Newmar PT-24-95U Battery Chargers"Three Stage "Smart" Chargers Phase Three "Smart" battery charging technology is now available in a wide range of power levels, allowing you to select the right size, features and flexibility you require for virtually any application from small recreational craft to large live-aboards, workboats and other commercial vessels. These chargers interact with batteries to put them through the optimum three stage charge process which provides for fastest recovery and ideal conditioning, maximizing battery performance and extending battery life. A selector switch adjusts output voltage to adapt for gel-cell/flooded lead-acid/AGM battery types. An optional temperature compensation sensor also adjusts output for ideal voltage based on changes in the batteries' ambient temperature. All models are housed in a rugged stainless steel case with a durable white powder coat finish, and the internal circuitry is polyurethane coated for maximum corrosion resistance. Features "Smart" circuitry provides three stage charging?bulk, absorption, float. Wide model range covers battery system ratings from 14-950 amp-hours Gel-Cell/Flooded Lead-acid/AGM battery type switch selects optimum charge/float voltages. Multiple isolated output banks; ammeter indicates total output current. (except PT-7) Optional sensor adjusts output voltage based on battery temperature. (except PT-7) Current limiting-prevents damage from overloading. Charger status clearly displayed with L.E.D. and/or audible indicators or optional remote panel. Use as a power supply; can power loads without a battery in line. Built to last?rugged stainless steel case with a durable white powder coat finish with an optional drip shield and marinized internal circuitry. Numerous Safety and EMC CompliancesTwo year parts and labor warranty Models   12 Volt 24 Volt 32 Volt PT-7 PT-24-8W PT-32-25W PT-14W PT-24-13W   PT-25W PT-24-20U   PT-40U PT-24-45U   PT-80 PT-24-60W     PT-24-95U   Detailed specifications below.  Specifications   12 Volt Models PT-7 PT-14W PT-25W PT-40W PT-80 Input VAC (50-60 Hz.) 88-132 or 176-264 85-264 90-132 or 180-264 85-135 or 170-270 90-264 Input Amps @ Full Load   @ 115 VAC 2 2.8 6.5 8.5 12 @ 230 VAC 1 1.4 4 4.3 7 P.F. Rating >.65 .93@230V .98@115V .7 .7 .95@230V .98@115V Max Output Amps 7 14 25 40 80 Output Banks 2 3 3 3 3 Battery Capacity (Amp-Hours) 14-70 28-140 50-250 80-400 160-800 Operating Temp. Rating Reference T-1 T-2 T-4 T-5 T-7 Case Size Ref. A-1 A-2 A-2 A-3 A-5 Weight; Lbs./Kg. 3.2/1.5 8/4 8.2/4 12/6 15.2/7 Optional Temp.Sensor Model N/A TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 Remote Panel Model N/A RP RP RP RP Equalize Option No Yes Yes Yes Yes Output Indicator Ref. M-1 M-3 M-3 M-3 M-3 Compliance Ref. CG, CE CG, CE CG CG, CE CE    24 Volt Models PT-24-8W PT-24-13W PT-24-20U PT-24-45U PT-24-60W PT-24-95U Input VAC (50-60 Hz.) 85-264 90-132 or 180-264 85-135 or 170-270 90-264 207-253 90-264 Input Amps @ Full Load   @ 115 VAC 2.8 6.5 8.5 12 NA 26 @ 230 VAC 1.4 4 4.3 7 13 14 P.F. Rating .93@230V .98@115V .7 .7 .95@230V .98@115V .7 .95@230V .98@115V Max Output Amps 8 13 20 45 60 95 Output Banks 3 3 3 3 3 3 Battery Capacity (Amp-Hours) 16-80 26-130 40-200 90-450 120-600 180-950 Operating Temp. Rating Reference T-2 T-3 T-5 T-8 T-6 T-8 Case Size Ref. A-2 A-2 A-3 A-5 A-6 A-6 Weight; Lbs./Kg. 8/4 8.2/4 12/6 12.2/6 24.1/11 24.5/11 Optional Temp.Sensor Model TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 TP TCS-12/24 Remote Panel Model RP RP RP RP N/A RP Equalize Option Yes Yes Yes Yes No Yes Output Indicator Ref. M-3 M-3 M-3 M-3 M-2 M-3 Compliance Ref. CG, CE CG CG, CE EN, CE EN, CE EN, CE   32 Volt Model  PT-32-25W Input VAC (50-60 Hz.) 104-126 Input Amps @ Full Load    @ 115 VAC 15 @ 230 VAC N/A P.F. Rating .7 Max Output Amps 25 Output Banks 3 Battery Capacity (Amp-Hours) 