Raymarine T70169 Radar DomeRD424HDIncludes 10m Cable - A80228 24" HD Dome - E92143 Raymarine's HD Digital radome scanners combine the power and clarity of HD Digital signal processing with an ultra-compact scanner suitable for all types of vessels. Compatible with a,c & e Series Multifunction Displays, these radomes offer a 256-color radar display and the clearest, most lifelike radome presentation available from any radome scanner.The RD424HD feature the same adaptive digital receiver technology found in our open array antennas. By adjusting automatically to changing environmental and sea conditions, the HD Digital radomes provide crisp, accurate contact echoes at short ranges, as well as outstanding long range performance up to 48 nautical miles. RD424HD Features: Adaptive digital receiver automatically adjusts to changing environmental and see conditions for a dramatically clearer picture Fast digital receiver processor 256 color multi-level target display with selectable color palettes New Bird Mode automatically optimizes the receiver for detecting sea birds above schools of fish¹ New High Speed Mode (48 RPM) automatically engages for optimal tracking of high speed targets at short ranges Dual-range mode allow you to monitor both long and short ranges simultaneously with a single scanner and display Specifications: Array Size (Inches) = 24" Hor/Vert Beam Width = 3.9/25° Power - Output (Kilowatts) = 4kW Range - Max (Miles) = 48nm Normalized SKU: T70169UPC Code: 723193774502

Raymarine T70168 Radar DomeRD418HD w/10M CableIncludes 10M Cable - A80228 18" HD Digital Radar Dome RD418HD - E92142 Raymarine's HD Digital radome scanners combine the power and clarity of HD Digital signal processing with an ultra-compact scanner suitable for all types of vessels. Compatible with a, c & e Series Multifunction displays these radomes offer a 256-color radar display and the clearest, most lifelike radar presentation available from any radome scanner. The RD418HD and RD424HD feature the same adaptive digital receiver technology found in our open array antennas. By adjusting automatically to changing environmental and sea conditions, the HD Digital radomes provide crisp, accurate contact echoes at short ranges, as well as outstanding long range performance up to 48 nautical miles. Rain, fog and high seas are no match for the HD Digital radome. Using it's powerfulprocessor the HD Digtal radome intelligently seperates true contacts from noise and clutter. The RD418HD and RD424HD offer small boat captains all of the same capabilities usually reserved for larger capacity boats.FEATURES Adaptive digital receiver automatically adjusts to changing environmental and sea conditions for a dramatically clearer picture New high speed (48rpm) target tracking Fast digital receiver processor 256 color multi-level display with selectable color palettes New Bird Mode automatically optimizes the receiver for detecting sea birds above schools of fish Automatic harbor, coastal, offshore and buoy operating modes Dual-range mode allows you to monitor both long and short ranges simultaneously with a single scanner and display Specifications:Array Size (Inches) = 18" Hor/Vert Beam Width = 4.9/25° Power - Output (Kilowatts) = 4kw Range - Max (Miles) = 48Normalized SKU: T70168UPC Code: 723193774496

  Download LiteratureRaymarine E92142 Radar DomeRaymarine's new HD Digital radome scanners combine the power and clarity ofHD Digital signal processing with an ultra-compact scanner suitable for all types of vessels. Compatible with C-Series Widescreen, E-Series Widescreen and G-Series Multifunction displays these radomes offer a 256-color radar display and the clearest, most lifelike radar presentation available from any radome scanner. The RD418HD and RD424HD feature the same adaptive digital receiver technology found in our open array antennas. By adjusting automatically to changing environmental and sea conditions, the HD Digital radomes provide crisp, accurate contact echoes at short ranges, as well as outstanding long range performance up to 48 nautical miles. Rain, fog and high seas are no match for the HD Digital radome. Using it's powerfulprocessor the HD Digtal radome intelligently seperates true contacts from noise and clutter. The RD418HD and RD424HD offer small boat captains all of the same capabilities usually reserved for larger capacity boats.FEATURESAdaptive digital receiver automatically adjusts to changing environmental and sea conditions for a dramatically clearer picture New high speed (48rpm) target tracking Fast digital receiver processor 256 color multi-level display with selectable color palettes New Bird Mode automatically optimizes the receiver for detecting sea birds above schools of fish Automatic harbor, coastal, offshore and buoy operating modes Dual-range mode allows you to monitor both long and short ranges simultaneously with a single scanner and display Specifications: Hor/Vert Beam Width = 4.9/25 degree Range - Max (Miles) = 48 Power - Output (Kilowatts) = 4kw Array Size (Inches) = 18" RAYMARINE RD418HD 4KW 18" HD DIGITAL RADOME NO CABLE Normalized SKU: E92142UPC Code: 091975005121Raymarine E92142 Literature Download   Owners Manual

