VDO 301-105 GaugesVision Black Fuel Gauge - Use with 240-33 Ohm Sender - 12VCrisp black dials and matching bezels, along with VDO Tri-optic through dial illumination make Vision Black a solid choice for small fishing and pleasure boats. High contrast clear white graphics and red pointers make Vision Black easy to read, while patented VDO movements provide smooth and accurate performance and long life dependability. Standard 0.25" spade connectors simplify wiring and VDO Spin-lok™ mounting makes installation fast and easy. Included light diffusers allow the dial illumination color to be changed to red or green.Features: Connection: .250" Spade Input Type: Analog Mounting Hardware: Spin-Lok™ Voltage: 12V Diameter: 2-2/16" Diameter (Metric): 52mm Max Range Outer Scale: F Normalized SKU: 301105UPC Code: 754059015750

VDO 226-456 GaugesWastewater Level Sender Voltage: 12-24V Length: 80-600mm 4-20mA Normalized SKU: 226456UPC Code: 754059052557

VDO 600-846-LED Senders & AccessoriesRed LED Warning Light - 12VYellow LED Warning Light with Socket and Pigtail.Features:  Color - Yellow Includes Pigtail and Socket 12V *Sold as an Individual Normalized SKU: 600846LEDUPC Code: 754059059280

VDO 301-107 Gauges2-1/16" (52mm) Vision Fuel Gauge (E-1/2-F) Black Dial & BezelFeatures: Connection: .250" Spade Mounting Hardware: Spin-Lok™ Voltage: 12V Diameter (Metric): 52mm Max. Range Outer Scale: F Input Type: Analog Diameter: 2-1/16" Normalized SKU: 301107UPC Code: 754059015743

Download LiteratureVDO B00059201 Senders & Accessories0-5 Volt LinkUp ConverterEasily installed LinkUp gateway modules replace the original wiring, delivering power to both the LinkUp device and the sensor from the NMEA 2000 backbone while being still compliant with the NMEA 2000 certification.Thanks to their passive wireless receiver, the configuration is done in a snap by using your mobile device and the LinkUp Configurator app available for Android and iOS devices. The parameters of the sensor are configured to type, instance, and warning threshold on the mobile device and then tapped against the LinkUp device for instant data download.Before describing the different versions of LinkUp, we would like to highlight the fact that this device is a money saver compared to an over-designed NMEA 2000 converter. It reduces wiring, since the complete device – consists of 3 parts: a 30 cm wire pigtail with a standard M12 connector with 5 pins, the LinkUp device itself containing the device electronics, notification LED, wireless interface to program the device, and the NMEA 2000 side wiring, which is the output of all the LinkUp variants and finally a sensor-side cable – including the wires is approx. 50 cm long when unrolled.The other benefits of this equipment are the contactless configuration with your smartphone, no need to spend money on an expensive HW, and no need for a power supply since the LinkUp is powered by NMEA.Last but not least, thanks to its air-sealed housing, the device can be installed in the engine compartment according to ISO 8846:1990 (protection against ignition of surrounding flammable gases). As with all our products, LinkUp is CE, Reach, and RoHS compliant.These powerful devices are fast, efficient, secure, safe, and cost-effective.Features: Wireless configurable via a smartphone app Customizable sensor curves Approved for engine compartments acc. to ISO8846:1990 Provides 5V-Source for passive sensors Alarms setup and transmission on NMEA 2000® Plug-and-Play installation NMEA 2000® certified Technical Specifications: Operating voltage - 12V (from NMEA 2000®) Input signal range - 0-5V Protection class - IP X9/K Power consumption - ≤ 100mA Output current on 5V-source - 15mA Output signal - NMEA 2000® Dimensions - 125 mm x 32 mm (+cables) Operating temperature - -30°C to +80°C Flammability - UL94 Housing material - PC-FR Compliance - CE, UKCA, Reach, RoHS, ISO8846:1990 In the Box: LinkUp Gateway – 0-5V  Veratron Card  Safety Manual This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: B00059201UPC Code: 7640190290145VDO B00059201 Literature Download Owners Manual Product Brochure

VDO A2C59514117 Gauges52mm (2-1/16") Viewline Engine Oil Pressure 150 PSI - Black Dial & BezelFeatures: Installation Dimension: 52mm - 2-1/16" Color: Black Lens: Plastic Double Anti-Fog Bezel Model: Black Triangle Measurement Range: 0 - 150 PSI Category: Pressure Gauges Series: Veratron Viewline Application: VDO Engine Monitoring Signal Analogue: 10 - 184 Ohm IP Class Front: IP67 (IEC 60529) Operating Voltage: 8 - 32 Volt DC Functionality: Engine Oil Pressure Input: Analog Bezel Interchangeable: Yes - Clip-On Warning Light: Red LED Via Plus And Min Communication: Analog Dial Scale: Double Normalized SKU: A2C59514117

