Download LiteratureRaymarine E92142 Radar DomeRaymarine's new HD Digital radome scanners combine the power and clarity ofHD Digital signal processing with an ultra-compact scanner suitable for all types of vessels. Compatible with C-Series Widescreen, E-Series Widescreen and G-Series Multifunction displays these radomes offer a 256-color radar display and the clearest, most lifelike radar presentation available from any radome scanner. The RD418HD and RD424HD feature the same adaptive digital receiver technology found in our open array antennas. By adjusting automatically to changing environmental and sea conditions, the HD Digital radomes provide crisp, accurate contact echoes at short ranges, as well as outstanding long range performance up to 48 nautical miles. Rain, fog and high seas are no match for the HD Digital radome. Using it's powerfulprocessor the HD Digtal radome intelligently seperates true contacts from noise and clutter. The RD418HD and RD424HD offer small boat captains all of the same capabilities usually reserved for larger capacity boats.FEATURESAdaptive digital receiver automatically adjusts to changing environmental and sea conditions for a dramatically clearer picture New high speed (48rpm) target tracking Fast digital receiver processor 256 color multi-level display with selectable color palettes New Bird Mode automatically optimizes the receiver for detecting sea birds above schools of fish Automatic harbor, coastal, offshore and buoy operating modes Dual-range mode allows you to monitor both long and short ranges simultaneously with a single scanner and display Specifications: Hor/Vert Beam Width = 4.9/25 degree Range - Max (Miles) = 48 Power - Output (Kilowatts) = 4kw Array Size (Inches) = 18" RAYMARINE RD418HD 4KW 18" HD DIGITAL RADOME NO CABLE Normalized SKU: E92142UPC Code: 091975005121Raymarine E92142 Literature Download   Owners Manual

Raymarine T70168 Radar DomeRD418HD w/10M CableIncludes 10M Cable - A80228 18" HD Digital Radar Dome RD418HD - E92142 Raymarine's HD Digital radome scanners combine the power and clarity of HD Digital signal processing with an ultra-compact scanner suitable for all types of vessels. Compatible with a, c & e Series Multifunction displays these radomes offer a 256-color radar display and the clearest, most lifelike radar presentation available from any radome scanner. The RD418HD and RD424HD feature the same adaptive digital receiver technology found in our open array antennas. By adjusting automatically to changing environmental and sea conditions, the HD Digital radomes provide crisp, accurate contact echoes at short ranges, as well as outstanding long range performance up to 48 nautical miles. Rain, fog and high seas are no match for the HD Digital radome. Using it's powerfulprocessor the HD Digtal radome intelligently seperates true contacts from noise and clutter. The RD418HD and RD424HD offer small boat captains all of the same capabilities usually reserved for larger capacity boats.FEATURES Adaptive digital receiver automatically adjusts to changing environmental and sea conditions for a dramatically clearer picture New high speed (48rpm) target tracking Fast digital receiver processor 256 color multi-level display with selectable color palettes New Bird Mode automatically optimizes the receiver for detecting sea birds above schools of fish Automatic harbor, coastal, offshore and buoy operating modes Dual-range mode allows you to monitor both long and short ranges simultaneously with a single scanner and display Specifications:Array Size (Inches) = 18" Hor/Vert Beam Width = 4.9/25° Power - Output (Kilowatts) = 4kw Range - Max (Miles) = 48Normalized SKU: T70168UPC Code: 723193774496

