EGIS 8710-1900 Battery SwitchEGIS 8710-1900 500A Battery Switch/Mechanical ContactorModel: 8710-1900 HIGH VISIBILTY KNOB Force each individual relay Open or Closed and optionally leave knob in either position to lock relay in either condition. 40 CIRCUIT LABEL SHEET INCLUDED Convenient recesses for included weatherproof label set makes circuit and relay identification easy. Blank labels for custom applications. PROTECTIVE COVER INCLUDED Protects terminal studs and cable terminal edges from inadvertent shorts to each other or ground. STAINLESS HARDWARE Corrosion is no issue with quality stainless steel studs and self locking flanged nuts. SMALLER FOOTPRINT XD Relays offers high Amp rating in a smaller package than competitive solutions, reducing install space requirements to a minimum. INTEGRATED VENT High quality Gortex vent regulates internal device pressure to eliminate moisture entry across seals and ensure long product life in harsh environments. Bullet-proof Construction: Sealed to IP67/IP6K9K, high temperature electronics and materials allow mounting anywhere. Stainless steel cable lug studs. Large mounting holes accept 1/4-20 / M6 attachment hardware.Intuitive Manual Control: Bright yellow knob and intuitive easy to read on/off label simplifies operation and awareness of state of manual override and whether the device is being left in a locked off or locked on state.Ignition Protected: Safe for install in gasoline powered boats and other combustible install environments.Sealed IP67 Construction keeps moisture out and the integrated Gore Tex pressure regulation vent increases its ability to operate reliably for long term harsh environment operation.Compact Case Design allows for easy surface mount or rear panel installs and rectangular shape (narrower than competing products) keeps finding a mounting location easy.Specifications MAX CONTINUOUS CURRENT (AMPS) 500 MAX CRANKING CURRENT (AMPS) 1500 TERMINAL STUD SIZE (MM) M10 VOLTAGE RANGE (VDC) 8 - 36 INGRESS PROTECTION IP67/IP6K9K CONTACT MATERIALS SILVER ALLOY Normalized SKU: 87101900UPC Code: 850035199794

EGIS 8710-1500 Battery SwitchEGIS XD Single - Remote Battery Switch w/Knob - Tinned Wires, Bulk PackModel: 8710-1500 Bullet-proof Construction: Sealed to IP67/IP6K9K, high temperature electronics and materials allow mounting anywhere. Stainless steel cable lug studs. Large mounting holes accept 1/4-20 / M6 attachment hardware. Intuitive Manual Control option simplifies operation and awareness of state of manual override and whether the device is being left in a locked off or locked on state (not available on competitive solutions) Simple Programmability via simple dip switches allows each individual relay function significant flexibility for OEMs and installers. Plug & Play Compatible with Legacy Competitor Products: Single, dual and triple relays options available with DTM/ATM connectors pin for pin compatible with ML Series Bi-stable Relays. 90-95% Less Off-State Current: Compared to competitive products and system solutions that require multiple devices for similar functionality Specifications total continous current (amps) 500 Max cranking current (amps) 1500 Mechanical switching life 1,000,000 cycles Voltage range 8-36vDC Off-state current draw 1.3mA State change current 5A @ 12vDC3A @ 24vDC Normalized SKU: 87101500UPC Code: 850035199992