  Download LiteratureRaymarine E92143 Radar DomeRaymarine's new HD Digital radome scanners combine the power and clarity ofHD Digital signal processing with an ultra-compact scanner suitable for alltypes of vessels. Compatible with C-Series Widescreen, E-Series Widescreenand G-Series Multifunction displays these radomes offer a 256-color radardisplay and the clearest, most lifelike radar presentation available from any radome scanner. The RD418HD and RD424HD feature the same adaptivedigital receiver technology found in our open array antennas. By adjustingautomatically to changing environmental and sea conditions, the HD Digitalradomes provide crisp, accurate contact echoes at short ranges, as well asoutstanding long range performance up to 48 nautical miles. Rain, fog andhigh seas are no match for the HD Digital radome. Using it's powerfulprocessor the HD Digtal radome intelligently seperates true contacts fromnoise and clutter. The RD418HD and RD424HD offer small boat captains all ofthe same capabilities usually reserved for larger capacity boats.FEATURESAdaptive digital receiver automatically adjusts to changingenvironmental and sea conditions for a dramatically clearer picture New high speed (48rpm) target tracking Fast digital receiver processor 256 color multi-level display with selectable color palettes New Bird Mode automatically optimizes the receiver for detecting seabirds above schools of fish Automatic harbor, coastal, offshore and buoy operating modes Dual-range mode allows you to monitor both long and short rangessimultaneously with a single scanner and display Specifications: Hor/Vert Beam Width = 3.9/25 degree Range - Max (Miles) = 48nm Power - Output (Kilowatts) = 4kw Array Size (Inches) = 24" RAYMARINE RD424HD 4KW 24" HD DIGITAL RADOME NO CABLE Normalized SKU: E92143UPC Code: 091975005138Raymarine E92143 Literature Download   Owners Manual

B & G 000-14538-001 Radar DomeHALO24 Radar Dome with Doppler TechnologyHALO24 radar offers an almost real-time view, with industry-first 60 RPM operation at close range for the ultimate in collision avoidance. Identify hazards in an instant with VelocityTrack™ Doppler technology, and enjoy simultaneous short and long-range coverage—up to 48 nautical miles—from one compact 24-inch dome antenna.See Near and Far with One Compact Dome Perfect for a wide range of sailboats, fishing boats and smaller powerboats, HALO24 comes in a compact dome antenna and delivers high-quality short, mid and long-range detection. Monitor two distance ranges at once in Dual Range mode, which enables you to keep an eye on far away weather cells while watching for collision hazards up close. HALO24 radar’s pulse-compression technology means no compromises in detection at either selected range, while beam sharpening provides enhanced separation between small or distant targets.The Ultimate View for Collision AvoidanceHALO24 radar introduces industry-first 60 RPM rotation at ranges up to 2 nautical miles, delivering a full 360-degree sweep every single second. These ultra-fast updates give you an almost real-time view at close range, offering the ultimate view for collision avoidance. Whether you’re navigating through crowded waterways or contending with poor visibility, Halo radar cuts through the clutter to give you a clear and current picture of your surroundingsVelocityTrack™ Doppler Technology Built-InVelocityTrack™ technology provides instant visual feedback on whether targets are coming towards you or moving away. Using the Doppler effect, this feature automatically checks every target seen by your radar; there’s no need to manually select individual targets, and no limit to the number of targets on screen at one time. Simple colour coding highlights potential hazards, improving your situational awareness and further reducing your risk of collision.Key Features: 48 nm range from a compact 24" dome Advanced pulse compression technology with beam sharpening Simultaneous Dual