Airmar 60WR-1 Transducers60WR-1 Crows Foot Transducer WrenchTransducer wrenches are available for all bronze low profile transducers. They are used to facilitate holding of the transducer and tightening of the hull nut. Wrenches are constructed of 3/16" thick mild steel. They can easily be bent or modified to accommodate challenging installation locations. For use with: SS60 B60 Normalized SKU: 60WR1

Airmar 75WR-1 Transducers75WR-1 Crows Foot Transducer WrenchTransducer wrenches are available for all bronze low profile transducers. They are used to facilitate holding of the transducer and tightening of the hull nut. Wrenches are constructed of 3/16" thick mild steel. They can easily be bent or modified to accommodate challenging installation locations. For use with: B75 SS75 Normalized SKU: 75WR1

Airmar D00342H Transducers10-Conductor In-Line Cable Splice - IP67Airmar CHIRP transducers are made with cables ending in a bare wire connection. Some sounders have internal terminal blocks to which these bare wires can be connected, but many CHIRP fishfinders and sounders use brand-specific connectors.Gemeco has introduced a new line of in-line splices that can be used to connect CHIRP transducers to the correct connector for a given application. These splices are available in two models, one for wires with up to 6 conductors and one for wires with up to 10 conductors. Both models have waterproof gland fittings rated to IP67. A 1.3mm hex-head wrench is included. Normalized SKU: D00342H

Airmar ANGLE FINDER TransducersDeadrise Angle Finder - Accuracy of ± 1/2°Accurate to 1/2 of 1°, this precision instrument, with strong ceramic magnet is designed for attachment to a carpenter's square or straight edge to overcome time consuming computation of angles.Features: Quickly measures boat hull deadrise angle. Ball Bearing construction for accuracy. Attach to straight edge or framing square Handy angle and grade chart on back of unit Normalized SKU: ANGLEFINDERUPC Code: 038987110061

Airmar 117WR-3 Transducers117WR-3 Double Handle Transducer WrenchTransducer wrenches are available for all bronze low profile transducers. They are used to facilitate holding of the transducer and tightening of the hull nut. Wrenches are constructed of 3/16" thick mild steel. They can easily be bent or modified to accommodate challenging installation locations. For use with: B117 B150 B744V B744VL B765C SS555 Normalized SKU: 117WR3

Airmar 164WR-3 Transducers164WR-3 Double Handle Transducer WrenchTransducer wrenches are available for all bronze low profile transducers. They are used to facilitate holding of the transducer and tightening of the hull nut. Wrenches are constructed of 3/16" thick mild steel. They can easily be bent or modified to accommodate challenging installation locations. For use with: B164 SS164 B175C SS264 Normalized SKU: 164WR3

Airmar 60WR-3 Transducers60WR-3 Double Handle Transducer WrenchTransducer wrenches are available for all bronze low profile transducers. They are used to facilitate holding of the transducer and tightening of the hull nut. Wrenches are constructed of 3/16" thick mild steel. They can easily be bent or modified to accommodate challenging installation locations. For use with: B60 SS60 Normalized SKU: 60WR3

Airmar 75WR-3 Transducers75WR-3 Double Handle Transducer WrenchTransducer wrenches are available for all bronze low profile transducers. They are used to facilitate holding of the transducer and tightening of the hull nut. Wrenches are constructed of 3/16" thick mild steel. They can easily be bent or modified to accommodate challenging installation locations. For use with: B75 SS75 Normalized SKU: 75WR3

