Attwood Marine 14230-3 Battery Switch Single-pole, triple-throw switch permits four connection modes: Battery One, Battery Two, two batteries in parallel, or both off. Rated for 230 amps continuous, 345 amps momentary. For 6-volt to 32-volt systems. Includes alternator field circuit disconnect to prevent surges. The selector has positive click positions. Bakelite housing with copper washers, brass terminals, and brass nuts. Install with #10 screws. Dimensions: 5-1/2" dia. x 2-3/4" deepElectrical: Battery Switch Attwood-Battery Selector Switch, 4-Wire #14230-3 Normalized SKU: 142303UPC Code: 022697000842

Blue Sea System 6008 Battery Switch6008 M-Series Battery Switch 3 Position - RedSwitches a single battery to a single load group.Features: Ignition protected—safe for installation aboard gasoline powered boats Case design allows surface or rear panel mounting Specifications: Switch Type: Selector 3 Position Color: Red Battery Combine: No Switch Positions: 3 Maximum Voltage: 32V DC Specifications:AFD = NONE Lockable = NONE Positions = NONENormalized SKU: 6008UPC Code: 632085060084

BEP Marine 720-MDO Battery SwitchRemote Operated Battery Switch w/Optical Sensor 500A 12/24VThe MD range of battery switches allow you to install the battery switch very close to the battery, to remotely manage the increased electrical loads found on today's boats. This reduces cable lengths and sizes, providing significant savings in expense and weight of copper battery cable. They are ideal for remote isolation of bow and stern thrusters. The 720-MDO has been enhanced to offer easy standard installation, or advanced options capable of switching different voltage circuits from the main supply (for example: a 48 volt bow thruster with a 24 volt house supply). The optical sensor uses the same easy connection for standard installation and gives you the ability to control different voltage circuits such as 36 or 48 volts. It can be used to switch positive or negative lines and the main contacts can be isolated from the control circuit allowing operation via another battery source. This optical sensor also has low stand-by current draw (<5mA). Remote operation Battery switch can be mounted alongside battery, reducing cable lengths and cable sizes. (Large cost and weight saving in copper cables) Reduced installation labor due to shorter battery cable runs Manual override option to meet CE/ABYC requirements LED status identification for remote control switch Same capacities/specifications and mounting options as standard BEP battery switches Uses interchangeable labeling system (Item # 713 or 715) Specifications:LxWxH: 4" x 4" x 4.33"Rating (A DC) Cont: 500Rating (A DC) Inter: 700Rating (A DC) Crank: 2500Voltage (V DC): 9.5-32Function: On/OffStud Size: 2x (1/2"/12mm)WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 720MDOUPC Code: 843687003731

  Download LiteratureBlue Sea System 11003 Battery Switch11003Features: Meets American Boat and Yacht Council (ABYC) requirements for battery switches Ignition protected safe for installation aboard gasoline powered boats Case design allows surface or rear panel mounting Accepts two 4/0 AWG (95mm) battery cables M12 tin-plated copper studs for maximum conductivity and corrosion resistance, accepts 1/2" and M12 ring terminals 7/8" (22.22mm) stud length to accept multiple cable terminals Tactile textures indicate knob position by feel only Case design allows surface or rear panel mounting Switch Ratings: 10 Sec: 2750A60 Sec: 1150A5 Min: 700AContinuous: 500AMax Voltage: 32V DCWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Electrical: Battery SwitchSpecifications: Lockable = NONE AFD = Yes Positions = 3 Amps - Max = NONE BLUE SEA 11003 HEAVY DUTY BATTERY SWITCH 3 POSITION W/ AFD Normalized SKU: 11003UPC Code: 632085110031Blue Sea System 11003 Literature Download   Product Brochure

  Download LiteratureBlue Sea System 11001 Battery Switche-Series Selector 3 Position Battery Switch with AFDAFD: YesBattery Combiner: NoFeatures: Make-before-break contact design allows switching between battery banks without power interruption CE Marked Ignition protected-safe for installation aboard gasoline powered boats Case design allows surface or rear panel mounting Meets American Boat and Yacht Council (ABYC) requirements for battery switches 3/8"-16 tin-plated copper studs for maximum conductivity and corrosion resistance, accepts 3/8" and M10 ring terminals 7/8" (22.22mm) stud length to accept multiple cable terminals Tactile textures indicate knob position by feel only WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Electrical: Battery SwitchSpecifications:Lockable = NONE AFD = Yes Positions = 3 Amps - Max = NONEBLUE SEA 11001 BATTERY SWITCH E SERIES 3 POS W/ AFDNormalized SKU: 11001UPC Code: 632085110017Blue Sea System 11001 Literature Download  Product Brochure

