Simrad 000-13211-001 FishfindersGO9 XSE Chartplotter/Fishfinder w/Medium/High DownScan Transom Mount TransducerGO9 XSE Multi-function display with built in Echosounder, GPS and Wi-Fi. Super-bright, 9" multi-touch widescreen display with NMEA 2000 and radar interface. Includes Medium / DownScan transdcuerFeatures: Easy to use, High brightness 9" tablet style touchscreen Built-in advanced echosounder capable of displaying CHIRP, Forwardscan, Sidescan and Downscan images Radar port for connection to a Simrad solid state radar Direct Audio, Autopilot, communication and engine connection and control over NMEA2000 Built-in WiFi for mobile device mirroring and internet downloads of charting and software Easy to use multi touch software Safely and easily navigate using your favourite cartography (Insight, Navionics, CMAP) Determine depth, bottom type and find fish using one of the many echosounder technology options Quick and simple control of entertainment systems connected on NMEA2000 Vessel circuit control when connected to a C-zone digital switching system View and monitor engine data while underway Low Profile Glass dash styling Super bright widescreen display Built in Wi-Fi connectivity Software update notifications and downloads when connected to the internet Screen mirroring when connected to a mobile device Built in 10 Hz GPS antenna Dual Micro SD card slot Built in echosounder (Broadband & Chirp) Built in DownScan and Sidescan Imaging (transducer required) Built in Forwardscan Imaging (transducer required) Radar port for direct connection to Simrad 3G/4G or Halo Radar scanners Operable with OP40/OP50 Remote Advanced NMEA2000 networking Easy to Use Multi-Touch DisplayThe GO9 XSE offers true ease of use with intuitive touchscreen controls that smartphone and tablet users will find instantly familiar. Tap to create or select waypoints, pinch to zoom, or tap and drag to pan smoothly across charts. Simple home screen and menu layouts make all functions quickly accessible, with large and clearly-captioned icons that are easy to recognise and tap.Chartplotter Navigation & Waypoint ManagementThe GO9 XSE is a full-featured chartplotter, with support for the widest available range of cartography options including C-MAP® MAX-N, Navionics®, Insight®, Insight Genesis®, and NV Digital® Charts. Navigate confidently to destinations near and far, with the flexibility to choose charts that best fit your needs and location. Set and record those destinations easily with simple waypoint mangement: mark waypoints with a touch, and assign meaningful names that make it easy to look up your desired destination whether youve mapped out ten places or a thousand.Expand Your View with a Simrad Radar SolutionThe Simrad GO9 XSE is a full-featured radar display with plug-and-play connectivity to Simrad Broadband 3G, Broadband 4G, and Halo Pulse Compression radar systems. Cruise confidently through crowded harbours, navigate safely in poor visibility, keep an eye on distant weather cells, and find flocks of feeding birds that hint at good fishing spots. Automatic tuning helps to provide a clear radar picture in any conditions, while radar overlay combines radar data with navigational charts for an easy-to-interpret view of your surroundings.Fully Customisable InterfaceThe Simrad GO9 XSE is fully customisable to suit your vessel and your favourite on-water activities from power boating, to fishing, to water sports. Customise your home screen with shortcuts to the features you use most, and personalise it with your choice of wallpaper. Adjustable split-screen views and customisable panel layouts let you see everything you need on-screen at once, whatever your activity.Plan Smarter with TripIntel™ TechnologyDesigned for power boaters, TripIntel technology tracks and displays the key information you need to plan safe and enjoyable days on the water. Make smart decisions with fuel range overlaid on charts, easy access to current and future tide levels, and a detailed history of your previous trips including the route you took and how your boat performed.Built-in 10 Hz GPS receiver*With a high-speed GPS receiver updating your position ten times every second, the Simrad GO9 XSE is ideal for use aboard fast-moving RIBs and powerboats. Watch your boat's movement tracked smoothly, accurately, and in real-time, without 'jumping' from point to point on the display.Cruise Charting ViewDesigned with power boating in mind, the Simrad GO9 XSE offers a unique Cruise Charting page that brings together crucial navigation data and charts in one easily readable display. Choose the information most relevant to your crusing style and on-water activities with the ability to edit on-screen data items.NMEA 2000® Engine Monitoring & InstrumentationThe Simrad GO9 XSE connects to any NMEA 2000®-capable equipment aboard your vessel including outboard and inboard engines; fuel level and flow meters; speed, heading, and water temperature sensors; and much more. Create your own custom digital instrument displays, bringing a wealth of information to even the most crowded dash while keeping a clean look with as few gauges as possible.Watch Your Depth with Built-in SonarKnowing the true depth beneath your hull can help you enjoy your time on the water with fewer worries, and makes it easier to locate suitable anchorages in unfamiliar waters. With built-in sonar, just add a suitable sonar transducer for accurate, real-time depth tracking. A scrollable depth history view lets you track back and easily set waypoints for promising anchorages, while StructureScan Imaging combines DownScan and SideScan sonar to offer a picture-like view of the bottom beneath your vessel.Cruise Confidently with ForwardScan SonarUsing an optional ForwardScan transducer, this forward-looking sonar technology provides a clear two-dimensional image of the bottom in front of your vessel, allowing you to navigate shallow or poorly-charted waters with confidence. With real-time updates and a forward-looking view of up to eight times your current depth, ForwardScan lets you relax and enjoy a safer day on the water.Find fish with CHIRP & StructureScan® HD sidescan imagingWhether fishing is your life or just a casual hobby, any fishing trip will benefit from the extensive array of built-in sonar technology on the Simrad GO9 XSE. Add a suitable transducer, available separately or bundled with your display, and the GO9 XSE works as a powerful fishfinder with CHIRP-enabled broadband sonar for clear detection of fish throughout the water column. With an optional HDI or TotalScan transducer, the GO9 XSE also offers StructureScan HD sidescan imaging for a picture-like view of fish-holding structure beneath and around your boat.Simrad SonicHub&erg;2 & Bluetooth® Audio IntegrationIf you're not at home on the water without a good soundtrack, the Simrad SonicHub®2 marine audio system is the perfect companion to a GO9 XSE display. Stream music from Bluetooth® connected tablets, smartphones, and other mobile devices, play MP3 files from a USB flash drive, or listen to the SonicHub 2's built-in AM/FM radio. SonicHub 2 brings complete control of your audio entertainment to your GO9 XSE display, eliminating the need for a separate stereo head-unit and letting you listen to your music, your way.GoFree™ cloud enabled with Built-in Wi-FiWith Wi-Fi built in, the Simrad GO9 XSE provides direct access to GoFree cloud services including easy wireless map downloads, software updates, and more. Whether hooked up to your home Wi-Fi with your boat trailered in the driveway, logged in to your marina's Wi-Fi, or tethered to your smartphone out on the lake, you can access GoFree cloud services anywhere you have an internet connection. On the water, GoFree connects the Simrad GO9 XSE to your mobile devices, mirroring your display's screen on your smartphone or giving you full remote control from your tablet with the free GoFree Controller app.SiriusXM Weather IntegrationThe Simrad GO9 XSE is the only GO Series display compatible with SiriusXM Marine satellite weather, via the optional WM-3 expansion module, for real-time access to weather information right on your display. With onboard access to weather radar, surface buoy reports, NOAA Marine Zone forecasts and more, you can check out the conditions offshore before you even leave the dock. SiriusXM Marine is a subscription service, exclusively available within North America.