Lowrance
Lowrance Eagle 7 with TripleShot Transducer & US Inland Charts #000-16120-001
$638.39
$796.78
Lowrance 000-16120-001 FishfindersEagle 7 with TripleShot Transducer & U.S. Inland ChartsEagle® was born to make fishing as simple and enjoyable as possible. Easy to use and quick to install, this model features a Tripleshot™ HD Transducer with FishReveal™ technology and autotuning for a quick and optimal set-up. An IPS screen provides higher resolution and visibility from all angles. This model also comes pre-loaded with high-resolution C-MAP® inland charts for the US, with coverage of over 17,000+ American lakes.Easy to Use SonarTripleShot HDHave the best chance of finding fish with underwater views to the side and below the boat, all with one transducer. TripleShot™ HD features the fish-finding capability of wide-angle high CHIRP sonar and high-resolution images of fish-holding structures from SideScan and DownScan Imaging™.FishReveal™Take the guesswork out of fish identification with FishReveal, combining DownScan with CHIRP for unparalleled target separation and identification. AutotuningSimple autotuning sonar gives users the optimal settings from the start, so users don’t have to spend time trying to find them.Detailed ChartingC-MAP Embedded InlandSpend more time fishing and less time searching with pre-loaded high-resolution C-MAP® Embedded inland charts for the US. Get coverage of over 17,000+ American lakes. With Eagle, users have all the details needed to discover and navigate to the best fishing spots, faster.Genesis LiveKnow the local waters better than anyone with the ability to create custom ½-foot contour maps of the local lake or uncharted water in real-time.Designed for FishingIPS ScreensSee clearly wherever users go with an IPS screen, offering improved resolution, clarity, and visibility, even with polarized sunglasses in direct sunlight.Connector SystemSet up in an instant with Eagle’s improved twist-locking connector, promising easy installation and removal every time.One-Year WarrantyLowrance's priority is to give users superior quality products and a stress-free time on the water. Enjoy the feeling of fishing with peace of mind, thanks to Lowrance's one-year warranty guarantee.Features:
Enhanced TripleShot™ HD Transducer with Autotuning Sonar
C-MAP® inland charts for the US, feat. Genesis® Live
IPS screen, viewable from all angles, even in polarized glasses
Reliable twist-lock connector system for easy installation in any boat or kayak
SD card slot for software updates, Genesis Live recording, and charting add-ons.
See fish hiding in cover with FishReveal™ mode
Increase contrast and viewability with Imaging color palettes
What’s in the Box?
Eagle 7 Display
TripleShot HD Transducer
TripleShot Bracket
Power Cable, with fuse and connectors
Eagle 7 Bracket and mounting hardware
Spotlight Feature Icons:
CHIRP
DownScan
FishReveal
IPS Screens
Autotuning Sonar
Normalized SKU: 00016120001UPC Code: 9420064131440
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Lowrance
Lowrance Eagle 7 with SplitShot T/M Transducer & Inland Charts #000-16114-001
$531.99
$663.98
Lowrance 000-16114-001 FishfindersEagle 7 with SplitShot T/M Transducer & Inland ChartsEagle® was born to make fishing as simple and enjoyable as possible. Easy to use and quick to install, this model features a SplitShot™ HD Transducer with FishReveal technology and autotuning for a quick and optimal setup. An IPS screen provides higher resolution and visibility from all angles. This model also comes pre-loaded with high-resolution C-MAP® inland charts for the US, with coverage of over 17,000+ American lakes.Easy to Use SonarSplitShot™ HDGet the best underwater views below the boat with SplitShot HD, featuring the fish-finding capability of wide-angle high-CHIRP sonar and the high-resolution images of fish-holding structures from DownScan Imaging™.FishReveal™Take the guesswork out of fish identification with FishReveal, combining DownScan with CHIRP for unparalleled target separation and identification. AutotuningSimple autotuning sonar gives users the optimal settings from the start, so users don’t have to spend time trying to find them.Detailed ChartingC-MAP Embedded InlandSpend more time fishing and less time searching with pre-loaded high-resolution C-MAP® Embedded inland charts for the US. Get coverage of over 17,000+ American lakes. With Eagle, users have all the details needed to discover and navigate to the best fishing spots, faster.Genesis LiveKnow the local waters better than anyone with the ability to create custom ½-foot contour maps of the local lake or uncharted water in real-time.Designed for FishingIPS ScreensSee clearly wherever the user goes with an IPS screen, offering improved resolution, clarity, and visibility, even with polarized sunglasses in direct sunlight.Connector SystemSet up in an instant with Eagle’s improved twist-locking connector, promising easy installation and removal every time.One-Year WarrantyLowrance's priority is to give users superior quality products and a stress-free time on the water. Enjoy the feeling of fishing with peace of mind, thanks to Lowrance's one-year warranty guarantee.Features:
Enhanced SplitShot™ HD Transducer with Autotuning Sonar
C-MAP® inland charts for the US, feat. Genesis® Live
IPS screen, viewable from all angles, even in polarized glasses
Reliable twist-lock connector system for easy installation in any boat or kayak
SD card slot for software updates, Genesis Live recording, and charting add-ons
See fish hiding in cover with FishReveal™ mode
Increase contrast and viewability with Imaging color palettes
What’s in the Box?
Eagle 7 Display
SplitShot HD Transducer
Bullet/SplitShot™ Transom Bracket
Power Cable, with fuse and connectors
Eagle 7 Bracket and mounting hardware
Spotlight Feature Icons:
CHIRP
DownScan
FishReveal
IPS Screens
Autotuning Sonar
Normalized SKU: 00016114001UPC Code: 9420064131389
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Lowrance
Lowrance Eagle 5 Combo with SplitShot Transducer #000-16111-001
$374.36
$467.24
Lowrance 000-16111-001 FishfindersEagle 5 Combo with SplitShot TransducerEagle® was born to make fishing as simple and enjoyable as possible. Easy to use and quick to install, this model features a SplitShot™ HD Transducer with FishReveal™ technology and autotuning for a quick and optimal set-up. An IPS screen provides higher resolution and visibility from all angles. This model also comes pre-loaded with high-resolution C-MAP® inland charts for the US, with coverage of over 17,000+ American lakes.Easy to Use SonarSplitShot™ HDGet the best underwater views below the boat with SplitShot HD, featuring the fish-finding capability of wide-angle high-CHIRP sonar and the high-resolution images of fish-holding structures from DownScan Imaging™.FishReveal™Take the guesswork out of fish identification with FishReveal, combining DownScan with CHIRP for unparalleled target separation and identification.Autotuning SonarSimple autotuning sonar gives users the optimal settings from the start, so you don’t have to spend time trying to find them yourself.Autotuning SonarSimple autotuning sonar gives users the optimal settings from the start, so you don’t have to spend time trying to find them yourself.Detailed ChartingC-MAP Embedded InlandSpend more time fishing and less time searching with pre-loaded, high-resolution C-MAP® embedded inland charts for the US. Get coverage of over 17,000+ American lakes. With Eagle, users have all the details needed to discover and navigate to the best fishing spots faster.Genesis LiveKnow the local waters better than anyone with the ability to create custom ½-foot contour maps of the local lake or uncharted water in real-time.Designed for FishingIPS ScreensSee clearly wherever users go with an IPS screen, offering improved resolution, clarity, and visibility, even with polarized sunglasses in direct sunlight.Connector SystemSet up in an instant with Lowrance's improved twist-locking connector, promising easy and reliable installation, and removal every time.One Year WarrantyLowrance's priority is to give users superior-quality products and a stress-free time on the water. Enjoy the feeling of fishing with peace of mind with our two-year warranty guarantee.Features:
Enhanced SplitShot™ HD Transducer with Autotuning Sonar
C-MAP® inland charts for the US, feat. Genesis® Live
IPS screen, viewable from all angles, even in polarized glasses
Reliable twist-lock connector system for easy installation in any boat or kayak
SD card slot for software updates, Genesis Live recording, and charting add-ons.
See fish hiding in cover with FishReveal™ mode
Increase contrast and viewability with Imaging color palettes
What’s in the Box?
Eagle 5 Display
SplitShot HD Transducer
Bullet/SplitShot™ Transom Bracket
Power Cable, with fuse and connectors
Eagle 5 Bracket and mounting hardware
Spotlight Feature Icons:
CHIRP
DownScan
FishReveal
IPS Screens
Autotuning Sonar
Normalized SKU: 00016111001UPC Code: 9420064131358
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Garmin
Garmin GPSMAP 1643xsv Combo GPS/Fishfinder GN+ #010-02919-03
$5,099.99
$5,519.49
Watch VideoGarmin 010-02919-03 FishfindersGPSMAP® 1643xsv ChartplotterGET A SHARPER VIEW FROM A CONNECTED HELMWith its sleek design, powerful processing, and upgraded IPS display, this advanced 16” chartplotter integrates seamlessly into a Garmin marine system.
Easily integrate with more engines.
Connect to compatible third-party devices with digital switching and OneHelm™ integrations.
Easily build a marine system by using our advanced network connectivity.
Navigate any waters with preloaded Garmin Navionics+™ charts
See below a boat with built-in sonar capabilities
Manage the marine experience from nearly anywhere1.
Ultra High-Definition Scanning SonarGet built-in Ultra High-Definition SideVü and ClearVü™ scanning sonars with vivid, high-contrast color palettes to help distinguish fish from structure. GPSMAP® X3 series also supports 1 kW CHIRP traditional sonar capabilities.Live Sonar SupportPair with Panoptix™ or LiveScope™ easy-to-interpret live sonar (transducer required, sold separately) to see all around the boat in real-time.Faster, Sharper, SmarterWith its added processing power and slimline design featuring edge-to-edge glass, it’s easy to fit this plotter in a wider range of dash configurations.Bright and Clear OpticsHigh-resolution IPS display chartplotter offers improved sunlight readability and visibility from any angle.Preloaded MappingExperience unparalleled coverage and detail with built-in Garmin Navionics+ integrated coastal and inland mapping that includes Auto Guidance+™ technology3 and a 1-year subscription for downloadable daily updates and more on select chartplotters.Optional Charts and MapsBring a fresh new look and feel to the chartplotter with an optional upgrade to a Garmin Navionics Vision+™ premium chart subscription, featuring downloadable high-resolution relief shading, satellite imagery, sonar imagery, and more.Power-Pole® Shallow Water AnchorBy networking select Garmin chartplotters with a Force® trolling motor and a compatible Power-Pole shallow water anchoring system, users can access advanced boat control features3 from the plotter, including smart anchor auto-deployment, smart anchor jog, auto stow, anchor drag detection, and end-of-route anchoring. Spend more time fishing and less time positioning.Trolling Motor IntegrationGet support and integration for a Force trolling motor (sold separately) to gain complete control while fishing.Charge Integration From Power-PoleCHARGE Marine Power Manager from Power-Pole integrates with compatible Garmin chartplotters to help keep battery power going longer and stronger on the water. Users can charge batteries on the run, monitor power use, select where power is allocated, control emergency starts, and even transfer power between battery banks — all from the chartplotter display.Garmin Sailassist™ Sailing FeaturesView laylines, race start line guidance, enhanced wind rose, heading and course-over-ground lines, true wind data fields and tide/current/time slider, wind angle, set and drift, wind speed, and more.Sailing PolarsUse the polar table to see key data, including how fast users should go at a certain wind angle and speed — so users know whether the sail trim needs to be adjusted.Garmin Marine NetworkIf users have multiple compatible Garmin devices on the boat, users can share information — such as maps, user data, radar, and IP camera video — among them.NMEA 2000® and NMEA 0183 NetworksConnect to compatible autopilots, digital switching, weather, the Fusion audio system, media, VHF, AIS, and more from one screen.Activecaptian® APPBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications, software updates, Helm app, Garmin Quickdraw™ Community data, and more1.Integrated ANT® TechnologyConnect with some of the favorite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments, and wireless remote controls.Engine ConnectivityUsers can connect a chartplotter to different engines, including select Yamaha® engines.OneHelm FeatureThis feature brings together all the operations and capabilities of select third-party devices, such as EmpirBus™ digital switching, on one screen.Send InReach® Device MessagesPair an inReach satellite communicator4 to the chartplotter, and type custom messages by using the MFD’s on-screen keyboard. Access the contact list, or enter an email, inReach address, or phone number. Users can also group messages by conversation for a texting-like experience.In the Box:
Chartplotter
microSD™ preinstalled
Power cable
NMEA 2000® T-connector
NMEA 2000 drop cable
Flush mount kit with gasket protective cover
Trim piece snap covers
Connections
NMEA 2000® Ports: 1
NMEA 0183 Input Ports: 1
NMEA 1083 Input (TX) Ports: 1
Video Input Ports: 1 (BNC composite)
Video Output Ports: 1 HDMI
J1939 Ports: 1
Garmin Marine Network Ports: 2
12-Pin Transducer Port: 1
USB Ports: 1
Bluetooth® Pairing
ANT+ (Connectivity)
Garmin Wi-Fi Network (Local Connection)
Specifications:
Unit Dimensions: 15.1" x 10.3" x 3" (38.4 cm x 26.2 cm x 7.6 cm)
Unit Weight: 9.7 lbs (4.4 kg)
1Requires ActiveCaptain app on your compatible smartphone paired to your chartplotter2Auto Guidance+ is for planning purposes only and does not replace safe navigation operations3Integration of these features requires the purchase of a C-Monster® GATEWAY through Power-Pole4Active satellite subscription required. Some jurisdictions regulate or prohibit the use of satellite communication devices. It is the responsibility of the user to know and follow all applicable laws in the jurisdictions where the device is intended to be used.Wi-Fi is a registered trademark of the Wi-Fi Alliance.Engineering enhancements are ongoing and may not be reflected in the pictures, videos, and specifications.WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100291903UPC Code: 753759335076Garmin 010-02919-03 Video
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Humminbird
Humminbird Helix 7 Chirp Si GPS G4 #411920-1
$637.07
$795.14
Humminbird 411920-1 FishfindersHELIX 7 GPS CHIRP SI G4The HELIX 7 SI GPS G4 fish finder features CHIRP Side Imaging, CHIRP Down Imaging, Dual Spectrum CHIRP Sonar, AutoChart Live, Internal GPS, and Humminbird Basemap built-in. An upgraded high-definition 7" display will give you the best view of the many pre-loaded split screen view options so that you'll never miss a fish. Features:
Keypad control: Master HELIX at the touch of a button. Access the pre-loaded views from the user-friendly menu system, operated by softkey controls that allow you to reliably operate your fish finder in any condition.
