BEP Marine 80-716-0032-00 Battery Switch BEP’s innovative Smart Battery Hub (SBH) is a world-first intelligent battery management system for vessels running two or more outboards, sterndrives, or multiple inboard engines. Smart Battery Hub simplifies battery management with remotely activated switches, automatic dual direction Voltage Sensitive Switching (VSS), and emergency parallel functionality, neatly housed in a robust, easy-to-install, ignition-protected IPX7 enclosure. VSS voltage thresholds can be configured to suit, or enabled/disabled with each installation. Switch inputs can be assigned to any function and two additional sensor inputs can be used for monitoring volts, fluid levels, and temperature. SBH monitors and transmits individual battery voltages and full house bank state of charge over NMEA2000, for easy integration with multi-function displays. Remote battery switching is operated via NMEA2000 or wired switches, with physical manual override of all battery switches for safety and servicing. Normalized SKU: 80716003200UPC Code: 870216049694

BEP Marine 80-716-0030-00 Battery SwitchBEP Smart Battery Hub Twin EngineModel: 80-716-0030-00 Remotely operated magnetic latching switches Remotely operated emergency parallel switches Configurable dual direction voltage sensitive switches Battery Voltage Monitoring House battery State of Charge Monitoring 2 x additional sensor inputs Safety manual override for all battery switches 12 or 24 volt systems Parallel two units together for 4, 5 and even 6 engine installations BEP’s innovative Smart Battery Hub (SBH) is a world-first intelligent battery management system for vessels running two or more outboards, sterndrives, or multiple inboard engines. Smart Battery Hub simplifies battery management with remotely activated switches, automatic dual direction Voltage Sensitive Switching (VSS) and emergency parallel functionality, neatly housed in a robust, easy-to-install, ignition-protected IPX7 enclosure. VSS voltage thresholds can be configured to suit, or enabled/disabled with each installation. Switch inputs can be assigned to any function and two additional sensor inputs can be used for monitoring volts, fluid levels and temperature. SBH monitors and transmits individual battery voltages and full house bank state of charge over NMEA2000, for easy integration with multi-function displays. Remote battery switching is operated via NMEA2000 or wired switches, with physical manual override of all battery switches for safety and servicing.Specifications Power consumption max 92mA Power consumption sleep <3.5mA NMEA2000 connectivity 1 x NMEA 2000 Micro-C port, 1 LEN Warranty period 5 years Operating temperature rang -15C to +55C (-5F to +131F) Storage temperature range -40C to +85C (-40F to +185F) Dimensions W x H x D 14.310 x 10.841 x 6.280" NMEA2000 PGN Output Fluid Level, Pressure, Temperature, Battery Volts, State of Charge Monitoring Battery voltage, House current draw, House state of charge Ingress protection IPX7 Nominal Voltage 12 or 24V, power harvested from all batteries Continuous rating 300A Intermittent rating 700A Cranking rating 1450A Additional Inputs 3 x Master switch inputs, 2 x Analogue Inputs, 1 x Battery temperature sensor Normalized SKU: 80716003000UPC Code: 870216049670

Sea-Dog 422768-1 Battery Switch The heavy-duty 422768 selector switch has 350A continuous and 1500 cranking amps to start a dual diesel engine. Battery selector switches either switch a single battery to a single load group or isolate and/or combine two battery banks.  It can be surface or rear panel mounted Ignition protected Safe for installation on gasoline-powered boats Constructed of injection molded nylon with machined brass contacts Installs with four #10 RH fasteners (not included) CE certified Specs: A: 4"     B: 4" C: 3-5/8" Function: Off/1/Both Batteries/2 Max Volts: 48 Amps: 350 Stud Diameter: 3/8" Normalized SKU: 4227681UPC Code: 035514433051

Sea-Dog 422732-1 Battery Switch These Mini Battery Switches feature a removable knob for extra security. To remove, simply twist the cap to the OUT position and pull. Mini footprint makes it ideal for close quarters. The 422732-1 is rated at 100A continuous and 150A cranking amps. Installation is as easy as drilling a 1-1/8" hole for the 422732-1, inserting the socket body, tightening the locking nut, and connecting the wires. Constructed of machined brass and injection molded nylon. A: 1-3/4"     B: 2-1/8"     C: 1-1/8"     Function: On/Off     Volts: 32     Amps:100     Stud Diameter: 1/4" Normalized SKU: 4227321UPC Code: 035514432955

Sea-Dog 422730-1 Battery SwitchSea-Dog Single Battery Switch #422730-1Normalized SKU: 4227301UPC Code: 035514432887

Sea-Dog 422766-1 Battery SwitchSea-Dog Battery Switch Single On/Off #422766-1Normalized SKU: 4227661UPC Code: 035514432733

