggled with the left and right buttons.Features: 80dB (typical) IMD and channel selectivity MA-500TR AIS transponder and Marine-Commander™ compatible IPX8 submersible plus protection (1m depth for 60 minutes) Front panel microphone version Optional voice scrambler Specifications:Channels - Available = All US, Canadian, International DSC Class = D Hailer/Intercom = Hailer Power - Output (Watts) = 25W/1W Remote Mic Capable = Yes Scrambler Capable = Yes Waterproof Rating = Submersible Weather Alert = YesNormalized SKU: M50601UPC Code: 731797017680Icom M506 01 Literature Download  Quick Reference Guide  Owners Manual  Product BrochureIcom M506 01 Video

  Download Literature  Watch VideoIcom M506 31 VHF Fixed Mount RadiosM506 VHF Fixed Mount with Rear Mic & NMEA 0183/2000® - BlackOne Platform - Five Real World Solutions. A Fit For Every Need. Simplythe Best.The Rear Mic model includes NMEA 0183/2000®. Other built-in M506 features include: 2 minute last call voice recording Active noice cancelling 25W two-way hailer and foghorn Large dot-matrix display Intuitive user interface Built-in Class D DSC IPX8 (advance waterproof rating) COMMANDMICIV™ compatible NMEA 2000® & NMEA 0183 ConnectivityWith the plug-and-play functionality of NMEA 2000, the IC-M506 can easilyconnect to a NMEA 2000 network and interconnect with other equipment. Alsothe NMEA 0183 input/output can be used for external GPS/NAV interface.Last Call Voice RecordingThe built-in bidirectional active noise cancelling reduces background noise to up to 90% and improves both your transmitted voice and incoming call.25W Two-Way HailerWhen connected to an external hailer horn, you can talk to people on the deck or shore from the radio's microphone and can hear people's reply via the hailer horn. Foghorn and RX speaker functions are also available.Optional COMMANDMIC™ HM-195B/SWThe optional COMMANDMIC, HM-195B/SW provides 2nd station capability for using the IC-M506 from a separate cabin or tower. Most functions including DSC and AIS functions can be controlled from the COMMANDMIC and can be used as an intercom between the IC-M506 and the COMMANDMIC.Large LCD & Intuitive User InterfaceThe IC-M506 is equipped with 132x96 pixels dot-matrix display which is larger than the IC-M504 (132x64 pixels). Reading GPS, AIS, DSC and radio menus are easier than ever. The bottom line of the display shows the software key functions and the functions can be toggled with the left and right buttons.Features: 80dB (typical) IMD and channel selectivity MA-500TR AIS transponder and Marine-Commander™ compatible IPX8 submersible plus protection (1m depth for 60 minutes) Rear panel microphone version Optional voice scrambler Specifications: Channels - Available = All US, Canadian, International DSC Class = D Hailer/Intercom = Hailer Power - Output (Watts) = 25W/1W Remote Mic Capable = Yes Scrambler Capable = Yes Waterproof Rating = Submersible Weather Alert = Yes Normalized SKU: M50631UPC Code: 731797017659Icom M506 31 Literature Download   Quick Reference Guide  Owners Manual  Product BrochureIcom M506 31 Video

  Download LiteratureStandard Horizon GX2200W VHF Fixed Mount RadiosMatrix Fixed Mount VHF w/AIS & GPS - Class D DSC - 30W - WhiteThe GX2200 Matrix AIS/GPS features a 66 channel WAAS GPS antenna integrated into the front panel of the radio, now there is no need to hassle with wiring the radio to a GPS for DSC (Digital Selective Calling) or AIS (Automated Identification System). Out of the box and ready to go, acquiring AIS and AIS SART targets, DSC calling, position sharing, waypoint navigation, and navigation to DSC distress calls can all be performed with just a few simple steps. The MATRIX AIS/GPS displays AIS target information (MMSI, Call Sign, Ship Name, BRG, DST, SOG and COG) allows you to contact an AIS Ship directly using DSC, shows your vessels position in relation to AIS targets and alerts you when an AIS ship may be approaching too close to your location via the Closest Point of Approach (CPA) Alarm. One antenna input is all that is needed since the MATRIX AIS/GPS utilizes the VHF antenna to receive AIS targets from ships class A or B AIS transponders. The MATRIX AIS/GPS features an 80dB commercial grade receiver with Local/Distance attenuator, ITU Class D DSC, powerful 30 Watt PA/Loud Hailer with listen back and preprogrammed fog signals. Other great features include; diecast chassis for durability, user-changeable channel names, optional voice scrambler, ClearVoice noise canceling speaker microphone, 4.5 Watt audio output, NOAA Weather Alert, Programmable Scan, Priority Scan and Dual Watch. The MATRIX AIS/GPS is also capable of entering and saving up to 100 waypoints, which may be selected and navigated to by using a unique navigation compass display that shows your vessels SOG, COG, BRG (Bearing) and DST (Distance) to the waypoint. The MATRIX AIS/GPS is capable of being connected to a RAM3 Remote Access Microphone, allowing full control of all VHF, DSC and hailer functions remotely as well as adding an intercom between the radio and second station microphone. Another unique feature is the ability of the MATRIX AIS/GPS to "poll" (request and send) the GPS LAT/LON of another vessel and show the vessel's position on the radio's alphanumeric display or send the data to a compatible GPS chart plotter to be viewed directly on the chart. This is a great feature for maintaining contact with fishing or cruising "buddy" boats. The MATRIX AIS/GPS also has the capability of sending all AIS target information to a chart plotter via high speed NMEA data connection. The MATRIX AI/GPS is backed by an industry leading 3-year waterproof warranty.Features: Integrated 66 Channel WAAS GPS antenna AIS / AIS SART target display: MMSI, Call Sign, Ship Name, BRG, DST, SOG and COG 4800 or 38400 NMEA baud rate selection, for plotters with 1 NMEA port True and Magnetic bearing selection on AIS display Contact Class A or B AIS Ship with DSC Programmable CPA or TCPA collision avoidance alarms Meets ITU-R M493-13 Class D DSC (Digital Selective Calling) Submersible IPX7 (3.3 feet or 1 meter for 30 minutes) front panel 80dB Commercial grade receiver DSC position request and report functions 30 Watt PA/Loud Hailer with preprogrammed fog signals and listen back ClearVoice noise canceling speaker microphone with channel selection and 16/9 key GPS Compass, Waypoint and GPS status pages Navigation (LAT/LON, Time, SOG and COG) information shown on display Enter, Save and Navigate to waypoints with Compass page E2O (Easy-To-Operate) menu system User customizable soft keys for easy menu operation Versatile user-programmable scanning, priority scan and Dual Watch Oversized rotary channel knob with push to enter, backlit display and keys Local/Distance attenuator Optional connection for RAM3 second station remote microphone with AIS display Intercom between radio and RAM3 Voice Scambler (optional) Specifications:Channels - Available = NONE DSC Class = D Hailer/Intercom = NONE Power - Output (Watts) = 30W Remote Mic Capable = NONE Scrambler Capable = NONE Waterproof Rating = Submersible Weather Alert = NONENormalized SKU: GX2200WUPC Code: 788026140855Standard Horizon GX2200W Literature Download  Owners Manual

  Download LiteratureStandard Horizon GX2200B VHF Fixed Mount RadiosMatrix Fixed Mount VHF w/AIS & GPS - Class D DSC - 30W - BlackThe GX2200 Matrix AIS/GPS features a WAAS GPS antenna integrated into the front panel of the radio, now there is no need to hassle with wiring the radio to a GPS for DSC (Digital Selective Calling) or AIS (Automated Identification System). Out of the box and ready to go, acquiring AIS and AIS SART targets, DSC calling, position sharing, waypoint navigation, and navigation to DSC distress calls can all be performed with just a few simple steps. The MATRIX AIS/GPS displays AIS target information (MMSI, Call Sign, Ship Name, BRG, DST, SOG and COG) allows you to contact an AIS Ship directly using DSC, shows your vessels