Magnum Energy MS2812-L Inverters The Magnum MS2812 is a 2800-watt, 120-volt AC inverter with a 125-amp Power Factor Corrected (PFC) charger, designed for efficient power conversion and battery charging. Input battery voltage range: 9 - 16.8 VDC AC output voltage accuracy: 120 VAC ± 5% Output frequency and accuracy: 60 Hz ± 0.1 Hz Total Harmonic Distortion (THD): < 5% 1 msec surge current (amps AC): 70 100 msec surge current (amps AC): 40 5 sec surge power (real watts): 3900 30 sec surge power (real watts): 3800 5 min surge power (real watts): 3200 30 min surge power (real watts): 3000 Output power (continuous watts): 2800 Maximum continuous input current: 373 ADC Inverter efficiency (peak): 90% AC Relay Transfer time (minimum): 16 msecs Power Consumption - searching: < 8 watts Power Consumption - inverting (no load): 30 watts Output Waveform: Pure Sine Wave Continuous charger output at 25° C: 125 ADC Charger efficiency: 85% Power factor: > .95 Input current for continuous rated output: 18 AAC Transfer relay capability: 60ACC total Five-stage charging capability: Bulk, Absorb, Float, Equalize (requires remote), and Battery Saver Battery temperature compensation: Standard with available temp sensor connected (battery temp 0-50° C) Internal cooling: 0 to 120 cfm variable speed drive using dual 92mm brushless DC fans Overcurrent protection: Yes, with two overlapping circuits Overtemperature protection: Yes on transformer, MOSFETS, and battery Corrosion protection: Yes, PCB’s conformal coated, powder coated chassis/top, and stainless steel fasteners Warranty: Three years parts and labor Physical dimensions (l x w x h): 13.75 x 12.65 x 8.0 inches (34.9 cm x 32.1 cm x 20.3 cm) Mounting: Shelf or wall (vents not allowed to face downward unless ME-CB or MMP/MP is installed) Unit weight: 55 pounds (24.9 kg) Shipping weight: 62 pounds (28.1 kg) Max operating altitude: 15,000 feet (4570 m) Temperature (Operating/Non-operating): -20° C to +60° C (-4° F to 140° F) to -40° C to +70° C (-40° F to 158° F) Operating humidity: 0 to 95% RH non-condensing Replaces Magnum Energy MS2812-L-U Normalized SKU: MS2812LUPC Code: 892608001110

Magnum Energy MS2012-L InvertersMagnum Energy 2000w 12v Inverter/100a Charger #MS2012-LNormalized SKU: MS2012L

Download LiteratureMastervolt 28013500 InvertersAC Master 12/3500 (230V) InverterReliable AC power for recreational and semi-professional use.These affordable sine wave inverters convert 12 or 24 V battery voltage into reliable 230 V 50/60 Hz or 120 V 50/60 Hz grid power, making them ideal for recreational and semi-professional applications. The AC Master series is easy to install and delivers full output, even under the most demanding conditions. Pure sine wave technology provides an outstanding power quality, ensuring the correct functioning of sensitive equipment. The usage of high-frequency switching technology eliminates any annoying humming and buzzing sounds.Representing complete value for money, these ruggedly built inverters provide essential home comforts when you’re far from the nearest grid connection.Features: Pure sine wave technology protects sensitive equipment. Delivers full output at high peak power under the most demanding conditions. Automatic power-saving system for extended runtime. Compact and lightweight design, saving valuable installation time. Reliable and safe operation; protected against over-temperature, overload, short circuit, high or low battery voltage. Variable-speed fan for quiet operation at low power. Optional remote control for instant switch-off of the inverter and all connected equipment (not available for the 300 and 500 W models). Convenient plug connection for all models, 2500/3500 Watt models also hard-wired.  In addition, the 2500/3500 Watt models offer: Combine 2 up to 15 units to obtain high power or 3-phase systems. Integrated transfer system, switches automatically between AC power sources.  Applications:Both recreational and semi-professional use, where grid power varies or is unavailable. Applications include lighting, appliances, electric cooking, and power tools. For (mobile) applications in your home, office, or service vehicle, or during your holidays.General Specifications: Output voltage: 230/240 V 50/60 Hz (selectable)  Output waveform: True sine Nominal battery voltage: 12V Recommended battery capacity: ≥ 360 Ah Continuous power at 25 °C / 77 °F, cos phi 1: 3500 W Continuous power at 40 °C / 104 °F, cos phi 1: 3500 W Peak load (1 min.): < 4500 W Peak load (1 s): < 6000 W AC connection: Hardwired + plug connection EU (Schuko), UK plug (code 28213500), or NZ/AU plug(code 28413500)  Galvanic isolation: Yes Efficiency: 90% Parallel configuration: Yes, up to 15 units 3-Phase configuration: Yes, 3 units Display/read-out: LED indication: battery voltage, load level, status  Alarms: Potential free alarm contact Dimensions, hxwxd: 283 x 496 x 128 mm/11.1 x 19.5 x 5.0 inch  Weight: 10 kg/22.0 lb Compliance: Safety: CE, E-mark, RCM  Technical Specifications: Technology: High frequency, input & output fully isolated Low battery voltage, switches off at 10.5 V Low battery voltage, switches on at 12.5 V High battery voltage, switches off at 16.5 V High battery voltage, switches on at 14.5 V Input current (nominal load): 350 A No-load power consumption (ON mode): < 3.6 A No-load power consumption (energy saving mode): < 1.1 A Minimal DC fuse (slow blow): 400 A Minimal cable size: 120 mm² Harmonic distortion typical: < 3 % Cos phi: All power factors allowed Temperature range (ambient temp.): -20 °C to 60 °C, derating power > 40 °C/-4 °F to 140 °F Cooling: Temperature and load controlled fan Protection degree: IP21, horizontal wall mounting Protections: Over-temperature, overload, short circuit, high/low voltage, reverse polarity (fuse) MasterBus compatible: Yes, using a MasterBus AC Master Interface WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 28013500Mastervolt 28013500 Literature Download Owners Manual Product Brochure