  Download LiteratureRaymarine E92143 Radar DomeRaymarine's new HD Digital radome scanners combine the power and clarity ofHD Digital signal processing with an ultra-compact scanner suitable for alltypes of vessels. Compatible with C-Series Widescreen, E-Series Widescreenand G-Series Multifunction displays these radomes offer a 256-color radardisplay and the clearest, most lifelike radar presentation available from any radome scanner. The RD418HD and RD424HD feature the same adaptivedigital receiver technology found in our open array antennas. By adjustingautomatically to changing environmental and sea conditions, the HD Digitalradomes provide crisp, accurate contact echoes at short ranges, as well asoutstanding long range performance up to 48 nautical miles. Rain, fog andhigh seas are no match for the HD Digital radome. Using it's powerfulprocessor the HD Digtal radome intelligently seperates true contacts fromnoise and clutter. The RD418HD and RD424HD offer small boat captains all ofthe same capabilities usually reserved for larger capacity boats.FEATURESAdaptive digital receiver automatically adjusts to changingenvironmental and sea conditions for a dramatically clearer picture New high speed (48rpm) target tracking Fast digital receiver processor 256 color multi-level display with selectable color palettes New Bird Mode automatically optimizes the receiver for detecting seabirds above schools of fish Automatic harbor, coastal, offshore and buoy operating modes Dual-range mode allows you to monitor both long and short rangessimultaneously with a single scanner and display Specifications: Hor/Vert Beam Width = 3.9/25 degree Range - Max (Miles) = 48nm Power - Output (Kilowatts) = 4kw Array Size (Inches) = 24" RAYMARINE RD424HD 4KW 24" HD DIGITAL RADOME NO CABLE Normalized SKU: E92143UPC Code: 091975005138Raymarine E92143 Literature Download   Owners Manual

Raymarine T70169 Radar DomeRD424HDIncludes 10m Cable - A80228 24" HD Dome - E92143 Raymarine's HD Digital radome scanners combine the power and clarity of HD Digital signal processing with an ultra-compact scanner suitable for all types of vessels. Compatible with a,c & e Series Multifunction Displays, these radomes offer a 256-color radar display and the clearest, most lifelike radome presentation available from any radome scanner.The RD424HD feature the same adaptive digital receiver technology found in our open array antennas. By adjusting automatically to changing environmental and sea conditions, the HD Digital radomes provide crisp, accurate contact echoes at short ranges, as well as outstanding long range performance up to 48 nautical miles. RD424HD Features: Adaptive digital receiver automatically adjusts to changing environmental and see conditions for a dramatically clearer picture Fast digital receiver processor 256 color multi-level target display with selectable color palettes New Bird Mode automatically optimizes the receiver for detecting sea birds above schools of fish¹ New High Speed Mode (48 RPM) automatically engages for optimal tracking of high speed targets at short ranges Dual-range mode allow you to monitor both long and short ranges simultaneously with a single scanner and display Specifications: Array Size (Inches) = 24" Hor/Vert Beam Width = 3.9/25° Power - Output (Kilowatts) = 4kW Range - Max (Miles) = 48nm Normalized SKU: T70169UPC Code: 723193774502

  Download LiteratureRaymarine T106-916 Navigational InstrumentsTacktick Remote Display & NMEA Wireless Interface KitPackage Contains: T113 Micronet Remote Display T122 Micronet Wireless NMEA Interface T113 Micronet Remote DisplayNot just a remote control, this is an independent, Micronet, wireless, palm sized display. With a dot matrix screen it not only shows you all the data in your system, but also incorporates a rolling road, as well as performance pages for uploads from your tactical software, and it can function as a remote control for your Micronet displays. You can add as many handsets as you need for the key members of your crew. Key Features: Can be used with existing instrument systems even from other manufacturers Palm sized Easy to hold Totally multifunction Graphic multi-line display Solar powered No need to change batteries Totally wireless T122 Micronet Wireless NMEA InterfaceThis interface enables sailors to integrate other marine electronics into any of the Micronet instrument range. Compatible with instruments using the NMEA language, the Wireless NMEA Interface (2 inputs/1 output) collects data from autopilots, GPS, chartplotters, PDAs and other on board instruments and transmits it wirelessly to the Micronet displays. Plugged into an on board PC, Micronet can send and receive information so that navigation and tactical software can be displayed anywhere on deck. The Wireless NMNEA Interface may be used with PC software to create custom pages on the T110 Micronet Digital Display using Proprietary NMEA Sentences. Specifications:Screen Size = NONE Shape = Square Digital/Analog = DigitalNormalized SKU: T106916UPC Code: 5037707101063Raymarine T106-916 Literature Download  Quick Reference Guide  Owners Manual  Product Brochure