position in relation to AIS targets and alerts you when an AIS ship may be approaching too close to your location via the Closest Point of Approach (CPA) Alarm. One antenna input is all that is needed since the MATRIX AIS/GPS utilizes the VHF antenna to receive AIS targets from ships class A or B AIS transponders. The MATRIX AIS/GPS features an 80dB commercial grade receiver with Local/Distance attenuator, ITU Class D DSC, powerful 30 Watt PA/Loud Hailer with listen back and preprogrammed fog signals. Other great features include; diecast chassis for durability, user-changeable channel names, optional voice scrambler, ClearVoice noise canceling speaker microphone, 4.5 Watt audio output, NOAA Weather Alert, Programmable Scan, Priority Scan and Dual Watch. The MATRIX AIS/GPS is also capable of entering and saving up to 100 waypoints, which may be selected and navigated to by using a unique navigation compass display that shows your vessels SOG, COG, BRG (Bearing) and DST (Distance) to the waypoint. The MATRIX AIS/GPS is capable of being connected to a RAM3 Remote Access Microphone, allowing full control of all VHF, DSC and hailer functions remotely as well as adding an intercom between the radio and second station microphone. Another unique feature is the ability of the MATRIX AIS/GPS to "poll" (request and send) the GPS LAT/LON of another vessel and show the vessel's position on the radio's alphanumeric display or send the data to a compatible GPS chart plotter to be viewed directly on the chart. This is a great feature for maintaining contact with fishing or cruising "buddy" boats. The MATRIX AIS/GPS also has the capability of sending all AIS target information to a chart plotter via high speed NMEA data connection. The MATRIX AI/GPS is backed by an industry leading 3-year waterproof warranty.Features: Integrated dual channel AIS (Automatic Identification System) receiver AIS/AIS SART target display: MMSI, Call Sign, Ship Name, BRG, DST, SOG and COG 4800 or 38400 NMEA baud rate selection, for plotters with 1 NMEA port True and Magnetic bearing selection on AIS display Contact Class A or B AIS Ship with DSC Programmable CPA or TCPA collision avoidance alarms Meets ITU-R M493-13 Class D DSC (Digital Selective Calling) Submersible IPX7 (3.3 feet or 1 meter for 30 minutes) front panel 80dB Commercial grade receiver DSC position request and report functions 30 Watt PA/Loud Hailer with preprogrammed fog signals and listen back ClearVoice noise canceling speaker microphone with channel selection and 16/9 key GPS Compass, Waypoint and GPS status pages Navigation (LAT/LON, Time, SOG and COG) information shown on display Enter, Save and Navigate to waypoints with Compass page E2O (Easy-To-Operate) menu system User customizable soft keys for easy menu operation Versatile user-programmable scanning, priority scan and Dual Watch Oversized rotary channel knob with push to enter, backlit display and keys Local/Distance attenuator Optional connection for RAM3 second station remote microphone with AIS display Intercom between radio and RAM3 Voice Scrambler (optional) Specifications:Channels - Available = NONE DSC Class = D Hailer/Intercom = NONE Power - Output (Watts) = 30W Remote Mic Capable = NONE Scrambler Capable = NONE Waterproof Rating = Submersible Weather Alert = NONENormalized SKU: GX2200BUPC Code: 788026140862Standard Horizon GX2200B Literature Download  Owners Manual