CHIRP Down Imaging: Filter out noise and clutter for a clear view beneath your boat. CHIRP Digital Sonar processing of Down Imaging sonar means that you'll see great detail to make finding the fish simple and easy.
Dual Spectrum CHIRP sonar: Before you cast, know what's down there thanks to highly-detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum CHIRP 2D sonar offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail.
Internal GPS and Humminbird Basemap: Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.
Premium Chart Compatible: Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.
AutoChart Live: Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually endless AutoChart Live mapping capacity.
Includes control head, transom-mount transducer, power cable, gimbal mounting bracket, and mounting hardware.
1-Year Limited Warranty
Specifications:
Display Size - Diagonal: 7"
Display Pixel Matrix: 1024H x 600V
Transducer Included: XNT 9 HW SI T
Compatible With: Minn Kota US2 Sonar, AIS, AutoPilot
Features: Down Imaging, Built-In GPS, Side Imaging, Dual Spectrum CHIRP, Built In Mapping
Memory Card Slot: Single Micro SD
Sonar-Standard: Dual Spectrum CHIRP, CHIRP Down Imaging, CHIRP Side Imaging
Sonar-Coverage: 20°, 42°, 60° & (2) 86° @ -10dB
Sonar-Optional: 53 kHz, 50/Low Airmar CHIRP
Live Sonar-Coverage: 20 degrees x 120 degrees
CHIRP - Frequencies Supported: Narrow Mode (180-240 kHz), 83/200 (75-155/130-250 kHz), Wide Mode (140-200 kHz), Full Mode (150-220 kHz)
Sonar-Frequencies Supported: 50/83/200/455 kHz
Depth-Sonar: 3,500' (optional 50 kHz), 1,200 ft (standard transducer)
CHIRP - Imaging Frequencies Supported: 455 kHz (420-520 kHz)
Depth-Down Imaging: 400 ft (455 kHz)
Range-Side Imaging (Side-To-Side): 800 ft (455 kHz)
Interface: Keypad Control
Power Draw: 800 mA
Power Input: 10.8-20 VDC
Power Output Peak-to-Peak: 4000 Watts
Power Output RMS: 500 Watts
Screen Snap Shot: Included
Sonar Recording: Included
Mount-Standard: Gimbal
Mount-Standard Size: 10.54 in W x 5.8 in H x 3.68 in D
Mount-Optional: In-Dash Mounting Kit
Mount-Optional Size: 10.54 in W x 5.44 in H x 1.13 in D
Transducer Mount Location: Transom
GPS Chartplotting: Included
GPS Receiver: Internal
GPS Trackplotting: Included
Waypoints, Routes, Tracks/Points: 2,750, 45, 50/20,000
Humminbird Basemap: Included
LakeMaster Compatibility: Yes
CoastMaster Compatibility: Yes
Navionics Gold/HotMaps Compatibility: Yes
Navionics Platinum+ Compatibility: Yes
Platinum Compatibility: Yes
AIS Compatibility: Optional
Autopilot Compatibility: Yes
Heading Sensor GPS Compatibility: Yes
Target Separation: 2.5"
Interference Rejection: 6 Modes
Noise Rejection: 10 Steps
Upgradable Software: Yes
X-Press Menu System: Yes
Custom Digital Readout: Yes
Display Colors Grayscale: 16-Bit
Display Type: Color TFT
Speed: Included
Temperature: Built In
Temperature Alarm: Yes
Temperature Graph: Yes
Warranty: One-Year Warranty
Normalized SKU: 4119201UPC Code: 082324058288
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Garmin
Garmin ECHOMAP Ultra 2 126sv US & Coastal CN GN+ & GT56UHD-TM Transducer #010-02882-01
$3,299.99
$3,596.94
Garmin 010-02882-01 FishfindersECHOMAP™ Ultra 2 126sv with GT56UHD-TM Transducer - Garmin Navionics+With big, crisp, sunlight-readable touchscreen displays, these versatile chartplotters put a world of fish-finding capability at the angler's fingertips. This display has built-in Garmin Navionics+™ mapping, and the transducer bundle adds Ultra High-Definition scanning sonars as well as CHIRP traditional sonar.Features:
ECHOMAP™ Ultra 2 126sv with Garmin Navionics+™
GT56UHD-TM Transducer
12” touchscreen
Supports livescope™ sonar, and more
Wirelessly network; share sonar, waypoints, and routes.
Capture screen recordings to share fish catches
Multi-band GPS for improved position accuracy
Livescope™ Sonar SupportThe ECHOMAP Ultra 2 series supports the full lineup of LiveScope live-scanning sonar products (transducers sold separately).Built-in UHD SonarSelect models are bundled with a GT56 transducer, which provides Garmin CHIRP traditional sonar and Ultra High-Definition ClearVü™ and SideVü™ scanning sonars for photo-like images of what’s beneath the surface.Vivid Color PalettesHigh-contrast, vivid scanning sonar color palettes make it easier than ever to distinguish targets and structures.Preloaded ChartsExperience unparalleled coverage and detail with built-in Garmin Navionics+ mapping, which includes a 1-year subscription for daily updates, depth range shading, and more.Premium Map UpgradesBring a fresh new look and feel to the chartplotter with optional Garmin Navionics Vision+™ premium mapping (sold separately), featuring high-resolution relief shading, satellite imagery, and more.Wireless NetworkingIf users have another compatible ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotter on the boat, users can wirelessly share information — such as sonar, waypoints, and routes — with them.Stay Connected Multi-Band GPSGet improved position accuracy with multi-band GPSNMEA 2000® Network CompatibilityConnect to heading sensors, autopilots, Fusion-Link™ audio systems, and more.ActiveCaptain® AppPair with the free smart-device app for software updates, screen recording, Garmin Quickdraw™ Community data, and more.Force® Trolling MotorWirelessly connect to a Force trolling motor to navigate to waypoints, draw and follow routes, and more.Take It With YouThe quick-disconnect bail mount lets users quickly install and remove the unit.In the Box:
ECHOMAP Ultra 126sv with optional Garmin Navionics+
GT56UHD-TM transducer
Power/data cable
Bail mount with quick-release cradle
Protective sun cover
Hardware
Documentation
SpecificationsGeneral:
Dimension: 13.4" x 9.0" x 3.9" (34.1 x 22.9 x 9.8 cm)
Weight: 5.5 lbs (2.5 kg)
Waterproof: IPX7
Touchscreen: Yes
Display Type: WXGA, IPS
Display Size: 10.3" x 6.4"; 12.1" diagonal (26.1 x 16.3 cm; 30.7 cm diagonal)
Display Resolution: 1280 x 800 pixels
Mounting Options: Bail or flush
Input: Touchscreen with Keyed Assist
Maps & Memory:
Accepts Data Cards: 2 microSD cards
Waypoints: 5000
Track Points: 50,000
Tracks: 50 saved tracks
Navigation Routes: 100
Sensors:
GPS: Yes
GLONASS: Yes
Galileo: Yes
BeiDou: Yes
Has Built-In Receiver: Yes
Receiver: 10 Hz
NMEA 2000 Compatible: Yes
NMEA 0183 Compatible: Yes
Supports WAAS: Yes
Supports Multi-Band, Multi-Constellation GPS: Yes
Built-In Maps:
Built-In Auto Guidance+: Yes
Garmin Navionics+ Inland & Coastal: Yes (see Additional)
Tide Tables: Yes (see Additional)
Optional Map Support:
Garmin Navionics+™: Yes
Garmin Navionics+ Vision+™: Yes
TOPO 100k: Yes
Standard Mapping: Yes
Garmin Quickdraw Contours: Yes
Chartplotter Features:
AIS: Yes
DSC: Yes
Supports Fusion-Link™ Compatible Radios: Yes
ActiveCaptain® Compatible: Yes
Sailing Features: Yes
Electrical Features:
Power Input: 9 to 18 VDC
Typical Current Draw at 12 VDC: 2.5 A
Maximum Current Draw at 12 VDC: 5.0 A
Maximum Power Usage at 10 VDC: 36 W
Sonar Features:
Displays Sonar: Yes
Power Output: 600 W
Traditional Sonar (Dual Frequency/Beam): Built-in (Single Channel Chirp, 70/83/200 Khz, L, M, H Chirp)
ClearVü: Built-in 260/455/800/1000/1200 kHz
SideVü: Built-in 260/455/800/1000/1200 kHz
Panoptix™ Sonar: Yes
Livescope: Yes
Connections:
NMEA 2000® Ports: 1
Garmin Marine Network Ports: 2 (Large Connector)
12-Pin Transducer Ports: 12-Pin Scanning Sonar
ANT+ (Connectivity): Yes
Garmin Wi-Fi Network (Local Connection): Yes
WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100288201UPC Code: 753759325572
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Furuno
Furuno CHIRP Fishfinder #FCV600
$1,007.44
$1,208.93
Furuno FCV600 Fishfinders
FCV600 CHIRP Fishfinder
The 5.7” FCV600 is capable of driving either a CHIRP or dual-frequency CW (continuous wave) transducer, allowing users to configure the Fish Finder to suit almost any need. With a sleek, piano-black presentation, comfortable rubber keys, and a robust rotary knob controller, the FCV600 gives users the freedom to choose from a wide variety of transducers. The soft-touch keys are inclined at the top and bottom, making them comfortable to press while creating an easy-to-operate and intuitive system.
Sunlight and yellow color palettes offer greatly improved visibility in daylight and for those who deal with color blindness. The Color Range Expansion feature broadens the range of discrete signal intensities that can be detected and paints them in different colors. With color range expansion, the range of identifiable echoes is expanded, so you can intuitively identify bottom fish from the seabed.