Wagan EL2323 Inverters Original Replacement 16-foot wired remote for Wagan Tech MSW Power Inverters Normalized SKU: EL2323

Outback Power Systems MATE3S Inverters Universal Housing (V)FXR & GS Inverter Normalized SKU: MATE3S

Victron Energy PIN243750500 Inverters Phoenix 24/220 115 volt /60Hz Normalized SKU: PIN243750500

Download LiteratureVictron Energy QUA245021010 InvertersQuattro 24/5000/120-100/100 230V VE.Bus 230VAC VE.BusLike the MultiPlus, the Quattro is a combined inverter and charger. Additionally it can accept two AC inputs and automatically connect to the active source. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology, and multiple system integration features such as three or split phase and parallel operation.Two AC Inputs & Two AC OutputsThe Quattro can be connected to two independent AC sources, for example, shore-side power and a generator, or two generators. The Quattro will automatically connect to the active source. The main output has no-break functionality. In the event of a grid failure, or shore or generator power being disconnected, the Quattro takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. The second output is live only when AC is available on one of the inputs of the Quattro. Loads that should not discharge the battery, such as air-conditioning or a water heater can be connected to this output.Unique PowerAssist FeatureThe Quattro will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shore side supply with power taken from the battery.Virtually unlimited power thanks to parallel operationUp to 6 Quattros can operate in parallel to achieve higher power output. Three phase or split phase operation is also possible. Please check our datasheets to see which models have paralleling, three phase and split phase capabilities.Remote Monitoring & ControlWhen coupled with a GX device (e.g. Cerbo GX) you can monitor and control your Quattro and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop or PC for multiple operating systems. There is no end to the level of control, from adjusting your Quattro to auto starting a backupgenerator and more…Please contact your dealer for any returns, repairs or support issues related to this product. Normalized SKU: QUA245021010UPC Code: 8719076024156Victron Energy QUA245021010 Literature Download Quick Reference Guide Product Brochure

Mastervolt 28012500 InvertersAC Master 12/2500 (230V) InverterReliable AC power for recreational and semi-professional use.These affordable sine wave inverters convert 12 or 24 V battery voltage into reliable 230 V 50/60 Hz or 120 V 50/60 Hz grid power, making them ideal for recreational and semi-professional applications. The AC Master series is easy to install and delivers full output, even under the most demanding conditions. Pure sine wave technology provides an outstanding power quality, ensuring the correct functioning of sensitive equipment. The usage of high-frequency switching technology eliminates any annoying humming and buzzing sounds.Representing complete value for money, these ruggedly built inverters provide essential home comforts when you’re far from the nearest grid connection.Features: Pure sine wave technology protects sensitive equipment. Delivers full output at high peak power under the most demanding conditions. Automatic power-saving system for extended runtime. Compact and lightweight design, saving valuable installation time. Reliable and safe operation; protected against over-temperature, overload, short circuit, high or low battery voltage. Variable-speed fan for quiet operation at low power. Optional remote control for instant switch-off of the inverter and all connected equipment (not available for the 300 and 500 W models). Convenient plug connection for all models, 2500/3500 Watt models also hard-wired.  In addition, the 2500/3500 Watt models offer: Combine 2 up to 15 units to obtain high power or 3-phase systems. Integrated transfer system, switches automatically between AC power sources.  Applications:Both recreational and semi-professional use, where grid power varies or is unavailable. Applications include lighting, appliances, electric cooking, and power tools. For (mobile) applications in your home, office, or service vehicle, or during your holidays.General Specifications: Output voltage: 230/240 V 50/60 Hz (selectable)  Output waveform: True sine Nominal battery voltage: 12V Recommended battery capacity: ≥ 270 Ah Continuous power at 25 °C / 77 °F, cos phi 1: 2500 W Continuous power at 40 °C / 104 °F, cos phi 1: 2500 W Peak load (1 min.): < 3000 W Peak load (1 s): < 4000 W AC connection: Hardwired + plug connection EU (Schuko), with UK plug (code 28212500) or NZ/AU plug (code 28412500) Galvanic isolation: Yes Efficiency: 88% Parallel configuration: Yes, up to 15 units 3-Phase configuration: Yes, 3 units Display/read-out: LED indication: battery voltage, load level, status  Alarms: Potential free alarm contact Dimensions, hxwxd: 283 x 436 x 128 mm/11.1 x 17.2 x 5.0 inch  Weight: 8 kg/17.6 lb Compliance: Safety: CE, E-mark, RCM  Technical Specifications: Technology: High frequency, input & output fully isolated Low battery voltage, switches off at 10.5 V Low battery voltage, switches on at 12.5 V High battery voltage, switches off at 16.5 V High battery voltage, switches on at 14.5 V Input current (nominal load): 250 A No-load power consumption (ON mode): < 3.6 A No-load power consumption (energy saving mode): < 1.1 A Minimal DC fuse (slow blow): 300 A Minimal cable size: 95 mm² Harmonic distortion typical: < 5 % Cos phi: All power factors allowed Temperature range (ambient temp.): -20 °C to 60 °C, derating power > 40 °C/-4 °F to 140 °F Cooling: Temperature and load controlled fan Protection degree: IP21, horizontal wall mounting Protections: Over-temperature, overload, short circuit, high/low voltage, reverse polarity (fuse) MasterBus compatible: Yes, using a MasterBus AC Master Interface WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 28012500