* Built-in GPS receiver works in any bracket-mount installation, and when flush-mounted with most fibreglass hulls. When flush-mounted in a metal hulled vessel, an external GPS receiver such as the Simrad GS25 may be required.Specifications: Casing: PC/ABS Operating temp: -15°C to +55°C (+5°F to +131°F) Water ingress: IPX6 and 7 Weight (excluding mounting hardware): 1.315 kg (2.9 lbs) - GO9 XSE Screen brightness: 1200 nits Screen resolution: 480 x 800 (H x W) Viewing angle in degrees (typical value at contrast ratio = 10): L/R: 70, top: 50, bottom: 60 Operating voltage: 10 - 17 V DC Current draw at 13.6 V (sonar off, max B/L): 1 A Low power standby mode: yes Protection: reverse polarity and temporary over-voltage to 36 V Alarm output current: 1 A max Processor: iMX61 single core Conformity: CE, C-Tick NMEA 2000 (compliant): 1 port (Micro-C male) -,network load 1 LEN : 1 combined port Power and NMEA 2000 (7 pin connector) Sonar 1 port (9 pin connector) Radar 1 port (5 pin Ethernet connector) Card reader: Dual microSD Comes With: 000-12728-001 - MED/HIGH 455/800 9PIN 000-13702-001 - Gimbal bracket, GO9,V9 000-13700-001 - GO9 / V9 Bezel Replacement 000-13699-001 - GO9/V9 Dash mount kit 000-00128-001 - Power Cable 000-13698-001 - GO9 XSE Suncover Specifications:Basemap = Yes Card Format = Micro SD Cartography - Preloaded = No Cartography Brand = Navionics/C-Map Cartography Type = Platinum/Gold/Hotmaps Frequency = NONE Included Transducer = 000-12728-001 Internal/External Antenna = Internal Resolution (VxH) = 480 x 800 Screen Size = 9" Screen Type = Color Speed/Temp = NONE Touchscreen = Yes Transducer Type = Transom Mount Waterproof Rating = Waterproof Watts RMS - Max = NONE Waypoints/Routes = NONE Weather Capable = YesNormalized SKU: 00013211001UPC Code: 9420024153680

  Download LiteratureSimrad 000-11043-001 Network AccessoriesHigh-Sensitivity GPS/GLONASS Antennaw/Built-in Compass Deliver Faster, More Accurate Position-Update Rates For Smoother Chartplotting FunctionalityThe Simrad GS25 antenna provides best-in-class GPS/GLONASS positioning along with industry-leading, 10Hz GPS performance for smooth and accurate location updates. Equipped with an integrated electronic compass with GPS, the antenna provides accurate heading for stable chart orientation in the Heading Up mode, improved Course Over Ground at low speeds and radar overlay on your chart. All of these features are possible with affordable module options that easily connect through an NMEA 2000® network.CompatibilitySimrad NSE, NSO & NSS Multifunction DisplaysKey features of the GS25: NMEA 2000 antenna module offers rugged and precise position, and heading sensor Spot-on, around-the-world accuracy - supporting GPS and GLONASS, WAAS/EGNOS/MSAS; Galileo-capable with future software update Excellent time-to-first-fix, with 10Hz, multi-GNSS, high-speed updates - up to 10 times per second - for smoother and more accurate location updates Integrated electronic compass with GPS provides vessel heading with rate stabilization that provides heading output for accurate chart orientation in the Heading Up mode, improved Course Over Ground at low speed, and radar overlay (not intended for MARPA or Autopilot Control) Rugged design for all marine environments and fully waterproof Include spat/pole mount for easy installation and flexible boat location for optimal performance Independent source selection on any display Specifications:Load Equivalence # (LEN) = NONENormalized SKU: 00011043001UPC Code: 9420024122747Simrad 000-11043-001 Literature Download  Owners Manual

Simrad 000-15947-001 Radar SystemsSimrad Halo 200x 50w Pulse Compression Radar System without AntennaModel: 000-15947-001 HALO 2000 - 50W power for longer range (from 6m to up to 72nm) and higher-resolution target detection Advanced pulse compression technology with beam sharpening Simultaneous Dual Range operation Easy operation with Harbour, Offshore, Weather, and Bird modes Track up to 50 targets per defined area with ZoneTrack (two areas can be defined) VelocityTrack Doppler technology for collision avoidance Dangerous Target Alerts for radar and AIS targets Ready instantly from standby, and in 16-25 seconds from power-on Benefit from safer navigation and unmatched ease of use with the new HALO® 2000 and 3000 Open Array radars. Advanced Pulse Compression technology allows you to detect birds, hazards and storms with superior precision across both short and long distances. While the range of Preset Modes and enhanced power provide constant peace of mind.The HALO® 2000 radar offers a premium experience on the water. An impressive 50 W of power — equivalent to a 12 kW magnetron radar — delivers an unrivaled combination of short- and long-range coverage that enables you to see targets from six meters (20 feet) out to 72 nautical miles with exceptional clarity. Pulse Compression technology powers confident navigation through marinas, and superior storm and hazard detection across a greater distance. The HALO® array series not only increase situational awareness and collision avoidance but also offer higher-resolution target detection you won’t find in lower-powered radars.The HALO 2000 series boast an array of new features that make navigation safer and offer peace of mind. ZoneTrack™ brings the best of professional boating technology to recreational users, allowing them to track up to 50 vessels within a defined area, automatically detecting their course and speed. HALO’s Dangerous Target Alerts highlight range, graphical bearing, and heading of other vessels relative to yours. Meanwhile, VelocityTrack™ uses Doppler technology to show targets color-coded so you can identify potential threats at a glance. Because, when it comes to safety, situational awareness is everything.The next generation of pulse compression radars, HALO 2000 and 3000 build on the features that have made HALO an established choice for boaters across the globe. The solid-state technology gets you up and running quickly, and HALO’s low-power pulsed transmissions make it safe to run in harbors and marinas. Dual Range mode allows you to keep an eye on distant weather cells while monitoring channel markers and high-speed watercraft up close. Advanced digital signal processing gives you a clearer view of targets, helping eliminate sea clutter, while Beam Sharpening provides enhanced separation between small or distant targets. Finally, HALO 2000 and 3000 have the same footprint as their predecessors, making it easy to upgrade your current system. It’s also compatible with a range of Simrad® chart plotters, including NSS™, NSX™, NSO™, and GO™.Designed with an intuitive interface HALO arrays make operation easier with smart features like Harbour, Offshore, Bird, and Weather modes. These Preset Modes require no manual tuning — just select your chosen mode and go. This