Furuno’s RezBoost™ signal processing technology produces a picture that is up to 8 times clearer, breathing life into the standard CW transducer users may already have installed. A second FCV600 display can be installed to show the echoes and nav data from the FCV600 via the built-in wireless network. This simple yet powerful solution allows for continuous monitoring of the underwater situation from the stern or bow while fishing with a simplified installation.
Features:
5.6” (FCV600) TruEcho CHIRP/CW Fish Finder
Drives either a CHIRP or CW transducer
Color palettes offer unbeatable daylight visibility
Color Range Expansion displays returns from more discreet signal frequencies for unbeatable target separation
RezBoost™ signal processing produces a picture up to 8 times clearer
Wireless 2nd display capability
Heave correction with the satellite compass
What's in the box:
FCV600 Display
FCV600 Display Cover
FCV600 Display Bracket
FCV600 Knob for Bracket (2)
2M Power/Data cable
Self-Tapping Screws 5x20 (4)
LCD Cleaning Cloth
Glass Fuse 3A (2)
Installation Manual
Normalized SKU: FCV600UPC Code: 611679401649
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Simrad
Simrad NSX 3012UW Combo with Active Imaging 3-In-1 T/M #000-16216-001
$2,899.00
$3,270.07
Watch VideoSimrad 000-16216-001 FishfindersNSX 3012UW Combo with Active Imaging™ 3-in-1 TransducerExpand your horizons with the world's first fully-featured ultrawide marine display. NSX® ULTRAWIDE brings all the benefits of dual screens to a single display for our most immersive experience yet. Get a truly unique, eye-catching dash, see apps as they were meant to be seen, and experience C-MAP®'s X-Gen charts in more detail than ever.Get a Fresh PerspectiveNSX ULTRAWIDE offers a new perspective on boating. Discover an all-new aspect ratio for our most immersive on-the-water experience yet. Simpler Boating with Simrad's Latest Operating SystemNSX ULTRAWIDE also delivers game-changing simplicity. Use the intuitive activity bar to pin your favorite apps and switch between them with a single touch. The fully customizable instruments panel lets users make the NSX their own by ensuring users always have the right data at hand and nothing more.The simplified interface means users spend less time navigating menus and more time navigating water. Even that is quicker considering Simrad's fastest-ever auto-routing calculates routes in one-third of the time.Superior Engine ControlConnectivity is at the heart of NSX ULTRAWIDE. The display feeds more information than ever to the helm, giving superior control over the full suite of on-board technology.It all begins with superior engine control. Nobody integrates better with Mercury® than Simrad does, and NSX ULTRAWIDE also offers superior integration with other leading propulsion brands such as Honda and Suzuki.Bow-To-Stern IntegrationControl with NSX ULTRAWIDE extends across the entire vessel, with support for CZone® digital switching, RGBW lighting, IP cameras, and audio—with an intuitive Setup Wizard to help you get it all connected.A Fishing SuperpowerAnglers benefit from leading sonar tech like FishReveal™ and Active Imaging®, which provide high-res images 300 feet to the sides and below the boat. Compatibility includes a wide range of 1kW transducers, meaning users can fish even in the deepest waters.*Requires additional sonar module and a minimum 1.7 software update.FeaturesSimrad® Suite Integration:
See near and far with full support for 3G, 4G, and HALO® radars
Easy autopilot integration with NAC-1, NAC-2, NAC-3 and NAC-D pilots
Simrad® App integration for waypoint management and offline trip planning
Third-Party Integration:
Best-in-class Mercury® Integration, inc. SmartCraft® Connect
Integration with leading propulsion brands such as Honda and Suzuki
CZone® digital switching
OmniSense
Dometic
Lumishore lighting
Multiple audio partners
IP cameras
HTML5 app compatible
Much, much more...
Charts & Navigation:
Optimized for C-MAP® DISCOVER™ X AND REVEAL™ X charts
X-Chart Manager
3x faster autorouting*
*vs SIMRAD® GO
Fishfinding & Sonar Capabilities:
Sonar sharing between NSX® devices
Compatible with Active Imaging™, featuring CHIRP, SideScan, and DownScan Imaging™, as well as the S3100 & S5100 sonar modules*
*Requires minimum 1.7 software update
Network Connectivity:
Wireless
Ethernet
USB
NMEA 2000®
Additional Features:
The latest Simrad® operating system, for game-changing ease of use
Ultrawide SolarMAX™ IPS HD touchscreen with extreme viewing angles
Intuitive setup wizard
Bracket mount sold separately
Specifications:Display:
Backlight Color: White
Display Resolution: 1920 x 720 px
Display Size: 12 inches
Screen Brightness: >1000 nits
Viewing Angles: 85° (top, bottom, left, and right)
Physical:
Compass Safe: 50 cm (1.7 ft)
Dimensions (W x H x D): No Bracket, no suncover W: 337.0 mm (13.30") x H: 147.9 mm (5.82") x D: 88.5 mm (3.48"). With gimbal bracket| H: 157.9 mm (6.22") D:96.5 mm (3.80")
Mounting Type: Rear mount (bracket supplied), bracket mount (bracket optional)
Weight: 1.5 kg (3.3 lbs)
Electrical:
Power Consumption Max: 19.8 W (1434 mA at 13.8 V)
Recommended Fuse Rating: 3A
Supply Voltage: 12 V DC (10 - 17 V DC min-max)
Environment:
Humidity: IEC 60945 Damp heat 66°C (150°F) at 95% relative (18 hr)
Operating Temperature Range: -15°C to 55°C (5°F to 131°F)
Shock Vibration: 100,000 cycles of 20 G
Storage Temperature Range: -20°C to 60°C (-4°F to 140°F)
Waterproof Rating: IPx6 and IPx7
Connectivity:
Bluetooth: Bluetooth 4.0 with support for Bluetooth Classic
Ethernet Ports: 1 port (5-pin connector)
Connectivity Wi-Fi: IEEE 802.11b/g/n
NMEA 2000 Connectivity: 1 x NMEA 2000 Micro-C port, 1 LEN
PC Connectivity: No
SD Card Storage: 1 MicroSD slot, 1 x USB
Video: IP Camera support
MFD:
Cartography Included: Discover X chart card of North America
Digital Switching: Czone / Simrad DDS
GPS: Internal, 10Hz
Sonar Compatibility: One 9-pin Xsonic 1 kW Sonar port. Single channel CHIRP, 50/200 kHz, HDI, Active Imaging
Waypoints, Routes, Tracks: 6000 waypoints, 500 Routes with 100 max route points, 50 tracks with up to 12,000 track points.
Weather: No
GPS:
GPS Receiver Channels: 32 Channels
Position Accuracy: Horizontal Accuracy 3 m (9.8 ft)
Update rate: 10 Hz high-speed update (internal)WASS, MSAS, EGNOS, GLONASS
Other:
Interface: Multi-touch screen
Languages: German -English -Dutch -Danish -Spanish-French-Italian -Norwegian -Portuguese -Finnish -Swedish -Icelandic -Greek -Chinese-Turkish -Estonian -Croatian -Lithuanian -Latvian -Polish -Chinese Simplified -Japanese -Korean -Ukrainian
Warranty Period: 2 Years
Normalized SKU: 00016216001UPC Code: 9420064132423Simrad 000-16216-001 Video
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Garmin
Garmin ECHOMAP UHD2 93sv & GT56 Livescope Bundle #010-02688-01/LIVESCOPE
$3,099.98
$3,496.77
Download Literature Watch VideoGarmin 010-02688-01/LIVESCOPE FishfindersECHOMAP™ UHD2 93sv with GT56 Livescope BundleThis kit includes Garmin’s ECHOMAP™ UHD2 93sv Chartplotter/Fishfinder Combo with US Inland Maps & GT56UHD-TM along with Garmin’s LiveScope™ Plus System with GLS 10™ & LVS34 Transducer.Garmin ECHOMAP™ UHD2 93sv Chartplotter/Fishfinder Combo with US Inland Maps & GT56UHD-TMWhen it comes to catching more fish, they say, “Talk to a local.” With the ECHOMAP UHD2 chartplotter, which offers our best-in-class sonar and mapping and premium touchscreen display with a keyed assist, you’ll know the water even better than they do.
The bright 9” touchscreen display with keyed assist is user-friendly and easy to read.
Good things come in threes. Three sonar types, that is Garmin traditional, ClearVü™ and SideVü™ sonars
Improved detail? Check. Distinguished targets? Yep. That’s the beauty of high-contrast vivid color palettes
If you’re running another ECHOMAP UHD2 chartplotter, you can wirelessly share sonar, waypoints, and routes
Want our best in mapping? Who doesn’t? Select chartplotters come with Garmin Navionics+™ mapping
Sonar SupportWith crisp, clear traditional sonar and brilliant ClearVü and SideVü scanning sonars, the fish will have nowhere to hide. Your ECHOMAP UHD2 also supports LiveScope™ live-scanning sonar.Vivid Color PalettesHigh-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structures.Bundle Your TransducerYour ECHOMAP UHD2 device supports a variety of Garmin transducers. The 9” chartplotter comes with a GT56 transducer.Preloaded ChartsYou’ve never seen Garmin cartography like this before. Select chartplotters come with built-in Garmin Navionics+ cartography which includes a 1-year subscription for daily updates, depth range shading, and more.Wireless NetworkingIf you have another compatible ECHOMAP UHD2 chartplotter on your boat, you can wirelessly share information — such as sonar1, waypoints, and routes — with them.Activecaptain® AppBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app on your compatible smartphone for access to the OneChart™ feature, smart notifications, software updates, Garmin Quickdraw™ Community data, and more2. Auto Guidance+™ TechnologyChartplotters with built-in Garmin Navionics+ charts include downloadable Auto Guidance+ technology3 with the ActiveCaptain app.Troll With Force®Your ECHOMAP UHD2 wirelessly connects to your Force trolling motor to create and follow routes, navigate to waypoints, control speed, check battery life, and more.Multi-Band GPSGet improved position accuracy, particularly in areas where signals are reflected or weak, with multi-band GPS.In The Box:
ECHOMAP UHD2 93sv
GT56-TM transducer
Power cable
Tilt mount with quick-release cradle
Protective cover
Hardware
Documentation
Connections:
NMEA 2000 Ports: 1
Garmin Marine Network Ports: 1
12-Pin Transducer Ports: 1
Bluetooth® Pairing
ANT+ (connectivity)
Garmin Wi-Fi Network (Local Connection)
1LiveScope sonar cannot be shared wirelessly between two ECHOMAP UHD2 chartplotters.2Requires the ActiveCaptain app on your compatible smartphone paired to the ECHOMAP UHD2 6”, 7” and 9” chartplotters3Auto Guidance+ is for planning purposes only and does not replace safe navigation operationsGarmin LiveScope™ Plus System with GLS 10™ & LVS34 TransducerThe latest in LiveScope technology, the LiveScope Plus System offers improved resolution, reduced noise, clearer images, and better target separation.Features:
See images clearly with improved screen clarity, transducer sensitivity, and target separation
Scan surroundings with sharper images, reduced noise, and fewer sonar artifact
Upgrade your current LiveScope System black box (GLS™ 10 sonar module) with just a new transducer
Get maximum contrast and clarity in your images with vivid color palettes
Don’t miss a thing with supported Forward, Down, and Perspective modes and necessary mount
Real-Time ImagesReal-time sonar ensures that your live images are as accurate as possible. Clear VisionSee exactly what you need with reduced noise and fewer sonar artifacts that impede your picture of fish and structure. Image StabilizationA built-in stabilization system keeps the sonar image on your compatible chartplotter steady, even in rough conditions. Vivid Color PalettesChoose from seven vivid color options — including Aqua, Caribbean, Lava, and more — to see fish and structure in maximum contrast and clarity. Forward ModeScout ahead of your boat to see what’s happening in real time. Down ModeExplore live views of the activity directly beneath your boat. Perspective ModeSee under the water with a view from your perspective above the water.In The Box:
LiveScope GLS 10 sonar black box
Panoptix LVS34 transducer
Perspective mount
Trolling motor barrel mount
Shaft mount
Power cable
2-meter Garmin Marine Network cable (small connector)
Network adapter cable
Documentation
Normalized SKU: 0100268801/LIVESCOPEGarmin 010-02688-01/LIVESCOPE Literature Download Product BrochureGarmin 010-02688-01/LIVESCOPE Video
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Garmin
Garmin ECHOMAP UHD2 93sv with Ducer Livescope Bundle #010-02688-00/LVS34
$2,999.98
$3,383.97
Download Literature Watch Video
Garmin 010-02688-00/LVS34 Fishfinders
ECHOMAP™ UHD2 93sv with Livescope Bundle
This kit includes Garmin’s ECHOMAP™ UHD2 93sv Chartplotter/Fishfinder Combo with US Inland Maps (no transducer) and Garmin’s LiveScope™ Plus System with GLS 10™ & LVS34 Transducer.