Range operation sees both near and far Ultra-fast 60 RPM operation at ranges up to 2nm VelocityTrack™ Doppler technology for collision avoidance Easy operation with harbour, offshore, weather, and bird modes MARPA target tracking (up to 10 targets, 20 in dual range). Ready instantly from standby Lightweight, low profile dome design, with integrated LED lights 20m Radar Cable Specifications:Environmental Operating Temperature: -25° to +55°C (-13° to +130°F) Relative humidity: +35° C (95° F), 95% RH Waterproof: IPX6 Max relative wind velocity: 51 m/sec (100 Knots) Complience: CE, FCC (ID:RAY3G4G), IC: 4697A-3G4G, IEC60945 : 2002 Power & Dimensions Power consumption (with 10M cable): Operating: 14.5 to 27W at 13.8 V Standby: 3.9 W (Typ.) at 13.8 V DC 170 mA DC input (at end of radar cable): 9 V to 31.2 V DC (12/24 V systems) Reverse polarity protection: Yes Minimum startup voltage: 10.75 V DC Transmitter source (pre-heating time): No magnetron – Instant On Physical Outside dimensions: Ø Diameter 610 mm (24”), Height 225 mm (8.9”) Scanner weight (no cable): 6.75kg (14.9 lbs) Radar and Antenna Parameters Radar ranges: 100M (328 ft) to 48nm with 18 range settings, (nm/sm/km) Rotation (mode dependent): 20 - 60 rpm (mode and MFD dependent) Transmitter frequency: X-band - 9.4 to 9.5 Ghz Transmitter source (warm-up time): No Magnetron – all solid state. Instant On™ Plane of polarization: Horizontal Polarization Transmitter peak power output: 25W Minimum range: 6M (19.7') Sweep repetition frequency: 700-2400 Hz (mode dependent) Pulse length: 0.04 - 64 usec Sweep bandwidth: 48 MHz max Horizontal beam width (Tx and Rx antenna): 3.9° nominal (-3 dB width) Target Seperation Control: OFF: 3.9°+/-10% (-3 dB width nominal), LOW: 3.4°+/-10% (-3 dB width nominal), MED: 2.5°+/-10% (-3 dB width nominal), HIGH: 2.0°+/-10% (-3 dB width nominal) Vertical beam width (Tx and Rx antenna): 22° (-3B width nominal) Side lobe level (Tx and Rx antenna): Below -18 dB (within ±10°);Below -24 dB (outside ±10°) Noise figure: Less than 5 dB nominal Communications/Cabling Protocol: Ethernet 100 Base T Maximum inter connecting cable length: 30M (98.5') – available as option, use NEP-2 for longer cable runs Specifications:Array Size (Inches) = NONE Hor/Vert Beam Width = NONE Power - Output (Kilowatts) = NONE Range - Max (Miles) = NONENormalized SKU: 00014538001UPC Code: 9420024173800

Lowrance 000-14541-001 Radar DomeHALO24 Radar Dome with Doppler TechnologyHALO24 radar offers an almost real-time view, with industry-first 60 RPM operation at close range for the ultimate in collision avoidance. Identify hazards in an instant with VelocityTrack™ Doppler technology, and enjoy simultaneous short and long-range coverage—up to 48 nautical miles—from one compact 24-inch dome antenna.See Near and Far with One Compact Dome Perfect for a wide range of sailboats, fishing boats and smaller powerboats, HALO24 comes in a compact dome antenna and delivers high-quality short, mid and long-range detection. Monitor two distance ranges at once in Dual Range mode, which enables you to keep an eye on far away weather cells while watching for collision hazards up close. HALO24 radar’s pulse-compression technology means no compromises in detection at either selected range, while beam sharpening provides enhanced separation between small or distant targets.The Ultimate View for Collision AvoidanceHALO24 radar introduces industry-first 60 RPM rotation at ranges up to 2 nautical miles, delivering a full 360-degree sweep every single second. These ultra-fast updates give you an almost real-time view at close range, offering the ultimate view for collision avoidance. Whether you’re navigating through crowded waterways or contending with poor visibility, Halo radar cuts through the clutter to give you a clear and current picture of your surroundingsVelocityTrack™ Doppler Technology Built-InVelocityTrack™ technology provides instant visual feedback on whether targets are coming towards you or moving away. Using the Doppler effect, this feature automatically checks every target seen by your radar; there’s no need to manually select individual targets, and no limit to the number of targets on screen at one time. Simple color coding highlights potential hazards, improving your situational awareness and further reducing your risk of collision.Key Features: 48 nm range from a compact 24" dome Advanced pulse compression technology with beam sharpening Simultaneous Dual Range operation sees both near and far Ultra-fast 60 RPM operation at ranges up to 2nm VelocityTrack™ Doppler technology for