Download LiteratureCommodore CM-402S Battery Switch4-Position Compact Dual Battery Selector SwitchThe 4-Position Battery Selector Switch is the ultimate solution for managing multiple battery banks in marine or RV electrical systems. Designed for 12V to 32V applications, this switch allows you to isolate battery banks, combine them, or direct power to all loads with a simple turn. Engineered with tin-plated copper studs, the switch ensures maximum conductivity and corrosion resistance for reliable long-term performance in harsh environments.This heavy-duty switch is IP66-rated for water resistance and features an ignition-protected design, meeting ISO 8846 and ABYC safety standards. The isolating cover with three snap-off side pieces protects rear contacts while allowing versatile wire access in any direction. With its robust one-piece terminal stud design and user-friendly operation, this battery switch is ideal for boats, RVs, and other off-grid applications requiring efficient power management.Features: Switches Between 4 Positions: Allows flexible power management by isolating battery banks, combining them, or directing power to all loads for maximum versatility. Tin-plated copper Studs: Provides exceptional conductivity and corrosion resistance, ensuring efficient operation in harsh marine or RV environments. Durable One-Piece Terminal Stud Design: Prevents loosening over time, ensuring a secure connection and stable performance for extended use. Isolating Cover with Snap-Off Sides: Protects rear contacts while allowing easy wire access from any direction, making installation quick and hassle-free. IP66 Water-Resistant Rating: Built to withstand powerful water jets, making it perfect for marine applications or environments exposed to moisture and dust. Meets Strict Safety Standards: Certified to ISO 8846 Marine Ignition Protection, ABYC, UL 1500, and SAE J1171, ensuring compliance with industry-leading safety requirements. Compact and Lightweight Design: Weighing just 0.83 lbs (0.38 kg), this switch is compact yet robust, saving space while delivering maximum performance. High Current Handling Capability: Rated for 300A continuous and 900A cranking, this switch is ideal for high-power applications like engine start and onboard systems. Specifications: Maximum Voltage: 32 VDC Switch Type: Selector 4-Position Battery Inputs: 1 Color: Red Cable Clearance for 4/0 AWG Cables: 1.12 in (28.45 mm) Cable Size to Meet Ratings: 4/0 AWG (120mm2) Switch Positions: 4 Battery Combine: Yes Alternator Field Disconnect: No Cranking Rating 30 seconds: 900A Continuous Rating: 300A Intermittent Rating: 500A (5 min) Mounting Holes: Accept #10 Screw Stud Material: Tinned Copper Stud Torque: 120 in-lb (13.56 Nm) Terminal Stud Size: 3/8" - 16 (M10) Weight: 0.77 lbs (0.35 kg) Normalized SKU: CM402SUPC Code: 817683023161Commodore CM-402S Literature Download Quick Reference Guide

Download LiteratureCommodore CM-202S Battery SwitchOn/Off Battery Disconnect SwitchThe Commodore On/Off Battery Disconnect Switch provides a reliable, durable, and safe solution for managing your marine or RV electrical systems. With a 300A continuous rating and a 900A cranking rating, this battery switch is designed to handle high-power applications, ensuring stable operation for your boat, RV, or off-grid systems. Its tin-plated copper studs offer superior conductivity and corrosion resistance, while the IP66-rated isolating cover provides robust protection against water and debris.This versatile switch can be surface-mounted or flush-mounted, with snap-off side pieces allowing wiring access from any direction. Designed to meet stringent marine safety standards, including ISO 8846 Marine Ignition Protection, this switch is a must-have for any professional or DIY marine electrical system. Built for durability and reliability, the CM-202S ensures your system stays safe and operational in even the harshest conditions.Features: High-Performance Ratings: Handles 300A continuous, 500A intermittent, and 900A cranking current, ensuring dependable performance for high-power marine or RV systems. Durable Tin-Plated Copper Studs: Features corrosion-resistant copper studs for maximum conductivity and long-lasting performance in harsh environments. Versatile Mounting Options: These can be surface-mounted or flush-mounted with snap-off side plates, offering flexible installation and clean cable management. Water-Resistant and Ignition Protected: Certified to ISO 8846 Marine standards, IP66-rated for protection against water jets, and safe for use in engine compartments. Easy Wire Access: The isolating cover includes three snap-off side pieces, allowing wiring from any direction while protecting rear terminals for enhanced safety. Meets Industry Standards: Complies with ABYC C-7, UL 1107, CSA C22.2 No.4, and other stringent safety regulations, ensuring compatibility and reliability. Compact and Lightweight Design: Weighing only 0.83 lbs (0.38 kg), the compact design saves space without compromising durability or performance. Rugged Marine-Grade Construction: Built to withstand the harshest marine and off-grid environments, ensuring long-lasting protection and reliable operation. Specifications: Maximum Voltage: 48 VDC Switch Type: Single Circuit On-Off Battery Inputs: 1 Color: Grey Cable Clearance for 4/0 AWG Cables: 1.12 in (28.45 mm) Cable Size to Meet Ratings: 4/0 AWG (120mm2) Switch Positions: 2 Battery Combine: No Alternator Field Disconnect: No Cranking Rating 30 seconds: 900A Continuous Rating: 300A Intermittent Rating: 500A (5 min) Mounting Holes: Accept #10 Screw Stud Material: Tinned Copper Stud Torque: 120 in-lb (13.56 Nm) Terminal Stud Size: 3/8" - 16 (M10) Weight: 0.65 lbs (0.29 kg) Normalized SKU: CM202SUPC Code: 817683023154Commodore CM-202S Literature Download Quick Reference Guide