Raymarine A80512 Network AccessoriesRight Angle RayNet to RayNet - 10MFeatures: Raymarine's right angle RayNet to RayNet connections Length: 10M Specifications:Load Equivalence # (LEN) = NONENormalized SKU: A80512UPC Code: 723193818152

Raymarine T70293 Network AccessoriesRMK-10 System Remote Control - Portrait & Landscape KeypadRaymarine's RMK-10 Remote Keypad is an ultra-compact wired keypad accessory that provides full control of aSeries, cSeries, eSeries, eS Series and gS Series Multifunction Displays (MFDs) from any mounting location. The fully backlit RMK-10 includes dedicated keys for home, menu, zoom in/out, window control, waypoint management, power/brightness, as well as Evolution autopilot control.RMK-10 also features the same multifunction rotary controller with the integrated cursor pad found on eS Series multifunction displaysThe RMK-10 can be surface-mounted or flush-mounted, and is available with key mats for horizontal or vertical installation. This gives you the flexibility to install the RMK-10 just about anywhere.RMK-10 Mounting OptionsThe RMK-10 is the perfect solution for controlling MFD’s mounted beyond arm’s reach, or in overhead electronics boxes. Instead of reaching for the MFD, the RMK-10 brings the system’s controls to you.For the ultimate in convenience, mount the RMK-10 in the arm of your favorite helm chair. Now it’s easy to sit back, relax and enjoy the ride on autopilot, while still being able to interact with your navigation system.RMK-10 is also great for bringing remote system control to secondary monitors and onboard LCD TV sets connected to the VGA or HDMI output of select e-Series, eS-Series and gS-Series displays. Now you can see and control your Raymarine navigation system from a below-deck navigation table, salon or stateroom.Networking & ControlUtilizing Raymarine’s RayNet high speed networking, the RMK-10 can be setup to control a single multifunction display, or multiple displays mounted at the same location. When controlling multiple displays on the same helm, the RMK-10 provides seamless control across all of the displays.When used with aSeries or gS Series Multitouch displays, the RMK-10 brings full HybridTouch™ control capability to these products. The RMK-10 integrates seamlessly with the LightHouse II user interface and allows the navigation system to be operated solely by touch, by keypad, or any variation between. Specifications:Load Equivalence # (LEN) = NONENormalized SKU: T70293UPC Code: 723193816653

Raymarine A80438 AccessoriesRMK-10 System Remote Control Portrait KeypadRemote Keypad is an ultra-compact wired keypad accessory that provides full control of aSeries, cSeries, eSeries, eS Series and gS Series Multifunction Displays (MFDs) from any mounting location.The fully backlit RMK-10 includes dedicated keys for home, menu, zoom in/out, window control, waypoint management, power/brightness, as well as Evolution autopilot control.RMK-10 also features the same multifunction rotary controller with the integrated cursor pad found on eS Series multifunction displaysThe RMK-10 can be surface-mounted or flush-mounted, and is available with key mats for horizontal or vertical installation. This gives you the flexibility to install the RMK-10 just about anywhere.Utilising Raymarine’s RayNet high speed networking, the RMK-10 can be setup to control a single multifunction display, or multiple displays mounted at the same location. When controlling multiple displays on the same helm, the RMK-10 provides seamless control across all of the displays.When used with aSeries or gS Series Multitouch displays, the RMK-10 brings full HybridTouch™ control capability to these products. The RMK-10 integrates seamlessly with the LightHouse II user interface and allows the navigation system to be operated solely by touch, by keypad, or any variation between.Mounting OptionsThe RMK-10 is the perfect solution for controlling MFD’s mounted beyond arm’s reach, or in overhead electronics boxes. Instead of reaching for the MFD, the RMK-10 brings the system’s controls to you.For the ultimate in convenience, mount the RMK-10 in the arm of your favorite helm chair. Now it’s easy to sit back, relax and enjoy the ride on autopilot, while still being able to interact with your navigation system.RMK-10 is also great for bringing remote system control to secondary monitors and onboard LCD TV sets connected to the VGA or HDMI output of select e-Series, eS-Series and gS-Series displays. Now you can see and control your Raymarine navigation system from a below-deck navigation table, salon or stateroom.Specifications: PoE classClass 1 Nominal supply voltage12 / 24 V dc Operating voltage range10.8V dc to 31.2V dc Power consumption3.84W Environmental: Operating temperature-25ºC to +55ºC (-13ºF to 131ºF) Storage temperature-30ºC to +70ºC (-22ºF to 158ºF) Relative humidityMaximum 75% Waterproof ratingIPX6 Wired Connections: Network / power1 x RayNet connector | (gS Series - 1000 Mb/s plus PoE) | (aSeries , cSeries, eSeries - 100 Mb/s) Alternate power1 x power connector Normalized SKU: A80438UPC Code: 723193816646