simple approach also extends to fishing, with HALO’s powerful bird-finding capability which enables boaters to find flocks of birds and — more importantly — schools of fish at a distance.Specifications Environmental Operating temperature -25°C to +55°C (-13°F to +131°F) Relative humidity IEC60945 Exposed product Vibration IEC60945 Exposed product UV IEC60945 Exposed product Waterproofing IPX6 for the pedestal and antenna, IPX5 for the RI-50 interface module Relative wind velocity HALO 2000 and HALO 3000 radars with 3 ft, 4 ft or 6 ft antenna have a wind rating of 80 knots at 48 rpm in both 24V and 12V systems. Power Power consumption 235 W (peak, 12V) at maximum wind velocity, 380 W (peak, 24V) at maximum wind velocity, 45-60 W (average) at zero wind velocity, 11 W (average) in standby mode. Refers to RI-50 input terminals DC Input Radar system input 12 OR 24 V DC into the RI-50: 12 V Systems 10.8 - 15 V DC, 24 V Systems 20 - 31.2 V DC. Pedestal voltage input is 50 V DC nominal generated by RI-50 Power up time 30-40 seconds from POWER OFF to TRANSMIT Physical Height 429 mm (16.88") with antenna mounted Antenna swing circle diameter 3 ft model: 3.75 ft / 1142 mm / 44.96": 4 ft model: 4.73 ft / 1443 mm / 56.81": 6 ft model: 6.72 ft / 2047 mm / 80.59" Pedestal weight 20.3 Kg (44.8lb) RI-50 weight 1.6 Kg (3.5 lb) 10 m (33 ft) cable weight 1.6 Kg (3.5 lb) Antenna (Sold Separately) Rotation speed 16 to 48 rpm depending on operating mode Beam width 3 ft model: 2.4°+/-10% (-3 dB width) — 1.7° with Beam sharpening mode on: 4 ft model: 1.8°+/-10% (-3 dB width) — 1.3° with Beam sharpening mode on:6 ft model: 1.2°+/-10% (-3 dB width) — 0.8° with Beam sharpening mode on Beam width Vertical 25° +/-10 % (-3 dB width) Plane of polarization Horizontal polarization Sidelobe level 3 ft Below -23 dB max. (within ±10°), Below -30 dB max. (outside ±10°) Side lobe level 4 ft Below -23 dB max. (within ±10°), Below -30 dB max. (outside ±10°) Side lobe level 6 ft Below -23 dB max. (within ±10°), Below -30 dB max. (outside ±10°) Radar Peak power output 50 W ± 10% under any transmit condition — up to 10% duty cycle max Transmitter Solid state module with no long-term transmitter power degradation Transmitter frequency Synthesized - Upper half of X-Band 9.390 - 9.495 GHz Pulse length 0.04 usec Chirp length 2-64 usec Chirp bandwidth 2-48 MHz. Up to 1 pulse and 4 chirps in a burst with burst repetition rate of 500-3000Hz. Range and mode dependent. Effective pulse compression ratio less than 150 in all modes. Instrumented range 72 nm SART/RACON triggering Yes — trigger distance: about 1nm max — weather, sea state, and SART position dependent Duplexer Circulator and isolator LNA GaAs front-end IF section Center frequency: 31.25 MHz Bandwidth: 50 MHz max.* A/D; 16 bit 125 MSPS *Narrower bandwidths defined by signal processing Noise figure 5 dB (Min) at antenna input Compass safe distance; Pedestal STD. 1.0 m (3.3 ft), Steer 0.5 m (1.6 ft) Compass safe distance; RI-50 1.0 m (3.3 ft) Other Communication ports Ethernet 10/100 Base-T RJ-45 for radar data and control Transmit synchronization RS-422 output Remote power on yes Antenna park hold Yes (while radar is unpowered) Motor Brushless with solid state commutation with electromagnetic braking for parking What's in the Box: Halo 200x Pedestal RI-50 Power Supply 10m Power and Ethernet cable Normalized SKU: 00015947001

Simrad 000-15761-001 Radar SystemsSimrad Halo 200x 50w Pulse Compression Radar System without AntennaModel: 000-15961-001 HALO 2000 - 50W power for longer range (from 6m to up to 72nm) and higher-resolution target detection Advanced pulse compression technology with beam sharpening Simultaneous Dual Range operation Easy operation with Harbour, Offshore, Weather, and Bird modes Track up to 50 targets per defined area with ZoneTrack (two areas can be defined) VelocityTrack Doppler technology for collision avoidance Dangerous Target Alerts for radar and AIS targets Ready instantly from standby, and in 16-25 seconds from power-on Benefit from safer navigation and unmatched ease of use with the new HALO® 2000 and 3000 Open Array radars. Advanced Pulse Compression technology allows you to detect birds, hazards and storms with superior precision across both short and long distances. While the range of Preset Modes and enhanced power provide constant peace of mind.The HALO® 2000 radar offers a premium experience on the water. An impressive 50 W of power — equivalent to a 12 kW magnetron radar — delivers an unrivaled combination of short- and long-range coverage that enables you to see targets from six meters (20 feet) out to 72 nautical miles with exceptional clarity. Pulse Compression technology powers confident navigation through marinas, and superior storm and hazard detection across a greater distance. The HALO® array series not only increase situational awareness and collision avoidance but also offer higher-resolution target detection you won’t find in lower-powered radars.The HALO 2000 series boast an array of new features that make navigation safer and offer peace of mind. ZoneTrack™ brings the best of professional boating technology to recreational users, allowing them to track up to 50 vessels within a defined area, automatically detecting their course and speed. HALO’s Dangerous Target Alerts highlight range, graphical bearing, and heading of other vessels relative to yours. Meanwhile, VelocityTrack™ uses Doppler technology to show targets color-coded so you can identify potential threats at a glance. Because, when it comes to safety, situational awareness is everything.The next generation of pulse compression radars, HALO 2000 and 3000 build on the features that have made HALO an established choice for boaters across the globe. The solid-state technology gets you up and running quickly, and HALO’s low-power pulsed transmissions make it safe to run in harbors and marinas. Dual Range mode allows you to keep an eye on distant weather cells while monitoring channel markers and high-speed watercraft up close. Advanced digital signal processing gives you a clearer view of targets, helping eliminate sea clutter, while Beam Sharpening provides enhanced separation between small or distant targets. Finally, HALO 2000 and 3000 have the same footprint as their predecessors, making it easy to upgrade your current system. It’s also compatible with a range of Simrad® chart plotters, including NSS™, NSX™, NSO™, and GO™.Designed with an intuitive interface HALO arrays make operation easier with smart features like Harbour, Offshore, Bird, and Weather modes. These Preset Modes require no manual tuning — just select your chosen mode and go. This simple approach also extends to fishing, with HALO’s powerful bird-finding capability which enables boaters to find flocks of birds and — more importantly — schools of fish at a distance.Specifications Environmental Operating temperature -25°C to +55°C (-13°F to +131°F) Relative humidity IEC60945 Exposed product Vibration IEC60945 Exposed product UV IEC60945 Exposed product Waterproofing IPX6 for the pedestal and antenna, IPX5 for the RI-50 interface module Relative wind velocity HALO 2000 and HALO 3000 radars with 3 ft, 4 ft or 6 ft antenna have a wind rating of 80 knots at 48 rpm in both 24V and 12V systems. Power Power consumption 235 W (peak, 12V) at maximum wind velocity, 380 W (peak, 24V) at maximum wind velocity, 45-60 W (average) at zero wind velocity, 11 W (average) in standby mode. Refers to RI-50 input terminals DC Input Radar system input 12 OR 24 V DC into the RI-50: 12 V Systems 10.8 - 15 V DC, 24 V Systems 20 - 31.2 V DC. Pedestal voltage input