Battery Tender 022-0150-DL-WH Battery ChargersThis 5 amp, 12 volt charger is made primarily for use with dry cell applications such as the Odyssey Battery. It can also be used on automotive batteries.Normalized SKU: 0220150DLWHUPC Code: 203300001702

Newmar PT-24-60W Battery Chargers PT-24-60W Battery Charger “Smart” marine battery charging technology for 24V systems aboard workboats, military vessels, commercial vessels, and recreational craft. This charger interacts with batteries, providing the optimum three-stage charge process for fast recovery and conditioning, maximizing performance, and extending battery life. A selector switch adjusts output voltage to adapt to gel-cell, flooded lead-acid, or AGM battery types. An optional temperature compensation sensor also adjusts output for ideal voltage based on changes in the batteries’ ambient temperature. All models are housed in a rugged stainless steel case with a durable white powder coat finish, and the internal circuitry is polyurethane coated for maximum corrosion resistance. Features: 24V model “Smart” circuitry provides three-stage charging – bulk, absorption, float Gel-cell/Flooded Lead-acid/AGM battery type switch selects optimum charge/float voltages Multiple isolated output banks; ammeter indicates total output current The optional sensor adjusts output voltage based on battery temperature Current limiting prevents damage from overloading Use as a power supply; can power loads without a battery in line Built to last – rugged stainless steel case with a durable white powder coat finish with an optional drip shield and marinized internal circuitry Protection: Current Limiting, Thermal Protection, Forced Air Cooling, Drip Shield Install in conjunction with PT-MCU for additional control and monitoring ABS type approval for battery charging and power supplies Specifications: Input VAC (50-60 Hz.): 207-253 Input Amps @ Full Load: @ 115 VAC: NA, @ 230 VAC: 13 Power Factor: .7 Max Output Amps: 60 Output Banks: 3 Battery Capacity (Amp-Hours): 120-600     Operating Temp. Rating Reference: T-4 Case Size Reference: A-5 Case Size (H x W x D): 17.5E x 12 x 7.2E inches (44.5E x 30.5 x 18.3E centimeters) *Note with Dripshield installed E add 2” (5.08 cm) to height and 1” (2.54 cm) to depth Weight Lbs./Kg: 24.1/11 Optional Temp. Sensor Model: TP     Remote Panel Model: N/A Compliance Reference: EN, CE, ABS Temperature Rating References: Temperature: -20 degrees C to +50 degrees C     Derate Linearly From Full output Nominal Output Voltages at Gel/Flooded Switch Settings (without Temperature Compensation): Gel-Cell: 28.0 VDC Charge @ 50% load and 27.2 VDC Float @ .5 amp load Flooded/AGM: 28.4 VDC Charge @ 50% load and 26.8 VDC Float @ .5 amp load Compliance References: UL: UL 1950 (per DNB report) CG: USCG CFR 183.410 (Ignition protected) EN: EN 60335-1 CE: Carries the CE mark ABS: PT Series meets SVR 2009 4-8-3/5.9, Under 90 meters Rules 2006 4-6-4/7.19, and HSNC 2007 4-8-3/5.13. This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.   Models  12 Volt 24 Volt 32 Volt PT-7 PT-24-8W PT-32-25W PT-14W PT-24-13W   PT-25W PT-24-20U   PT-40U PT-24-45U   PT-80 PT-24-60W     PT-24-95U   Detailed specifications below.   