  Download Literature  Watch VideoIcom M400BB VHF Fixed Mount RadiosM400BB VHF Marine Black BoxBlack Box Transceiver When Space Is At A PremiumIcom's M400BB is a VHF fixed mount with Class D DSC. The M400BB is a spacesaving unit, ideal for owners of compact boats and shipbuilders looking for a black box solution. The M400BB comprises only a black box main body and a supplied COMMANDMIC HM195 remote control microphone accessory. The two-piece radio set can easily be installed behind a wall or console-leaving a small or hidden footprint-and completely controlled from a remote position.Although compact in size, the M400BB possesses the same robust functionality found in Icom's M424 VHF fixed mount. Features include Class D DSC and the COMMANDMIC intuitive soft-key interface design. Active noise cancelling, a 10W loudspeaker and public address (PA) are built in for optimal audio performance. The M400MB is compatible with Icom's MA-500TR AIS transponder for additional safety at sea. Space-Saving, 2-Piece ConfigurationThe IC-M400BB consists of a two-piece, black box configuration. All function control including DSC operation, can be made from the COMMANDMIC™, HM-195B/SW, and the RF unit, IC-M400BB, can be installed in an out-of-sight place.Intuitive User InterfaceThe menu system is shared with Icom's latest models. The bottom line of the dot-matrix display shows the software key functions which can be toggled with the left and right buttons.Active Noise CancellingThe built-in bidirectional active noise cancelling reduces background noise to up to 90% and improves both your transmitted voice and incoming call. Hear and be heard more clearly.10W Loud Audio, Public Addres & FoghornBuilt-in 10W amplifier that increases the audio output from an additional external speaker. The public address function allows you to make an announcement from the microphone like a loud speaker, and the foghorn can also be emitted from the external speaker.Built-in Class D DSCThe built-in DSC watch function monitors Ch.70 (DSC channel) actively, even while you are receiving another channel. DSC functions include: distress, individual, group, all ships, urgency, safety, position request/report, polling request and DSC test calls.Common NMEA InterfaceWhen connected to an external GPS receiver, current position and time are shown on the Commandmic display. When receiving DSC information from another vessel, the radio can transfer it to a navigational device via NMEA 0183 connectivity.AIS Target Call With MA-500TRWhen connected to the optional MA-500TR Class B AIS transponder, the AIStarget call function allows you to set up an individual DSC call from the MA-500TR.Additional Features: MarineCommander™ compatible AquaQuake™ water draining function (HM-195B/SW) IPX7 waterproof protection both for IC-M400BB and HM-195B/SW(1m depth for 30 minutes) Dual/tri-watch function for monitoring Ch.16 and/or call channel Priority and normal scan Flexible installation Small foot print with 2-piece station Perfect for compact boats Comes with Commandmic (HM195B) DC Power cable Owner's manual Warranty: 3 years Specifications:Channels - Available = NONE DSC Class = D Hailer/Intercom = NONE Power - Output (Watts) = 25W, 1W Remote Mic Capable = NONE Scrambler Capable = NONE Waterproof Rating = Waterproof Weather Alert = NONENormalized SKU: M400BBUPC Code: 731797014733Icom M400BB Literature Download  Quick Reference GuideIcom M400BB Video

Simrad 000-10790-001 VHF Fixed Mount RadiosSimrad RS35 VHF/AIS Radio with Class D DSCThe Simrad RS35 marine VHF radio combines reliable performance with critical safety features for complete communication anywhere on the water. Features Class D DSC fixed-mount VHF transceiver with flush-mount option 25 W / 1 W transmission power Built-in, dual-channel AIS receiver with AIS plot functionality Extra-large, high-resolution LCD display NMEA 2000 connectivity plus NMEA0183 High-quality fist microphone with built-in speaker MOB feature Track Your Buddyr option Dual-watch / tri-watch and -can functions 22w PA/Hailer horn output with Listen Back feature 10 weather channel 20 user programmable names with MMSI Fully waterproof Specifications:Channels - Available = NONE DSC Class = D Hailer/Intercom = Hailer Power - Output (Watts) = 25w/1w Remote Mic Capable = Yes Scrambler Capable = NONE Waterproof Rating = Waterproof Weather Alert = NONENormalized SKU: 00010790001UPC Code: 9420024118757