Blue Sea System 6011-B Battery Switch 6011m-Series (Mini) Battery SwitchDual Circuit Plus™  (BULK - no packaging) Switches two battery banks simultaneously with one simple ON/OFF switch while maintaining battery bank isolation, minimizing the risk of a dead Start battery The "Combine Batteries" function offers the ability to combine the two battery banks in the event of a low-start battery Features: Ignition-protected - Safe for installation aboard gasoline-powered boats Case design allows surface, front panel, or rear panel mounting Isolating cover with snap-on sections protects rear contacts 3/8"-16 tin-plated copper studs for maximum conductivity and corrosion resistance, accepts 3/8" and M10 ring terminals 7/8" (22.22mm) stud length to accept multiple cable terminals Ideal for marine or RV applications All non-corrosive marine-grade metals Molded in durable reinforced polycarbonate Tactile textures indicate knob position by feel only Label with international ON/OFF legends Removable key or knob remains positively retained ICON label set included for circuit identification WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 6011B

Sea-Dog 422737-3 Battery SwitchPower Box Battery SwitchThe Power Box is controlled with a 50A battery switch and monitored with an LED voltmeter. The switch features a removable knob for extra security. The power box includes two power sockets, two Anderson outputs, one USB-C port, and four USB-A ports.Features: Onboard internal fuse block, great for john boats and kayaks  Anderson battery plug with terminals and four #8 FH mounting fasteners included 12-24V. 50A Specifications: Length (inch): 6-1/4" Height (inch): 3-1/8"  Width (inch): 5-9/16"     Volts: 12-24 Total Output (Amps): 50A Weight: 1.70 lb. Color: Black box Normalized SKU: 4227373UPC Code: 035514433167

Blue Sea System 1494 Battery Switch1494 - 360 Panel - Add-A-BatteryPart of the Blue Sea Systems Battery Management Panels.  Allows easy management of the multiple battery banks.Features: Isolates the Start circuit from the House circuit Allows emergency cross-connect between isolated battery banks Protects electronics from sags and spikes caused by engine cranking Technical Specifications: Switch Type - M-Series battery switch Nominal Voltage - 12V Dimensions (H x W x D) - 7.75" x 4.88" x 3.25" (197 x 124 x 83mm) In the Box: 1494 Panel Instruction Manual *Sold as an Individual Normalized SKU: 1494

Sea-Dog 422761-1 Battery SwitchMachined Brass/Injection Molded NylonBattery disconnect and selector switches either switch a single battery to a single load group or isolates and/or combines two battery banks. Can be surface or rear panel mounted. Ignition protected. Safe for installation on gasoline powered boats. Constructed of injection molded nylon with machined brass contacts. Installs with four #10 RH fasteners (not included).This product replaces:422761, 422761-1, 3-422761Normalized SKU: 4227611UPC Code: 035514425414