collision avoidance Easy operation with harbour, offshore, weather, and bird modes MARPA target tracking (up to 10 targets, 20 in dual range). Ready instantly from standby Lightweight, low profile dome design, with integrated LED lights 5m Radar Cable Specifications:Environmental Operating Temperature: -25° to +55°C (-13° to +130°F) Relative humidity: +35° C (95° F), 95% RH Waterproof: IPX6 Max relative wind velocity: 51 m/sec (100 Knots) Complience: CE, FCC (ID:RAY3G4G), IC: 4697A-3G4G, IEC60945 : 2002 Power & Dimensions Power consumption (with 10M cable): Operating: 14.5 to 27W at 13.8 V Standby: 3.9 W (Typ.) at 13.8 V DC 170 mA DC input (at end of radar cable): 9 V to 31.2 V DC (12/24 V systems) Reverse polarity protection: Yes Minimum startup voltage: 10.75 V DC Transmitter source (pre-heating time): No magnetron – Instant On Physical Outside dimensions: Ø Diameter 610 mm (24”), Height 225 mm (8.9”) Scanner weight (no cable): 6.75kg (14.9 lbs) Radar and Antenna Parameters Radar ranges: 100M (328 ft) to 48nm with 18 range settings, (nm/sm/km) Rotation (mode dependent): 20 - 60 rpm (mode and MFD dependent) Transmitter frequency: X-band - 9.4 to 9.5 Ghz Transmitter source (warm-up time): No Magnetron – all solid state. Instant On™ Plane of polarization: Horizontal Polarization Transmitter peak power output: 25W Minimum range: 6M (19.7') Sweep repetition frequency: 700-2400 Hz (mode dependent) Pulse length: 0.04 - 64 usec Sweep bandwidth: 48 MHz max Horizontal beam width (Tx and Rx antenna): 3.9° nominal (-3 dB width) Target Seperation Control: OFF: 3.9°+/-10% (-3 dB width nominal), LOW: 3.4°+/-10% (-3 dB width nominal), MED: 2.5°+/-10% (-3 dB width nominal), HIGH: 2.0°+/-10% (-3 dB width nominal) Vertical beam width (Tx and Rx antenna): 22° (-3B width nominal) Side lobe level (Tx and Rx antenna): Below -18 dB (within ±10°);Below -24 dB (outside ±10°) Noise figure: Less than 5 dB nominal Communications/Cabling Protocol: Ethernet 100 Base T Maximum inter connecting cable length: 30M (98.5') – available as option, use NEP-2 for longer cable runs Specifications:Hor/Vert Beam Width = 3.9/22 DEGREES Array Size (Inches) = 24 Power - Output (Kilowatts) = NONE Range - Max (Miles) = 48NMNormalized SKU: 00014541001UPC Code: 9420024173831

Simrad 000-14535-001 Radar DomeHALO24 Radar Dome with Doppler TechnologyHALO24 radar offers an almost real-time view, with industry-first 60 RPM operation at close range for the ultimate in collision avoidance. Identify hazards in an instant with VelocityTrack™ Doppler technology, and enjoy simultaneous short and long-range coverage—up to 48 nautical miles—from one compact 24-inch dome antenna.See Near and Far with One Compact Dome Perfect for a wide range of sailboats, fishing boats and smaller powerboats, HALO24 comes in a compact dome antenna and delivers high-quality short, mid and long-range detection. Monitor two distance ranges at once in Dual Range mode, which enables you to keep an eye on far away weather cells while watching for collision hazards up close. HALO24 radar’s pulse-compression technology means no compromises in detection at either selected range, while beam sharpening provides enhanced separation between small or distant targets.The Ultimate View for Collision AvoidanceHALO24 radar introduces industry-first 60 RPM rotation at ranges up to 2 nautical miles, delivering a full 360-degree sweep every single second. These ultra-fast updates give you an almost real-time view at close range, offering the ultimate view for collision avoidance. Whether you’re navigating through crowded waterways or contending with poor visibility, Halo radar cuts through the clutter to give you a clear and current picture of your surroundingsVelocityTrack™ Doppler Technology Built-InVelocityTrack™ technology provides instant visual feedback on whether targets are coming towards you or moving away. Using the Doppler effect, this feature automatically checks every target seen by your radar; there’s no need to manually select individual targets, and no limit to the number of targets on screen at one time. Simple colour coding highlights potential hazards, improving your situational awareness and further reducing your risk of collision.Key Features: 48 nm range from a compact 24" dome Advanced pulse compression technology with beam sharpening Simultaneous Dual Range operation sees both near and far Ultra-fast 60 RPM operation at ranges up to 2nm VelocityTrack™ Doppler technology for collision avoidance Easy operation with harbour, offshore, weather, and bird modes MARPA target tracking (up to 10 