Simrad 000-10785-001 VHF Handheld RadiosSimrad HH36 Handheld VHFA feature-packed handheld, Class D, DSC marine VHF radio loaded with the latest technology, integrated GPS, loud and clear audio and navigational features that leave other handheld VHF radios in the shade. Great for use on any sized boat, for professional or leisure useExtra Large DisplayThe backlit LCD screen is the largest currently available on any handheld VHF and allows for crystal clear viewing.WaterproofThe HH36 is waterproof to JIS-7 Standard, making it an ideal marine radio for all vessels, including open boats and RIBsFloatsThe HH36 weighs less than 300g and will float if accidentally dropped overboardClass D DSCIncreases safety by enabling DSC calling with your boat's MMSI in an emergencyIntegrated GPSFor instant positioning and planningDedicated ChannelsDedicated Channel 16 and MOB buttons make the HH36 quick and easy to use in any situationEasy to useLarge push-to-talk button and soft keys enable use even when wearing glovesDual watchKeep an eye on two channels at the same timeSelectable transmit powerChoose from 1 or 5 Watts to suit your calling needsLong battery lifeUp to 11 hours battery life when used with 1W transmit power (GPS Off), up to 8 hours when used with 5W (GPS Off).'Get Buddy' featureTransmit your position at the touch of a buttonNMEA 0183There is an NMEA 0183® output on the HH36 charging cradleNavigation modeSee navigational information such as distance to waypoint, bearing etc.Plotter modeSee nearby waypoints at a glance Specifications:Battery Type = NONE Capacity - Battery (mAH) = 11Hrs/8Hrs Channels - Available = All US, Canadian, International Channels - Other = NONE IPX Rating = NONE Power - Output (Watts) = 1W/5W Speaker Mic = NONE Waterproof Rating = Submersible Weather Alert = NONENormalized SKU: 00010785001UPC Code: 9420024118702

Simrad 21113386 Autopilots"HLD350 MK2 and HLD2000 MK2 are hydraulic linear drives designed for boats with mechanical steering systems such as wire and cable steering (Edson, Whitlock, Teleflex). The HLD is a compact, assembled unit, consisting of a reversible hydraulic pump, a balanced hydraulic cylinder, by-pass valve and oil tank. Because of the direct connection to the rudder, the hydraulic linear drive can be used even if the hand steering should fail. This can be an important safety factor. The by-pass valve makes it possible to use the helm with little back drive force when the autopilot is switched off. The HLD350 MK2 and HLD2000 MK2L supersede the previous HLD350 and HLD2000L models.   Max Boat Displacement 20 tons Max Stroke 340 Max Torque 1460 Nm Drive Unit Max Thrust 500 Drive Unit Tiller Arm 298 mm \ 11.7 in POWERPower Supply 12V (3-10A) vDC"Normalized SKU: 21113386UPC Code: 809190046306

Simrad 000-10791-001 VHF AccessoriesSimrad HS35 Wireless HandsetUse your Simrad RS35 VHF/AIS Radio wherever you are on your boat, with the HS35 wireless handset. Easy to use and with full VHF functionality, this innovative handset gives you total freedom of movement on board your boat.Wireless ControlMake calls, scroll through channels, view AIS data and even initiate distress functions with this easy to use handset.IntercomCommunicate with the base station and other remote stations to relay vital information to crew members.Inductive ChargingSimply charge using the induction plate on the back of the Handset for 8 hours of battery lifeUp to 100m RangeThe long operational working range covers even the largest of vessels.Keypad LockAvoid unintentional operation, the handset also includes a handy belt clip and headphone jack for freeing your hands.Fully WaterproofCertified to IPX7 standard.Whats in the BoxHS Wireless HandsetCharging CradleBelt clipUser GuideMounting Hardware Normalized SKU: 00010791001UPC Code: 9420024118764