Specifications  12 Volt Models PT-7 PT-14W PT-25W PT-40W PT-80 Input VAC (50-60 Hz.) 88-132 or 176-264 85-264 90-132 or 180-264 85-135 or 170-270 90-264 Input Amps @ Full Load   @ 115 VAC 2 2.8 6.5 8.5 12 @ 230 VAC 1 1.4 4 4.3 7 P.F. Rating >.65 .93@230V.98@115V .7 .7 .95@230V.98@115V Max Output Amps 7 14 25 40 80 Output Banks 2 3 3 3 3 Battery Capacity (Amp-Hours) 14-70 28-140 50-250 80-400 160-800 Operating Temp.Rating Reference T-1 T-2 T-4 T-5 T-7 Case Size Ref. A-1 A-2 A-2 A-3 A-5 Weight; Lbs./Kg. 3.2/1.5 8/4 8.2/4 12/6 15.2/7 Optional Temp.Sensor Model N/A TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 Remote Panel Model N/A RP RP RP RP Equalize Option No Yes Yes Yes Yes Output Indicator Ref. M-1 M-3 M-3 M-3 M-3 Compliance Ref. CG, CE CG, CE CG CG, CE CE    24 Volt Models PT-24-8W PT-24-13W PT-24-20U PT-24-45U PT-24-60W PT-24-95U Input VAC (50-60 Hz.) 85-264 90-132 or 180-264 85-135 or 170-270 90-264 207-253 90-264 Input Amps @ Full Load   @ 115 VAC 2.8 6.5 8.5 12 NA 26 @ 230 VAC 1.4 4 4.3 7 13 14 P.F. Rating .93@230V.98@115V .7 .7 .95@230V.98@115V .7 .95@230V.98@115V Max Output Amps 8 13 20 45 60 95 Output Banks 3 3 3 3 3 3 Battery Capacity (Amp-Hours) 16-80 26-130 40-200 90-450 120-600 180-950 Operating Temp.Rating Reference T-2 T-3 T-5 T-8 T-6 T-8 Case Size Ref. A-2 A-2 A-3 A-5 A-6 A-6 Weight; Lbs./Kg. 8/4 8.2/4 12/6 12.2/6 24.1/11 24.5/11 Optional Temp.Sensor Model TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 TP TCS-12/24 Remote Panel Model RP RP RP RP N/A RP Equalize Option Yes Yes Yes Yes No Yes Output Indicator Ref. M-3 M-3 M-3 M-3 M-2 M-3 Compliance Ref. CG, CE CG CG, CE EN, CE EN, CE EN, CE   32 Volt Model  PT-32-25W Input VAC (50-60 Hz.) 104-126 Input Amps @ Full Load    @ 115 VAC 15 @ 230 VAC N/A P.F. Rating .7 Max Output Amps 25 Output Banks 3 Battery Capacity (Amp-Hours) 50-250 Operating Temp.Rating Reference T-6 Case Size Ref. A-4 Weight; Lbs./Kg. 12.2/6 Optional Temp.Sensor Model TP Remote Panel Model N/A Equalize Option No Output Indicator Ref. M-2 Compliance Ref. EN, CE Case Size    Inches Centimeters Ref H W D H W D A-1 10.5 5.0 2.8 26.7 12.7 7.1 A-2 12.5 7.7 4.3 31.8 19.6 10.9 A-3 13.85* 9.5 4.8* 35.2* 24.1 12.2* A-4 13.8A 9.8 5A 35A 24.9 12.7A A-5 14.8B 9.6 5.6B 37.6B 24.4 14.2B A-6 17.5C 12 7.2C 44.5C 30.5 18.3C * Add .75" (1.9 cm) to height and 1.35" (3.4 cm) to depthA Add 1.27" (3.2 cm) to height and 1.1" (2.8 cm) to depthB Add 1" (2.54 cm) to height and .5" (1.27 cm) to depthC Add 2" (5.08 cm) to height and 1" (2.54 cm) to depth Temperature Rating References:  T-1 -10°C to +45°C; Derate linearly from 100% @ 0°C to 80% @ -10°C T-2 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-3 -10°C to +60°C; Derate linearly from 100% @ 50°C to 60% @ 60°C T-4 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-5 -40°C to +60°C; Derate linearly from 100% @ 50°C to 75% @ 60°C T-6 -20°C to +50°C; Full output T-7 -20°C to +70°C; Derate linearly from 100% @ 45°C to 50% @ 70°C T-8 -20°C to +70°C; Derate linearly from 100% @ 50°C to 50% @ 70°C Output Indicator References  M-1 Total output ammeter M-2 Charge/Float L.E.D. M-3 Total output ammeter and charger status L.E.D.'s/Alarms Compliance References*See matrix for applicable modelsCG USCG CFR 183.410 (Ignition protected)EN EN 60335-1, EN 60335-2-29CE Carries the CE Mark* Numerous other Safety and EMC compliances may also apply. Contact factory if further compliance  information is required.Nominal Output Voltages at Gel/Flooded Switch Settings(Without Temperature Compensation option installed or at 22.2˚C (72˚F) with TemperatureCompensation option installed.)    12 Volt Models 24 Volt Models 32 Volt Model Charge Float Charge Float Charge Float Setting @ 50% load @ .5 amp load @ 50% load @ .5 amp load @ 50% load @ .5 amp load Gel-Cell 14.0 VDC 13.6 VDC 28.0 VDC 27.2 VDC 37.3 VDC 36.2 VDC Flooded/AGM 14.2 VDC 13.4 VDC 28.4 VDC 26.8 VDC 37.8 VDC 35.7 VDC Normalized SKU: PT2460WUPC Code: 012302330563

