Raymarine E70493R VHF Fixed Mount RadiosRaymarine RAY91 Modular Dual-Station VHF Radio with VHF - RemanufacturedModel: E70493R Black box, dual-station capable VHF radio Built-in Automatic Identification System (AIS) Class B Receiver NEW - Optional Wireless handset and active speaker available Wired handset and passive speaker included Expandable to 2 RayMic handsets Built-in loudhailer and fog signal generator Optional external GPS receiver and Class D Digital Selective Calling Simple NMEA2000 and NMEA0183 Networking The Ray91 modular VHF radio brings dual-station communications and traffic management to a whole new level of power, performance, and flexibility. The Ray91 is a black-box design with a transceiver that hides out of sight while the ergonomic RayMic handset and remote speaker provide full control of the radio with crystal clear audio.The Ray91 is also equipped with an integrated Automatic Identification System (AIS) receiver. Us the Ray91 to receive navigation and safety broadcasts from nearby AIS-equipped vessels and share them over NMEA2000 or NMEA0183 with compatible MFDs. AIS equipped vessels can easily be identified along with their vessel name, course, speed, CPA, and other voyage information.Ray91 is equipped with a powerful 25-watt transmitter and commercial grade electronics for long life and superior performance. Channel scanning, dual-watch, tri-watch and weather alert are standard. Class D Digital Selective Calling radio and integrated GPS makes setting up the advanced safety and calling features easy. Simply input your vessel’s MMSI number during setup and you’re ready to go. For GPS operation the optional GA150 passive GPS antenna is required.Use Ray91’s position tracking feature to keep tabs on up to 5 nearby DSC equipped vessels. Their positions are automatically shared with your Raymarine MFD. Keep an eye on other boats in your cruising party, monitor vessels of interest, or manage your local fleet. In Europe the Ray91 supports the ATIS system on navigable inland waterways.Ray91’s built-in loudhailer will make you heard on-deck and across the harbour. Connect an optional hailing horn and make your presence known with 30-watts of audio output, plus 2-way talkback. When things get foggy, the loudhailer can be set to automatically sound required fog signals for power and sailing vessels underway and at anchor.Ray91’s transceiver unit is cast in solid aluminum for shock and vibration resistance and maximum heat dissipation. RayMic handsets feature super-bright backlighting for easy viewing in all conditions and oversized keys provide a sure grip with easy access to commonly used functions.Specifications ENVIRONMENTAL Water Integrity Complies with IPX6 & IPX7 Complies with EN60945 Operating Temperature Range -25°C to 55°C Storage Temperature Range -25°C to 70°C Humidity up to 95% Electrical Communications Port NMEA 0183 (version 4.01); NMEA2000 (version 3.101) Nominal Supply Voltage 12V DC. Reverse polarity and over voltage protected Operating Voltage Range 9V DC to 16V DC Current Consumption Less than 6A at High Power (13.6V) Standby: 600 mA Receive: 2 Amps Transmitter Channels All available US, International and Canadian VHF marine bands Frequency Range 156.000 — 157.425 MHz 155.500 to 161.425 MHz Private channels Frequency Stability + / - 1.5 ppm Channel Spacing 12.5 kHz Power Output High Power = 25 Watt, Low Power = 1 Watt Spurious emmission Better than -36 dBm at 25W (Less than 0.25 µW) Maximum Deviation +/- 5kHz Antenna port impedance 50 ohms typical Receiver Receiver Type Double Conversion Super Heterodyne Channels All available US, International and Canadian VHF marine bands Frequency Range 156.000 — 157.425 MHz 155.500 to 161.425 MHz Private channels Sensitivity: Better than 1 microvolt EMF @ 20dB SINAD Hum & Noise Better than -40 dB Audio Distortion Less than 10% Receiver Sensitivity Distance -119 dBm (0.25uV)@12 dB SINAD ? Typical Local -110 dBm (0.7uV)@12 dB SINAD ? Typical Adjacent Channel Selectivity More than 70 dB Spurious Response Rejection More than 70 dB Inter Modulation Rejection More than 70 dB GPS Number of channels 72 Cold Start 29s Receiver IC Sensitivity -167 dBm (Tracking) / -148 dBM (Acquisition) GNSS Compatibility GPS GLONASS *BeiDou SBAS Compatibility WAAS EGNOS MSAS Special Features Active jamming and interference reduction Operating frequencies GPS L1 C/A GLONASS L10F Beidou B1 Signal Acquisition Automatic Almanac Update Automatic Geodetic Datum WGS-84 (alternatives available through Raymarine MFD) Refresh Rate 20 Hz (20 times per second concurrent GNSS) Positional Accuracy Without SBAS: <2.5 metres 95% of the time With SBAS: <2 metres 95% of the time AIS Class type Receive Only Dimensions 2.48" H x 9.25" W x 6.3" W What's in the Box: Ray91 VHF DSC Radio (including fitted power and data cable) - Remanufactured Raymic handset cradle Raymic handset Raymic handset adaptor cable (12 pin female to 12 pin male with RCA Audio) Passive speaker Passive speaker mounting gasket Passive speaker mounting screws x 4 Documentation VHF radio mounting screws x 4 Handset cradle mounting screws x 4 DeviceNet to SeaTalkng® adaptor Normalized SKU: E70493R

Raymarine A80272 Network Accessories RayNet (M) To STHS (M) Adapter 400mm Connect Classic or Wide to RayNet Radars Specifications:Load Equivalence # (LEN) = NONENormalized SKU: A80272UPC Code: 723193783962

Raymarine E62351 Multifunction DisplaysRCU-3 Remote ControlFeatures: Stay in command of the Raymarine e7 Multifunction Navigation Display without letting go of the wheel The Raymarine RCU-3 Steering Wheel Remote gives you simple access to frequently used functions while underway Change range scales, control your music, switch between apps, and even mark a waypoint, it's all possible with the wireless RCU-3 remote If you don't need the RCU-3 on your wheel, it can also be attached to the supplied lanyard and transform the RCU-3 into a convenient handheld remote control for the e7 Display Bluetooth wireless technology makes configuring the RCU-3 remote easy Gives wireless control of the e7 Display from up to 15 feet away Normalized SKU: E62351UPC Code: 091975010415