is 50 V DC nominal generated by RI-50 Power up time 30-40 seconds from POWER OFF to TRANSMIT Physical Height 429 mm (16.88") with antenna mounted Antenna swing circle diameter 3 ft model: 3.75 ft / 1142 mm / 44.96": 4 ft model: 4.73 ft / 1443 mm / 56.81": 6 ft model: 6.72 ft / 2047 mm / 80.59" Pedestal weight 20.3 Kg (44.8lb) RI-50 weight 1.6 Kg (3.5 lb) 10 m (33 ft) cable weight 1.6 Kg (3.5 lb) Antenna (Sold Separately) Rotation speed 16 to 48 rpm depending on operating mode Beam width 3 ft model: 2.4°+/-10% (-3 dB width) — 1.7° with Beam sharpening mode on: 4 ft model: 1.8°+/-10% (-3 dB width) — 1.3° with Beam sharpening mode on:6 ft model: 1.2°+/-10% (-3 dB width) — 0.8° with Beam sharpening mode on Beam width Vertical 25° +/-10 % (-3 dB width) Plane of polarization Horizontal polarization Sidelobe level 3 ft Below -23 dB max. (within ±10°), Below -30 dB max. (outside ±10°) Side lobe level 4 ft Below -23 dB max. (within ±10°), Below -30 dB max. (outside ±10°) Side lobe level 6 ft Below -23 dB max. (within ±10°), Below -30 dB max. (outside ±10°) Radar Peak power output 50 W ± 10% under any transmit condition — up to 10% duty cycle max Transmitter Solid state module with no long-term transmitter power degradation Transmitter frequency Synthesized - Upper half of X-Band 9.390 - 9.495 GHz Pulse length 0.04 usec Chirp length 2-64 usec Chirp bandwidth 2-48 MHz. Up to 1 pulse and 4 chirps in a burst with burst repetition rate of 500-3000Hz. Range and mode dependent. Effective pulse compression ratio less than 150 in all modes. Instrumented range 72 nm SART/RACON triggering Yes — trigger distance: about 1nm max — weather, sea state, and SART position dependent Duplexer Circulator and isolator LNA GaAs front-end IF section Center frequency: 31.25 MHz Bandwidth: 50 MHz max.* A/D; 16 bit 125 MSPS *Narrower bandwidths defined by signal processing Noise figure 5 dB (Min) at antenna input Compass safe distance; Pedestal STD. 1.0 m (3.3 ft), Steer 0.5 m (1.6 ft) Compass safe distance; RI-50 1.0 m (3.3 ft) Other Communication ports Ethernet 10/100 Base-T RJ-45 for radar data and control Transmit synchronization RS-422 output Remote power on yes Antenna park hold Yes (while radar is unpowered) Motor Brushless with solid state commutation with electromagnetic braking for parking What's in the Box: Halo 200x Pedestal RI-50 Power Supply 20m Power and Ethernet cable Normalized SKU: 00015761001

Simrad 000-11469-001 Radar DomeHALO™-3 Pulse Compression Radar with 3' Antenna, RI-12 Interface Module & 20M CableCombining the best characteristics of traditional pulse and FMCW broadband radar systems, Simrad's Halo™ Radar uses Pulse Compression technology to provide an unprecedented mix of long and short detection range, high target definition, and minimal clutter. Solid State technology means minimal warm-up time and maximum ocean-going reliability, while compliance with upcoming Low Emission standards makes Halo Radar safe to run in anchorages and marinas.Key Features: True 48nm range with 3' open array antenna Beam Sharpening with Target Separation Control Dual Range operation with NSS/NSO multifunction displays Advanced signal processing with Harbour, Offshore, Weather, Bird, and Custom modes. Other modes available soon. High-speed 48RPM operation InstantOn™, ready in 16-25 seconds from power-on, instant from standby MARPA target tracking, up to 10 targets (20 with dual range) Low electromagnetic emissions and radiation Low power consumption with 12/24V operation Ethernet connectivity Unique blue LED accent lighting in pedestal with brightness control Solid-State with Pulse Compression TechnologySimrad Halo Radar is the world's first high performance, solid-state radar with pulse compression technology designed specifically for recreational mariners. Unlike traditional pulse radar, Halo Radar isn't reliant on a high-powered magnetron (vacuum tube) to transmit. Instead, Halo Radar uses solid-state electronics and low-power 25W pulsed, frequency-swept transmission bursts to deliver pulse radar-like range and resolution, without the associated warm-up time, power consumption, or electromagnetic emissions.48nm RangeHalo Radar delivers a maximum range comparable to traditional 6kW pulse radar, at up to 48nm with the HALO-3 Radar's 3' open array antenna. It offers unprecedented 10M (30') minimum range, peering into that pulse-radar blind spot where once only FMCW (3G/4G) Broadband Radar could operate.Beam SharpeningWhether you're looking at a flock of birds or a string of channel markers, separating one radar target from another is key. Beam Sharpening with Target Separation Control provides unmatched target resolution, granting the Halo Pulse Compression Radar's 3' open array antenna the same effective target resolution as a 4' array without beam sharpening.Dual Range OperationWith Dual Range, Halo Radar functions like two arrays in one - monitor two distance ranges simultaneously with independent displays, controls, and totally independent MARPA target tracking. Take full advantage of Halo Radar's combination of short-, mid-, and long-range performance to keep an eye on faraway weather cells, while monitoring channel markers and high speed watercraft up close. Dual Range operation is available with Simrad NSS and NSO multifunction display systems.Target DetectionThe HALO-3 Radar offers excellent target detection for its compact 3' open array. For enhanced target detection in line with tough IEC 62388 Annex D specifications, consider our larger HALO-4 Radar or HALO-6 Radar arrays.ARPA Target TrackingAutomatically track up to 10 user-selected radar targets, displaying CPA (closest point of approach) and TCPA (time to closest point of approach). Up to 20 different targets can be tracked in Dual Range mode, with 10 targets per screen. MARPA functionality requires a heading sensor and GPS.Advanced Signal ProcessingHalo Radar employs advanced signal processing for digital azimuth and range sidelobe reduction, enhancing discrimination of small targets such as channel markers from larger adjacent targets such as ships and bridges. In addition, Directional Sea Clutter Rejection dynamically changes gain in the sweep to allow smaller targets to be seen in the leeward. Sector Blanking eliminates unwanted reflections, for less clutter on screen.8 Usage Modes with Automatic Harbour/Offshore SelectionHarbour, Offshore, Weather, and Bird modes tune Halo Radar's advanced signal processing to help ensure the targets you're interested in can be seen vividly - even in the toughest environmental conditions. Automatic selection of Harbour and Offshore modes configures your Halo Radar to suit your =surroundings, while a 'Custom' mode enables easy manual tuning to suit any purpose or conditionHigh Speed Mode Halo Pulse Compression Radar provides rapid position updates, with high speed operation up to 48RPM (mode and range dependent). Simrad quality construction and Halo Radar's brushless motor with advanced helical geartrain design ensure exceptionally quiet operation, especially at 48RPM.InstantOn™Collision hazards won't wait for your radar to start up - why should you? Halo Radar's solid-state technology is ready instantly from standby, and in just 16-25 seconds from power-on to fully-operational. Avoid the 2-3 minute warm-up time associated with traditional pulse radar, and trust Halo Radar to produce an immediate, accurate radar image when you need it.High ReliabilityHalo Radar is built to last, with its solid-state transceiver meaning no magnetron to replace, and no manual tuning required as the magnetron heats up or ages. Similarly, a solid-state brushless motor