BEP Marine 80-716-0031-00 Battery SwitchBEP Smart Battery Hub Triple EngineModel: 80-716-0031-00 Remotely operated magnetic latching switches Remotely operated emergency parallel switches Configurable dual direction voltage sensitive switches Battery Voltage Monitoring House battery State of Charge Monitoring 2 x additional sensor inputs Safety manual override for all battery switches 12 or 24 volt systems Parallel two units together for 4, 5 and even 6 engine installations BEP’s innovative Smart Battery Hub (SBH) is a world-first intelligent battery management system for vessels running two or more outboards, sterndrives, or multiple inboard engines. Smart Battery Hub simplifies battery management with remotely activated switches, automatic dual direction Voltage Sensitive Switching (VSS) and emergency parallel functionality, neatly housed in a robust, easy-to-install, ignition-protected IPX7 enclosure. VSS voltage thresholds can be configured to suit, or enabled/disabled with each installation. Switch inputs can be assigned to any function and two additional sensor inputs can be used for monitoring volts, fluid levels and temperature. SBH monitors and transmits individual battery voltages and full house bank state of charge over NMEA2000, for easy integration with multi-function displays. Remote battery switching is operated via NMEA2000 or wired switches, with physical manual override of all battery switches for safety and servicing.Specifications Power consumption max 92mA Power consumption sleep <3.5mA NMEA2000 connectivity 1 x NMEA 2000 Micro-C port, 1 LEN Warranty period 5 years Operating temperature rang -15C to +55C (-5F to +131F) Storage temperature range -40C to +85C (-40F to +185F) Dimensions W x H x D 14.310 x 10.841 x 6.280" NMEA2000 PGN Output Fluid Level, Pressure, Temperature, Battery Volts, State of Charge Monitoring Battery voltage, House current draw, House state of charge Ingress protection IPX7 Nominal Voltage 12 or 24V, power harvested from all batteries Continuous rating 300A Intermittent rating 700A Cranking rating 1450A Additional Inputs 3 x Master switch inputs, 2 x Analogue Inputs, 1 x Battery temperature sensor Normalized SKU: 80716003100UPC Code: 870216049687

BEP Marine 80-716-0032-00 Battery Switch BEP’s innovative Smart Battery Hub (SBH) is a world-first intelligent battery management system for vessels running two or more outboards, sterndrives, or multiple inboard engines. Smart Battery Hub simplifies battery management with remotely activated switches, automatic dual direction Voltage Sensitive Switching (VSS), and emergency parallel functionality, neatly housed in a robust, easy-to-install, ignition-protected IPX7 enclosure. VSS voltage thresholds can be configured to suit, or enabled/disabled with each installation. Switch inputs can be assigned to any function and two additional sensor inputs can be used for monitoring volts, fluid levels, and temperature. SBH monitors and transmits individual battery voltages and full house bank state of charge over NMEA2000, for easy integration with multi-function displays. Remote battery switching is operated via NMEA2000 or wired switches, with physical manual override of all battery switches for safety and servicing. Normalized SKU: 80716003200UPC Code: 870216049694

BEP Marine 80-716-0030-00 Battery SwitchBEP Smart Battery Hub Twin EngineModel: 80-716-0030-00 Remotely operated magnetic latching switches Remotely operated emergency parallel switches Configurable dual direction voltage sensitive switches Battery Voltage Monitoring House battery State of Charge Monitoring 2 x additional sensor inputs Safety manual override for all battery switches 12 or 24 volt systems Parallel two units together for 4, 5 and even 6 engine installations BEP’s innovative Smart Battery Hub (SBH) is a world-first intelligent battery management system for vessels running two or more outboards, sterndrives, or multiple inboard engines. Smart Battery Hub simplifies battery management with remotely activated switches, automatic dual direction Voltage Sensitive Switching (VSS) and emergency parallel functionality, neatly housed in a robust, easy-to-install, ignition-protected IPX7 enclosure. VSS voltage thresholds can be configured to suit, or enabled/disabled with each installation. Switch inputs can be assigned to any function and two additional sensor inputs can be used for monitoring volts, fluid levels and temperature. SBH monitors and transmits individual battery voltages and full house bank state of charge over NMEA2000, for easy integration with multi-function displays. Remote battery switching is operated via NMEA2000 or wired switches, with physical manual override of all battery switches for safety and servicing.Specifications Power consumption max 92mA Power consumption sleep <3.5mA NMEA2000 connectivity 1 x NMEA 2000 Micro-C port, 1 LEN Warranty period 5 years Operating temperature rang -15C to +55C (-5F to +131F) Storage temperature range -40C to +85C (-40F to +185F) Dimensions W x H x D 14.310 x 10.841 x 6.280" NMEA2000 PGN Output Fluid Level, Pressure, Temperature, Battery Volts, State of Charge Monitoring Battery voltage, House current draw, House state of charge Ingress protection IPX7 Nominal Voltage 12 or 24V, power harvested from all batteries Continuous rating 300A Intermittent rating 700A Cranking rating 1450A Additional Inputs 3 x Master switch inputs, 2 x Analogue Inputs, 1 x Battery temperature sensor Normalized SKU: 80716003000UPC Code: 870216049670