Garmin ECHOMAP™ UHD2 93sv Chartplotter/Fishfinder Combo with US Inland Maps without Transducer
When it comes to catching more fish, they say, “Talk to a local.” With the ECHOMAP UHD2 chartplotter, which offers our best-in-class sonar and mapping and premium touchscreen display with a keyed assist, you’ll know the water even better than they do.
The bright 9” touchscreen display with keyed assist is user-friendly and easy to read.
Good things come in threes. Three sonar types, that is Garmin traditional, ClearVü™ and SideVü™ sonars.
Improved detail? Check. Distinguished targets? Yep. That’s the beauty of high-contrast vivid color palettes.
If you’re running another ECHOMAP UHD2 chartplotter, you can wirelessly share sonar, waypoints, and routes.
Want our best in mapping? Who doesn’t? Select chartplotters come with Garmin Navionics+™ mapping.
Sonar Support
With crisp, clear traditional sonar and brilliant ClearVü and SideVü scanning sonars, the fish will have nowhere to hide. Your ECHOMAP UHD2 also supports LiveScope™ live-scanning sonar.
Vivid Color Palettes
High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structures.
Preloaded Charts
You’ve never seen Garmin cartography like this before. Select chartplotters come with built-in Garmin Navionics+ cartography which includes a 1-year subscription for daily updates, depth range shading, and more.
Wireless Networking
If you have another compatible ECHOMAP UHD2 chartplotter on your boat, you can wirelessly share information — such as sonar1, waypoints, and routes — with them.
Activecaptain® App
Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app on your compatible smartphone for access to the OneChart™ feature, smart notifications, software updates, Garmin Quickdraw™ Community data, and more2.
Auto Guidance+™ Technology
Chartplotters with built-in Garmin Navionics+ charts include downloadable Auto Guidance+ technology3 with the ActiveCaptain app.
Troll With Force®
Your ECHOMAP UHD2 wirelessly connects to your Force trolling motor to create and follow routes, navigate to waypoints, control speed, check battery life, and more.
Multi-Band GPS
Get improved position accuracy, particularly in areas where signals are reflected or weak, with multi-band GPS.
Connections:
NMEA 2000 Ports: 1
Garmin Marine Network Ports: 1
12-Pin Transducer Ports: 1
Bluetooth® Pairing
ANT+ (connectivity)
Garmin Wi-Fi Network (Local Connection)
1LiveScope sonar cannot be shared wirelessly between two ECHOMAP UHD2 chartplotters.
2Requires the ActiveCaptain app on your compatible smartphone paired to the ECHOMAP UHD2 6”, 7” and 9” chartplotters
3Auto Guidance+ is for planning purposes only and does not replace safe navigation operations
Garmin LiveScope™ Plus System with GLS 10™ & LVS34 Transducer
The latest in LiveScope technology, the LiveScope Plus System offers improved resolution, reduced noise, clearer images, and better target separation.
Features:
See images clearly with improved screen clarity, transducer sensitivity, and target separation.
Scan surroundings with sharper images, reduced noise, and fewer sonar artifacts
Upgrade your current LiveScope System black box (GLS™ 10 sonar module) with just a new transducer
Get maximum contrast and clarity in your images with vivid color palettes.
Don’t miss a thing with supported Forward, Down, and Perspective modes and necessary mount
Real-Time Images
Real-time sonar ensures that your live images are as accurate as possible.
Clear Vision
See exactly what you need with reduced noise and fewer sonar artifacts that impede your picture of fish and structure.
Image Stabilization
A built-in stabilization system keeps the sonar image on your compatible chartplotter steady, even in rough conditions.
Vivid Color Palettes
Choose from seven vivid color options — including Aqua, Caribbean, Lava, and more — to see fish and structure in maximum contrast and clarity.
Forward Mode
Scout ahead of your boat to see what’s happening in real time.
Down Mode
Explore live views of the activity directly beneath your boat.
Perspective Mode
See under the water with a view from your perspective above the water.
In The Box:
LiveScope GLS 10 sonar black box
Panoptix LVS34 transducer
Perspective mount
Trolling motor barrel mount
Shaft mount
Power cable
2-meter Garmin Marine Network cable (small connector)
Network adapter cable
Documentation
Normalized SKU: 0100268800/LVS34
Garmin 010-02688-00/LVS34 Literature Download
Product Brochure
Garmin 010-02688-00/LVS34 Video
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
SI-TEX
Sitex Standalone 8" Chart Plotter System with Color LCD #SVS-880CE+
$1,074.99
$1,289.99
SI-TEX SVS-880CE+ FishfindersStandalone 8" Chartplotter System with Color LCD, Internal & External GPS Antenna & C-MAP 4D CardThe SI-TEX SVS-880CE+ is a powerful big-screen performer designed to fit every boat and budget. This compact chartplotter and chartplotter/sonar system delivers the goods for any vessel, from center console skiffs to sailboats to light commercial boats.Differences between SVS-880CE & SVS-880CE+The SVS-880CE+ has an updated Android processor and it only uses C-Map 4D cartridges. Features:
8" high-resolution color LCD and compact case
52-channel GPS
"Dual fuel" charting the C-MAP and Navionics cartography
Global GPS compatibility
Brilliant LED backlighting for daylight readability
Easy, intuitive operation and control
Video input for underwater and on-deck cameras
Weather protector cover included
General Specifications:
Display Screen SVS-880CE+: 8-inch Color LCD with LED backlight
Resolution SVS-880CE+: SVGA (800 x 600 pixels)
Power Supply: DC 12V-36V(±10%) SVS-880: 4W(without sonar)/ 6W(with sonar
Operating Temperature: Display Unit -15 degrees C to +50 degrees C, Antenna Unit -25 degrees C to +70 degrees C
Performance Standard: IMO Resolution MSC.112(73)
Chartplotter Specifications:
Display Method: Mercator Projection
Display Mode: True motion / N/S/E/W up / Course up / Head up
Latitude Limits: Between 85 degrees N to 85 degrees S
Map Scale: 0.05nm to 1500nm
Map Datum: WGS-84 6
Waypoints: 20,000 points *Total of 16 colors and 16 icons are selectable for each point with a name tag (6 alphanumeric characters)
Track Points: 50,000 points (2 types)
Route: Max capacity 100 Routes *20 WPTs per each Route. Each with name tags (8 alphanumeric characters)
Draw Point: 1,000 points
Area Name: 1,000 points
Chart Data: Standard w/Navionics Gold C-MAP MAX optional
Output Data: NMEA-0183
Input Data: NMEA-0183
Alarm Arrival, Anchor, XTE, Interval timer, Userline
GPS Receiver Specifications:
GNSS Receiver Capabilities: GPS - L1 C/A code, GLONASS - L1OF/, QZSS - L1 C/A code, Galileo - E1B/E1C/L1
Number of Channels: 52 channels
Horizontal Positioning Accuracy: Autonomous 2.5m (CEP 50%)
Sensitivity: Acquisition -148 dBm, Tracking -165 dBm, Reacquisition -162 dBm, Nav Update 1Hz, 5Hz)
Support: DGPS, SBAS (EGNOS,WAAS, MASA, GAGAN)
Sonar Specifications:
Display Mode: Normal (single/dual-frequency), Bottom-lock. Bottom-zoom, A-scope
Frequency 50 and 200 KHz (single or dual)
Output Power: 600W
Range Speed: 600W - 2.5m - 600m
Image Speed: Fixed 8 speeds (4/1, 2/1, 1/1, 1/2, 1/4, 1/8, 1/16, 1/32) and stop
Rejection: Interference rejection: 3 levels, Noise rejection: 4 levels
Function: Gain(auto/manual), Range(auto/manual), Shift(auto/manual), White/Black line Support speed sensor, Water temperature
Normalized SKU: SVS880CE+UPC Code: 010407102122
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Garmin
Garmin ECHOMAP Ultra 2 126sv without Transducer Navionics+ #010-02882-00
$2,899.99
$3,160.95
Garmin 010-02882-00 FishfindersECHOMAP™ Ultra 2 126sv without Transducer - Garmin Navionics+With big, crisp, sunlight-readable touchscreen displays, these versatile chartplotters put a world of fish-finding capability at the angler's fingertips. This display has built-in Garmin Navionics+™ mapping.Features:
ECHOMAP™ Ultra 2 126sv with Garmin Navionics+™
12” touchscreen
Supports livescope™ sonar, and more
Wirelessly network; share sonar, waypoints, and routes.
Capture screen recordings to share fish catches
Multi-band GPS for improved position accuracy
Livescope™ Sonar SupportThe ECHOMAP Ultra 2 series supports the full lineup of LiveScope live-scanning sonar products (transducers sold separately).Built-in UHD SonarSelect models are bundled with a GT56 transducer, which provides Garmin CHIRP traditional sonar and Ultra High-Definition ClearVü™ and SideVü™ scanning sonars for photo-like images of what’s beneath the surface.Vivid Color PalettesHigh-contrast, vivid scanning sonar color palettes make it easier than ever to distinguish targets and structures.Preloaded ChartsExperience unparalleled coverage and detail with built-in Garmin Navionics+ mapping, which includes a 1-year subscription for daily updates, depth range shading, and more.Premium Map UpgradesBring a fresh new look and feel to the chartplotter with optional Garmin Navionics Vision+™ premium mapping (sold separately), featuring high-resolution relief shading, satellite imagery, and more.Wireless NetworkingIf users have another compatible ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotter on the boat, users can wirelessly share information — such as sonar, waypoints, and routes — with them.Stay Connected Multi-Band GPSGet improved position accuracy with multi-band GPSNMEA 2000® Network CompatibilityConnect to heading sensors, autopilots, Fusion-Link™ audio systems, and more.ActiveCaptain® AppPair with the free smart-device app for software updates, screen recording, Garmin Quickdraw™ Community data, and more.Force® Trolling MotorWirelessly connect to a Force trolling motor to navigate to waypoints, draw and follow routes, and more.Take It With YouThe quick-disconnect bail mount lets users quickly install and remove the unit.In the Box:
ECHOMAP Ultra 126sv with optional Garmin Navionics+
Power/data cable
Bail mount with quick-release cradle
Protective sun cover
8-pin transducer to 12-pin sounder adapter cable
Hardware
Documentation
SpecificationsGeneral:
Dimension: 13.4" x 9.0" x 3.9" (34.1 x 22.9 x 9.8 cm)
Weight: 5.5 lbs (2.5 kg)
Waterproof: IPX7
Touchscreen: Yes
Display Type: WXGA, IPS
Display Size: 10.3" x 6.4"; 12.1" diagonal (26.1 x 16.3 cm; 30.7 cm diagonal)
Display Resolution: 1280 x 800 pixels
Mounting Options: Bail or flush
Input: Touchscreen with Keyed Assist
Maps & Memory:
Accepts Data Cards: 2 microSD cards
Waypoints: 5000
Track Points: 50,000
Tracks: 50 saved tracks
Navigation Routes: 100
Sensors:
GPS: Yes
GLONASS: Yes
Galileo: Yes
BeiDou: Yes
Has Built-In Receiver: Yes
Receiver: 10 Hz
NMEA 2000 Compatible: Yes
NMEA 0183 Compatible: Yes
Supports WAAS: Yes
Supports Multi-Band, Multi-Constellation GPS: Yes
Built-In Maps:
Built-In Auto Guidance+: Yes
Garmin Navionics+ Inland & Coastal: Yes (see Additional)
Tide Tables: Yes (see Additional)
Optional Map Support:
Garmin Navionics+™: Yes
Garmin Navionics+ Vision+™: Yes
TOPO 100k: Yes
Standard Mapping: Yes
Garmin Quickdraw Contours: Yes
Chartplotter Features:
AIS: Yes
DSC: Yes
Supports Fusion-Link™ Compatible Radios: Yes
ActiveCaptain® Compatible: Yes
Sailing Features: Yes
Electrical Features:
Power Input: 9 to 18 VDC
Typical Current Draw at 12 VDC: 2.5 A
Maximum Current Draw at 12 VDC: 5.0 A
Maximum Power Usage at 10 VDC: 36 W
Sonar Features:
Displays Sonar: Yes
Power Output: 600 W
Traditional Sonar (Dual Frequency/Beam): Built-in (Single Channel Chirp, 70/83/200 Khz, L, M, H Chirp)
ClearVü: Built-in 260/455/800/1000/1200 kHz
SideVü: Built-in 260/455/800/1000/1200 kHz
Panoptix™ Sonar: Yes
Livescope: Yes
Connections:
NMEA 2000® Ports: 1
Garmin Marine Network Ports: 2 (Large Connector)
12-Pin Transducer Ports: 12-Pin Scanning Sonar
ANT+ (Connectivity): Yes
Garmin Wi-Fi Network (Local Connection): Yes
WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100288200UPC Code: 753759325565
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Garmin
Garmin ECHOMAP Ultra 2 122sv without Transducer #010-02881-00
$2,899.99
$3,160.95
Garmin 010-02881-00 FishfindersECHOMAP™ Ultra 2 122sv without TransducerWith big, crisp, sunlight-readable touchscreen displays, these versatile chartplotters put a world of fish-finding capability at the angler's fingertips. Features:
ECHOMAP™ Ultra 2 122sv with Worldwide Basemap
12” touchscreen
Supports livescope™ sonar, and more
Wirelessly network; share sonar, waypoints, and routes.