50-250 Operating Temp. Rating Reference T-6 Case Size Ref. A-4 Weight; Lbs./Kg. 12.2/6 Optional Temp.Sensor Model TP Remote Panel Model N/A Equalize Option No Output Indicator Ref. M-2 Compliance Ref. EN, CE Case Size     Inches Centimeters Ref H W D H W D A-1 10.5 5.0 2.8 26.7 12.7 7.1 A-2 12.5 7.7 4.3 31.8 19.6 10.9 A-3 13.85* 9.5 4.8* 35.2* 24.1 12.2* A-4 13.8A 9.8 5A 35A 24.9 12.7A A-5 14.8B 9.6 5.6B 37.6B 24.4 14.2B A-6 17.5C 12 7.2C 44.5C 30.5 18.3C * Add .75" (1.9 cm) to height and 1.35" (3.4 cm) to depth A Add 1.27" (3.2 cm) to height and 1.1" (2.8 cm) to depth B Add 1" (2.54 cm) to height and .5" (1.27 cm) to depth C Add 2" (5.08 cm) to height and 1" (2.54 cm) to depth Temperature Rating References:   T-1 -10°C to +45°C; Derate linearly from 100% @ 0°C to 80% @ -10°C T-2 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-3 -10°C to +60°C; Derate linearly from 100% @ 50°C to 60% @ 60°C T-4 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-5 -40°C to +60°C; Derate linearly from 100% @ 50°C to 75% @ 60°C T-6 -20°C to +50°C; Full output T-7 -20°C to +70°C; Derate linearly from 100% @ 45°C to 50% @ 70°C T-8 -20°C to +70°C; Derate linearly from 100% @ 50°C to 50% @ 70°C Output Indicator References   M-1 Total output ammeter M-2 Charge/Float L.E.D. M-3 Total output ammeter and charger status L.E.D.'s/Alarms Compliance References* See matrix for applicable models CG USCG CFR 183.410 (Ignition protected) EN EN 60335-1, EN 60335-2-29 CE Carries the CE Mark * Numerous other Safety and EMC compliances may also apply. Contact factory if further compliance   information is required. Nominal Output Voltages at Gel/Flooded Switch Settings (Without Temperature Compensation option installed or at 22.2˚C (72˚F) with Temperature Compensation option installed.)     12 Volt Models 24 Volt Models 32 Volt Model Charge Float Charge Float Charge Float Setting @ 50% load @ .5 amp load @ 50% load @ .5 amp load @ 50% load @ .5 amp load Gel-Cell 14.0 VDC 13.6 VDC 28.0 VDC 27.2 VDC 37.3 VDC 36.2 VDC Flooded/AGM 14.2 VDC 13.4 VDC 28.4 VDC 26.8 VDC 37.8 VDC 35.7 VDC "Normalized SKU: PT2495UUPC Code: 445-4906-0

Newmar PT-24-45U Battery Chargers"Three Stage "Smart" Chargers Phase Three "Smart" battery charging technology is now available in a wide range of power levels, allowing you to select the right size, features and flexibility you require for virtually any application from small recreational craft to large live-aboards, workboats and other commercial vessels. These chargers interact with batteries to put them through the optimum three stage charge process which provides for fastest recovery and ideal conditioning, maximizing battery performance and extending battery life. A selector switch adjusts output voltage to adapt for gel-cell/flooded lead-acid/AGM battery types. An optional temperature compensation sensor also adjusts output for ideal voltage based on changes in the batteries' ambient temperature. All models are housed in a rugged stainless steel case with a durable white powder coat finish, and the internal circuitry is polyurethane coated for maximum corrosion resistance. Features "Smart" circuitry provides three stage charging?bulk, absorption, float. Wide model range covers battery system ratings from 14-950 amp-hours Gel-Cell/Flooded Lead-acid/AGM battery type switch selects optimum charge/float voltages. Multiple isolated output banks; ammeter indicates total output current. (except PT-7) Optional sensor adjusts output voltage based on battery temperature. (except PT-7) Current limiting-prevents damage from overloading. Charger status clearly displayed with L.E.D. and/or audible indicators or optional remote panel. Use as a power supply; can power loads without a battery in line. Built to last?rugged stainless steel case with a durable white powder coat finish with an optional drip shield and marinized internal circuitry. Numerous Safety and EMC CompliancesTwo year parts and labor warranty Models   12 Volt 24 Volt 32 Volt PT-7 PT-24-8W PT-32-25W PT-14W PT-24-13W   PT-25W PT-24-20U   PT-40U PT-24-45U   PT-80 PT-24-60W     PT-24-95U   Detailed specifications below.  