  Download LiteratureBlue Sea System 9001E Battery Switch9001ee-Series Battery Switch Selector Make-before-break contact design allows switching between battery banks without power interruption CE Marked Ignition protected - Safe for installation aboard gasoline powered boats Case design allows surface or rear panel mounting Meets American Boat and Yacht Council (ABYC) requirements for battery switches 3/8"-16 tin-plated copper studs for maximum conductivity and corrosion resistance, accepts 3/8" and M10 ring terminals 7/8" (22.22mm) stud length to accept multiple cable terminals Tactile textures indicate knob position by feel only WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Electrical: Battery SwitchSpecifications:Lockable = No AFD = No Positions = 2 Amps - Max = NONEBLUE SEA 9001E BATTERY SWITCH E SELECTORNormalized SKU: 9001EUPC Code: 632085900151Blue Sea System 9001E Literature Download  Owners Manual  Product Brochure

Marpac 7-0378 Battery SwitchMarpac Battery Selector Switch Perko #8501 #7-0378Normalized SKU: 70378UPC Code: 787766703788

Marpac 7-0380 Battery SwitchMarpac Battery Selector Switch #7-0380Normalized SKU: 70380UPC Code: 787766703801

EGIS 2703 Battery SwitchEGIS 2703 Mini Selector Battery SwitchModel: 2703 Surface and Panel mounting variations allow for flexible installations. Harsh Environment Design with stainless-steel hardware, serated flange nuts and high temperature materials. Ignition Protected safe for installation in closed compartments with potential explosive gases. Normalized SKU: 2703

EGIS 2701 Battery SwitchEGIS 2701 Mini On/Off Battery SwitchModel: 2701 Surface and Panel mounting variations allow for flexible installations. Harsh Environment Design with stainless-steel hardware, serated flange nuts and high temperature materials. Ignition Protected safe for installation in closed compartments with potential explosive gases. Normalized SKU: 2701

EGIS 2502 Battery SwitchEGIS 2502 Heavy Duty-Series 600A Battery Selector Switch Off/1/Both/2Model: 2502 Surface and Panel mounting variations allow for flexible installations. Harsh Environment Design with stainless-steel hardware, serated flange nuts and high temperature materials. Ignition Protected safe for installation in closed compartments with potential explosive gases. Normalized SKU: 2502

EGIS 2402 Battery SwitchEGIS 2402 e-Series 350A Battery Selector Switch Off/1/Both/2 w/AFDModel: 2402 Surface and Panel mounting variations allow for flexible installations. Harsh Environment Design with stainless-steel hardware, serated flange nuts and high temperature materials. Ignition Protected safe for installation in closed compartments with potential explosive gases. Normalized SKU: 2402

EGIS 2401 Battery SwitchEGIS 2401 e-Series 350A Battery Selector Switch Off/1/Both/2Model: 2401 Surface, Front & Panel mounting variations for flexible installations. Harsh Environment Design with stainless-steel hardware, serrated flange nuts and high temperature materials. Ignition Protected safe for compartments with potential explosive gases. Normalized SKU: 2401

EGIS 2307 Battery SwitchEGIS 2307 m-Series 300A Battery Selector Switch Off/1/Both/2Model: 2307 Surface, Front & Panel mounting variations for flexible installations. Harsh Environment Design with stainless-steel hardware, serrated flange nuts and high temperature materials. Ignition Protected safe for compartments with potential explosive gases. Normalized SKU: 2307

Download LiteratureEgis 2305 Battery AccessoriesM-Series 300A Battery Switch Off/On Key ActuatorSealed Against Dust & Water Intrusion - To ensure reliable circuit protection for the life of the electrical system installation.Ignition Protected - Safe for installation in closed compartments with potential explosive gases.Serrated Flange Lock Nuts - Improves resistance to cable terminal loosening in high-vibration environments.Flexible Mounting Options - Allow for multiple mounting configurations and a variety of installation types.Harsh Environment Design - With stainless steel hardware, serrated flange nuts, and high-temperature materials.Specifications: Maximum Voltage (Single Circuit): 48 Vdc Maximum Voltage (Selector / Dual Circuit): 32 Vdc Stud Size And Thread: 3/8”-16 Terminal Stud Torque: 120 in-lbs (13.6 N-m) Ring Terminal Size Acceptance: 3/8” (M10) Mounting Holes: #10 Screw Live Switching Rating: 25 Amps Ignition Protection Rating: SAE J1171 / ISO 8846 Bulkhead / Panel - Mounting Hole Size: 2-5/8" / 2-5/16" Cable Size to Meet Rating: 4/0 AWG Normalized SKU: 2305UPC Code: 850067590491Egis 2305 Literature Download Quick Reference Guide