Capture screen recordings to share fish catches
Multi-band GPS for improved position accuracy
Livescope™ Sonar SupportThe ECHOMAP Ultra 2 series supports the full lineup of LiveScope live-scanning sonar products (transducers sold separately).Built-in UHD SonarSelect models are bundled with a GT56 transducer, which provides Garmin CHIRP traditional sonar and Ultra High-Definition ClearVü™ and SideVü™ scanning sonars for photo-like images of what’s beneath the surface.Vivid Color PalettesHigh-contrast, vivid scanning sonar color palettes make it easier than ever to distinguish targets and structures.Premium Map UpgradesBring a fresh new look and feel to the chartplotter with optional Garmin Navionics Vision+™ premium mapping (sold separately), featuring high-resolution relief shading, satellite imagery, and more.Wireless NetworkingIf users have another compatible ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotter on the boat, users can wirelessly share information — such as sonar, waypoints, and routes — with them.Stay Connected Multi-Band GPSGet improved position accuracy with multi-band GPSNMEA 2000® Network CompatibilityConnect to heading sensors, autopilots, Fusion-Link™ audio systems, and more.ActiveCaptain® AppPair with the free smart-device app for software updates, screen recording, Garmin Quickdraw™ Community data, and more.Force® Trolling MotorWirelessly connect to a Force trolling motor to navigate to waypoints, draw and follow routes, and more.Take It With YouThe quick-disconnect bail mount lets users quickly install and remove the unit.In the Box:
ECHOMAP Ultra 122sv
Power/data cable
Bail mount with quick-release cradle
Protective sun cover
8-pin transducer to 12-pin sounder adapter cable
Hardware
Documentation
Specifications
General:
Dimension: 13.4" x 9.0" x 3.9" (34.1 x 22.9 x 9.8 cm
Weight: 5.5 lbs (2.5 kg)
Waterproof: IPX7
Touchscreen: Yes
Display Type: WXGA, IPS
Display Size: 10.3" x 6.4"; 12.1" diagonal (26.1 x 16.3 cm; 30.7 cm diagonal)
Display Resolution: 1280 x 800 pixels
Mounting Options: Bail or flush
Input: Touchscreen with Keyed Assist
Maps & Memory:
Accepts Data Cards: 2 microSD cards
Waypoints: 5000
Track Points: 50,000
Tracks: 50 saved tracks
Navigation Routes: 100
Sensors:
GPS: Yes
GLONASS: Yes
Galileo: Yes
BeiDou: Yes
Has Built-In Receiver: Yes
Receiver: 10 Hz
NMEA 2000 Compatible: Yes
NMEA 0183 Compatible: Yes
Supports WAAS: Yes
Supports Multi-Band, Multi-Constellation GPS: Yes
Built-In Maps:
Built-In Auto Guidance+: Yes
Garmin Navionics+ Inland & Coastal: Yes (see Additional)
Tide Tables: Yes (see Additional)
Optional Map Support:
BlueChart g3: Yes
BlueChart g3 Vision: Yes
LakeVü g3: Yes
LakeVü g3 Ultra: Yes
Garmin Navionics+™: Yes
Garmin Navionics+ Vision+™: Yes
TOPO 100k: Yes
Standard Mapping: Yes
Garmin Quickdraw Contours: Yes
Chartplotter Features:
AIS: Yes
DSC: Yes
Supports Fusion-Link™ Compatible Radios: Yes
ActiveCaptain® Compatible: Yes
Sailing Features: Yes
Electrical Features:
Power Input: 9 to 18 VDC
Typical Current Draw at 12 VDC: 2.5 A
Maximum Current Draw at 12 VDC: 5.0 A
Maximum Power Usage at 10 VDC: 36 W
Sonar Features:
Displays Sonar: Yes
Power Output: 600 W
Traditional Sonar (Dual Frequency/Beam): Built-in (Single Channel Chirp, 70/83/200 Khz, L, M, H Chirp)
ClearVü: Built-in 260/455/800/1000/1200 kHz
SideVü: Built-in 260/455/800/1000/1200 kHz
Panoptix™ Sonar: Yes
Livescope: Yes
Connections:
NMEA 2000® Ports: 1
Garmin Marine Network Ports: 2 (Large Connector)
12-Pin Transducer Ports: 12-Pin Scanning Sonar
ANT+ (Connectivity): Yes
Garmin Wi-Fi Network (Local Connection): Yes
WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100288100UPC Code: 753759325534
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Garmin
Garmin ECHOMAP Ultra 2 106sv with GT56UHD-TM Transducer Navionics+ #010-02880-01
$2,499.99
$2,802.26
Garmin 010-02880-01 FishfindersECHOMAP™ Ultra 2 106sv with GT56UHD-TM Transducer - Garmin Navionics+With big, crisp, sunlight-readable touchscreen displays, these versatile chartplotters put a world of fish-finding capability at the angler's fingertips. This display has built-in Garmin Navionics+™ mapping, and the transducer bundle adds Ultra High-Definition scanning sonars as well as CHIRP traditional sonar.Features:
ECHOMAP™ Ultra 2 106sv with Garmin Navionics+ Inland & Coastal Mapping
GT56UHD-TM transducer
10” touchscreen
Supports livescope™ sonar, and more
Wirelessly network; share sonar, waypoints, and routes.
Capture screen recordings to share fish catches
Multi-band GPS for improved position accuracy
Livescope™ Sonar SupportThe ECHOMAP Ultra 2 series supports the full lineup of LiveScope live-scanning sonar products (transducers sold separately).Built-in UHD SonarSelect models are bundled with a GT56 transducer, which provides Garmin CHIRP traditional sonar and Ultra High-Definition ClearVü™ and SideVü™ scanning sonars for photo-like images of what’s beneath the surface.Vivid Color PalettesHigh-contrast, vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.Preloaded ChartsExperience unparalleled coverage and detail. with built-in Garmin Navionics+ mapping, which includes a 1-year subscription for daily updates, depth range shading, and more.Premium Map UpgradesBring a fresh new look and feel to the chartplotter with optional Garmin Navionics Vision+™ premium mapping (sold separately), featuring high-resolution relief shading, satellite imagery and more.Wireless NetworkingIf users have another compatible ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotter on the boat, users can wirelessly share information — such as sonar, waypoints and routes — with them.Stay Connected Multi-Band GPSGet improved position accuracy with multi-band GPSNMEA 2000® Network CompatibilityConnect to heading sensors, autopilots, Fusion-Link™ audio systems, and more.ActiveCaptain® AppPair with the free smart-device app for software updates, screen recording, Garmin Quickdraw™ Community data, and more.Force® Trolling MotorWirelessly connect to a Force trolling motor to navigate to waypoints, draw and follow routes, and more.Take It With YouThe quick-disconnect bail mount lets users quickly install and remove the unit.In the Box:
ECHOMAP Ultra 106sv with optional Garmin Navionics+
GT56UHD-TM transducer
Power/data cable
Bail mount with quick-release cradle
Protective sun cover
Hardware
Documentation
Specifications
General:
Dimension: 11.6" x 7.7" x 3.9" (29.5 x 19.5 x 9.8 cm)
Weight: 4.0 lbs (1.8 kg)
Waterproof: IPX7
Touchscreen: Yes
Display Type: WXGA, IPS
Display Size: 8.5" x 5.4"; 10" diagonal (21.7 x 13.6 cm; 25.4 cm diagonal)
Display Resolution: 1280 x 800 pixels
Mounting Options: Bail or flush
Input: Touchscreen with Keyed Assist
Maps & Memory:
Accepts Data Cards: 2 microSD cards
Waypoints: 5000
Track Points: 50,000
Tracks: 50 saved tracks
Navigation Routes: 100
Sensors:
GPS: Yes
GLONASS: Yes
Galileo: Yes
BeiDou: Yes
Has Built-In Receiver: Yes
Receiver: 10 Hz
NMEA 2000 Compatible: Yes
NMEA 0183 Compatible: Yes
Supports WAAS: Yes
Supports Multi-Band, Multi-Constellation GPS: Yes
Built-In Maps:
Built-In Auto Guidance+: Yes
Garmin Navionics+ Inland & Coastal: Yes (see Additional)
Tide Tables: Yes (see Additional)
Optional Map Support:
Garmin Navionics+™: Yes
Garmin Navionics+ Vision+™: Yes
TOPO 100k: Yes
Standard Mapping: Yes
Garmin Quickdraw Contours: Yes
Chartplotter Features:
AIS: Yes
DSC: Yes
Supports Fusion-Link™ Compatible Radios: Yes
ActiveCaptain® Compatible: Yes
Sailing Features: Yes
Electrical Features:
Power Input: 9 to 18 VDC
Typical Current Draw at 12 VDC: 2.5 A
Maximum Current Draw at 12 VDC: 5.0 A
Maximum Power Usage at 10 VDC: 36 W
Sonar Features:
Displays Sonar: Yes
Power Output: 600 W
Traditional Sonar (Dual Frequency/Beam): Built-in (Single Channel Chirp, 70/83/200 Khz, L, M, H Chirp)
ClearVü: Built-in 260/455/800/1000/1200 kHz
SideVü: Built-in 260/455/800/1000/1200 kHz
Panoptix™ Sonar: Yes
Livescope: Yes
Connections:
NMEA 2000® Ports: 1
Garmin Marine Network Ports: 2 (Large Connector)
12-Pin Transducer Ports: 12-Pin Scanning Sonar
ANT+ (Connectivity): Yes
Garmin Wi-Fi Network (Local Connection): Yes
Normalized SKU: 0100288001UPC Code: 753759325527
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Garmin
Garmin ECHOMAP Ultra 2 102sv with GT56UHD-TM Transducer #010-02879-01
$2,499.99
$2,899.99
Garmin 010-02879-01 FishfindersECHOMAP™ Ultra 2 102sv with GT56UHD-TM TransducerWith big, crisp, sunlight-readable touchscreen displays, these versatile chartplotters put a world of fish-finding capability at the angler's fingertips. This display's transducer bundle adds Ultra High-Definition scanning sonars as well as CHIRP traditional sonar.Features:
ECHOMAP™ Ultra 2 102sv with Worldwide Basemap
GT56UHD-TM Transducer
10” touchscreen
Supports livescope™ sonar, and more
Wirelessly network; share sonar, waypoints, and routes.