Specifications   12 Volt Models PT-7 PT-14W PT-25W PT-40W PT-80 Input VAC (50-60 Hz.) 88-132 or 176-264 85-264 90-132 or 180-264 85-135 or 170-270 90-264 Input Amps @ Full Load   @ 115 VAC 2 2.8 6.5 8.5 12 @ 230 VAC 1 1.4 4 4.3 7 P.F. Rating >.65 .93@230V .98@115V .7 .7 .95@230V .98@115V Max Output Amps 7 14 25 40 80 Output Banks 2 3 3 3 3 Battery Capacity (Amp-Hours) 14-70 28-140 50-250 80-400 160-800 Operating Temp. Rating Reference T-1 T-2 T-4 T-5 T-7 Case Size Ref. A-1 A-2 A-2 A-3 A-5 Weight; Lbs./Kg. 3.2/1.5 8/4 8.2/4 12/6 15.2/7 Optional Temp.Sensor Model N/A TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 Remote Panel Model N/A RP RP RP RP Equalize Option No Yes Yes Yes Yes Output Indicator Ref. M-1 M-3 M-3 M-3 M-3 Compliance Ref. CG, CE CG, CE CG CG, CE CE    24 Volt Models PT-24-8W PT-24-13W PT-24-20U PT-24-45U PT-24-60W PT-24-95U Input VAC (50-60 Hz.) 85-264 90-132 or 180-264 85-135 or 170-270 90-264 207-253 90-264 Input Amps @ Full Load   @ 115 VAC 2.8 6.5 8.5 12 NA 26 @ 230 VAC 1.4 4 4.3 7 13 14 P.F. Rating .93@230V .98@115V .7 .7 .95@230V .98@115V .7 .95@230V .98@115V Max Output Amps 8 13 20 45 60 95 Output Banks 3 3 3 3 3 3 Battery Capacity (Amp-Hours) 16-80 26-130 40-200 90-450 120-600 180-950 Operating Temp. Rating Reference T-2 T-3 T-5 T-8 T-6 T-8 Case Size Ref. A-2 A-2 A-3 A-5 A-6 A-6 Weight; Lbs./Kg. 8/4 8.2/4 12/6 12.2/6 24.1/11 24.5/11 Optional Temp.Sensor Model TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 TP TCS-12/24 Remote Panel Model RP RP RP RP N/A RP Equalize Option Yes Yes Yes Yes No Yes Output Indicator Ref. M-3 M-3 M-3 M-3 M-2 M-3 Compliance Ref. CG, CE CG CG, CE EN, CE EN, CE EN, CE   32 Volt Model  PT-32-25W Input VAC (50-60 Hz.) 104-126 Input Amps @ Full Load    @ 115 VAC 15 @ 230 VAC N/A P.F. Rating .7 Max Output Amps 25 Output Banks 3 Battery Capacity (Amp-Hours) 50-250 Operating Temp. Rating Reference T-6 Case Size Ref. A-4 Weight; Lbs./Kg. 12.2/6 Optional Temp.Sensor Model TP Remote Panel Model N/A Equalize Option No Output Indicator Ref. M-2 Compliance Ref. EN, CE Case Size     Inches Centimeters Ref H W D H W D A-1 10.5 5.0 2.8 26.7 12.7 7.1 A-2 12.5 7.7 4.3 31.8 19.6 10.9 A-3 13.85* 9.5 4.8* 35.2* 24.1 12.2* A-4 13.8A 9.8 5A 35A 24.9 12.7A A-5 14.8B 9.6 5.6B 37.6B 24.4 14.2B A-6 17.5C 12 7.2C 44.5C 30.5 18.3C * Add .75" (1.9 cm) to height and 1.35" (3.4 cm) to depth A Add 1.27" (3.2 cm) to height and 1.1" (2.8 cm) to depth B Add 1" (2.54 cm) to height and .5" (1.27 cm) to depth C Add 2" (5.08 cm) to height and 1" (2.54 cm) to depth Temperature Rating References:   T-1 -10°C to +45°C; Derate linearly from 100% @ 0°C to 80% @ -10°C T-2 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-3 -10°C to +60°C; Derate linearly from 100% @ 50°C to 60% @ 60°C T-4 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-5 -40°C to +60°C; Derate linearly from 100% @ 50°C to 75% @ 60°C T-6 -20°C to +50°C; Full output T-7 -20°C to +70°C; Derate linearly from 100% @ 45°C to 50% @ 70°C T-8 -20°C to +70°C; Derate linearly from 100% @ 50°C to 50% @ 70°C Output Indicator References   M-1 Total output ammeter M-2 Charge/Float L.E.D. M-3 Total output ammeter and charger status L.E.D.'s/Alarms Compliance References* See matrix for applicable models CG USCG CFR 183.410 (Ignition protected) EN EN 60335-1, EN 60335-2-29 CE Carries the CE Mark * Numerous other Safety and EMC compliances may also apply. Contact factory if further compliance   information is required. Nominal Output Voltages at Gel/Flooded Switch Settings (Without Temperature Compensation option installed or at 22.2˚C (72˚F) with Temperature Compensation option installed.)     12 Volt Models 24 Volt Models 32 Volt Model Charge Float Charge Float Charge Float Setting @ 50% load @ .5 amp load @ 50% load @ .5 amp load @ 50% load @ .5 amp load Gel-Cell 14.0 VDC 13.6 VDC 28.0 VDC 27.2 VDC 37.3 VDC 36.2 VDC Flooded/AGM 14.2 VDC 13.4 VDC 28.4 VDC 26.8 VDC 37.8 VDC 35.7 VDC "Normalized SKU: PT2445UUPC Code: 445-4800-0