  Download LiteratureStandard Horizon GX1700B VHF Fixed Mount RadiosExplorer GX1700B GPS Fixed Mount VHF - BlackFeatures: Integrated 12 Channel WAAS GPS receiver GPS antenna built-in to the front panel allows reception when bracket or flush mounted Ultra thin and compact rear case design (3.5" depth) Meets ITU-R M493-13 Class D DSC (Digital Selective Calling) Navigation to a DSC Distress Call with compass page GPS Compass display Navigation (LAT/LON, SOG, and COG) information shown on display Submersible JIS-8 1.5M (4.92Ft) for 30 minutes Noise canceling microphone with channel UP/DOWN, 16/9 and H/L keys NOAA weather channel selection with alert Programmable Scan, Priority Scan, and Dual Watch Preset Key stores up to 10 favorite channels, with scan function Customizable channel names Oversized dot matrix display NMEA Input and Output of GPS information to other NMEA compatible devices Programmable soft keys Capable of connecting to a Second Station RAM3 Remote Access Microphone Die-cast chassis 3-Year Waterproof Warranty Easy DSC & InstallationThe GX1700 makes DSC easy. With an internal 12 Channel GPS built into the front panel, there is no need to hassle with wiring the radio to a GPS for DSC. Out of the box and ready to go, DSC calling, position sharing, waypoint navigation, navigation to DSC distress calls can all be performed with just a few simple steps. Mounting a VHF radio has never been easier. The Explorer GPS has an ultra thin, compact rear case, only 3.5" in depth or half the depth of comparable VHF radios on the market. The Built-In WAAS GPS reciever and antenna mounted in the front panel also gives the flexibility to flush mount the radio in tight areas.GPS Compass - Navigate to WaypointsThe GX1700 is capable of entering and saving up to 100 waypoints. These waypoints may be selected and navigated to by using a unique navigation compass display that shows your vessels SOG, COG, BRG (Bearing) and DST (Distance) to the waypoint with the internal 12 channel WAAS GPS.ITU-R M493-11 Class D Digital Selective CallingThe GX1700 is an ITU-R M493 Class D class VHF with a separate Channel 70 receiver, which allows DSC calls to be received even when listening to communications. The DSC DISTRESS function when activated transmits a digital MAYDAY including vessel identification, Latitude / Longitude and time (with GPS connected), to facilitate prompt response. Additional calls that can be made are Individual, Urgency, Safety, Position Report and Send.RAM3 second station mic capableNeed to remotely control the VHF from your cockpit of fly bridge? The GX1700 is RAM3 remote mic capable to control all VHF, DSC functions at a second station.Big, bold displayThere is no question about it. With a big, bold display there is no mistaking the information. The contrast and brightness can be adjusted for situations where the radio cannot be mounted directly in front of you.DSC Position Polling and NMEA in/outputEasily share position information with other DSC equipped vessels using the position request and position reporting functions. With the push of a few buttons you can request the position of another vessel, or simply send your position information to the vessel you select.The GPS Position of a received DSC Distress or Position Request call can be shown on a compatible GPS Chart plotter simply by connecting 2 NMEA wires. In addition, the GX1700 may be setup to automatically poll the GPS position of up to 4 stations.Programmable Scan, Priority Scan and Dual WatchScanning is not an issue with the GX1700 The radio can be setup to scan any number of channels with or without a Channel 16 as the priority channel or simply can be setup to scan between a priority channel and one other channel (dual watch).Clearvoice noise reduction technologyThe GX1700 features Clear Voice Noise Reduction Technology eliminating unwanted background noises like engines and wind during transmission. This assures transmissions are crystal clear along with dedicated 16/9, H/L keys and channel selection.Programmable Channel NamesThe GX1700 is supplied from the factory preloaded with description of