Capture screen recordings to share fish catches
Multi-band GPS for improved position accuracy
Livescope™ Sonar SupportThe ECHOMAP Ultra 2 series supports the full lineup of LiveScope live-scanning sonar products (transducers sold separately).Built-in UHD SonarSelect models are bundled with a GT56 transducer, which provides Garmin CHIRP traditional sonar and Ultra High-Definition ClearVü™ and SideVü™ scanning sonars for photo-like images of what’s beneath the surface.Vivid Color PalettesHigh-contrast, vivid scanning sonar color palettes make it easier than ever to distinguish targets and structures.Premium Map UpgradesBring a fresh new look and feel to the chartplotter with optional Garmin Navionics Vision+™ premium mapping (sold separately), featuring high-resolution relief shading, satellite imagery, and more.Wireless NetworkingIf users have another compatible ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotter on the boat, users can wirelessly share information — such as sonar, waypoints, and routes — with them.Stay Connected Multi-Band GPSGet improved position accuracy with multi-band GPSNMEA 2000® Network CompatibilityConnect to heading sensors, autopilots, Fusion-Link™ audio systems, and more.ActiveCaptain® AppPair with the free smart-device app for software updates, screen recording, Garmin Quickdraw™ Community data, and more.Force® Trolling MotorWirelessly connect to a Force trolling motor to navigate to waypoints, draw and follow routes, and more.Take It With YouThe quick-disconnect bail mount lets users quickly install and remove the unit.In the Box:
ECHOMAP Ultra 102sv
GT56UHD-TM transducer
Power/data cable
Bail mount with quick-release cradle
Protective sun cover
Hardware
Documentation
SpecificationsGeneral:
Dimension: 11.6" x 7.7" x 3.9" (29.5 x 19.5 x 9.8 cm)
Weight: 4.0 lbs (1.8 kg)
Waterproof: IPX7
Touchscreen: Yes
Display Type: WXGA, IPS
Display Size: 8.5" x 5.4"; 10" diagonal (21.7 x 13.6 cm; 25.4 cm diagonal)
Display Resolution: 1280 x 800 pixels
Mounting Options: Bail or flush
Input: Touchscreen with Keyed Assist
Maps & Memory:
Accepts Data Cards: 2 microSD cards
Waypoints: 5000
Track Points: 50,000
Tracks: 50 saved tracks
Navigation Routes: 100
Sensors:
GPS: Yes
GLONASS: Yes
Galileo: Yes
BeiDou: Yes
Has Built-In Receiver: Yes
Receiver: 10 Hz
NMEA 2000 Compatible: Yes
NMEA 0183 Compatible: Yes
Supports WAAS: Yes
Supports Multi-Band, Multi-Constellation GPS: Yes
Built-In Maps:
Built-In Auto Guidance+: Yes
Garmin Navionics+ Inland & Coastal: Yes (see Additional)
Tide Tables: Yes (see Additional)
Optional Map Support:
BlueChart g3: Yes
BlueChart g3 Vision: Yes
LakeVü g3: Yes
LakeVü g3 Ultra: Yes
Garmin Navionics+™: Yes
Garmin Navionics+ Vision+™: Yes
TOPO 100k: Yes
Standard Mapping: Yes
Garmin Quickdraw Contours: Yes
Chartplotter Features:
AIS: Yes
DSC: Yes
Supports Fusion-Link™ Compatible Radios: Yes
ActiveCaptain® Compatible: Yes
Sailing Features: Yes
Electrical Features:
Power Input: 9 to 18 VDC
Typical Current Draw at 12 VDC: 2.5 A
Maximum Current Draw at 12 VDC: 5.0 A
Maximum Power Usage at 10 VDC: 36 W
Sonar Features:
Displays Sonar: Yes
Power Output: 600 W
Traditional Sonar (Dual Frequency/Beam): Built-in (Single Channel Chirp, 70/83/200 Khz, L, M, H Chirp)
ClearVü: Built-in 260/455/800/1000/1200 kHz
SideVü: Built-in 260/455/800/1000/1200 kHz
Panoptix™ Sonar: Yes
Livescope: Yes
Connections:
NMEA 2000® Ports: 1
Garmin Marine Network Ports: 2 (Large Connector)
12-Pin Transducer Ports: 12-Pin Scanning Sonar
ANT+ (Connectivity): YesGarmin Wi-Fi Network (Local Connection): YesWARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100287901UPC Code: 753759325497
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Garmin
Garmin ECHOMAP Ultra 2 106sv US & Coastal Canada GN+ No Transducer #010-02880-00
$2,099.99
$2,353.89
Garmin 010-02880-00 FishfindersECHOMAP™ Ultra 2 106sv without Transducer - Garmin Navionics+With big, crisp, sunlight-readable touchscreen displays, these versatile chartplotters put a world of fish-finding capability at the angler's fingertips. This display has built-in Garmin Navionics+™ mapping.Features:
ECHOMAP™ Ultra 2 106sv with Garmin Navionics+ Inland & Coastal Mapping
10” touchscreen
Supports livescope™ sonar, and more
Wirelessly network; share sonar, waypoints, and routes.
Capture screen recordings to share fish catches
Multi-band GPS for improved position accuracy
Livescope™ Sonar SupportThe ECHOMAP Ultra 2 series supports the full lineup of LiveScope live-scanning sonar products (transducers sold separately).Built-in UHD SonarSelect models are bundled with a GT56 transducer, which provides Garmin CHIRP traditional sonar and Ultra High-Definition ClearVü™ and SideVü™ scanning sonars for photo-like images of what’s beneath the surface.Vivid Color PalettesHigh-contrast, vivid scanning sonar color palettes make it easier than ever to distinguish targets and structures.Preloaded ChartsExperience unparalleled coverage and detail. with built-in Garmin Navionics+ mapping, which includes a 1-year subscription for daily updates, depth range shading, and more.Premium Map UpgradesBring a fresh new look and feel to the chartplotter with optional Garmin Navionics Vision+™ premium mapping (sold separately), featuring high-resolution relief shading, satellite imagery, and more.Wireless NetworkingIf users have another compatible ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotter on the boat, users can wirelessly share information — such as sonar, waypoints, and routes — with them.Stay Connected Multi-Band GPSGet improved position accuracy with multi-band GPSNMEA 2000® Network CompatibilityConnect to heading sensors, autopilots, Fusion-Link™ audio systems, and more.ActiveCaptain® AppPair with the free smart-device app for software updates, screen recording, Garmin Quickdraw™ Community data, and more.Force® Trolling MotorWirelessly connect to a Force trolling motor to navigate to waypoints, draw and follow routes, and more.Take It With YouThe quick-disconnect bail mount lets users quickly install and remove the unit.In the Box:
ECHOMAP Ultra 106sv with optional Garmin Navionics+
Power/data cable
Bail mount with quick-release cradle
Protective sun cover
8-pin transducer to 12-pin sounder adapter cable
Hardware
Documentation
SpecificationsGeneral:
Dimension: 11.6" x 7.7" x 3.9" (29.5 x 19.5 x 9.8 cm)
Weight: 4.0 lbs (1.8 kg)
Waterproof: IPX7
Touchscreen: Yes
Display Type: WXGA, IPS
Display Size: 8.5" x 5.4"; 10" diagonal (21.7 x 13.6 cm; 25.4 cm diagonal)
Display Resolution: 1280 x 800 pixels
Mounting Options: Bail or flush
Input: Touchscreen with Keyed Assist
Maps & Memory:
Accepts Data Cards: 2 microSD cards
Waypoints: 5000
Track Points: 50,000
Tracks: 50 saved tracks
Navigation Routes: 100
Sensors:
GPS: Yes
GLONASS: Yes
Galileo: Yes
BeiDou: Yes
Has Built-In Receiver: Yes
Receiver: 10 Hz
NMEA 2000 Compatible: Yes
NMEA 0183 Compatible: Yes
Supports WAAS: Yes
Supports Multi-Band, Multi-Constellation GPS: Yes
Built-In Maps:
Built-In Auto Guidance+: Yes
Garmin Navionics+ Inland & Coastal: Yes (see Additional)
Tide Tables: Yes (see Additional)
Optional Map Support:
Garmin Navionics+™: Yes
Garmin Navionics+ Vision+™: Yes
TOPO 100k: Yes
Standard Mapping: Yes
Garmin Quickdraw Contours: Yes
Chartplotter Features:
AIS: Yes
DSC: Yes
Supports Fusion-Link™ Compatible Radios: Yes
ActiveCaptain® Compatible: Yes
Sailing Features: Yes
Electrical Features:
Power Input: 9 to 18 VDC
Typical Current Draw at 12 VDC: 2.5 A
Maximum Current Draw at 12 VDC: 5.0 A
Maximum Power Usage at 10 VDC: 36 W
Sonar Features:
Displays Sonar: Yes
Power Output: 600 W
Traditional Sonar (Dual Frequency/Beam): Built-in (Single Channel Chirp, 70/83/200 Khz, L, M, H Chirp)
ClearVü: Built-in 260/455/800/1000/1200 kHz
SideVü: Built-in 260/455/800/1000/1200 kHz
Panoptix™ Sonar: Yes
Livescope: Yes
Connections:
NMEA 2000® Ports: 1
Garmin Marine Network Ports: 2 (Large Connector)
12-Pin Transducer Ports: 12-Pin Scanning Sonar
ANT+ (Connectivity): Yes
Garmin Wi-Fi Network (Local Connection): Yes
WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100288000UPC Code: 753759325510
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Garmin
Garmin ECHOMAP Ultra 2 102sv Worldwide Basemap No Transducer #010-02879-00
$2,099.99
$2,353.89
Garmin 010-02879-00 FishfindersECHOMAP™ Ultra 2 102sv without TransducerWith big, crisp, sunlight-readable touchscreen displays, these versatile chartplotters put a world of fish-finding capability at the angler's fingertips. Features:
ECHOMAP™ Ultra 2 102sv with Worldwide Basemap
10” touchscreen
Supports livescope™ sonar, and more
Wirelessly network; share sonar, waypoints, and routes.
