Simrad 000-13262-001 Network AccessoriesSimrad xSonic Pigtail Transducer Wiring Block AdapterModel: 000-13262-001The xSonic Pigtail Transducer Wiring Block Adapter allows you to connect a transducer without a connector (bare wires) to a display requiring a xSonic (9-pin) connection.Normalized SKU: 00013262001UPC Code: 9420024154618

Simrad 000-13914-001 Transducers"Simrad M260 9-pin In-hull transducer Model: 000-13914-001 UPC: 9420024162699 50 kHz with 19° beam width 200 kHz with 6° beam width Up to 900 m (3000 ft) range at 50 kHz 8 internal broadband ceramics In-Hull with plastic/urethane housing and yellow in-hull tank (can mount in existing M260 installed tanks) Suitable for fiberglass hulls Ideal for sportfishing and commercial vessels 8 m (25 ft) and up Recommended for use with the SonarHub sounder module, Simrad NSSevo3 sport multifunction displays The M260 is a plastic/urethane, in-hull Broadband transducer, ideal for smaller sportfishing and commercial vessels 8 m (25 ft) and up, fishing in depths of less than 900 m (3000 ft). Black 9 Pin connector The dual-frequency M260 includes an array of seven ceramic elements delivering 50 kHz with a 19° beam width, and a single 200 kHz element with a 6° beam width. 50 kHz low-frequency operation offers a maximum operational depth of 900 m (3000 ft), while 200 kHz high-frequency provides higher-resolution fish arches and bottom detail in shallower water."Normalized SKU: 00013914001UPC Code: 9420024162699

Simrad 000-13892-001 AccessoriesSimrad MI10 Dashmount microSD Card Reader #000-13892-001Normalized SKU: 00013892001UPC Code: 9420024162491

Simrad 24006199 AccessoriesMicro-C Female to SimNet Cable Simrad's Micro-C Female to SimNet 1M Cable Normalized SKU: 24006199UPC Code: 809190312579

Simrad 24006413 Network AccessoriesMicro-C Female to SimNetSimrad's Micro-C Female to SimNet 4M Cable SIMRAD MICRO-C FEMALE TO SIMNET 4M 24006413Normalized SKU: 24006413UPC Code: 809190341357

Simrad 000-10760-001 AccessoriesN2K Starter KitNMEA 2000 Network Starter Kit Includes: Network power cable 4.5M (15') N2K cable 3 x T-connectors 2 x network terminators Normalized SKU: 00010760001UPC Code: 9420024118382

Simrad 000-11769-001 AutopilotsSimrad NAC-1 Course Computer Model: 000-11769-001 UPC: 9420024134757 NAC-1 Autopilot Computer — The brains behind the Outboard Pilot and Drive Pilot systems. It contains the steering computer and electronics for the drive unit motor and clutch. What's in the Box: NAC-1 Power cord Normalized SKU: 00011769001UPC Code: 9420024134757

Simrad 000-15951-001 AutopilotsSimrad Outboard Pilot Hydraulic Pack with MKII Pump-1 AND Precision-9 Heading SensorModel: 000-15951-001 Easy to Install Dash-mount button for one-touch Auto/Standby activation Steer to Heading, Course or Route Automatic Turn Patters NAC-1 Plug & Socket connectors — no screw terminals or wire stripping necessary High efficiency, super-quiet 0.8L hydraulic gear pump (Pump-1 MKII) Add a second Helm station to a boat using the MFD Power steer commands — no need for additional hydraulics + steering wheel. Outboard Pilot is an MFD Autopilot add-on system designed for boats up to 30ft with single outboard motor. System packs contain everything you need to fit an Autopilot to Hydraulic or Cable steer outboard motors.Specifications Supply Voltag 12vDC Max Drive output 8A continuous, 16 Amp peak Interfaces Network 1xMicroC Feedback Variable voltage from HELM -1 drive unit Drive output To PUMP-1 or HELM-1 What's in the Box: NAC-1 AUTOPILOT COMPUTER PUMP-1 - 12V 0.8L For outboard pilot Autopilot pump fitting kit for ORB steering system Auto-Stby Button - Metal N2KEXT-2RD - 0.61 m (2-ft) NMEA 2000® cable N2KEXT-6RD - 1.82 m (6-ft) NMEA 2000® cable N2KEXT-15RD - 4.55 m (15-ft) NMEA 2000® cable TR-120-KIT - Set of 1 male and 1 female NMEA 2000® terminators MICRO-C Power cable only Low loss NMEA2000 4-way joiner Precision-9 Compass Normalized SKU: 00015951001UPC Code: 9420064128099