Download LiteratureRaymarine A80731 Network AccessoriesRNS-5 5 Port RayNet Gigabit SwitchThe RNS-5 network Gigabit switch is designed for expanding Raymarine integrated chartplotter systems using RayNet high-speed Ethernet cabling. Use the RNS-5 to integrate Axiom displays with radars, sonar modules, IP cameras, and Teledyne FLIR thermal cameras. The RNS-5 also supports networking with Raymarine YachtSense digital control systems and the YachtSense Link marine mobile router. Two RNS-5 switches can be daisy-chained together for larger systems. The RNS-5 is simple to install and requires no complicated setup.Features: 5 RayNet Ethernet gigabit ports for fast and reliable connectivity Rugged IPX6 and IPX7 construction Reliable, waterproof RayNet connector Ethernet cable ports Designed for simple bulkhead mounting LED power and network port status indicators Unmanaged- simply plug and play with Raymarine devices No complicated setup or configuration Normalized SKU: A80731UPC Code: 723193845912Raymarine A80731 Literature Download Quick Reference Guide

Raymarine A80732 Network AccessoriesRNS-8 Network Switch - 8 Port Raynet Network SwitchThe RNS-8 network switch is a premium network switch for integrated Raymarine chartplotter systems. Use the RNS-8 to integrate Axiom displays with radars, sonar modules, and FLIR thermal cameras. The RNS-8 features 4 dedicated Power-Over-Ethernet (POE) ports for integrating and powering POE-compatible devices like CAM300 marine IP cameras and RMK-10 remote keypads. The RNS-8 also supports networking with Raymarine YachtSense digital control systems and the YachtSense Link marine mobile router. Multiple RNS-8 switches can be daisy-chained together for larger systems. The RNS-8 is simple to install and requires no complicated setup.Features: 8 RayNet Ethernet gigabit ports for fast and reliable connectivity 4 dedicated Power-Over-Ethernet (POE) ports for powering cameras and remotes Rugged IPX6/IPX7 construction Reliable, waterproof RayNet connector Ethernet cable ports Designed for simple bulkhead mounting LED power and network port status indicators Unmanaged- simply plug and play with Raymarine devices. Remote diagnostics and performance monitoring via web browser For extended networks, up to 8 RNS-8 switches can be daisy-chained together Normalized SKU: A80732UPC Code: 723193845929

  Download LiteratureRaymarine M81105 RuddersRotary Rudder ReferenceReplacement Rudder Reference Transducer used on Raymarine and Autohelm autopilot systems. Includes 10 meter cable and mounting hardware. Specifications:Drive Type = NONE Feedback Type = NONE Pilot Type = NONE Remote Capable = NONE Turn Patterns = NONE Vessel Displacement - Max (Pounds) = NONE Boat Length - Max (Feet) = NONE Capacity - Max Ram (CU) = NONERAYMARINE ROTARY RUDDER REFERE M81105Normalized SKU: M81105UPC Code: 723193811054Raymarine M81105 Literature Download  Quick Reference Guide