Newmar PT-14W Battery Chargers"Three Stage "Smart" Chargers Phase Three "Smart" battery charging technology is now available in a wide range of power levels, allowing you to select the right size, features and flexibility you require for virtually any application from small recreational craft to large live-aboards, workboats and other commercial vessels. These chargers interact with batteries to put them through the optimum three stage charge process which provides for fastest recovery and ideal conditioning, maximizing battery performance and extending battery life. A selector switch adjusts output voltage to adapt for gel-cell/flooded lead-acid/AGM battery types. An optional temperature compensation sensor also adjusts output for ideal voltage based on changes in the batteries' ambient temperature. All models are housed in a rugged stainless steel case with a durable white powder coat finish, and the internal circuitry is polyurethane coated for maximum corrosion resistance. Features "Smart" circuitry provides three stage charging?bulk, absorption, float. Wide model range covers battery system ratings from 14-950 amp-hours Gel-Cell/Flooded Lead-acid/AGM battery type switch selects optimum charge/float voltages. Multiple isolated output banks; ammeter indicates total output current. (except PT-7) Optional sensor adjusts output voltage based on battery temperature. (except PT-7) Current limiting-prevents damage from overloading. Charger status clearly displayed with L.E.D. and/or audible indicators or optional remote panel. Use as a power supply; can power loads without a battery in line. Built to last?rugged stainless steel case with a durable white powder coat finish with an optional drip shield and marinized internal circuitry. Numerous Safety and EMC CompliancesTwo year parts and labor warranty Models   12 Volt 24 Volt 32 Volt PT-7 PT-24-8W PT-32-25W PT-14W PT-24-13W   PT-25W PT-24-20U   PT-40U PT-24-45U   PT-80 PT-24-60W     PT-24-95U   Detailed specifications below.  Specifications   12 Volt Models PT-7 PT-14W PT-25W PT-40W PT-80 Input VAC (50-60 Hz.) 88-132 or 176-264 85-264 90-132 or 180-264 85-135 or 170-270 90-264 Input Amps @ Full Load   @ 115 VAC 2 2.8 6.5 8.5 12 @ 230 VAC 1 1.4 4 4.3 7 P.F. Rating >.65 .93@230V .98@115V .7 .7 .95@230V .98@115V Max Output Amps 7 14 25 40 80 Output Banks 2 3 3 3 3 Battery Capacity (Amp-Hours) 14-70 28-140 50-250 80-400 160-800 Operating Temp. Rating Reference T-1 T-2 T-4 T-5 T-7 Case Size Ref. A-1 A-2 A-2 A-3 A-5 Weight; Lbs./Kg. 3.2/1.5 8/4 8.2/4 12/6 15.2/7 Optional Temp.Sensor Model N/A TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 Remote Panel Model N/A RP RP RP RP Equalize Option No Yes Yes Yes Yes Output Indicator Ref. M-1 M-3 M-3 M-3 M-3 Compliance Ref. CG, CE CG, CE CG CG, CE CE    24 Volt Models PT-24-8W PT-24-13W PT-24-20U PT-24-45U PT-24-60W PT-24-95U Input VAC (50-60 Hz.) 85-264 90-132 or 180-264 85-135 or 170-270 90-264 207-253 90-264 Input Amps @ Full Load   @ 115 VAC 2.8 6.5 8.5 12 NA 26 @ 230 VAC 1.4 4 4.3 7 13 14 P.F. Rating .93@230V .98@115V .7 .7 .95@230V .98@115V .7 .95@230V .98@115V Max Output Amps 8 13 20 45 60 95 Output Banks 3 3 3 3 3 3 Battery Capacity (Amp-Hours) 16-80 26-130 40-200 90-450 120-600 180-950 Operating Temp. Rating Reference T-2 T-3 T-5 T-8 T-6 T-8 Case Size Ref. A-2 A-2 A-3 A-5 A-6 A-6 Weight; Lbs./Kg. 8/4 8.2/4 12/6 12.2/6 24.1/11 24.5/11 Optional Temp.Sensor Model TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 