Download LiteratureSI-TEX T-760 Radar DomeT-760 Compact Color Radar with 4kW 18" DomeBig radar performance and features are available for any size boat -- and budget with the SI-TEX T-760. A vertically oriented, slim case boasts advanced touch screen technology and a host of professional features. Powerful 4kW output ensures superior target acquisition and tracking in the the most challenging conditions.The T-760 Series case measures only 5.4" W X 8.9" H X 3.5" D. Yet, this system boasts a long list of professional-grade features, including powerful 4kW output, up to 24nm range, multi-speed antenna rotation, standard 50-target AIS tracking capability and standard 10-target MARPA - features often associated with larger, costlier systems. Control of all these features is achieved via the T-760's touch screen LCD display and single rotary encoder dial, for simple, intuitive operation.The series includes the T-760, equipped with an 18-inch compact radome antenna for solid performance in a wide range of conditions and range scale choices from 1/8th nm to 24nm. Both the T-760 and T-761 feature powerful 4kW transmitters, ensuring accurate detection and presentation of targets large and small. Both models also offer multi-speed antenna rotation (16/27/36/48rpm) for optimum target detection and tracking over a range of boat speeds.Among many other notable standard features of the T-760 Series are Relative Motion, True Motion, North-Up, Head-Up and Course-Up presentation modes, Auto or Manual Sea/Rain Clutter modes, 11 Trail Indication settings (including Off and Continuous), and more. With input from a SI-TEX Metadata AIS module (or other AIS receiver), the T-760 Series can track up to 50 AIS targets simultaneously for enhanced navigational safety in crowded waterways. With input of bearing, ship's speed and lat/lon data, the T-760 Series empowers navigators with professional MARPA tracking of up to 10 targets at distances up to 20nm.In the SI-TEX tradition, the T-760 Series radar is ruggedly built to withstand harsh conditions at sea on commercial as well as recreational vessels. SI-TEX's two-year limited warranty and Long Island, New York-based service department are the navigator's assurance of reliable performance and long-term satisfactionFeatures: 7" color LCD display 10M Cable Intuitive touch screen/rotary dial control Standard 50 target AIS tracking Standard 10 target MARPA Multi-speed (16-48 rpm) antenna rotation for optimum performance in real-world conditions Features include Relative Motion/True Motion/Head-Up/North-Up Optional color RGB video output Specifications:ARPA Available = NONE Array Size (Inches) = NONE Cable Length (Meters) = NONE Hor/Vert Beam Width = NONE Power - Output (Kilowatts) = NONE Range - Max (Miles) = 24-Mile Range Scale = NONE Resolution (VxH) = NONE Screen Size = 7"Normalized SKU: T760UPC Code: 010407230740SI-TEX T-760 Literature Download  Quick Reference Guide  Owners Manual  Product Brochure

Furuno ARP11 Radar DomeARP11 10-Target Auto PlotterThe ARP11 is a 10-target auto plotter designed for use with NavNet and NavNet vx2, as well as the FR8002 Radar series. The ARP automatically tracks automatically or manually acquired radar targets and calculates their courses and speeds, indicating them by vectors. Since the data generated by the auto plotter are based on what radar targets are selected, the radar must always be optimally tuned for use with the ARP to ensure required targets will not be lost or unwanted targets such as sea returns and noise will not be acquired and tracked. The plotting accuracy and response of this ARP meets IMO standards. Tracking accuracy is affected by the following: Tracking accuracy is affected by course change. One to two minutes is required to restore vectors to full accuracy after an abrupt course change. (The actual amount depends on gyrocompass specifications.) The amount of tracking delay is inversely proportional to the relative speed of the target. Delay is on the order of 15-30 seconds for high relative speed; 30-60 seconds for low relative speed. WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: ARP11UPC Code: 611679247032

Furuno DRS6AX Radar Dome6kW UHD Digital Radar f/TZtouch & TZtouch2 - Less AntennaDRS6AX "X-Class" , a whole new class of Radar!Pushing the boundaries of what is possible with conventional Radar technology, DRS6AX "X-Class" marks yet another leap forward for FURUNO. Improved in almost all aspects, DRS6AX "X-Class" Radar features improved short range detection, as well as an impressive long range detection of up to 120 nautical miles.The redesigned pedestal unit is 20% lighter than previous DRS6AX model and features an updated motor for significantly lower noise levels. Combined with an updated smart-connector cable, installation and maintenance is simpler than ever before.Fast Target Tracking™ function adopted from our commercial Radar FAR3000, is also available on the DRS6AX "X-Class." Target course and speed vectors are displayed instantly with the press of a button. Target vectors increase situational awareness and can increase overall safety on your vessel.Features: 6kW Power Output Enhanced target detection, both short and long range Minimum detection range of just 20M Fast Target Tracking™ Bird Mode Pedestal unit, 20% lighter than previous DRS6A unit, updated low noise motor No PSU required, decreasing total costs Easy installation without the need to open pedestal unit New smart-connector cable Choice of 3.5', 4' or 6' Antenna Compatible with NavNet TZtouch and NavNet TZtouch2 (not compatible with NavNet 3D or earlier NavNet models) The DRS6AX is a 24V system; a converter will be required for use with 12V power systems Normalized SKU: DRS6AX