Raymarine E70310 AccessoriesRS150 GPS SensorThe RS150 GPS is a high performance, 72-channel, remotely mounted GPS sensor for Raymarine navigation systems. The RS150 offers fast 10Hz position updates and enhanced accuracy. The RS150 is also a GNSS receiver and supports the GLONASS global navigation satellite system.Features: 72-channel GPS receiver Fast 10Hz position updates Satellite differential GPS-compatible. Space-Based Augmentation System (SBAS) enabled with WASS, EGNOS, MSAS and GAGAN support A GNSS receiver with GLONASS compatibility Low power consumption: 30mA (1 LEN) SeaTalkng and NMEA2000 compatible (using a device net adapter cable) Designed for low profile surface mounting or optional pole mounting Specifications: Nominal supply voltage: 12V D.C. Powered by N2K bus Operating voltage range: 8 - 32V DC Power consumption: 30 mA max (NMEA LEN = 1) Operating temperature: -13ºF to 131ºF (-25ºC to +55ºC) Relative humidity: max 93% Waterproof: IPx6/7 Supported connection protocols: SeaTalkng: NMEA 2000 (certified) (via DeviceNet adaptor) Sensitivity: High sensitivity - acquisition down to -163dBm No. of channels: 72 Positioning System: GPS & GLONASS Satellite Differential Type: WAAS (United States); EGNOS (Europe); MSAS (Japan); GAGAN (India) Differential acquisition: Automatic Position accuracy (95%): <15M Position accuracy with SDGPS (95%): <5M Speed accuracy (95%): <0.3kt Time to first fix from cold start: <2 minutes (< 45 seconds typical) Time to first fix from hot start: < 8 seconds -72 hour hold up battery allows for hot start Geodetic Datum: WGS84 Pole Mount for RS150 GPS Antenna Normalized SKU: E70310UPC Code: 723193796917

Raymarine T70327 AccessoriesRayStar 150 GPS Sensor w/Pole MountRS150 GPS SensorThe RS150 GPS is a high performance, 72-channel, remotely mounted GPS sensor for Raymarine navigation systems. The RS150 offers fast 10Hz position updates and enhanced accuracy. The RS150 is also a GNSS receiver and supports the GLONASS global navigation satellite system.Features: 72-channel GPS receiver Fast 10Hz position updates Satellite differential GPS-compatible. Space-Based Augmentation System (SBAS) enabled with WASS, EGNOS, MSAS and GAGAN support A GNSS receiver with GLONASS compatibility Low power consumption: 30mA (1 LEN) SeaTalkng and NMEA2000 compatible (using a device net adapter cable) Designed for low profile surface mounting or optional pole mounting Specifications: Nominal supply voltage: 12V D.C. Powered by N2K bus Operating voltage range: 8 - 32V DC Power consumption: 30 mA max (NMEA LEN = 1) Operating temperature: -13ºF to 131ºF (-25ºC to +55ºC) Relative humidity: max 93% Waterproof: IPx6/7 Supported connection protocols: SeaTalkng: NMEA 2000 (certified) (via DeviceNet adaptor) Sensitivity: High sensitivity - acquisition down to -163dBm No. of channels: 72 Positioning System: GPS & GLONASS Satellite Differential Type: WAAS (United States); EGNOS (Europe); MSAS (Japan); GAGAN (India) Differential acquisition: Automatic Position accuracy (95%): <15M Position accuracy with SDGPS (95%): <5M Speed accuracy (95%): <0.3kt Time to first fix from cold start: <2 minutes (< 45 seconds typical) Time to first fix from hot start: < 8 seconds -72 hour hold up battery allows for hot start Geodetic Datum: WGS84 Pole Mount for RS150 GPS AntennaRaymarine's Pole Mount specifically for the RS150 GPS Antenna. The RS150 has 72 channels and offers faster 10Hz performance and enhanced accuracy. The RS150 is also a GNSS receiver and supports the GLONASS global navigation satellite system. Normalized SKU: T70327UPC Code: 723193817513