Newmar PT-24-8W Battery Chargers"Three Stage "Smart" Chargers Phase Three "Smart" battery charging technology is now available in a wide range of power levels, allowing you to select the right size, features and flexibility you require for virtually any application from small recreational craft to large live-aboards, workboats and other commercial vessels. These chargers interact with batteries to put them through the optimum three stage charge process which provides for fastest recovery and ideal conditioning, maximizing battery performance and extending battery life. A selector switch adjusts output voltage to adapt for gel-cell/flooded lead-acid/AGM battery types. An optional temperature compensation sensor also adjusts output for ideal voltage based on changes in the batteries' ambient temperature. All models are housed in a rugged stainless steel case with a durable white powder coat finish, and the internal circuitry is polyurethane coated for maximum corrosion resistance. Features "Smart" circuitry provides three stage charging?bulk, absorption, float. Wide model range covers battery system ratings from 14-950 amp-hours Gel-Cell/Flooded Lead-acid/AGM battery type switch selects optimum charge/float voltages. Multiple isolated output banks; ammeter indicates total output current. (except PT-7) Optional sensor adjusts output voltage based on battery temperature. (except PT-7) Current limiting-prevents damage from overloading. Charger status clearly displayed with L.E.D. and/or audible indicators or optional remote panel. Use as a power supply; can power loads without a battery in line. Built to last?rugged stainless steel case with a durable white powder coat finish with an optional drip shield and marinized internal circuitry. Numerous Safety and EMC CompliancesTwo year parts and labor warranty Models   12 Volt 24 Volt 32 Volt PT-7 PT-24-8W PT-32-25W PT-14W PT-24-13W   PT-25W PT-24-20U   PT-40U PT-24-45U   PT-80 PT-24-60W     PT-24-95U   Detailed specifications below.  Specifications   12 Volt Models PT-7 PT-14W PT-25W PT-40W PT-80 Input VAC (50-60 Hz.) 88-132 or 176-264 85-264 90-132 or 180-264 85-135 or 170-270 90-264 Input Amps @ Full Load   @ 115 VAC 2 2.8 6.5 8.5 12 @ 230 VAC 1 1.4 4 4.3 7 P.F. Rating >.65 .93@230V .98@115V .7 .7 .95@230V .98@115V Max Output Amps 7 14 25 40 80 Output Banks 2 3 3 3 3 Battery Capacity (Amp-Hours) 14-70 28-140 50-250 80-400 160-800 Operating Temp. Rating Reference T-1 T-2 T-4 T-5 T-7 Case Size Ref. A-1 A-2 A-2 A-3 A-5 Weight; Lbs./Kg. 3.2/1.5 8/4 8.2/4 12/6 15.2/7 Optional Temp.Sensor Model N/A TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 Remote Panel Model N/A RP RP RP RP Equalize Option No Yes Yes Yes Yes Output Indicator Ref. M-1 M-3 M-3 M-3 M-3 Compliance Ref. CG, CE CG, CE CG CG, CE CE    24 Volt Models PT-24-8W PT-24-13W PT-24-20U PT-24-45U PT-24-60W PT-24-95U Input VAC (50-60 Hz.) 85-264 90-132 or 180-264 85-135 or 170-270 90-264 207-253 90-264 Input Amps @ Full Load   @ 115 VAC 2.8 6.5 8.5 12 NA 26 @ 230 VAC 1.4 4 4.3 7 13 14 P.F. Rating .93@230V .98@115V .7 .7 .95@230V .98@115V .7 .95@230V .98@115V Max Output Amps 8 13 20 45 60 95 Output Banks 3 3 3 3 3 3 Battery Capacity (Amp-Hours) 16-80 26-130 40-200 90-450 120-600 180-950 Operating Temp. Rating Reference T-2 T-3 T-5 T-8 T-6 T-8 Case Size Ref. A-2 A-2 A-3 A-5 A-6 A-6 Weight; Lbs./Kg. 8/4 8.2/4 12/6 12.2/6 24.1/11 24.5/11 Optional Temp.Sensor Model TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 TP TCS-12/24 Remote Panel Model RP RP RP RP N/A RP Equalize Option Yes Yes Yes Yes No Yes Output Indicator Ref. M-3 M-3 M-3 M-3 