Simrad 000-12308-001 CompassHS60 GPS Compass NMEA2000 - Cable not IncludedThe Simrad HS60 GPS compass provides boaters with accurate heading and position data suitable for use with Simrad chartplotters, autopilots, radar, and AIS transponder systems. For applications such as autopilot, where precise heading information is required, the HS60 provides an all-in-one alternative to the traditional solution of a separate fluxgate compass and GPS receiver.Features: Compass and GPS receiver in one Tracks heading, position, heave, roll, and pitch Suitable for use with Simrad autopilot systems 2° RMS heading accuracy with dual internal GPS antennas 1M differential positioning accuracy (using SBAS supports WAAS, EGNOS, MSAS & GAGAN) 3M positioning accuracy (GPS only) Maintains an accurate heading for up to 3 minutes during GPS outages Compact flush or pole-mounted design NMEA 2000® connectivity (NMEA 0183® optional)The Simrad HS60 combines a high-speed 10 Hz, SBAS-compatible GPS receiver with integrated gyro and tilt sensors to provide smooth and accurate heading, position, heave, roll, and pitch information to Simrad chartplotters, autopilots, radar, and AIS systems.10 Hz GPS ReceiverThe HS60's high-speed GPS receiver delivers accurate and reliable positioning, updated ten times every second for smooth tracking of fast-moving powerboats. Fast startup means you won't get caught waiting for a position fix before you can get underway, with 'hot start' in less than a second and 'cold start' typically under a minute.Enhanced Positioning with SBASWith support for Satellite Based Augmentation Systems (SBAS) including WAAS (USA), EGNOS (Europe), MSAS (Japan) and GAGAN (India), the HS60 is able to use satellite-broadcast error correction data to deliver positional accuracy of up to 1M RMS, 95% of the time. Simrad COAST™ technology means the HS60 can even continue to deliver enhanced accuracy for up to 40 minutes if SBAS signal is lost, using the last error correction data received.In areas or conditions where SBAS is unavailable, the HS60 delivers 'single-point' positioning with accuracy of up to 3M RMS (95%). Actual accuracy experienced depends on environmental factors, the number of satellites in view, satellite geometry, and SBAS coverage where available.Accurate Heading with Dual GPS AntennasThe HS60 includes two separate GPS antennas within its compact casing, which are used to calculate heading with an accuracy of 2° RMS - greater accuracy than a magnetic fluxgate compass, without the cost and ongoing maintenance of a gyrocompass. With its dual GPS antennas, the HS60 provides an accurate heading even when your vessel is stationary, with a typical heading fix in less than ten seconds.Integrated Gyro & Tilt SensorsOnboard gyro and tilt sensors deliver heave, roll, and pitch information; offer faster and smoother heading updates than GPS alone; and provide heading updates during any temporary loss of GPS signal. Using these sensors, the HS60 is able to provide an accurate heading for up to three minutes during GPS outages, with an accuracy loss of no more than two degrees per minute and quick reacquisition of position once the signal has been reacquired.Simple Installation with NMEA 2000® ConnectivityThe compact and lightweight HS60 is supplied as a standalone system including mounting accessories. With GPS receiver, gyro and tilt sensors, and all other electronics integrated into the IP69 water-resistant antenna enclosure, there is no 'black box' required below deck.The HS60 connects to Simrad autopilot systems, NSS evo2 and NSO evo2 chartplotter/multifunction displays, and other systems requiring a NMEA 2000®-connected compass or GPS. A single NMEA 2000® bus connection is required for both power and data, standard drop cable with 5-pin micro connector sold separately.Specifications: Reverse Polarity Protection: Yes Power Consumption: 2.0W nominal Power Supply (Supply Voltage): 8 to 36 VDC Grounding: Isolated to enclosure Humidity: 100% non-condensing Product Width: 129mm / 5.1" Product Depth: 259mm / 10.2" Product Height: 45mm / 1.8" Baud Rates: 4800, 9600, 19200, 38400, 57600, 115200 Correction I/O Protocol: RTCM SC-104 Data I/O Protocol: NMEA 2000 (Optional NMEA 0183) Serial Ports: 2 full-duplex RS232 or 1 NMEA 2000 Compass Safe Distance [mm]: 300 Pitch/Roll Angle: 2° Rate of Turn: 90°/s maximum Receiver Type: GPS L1 Compass Heading Accuracy: 2° RMS Heading Fix: < 10s typical (valid position) Connectors: NMEA 2000 Connector: 5 Pin Male Micro Connector Specifications: Backlight = NONE Load Equivalence # (LEN) = NONE Mounting Style = NONE Output Frequency (mHz) = NONE Output Type = NONE Normalized SKU: 00012308001UPC Code: 000-12308-001

Simrad 000-10453-001 CompassHS70 GPS Compass Non-Magnetic Heading SourceExperience superior navigation from the accurate heading and positioning performance available with the HS70 GPS compass. The HS70 uses SBAS (WAAS, EGNOS, MSAS, etc.) for differential GPS positioning, providing a low cost and highly effective heading and position based smart antenna.The rugged and low profile enclosure provides two multipath-resistant antennas for accuracy, portability and simple installation. The smart antenna – measuring only a revolutionary 40cm/16” - mounts easily to a flat surface or pole. The stability and maintenance-free design of the HS70 provides traditional GPS positioning and heading at a low cost.Main Features Provides heading, positioning, heave, roll and pitch SimNet/NMEA2000 or NMEA0183 communication All in one antenna cable – No black box needed Excellent in-band and out-of-band interference rejection 0.75° heading accuracy in amazingly small form factor Extremely quick time-to-first-fix Differential positioning accuracy of 1.0 m, 95% of the time Integrated gyro and tilt sensors deliver fast start- up times and provide heading updates during temporary loss of GPS SBAS compatible (WAAS, EGNOS, MSAS, etc.) and optional external differential input COAST™ technology maintains differentially- corrected positioning for 40 minutes after loss of differential signal Specifications:Backlight = NONE Lubber Lines = NONE Mounting Style = NONE Read = NONENormalized SKU: 00010453001UPC Code: 000-10453-001