Download LiteratureEgis 2311 Battery AccessoriesM-Series 300A Dual Circuit Battery Switch with Combine Battery SwitchSealed Against Dust & Water Intrusion - To ensure reliable circuit protection for the life of the electrical system installation.Ignition Protected - Safe for installation in closed compartments with potential explosive gases.Serrated Flange Lock Nuts - Improves resistance to cable terminal loosening in high-vibration environments.Flexible Mounting Options - Allow for multiple mounting configurations and a variety of installation types.Harsh Environment Design - With stainless steel hardware, serrated flange nuts, and high-temperature materials.Specifications: Maximum Voltage (Single Circuit): 48 Vdc Maximum Voltage (Selector / Dual Circuit): 32 Vdc Stud Size And Thread: 3/8”-16 Terminal Stud Torque: 120 in-lbs (13.6 N-m) Ring Terminal Size Acceptance: 3/8” (M10) Mounting Holes: #10 Screw Live Switching Rating: 25 Amps Ignition Protection Rating: SAE J1171 / ISO 8846 Bulkhead / Panel - Mounting Hole Size: 2-5/8" / 2-5/16" Cable Size to Meet Rating: 4/0 AWG Normalized SKU: 2311UPC Code: 850067590538Egis 2311 Literature Download Quick Reference Guide

Download LiteratureEgis 2310 Battery AccessoriesM-Series 300A Dual Circuit Battery Switch Off/OnSealed Against Dust & Water Intrusion - To ensure reliable circuit protection for the life of the electrical system installation.Ignition Protected - Safe for installation in closed compartments with potential explosive gases.Serrated Flange Lock Nuts - Improves resistance to cable terminal loosening in high-vibration environments.Flexible Mounting Options - Allow for multiple mounting configurations and a variety of installation types.Harsh Environment Design - With stainless steel hardware, serrated flange nuts, and high-temperature materials.Specifications: Maximum Voltage (Single Circuit): 48 Vdc Maximum Voltage (Selector / Dual Circuit): 32 Vdc Stud Size And Thread: 3/8”-16 Terminal Stud Torque: 120 in-lbs (13.6 N-m) Ring Terminal Size Acceptance: 3/8” (M10) Mounting Holes: #10 Screw Live Switching Rating: 25 Amps Ignition Protection Rating: SAE J1171 / ISO 8846 Bulkhead / Panel - Mounting Hole Size: 2-5/8" / 2-5/16" Cable Size to Meet Rating: 4/0 AWG Normalized SKU: 2310UPC Code: 850067590521Egis 2310 Literature Download Quick Reference Guide

Download LiteratureEgis 2403 Battery AccessoriesE-Series 350A Battery Switch Off/OnSealed Against Dust & Water Intrusion - To ensure reliable circuit protection for the life of the electrical system installation.Ignition Protected - Safe for installation in closed compartments with potential explosive gases.Serrated Flange Lock Nuts - Improves resistance to cable terminal loosening in high-vibration environments.Flexible Mounting Options - Allow for multiple mounting configurations and a variety of installation types.Harsh Environment Design - With stainless steel hardware, serrated flange nuts, and high-temperature materials.Specifications: Maximum Voltage (Single Circuit): 48 Vdc Maximum Voltage (Selector / Dual Circuit): 32 Vdc Stud Size And Thread: 3/8”-16 Terminal Stud Torque: 140 in-lbs (15.8 N-m) Ring Terminal Size Acceptance: 3/8” (M10) Mounting Holes: #1/4" (M6) Screw Live Switching Rating: 25 Amps Ignition Protection Rating: SAE J1171 / ISO 8846 Bulkhead / Panel - Mounting Hole Size: 3-5/8" Diameter Cable Size to Meet Rating: 4/0 AWG Normalized SKU: 2403UPC Code: 850067590569Egis 2403 Literature Download Quick Reference Guide