Simrad 000-15952-001 AutopilotsSimrad Outboard Pilot Hydraulic Pack with MKII Pump-1Model: 000-15952-001 Easy to Install Dash-mount button for one-touch Auto/Standby activation Steer to Heading, Course or Route Automatic Turn Patters NAC-1 Plug & Socket connectors — no screw terminals or wire stripping necessary High efficiency, super-quiet 0.8L hydraulic gear pump (Pump-1 MKII) Add a second Helm station to a boat using the MFD Power steer commands — no need for additional hydraulics + steering wheel. Outboard Pilot is an MFD Autopilot add-on system designed for boats up to 30ft with single outboard motor. System packs contain everything you need to fit an Autopilot to Hydraulic or Cable steer outboard motors.Specifications Supply Voltag 12vDC Max Drive output 8A continuous, 16 Amp peak Interfaces Network 1xMicroC Feedback Variable voltage from HELM -1 drive unit Drive output To PUMP-1 or HELM-1 What's in the Box: NAC-1 AUTOPILOT COMPUTER PUMP-1 - 12V 0.8L For outboard pilot Autopilot pump fitting kit for ORB steering system Auto-Stby Button - Metal N2KEXT-2RD - 0.61 m (2-ft) NMEA 2000® cable N2KEXT-6RD - 1.82 m (6-ft) NMEA 2000® cable N2KEXT-15RD - 4.55 m (15-ft) NMEA 2000® cable TR-120-KIT - Set of 1 male and 1 female NMEA 2000® terminators MICRO-C Power cable only Low loss NMEA2000 4-way joiner Point-1 AP Heading and GPS Sensor Normalized SKU: 00015952001UPC Code: 9420064128105

Simrad 000-13335-001 AutopilotsNAC-2 Autopilot Core Pack - NAC-2, Precision-9, RF25N & N2k Starter KitComprising of the high-current NAC-2 autopilot computer, Precision-9 compass and RF-25 rudder feedback unit ideal for smaller vessels, designed to run small hydraulic drives and mechanical drives for vessels up to 10M (33') in length.The NAC-2 Autopilot Computer is the brains behind your autopilot system. NAC-2 contains the control algorithms developed to helm a yacht across a broad range of weather conditions and sea-states, alongside the electronics needed to operate a hydraulic or mechanical drive unit, while also interfacing with other components including heading sensors and rudder feedback units. The NAC-2 was designed for boats up to 10M (33') in length and is suitable for low-current hydraulic drives, mechanical drives, or solenoid valves with a current rating of 8 Amps continuous (12 Amps peak).Precision-9 CompassThe Precision-9 Compass. Outputs Heading (20 hZ), Rate Of Turn (20 hZ), roll, and pitch (10 hZ) over the NMEA 2000® network.RF25N NMEA2000RF25N, Rudder Feedback Unit: With transmission link and 5M (16.5') NMEA2000 Micro-C cableN2k Backbone Starter KitNMEA 2000 Micro-C Network starter kit: Includes Network power cable, 4.5M (15') N2K cable, 3 x T-connectors, 2 x network terminatorsSpecifications: Operating temperature: -25°C to +55°C (13°F to 131°F) Protection: Splashproof, IPx5 Weight: 0.6 kg (1.3 lbs) Overall Dimensions: Width: 7.1" \ 180mm / Height: 2.2" \ 57mm Power supply: 9-31.2 V DC Load: 140 mA + drive unit load Performance: Drive: 8 A cont., 16A for 1s Network: 1xMicroC (NMEA2000) Feedback: Variable voltage/resistive 0-5V Drive output: To PUMP-1 or HELM-1 Power supply: 9-31.2 V DC Solenoid: 12/24V DC, common, load range 10mA to 10A, off current <1mA Clutch: 12/24V DC, min 10mA, max 3A Specifications:Boat Length - Max (Feet) = NONE Capacity - Max Ram (CU) = NONE Drive Type = NONE Feedback Type = NONE Pilot Type = NONE Remote Capable = NONE Turn Patterns = NONE Vessel Displacement - Max (Pounds) = NONENormalized SKU: 00013335001UPC Code: 9420024155639