Sea-Dog 422760-1 Battery Switch Battery disconnect and selector switches either switch a single battery to a single load group (422760 & 422761) or isolate and/or combines two battery banks (422760). Can be surface or rear panel mounted. Ignition protected. Safe for installation on gasoline-powered boats. Constructed of injection molded nylon with machined brass contacts. Installs with four #10 RH fasteners (not included). A  2-3/4" B  2-3/4" C  3" Normalized SKU: 4227601UPC Code: 035514425407

Sea-Dog 422780 Battery Switch Battery disconnect and selector switches either switch a single battery to a single load group (422780 & 422781) or isolate and/or combines two battery banks (422780). Can be surface or rear panel mounted. Ignition protected. Safe for installation on gasoline-powered boats. Constructed of injection molded nylon with machined brass contacts. Installs with four #10 RH fasteners (not included). A  6-3/8" B  2-1/2" Function Off/1/Both Batteries/2 Volts 36 Amps 300 Stud Fastener 3/8" Fasteners #10 RH Normalized SKU: 422780UPC Code: 035514432573

Recmar GS11200 Battery SwitchRecmar Battery Switch 500a #GS11200Normalized SKU: GS11200UPC Code: 8435412035371

Sierra BS11020 Battery Switch Function: 1-2-BOTH-OFF Maximum Voltage Rating: 48VDC Stud Size: M8 Cranking Rating: (10 Seconds): 1000A Intermittent Rating: (5 Minutes): 300A Continuous Rating: 200A Battery Input: 2 Switch Function: 4 Battery Studs: Tin-Plated Copper Stud Torque: 120 lb.-in Cable Size: 4/0 AWG to Meet Ratings Unique ergonomic and aesthetic knob design Removable knob for an added level of safety and isolation Robust Glass Fiber reinforced Nylon enclosure Removable windows on all four sides for unobstructed wiring Surface or panel mount options provide flexibility during installation Includes (4) M4x35 Mounting Screws Meets Ignition Protection Standard (ISO8846/ SAE J1171) Interchangeable knob labels for easy identification CE certified; IP66 Rated Normalized SKU: BS11020UPC Code: 808282381967

Sierra BS11000 Battery Switch Function: ON-OFF Maximum Voltage Rating: 48VDC Stud Size: M10 Cranking Rating: (10 Seconds): 1250A Intermittent Rating: (5 Minutes): 455A Continuous Rating: 275A Battery Input: 1 Switch Function: 2 Battery Studs: Tin-Plated Copper Stud Torque: 120 lb.-in Cable Size: 4/0 AWG to Meet Ratings Unique ergonomic and aesthetic knob design Removable knob for an added level of safety and isolation Robust Glass Fiber reinforced Nylon enclosure Removable windows on all four sides for unobstructed wiring Surface or panel mount options provide flexibility during installation Includes (4) M4x35 Mounting Screws Meets Ignition Protection Standard (ISO8846/ SAE J1171) Interchangeable knob labels for easy identification CE certified; IP66 Rated Normalized SKU: BS11000UPC Code: 808282382445

Sierra BS11030 Battery Switch Function: 1-2-BOTH-OFF Maximum Voltage Rating: 48VDC Stud Size: M8 Cranking Rating: (10 Seconds): 1000A Intermittent Rating: (5 Minutes): 300A Continuous Rating: 200A Battery Input: 2 Switch Function: 4 Battery Studs: Tin-Plated Copper Stud Torque: 120 lb.-in Cable Size: 4/0 AWG to Meet Ratings Unique ergonomic and aesthetic knob design Removable knob for an added level of safety and isolation Robust Glass Fiber reinforced Nylon enclosure Removable windows on all four sides for unobstructed wiring Surface or panel mount options provide flexibility during installation Includes (4) M4x35 Mounting Screws Meets Ignition Protection Standard (ISO8846/ SAE J1171) Interchangeable knob labels for easy identification CE certified; IP66 Rated Battery Switch with Alternator Field Disconnect Normalized SKU: BS11030UPC Code: 808282382100

Sierra BS11010 Battery Switch Function: ON-OFF Maximum Voltage Rating: 48VDC Stud Size: M10 Cranking Rating: (10 Seconds): 1250A Intermittent Rating: (5 Minutes): 455A Continuous Rating: 275A Battery Input: 1 Switch Function: 2 Battery Studs: Tin-Plated Copper Stud Torque: 120 lb.-in Cable Size: 4/0 AWG to Meet Ratings Unique ergonomic and aesthetic knob design Removable knob for an added level of safety and isolation Robust Glass Fiber reinforced Nylon enclosure Removable windows on all four sides for unobstructed wiring Surface or panel mount options provide flexibility during installation Includes (4) M4x35 Mounting Screws Meets Ignition Protection Standard (ISO8846/ SAE J1171) Interchangeable knob labels for easy identification CE certified; IP66 Rated Smallest battery switch with Alternator Field Disconnect in the market Normalized SKU: BS11010UPC Code: 808282382049