driver means no motor brushes to wear out and replace. Be confident that Halo Radar will operate at high speed in winds up to 70 knots, year after year.Low Electromagnetic EmissionsUnlike traditional pulse radar, Halo Radar's low-power pulsed transmissions meet upcoming Low Emission standards. This makes Halo Radar safe to run in anchorages and marinas, providing enhanced radar coverage at the very start and end of each journey.Low Power Consumption Halo Radar uses 40W average with no wind, and no more than 200W at maximum wind velocity. Experience even greater power savings in standby with just 7W power usage, versus 10/15W for pulse radar. With its low power consumption and support for 12/24 volt DC systems, Halo Radar is ideal for small to mid-sized powerboats.Ethernet ConnectivitySimrad Halo Pulse Compression Radar connects to any Simrad NSS or NSO multifunction display system via Ethernet, with a bulkhead-mounted interface box below deck. Antenna installation is simple and elegant, with the same thin cable and small-diameter connectors as our 3G/4G Broadband radars.Uncompromising AestheticsBringing the range and reliability of Halo Pulse Compression Radar to your boat doesn't mean compromising on aesthetics. Halo Radar's sleek open-array antenna sits atop a uniquely curved pedestal, a departure from traditional boxy and utilitarian radar designs. Display your Halo Radar on the water with soft-glow, dual-beam Blue LED accent lighting, integrated into the pedestal and customizable with 4-level brightness control.*Halo™ Pulse Compression Radar's blue 4 level static accent pedestal lighting may not be approved for use in your boating location. Please check your local boating regulations before turning the blue accent lights ON.***MARPA functionality will not be available on Halo Radar at initial release, but will be enabled via software update in Q3 2015.**** Specifications:Power - Output (Kilowatts) = 6kW Hor/Vert Beam Width = NONE Array Size (Inches) = 3' Range - Max (Miles) = 48nmNormalized SKU: 00011469001UPC Code: 9420024128800

Simrad 000-15948-001 Radar SystemsSimrad Halo 300x 130w Pulse Compression Radar System without AntennaModel: 000-15948-001 HALO 3000 - 130W power for longer range (from 6m to up to 96nm) and higher-resolution target detection Advanced pulse compression technology with beam sharpening Simultaneous Dual Range operation Easy operation with Harbour, Offshore, Weather, and Bird modes Track up to 50 targets per defined area with ZoneTrack (two areas can be defined) VelocityTrack Doppler technology for collision avoidance Dangerous Target Alerts for radar and AIS targets Ready instantly from standby, and in 16-25 seconds from power-on The HALO® 3000 array radar offers a premium experience on the water. An impressive 130 W of power — equivalent to a 25 kW magnetron radar — delivers an unrivaled combination of short- and long-range coverage that enables you to see targets from six meters (20 feet) out to 96 nautical miles with exceptional clarity. Pulse Compression technology powers confident navigation through marinas, and superior storm and hazard detection across a greater distance. The HALO® array series not only increase situational awareness and collision avoidance but also offer higher-resolution target detection you won’t find in lower-powered radars.The HALO 3000-series boast an array of new features that make navigation safer and offer peace of mind. ZoneTrack™ brings the best of professional boating technology to recreational users, allowing them to track up to 50 vessels within a defined area, automatically detecting their course and speed. HALO’s Dangerous Target Alerts highlight range, graphical bearing, and heading of other vessels relative to yours. Meanwhile, VelocityTrack™ uses Doppler technology to show targets color-coded so you can identify potential threats at a glance. Because, when it comes to safety, situational awareness is everything.The next generation of pulse compression radars, HALO 2000 and 3000 build on the features that have made HALO an established choice for boaters across the globe. The solid-state technology gets you up and running quickly, and HALO’s low-power pulsed transmissions make it safe to run in harbors and marinas. Dual Range mode allows you to keep an eye on distant weather cells while monitoring channel markers and high-speed watercraft up close. Advanced digital signal processing gives you a clearer view of targets, helping eliminate sea clutter, while Beam Sharpening provides enhanced separation between small or distant targets. Finally, HALO 2000 and 3000 have the same footprint as their predecessors, making it easy to upgrade your current system. It’s also compatible with a range of Simrad® chart plotters, including NSS™, NSX™, NSO™, and GO™.Designed with an intuitive interface HALO arrays make operation easier with smart features like Harbour, Offshore, Bird, and Weather modes. These Preset Modes require no manual tuning — just select your chosen mode and go. This simple approach also extends to fishing, with HALO’s powerful bird-finding capability which enables boaters to find flocks of birds and — more importantly — schools of fish at a distance.Designed with an intuitive interface, HALO 3000 has smart features like Harbour, Offshore, Bird, and Weather modes. These Preset Modes require no manual tuning — just select your chosen mode and go. This simplified approach also extends to fishing, with HALO 3000’s powerful Bird+ mode — a must-have tool for sportfishing enthusiasts. Bird+ mode allows you to focus the full 130W of HALO 3000’s power on bird finding, enabling boaters to find schools of fish up to 8nm away.Specifications Environmental Operating temperature -25°C to +55°C (-13°F to +131°F) Relative humidity IEC60945 Exposed product Vibration IEC60945 Exposed product UV IEC60945 Exposed product Waterproofing IPX6 for the pedestal and antenna, IPX5 for the RI-50 interface module Relative wind velocity HALO 2000 and HALO 3000 radars with 3 ft, 4 ft or 6 ft antenna have a wind rating of 80 knots at 48 rpm in both 24V and 12V systems. Power Power consumption 250 W (peak, 12V) at maximum wind velocity 395 W (peak, 24V) at maximum wind velocity 45-75 W (average) at zero wind velocity 11 W (average) in standby mode. Refers to RI-50 input terminals Power up time 30-40 seconds from POWER OFF to TRANSMIT Physical Height 429 mm (16.88") with antenna mounted Antenna swing circle diameter 3 ft model: 3.75 ft / 1142 mm / 44.96": 4 ft model: 4.73 ft / 1443 mm / 56.81": 6 ft model: 6.72 ft / 2047 mm / 80.59" Pedestal weight 20.3 Kg (44.8lb) RI-50 weight 1.6 Kg (3.5 lb) 10 m (33 ft) cable weight 1.6 Kg (3.5 lb) Antenna (Sold Separately) Rotation speed 16 to 48 rpm depending on operating mode Beam width 3 ft model: 2.4°+/-10% (-3 dB width) — 1.7° with Beam sharpening mode on: 4 ft model: 1.8°+/-10% (-3 dB width) — 1.3° with Beam sharpening mode on:6 ft model: 1.2°+/-10% (-3 dB width) — 0.8° with Beam sharpening mode on Beam width Vertical 25° +/-10 % (-3 dB width) Plane of polarization Horizontal polarization Sidelobe level 3 ft Below -23 dB max. (within ±10°), Below -30 dB max. (outside ±10°) Side lobe level 4 ft Below -23 dB max. (within ±10°), Below -30 dB max. (outside ±10°) Side lobe level 6 ft Below -23 dB max. (within ±10°), Below -30 dB max. (outside ±10°) Radar Peak power output 130 W ± 10% under any transmit condition — up to 13% duty cycle max Transmitter Solid state module with no long-term transmitter power degradation Transmitter frequency Synthesized - Upper half of X-Band 9.390 - 9.495 GHz Pulse length 0.04 usec Chirp length 2-64 usec Chirp bandwidth 2-48 MHz. Up to 1 pulse and 4 chirps in a burst with burst repetition rate of 500-3000Hz. Range and mode dependent. Effective pulse compression ratio less than 150 in all modes. Instrumented range 96 nm SART/RACON triggering Yes — trigger distance: about 1nm max — weather, sea state, and SART position dependent Duplexer Circulator and isolator LNA GaAs front-end IF section Center frequency: 31.25 MHz Bandwidth: 50 MHz max.* A/D; 16 bit 125 MSPS *Narrower bandwidths defined by signal processing Noise figure 5 dB (Min) at antenna input Compass safe distance; Pedestal STD. 1.0 m (3.3 ft), Steer 0.5 m (1.6 ft) Compass safe distance; RI-50 1.0 m (3.3 ft) Other Communication ports Ethernet 10/100 Base-T RJ-45 for radar data and control Transmit synchronization RS-422 output Remote power on yes Antenna park hold Yes (while radar is unpowered) Motor Brushless with solid state commutation with electromagnetic braking for parking What's in the Box: Halo 300x Pedestal RI-50 Power Supply 10m Power and Ethernet cable Normalized SKU: 00015948001