M-2 M-3 Compliance Ref. CG, CE CG CG, CE EN, CE EN, CE EN, CE   32 Volt Model  PT-32-25W Input VAC (50-60 Hz.) 104-126 Input Amps @ Full Load    @ 115 VAC 15 @ 230 VAC N/A P.F. Rating .7 Max Output Amps 25 Output Banks 3 Battery Capacity (Amp-Hours) 50-250 Operating Temp. Rating Reference T-6 Case Size Ref. A-4 Weight; Lbs./Kg. 12.2/6 Optional Temp.Sensor Model TP Remote Panel Model N/A Equalize Option No Output Indicator Ref. M-2 Compliance Ref. EN, CE Case Size     Inches Centimeters Ref H W D H W D A-1 10.5 5.0 2.8 26.7 12.7 7.1 A-2 12.5 7.7 4.3 31.8 19.6 10.9 A-3 13.85* 9.5 4.8* 35.2* 24.1 12.2* A-4 13.8A 9.8 5A 35A 24.9 12.7A A-5 14.8B 9.6 5.6B 37.6B 24.4 14.2B A-6 17.5C 12 7.2C 44.5C 30.5 18.3C * Add .75" (1.9 cm) to height and 1.35" (3.4 cm) to depth A Add 1.27" (3.2 cm) to height and 1.1" (2.8 cm) to depth B Add 1" (2.54 cm) to height and .5" (1.27 cm) to depth C Add 2" (5.08 cm) to height and 1" (2.54 cm) to depth Temperature Rating References:   T-1 -10°C to +45°C; Derate linearly from 100% @ 0°C to 80% @ -10°C T-2 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-3 -10°C to +60°C; Derate linearly from 100% @ 50°C to 60% @ 60°C T-4 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-5 -40°C to +60°C; Derate linearly from 100% @ 50°C to 75% @ 60°C T-6 -20°C to +50°C; Full output T-7 -20°C to +70°C; Derate linearly from 100% @ 45°C to 50% @ 70°C T-8 -20°C to +70°C; Derate linearly from 100% @ 50°C to 50% @ 70°C Output Indicator References   M-1 Total output ammeter M-2 Charge/Float L.E.D. M-3 Total output ammeter and charger status L.E.D.'s/Alarms Compliance References* See matrix for applicable models CG USCG CFR 183.410 (Ignition protected) EN EN 60335-1, EN 60335-2-29 CE Carries the CE Mark * Numerous other Safety and EMC compliances may also apply. Contact factory if further compliance   information is required. Nominal Output Voltages at Gel/Flooded Switch Settings (Without Temperature Compensation option installed or at 22.2˚C (72˚F) with Temperature Compensation option installed.)     12 Volt Models 24 Volt Models 32 Volt Model Charge Float Charge Float Charge Float Setting @ 50% load @ .5 amp load @ 50% load @ .5 amp load @ 50% load @ .5 amp load Gel-Cell 14.0 VDC 13.6 VDC 28.0 VDC 27.2 VDC 37.3 VDC 36.2 VDC Flooded/AGM 14.2 VDC 13.4 VDC 28.4 VDC 26.8 VDC 37.8 VDC 35.7 VDC "Normalized SKU: PT248W

Newmar PT-25W Battery Chargers"Three Stage "Smart" Chargers Phase Three "Smart" battery charging technology is now available in a wide range of power levels, allowing you to select the right size, features and flexibility you require for virtually any application from small recreational craft to large live-aboards, workboats and other commercial vessels. These chargers interact with batteries to put them through the optimum three stage charge process which provides for fastest recovery and ideal conditioning, maximizing battery performance and extending battery life. A selector switch adjusts output voltage to adapt for gel-cell/flooded lead-acid/AGM battery types. An optional temperature compensation sensor also adjusts output for ideal voltage based on changes in the batteries' ambient temperature. All models are housed in a rugged stainless steel case with a durable white powder coat finish, and the internal circuitry is polyurethane coated for maximum corrosion resistance. Features "Smart" circuitry provides three stage charging?bulk, absorption, float. Wide model range covers battery system ratings from 14-950 amp-hours Gel-Cell/Flooded Lead-acid/AGM battery type switch selects optimum charge/float