targets, 20 in dual range). Ready instantly from standby Lightweight, low profile dome design, with integrated LED lights 10m Radar Cable Specifications:Environmental Operating Temperature: -25° to +55°C (-13° to +130°F) Relative humidity: +35° C (95° F), 95% RH Waterproof: IPX6 Max relative wind velocity: 51 m/sec (100 Knots) Complience: CE, FCC (ID:RAY3G4G), IC: 4697A-3G4G, IEC60945 : 2002 Power & Dimensions Power consumption (with 10M cable): Operating: 14.5 to 27W at 13.8 V Standby: 3.9 W (Typ.) at 13.8 V DC 170 mA DC input (at end of radar cable): 9 V to 31.2 V DC (12/24 V systems) Reverse polarity protection: Yes Minimum startup voltage: 10.75 V DC Transmitter source (pre-heating time): No magnetron – Instant On Physical Outside dimensions: Ø Diameter 610 mm (24”), Height 225 mm (8.9”) Scanner weight (no cable): 6.75kg (14.9 lbs) Radar and Antenna Parameters Radar ranges: 100M (328 ft) to 48nm with 18 range settings, (nm/sm/km) Rotation (mode dependent): 20 - 60 rpm (mode and MFD dependent) Transmitter frequency: X-band - 9.4 to 9.5 Ghz Transmitter source (warm-up time): No Magnetron – all solid state. Instant On™ Plane of polarization: Horizontal Polarization Transmitter peak power output: 25W Minimum range: 6M (19.7') Sweep repetition frequency: 700-2400 Hz (mode dependent) Pulse length: 0.04 - 64 usec Sweep bandwidth: 48 MHz max Horizontal beam width (Tx and Rx antenna): 3.9° nominal (-3 dB width) Target Seperation Control: OFF: 3.9°+/-10% (-3 dB width nominal), LOW: 3.4°+/-10% (-3 dB width nominal), MED: 2.5°+/-10% (-3 dB width nominal), HIGH: 2.0°+/-10% (-3 dB width nominal) Vertical beam width (Tx and Rx antenna): 22° (-3B width nominal) Side lobe level (Tx and Rx antenna): Below -18 dB (within ±10°);Below -24 dB (outside ±10°) Noise figure: Less than 5 dB nominal Communications/Cabling Protocol: Ethernet 100 Base T Maximum inter connecting cable length: 30M (98.5') – available as option, use NEP-2 for longer cable runs Specifications:Array Size (Inches) = NONE Hor/Vert Beam Width = NONE Power - Output (Kilowatts) = NONE Range - Max (Miles) = NONENormalized SKU: 00014535001UPC Code: 9420024173770

Scanstrut DPT-R-PLATE-01 Radar DomeRadome Plate 1 for Raymarine, Garmin, B&G, Lowrance DomesThe modular Dual PowerTower has been designed to allow your open array. radar, satdome and camera to be mounted together in one single space saving modular installation. Features:Radome plate 1 (Raymarine, Garmin, B&G, Simrad and Lowrance radomes) Specifications:Array Size (Inches) = NONE Hor/Vert Beam Width = NONE Power - Output (Kilowatts) = NONE Range - Max (Miles) = NONENormalized SKU: DPTRPLATE01UPC Code: 5060114796348

Download Literature Watch VideoRaymarine E70498 Radar DomeQuantum 2 Q24D Dopper Radar - No CableThe Raymarine Quantum 2 Radar has Doppler collision avoidance technology. The Quantum 2 next generation CHIRP pulse compression radar by Raymarine provides superior target awareness at both long and extremely short ranges.Using advanced Doppler processing, the system instantly highlights moving radar contacts and color codes them to indicate whether they are inbound or outbound. Quantum with Doppler makes it easy to discern potentially dangerous targets when navigating in high-traffic areas.Easily Identify Dangerous TargetsRaymarine Quantum 2 Doppler target processing readily identifies and color codes moving radar contacts for instant recognition and reduced risk of collision.Safer NavigationQuantum 2’s exclusive Safety Sector feature provides the maximum level of visibility to dangerous targets in the path of your vessel (both mobile and stationary).Superior Collision AvoidanceDoppler-enabled MARPA provides an effortless means of dangerous target tracking by eliminating the need to setup guard zones. Raymarine MARPA target tracking is the same technology trusted by the United States Coast Guard.Features: Doppler moving target display allows for superior situational awareness at-a-glance Fully automatic ARPA target tracking, along with manual MARPA mode Adjustable TrueTrails target history shows the motion history of moving contacts CHIRP Pulse Compression detects contacts as close as 18-feet for zero-visibility navigation 24-mile range for early detection of traffic, navigation aids, landfall and weather Immediate awareness – Quantum starts up and is ready to go in seconds Superior interference rejection eliminates noise from other radars Simplified installation with Wi-Fi or thin wire network connectivity Easy upgrade – Quantum 2 fits the same bolt pattern as other Raymarine scanners Lightweight and easy