the use of Marine channels (16-Distress, 22A-USCG, 71-Pleasure...). The channel names may be customized to easily understand the use of each channel.NOAA Weather channels and Weather Alert10 NOAA and Canadian Weather channels are pre-programmed and easily selectable using the dedicated WX key. In addition, the GX1700 can be set to monitor WX channels and provide an audible alert to inform of pending storm advisories.3-Year waterproof warrantyIf the GX1700 fails for any reason (including water damage) during normal use for the first 3 years of ownership, STANDARD HORIZON will repair or replace it free, without hassles or charges. If it fails for anytime thereafter in normal use, for as long as the original purchaser owns the radio, STANDARD Horizon's Lifetime Flat Rate and Customer Loyalty Service Programs will cover it. Specifications:Channels - Available = NONE DSC Class = D Hailer/Intercom = N/A Power - Output (Watts) = 25/1 Remote Mic Capable = NONE Scrambler Capable = No Waterproof Rating = Submersible Weather Alert = YesNormalized SKU: GX1700BUPC Code: 788026134496Standard Horizon GX1700B Literature Download  Owners Manual

  Download LiteratureStandard Horizon GX1600B VHF Fixed Mount RadiosGX1600B Explorer Ultra Compact Class D DSC - BlackMounting a VHF radio has never been easier. The Explorer GX1600 has an ultra thin and compact rear case, only 3.5" in depth or half the depth of comparable VHF radios on the market. The rear case design also gives flexibility when flush mounting the radio in tight areas or bracket mounting the radio by taking up less dash space, and allowing more mounting options. The GX1600 has been designed to meet the NEW ITU-R M493-13 Class D DSC regulations with a dedicated channel 70 receiver that continuously watches for DSC calls. The GX1600S has the ability to accept a RAM3 Remote Access Microphone allowing full control of all radio and DSC functions from a second station. Additional features include, oversized full dot matrix display, user selectable Programmable Scan, Dual Watch, Ch16 Priority Scan, user changeable channel names, NOAA weather with alert, dedicated preset channel and a dedicated CH16/9 keys and 3 programmable soft keys. The microphone also has dedicated 16/9 and H/L keys, channel selection keys and uses ClearVoice noise reduction technology which reduces wind and engine noise when transmitting. Another unique feature of the GX1600 is the ability to "poll" (request and send) the GPS location of another vessel and show that vessel's position on the radio's display. Connecting a compatible GPS chart plotter will allow the GX1600 to repeat your position, SOG, COG and time on the full dot matrix display. The GX1600 is backed by an industry leading 3-year waterproof warranty. Features: Ultra thin and compact rear case design (3.5" depth) Meets ITU-R M493-13 Class D DSC (Digital Selective Calling) with Individual, All ship, Position Report, Request and Distress Navigation to a DSC Distress Call with compass page Automatically poll the GPS position of up to 4 ships using DSC Enter, Save, and Navigation to waypoint with Compass page GPS Compass display Navigation (LAT/LON, SOG, and COG) information shown on display Submersible JIS-8 1.5M (4.92Ft) for 30 minutes Noise canceling microphone with channel UP/DOWN, 16/9 and H/L keys NOAA weather channel selection with alert Programmable Scan, Priority Scan, and Dual Watch GPS repeating of position, SOG, COG and time Customizable channel names Oversized dot matrix display NMEA Input and Output Programmable soft keys Capable of connecting to a Second Station CMP30 Remote Access Microphone Die-cast chassis 3 Year Waterproof Warranty Specifications: DSC Class = D Hailer/Intercom = NONE Power - Output (Watts) = NONE Remote Mic Capable = NONE Scrambler Capable = NONE Waterproof Rating = Waterproof Weather Alert = Yes Channels - Available = NONE Normalized SKU: GX1600BUPC Code: 788026134465Standard Horizon GX1600B Literature Download   Owners Manual