  Watch VideoRaymarine E70210 Radar DomeQuantum™ Q24C Radome w/Wi-Fi & Ethernet - 10M Power Cable IncludedRaymarine Quantum Radar, by FLIR, is the next generation of marine radar featuring CHIRP pulse compression technology.Setting a standard for compact solid state radar, Quantum delivers superior radar imaging on both long and extremely short ranges. Integrated Wi-Fi and thin cabling simplifies installation plus Quantum's energy efficient and lightweight design provides safe radiated emissions and substantially reduced power consumption. Superior Radar ImagingFLIR's exclusive ATXT advanced target separation technology displays targets like boats, landmarks, rocks, buoys, and weather cells with unsurpassed resolution and separation quality.CHIRP Pulse CompressionExcellent short-range detection and enhanced target detail with 18' (6m) minimum range. CHIRP Pulse compression ensures more energy reaches each target, resulting in superior imaging on long ranges.Small Target DetectionQuantum's CHIRP Pulse Compression technology identifies small, weak targets, even when positioned close to strong returns.Simplified InstallationSimple Wi-Fi connection between Quantum and any Raymarine LightHouse II powered MFD. Quantum's small diameter power cable is easy to route through tight spaces. Easy to upgrade - Quantum uses the same bolt pattern as previous generation radars. Optional Quantum adapter cable eliminate the need to run new radar cables.Energy Efficient & Lightweight DesignWeighs 50% less than traditional magnetron radars. Safe Emissions thanks to Quantum's low power solid state radar transmitter. Very low power consumption (17 Watts transmit and 7 watts standby). Extended vessel battery life when under sail. Specifications:Array Size (Inches) = NONE Hor/Vert Beam Width = NONE Power - Output (Kilowatts) = NONE Range - Max (Miles) = NONENormalized SKU: E70210UPC Code: 723193783931Raymarine E70210 Video

  Watch VideoRaymarine T70243 Radar DomeQuantum™ Q24C Radome w/Wi-Fi & Ethernet - 10M Power & 10M Data Cable IncludedRaymarine Quantum Radar, by FLIR, is the next generation of marine radar featuring CHIRP pulse compression technology.Setting a standard for compact solid state radar, Quantum delivers superior radar imaging on both long and extremely short ranges. Integrated Wi-Fi and thin cabling simplifies installation plus Quantum's energy efficient and lightweight design provides safe radiated emissions and substantially reduced power consumption. Superior Radar ImagingFLIR's exclusive ATX™ advanced target separation technology displays targets like boats, landmarks, rocks, buoys, and weather cells with unsurpassed resolution and separation quality.CHIRP Pulse CompressionExcellent short-range detection and enhanced target detail with 18' (6m) minimum range. CHIRP Pulse compression ensures more energy reaches each target, resulting in superior imaging on long ranges.Small Target DetectionQuantum's CHIRP Pulse Compression technology identifies small, weak targets, even when positioned close to strong returns.Simplified InstallationSimple Wi-Fi connection between Quantum and any Raymarine LightHouse II powered MFD. Quantum's small diameter power cable is easy to route through tight spaces. Easy to upgrade - Quantum uses the same bolt pattern as previous generation radars. Optional Quantum adapter cable eliminate the need to run new radar cables.Energy Efficient & Lightweight DesignWeighs 50% less than traditional magnetron radars. Safe Emissions thanks to Quantum's low power solid state radar transmitter. Very low power consumption (17 Watts transmit and 7 watts standby). Extended vessel battery life when under sail. Specifications:Array Size (Inches) = NONE Hor/Vert Beam Width = NONE Power - Output (Kilowatts) = NONE Range - Max (Miles) = NONENormalized SKU: T70243UPC Code: 723193793398Raymarine T70243 Video