to install – Quantum weighs up to 50% less than comparable magnetron radars Safe emissions – mount Quantum anywhere onboard Low power consumption for extended battery life under sail How Doppler Radar Works: Microwave energy waves are bounced off of a distant target, just like conventional radar. Moving targets send back echoes whose frequencies shift upward or downward from what was originally transmitted. For inbound targets, the frequency increases as the leading edge of the returning echoes are received more frequently as the target’s range decreases. For outbound targets, the frequency drops as the returning echoes spread out as its range increases. Doppler radars are engineered to detect these small shifts in wave frequency, and use them to classify moving radar targets. Doppler Target ProcessingDoppler radar is tuned specifically to detect the radar echo frequency shift returned by moving vs. stationary targets.Quantum 2 then uniquely color codes moving targets to indicate whether they are getting closer, or moving away. Inbound targets are colored red Outbound targets are colored green Color coded targets make it simple to pick out moving traffic from other stationary targets like land, navigation aids or stopped/anchored vessels.Quantum 2 Safety SectorDoppler does an excellent job of bringing attention to moving targets, but it does downplay stationary targets, that can be equally as dangerous.Safety Sector provides equal attention to these imminent threats by coloring them as inbound targets. Potential targets include: Buoys Exposed Hazard (rocks, pilings, etc...) Slow moving, low visibility vessels Quantum 2's Safety Sector spreads 15° from the bow to a distance of approximately 200m NOTE: The safety sector is not visible on the display. Quantum 2 automatically processes and highlights targets within this region in red.The Quantum 2 also features fully automatic target acquisition and tracking. Configure custom safety or alarm zones and be alerted to new radar contacts entering the zone. Quantum 2 can begin tracking those contacts automatically, calculating their course, speed, closest point of approach and more. You’ll be alerted to dangerous contacts with audible alerts and easy to understand on-screen graphics.Quantum 2 also features Raymarine’s True Trails target history display. The True Trails features enables you to see a historical “wake” behind every moving contact. This additional information makes it even easier to interpret the motion of other vessels, and make smart maneuvering decisions to pass safely.Like every Raymarine Quantum system, you’ll also benefit from a rugged and lightweight design that is super-easy to install. Quantum 2 has very low power consumption making it especially friendly to vessels running exclusively on battery power. Quantum 2 with Doppler can be installed in a traditional wired configuration, or use its built-in Wi-Fi technology to connect it to your Raymarine MFD.The Quantum 2 with Doppler truly sets the standard for on the water safety and collision avoidance. Normalized SKU: E70498UPC Code: 723193823101Raymarine E70498 Literature Download Quick Reference GuideRaymarine E70498 Video

  Download Literature  Watch VideoRaymarine T70416 Radar DomeQuantum 2 Q24D Radar Doppler with 10m Power & Data CablesThe Raymarine Quantum 2 Radar has Doppler collision avoidance technology. The Quantum 2 next generation CHIRP pulse compression radar by Raymarine provides superior target awareness at both long and extremely short ranges.Using advanced Doppler processing, the system instantly highlights moving radar contacts and color codes them to indicate whether they are inbound or outbound. Quantum with Doppler makes it easy to discern potentially dangerous targets when navigating in high-traffic areas.Easily Identify Dangerous TargetsRaymarine Quantum 2 Doppler target processing readily identifies and color codes moving radar contacts for instant recognition and reduced risk of collision.Safer NavigationQuantum 2’s exclusive Safety Sector feature provides the maximum level of visibility to dangerous targets in the path of your vessel (both mobile and stationary).Superior Collision AvoidanceDoppler-enabled MARPA provides an effortless means of dangerous target tracking by eliminating the need to setup guard zones. Raymarine MARPA target tracking is the same technology trusted by the United States Coast Guard.Features: Doppler moving target display allows for superior situational awareness at-a-glance Fully automatic ARPA target tracking, along with manual MARPA mode Adjustable