Airmar DST820-BV-N2 TransducersDST820 Bronze Thru Hull - NMEA 2000 - 235kHzThe DST820 Smart Multisensor is the next evolution of Airmar’s industry-leading technology, replacing the DST810 and introducing PSTI compliance for enhanced onboard network security.With its secure QR-code setup, connecting your DST820 has never been easier—or safer. Simply scan the QR code and enter a one-time security password on your mobile device to protect your sensor on the network.Featuring Airmar’s high-performance Gen2 paddlewheel, the DST820 delivers unmatched speed-through-water accuracy— providing precise start-up data below 0.3 knots, linear accuracy from 0.6 knots, and stable, reliable readings all the way up to 45 knots.Whether you’re a day sailor, weekend cruiser, or tactical racer, accurate speed-through-water (STW) data helps you fine-tune sail trim and rig balance for maximum performance. For racers, precise STW readings enable accurate velocity made good (VMG) and target speed calculations, ensuring every tactical decision is data-driven.Together, the DST820 and Airmar’s CAST™ app make speed calibration simpler than ever. The free CAST app provides powerful calibration tools—once only available through costly PC-based software—now instantly accessible from your smartphone or tablet. Choose from basic or advanced calibration options to suit your needs.Beyond speed, the DST820 measures depth and water temperature, and provides a 5.7 Hz (5× per second) speed output with improved resolution. Its integrated attitude sensor delivers heel and trim data, enabling heel-compensated speed calibration across multiple heel angles and speed ranges—fast, intuitive, and completely independent of onboard instruments.With depth tracking from 0.5 m (1.6 ft) to 100 m (328 ft), the DST820 also provides reliable depth data to help ensure you never run aground.The result: industry-leading speed accuracy, wireless calibration convenience, and next-generation security—all in one powerful, compact sensor.Features: The DST820 is fully compliant with UK PSTI security standards, ensuring that the connection between DST820 and a mobile device is secure. The industry’s best speed paddlewheel – DST820 features the Gen2 paddlewheel for industry-leading speed performance from 0.3 knots to 45 knots. Smoother Speed – 5.7 Hz speed output (5X per second) for visibly smoother speed-through-water reporting and faster data for better decision making when every second counts. Integrated Attitude Sensor – For heel and trim, and used in advanced speed calibration. DST820 secure Bluetooth® connectivity to Airmar’s CAST app provides the ability to: Calibrate the DST820 in a simple, intuitive way from your mobile device. Conduct basic and advanced heel-compensated speed calibrations for improved speed-through-water outputs across the speed range. Advanced speed calibration allows for manual speed entries for multiple heel angles and up to 10 speeds, formerly only possible through expensive PC software. Specifications: Functions: Depth, Speed, Temperature, Attitude Mounting Style: Low Profile Thru-Hull Power Rating: 80 W Protocol Output: NMEA 2000® Housing: Bronze Max Deadrise Angle: 22° Hull Material: Fiberglass or metal Hole Size: 51 mm (2") Retractable housing: Yes Acoustic Window: Urethane Attitude Sensor: Yes Bluetooth Capable: YES Bluetooth BLE Cable-Length: 6 m (20') NMEA 2000® cable Certifications: CE Common Use: Cruising/Racing Sailboats, Leisure/Yachting, Fishing Conventional Beam: 10°x44° Data Rate: Depth: 1X/second, Speed: 5X/second, Heel/Trim: 10X/second Max Deadrise: Up to 22° Max Depth: 0.5 m (1.6') to 100 m (330') Minimum Depth: 0.5 m (1.6') NMEA 2000 LEN: 2 Pulses: 20,000 p/nm* (5.6 Hz per knot)—*p/nm = pulses per nautical mile Retrofits: Fits most Airmar 2" housings Speed Range: Up to 45 knots Temperature Accuracy: ±0.5°C (±1.8°F) Tilted Element: No Usable Shaft Length: 121 mm (4.75") Voltage: 9 to 16 VDC Water Temperature: -10° to 40°C (14° to 104°F) Normalized SKU: DST820BVN2

Airmar DT800SV-235-N2 TransducersAIRMAR DT800SV-235-N2 DT800 235KHZ NMEA2000 Smart TransducerModel: DT800235SVN2 Depth and fast-response water-temperature sensing Depth performance of 1.6 to 600' (0.5 to 183 m) 235 kHz frequency prevents mutual interference with other echosounders on the vessel NMEA 0183 standard data output Retractable insert for cleaning and safe storage Cable lengths up to 330' (100 m) are possible with no loss of performance Rugged stainless steel housing to accommodate vessel type or hull material The DT800 utilizes Airmar's proven Tilted Element and broadband technologies in this depth and temperature Smart™ Sensor. The DT800 is a low-profile, retractable, thru-hull sensor that accurately computes depth and temperature data and sends it to the NMEA 0183 network. Airmar's Smart™ Sensors have embedded microelectronics - the transducer element and signal processor are only millimeters apart. The signal from the depth transducer is processed right inside the sensor itself. All that is needed to receive depth and temperature data is a single cable into a compatible network or display.Normalized SKU: DT800SV235N2