TP TCS-12/24 Remote Panel Model RP RP RP RP N/A RP Equalize Option Yes Yes Yes Yes No Yes Output Indicator Ref. M-3 M-3 M-3 M-3 M-2 M-3 Compliance Ref. CG, CE CG CG, CE EN, CE EN, CE EN, CE   32 Volt Model  PT-32-25W Input VAC (50-60 Hz.) 104-126 Input Amps @ Full Load    @ 115 VAC 15 @ 230 VAC N/A P.F. Rating .7 Max Output Amps 25 Output Banks 3 Battery Capacity (Amp-Hours) 50-250 Operating Temp. Rating Reference T-6 Case Size Ref. A-4 Weight; Lbs./Kg. 12.2/6 Optional Temp.Sensor Model TP Remote Panel Model N/A Equalize Option No Output Indicator Ref. M-2 Compliance Ref. EN, CE Case Size     Inches Centimeters Ref H W D H W D A-1 10.5 5.0 2.8 26.7 12.7 7.1 A-2 12.5 7.7 4.3 31.8 19.6 10.9 A-3 13.85* 9.5 4.8* 35.2* 24.1 12.2* A-4 13.8A 9.8 5A 35A 24.9 12.7A A-5 14.8B 9.6 5.6B 37.6B 24.4 14.2B A-6 17.5C 12 7.2C 44.5C 30.5 18.3C * Add .75" (1.9 cm) to height and 1.35" (3.4 cm) to depth A Add 1.27" (3.2 cm) to height and 1.1" (2.8 cm) to depth B Add 1" (2.54 cm) to height and .5" (1.27 cm) to depth C Add 2" (5.08 cm) to height and 1" (2.54 cm) to depth Temperature Rating References:   T-1 -10°C to +45°C; Derate linearly from 100% @ 0°C to 80% @ -10°C T-2 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-3 -10°C to +60°C; Derate linearly from 100% @ 50°C to 60% @ 60°C T-4 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-5 -40°C to +60°C; Derate linearly from 100% @ 50°C to 75% @ 60°C T-6 -20°C to +50°C; Full output T-7 -20°C to +70°C; Derate linearly from 100% @ 45°C to 50% @ 70°C T-8 -20°C to +70°C; Derate linearly from 100% @ 50°C to 50% @ 70°C Output Indicator References   M-1 Total output ammeter M-2 Charge/Float L.E.D. M-3 Total output ammeter and charger status L.E.D.'s/Alarms Compliance References* See matrix for applicable models CG USCG CFR 183.410 (Ignition protected) EN EN 60335-1, EN 60335-2-29 CE Carries the CE Mark * Numerous other Safety and EMC compliances may also apply. Contact factory if further compliance   information is required. Nominal Output Voltages at Gel/Flooded Switch Settings (Without Temperature Compensation option installed or at 22.2˚C (72˚F) with Temperature Compensation option installed.)     12 Volt Models 24 Volt Models 32 Volt Model Charge Float Charge Float Charge Float Setting @ 50% load @ .5 amp load @ 50% load @ .5 amp load @ 50% load @ .5 amp load Gel-Cell 14.0 VDC 13.6 VDC 28.0 VDC 27.2 VDC 37.3 VDC 36.2 VDC Flooded/AGM 14.2 VDC 13.4 VDC 28.4 VDC 26.8 VDC 37.8 VDC 35.7 VDC "Normalized SKU: PT14W

Newmar PT-7 Battery Chargers"Three Stage "Smart" Chargers Phase Three "Smart" battery charging technology is now available in a wide range of power levels, allowing you to select the right size, features and flexibility you require for virtually any application from small recreational craft to large live-aboards, workboats and other commercial vessels. These chargers interact with batteries to put them through the optimum three stage charge process which provides for fastest recovery and ideal conditioning, maximizing battery performance and extending battery life. A selector switch adjusts output voltage to adapt for gel-cell/flooded lead-acid/AGM battery types. An optional temperature compensation sensor also adjusts output for ideal voltage based on changes in the batteries' ambient temperature. All models are housed in a rugged stainless steel case with a durable white powder coat finish, and the internal circuitry is polyurethane coated for maximum corrosion resistance. Features "Smart" circuitry provides three stage charging?bulk, absorption, float. Wide model range covers battery system ratings from 14-950 amp-hours Gel-Cell/Flooded Lead-acid/AGM battery type switch selects optimum charge/float voltages. Multiple isolated output banks; ammeter indicates total output current. (except PT-7) Optional sensor adjusts output voltage