Raymarine A80703 TransducersRVM-100 Transom Mount Transducer RVM-100 all-in-one transom mount transducer is designed for Raymarine RealVision MAX compatible sonar modules, and RealVision MAX equipped chartplotters.  The RVM-100 lets you easily identify structures and locate fish with the life-like clarity of RealVision MAX technology. The RVM-100 is a 4-channel, Wide Spectrum CHIRP transducer with DownVision™, SideVision™, high-frequency CHIRP fish targeting, and 3D sonar inside. The transducer has a built-in attitude and heading reference system (AHRS) that stabilizes 3D sonar imagery, automatically compensating for vessel motion. You’ll enjoy an accurate and life-like model of the underwater environment that filters out distortions caused by waves, swells, or vessel maneuvering.  The RVM-100 also has a built-in fast-response water temperature sensor for quick, accurate readings.The RVM-100 is designed for easy transom mounting on outboard-powered motor boats. It features a rugged, marine-grade stainless steel mounting bracket with an integrated kick-up to prevent damage in the event of a strike with floating debris, rocks, or stumps.For bass boats, flats boats, and skiffs, an optional stainless Jack-Plate mounting bracket (A80480) and spacer kit (A80482) are available. *Works with Axiom 2 Pro RVM series, and RVM1600 Sounder ModuleFeatures: 600-Watt traditional CHIRP Designed for transom mounting on outboard boats Stainless Steel mounting bracket with an integrated kick-up feature 8M Cable Normalized SKU: A80703UPC Code: 723193842416

Airmar R509C-LM TransducersAirmar R509 Low-Medium Chirp, 3kW, w/FB, No Connector, DTModel: R509C-LM Depth and fast-response water-temperature sensing 2 to 3 kW of power for exceptional deep-water performance Low frequency: 28 to 60 kHz, 23° to 9° port-starboard beamwidth, 11° to 5° fore-aft beamwidth, Maximum depth of 3048 m (10000') Medium frequency: 80 to 130 kHz, 13° to 8° beamwidth, Maximum depth of 914 m (3000') 82 kHz of total bandwidth from one transducer Covers popular fishing frequencies of 38, 50, 88, and 107 kHz plus everything else in the bandwidth Urethane housing with fairing for optimal performance Patented Xducer ID® technology Having the right tool for the job makes the job easier and gives better results. The right tool for covering deep-water haunts of swordfish, tuna, and other species is a 2-3 kW, low and medium-frequency transducer. The Chirp-ready R509LM delivers the deep-water performance of the low frequency down to 3048 m (10000') plus the detailed returns produced by the narrower beams of the medium band.Chirp technology shows 5 to 10 times-greater detail and resolution than conventional frequencies. The R509LM transmits across the low-frequency bandwidth of 28 to 60 kHz and operates in the medium-frequency range of 80 to 130 kHz. This transducer delivers up to 82 kHz of total bandwidth in a single installation.Specifications Acoustic Window Epoxy/urethane Cable-Length 15 m (49') Connector Bare Wire Deadrise Range Up to 25° with fairing Frequency Low-Medium Low Frequency 28-60 kHz Low Frequency Beamwidth 11°x23°-5°x9° Medium Frequency 80-130 kHz Medium Frequency Beamwidth 13°-8° Housing Material Urethane Max Deadrise Up to 22° Normalized SKU: R509CLM

Lowrance 000-16061-001 Transducers Lowrance ActiveImaging™ HD 3-in-1 (High/Wide)— SideScan Fish Reveal Step up to the ultimate fishfinding clarity with new, high-definition Active Imaging™ HD 3-in-1 sonar. Get the clearest images of fish and structure from Lowrance® High/Wide CHIRP sonar, high-frequency (up to 1.2MHz) SideScan/DownScan Imaging™, plus FishReveal™ DownScan and a new FishReveal SideScan* view, making fish identification easier. *Requires S3100 sonar module for Fish Reveal SideScan on HDS Pro Features: High definition (up to 1.2MHz) SideScan and DownScan Imaging deliver the clearest images of fish and structure High/Wide Lowrance CHIRP delivers superb clarity and target separation over a wider coverage area FishReveal™ with new SideScan* view as well as DownScan Supports Medium and High/Wide CHIRP (83/200kHz) + 455/800kHz and 455/1.2MHz frequencies Smart transducer design boosts signal clarity Compatible directly with Lowrance HDS PRO or with an S3100 module *Requires S3100 sonar module and relevant transducer for Fish Reveal SideScan on HDS PRO Normalized SKU: 00016061001UPC Code: 9420064130351