Simrad 000-15585-001 CompassHS75 GNSS CompassThe multi-GNSS HS75 supports GPS, GLONASS, BeiDou, Galileo, and QZSS for pinpoint global positioning and heading accuracy. The HS75 offers a powerful combination of simple installation, small form factor, and high performance. The compass - measuring only 35 cm in length - mounts easily to a flat surface or pole. Accurate HeadingAn accurate heading sensor is essential for autopilot, advanced radar features, and many other on-board electronics. The multi-GNSS HS75 supports GPS, GLONASS, BeiDou, Galileo, and QZSS for pinpoint global positioning and heading accuracy. The commercial-grade HS75 offers heading accuracy to within 0.75 degrees: much greater than a common magnetic rate compass, without the cost and maintenance of a gyrocompass.Unlike a standard GPS receiver, which can only estimate heading based on the movement of your boat, the HS75 provides an accurate heading even while your boat is stationary. Integrated gyro and tilt sensors offer enhanced performance, and provide a temporary source of heading data during any loss of GPS signal.Fast and Accurate PositioningThe HS75’s high-speed GPS receiver calculates your position up to 20 times every second, perfect for fast-moving powerboats and equipment that relies on high-speed position updates. Quick startup means you won’t get caught waiting for a position fix before you can get underway. Support for satellite based augmentation systems (SBAS) offers enhanced positional accuracy where available.Rate of Turn, Heave, Pitch, and RollThe HS75 also calculates your boat’s rate of turn, heave, pitch, and roll. Rate of turn is essential for optimal autopilot performance, while heave data is used by some sonar equipment to compensate for the effects of wave action. This additional data is output to compatible equipment over your boat’s NMEA 2000® network.Simple InstallationThe HS75 offers a plug-and-play installation, small form factor, and high performance. The compass - measuring only 35 cm in length - mounts easily to a flat surface or pole. Normalized SKU: 00015585001UPC Code: 9420064115310

Simrad 000-13951-001 AutopilotsSimrad Install Kit for AP44 #000-13951-001Normalized SKU: 00013951001UPC Code: 9420024163412

Simrad 000-14974-001 AccessoriesSimrad Install Kit for WM-4 SMA Adapter and Screws #000-14974-001Normalized SKU: 00014974001UPC Code: 9420024178959

Simrad 000-11773-001 Cases & CoversIS35 SuncoverProtective suncover for IS35. Normalized SKU: 00011773001UPC Code: 9420024134795

Simrad 000-13293-001 Navigational InstrumentsIS42 Speed/Depth Pack - IS42 Digital Display, DST800 Ducer & N2k Backbone Starter KitThe IS42 is a smart multi-purpose instrument featuring a full color display and modern glass helm styling. View wind, speed, depth, engine data, autopilot status and more at a glance, or add the optional OP12 keypad to take full control of your Simrad autopilot system. The IS42 integrates brilliantly with Simrad multifunction displays and glass helm systems, or can function as a standalone instrument display and autopilot controller aboard smaller vessels.Features: Optically bonded 4.1" color display Multi-purpose digital instrument Display wind, speed, depth, engine data, autopilot status and more Intuitive operation Easy installation Add an OP12 keypad for full Simrad autopilot control Compatible with Simrad AC12, AC42, NAC-2 and NAC-3 autopilot computers Low-profile glass helm design Low power consumption Certified NMEA 2000® connectivity Specifications: Dimensions: 118 x 115 x 28mm (4.6" x 4.5" x 1.1") Weight: 0.32kg (0.7lbs) Power Consumption: 1.8 Watts (MAX) Network Load: 3 LEN Color: Black Display Size: 4.1" (diagonal). 4:3 Aspect ratio Display Type: Transmissive TFT-LCD, bonded. White LED backlight Dsiplay Resolution: 320 x 240 pixels Illumination: White for day mode. Red, green, blue or white for night mode Environmental Protection, Waterproof: IPx7 Environmental Protection, Humidity: up to 95% RH Compass Safe Distance: 300mm (1.0") Temperature Operating: -15 to +55°C (5°F to +131°F) Temperature Storage: -30 to +70 °C (-22 to +158° F) Specifications:Digital/Analog = NONE Load Equivalence # (LEN) = NONE Screen Size = NONE Shape = NONENormalized SKU: 00013293001UPC Code: 9420024155189