based on battery temperature. (except PT-7) Current limiting-prevents damage from overloading. Charger status clearly displayed with L.E.D. and/or audible indicators or optional remote panel. Use as a power supply; can power loads without a battery in line. Built to last?rugged stainless steel case with a durable white powder coat finish with an optional drip shield and marinized internal circuitry. Numerous Safety and EMC CompliancesTwo year parts and labor warranty Models   12 Volt 24 Volt 32 Volt PT-7 PT-24-8W PT-32-25W PT-14W PT-24-13W   PT-25W PT-24-20U   PT-40U PT-24-45U   PT-80 PT-24-60W     PT-24-95U   Detailed specifications below.  Specifications   12 Volt Models PT-7 PT-14W PT-25W PT-40W PT-80 Input VAC (50-60 Hz.) 88-132 or 176-264 85-264 90-132 or 180-264 85-135 or 170-270 90-264 Input Amps @ Full Load   @ 115 VAC 2 2.8 6.5 8.5 12 @ 230 VAC 1 1.4 4 4.3 7 P.F. Rating >.65 .93@230V .98@115V .7 .7 .95@230V .98@115V Max Output Amps 7 14 25 40 80 Output Banks 2 3 3 3 3 Battery Capacity (Amp-Hours) 14-70 28-140 50-250 80-400 160-800 Operating Temp. Rating Reference T-1 T-2 T-4 T-5 T-7 Case Size Ref. A-1 A-2 A-2 A-3 A-5 Weight; Lbs./Kg. 3.2/1.5 8/4 8.2/4 12/6 15.2/7 Optional Temp.Sensor Model N/A TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 Remote Panel Model N/A RP RP RP RP Equalize Option No Yes Yes Yes Yes Output Indicator Ref. M-1 M-3 M-3 M-3 M-3 Compliance Ref. CG, CE CG, CE CG CG, CE CE    24 Volt Models PT-24-8W PT-24-13W PT-24-20U PT-24-45U PT-24-60W PT-24-95U Input VAC (50-60 Hz.) 85-264 90-132 or 180-264 85-135 or 170-270 90-264 207-253 90-264 Input Amps @ Full Load   @ 115 VAC 2.8 6.5 8.5 12 NA 26 @ 230 VAC 1.4 4 4.3 7 13 14 P.F. Rating .93@230V .98@115V .7 .7 .95@230V .98@115V .7 .95@230V .98@115V Max Output Amps 8 13 20 45 60 95 Output Banks 3 3 3 3 3 3 Battery Capacity (Amp-Hours) 16-80 26-130 40-200 90-450 120-600 180-950 Operating Temp. Rating Reference T-2 T-3 T-5 T-8 T-6 T-8 Case Size Ref. A-2 A-2 A-3 A-5 A-6 A-6 Weight; Lbs./Kg. 8/4 8.2/4 12/6 12.2/6 24.1/11 24.5/11 Optional Temp.Sensor Model TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 TP TCS-12/24 Remote Panel Model RP RP RP RP N/A RP Equalize Option Yes Yes Yes Yes No Yes Output Indicator Ref. M-3 M-3 M-3 M-3 M-2 M-3 Compliance Ref. CG, CE CG CG, CE EN, CE EN, CE EN, CE   32 Volt Model  PT-32-25W Input VAC (50-60 Hz.) 104-126 Input Amps @ Full Load    @ 115 VAC 15 @ 230 VAC N/A P.F. Rating .7 Max Output Amps 25 Output Banks 3 Battery Capacity (Amp-Hours) 50-250 Operating Temp. Rating Reference T-6 Case Size Ref. A-4 Weight; Lbs./Kg. 12.2/6 Optional Temp.Sensor Model TP Remote Panel Model N/A Equalize Option No Output Indicator Ref. M-2 Compliance Ref. EN, CE Case Size     Inches Centimeters Ref H W D H W D A-1 10.5 5.0 2.8 26.7 12.7 7.1 A-2 12.5 7.7 4.3 31.8 19.6 10.9 A-3 13.85* 9.5 4.8* 35.2* 24.1 12.2* A-4 13.8A 9.8 5A 35A 24.9 12.7A A-5 14.8B 9.6 5.6B 37.6B 24.4 14.2B A-6 17.5C 12 7.2C 44.5C 30.5 18.3C * Add .75" (1.9 cm) to height and 1.35" (3.4 cm) to depth A Add 1.27" (3.2 cm) to height and 1.1" (2.8 cm) to depth B Add 1" (2.54 cm) to height and .5" (1.27 cm) to depth C Add 2" (5.08 cm) to height and 1" (2.54 cm) to depth Temperature Rating References:   T-1 -10°C to +45°C; Derate linearly from 100% @ 0°C to 80% @ -10°C T-2 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-3 -10°C to +60°C; Derate linearly from 100% @ 50°C to 60% @ 60°C T-4 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-5 -40°C to +60°C; Derate linearly from 100% @ 50°C to 75% @ 60°C T-6 -20°C to +50°C; Full output T-7 -20°C to +70°C; Derate linearly from 100% @ 45°C to 50% @ 70°C T-8 -20°C to +70°C; Derate linearly from 100% @ 50°C to 50% @ 70°C Output Indicator References   M-1 Total output ammeter M-2 Charge/Float L.E.D. M-3 Total output ammeter and charger status L.E.D.'s/Alarms Compliance References* See matrix for applicable models CG USCG CFR 183.410 (Ignition protected) EN EN 60335-1, EN 60335-2-29 CE Carries the CE Mark * Numerous other Safety and EMC compliances may also apply. Contact factory if further compliance   information is required. Nominal Output Voltages at Gel/Flooded Switch Settings (Without Temperature Compensation option installed or at 22.2˚C (72˚F) with Temperature Compensation option installed.)     