Lowrance 000-16060-001 Transducers Lowrance ActiveImaging™ HD 3-in-1 (Medium/High)— SideScan Fish Reveal transom mount Transducer Step up to the ultimate fishfinding clarity with new, high-definition Active Imaging™ HD 3-in-1 sonar. Get the most precise images of fish and structure from Lowrance® CHIRP sonar, high-frequency (up to 1.2MHz) SideScan/DownScan Imaging™, plus FishReveal™ DownScan and a new FishReveal SideScan* view, making fish identification easy. *requires S3100 sonar module for Fish Reveal SideScan Features: High definition (up to 1.2MHz) SideScan and DownScan Imaging deliver the most precise images of fish and structure Lowrance CHIRP with superb clarity and target separation FishReveal™ with new SideScan* view as well as DownScan Supports Medium and High CHIRP (83/200kHz) and 455/700/1000/1200 kHz frequencies Smart transducer design boosts signal clarity Compatible directly with Lowrance HDS PRO or with an S3100 module with HDS LIVE, HDS Carbon, and Elite FS. *requires S3100 sonar module and relevant transducer for Fish Reveal SideScan on HDS PRO Normalized SKU: 00016060001UPC Code: 9420064130344

Lowrance 000-16062-001 TransducersStep up to the ultimate fishfinding clarity with new, high-definition Active Imaging 3-in-1 HD sonar up to 1Mghtz. Get the clearest images of fish and structure from Lowrance CHIRP sonar, SideScan and DownScan Imaging. Our clearest sonar ever, Active Imaging HD delivers the highest-definition views of Lowrance CHIRP, SideScan and DownScan Imaging. Experience a new level of clarity and improved target separation with extremely detailed views of fish and fish-holding structure like rockpiles, standing timber, weedbeds, ditches, drop-offs and more. Active Imaging HD 3-in-1 (CHIRP/Side/Down) Transducer High definition up to 1MHz SideScan and DownScan Imaging deliver the clearest images of fish and structure, Lowrance CHIRP with superb clarity and target separation Supports Medium and High CHIRP (83/200kHz) + 455/800kHz and 455/1Mghtz frequencies Smart transducer design boosts signal clarity Compatible with Lowrance HDS PRO or with a S3100 module with HDS LIVE, HDS Carbon, Elite FS Normalized SKU: 00016062001UPC Code: 9420064130368

Lowrance 000-16063-001 TransducersStep up to the ultimate fishfinding clarity with new, high-definition Active Imaging 2-in-1 HD sonar up to 1Mghtz. Get the clearest images of fish and structure from Lowrance SideScan and DownScan Imaging. Our clearest sonar ever, Active Imaging HD delivers the highest-definition views of Lowrance CHIRP and DownScan Imaging. Experience a new level of clarity and improved target separation with extremely detailed views of fish and fish-holding structure like rockpiles, standing timber, weedbeds, ditches, drop-offs and more. Active Imaging HD 2-in-1 (Side/Down) Transducer High definition up to 1MHz SideScan and DownScan Imaging deliver the clearest images of fish and structure Supports Medium and High CHIRP (83/200kHz) + 455/800kHz and 455/1Mghtz frequencies Smart transducer design boosts signal clarity Compatible with Lowrance HDS PRO or with a S3100 module with HDS LIVE, HDS Carbon, Elite FS Normalized SKU: 00016063001UPC Code: 9420064130375

Lowrance 000-15961-001 TransducersActiveTarget 2 module only. ActiveTarget 2 gives you the highest resolution and clearest live views of fish and structure. By watching fish respond to your lure in real-time, you can make the quick adjustments that make the difference and help you catch more fish. Available on HDS Pro, HDS Live and ELITE FS systems*. Module only for ActiveTarget 2 Clearest live action views of fish and structure Smoothest underwater images for quicker interpretation See all around your boat with Forward, Down and Scout views See multiple views simultaneously with HDS Pro, and enable 180 and Scout Wide views for more effective bait tracking ahead of boat with second optional ActiveTarget 2 transducer Normalized SKU: 00015961001UPC Code: 9420064128259

Lowrance 000-15962-001 TransducersActiveTarget 2 transducer only. ActiveTarget 2 gives you the highest resolution and clearest live views of fish and structure. By watching fish respond to your lure in real-time, you can make the quick adjustments that make the difference and help you catch more fish. Available on HDS Pro, HDS Live and ELITE FS systems*. Transducer only for ActiveTarget 2 Use for two ActiveTarget Systems for multiple views simultaneously on HDS PRO Smoothest underwater images for quicker interpretation See all around your boat with Forward, Down and Scout views See multiple views simultaneously with HDS Pro, and enable 180 and Scout Wide views for more effective bait tracking ahead of boat with second optional ActiveTarget 2 transducer Normalized SKU: 00015962001UPC Code: 9420064128266

Lowrance 000-15640-001 TransducersLowrance HDI Skimmer® Transducer 83/200/455/800kHz with built in temp. 8-Pin Push ConnectorModel: 000-15640-001Hybrid Dual Imaging™ (HDI) transducer (83/200/455/800) - The power of two award-winning technologies -- Broadband Sounder PLUS Exclusive DownScan Imaging™ -- combined to provide the best-possible view beneath your boat.Specifications Frequency 83/200/455/800 kHz Temperature Sensor Yes Mounting Style Transom Mount Elements 2 Connector 8 pin push fit Cable length 6m (20') Normalized SKU: 00015640001UPC Code: 9420064115938