Simrad 000-15765-001 Radar SystemsSimrad Halo 300x 130w Pulse Compression Radar System without AntennaModel: 000-15765-001 HALO 3000 - 130W power for longer range (from 6m to up to 96nm) and higher-resolution target detection Advanced pulse compression technology with beam sharpening Simultaneous Dual Range operation Easy operation with Harbour, Offshore, Weather, and Bird modes Track up to 50 targets per defined area with ZoneTrack (two areas can be defined) VelocityTrack Doppler technology for collision avoidance Dangerous Target Alerts for radar and AIS targets Ready instantly from standby, and in 16-25 seconds from power-on The HALO® 3000 array radar offers a premium experience on the water. An impressive 130 W of power — equivalent to a 25 kW magnetron radar — delivers an unrivaled combination of short- and long-range coverage that enables you to see targets from six meters (20 feet) out to 96 nautical miles with exceptional clarity. Pulse Compression technology powers confident navigation through marinas, and superior storm and hazard detection across a greater distance. The HALO® array series not only increase situational awareness and collision avoidance but also offer higher-resolution target detection you won’t find in lower-powered radars.The HALO 3000-series boast an array of new features that make navigation safer and offer peace of mind. ZoneTrack™ brings the best of professional boating technology to recreational users, allowing them to track up to 50 vessels within a defined area, automatically detecting their course and speed. HALO’s Dangerous Target Alerts highlight range, graphical bearing, and heading of other vessels relative to yours. Meanwhile, VelocityTrack™ uses Doppler technology to show targets color-coded so you can identify potential threats at a glance. Because, when it comes to safety, situational awareness is everything.The next generation of pulse compression radars, HALO 2000 and 3000 build on the features that have made HALO an established choice for boaters across the globe. The solid-state technology gets you up and running quickly, and HALO’s low-power pulsed transmissions make it safe to run in harbors and marinas. Dual Range mode allows you to keep an eye on distant weather cells while monitoring channel markers and high-speed watercraft up close. Advanced digital signal processing gives you a clearer view of targets, helping eliminate sea clutter, while Beam Sharpening provides enhanced separation between small or distant targets. Finally, HALO 2000 and 3000 have the same footprint as their predecessors, making it easy to upgrade your current system. It’s also compatible with a range of Simrad® chart plotters, including NSS™, NSX™, NSO™, and GO™.Designed with an intuitive interface HALO arrays make operation easier with smart features like Harbour, Offshore, Bird, and Weather modes. These Preset Modes require no manual tuning — just select your chosen mode and go. This simple approach also extends to fishing, with HALO’s powerful bird-finding capability which enables boaters to find flocks of birds and — more importantly — schools of fish at a distance.Designed with an intuitive interface, HALO 3000 has smart features like Harbour, Offshore, Bird, and Weather modes. These Preset Modes require no manual tuning — just select your chosen mode and go. This simplified approach also extends to fishing, with HALO 3000’s powerful Bird+ mode — a must-have tool for sportfishing enthusiasts. Bird+ mode allows you to focus the full 130W of HALO 3000’s power on bird finding, enabling boaters to find schools of fish up to 8nm away.Specifications Environmental Operating temperature -25°C to +55°C (-13°F to +131°F) Relative humidity IEC60945 Exposed product Vibration IEC60945 Exposed product UV IEC60945 Exposed product Waterproofing IPX6 for the pedestal and antenna, IPX5 for the RI-50 interface module Relative wind velocity HALO 2000 and HALO 3000 radars with 3 ft, 4 ft or 6 ft antenna have a wind rating of 80 knots at 48 rpm in both 24V and 12V systems. Power Power consumption 250 W (peak, 12V) at maximum wind velocity 395 W (peak, 24V) at maximum wind velocity 45-75 W (average) at zero wind velocity 11 W (average) in standby mode. Refers to RI-50 input terminals Power up time 30-40 seconds from POWER OFF to TRANSMIT Physical Height 429 mm (16.88") with antenna mounted Antenna swing circle diameter 3 ft model: 3.75 ft / 1142 mm / 44.96": 4 ft model: 4.73 ft / 1443 mm / 56.81": 6 ft model: 6.72 ft / 2047 mm / 80.59" Pedestal weight 20.3 Kg (44.8lb) RI-50 weight 1.6 Kg (3.5 lb) 10 m (33 ft) cable weight 1.6 Kg (3.5 lb) Antenna (Sold Separately) Rotation speed 16 to 48 rpm depending on operating mode Beam width 3 ft model: 2.4°+/-10% (-3 dB width) — 1.7° with Beam sharpening mode on: 4 ft model: 1.8°+/-10% (-3 dB width) — 1.3° with Beam sharpening mode on:6 ft model: 1.2°+/-10% (-3 dB width) — 0.8° with Beam sharpening mode on Beam width Vertical 25° +/-10 % (-3 dB width) Plane of polarization Horizontal polarization Sidelobe level 3 ft Below -23 dB max. (within ±10°), Below -30 dB max. (outside ±10°) Side lobe level 4 ft Below -23 dB max. (within ±10°), Below -30 dB max. (outside ±10°) Side lobe level 6 ft Below -23 dB max. (within ±10°), Below -30 dB max. (outside ±10°) Radar Peak power output 130 W ± 10% under any transmit condition — up to 13% duty cycle max Transmitter Solid state module with no long-term transmitter power degradation Transmitter frequency Synthesized - Upper half of X-Band 9.390 - 9.495 GHz Pulse length 0.04 usec Chirp length 2-64 usec Chirp bandwidth 2-48 MHz. Up to 1 pulse and 4 chirps in a burst with burst repetition rate of 500-3000Hz. Range and mode dependent. Effective pulse compression ratio less than 150 in all modes. Instrumented range 96 nm SART/RACON triggering Yes — trigger distance: about 1nm max — weather, sea state, and SART position dependent Duplexer Circulator and isolator LNA GaAs front-end IF section Center frequency: 31.25 MHz Bandwidth: 50 MHz max.* A/D; 16 bit 125 MSPS *Narrower bandwidths defined by signal processing Noise figure 5 dB (Min) at antenna input Compass safe distance; Pedestal STD. 1.0 m (3.3 ft), Steer 0.5 m (1.6 ft) Compass safe distance; RI-50 1.0 m (3.3 ft) Other Communication ports Ethernet 10/100 Base-T RJ-45 for radar data and control Transmit synchronization RS-422 output Remote power on yes Antenna park hold Yes (while radar is unpowered) Motor Brushless with solid state commutation with electromagnetic braking for parking What's in the Box: Halo 300x Pedestal RI-50 Power Supply 20m Power and Ethernet cable Normalized SKU: 00015765001