Capture screen recordings to share fish catches
Multi-band GPS for improved position accuracy
Livescope™ Sonar SupportThe ECHOMAP Ultra 2 series supports the full lineup of LiveScope live-scanning sonar products (transducers sold separately).Built-in UHD SonarSelect models are bundled with a GT56 transducer, which provides Garmin CHIRP traditional sonar and Ultra High-Definition ClearVü™ and SideVü™ scanning sonars for photo-like images of what’s beneath the surface.Vivid Color PalettesHigh-contrast, vivid scanning sonar color palettes make it easier than ever to distinguish targets and structures.Premium Map UpgradesBring a fresh new look and feel to the chartplotter with optional Garmin Navionics Vision+™ premium mapping (sold separately), featuring high-resolution relief shading, satellite imagery, and more.Wireless NetworkingIf users have another compatible ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotter on the boat, users can wirelessly share information — such as sonar, waypoints, and routes — with them.Stay Connected Multi-Band GPSGet improved position accuracy with multi-band GPSNMEA 2000® Network CompatibilityConnect to heading sensors, autopilots, Fusion-Link™ audio systems, and more.ActiveCaptain® AppPair with the free smart-device app for software updates, screen recording, Garmin Quickdraw™ Community data, and more.Force® Trolling MotorWirelessly connect to a Force trolling motor to navigate to waypoints, draw and follow routes, and more.Take It With YouThe quick-disconnect bail mount lets users quickly install and remove the unit.In the Box:
ECHOMAP Ultra 102sv
Power/data cable
Bail mount with quick-release cradle
Protective sun cover
8-pin transducer to 12-pin sounder adapter cable
Hardware
Documentation
SpecificationsGeneral:
Dimension: 11.6" x 7.7" x 3.9" (29.5 x 19.5 x 9.8 cm)
Weight: 4.0 lbs (1.8 kg)
Waterproof: IPX7
Touchscreen: Yes
Display Type: WXGA, IPS
Display Size: 8.5" x 5.4"; 10" diagonal (21.7 x 13.6 cm; 25.4 cm diagonal)
Display Resolution: 1280 x 800 pixels
Mounting Options: Bail or flush
Input: Touchscreen with Keyed Assist
Maps & Memory:
Accepts Data Cards: 2 microSD cards
Waypoints: 5000
Track Points: 50,000
Tracks: 50 saved tracks
Navigation Routes: 100
Sensors:
GPS: Yes
GLONASS: Yes
Galileo: Yes
BeiDou: Yes
Has Built-In Receiver: Yes
Receiver: 10 Hz
NMEA 2000 Compatible: Yes
NMEA 0183 Compatible: Yes
Supports WAAS: Yes
Supports Multi-Band, Multi-Constellation GPS: Yes
Built-In Maps:
Built-In Auto Guidance+: Yes
Garmin Navionics+ Inland & Coastal: Yes (see Additional)
Tide Tables: Yes (see Additional)
Optional Map Support:
BlueChart g3: Yes
BlueChart g3 Vision: Yes
LakeVü g3: Yes
LakeVü g3 Ultra: Yes
Garmin Navionics+™: Yes
Garmin Navionics+ Vision+™: Yes
TOPO 100k: Yes
Standard Mapping: Yes
Garmin Quickdraw Contours: Yes
Chartplotter Features:
AIS: Yes
DSC: Yes
Supports Fusion-Link™ Compatible Radios: Yes
ActiveCaptain® Compatible: Yes
Sailing Features: Yes
Electrical Features:
Power Input: 9 to 18 VDC
Typical Current Draw at 12 VDC: 2.5 A
Maximum Current Draw at 12 VDC: 5.0 A
Maximum Power Usage at 10 VDC: 36 W
Sonar Features:
Displays Sonar: Yes
Power Output: 600 W
Traditional Sonar (Dual Frequency/Beam): Built-in (Single Channel Chirp, 70/83/200 Khz, L, M, H Chirp)
ClearVü: Built-in 260/455/800/1000/1200 kHz
SideVü: Built-in 260/455/800/1000/1200 kHz
Panoptix™ Sonar: Yes
Livescope: Yes
Connections:
NMEA 2000® Ports: 1
Garmin Marine Network Ports: 2 (Large Connector)
12-Pin Transducer Ports: 12-Pin Scanning Sonar
ANT+ (Connectivity): Yes
Garmin Wi-Fi Network (Local Connection): Yes
WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100287900UPC Code: 753759325480
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Humminbird
Humminbird Helix 12 Chirp Mega Si+GPS G4N #411970-1CHO
$2,657.91
$2,998.13
Humminbird 411970-1CHO FishfindersHELIX 12 CHIRP MEGA MSI+ GPS G4N CHOThe HELIX 12 CHIRP MSI+ GPS G4N CHO features a 12.1" display, MEGA Side Imaging+, MEGA Down Imaging+, Dual Spectrum CHIRP Sonar, and internal GPS with Humminbird Basemap. As with all HELIX G4N models, this HELIX 12 includes standard features such as AutoChart Live, Wi-Fi, and NMEA 2000®, in addition to Bluetooth® and Ethernet networking for compatibility with the One-Boat Network™ family of products from Humminbird, Minn Kota, and Cannon.This CHO (Control Head Only) model allows users to pick the right accessory transducer for almost any need, including compatibility with Minn Kota built-in MEGA Imaging trolling motors.FeaturesControl Head Only ModelThis model does not include a transducer. This CHO model is a great choice for those looking to connect to built-in MEGA Imaging on Minn Kota trolling motors, accessory transducer options like MEGA 360 Imaging, or share sonar data from an existing Humminbird Ethernet network.Keypad ControlMaster HELIX at the touch of a button. Access the preloaded views from the user-friendly menu system, operated by soft-key controls that allow users to reliably operate the fish finder in any conditions.MEGA Side Imaging+See the world below like never before with a crystal-clear side imaging view out to 200 feet on either side of the boat. Users will unlock more fish and structures with 20% more detail and 60% more range capability than MEGA Side Imaging sonar.MEGA Down Imaging+Get unprecedented underwater clarity with Down Imaging coverage down to 200 feet below the boat. Users will unlock more fish and structures with 20% more detail and 60% more depth capability than MEGA Down Imaging sonar.Dual Spectrum CHIRP SonarBefore users cast, know what's down there thanks to highly-detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by Humminbird's proprietary Low-Q CHIRP transducer, the Dual Spectrum offers two ways to search: wide mode for maximum coverage and narrow mode for focusing on the slightest detail.Internal GPS and Humminbird BasemapHumminbird's enhanced basemap provides users with a clear view of underwater terrain and surrounding points of interest, so users can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.Premium Chart CompatibleHumminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as compatible Navionics® charts.AutoChart LiveCreate real-time maps of the fishing spots with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as users drive the boat. It comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually unlimited AutoChart Live mapping capacity.One-Boat Network CompatibleMany Humminbird models seamlessly integrate and communicate with Minn Kota and Cannon products to unlock more features and capabilities for anglers everywhere. Users can take advantage of the time on the water by using the exclusive boat control and fish-catching features of the One-Boat Network.Ethernet NetworkingHigh-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar.BluetoothTake control right from the screen of a Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird FishSmart App and the display of smartphone notifications on the Humminbird.NMEA 2000 Networking Built-inConnect an accessory NMEA 2000 network to a control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking.Includes:Includes control head, screen cover, power cable, gimbal mounting bracket, and mounting hardware. This CHO model does not include a transducer, allowing you to pick the best fit for your rigging needs.Specifications:
Series: HELIX
Display Size – Diagonal: 12.1 in
Display Pixel Matrix: 1280H x 800V
Sonar-Standard: Dual Spectrum CHIRP / MEGA Down Imaging+ / MEGA Side Imaging+
Sonar-Coverage: 20°, 42°, 60°, (2) 86° & (2) 55° @ -10dB
Sonar-Optional: 50 kHz, 50/Low Airmar CHIRP
Live Sonar Coverage: 20 degrees x 120 degrees
CHIRP - Frequencies Supported: Full Mode (150-220 kHz) / Narrow Mode (180-240 kHz) / Wide Mode (140-200 kHz)
Sonar-Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz
Depth-Sonar: 1,200 ft (standard transducer) / 3,500 ft (optional 50 kHz)
CHIRP - Imaging-Frequencies Supported: 455 kHz DI+ (435-535 kHz) / 455 kHz SI+ (405-505 kHz) / 800 kHz DI+ (800-860 kHz) / 800 kHz SI+ (780-840 kHz) / MEGA DI+ (1100-1200 kHz) / MEGA SI+ (1050-1175 kHz)
Depth-Down Imaging: 125 ft (800 kHz) / 200 ft (MEGA) / 400 ft (455 kHz)
Range-Side Imaging (Side-To-Side): 800 ft (455 kHz) / 250 ft (800 kHz) / 400 ft (MEGA)
Memory Card Slot: Dual SD
Compatible With: AIS / AutoPilot/ Minn Kota US2 Sonar / Minn Kota Built-In MEGA DI/ Minn Kota Built-In MEGA SI / MEGA Live / One-Boat Network / Minn Kota i-Pilot Link / Minn Kota Talon/Raptor / NMEA 2000
Power Draw: 3.2 Amps
Power Input: 10.8-20 VDC
Power Output Peak-to-Peak: 8000 Watts
Power Output RMS: 1000 Watts
Screen Snap Shot: Included
Sonar Recording: Included
Mount-Standard: Gimbal
Mount-Standard Size: 14.86 in W x 8.83 in H x 4.25 in D
Mount-Optional: In-Dash Mounting Kit
Mount-Optional Size: 14.86 in W x 8.52 in H x 1.36 in D
Transducer Mount Location: N/A
GPS Chartplotting: Included
GPS Receiver: Internal
GPS Trackplotting: Included
Waypoints, Routes, Tracks/Points: 2,750, 47, 50/20,000
360 Imaging Compatibility: Yes
LakeMaster Compatibility: Yes
Coast Master Compatibility: Yes
Navionics Gold/HotMaps Compatibility: Yes
Navionics Platinum + Compatibility: Yes
Platinum Compatibility: Yes
Minn Kota i-Pilot Link Compatibility: Yes
Minn Kota Talon Shallow Water Anchor Compatibility: Yes
Radar Compatibility: Yes
5-Port Ethernet Switch Compatibility: Yes
AIS Compatibility: Optional
Autopilot Compatibility: Yes
Heading Sensor GPS Compatibility: Yes
NMEA2000: Included
Target Separation: 2.5 in
Interference Rejection: 6 Modes
Noise Rejection: 10 Steps
Upgradable Software: Yes
View Preset Keys: Yes
X-Press Menu System: Yes
Custom Digital Readout: Yes
Custom View Selections: Yes
Display Colors Grayscale: 16-Bit
Display Type: Color TFT
Speed: Included
Temperature: Built In
Temperature Alarm: Yes
Temperature Graph: Yes
Transducer Included: N/A
HDMI Compatible: No
MEGA Live Compatibility: Yes
Humminbird Basemap: Included
Warranty: Two-Year Warranty
Normalized SKU: 4119701CHOUPC Code: 082324058264
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Humminbird
Humminbird Helix 12 Chirp Mega Si+GPS G4N #411970-1
$2,738.69
$3,089.24
Humminbird 411970-1 FishfindersHELIX 12 CHIRP MEGA MSI+ GPS G4NThe HELIX 12 CHIRP MSI+ GPS G4N features a 12.1" display, MEGA Side Imaging+, MEGA Down Imaging+, Dual Spectrum CHIRP Sonar, and internal GPS with Humminbird Basemap. As with all HELIX G4N models, this HELIX 12 includes standard features such as AutoChart Live, Wi-Fi, and NMEA 2000®, in addition to Bluetooth® and Ethernet networking for compatibility with the One-Boat Network™ family of products from Humminbird, Minn Kota, and Cannon.FeaturesKeypad ControlMaster HELIX at the touch of a button. Access the preloaded views from the user-friendly menu system, operated by soft-key controls that allow users to reliably operate the fish finder in any conditions.MEGA Side Imaging+See the world below like never before with a crystal-clear side imaging view out to 200 feet on either side of the boat. Users will unlock more fish and structures with 20% more detail and 60% more range capability than MEGA Side Imaging sonar.MEGA Down Imaging+Get unprecedented underwater clarity with Down Imaging coverage down to 200 feet below the boat. Users will unlock more fish and structures with 20% more detail and 60% more depth capability than MEGA Down Imaging sonar.Dual Spectrum CHIRP SonarBefore users cast, know what's down there thanks to highly-detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by Humminbird's proprietary Low-Q CHIRP transducer, the Dual Spectrum offers two ways to search: wide mode for maximum coverage and narrow mode for focusing on the slightest detail.Internal GPS and Humminbird BasemapHumminbird's enhanced basemap provides users with a clear view of underwater terrain and surrounding points of interest, so users can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.Premium Chart CompatibleHumminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as compatible Navionics® charts.AutoChart LiveCreate real-time maps of the fishing spots with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as users drive the boat. It comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually unlimited AutoChart Live mapping capacity.One-Boat Network CompatibleMany Humminbird models seamlessly integrate and communicate with Minn Kota and Cannon products to unlock more features and capabilities for anglers everywhere. Users can take advantage of the time on the water by using the exclusive boat control and fish-catching features of the One-Boat Network.Ethernet NetworkingHigh-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar.BluetoothTake control right from the screen of a Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird FishSmart App and the display of smartphone notifications on the Humminbird.NMEA 2000 Networking Built-inConnect an accessory NMEA 2000 network to a control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking.Includes:Includes control head, screen cover, transom-mount transducer, power cable, gimbal mounting bracket, and mounting hardware.Specifications:
Series: HELIX
Display Size – Diagonal: 12.1 in
Display Pixel Matrix: 1280H x 800V
Sonar-Standard: Dual Spectrum CHIRP / MEGA Down Imaging+ / MEGA Side Imaging+
Sonar-Coverage: 20°, 42°, 60°, (2) 86° & (2) 55° @ -10dB
Sonar-Optional: 50 kHz, 50/Low Airmar CHIRP
Live Sonar Coverage: 20 degrees x 120 degrees
CHIRP - Frequencies Supported: Full Mode (150-220 kHz) / Narrow Mode (180-240 kHz) / Wide Mode (140-200 kHz)
Sonar-Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz
Depth-Sonar: 1,200 ft (standard transducer) / 3,500 ft (optional 50 kHz)
CHIRP - Imaging-Frequencies Supported: 455 kHz DI+ (435-535 kHz) / 455 kHz SI+ (405-505 kHz) / 800 kHz DI+ (800-860 kHz) / 800 kHz SI+ (780-840 kHz) / MEGA DI+ (1100-1200 kHz) / MEGA SI+ (1050-1175 kHz)
Depth-Down Imaging: 125 ft (800 kHz) / 200 ft (MEGA) / 400 ft (455 kHz)
Range-Side Imaging (Side-To-Side): 800 ft (455 kHz) / 250 ft (800 kHz) / 400 ft (MEGA)
Memory Card Slot: Dual SD
Compatible With: AIS / AutoPilot / Minn Kota US2 Sonar / Minn Kota Built-In MEGA DI / Minn Kota Built-In MEGA SI / MEGA Live / One-Boat Network / Minn Kota i-Pilot Link / Minn Kota Talon/Raptor/ NMEA 2000
Power Draw; 3.2 Amps
Power Input: 10.8-20 VDC
Power Output Peak-to-Peak; 8000 Watts
Power Output RMS: 1000 Watts
Screen Snap Shot: Included
Sonar Recording: Included
Mount-Standard: Gimbal
Mount-Standard Size: 14.86 in W x 8.83 in H x 4.25 in D
Mount-Optional: In-Dash Mounting Kit
Mount-Optional Size: 14.86 in W x 8.52 in H x 1.36 in D
Transducer Mount Location: Transom
GPS Chartplotting: Included
GPS Receiver: Internal
GPS Trackplotting: Included
Waypoints, Routes, Tracks/Points: 2,750, 47, 50/20,000
360 Imaging Compatibility: Yes
LakeMaster Compatibility: Yes
Coast Master Compatibility: Yes
Navionics Gold/HotMaps Compatibility: Yes
Navionics Platinum + Compatibility: Yes
Platinum Compatibility: Yes
Minn Kota i-Pilot Link Compatibility: Yes
Minn Kota Talon Shallow Water Anchor Compatibility: Yes
Radar Compatibility: Yes
5-Port Ethernet Switch Compatibility: Yes
AIS Compatibility: Optional
Autopilot Compatibility: Yes
Heading Sensor GPS Compatibility: Yes
NMEA2000: Included
Target Separation: 2.5 in
Interference Rejection: 6 Modes
Noise Rejection: 10 Steps
Upgradable Software: Yes
View Preset Keys: Yes
X-Press Menu System: Yes
Custom Digital Readout: Yes
Custom View Selections: Yes
Display Colors Grayscale: 16-Bit
Display Type: Color TFT
Speed: Included
Temperature: Built In
Temperature Alarm: Yes
Temperature Graph: Yes
Transducer Included: XM 9 HW MSI T
HDMI Compatible: No
MEGA Live Compatibility: Yes
Humminbird Basemap: Included
Warranty: Two-Year Warranty
Normalized SKU: 4119701UPC Code: 082324058257
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Humminbird
Humminbird Helix 10 Chirp Mega Si+GPS G4N #411960-1CHO
$1,799.99
$1,949.55
Humminbird 411960-1CHO FishfindersHELIX 10 CHIRP MEGA MSI+ GPS G4N CHOThe HELIX 10 CHIRP MSI+ GPS G4N CHO features a 10.1" display, MEGA Side Imaging+, MEGA Down Imaging+, Dual Spectrum CHIRP Sonar, and internal GPS with Humminbird Basemap. As with all HELIX G4N models, this HELIX 10 includes standard features such as AutoChart Live, Wi-Fi and NMEA 2000®, in addition to Bluetooth® and Ethernet networking for compatibility with the One-Boat Network™ family of products from Humminbird, Minn Kota, and Cannon.This CHO (Control Head Only) model allows users to pick the right accessory transducer for almost any need, including compatibility with Minn Kota Built-in MEGA Imaging trolling motors.FeaturesControl Head Only ModelThis model does not include a transducer. This CHO model is a great choice for those looking to connect to built-in MEGA Imaging on Minn Kota trolling motors, accessory transducer options like MEGA 360 Imaging, or share sonar data from an existing Humminbird Ethernet network.Keypad ControlMaster HELIX at the touch of a button. Access the preloaded views from the user-friendly menu system, operated by soft-key controls that allow users to reliably operate the fish finder in any conditions.MEGA Side Imaging+See the world below like never before with a crystal-clear side imaging view out to 200 feet on either side of the boat. Users will unlock more fish and structures with 20% more detail and 60% more range capability than MEGA Side Imaging sonar.MEGA Down Imaging+Get unprecedented underwater clarity with Down Imaging coverage down to 200 feet below the boat. Users will unlock more fish and structures with 20% more detail and 60% more depth capability than MEGA Down Imaging sonar.Dual Spectrum CHIRP SonarBefore users cast, know what's down there thanks to highly-detailed fish arches and a clear view of the fish-holding structure and the bottom. Powered by Humminbird's proprietary Low-Q CHIRP transducer, the Dual Spectrum offers two ways to search: wide mode for maximum coverage and narrow mode for focusing on the slightest detail.Internal GPS and Humminbird BasemapHumminbird's enhanced basemap provides users with a clear view of underwater terrain and surrounding points of interest, so users can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.Premium Chart CompatibleHumminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as compatible Navionics® charts.AutoChart LiveCreate real-time maps of the fishing spots with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness, and vegetation as users drive the boat. It comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually unlimited AutoChart Live mapping capacity.One-Boat Network CompatibleMany Humminbird models seamlessly integrate and communicate with Minn Kota and Cannon products to unlock more features and capabilities for anglers everywhere. Users can take advantage of the time on the water by using the exclusive boat control and fish-catching features of the One-Boat Network.Ethernet NetworkingHigh-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar.BluetoothTake control right from the screen of a Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird FishSmart App and the display of smartphone notifications on the Humminbird.NMEA 2000 Networking Built-inConnect an accessory NMEA 2000 network to a control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking.Includes:Includes control head, screen cover, power cable, gimbal mounting bracket, and mounting hardware. This CHO model does not include a transducer, allowing users to pick the best fit for their rigging needs.Specifications:
Series: HELIX
Display Size – Diagonal: 10.1 in
Display Pixel Matrix: 1024H x 600V
Sonar-Standard: Dual Spectrum CHIRP / MEGA Down Imaging+ / MEGA Side Imaging+
Sonar-Coverage: 20°, 42°, 60°, (2) 86° & (2) 55° @ -10dB
Sonar-Optional: 50 kHz, 50/Low Airmar CHIRP
Live Sonar Coverage: 20 degrees x 120 degrees
CHIRP - Frequencies Supported: Full Mode (150-220 kHz) / Narrow Mode (180-240 kHz) / Wide Mode (140-200 kHz)
Sonar-Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz
Depth-Sonar: 1,200 ft (standard transducer) / 3,500 ft (optional 50 kHz)
CHIRP - Imaging-Frequencies Supported: 455 kHz DI+ (435-535 kHz) / 455 kHz SI+ (405-505 kHz) / 800 kHz DI+ (800-860 kHz) / 800 kHz SI+ (780-840 kHz) / MEGA DI+ (1100-1200 kHz) / MEGA SI+ (1050-1175 kHz)
Depth-Down Imaging: 125 ft (800 kHz) / 200 ft (MEGA) / 400 ft (455 kHz)
Range-Side Imaging (Side-To-Side): 800 ft (455 kHz) / 250 ft (800 kHz) / 400 ft (MEGA)
Memory Card Slot: Dual SD
Compatible With: AIS / AutoPilot / Minn Kota US2 Sonar / Minn Kota Built-In MEGA DI / Minn Kota Built-In MEGA SI / MEGA Live / One-Boat Network / Minn Kota i-Pilot Link / Minn Kota Talon/Raptor / NMEA 2000
Power Draw: 2.7 Amps
Power Input: 10.8-20 VDC
Power Output Peak-to-Peak: 8000 Watts
Power Output RMS: 1000 Watts
Screen Snap Shot: Included
Sonar Recording: Included
Mount-Standard: Gimbal
Mount-Standard Size: 13.44 in W x 7.5 in H x 4.2 in D
Mount-Optional: In-Dash Mounting Kit
Mount-Optional Size: 13.44 in W x 7.12 in H x 1.32 in D
Transducer Mount Location: N/A
GPS Chartplotting: Included
GPS Receiver: Internal
GPS Trackplotting: Included
Waypoints, Routes, Tracks/Points: 2,750, 47, 50/20,000
360 Imaging Compatibility: Yes
LakeMaster Compatibility: Yes
Coast Master Compatibility: Yes
Navionics Gold/HotMaps Compatibility: Yes
Navionics Platinum + Compatibility: Yes
Platinum Compatibility: Yes
Minn Kota i-Pilot Link Compatibility: Yes
Minn Kota Talon Shallow Water Anchor Compatibility: Yes
Radar Compatibility: Yes
5-Port Ethernet Switch Compatibility: Yes
AIS Compatibility: Optional
Autopilot Compatibility: Yes
Heading Sensor GPS Compatibility: Yes
NMEA2000: Included
Target Separation: 2.5 in
Interference Rejection: 6 Modes
Noise Rejection: 10 Steps
Upgradable Software: Yes
View Preset Keys: Yes
X-Press Menu System: Yes
Custom Digital Readout: Yes
Custom View Selections: Yes
Display Colors Grayscale: 16-Bit
Display Type: Color TFT
Speed: Included
Temperature: Built In
Temperature Alarm: Yes
Temperature Graph: Yes
Transducer Included: N/A
HDMI Compatible: No
MEGA Live Compatibility: Yes
Humminbird Basemap: Included
Warranty: Two-Year Warranty
Normalized SKU: 4119601CHOUPC Code: 082324058233
Frequently Asked Questions
First Choice Marine is an online marine retailer carrying a diverse line of marine parts and accessories and related items from industry-respected and demanded manufacturers and suppliers. Through our diverse distributor network, we are able to access over 150,000 items, including our current site inventory, new products being added, and special order items. If you need it on your boat... we are your one-stop shop!
Yes, we offer FREE Shipping on most orders over $149 to US-48*.
Each product displays a shipping status message, just above the item price. Below is the meaning for each of these codes.
- Qualifies for Free Shipping: This item qualifies for free shipping when the order is $149+
- Qualifies for Free Ground Shipping: This item qualifies for free ground shipping when the order is $149+.
- Oversized - Not Qualified for Free Shipping: This item is too large/heavy to qualify for free shipping
- Hazardous Item - Not Qualified for Free Shipping: This item is hazardous and does not qualify for free shipping
- Truck Freight - Not Qualified for Free Shipping: This item has to be shipped via truck freight. Please contact us for a quote
- In-Store Pickup Only: This item can only be picked up in our Grain Valley, MO retail store
Below the price of the item, on the product page, there is a message indicating the availability of the product.
The quantity on hand is updated as inventory events happen and matches what we have available. If you have urgent needs and we are close to what you need, contact us, and we can confirm stock.
We offer a hassle-free return policy. If you're not completely satisfied with your purchase, you can return it within 30 days for a full refund or exchange.
If you need to return an item, please follow the guidelines here so we can process a prompt refund and assist you in finding the correct item.
Free Shipping
On most orders $149+ to the continental 48 US states.Secure Shopping
Fast, secure checkout with a variety of payment methods.Shop with confidence
25+ years serving the marine industry.Support center
Need help? Contact us via live chat, phone, or email.