VDO A2C59512458 Gauges52mm (2-1/16") Viewline Voltmeter 18-32V - Black Dial & BezelThe Viewline voltmeter displays the status of the generator and battery and their loads on a voltage scale. Values exceeding the normal charging voltages can therefore be monitored exactly. Features: Installation Dimension: 52mm - 2-1/16" Color: Black Lens: Plastic Double Anti-Fog Bezel Model: Black Round Measurement Range: 18 - 32V DC Category: Voltmeters Series: Veratron Viewline Application: VDO Engine Monitoring Signal Analogue: 0 - 32V DC IP Class Front: IP67 (IEC 60529) Operating Voltage: 18 - 32 Volt DC Functionality: 24 Volt Battery Condition Input: Analog Bezel Interchangeable: Yes - Clip-On Warning Light: Red LED Via Plus And Min Communication: Analog Normalized SKU: A2C59512458UPC Code: 7640178722811

Watch VideoVDO B00067401 GaugesProfessional 85MM (3-3/8") Rudder Angle Indicator for NMEA 0183Specially designed to fit into the standard 85mm panel cut, the Professional Rudder Angle Indicator is developed to suit commercial applications thanks to the embedded NMEA 0183 transceiver - which makes it operable with most of the professional autopilots out in the field - and the large 270° dial scale and Red illumination which makes it well readable and accurate in the indication.It supports both 12V and 24V systems, and it is designed to resist the harshest environment thanks to its extended operating temperature from -30°C to +80°C and IPX7 protection class.Able to support the analogue 3-180 Ohm and 0-5V rudder sensors, the Professional Rudder Angle Indicator also repeats the rudder angle data via NMEA 0183 to multiple gauges connected in series to it.The embedded infrared (IR) pushbutton allows for a user-friendly fine tuning of the predefined calibration.Features: Designed for NMEA 0183 Easy programing and installation Technical Specifications: Operating Voltage - 8 to 32 V Protection Class - IP6K7 Illumination - Red LED Dial - Black w/graphics Pointer - Red Illuminated Lens - Plastic Double Lens (anti-reflective) Operating Temp. - -40°C to 115°C Connector - Molex MX150 - 12 pin In the Box: Gauge  Wire Harness Mounting Spinlock Safety Instructions *Sold as an Individual Normalized SKU: B00067401VDO B00067401 Video

VDO B00085502 Gauges85mm (3-3/8") VMH-35 Multifunction Gauge with Battery SensorThe Veratron VMH 35 is engineered for single inboard or outboard engine applications. The Veratron VMH 35 has an embedded NMEA 2000 gateway that distributes sensor data inputs such as fuel, trim, and tachometer to other devices like chartplotters.  This saves the need for an additional external converter.  Highly adaptable to a wide range of onboard networks, it's equipped with analog inputs, making it ideal for refitting with older engines.An integrated GPS makes the VMH 35 the perfect standalone navigation solution.  It integrates speed, compass, and position into the engine data information.  A dedicated Veratron IBS (Intelligent Battery System) input can provide critical 12V battery monitoring capabilities.The Veratron VMH 35 has a mineral glass front that's optically bonded to the sun-readable hybrid display.  A sleek, brushed stainless steel bezel surrounds the device and fits into classic and modern marine décors.  Because small boat consoles are often fully exposed, the round display is waterproof to IPX7 criteria, both front and back.  It fits a standard 3-3/8" panel cutout size.Features: Integrated high-performance GNSS receiver Integrated Analog to NMEA 2000 Gateway Waterproof to IPX7 Stylish black-glass design with brushed stainless-steel ring New generation sun-readable color hybrid display Intelligent Battery Sensor (IBS) port NMEA 2000® certified In the Box: VMH35 Gauge Wire harness  Mounting Spinlock Outboard Engine Kit w/IBS (B00062402) Safety Instructions *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: B00085502UPC Code: 7640178729940

VDO B00006302 Gauges52MM (2-1/16") ViewLine Hour Counter-Voltmeter - WhiteVeratron ViewLine offers a comprehensive modular, modern series of instruments for engine monitoring.More functions and greater flexibility in installation and design increase the scope for high manufacturing standards and guarantee the highest level of reliability and readability. As the result of ongoing research and development work, we offer an innovative comprehensive standard instrumentation platform which is also available for outboard engine use.  ViewLine provides maximum freedom to customize the cockpit and is the natural choice for an attractive price/performance ratio.The ViewLine 52 mm Gauges are available in black or white dial versions, which are always completed with a round bezel in the identical color. Interchangeable bezel option.Features: 8 pole Tyco / Hirschmann MQS plug Operating voltage 8 – 48 V Reverse polarity protection Anti-fog double lens Front side protection rating IP67 52 mm installation diameter 50 mm installation depth This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: B00006302UPC Code: 7640178729285