Simrad 000-11470-001 Radar DomeHALO™-4 Pulse Compression Radar with 4' Antenna, RI-12 Interface Module & 20M CableCombining the best characteristics of traditional pulse and FMCW broadband radar systems, Simrad's Halo™ Radar uses Pulse Compression technology to provide an unprecedented mix of long and short detection range, high target definition, and minimal clutter. Solid State technology means minimal warm-up time and maximum ocean-going reliability, while compliance with upcoming Low Emission standards makes Halo Radar safe to run in anchorages and marinas.Key Features: True 64nm range with 4' open array antenna Beam Sharpening with Target Separation Control Dual Range operation with NSS/NSO multifunction displays Advanced signal processing with Harbour, Offshore, Weather, Bird, and Custom modes. Other modes available soon. High-speed 48RPM operation InstantOn™, ready in 16-25 seconds from power-on, instant from standby MARPA target tracking, up to 10 targets (20 with dual range) Low electromagnetic emissions and radiation Low power consumption with 12/24V operation Ethernet connectivity Unique blue LED accent lighting in pedestal with brightness control Solid-State with Pulse Compression TechnologySimrad Halo Radar is the world's first high performance, solid-state radar with pulse compression technology designed specifically for recreational mariners. Unlike traditional pulse radar, Halo Radar isn't reliant on a high-powered magnetron (vacuum tube) to transmit. Instead, Halo Radar uses solid-state electronics and low-power 25W pulsed, frequency-swept transmission bursts to deliver pulse radar-like range and resolution, without the associated warm-up time, power consumption, or electromagnetic emissions.64nm RangeHalo Radar delivers a maximum range comparable to traditional 6kW pulse radar, at up to 64nm with the HALO-4 Radar's 4' open array antenna. It offers unprecedented 10M (30') minimum range, peering into that pulse-radar blind spot where once only FMCW (3G/4G) Broadband Radar could operate.Beam SharpeningWhether you're looking at a flock of birds or a string of channel markers, separating one radar target from another is key. Beam Sharpening with Target Separation Control provides unmatched target resolution, granting the Halo Pulse Compression Radar's 4' open array antenna the same effective target resolution as a 4' array without beam sharpening.Dual Range OperationWith Dual Range, Halo Radar functions like two arrays in one - monitor two distance ranges simultaneously with independent displays, controls, and totally independent MARPA target tracking. Take full advantage of Halo Radar's combination of short-, mid-, and long-range performance to keep an eye on faraway weather cells, while monitoring channel markers and high speed watercraft up close. Dual Range operation is available with Simrad NSS and NSO multifunction display systems.Target DetectionThe HALO-3 Radar offers excellent target detection for its compact 3' open array. For enhanced target detection in line with tough IEC 62388 Annex D specifications, consider our larger HALO-4 Radar or HALO-6 Radar arrays.ARPA Target TrackingAutomatically track up to 10 user-selected radar targets, displaying CPA (closest point of approach) and TCPA (time to closest point of approach). Up to 20 different targets can be tracked in Dual Range mode, with 10 targets per screen. MARPA functionality requires a heading sensor and GPS.Advanced Signal ProcessingHalo Radar employs advanced signal processing for digital azimuth and range sidelobe reduction, enhancing discrimination of small targets such as channel markers from larger adjacent targets such as ships and bridges. In addition, Directional Sea Clutter Rejection dynamically changes gain in the sweep to allow smaller targets to be seen in the leeward. Sector Blanking eliminates unwanted reflections, for less clutter on screen.8 Usage Modes with Automatic Harbour/Offshore SelectionHarbour, Offshore, Weather, and Bird modes tune Halo Radar's advanced signal =processing to help ensure the targets you're interested in can be seen vividly - even in the toughest environmental conditions. Automatic selection of Harbour and Offshore modes configures your Halo Radar to suit your surroundings, while a 'Custom' mode enables easy manual tuning to suit any purpose or conditionHigh Speed Mode Halo Pulse Compression Radar provides rapid position updates, with high speed operation up to 48RPM (mode and range dependent). Simrad quality construction and Halo Radar's brushless motor with advanced helical geartrain design ensure exceptionally quiet operation, especially at 48RPM.InstantOn™Collision hazards won't wait for your radar to start up - why should you? Halo Radar's solid-state technology is ready instantly from standby, and in just 16-25 seconds from power-on to fully-operational. Avoid the 2-3 minute warm-up time associated with traditional pulse radar, and trust Halo Radar to produce an immediate, accurate radar image when you need it.High ReliabilityHalo Radar is built to last, with its solid-state transceiver meaning no magnetron to replace, and no manual tuning required as the magnetron heats up or ages. Similarly, a solid-state brushless motor driver means no motor brushes to wear out and replace. Be confident that Halo Radar will operate at high speed in winds up to 70 knots, year after year.Low Electromagnetic EmissionsUnlike traditional pulse radar, Halo Radar's low-power pulsed transmissions meet upcoming Low Emission standards. This makes Halo Radar safe to run in anchorages and marinas, providing enhanced radar coverage at the very start and end of each journey.Low Power ConsumptionHalo Radar uses 40W average with no wind, and no more than 200W at maximum wind velocity. Experience even greater power savings in standby with just 7W power usage, versus 10/15W for pulse radar. With its low power consumption and support for 12/24 volt DC systems, Halo Radar is ideal for small to mid-sized powerboats.Ethernet ConnectivitySimrad Halo Pulse Compression Radar connects to any Simrad NSS or NSO multifunction display system via Ethernet, with a bulkhead-mounted interface box below deck. Antenna installation is simple and elegant, with the same thin cable and small-diameter connectors as our 3G/4G Broadband radars.Uncompromising AestheticsBringing the range and reliability of Halo Pulse Compression Radar to your boat doesn't mean compromising on aesthetics. Halo Radar's sleek open-array antenna sits atop a uniquely curved pedestal, a departure from traditional boxy and utilitarian radar designs. Display your Halo Radar on the water with soft-glow, dual-beam Blue LED accent lighting, integrated into the pedestal and customizable with 4-level brightness control.*Halo™ Pulse Compression Radar's blue 4 level static accent pedestal lighting may not be approved for use in your boating location. Please check your local boating regulations before turning the blue accent lights ON.***MARPA functionality will not be available on Halo Radar at initialrelease, but will be enabled via software update in Q3 2015.**** Specifications:Range - Max (Miles) = 64nm Power - Output (Kilowatts) = 6kW Hor/Vert Beam Width = NONE Array Size (Inches) = 4'Normalized SKU: 00011470001UPC Code: 9420024128787