TrueTrails target history shows the motion history of moving contacts CHIRP Pulse Compression detects contacts as close as 18-feet for zero-visibility navigation 24-mile range for early detection of traffic, navigation aids, landfall and weather Immediate awareness – Quantum starts up and is ready to go in seconds Superior interference rejection eliminates noise from other radars Simplified installation with Wi-Fi or thin wire network connectivity Easy upgrade – Quantum 2 fits the same bolt pattern as other Raymarine scanners Lightweight and easy to install – Quantum weighs up to 50% less than comparable magnetron radars Safe emissions – mount Quantum anywhere onboard Low power consumption for extended battery life under sail How Doppler Radar Works: Microwave energy waves are bounced off of a distant target, just like conventional radar. Moving targets send back echoes whose frequencies shift upward or downward from what was originally transmitted. For inbound targets, the frequency increases as the leading edge of the returning echoes are received more frequently as the target’s range decreases. For outbound targets, the frequency drops as the returning echoes spread out as its range increases. Doppler radars are engineered to detect these small shifts in wave frequency, and use them to classify moving radar targets. Doppler Target ProcessingDoppler radar is tuned specifically to detect the radar echo frequency shift returned by moving vs. stationary targets.Quantum 2 then uniquely color codes moving targets to indicate whether they are getting closer, or moving away. Inbound targets are colored red Outbound targets are colored green Color coded targets make it simple to pick out moving traffic from other stationary targets like land, navigation aids or stopped/anchored vessels.Quantum 2 Safety SectorDoppler does an excellent job of bringing attention to moving targets, but it does downplay stationary targets, that can be equally as dangerous.Safety Sector provides equal attention to these imminent threats by coloring them as inbound targets. Potential targets include: Buoys Exposed Hazard (rocks, pilings, etc...) Slow moving, low visibility vessels Quantum 2's Safety Sector spreads 15° from the bow to a distance of approximately 200m NOTE: The safety sector is not visible on the display. Quantum 2 automatically processes and highlights targets within this region in red.The Quantum 2 also features fully automatic target acquisition and tracking. Configure custom safety or alarm zones and be alerted to new radar contacts entering the zone. Quantum 2 can begin tracking those contacts automatically, calculating their course, speed, closest point of approach and more. You’ll be alerted to dangerous contacts with audible alerts and easy to understand on-screen graphics.Quantum 2 also features Raymarine’s True Trails target history display. The True Trails features enables you to see a historical “wake” behind every moving contact. This additional information makes it even easier to interpret the motion of other vessels, and make smart maneuvering decisions to pass safely.Like every Raymarine Quantum system, you’ll also benefit from a rugged and lightweight design that is super-easy to install. Quantum 2 has very low power consumption making it especially friendly to vessels running exclusively on battery power. Quantum 2 with Doppler can be installed in a traditional wired configuration, or use its built-in Wi-Fi technology to connect it to your Raymarine MFD.The Quantum 2 with Doppler truly sets the standard for on the water safety and collision avoidance. Specifications:Array Size (Inches) = NONE Hor/Vert Beam Width = Horizontal: 4.9° Vertical: 20° Power - Output (Kilowatts) = 20W Range - Max (Miles) = NONENormalized SKU: T70416UPC Code: 723193823118Raymarine T70416 Literature Download  Quick Reference GuideRaymarine T70416 Video

  Download Literature  Watch VideoRaymarine T70417 Radar DomeQuantum 2 Q24D Radar Doppler with 15m Power & Data CablesThe Raymarine Quantum 2 Radar has Doppler collision avoidance technology. The Quantum 2 next generation CHIRP pulse compression radar by Raymarine provides superior target awareness at both long and extremely short ranges.Using advanced Doppler processing, the system instantly highlights moving radar contacts and color codes them to indicate whether they are inbound or outbound. Quantum with Doppler makes it easy to discern potentially dangerous targets when navigating in high-traffic areas.Easily Identify Dangerous TargetsRaymarine Quantum 2 Doppler target processing readily