  Download LiteratureFuruno FR8065 Radar DomeFR8065 12.1" 6kW, 72nm UHD Radar System - Less AntennaState of the art signal processing an& UHD digital radar technology!The 12.1" color radar FR8005 series features state of the art signal processing, which makes it easier to identify targets in heavy rain and poor visibility. The FR8005 radar can discern between rain and surface reflections, providing the ability to find and track the movement of rain clouds as well as removing unnecessary echoes. For tracking the movement of other vessels at sea, "True Motion Trails" can be displayed as well as AIS/TT target-tracking with a zoom display function. When the vessel is in motion, the radar echoes move smoothly on the main display thanks to the "True View Mode."Target-Tracking Zoom Display FunctionEven during rainfalls or severe weather conditions, radar echoes are clearly displayed, and unnecessary echoes can be removed instantly with ease. Compared with current radars (FR8002 series) the technology for removing sea, rain and snow clutter has been greatly enhanced utilizing FURUNO's state of the art knowledge in digital signal processing. When using the Target mode, vessels close by and vessels on intersecting courses are automatically displayed zoomed in. These targets will remain displayed for as long as they pose any concern. Target Trails are also displayed, making it easy for the user to determine the movements of individual vessels.True Trail ModeWhen using the True Trail Mode, moving objects will show up on the main screen with a colorful trail. These trails make it possible to see the movement of nearby vessels in the blink of an eye.True View ModeThe radar echoes move smoothly on the main display thanks to the "True View Mode". The True View Mode is based on the head-up mode. During the radar sweep, the echoes move according to the heading of your ship. Since the echoes move in real-time, the discrepancy between an observed target and what is displayed on the radar screen is greatly reduced.Full-Screen Mode and Off-Center ModeMake use of the whole display surface with the Full-Screen mode, giving you more information when making important decisions. When combining Full-Screen mode with Off-Center mode any target or point of interest can be observed in detail. The overlay information can be turned off, to observe targets obstructed by the text as well as providing an unobstructed radar view.Target Tracking and AIS DisplayThe Target Tracking (TT) feature continously tracks and provides positional information for up to ten targets. An AIS device-equipped FR8005 series radar can track target heading, name, speed and direction of movement. With AIS it is possible to identify and track the movement of other vessels in heavy fog, during nighttime and otherwise difficult conditions. Another benefit is that with AIS you can identify obscured targets that the radar signals cannot reach, giving you more time to act. AIS can display up to 100 targets simultaneously, TT can display up to 10 different targets simultaneously.Standard Features: 12.1" SVGA color LCD with echo colors of 32 levels Wide viewing angle LCD for great visibility from any direction One-touch auto-adjust settings for Gain/Sea clutter/Rain clutter Optional 48 rpm high-speed antenna rotation displays information clearly in narrow passages and on high-speed vessels Superior short range target detection capability Advanced auto modes to automatically adjust gain, tuning and AC rain/sea for delivering the best available pictures True motion echo trail Display Modes: Head-up, Course-up, North-up, True View, True Trail Up to three programmable radar settings can be selected to give the best radar performance in different sea conditions Specifications:Screen Size = 12.1" Resolution (VxH) = 800 x 600 Range Scale = 0.0625 to 72 nm Range - Max (Miles) = 72 Power - Output (Kilowatts) = 6 Hor/Vert Beam Width = NONE Cable Length (Meters) = 15m Array Size (Inches) = NONE ARPA Available = YesNormalized SKU: FR8065Furuno FR8065 Literature Download  Owners Manual  Product Brochure

  Download Literature  Watch Video Furuno DRS4W Radar Dome 1st Watch Wireless RadarUntether & Explore - Furuno 1st Watch Wireless Radar, which you can access directly from your iOS devices.Move Around & ExploreWith Furuno's 1st Watch Wireless Radar, you can do things previously impossible. You can bring the Radar display whenever you go, even put it on the iPhone in your pocket. Since the display is untethered, you are free to roam the vessel while maintaining full situational awareness of your surroundings. For example, you can bring the Radar display with you when jumping into the cabin quickly to grab a fishing gear or other tools needed during your voyage.Easy To Use At 1st GlancePlug in the Radar, set up the free app from App Store and you're good to go. With familiar gestures it's a breeze to use; you can even use two iOS devices simultaneously. The app has been created with simplicity and efficiency in mind, providing reliable information that is easily accessible.Less Cables, More FlexibilityInstallation is simple with its compact and lightweight Radar antenna. Mount it, plug in the power cord and you're done. The portability of the iOS devices makes the system a good option for boats where space constrictions are of concern.Features: 4kW Radar antenna, powerful yet compact in size (same housing as DRS2D) Wireless LAN, the first Radar in the world accessible from your iOS devices No extra wiring is needed except the power source, making installation a breeze Exceptionally simple setup and intuitive operation with a user-friendly and free iOS app Extremely economical power consumption Vivid, multi-color Radar target presentation (1/8nm - 24nm) Simple touch interface with familiar gestures User-selectable range scale from 0.125 to 24 nm Simultaneously connect and utilize 2 iOS devices, via a high-sensitivity wireless signal Does not include cable, sold separately (#001-266-010-00 15m) Power Requirements: 12-24 VDC Only 24W In the Box: 19" Dome 4KW Wireless Radar 15m Power Cable *Please note: iOS devices and accessories are sold separately and do not come included with this product. Specifications: Range - Max (Miles) = 0.125 to 24 nm Power - Output (Kilowatts) = 4 kW Hor/Vert Beam Width = 7.2°/25° Array Size (Inches) = NONE Normalized SKU: DRS4WUPC Code: 611679357090 Furuno DRS4W Literature Download   Owners Manual  Product Brochure Furuno DRS4W Video