Garmin 010-02719-19 TransducersGarmin LVS62 Transducer Only for Livescope XRModel: 010-02719-10 Explore the deep with an extended range up to 500’ in freshwater and 350’ in saltwater. Find fish circling your boat with clear views close around your hull. Upgrade your current LiveScope System black box (GLS™ 10 sonar module) with just a new transducer. Get maximum contrast and clarity in your images with vivid color palettes. Don’t miss a thing with supported Forward, Down and Perspective modes plus necessary mount. You didn’t think it could get better, but it did with the extended range of the LiveScope XR System. It’s the latest in LiveScope technology, now for coastal and open-water fishing.The Reverse Range Offset feature uses more of the screen to display fish and structure up to 500’ in freshwater and 350’ in saltwater.The Compress Range feature gives you a clear view close to your boat while keeping an eye on targets farther away.Real-time sonar ensures that your live images are as accurate as possible.A built-in stabilization system keeps the sonar image on your compatible chartplotter steady, even in rough conditions.Choose from seven vivid color options — including aqua, Caribbean, lava and more — to see fish and structure in maximum contrast and clarity.Now scout even farther ahead of your boat to see what’s happening in real time.Explore live views of the activity deeper beneath your boat.See under the water with a view from your perspective above the water.Specifications General DIMENSION LVS62 transducer: 8.20" x 3.98" x 2.76" (20.8 x 10.1 x 7.0 cm) WEIGHT LVS62 transducer with cable: 3.92 lbs (1.78 kg) WATERPROOF IPX7 TRANSDUCER BEAMWIDTH 20° x 135° TRANSDUCER CABLE LENGTH 20 ft TRANSDUCER NUMBER OF PINS 21 TEMPERATURE RANGE LVS62 Transducer: Operating: 0 C to 40 C Sonar Features & Specifications FREQUENCY 265 - 550 kHz MAXIMUM DEPTH Freshwater: Down and Forward: 500’ (152.0 m) Saltwater: Down and Forward: 350’ (106.0 m) SONAR TYPE Live TARGET SEPARATION @100' 22" PERSPECTIVE MODE MOUNT INCLUDED Yes Connections GARMIN MARINE NETWORK PORTS 1 (small connector) Electrical Features POWER INPUT 10-32 V POWER USAGE 21 W typical, 58 W max TRANSMIT POWER 500 W FUSE 7.5 A COMPASS-SAFE DISTANCE 7" (0.18 m) What's in the Box: LiveScope XR LVS62 transducer Perspective mount (LiveScope XR LVS62 transducer only) Trolling motor barrel mount Shaft mount Power cable Documentation Normalized SKU: 0100271919

Furuno 225T-SS904 TransducersThru-Hull Side-Scan Transducer 12-Pin for TZtouch3 12, 16 & 19 ModelsThe 225T-SS904 is a Thru-Hull transducer that works with the built-in Side-Scan functionality on your NavNet TZtouch3 TZT12F, TZT16F, or TZT19F MFD.Features: 150 watts on each side CHIRP 220-240kHz Stainless Steel Thru-Hull with Temperature 12-pin connector 12m (40ft) cable Normalized SKU: 225TSS904UPC Code: 611679398888

Garmin 010-02719-10 TransducersLiveScope™ XR LVS62 Transducer OnlyTHE BEST OF THE BEST JUST HIT THE OPEN WATERYou didn’t think it could get better, but it did with the extended range of the LiveScope XR System. It’s the latest in LiveScope technology, now for coastal and open-water fishing.Features: Explore the deep with an extended range up to 500’ in freshwater and 350’ in saltwater.  Find fish circling your boat with clear views close around your hull. Upgrade your current LiveScope System black box (GLS™ 10 sonar module) with just a new transducer.  Get maximum contrast and clarity in your images with vivid color palettes.  Don’t miss a thing with supported Forward, Down and Perspective modes plus necessary mount.  The Long ViewThe Reverse Range Offset feature uses more of the screen to display fish and structure up to 500’ in freshwater and 350’ in saltwater.A Close ViewThe Compress Range feature gives you a clear view close to your boat while keeping an eye on targets farther away.Real-Time Images Real-time sonar ensures that your live images are as accurate as possible.Image Stabilization A built-in stabilization system keeps the sonar image on your compatible chartplotter steady, even in rough conditions.Vivid Color Palettes Choose from seven vivid color options — including aqua, Caribbean, lava and more — to see fish and structure in maximum contrast and clarity.Forward Mode Now scout even farther ahead of your boat to see what’s happening in real time.Down Mode Explore live views of the activity deeper beneath your boat.Perspective Mode See under the water with a view from your perspective above the water.In The Box: LiveScope XR LVS62 transducer Perspective mount (LiveScope XR LVS62 transducer only) Trolling motor barrel mount Shaft mount Power cable Documentation  Normalized SKU: 0100271910UPC Code: 753759298548