identifies and color codes moving radar contacts for instant recognition and reduced risk of collision.Safer NavigationQuantum 2’s exclusive Safety Sector feature provides the maximum level of visibility to dangerous targets in the path of your vessel (both mobile and stationary).Superior Collision AvoidanceDoppler-enabled MARPA provides an effortless means of dangerous target tracking by eliminating the need to setup guard zones. Raymarine MARPA target tracking is the same technology trusted by the United States Coast Guard.Features: Doppler moving target display allows for superior situational awareness at-a-glance Fully automatic ARPA target tracking, along with manual MARPA mode Adjustable TrueTrails target history shows the motion history of moving contacts CHIRP Pulse Compression detects contacts as close as 18-feet for zero-visibility navigation 24-mile range for early detection of traffic, navigation aids, landfall and weather Immediate awareness – Quantum starts up and is ready to go in seconds Superior interference rejection eliminates noise from other radars Simplified installation with Wi-Fi or thin wire network connectivity Easy upgrade – Quantum 2 fits the same bolt pattern as other Raymarine scanners Lightweight and easy to install – Quantum weighs up to 50% less than comparable magnetron radars Safe emissions – mount Quantum anywhere onboard Low power consumption for extended battery life under sail How Doppler Radar Works: Microwave energy waves are bounced off of a distant target, just like conventional radar. Moving targets send back echoes whose frequencies shift upward or downward from what was originally transmitted. For inbound targets, the frequency increases as the leading edge of the returning echoes are received more frequently as the target’s range decreases. For outbound targets, the frequency drops as the returning echoes spread out as its range increases. Doppler radars are engineered to detect these small shifts in wave frequency, and use them to classify moving radar targets. Doppler Target ProcessingDoppler radar is tuned specifically to detect the radar echo frequency shift returned by moving vs. stationary targets.Quantum 2 then uniquely color codes moving targets to indicate whether they are getting closer, or moving away. Inbound targets are colored red Outbound targets are colored green Color coded targets make it simple to pick out moving traffic from other stationary targets like land, navigation aids or stopped/anchored vessels.Quantum 2 Safety SectorDoppler does an excellent job of bringing attention to moving targets, but it does downplay stationary targets, that can be equally as dangerous.Safety Sector provides equal attention to these imminent threats by coloring them as inbound targets. Potential targets include: Buoys Exposed Hazard (rocks, pilings, etc...) Slow moving, low visibility vessels Quantum 2's Safety Sector spreads 15° from the bow to a distance of approximately 200m NOTE: The safety sector is not visible on the display. Quantum 2 automatically processes and highlights targets within this region in red.The Quantum 2 also features fully automatic target acquisition and tracking. Configure custom safety or alarm zones and be alerted to new radar contacts entering the zone. Quantum 2 can begin tracking those contacts automatically, calculating their course, speed, closest point of approach and more. You’ll be alerted to dangerous contacts with audible alerts and easy to understand on-screen graphics.Quantum 2 also features Raymarine’s True Trails target history display. The True Trails features enables you to see a historical “wake” behind every moving contact. This additional information makes it even easier to interpret the motion of other vessels, and make smart maneuvering decisions to pass safely.Like every Raymarine Quantum system, you’ll also benefit from a rugged and lightweight design that is super-easy to install. Quantum 2 has very low power consumption making it especially friendly to vessels running exclusively on battery power. Quantum 2 with Doppler can be installed in a traditional wired configuration, or use its built-in Wi-Fi technology to connect it to your Raymarine MFD.The Quantum 2 with Doppler truly sets the standard for on the water safety and collision avoidance. Specifications:Array Size (Inches) = NONE Hor/Vert Beam Width = Horizontal: 4.9° Vertical: 20° Power - Output (Kilowatts) = 20W Range - Max (Miles) = NONENormalized SKU: T70417UPC Code: 723193823125Raymarine T70417 Literature Download  Quick Reference GuideRaymarine T70417 Video