Raymarine E70670 Weather InstrumentsRSW Wired - Smart Performance Wind Transducer - Short Arm with 30M CableThe RSW Wired, Smart Wind transducer is a professional-level wind sensor designed to deliver highly accurate calibrated wind speed and direction data. Supplied with a 30-meter Smart Wind mast cable as standard.Install & Go!Raymarine Smart Wind technology delivers expert-level accuracy without the need for additional, expensive processors or extensive calibration and set-up. Finely TunedThrough rigorous wind tunnel testing, we've fine-tuned and balanced the instrument to ensure that data from the masthead is accurate and consistent.Sail SmarterTrusted, high-accuracy True Wind data combined with the Alpha Performance Displays and Axiom Chartplotters let you sail smarter.Specifications:Length     Wind transducer (including cable): 657.762 mm (25.90 in) Wind transducer (excluding cable): 540.712 mm (21.29 in) Wired gateway: 155.61 mm (6.13 in) Width     Wind transducer: 46.96 mm (1.85 in) Wired gateway: 47.38 mm (1.88 in) Height     Wind transducer: 305.86 mm (12.04 in) Wired gateway: 30.61 mm (1.21 in) Power Nominal supply voltage: 12 V dc (via SeaTalk NG) Operating voltage range: 9 V to 16 V dc Power Consumption: < 100 mW Fuse rating: Ensure that the SeaTalk NG backbone is protected by a 5 A fuse NMEA 2000 LEN (Load Equivalency Number) - based on nominal 9 V rating: 1 Environmental Operating temperature range: -25°C to +55°C (-13°F to +131°F) Storage temperature range: -30°C to +70°C (-22°F to +158°F) Relative humidity: Masthead: 100%/Below deck: up to 93% @ 40°C Waterproof rating: Wind transducer: IPx6/IPx7/Wired gateway: IPx3 Wind: 115 mph (185 kph) Vibration: EN 60945:2002 (exposed) What's In The Box? No.10 x 3/4" self tapping screws x 4 (for mounting the wind transducer) No.7 x 3/4" self tapping screws x 2 (for mounting the gateway) 40 mm (1.57 in) heat shrink tube (required to insulate ground wire when shortening the mast cable) Ring crimp terminal (required for additional ground connection when the gateway is not mounted on a metal surface) Mast cable, 30 m (98.43 ft) reel Documentation Wind transducer Smart wind-wired gateway SeaTalk NG to DeviceNet adaptor cable, 120 mm (4.72 in) Normalized SKU: E70670UPC Code: 723193846629

Raymarine A80464 TransducersRealVision 3D™ All-In-One Transom Mount TransducerRaymarine’s RV-100 All-In-One Transom Mount Transducer lets you easily identify structures and locate fish with the life-like clarity of RealVision 3D sonar. The RV-100 is a 4-channel, Wide Spectrum CHIRP transducer with DownVision™, SideVision™, high frequency CHIRP fish targeting and RealVision 3D™ sonar inside. The transducer has a built-in attitude and heading reference system (AHRS) that stabilizes the sonar imagery, automatically compensating for vessel motion. You’ll enjoy crystal-clear imagery in waves, swells and while maneuvering. The RV-100 also has a built-in fast response water temperature sensor for quick, accurate readings.The RV-100 is designed for easy transom mounting on outboard-powered motor boats. It features a rugged, marine-grade stainless steel mounting bracket with integrated kick-up to prevent damage in the event of a strike with floating debris, rocks, or stumps.The RV-100 can also be removed from the transom bracket and attached to the stainless Jack-Plate mounting bracket (sold separately) which is ideal for bass boats, flats boats and skiffs. The RV-100 can also be mounted onto stepped hull vessels using the optional stainless steel step-mounting bracket (sold separately)What’s in the Box? RV-100 All-In-One Transom Mount Transducer with 8-meter (26-foot) cable Transom bracket Mounting hardware Installation instructions Normalized SKU: A80464UPC Code: 723193816523

Raymarine R70521 TransducersRV-100 RealVision 3D Transom Bracket KitThis transom mount transducer service kit includes all of the spare parts and accessories originally included with the RV-100 transducer. The bracket kit includes the stainless steel transom bracket and mounting screws, kick-up pivot hardware, transducer carrier bracket and the carrier mounting bolt. *The RV-100 transducer and cable is not included. Normalized SKU: R70521UPC Code: 723193817285