Simrad 000-11471-001 Radar DomeHALO™-6 Pulse Compression Radar with 6' Antenna, RI-12 Interface Module & 20M CableCombining the best characteristics of traditional pulse and FMCW broadband radar systems, Simrad's Halo™ Radar uses Pulse Compression technology to provide an unprecedented mix of long and short detection range, high target definition, and minimal clutter. Solid State technology means minimal warm-up time and maximum ocean-going reliability, while compliance with upcoming Low Emission standards makes Halo Radar safe to run in anchorages and marinas.Key Features: True 72nm range with 6' open array antenna Beam Sharpening with Target Separation Control Dual Range operation with NSS/NSO multifunction displays Advanced signal processing with Harbour, Offshore, Weather, Bird, and Custom modes. Other modes available soon. High-speed 48RPM operation InstantOn™, ready in 16-25 seconds from power-on, instant from standby MARPA target tracking, up to 10 targets (20 with dual range) Low electromagnetic emissions and radiation Low power consumption with 12/24V operation Ethernet connectivity Unique blue LED accent lighting in pedestal with brightness control Solid-State with Pulse Compression TechnologySimrad Halo Radar is the world's first high performance, solid-state radar with pulse compression technology designed specifically for recreational mariners. Unlike traditional pulse radar, Halo Radar isn't reliant on a high-powered magnetron (vacuum tube) to transmit. Instead, Halo Radar uses solid-state electronics and low-power 25W pulsed, frequency-swept transmission bursts to deliver pulse radar-like range and resolution, without the associated warm-up time, power consumption, or electromagnetic emissions.72nm RangeHalo Radar delivers a maximum range comparable to traditional 6kW pulse radar, at up to 72nm with the HALO-6 Radar's 6' open array antenna. It offers unprecedented 10M (30') minimum range, peering into that pulse-radar blind spot where once only FMCW (3G/4G) Broadband Radar could operate.Beam SharpeningWhether you're looking at a flock of birds or a string of channel markers, separating one radar target from another is key. Beam Sharpening with Target Separation Control provides unmatched target resolution, granting the Halo Pulse Compression Radar's 6' open array antenna the same effective target resolution as a 6' array without beam sharpening.Dual Range OperationWith Dual Range, Halo Radar functions like two arrays in one - monitor two distance ranges simultaneously with independent displays, controls, and totally independent MARPA target tracking. Take full advantage of Halo Radar's combination of short-, mid-, and long-range performance to keep an eye on faraway weather cells, while monitoring channel markers and high speed watercraft up close. Dual Range operation is available with Simrad NSS and NSO multifunction display systems.Target DetectionThe HALO-6 Radar offers excellent target detection for its compact 6' open array. ARPA Target TrackingAutomatically track up to 10 user-selected radar targets, displaying CPA (closest point of approach) and TCPA (time to closest point of approach). Up to 20 different targets can be tracked in Dual Range mode, with 10 targets per screen. MARPA functionality requires a heading sensor and GPS.Advanced Signal ProcessingHalo Radar employs advanced signal processing for digital azimuth and range sidelobe reduction, enhancing discrimination of small targets such as channel markers from larger adjacent targets such as ships and bridges. In addition, Directional Sea Clutter Rejection dynamically changes gain in the sweep to allow smaller targets to be seen in the leeward. Sector Blanking eliminates unwanted reflections, for less clutter on screen.8 Usage Modes with Automatic Harbour/Offshore SelectionHarbour, Offshore, Weather, and Bird modes tune Halo Radar's advanced signal processing to help ensure the targets you're interested in can be seen vividly - even in the toughest environmental conditions. Automatic selection of Harbour and Offshore modes configures your Halo Radar to suit your surroundings, while a 'Custom' mode enables easy manual tuning to suit any purpose or conditionHigh Speed Mode Halo Pulse Compression Radar provides rapid position updates, with high speed operation up to 48RPM (mode and range dependent). Simrad quality construction and Halo Radar's brushless motor with advanced helical geartrain design ensure exceptionally quiet operation, especially at 48RPM.InstantOn™Collision hazards won't wait for your radar to start up - why should you? Halo Radar's solid-state technology is ready instantly from standby, and in just 16-25 seconds from power-on to fully-operational. Avoid the 2-3 minute warm-up time associated with traditional pulse radar, and trust Halo Radar =to produce an immediate, accurate radar image when you need it.High ReliabilityHalo Radar is built to last, with its solid-state transceiver meaning no magnetron to replace, and no manual tuning required as the magnetron heats up or ages. Similarly, a solid-state brushless motor driver means no motor brushes to wear out and replace. Be confident that Halo Radar will operate at high speed in winds up to 70 knots, year after year.Low Electromagnetic EmissionsUnlike traditional pulse radar, Halo Radar's low-power pulsed transmissions meet upcoming Low Emission standards. This makes Halo Radar safe to run in anchorages and marinas, providing enhanced radar coverage at the very start and end of each journey.Low Power ConsumptionHalo Radar uses 40W average with no wind, and no more than 200W at maximum wind velocity. Experience even greater power savings in standby with just 7W power usage, versus 10/15W for pulse radar. With its low power consumption and support for 12/24 volt DC systems, Halo Radar is ideal for small to mid-sized powerboats.Ethernet ConnectivitySimrad Halo Pulse Compression Radar connects to any Simrad NSS or NSO multifunction display system via Ethernet, with a bulkhead-mounted interface box below deck. Antenna installation is simple and elegant, with the same thin cable and small-diameter connectors as our 3G/4G Broadband radars.Uncompromising AestheticsBringing the range and reliability of Halo Pulse Compression Radar to your boat doesn't mean compromising on aesthetics. Halo Radar's sleek open-array antenna sits atop a uniquely curved pedestal, a departure from traditional boxy and utilitarian radar designs. Display your Halo Radar on the water with soft-glow, dual-beam Blue LED accent lighting, integrated into the pedestal and customizable with 4-level brightness control.*Halo™ Pulse Compression Radar's blue 4 level static accent pedestal lighting may not be approved for use in your boating location. Please check your local boating regulations before turning the blue accent lights ON. Specifications:Range - Max (Miles) = 78nm Power - Output (Kilowatts) = 6kW Hor/Vert Beam Width = NONE Array Size (Inches) = 6'Normalized SKU: 00011471001UPC Code: 9420024128824

Simrad 000-11467-001 Radar DomeRI-12 Radar Interface ModuleFeatures: Designed to accomodate either 12 or 24 colt systems and used for all Halo models Rugged, screw-in power connector block (DC cable not supplied) Supplies 36V DC to the pedestal in Tx mode - Status LED is Green when on - Red when not Easy to connect NMEA2000 Micro C Ethernet 10_100BaseT output with Ethernet LED (pigtail adapter supplied for internal RJ45 to external Navico Yellow) Easy removable access cover with captive screws Silicon Rubber Cable glands Comes with: N2K-T-RD Network T-Connector - 000-0119-79   ETHEXT-6YL 6ft Ethernet Cable- 000-0127-51  N2KEXT-6RD - MICRO-C 6ft Cable, 1,8M - 000-0127-53  CABLE RJ45M-5F Ethernet adapter Cable  - 000-11246-00 Specifications:Array Size (Inches) = NONE Hor/Vert Beam Width = NONE Power - Output (Kilowatts) = NONE Range - Max (Miles) = NONENormalized SKU: 00011467001UPC Code: 9420024128787