12 Volt Models 24 Volt Models 32 Volt Model Charge Float Charge Float Charge Float Setting @ 50% load @ .5 amp load @ 50% load @ .5 amp load @ 50% load @ .5 amp load Gel-Cell 14.0 VDC 13.6 VDC 28.0 VDC 27.2 VDC 37.3 VDC 36.2 VDC Flooded/AGM 14.2 VDC 13.4 VDC 28.4 VDC 26.8 VDC 37.8 VDC 35.7 VDC "Normalized SKU: PT7

Newmar POWER PAC 7AH Battery Chargers" Power-Pac Designed for critical applications such as VHF shore stations that must remain on the air, even during a power outage. The 12 volt supply features built-in back-up batteries which are charged during normal operation and then continue to power radios even when AC power is lost. Highly regulated, low ripple output for noise-free radio operation Battery automatically comes on-line if AC fails Low battery alarm and disconnect, with override switch for emergency power General Specifications Input 115/230 VAC, 50-60 Hz. Output:13.6 VDC @ 5A cont., 10A Int. Regulation: 1% line and load Ripple: 1% P-P Operating Temp: 0-40° C Models: Power-Pac 7 A/H (w/7 amp/hour battery), 18 lbs. Power-Pac 14 A/H (w/14 amp/hour battery), 24 lbs. Dimensions (both models): 5.3? H x 9.0? W x 10.5? D"Normalized SKU: POWERPAC7AHUPC Code: 360-2007-0

Newmar POWER PAC 14AH Battery Chargers" Power-Pac Designed for critical applications such as VHF shore stations that must remain on the air, even during a power outage. The 12 volt supply features built-in back-up batteries which are charged during normal operation and then continue to power radios even when AC power is lost. Highly regulated, low ripple output for noise-free radio operation Battery automatically comes on-line if AC fails Low battery alarm and disconnect, with override switch for emergency power General Specifications Input 115/230 VAC, 50-60 Hz. Output:13.6 VDC @ 5A cont., 10A Int. Regulation: 1% line and load Ripple: 1% P-P Operating Temp: 0-40° C Models: Power-Pac 7 A/H (w/7 amp/hour battery), 18 lbs. Power-Pac 14 A/H (w/14 amp/hour battery), 24 lbs. Dimensions (both models): 5.3? H x 9.0? W x 10.5? D"Normalized SKU: POWERPAC14AHUPC Code: 360-2014-0

ACR Electronics 2815 Battery ChargersACR Ectronics Rapid Charger #2815Normalized SKU: 2815UPC Code: 791659028155

Analytic Systems BCH10W-24 Battery ChargersWaterproof IP66 DC Battery Charger 10A, 24V Out, 30-80V In, RuggedizedThe BCH10 Step Down series of Battery Chargers supply up to 10 amps of charging current at 12, 24, 36 or 48 volts from any higher voltage between 20 and 80 volts DC in an IP66 rated watertight and EMC shielded enclosure for use in automotive, heavy equipment, marine, industrial, rail or alternative energy environments. The output voltage is configured to allow permanent connection to the battery.The standard BCH10W model offers a Deutsch connector on a pigtail input/output cable, and the military grade BCH10MW features separate bayonet style MIL connectors for input and output.The all surface mount high frequency design offers higher reliability, higher efficiency (more than 91%), more power (up to 544 watts at 48 VDC Out) and minimum size.The BCH10MW is rated for operation from -40 to +55 degrees C and has been tested and confirmed to meet MIL-STD-461F for radiated and conducted emissions. It is designed to meet MIL-STD-810G for shock and vibration.The unit has reverse input protection, reverse battery connection protection, output over-voltage protection and features spark free connection to the