Airmar DT800L-235-N2 TransducersDT800 NMEA 2000 Bronze Retractable Long Stem Thru-Hull with Depth & TemperatureThe DT800 utilizes Airmar’s proven Tilted Element and broadband technologies in this depth and temperature Smart™ Sensor. The DT800 is a long-stemmed, low-profile, retractable, thru-hull sensor that accurately computes depth and temperature data and sends it to any NMEA 2000® network. Airmar's Smart™ Sensors have embedded microelectronics—the transducer element and signal processor are only millimeters apart. The signal from the depth transducer is processed right inside the sensor itself. All that is needed to receive depth and temperature data is a single cable into a compatible network or display.The ceramic is tilted inside the housing, compensating for hull deadrise and orienting the transducer beam straight down. This results in strong echo returns and accurate depth readings. The DT800 is sold with a choice of rugged housings—plastic, bronze, or stainless steel—to accommodate any vessel type or hull material. These low-profile housings do not affect hull performance and will give accurate readings at high speeds. The housing features a water valve that minimizes water entering the boat when the retractable insert is being removed and replaced with the blanking plug.Features: Depth and fast-response water-temperature sensing Depth performance from 0.5 to 183 m (1.6 to 600') 235 kHz frequency prevents mutual interference with other echosounders on the vessel NMEA 2000 standard Retractable insert for cleaning and safe storage Specifications: Display Connector: NMEA 2000 Micro Power Rating: 100 W Functions: Depth, Temperature Material: Bronze Mounting Style: Low Profile Thru-Hull Tilt Angle: 0° Deadrise Range: Up to 12° w/out fairing. Up to 28° with fairing Hull Material: Fiberglass or wood Usable Shaft Length: 102 mm (4.00") Hole Size: 51 mm (2") Frequency Band: 235 kHz Voltage: 9 to 16 VDC Common Use: Cruising/Racing Sailboats, Leisure/Yachting, Fishing Country of Origin: USA Temperature Accuracy: ±0.5°C (±1.8°F) Cable Length: NMEA 2000®: 6 m (20') Conventional Beam: 12° Data Rate: 1X per second Max Deadrise Angle: 28° Speed Range: Up to 45 knots Tilted Element: Yes Weight: 3.9 kg (8.7 lb.) Max Depth: 0.5 to 180 m (1.6 to 590') Water Temperature: -10° to 40°C (14° to 104°F) Acoustic Window: Urethane Normalized SKU: DT800L235N2UPC Code: 801769002492

Airmar DT812PV-235-N2 TransducersDT812PV-235-N2 - 235kHz - Plastic Thru Hull Smart Sensor - 12° Tilt - NMEA 2000 - 6M CableAirmar has taken its proven Tilted Element™ and broadband technologies and applied them to its leading line of Smart™ Sensors. The DT800 is a low-profile, retractable, thru-hull sensor that computes accurate depth and temperature data and sends it to any NMEA 0183 or NMEA 2000® display. The DT800 operates at a frequency of 235 kHz and can run simultaneously with other Airmar 50/200 kHz transducers on-board with no interference. The broadband ceramic delivers depth readings to 183 m (600'), as well as accurate shallow-water readings in as little as 500 mm (1.6'). Available in fixed 0°, 12°, or 20° tilt, the DT800 is perfect for power and sailboat applications. It is sold with a choice of rugged housings— plastic, bronze, or stainless steel—to accommodate any vessel type or hull material. These low-profile housings do not affect hull performance and will provide accurate readings at high speeds.Airmar's Smart™ Sensors have embedded microelectronics—the transducer element and signal processor are only millimeters apart. The signal from the depth transducer is processed right inside the sensor itself. All that is needed to receive depth and temperature data is a single cable into a compatible device or display. Because the ceramic is tilted inside the housing, the transducer beam is oriented straight down, resulting in strong bottom echo returns and accurate depth readings. The retractable housing with a self-closing valve reduces water flow into the vessel when the transducer is removed for cleaning.Smart™ Sensor Features Broadband ceramic available with 0°, 12° and 20° tilt options Enhanced depth performance Maximum Depth Range: 180M (594’) Minimum range 0.5M (1.6’) Urethane face provides better sensitivity Excellent high-speed performance Fixed 12° tilt for 8° to 15° deadrise NMEA 2000 output 100 W RMS power Frequency: 235 kHz Cone: 12° All models have depth and temperature 235 kHz eliminates interference with fishfinders Retractable insert provides ease of serviceability Usable Shaft Length: 57mm (2.25”) 6M(19.8”) NMEA 2000® devicenet cable and connector 51mm (2”) housing Blanking plug included Accommodates maximum hull thicknesses 54 mm (2 1/8”) Accommodates minimum hull thicknesses 6.3 mm (0.25”) Normalized SKU: DT812PV235N2