battery. Smart Ideal Diode output circuitry prevents any reverse current flowing from the battery back into the converter.Features: Watertight O-ring sealed and EMC gasketed enclosure ‘Output ON’ and “Charging” LED indicators Up to 80V input Compact size and easy mounting Deutsch DT04-4P connector on pigtail or MIL connectors Heavy duty ruggedization with wide temperature range Custom output voltages available Custom connector arrangements Input and output EMC filters Two year warranty (parts and labor) Specifications:Amps Per Bank = NONE Battery Type = NONE Charger Input - Voltage = 30-80 VDC Charger Output - Amps = 10 Charger Output Voltage = 24 VDC Charger Type = NONE Charging Banks = NONE Portable = NONENormalized SKU: BCH10W24

Analytic Systems VCH10W-24 Battery ChargersWaterproof IP66 DC Converter 10A, 24V Out, 30-80V In, RuggedizedThe VCH10 Step Down series of Voltage Converters supply up to 10 amps of output current at 12, 24, 36 or 48 volts from any higher voltage between 20 and 80 volts DC in an IP66 rated watertight and EMC shielded enclosure for use in rugged environments.The standard VCH10W model offers a Deutsch connector on a pigtail input/output cable, and the military grade VCH10MW features separate bayonet style MIL connectors for input and output.The all surface mount high frequency design offers higher reliability, higher efficiency (more than 92%), more power (up to 544 watts at 48 VDC Out) and minimum size.The VCH10MW is rated for operation from -40 to +55 degrees C and has been tested and confirmed to meet MIL-STD-461F for radiated and conducted emissions. It is designed to meet MIL-STD-810G for shock and vibration.The unit has reverse input protection, output current limiting and output over-voltage protection.Features: Watertight O-ring sealed and EMC gasketed enclosure MIL connectors ‘Output ON’ and ‘Overload’ LED indicators Compact size and easy mounting Up to 80V input Heavy duty ruggedization with wide temperature range Paralleling diodes Custom output voltages available Two year warranty (parts and labor) Specifications:Amps Per Bank = NONE Battery Type = NONE Charger Input - Voltage = 30-80 VDC Charger Output - Amps = 10 Charger Output Voltage = 32 VDC Charger Type = NONE Charging Banks = NONE Portable = NONENormalized SKU: VCH10W24

Analytic Systems VCH10W-12 Battery ChargersWaterproof IP66 DC Converter 10A, 12V Out 20-80V In, RuggedizedThe VCH10 Step Down series of Voltage Converters supply up to 10 amps of output current at 12, 24, 36 or 48 volts from any higher voltage between 20 and 80 volts DC in an IP66 rated watertight and EMC shielded enclosure for use in rugged environments.The standard VCH10W model offers a Deutsch connector on a pigtail input/output cable, and the military grade VCH10MW features separate bayonet style MIL connectors for input and output.The all surface mount high frequency design offers higher reliability, higher efficiency (more than 92%), more power (up to 544 watts at 48 VDC Out) and minimum size.The VCH10MW is rated for operation from -40 to +55 degrees C and has been tested and confirmed to meet MIL-STD-461F for radiated and conducted emissions. It is designed to meet MIL-STD-810G for shock and vibration.The unit has reverse input protection, output current limiting and output over-voltage protection.Features: Watertight O-ring sealed and EMC gasketed enclosure MIL connectors ‘Output ON’ and ‘Overload’ LED indicators Compact size and easy mounting Up to 80V input Heavy duty ruggedization with wide temperature range Paralleling diodes Custom output voltages available Two year warranty (parts and labor) Specifications:Amps Per Bank = NONE Battery Type = NONE Charger Input - Voltage = 20-80 VDC Charger Output - Amps = 10 Charger Output Voltage = 12 VDC Charger Type = NONE Charging Banks = NONE Portable = NONENormalized SKU: VCH10W12