voltages. Multiple isolated output banks; ammeter indicates total output current. (except PT-7) Optional sensor adjusts output voltage based on battery temperature. (except PT-7) Current limiting-prevents damage from overloading. Charger status clearly displayed with L.E.D. and/or audible indicators or optional remote panel. Use as a power supply; can power loads without a battery in line. Built to last?rugged stainless steel case with a durable white powder coat finish with an optional drip shield and marinized internal circuitry. Numerous Safety and EMC CompliancesTwo year parts and labor warranty Models   12 Volt 24 Volt 32 Volt PT-7 PT-24-8W PT-32-25W PT-14W PT-24-13W   PT-25W PT-24-20U   PT-40U PT-24-45U   PT-80 PT-24-60W     PT-24-95U   Detailed specifications below.  Specifications   12 Volt Models PT-7 PT-14W PT-25W PT-40W PT-80 Input VAC (50-60 Hz.) 88-132 or 176-264 85-264 90-132 or 180-264 85-135 or 170-270 90-264 Input Amps @ Full Load   @ 115 VAC 2 2.8 6.5 8.5 12 @ 230 VAC 1 1.4 4 4.3 7 P.F. Rating >.65 .93@230V .98@115V .7 .7 .95@230V .98@115V Max Output Amps 7 14 25 40 80 Output Banks 2 3 3 3 3 Battery Capacity (Amp-Hours) 14-70 28-140 50-250 80-400 160-800 Operating Temp. Rating Reference T-1 T-2 T-4 T-5 T-7 Case Size Ref. A-1 A-2 A-2 A-3 A-5 Weight; Lbs./Kg. 3.2/1.5 8/4 8.2/4 12/6 15.2/7 Optional Temp.Sensor Model N/A TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 Remote Panel Model N/A RP RP RP RP Equalize Option No Yes Yes Yes Yes Output Indicator Ref. M-1 M-3 M-3 M-3 M-3 Compliance Ref. CG, CE CG, CE CG CG, CE CE    24 Volt Models PT-24-8W PT-24-13W PT-24-20U PT-24-45U PT-24-60W PT-24-95U Input VAC (50-60 Hz.) 85-264 90-132 or 180-264 85-135 or 170-270 90-264 207-253 90-264 Input Amps @ Full Load   @ 115 VAC 2.8 6.5 8.5 12 NA 26 @ 230 VAC 1.4 4 4.3 7 13 14 P.F. Rating .93@230V .98@115V .7 .7 .95@230V .98@115V .7 .95@230V .98@115V Max Output Amps 8 13 20 45 60 95 Output Banks 3 3 3 3 3 3 Battery Capacity (Amp-Hours) 16-80 26-130 40-200 90-450 120-600 180-950 Operating Temp. Rating Reference T-2 T-3 T-5 T-8 T-6 T-8 Case Size Ref. A-2 A-2 A-3 A-5 A-6 A-6 Weight; Lbs./Kg. 8/4 8.2/4 12/6 12.2/6 24.1/11 24.5/11 Optional Temp.Sensor Model TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 TP TCS-12/24 Remote Panel Model RP RP RP RP N/A RP Equalize Option Yes Yes Yes Yes No Yes Output Indicator Ref. M-3 M-3 M-3 M-3 M-2 M-3 Compliance Ref. CG, CE CG CG, CE EN, CE EN, CE EN, CE   32 Volt Model  PT-32-25W Input VAC (50-60 Hz.) 104-126 Input Amps @ Full Load    @ 115 VAC 15 @ 230 VAC N/A P.F. Rating .7 Max Output Amps 25 Output Banks 3 Battery Capacity (Amp-Hours) 50-250 Operating Temp. Rating Reference T-6 Case Size Ref. A-4 Weight; Lbs./Kg. 12.2/6 Optional Temp.Sensor Model TP Remote Panel Model N/A Equalize Option No Output Indicator Ref. M-2 Compliance Ref. EN, CE Case Size     Inches Centimeters Ref H W D H W D A-1 10.5 5.0 2.8 26.7 12.7 7.1 A-2 12.5 7.7 4.3 31.8 19.6 10.9 A-3 13.85* 9.5 4.8* 35.2* 24.1 12.2* A-4 13.8A 9.8 5A 35A 24.9 12.7A A-5 14.8B 9.6 5.6B 37.6B 24.4 14.2B A-6 17.5C 12 7.2C 44.5C 30.5 18.3C * Add .75" (1.9 cm) to height and 1.35" (3.4 cm) to depth A Add 1.27" (3.2 cm) to height and 1.1" (2.8 cm) to depth B Add 1" (2.54 cm) to height and .5" (1.27 cm) to depth C Add 2" (5.08 cm) to height and 1" (2.54 cm) to depth Temperature Rating References:   T-1 -10°C to +45°C; Derate linearly from 100% @ 0°C to 80% @ -10°C T-2 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-3 -10°C to +60°C; Derate linearly from 100% @ 50°C to 60% @ 60°C T-4 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-5 -40°C to +60°C; Derate linearly from 100% @ 50°C to 75% @ 60°C T-6 -20°C to +50°C; Full output T-7 -20°C to +70°C; Derate linearly from 100% @ 45°C to 50% @ 70°C T-8 -20°C to +70°C; Derate linearly from 100% @ 50°C to 50% @ 70°C Output Indicator References   M-1 Total output ammeter M-2 Charge/Float L.E.D. M-3 Total output ammeter and charger status L.E.D.'s/Alarms Compliance References* See matrix for applicable models CG USCG CFR 183.410 (Ignition protected) EN EN 60335-1, EN 60335-2-29 CE Carries the CE Mark * Numerous other Safety and EMC compliances may also apply. Contact factory if further compliance   information is required. Nominal Output Voltages at Gel/Flooded Switch Settings (Without Temperature Compensation option installed or at 22.2˚C (72˚F) with Temperature Compensation option installed.)     12 Volt Models 24 Volt Models 32 Volt Model Charge Float Charge Float Charge Float Setting @ 50% load @ .5 amp load @ 50% load @ .5 amp load @ 50% load @ .5 amp load Gel-Cell 14.0 VDC 13.6 VDC 28.0 VDC 27.2 VDC 37.3 VDC 36.2 VDC Flooded/AGM 14.2 VDC 13.4 VDC 28.4 VDC 26.8 VDC 37.8 VDC 35.7 VDC "Normalized SKU: PT25W

Newmar PT40U Battery Chargers"Three Stage "Smart" Chargers Phase Three "Smart" battery charging technology is now available in a wide range of power levels, allowing you to select the right size, features and flexibility you require for virtually any application from small recreational craft to large live-aboards, workboats and other commercial vessels. These chargers interact with batteries to put them through the optimum three stage charge process which provides for fastest recovery and ideal conditioning, maximizing battery performance and extending battery life. A selector switch adjusts output voltage to adapt for gel-cell/flooded lead-acid/AGM battery types. An optional temperature compensation sensor also adjusts output for ideal voltage based on changes in the batteries' ambient temperature. All models are housed in a rugged stainless steel case with a durable white powder coat finish, and the internal circuitry is polyurethane coated for maximum corrosion resistance. Features "Smart" circuitry provides three stage charging?bulk, absorption, float. Wide model range covers battery system ratings from 14-950 amp-hours Gel-Cell/Flooded Lead-acid/AGM battery type switch selects optimum charge/float voltages. Multiple isolated output banks; ammeter indicates total output current. (except PT-7) Optional sensor adjusts output voltage based on battery temperature. (except PT-7) Current limiting-prevents damage from overloading. Charger status clearly displayed with L.E.D. and/or audible indicators or optional remote panel. Use as a power supply; can power loads without a battery in line. Built to last?rugged stainless steel case with a durable white powder coat finish with an optional drip shield and marinized internal circuitry. Numerous Safety and EMC CompliancesTwo year parts and labor warranty Models   12 Volt 24 Volt 32 Volt PT-7 PT-24-8W PT-32-25W PT-14W PT-24-13W   PT-25W PT-24-20U   PT-40U PT-24-45U   PT-80 PT-24-60W     PT-24-95U   Detailed specifications below.  Specifications   12 Volt Models PT-7 PT-14W PT-25W PT-40W PT-80 Input VAC (50-60 Hz.) 88-132 or 176-264 85-264 90-132 or 180-264 85-135 or 170-270 90-264 Input Amps @ Full Load   @ 115 VAC 2 2.8 6.5 8.5 12 @ 230 VAC 1 1.4 4 4.3 7 P.F. Rating >.65 .93@230V .98@115V .7 .7 .95@230V .98@115V Max Output Amps 7 14 25 40 80 Output Banks 2 3 3 3 3 Battery Capacity (Amp-Hours) 14-70 28-140 50-250 80-400 160-800 Operating Temp. Rating Reference T-1 T-2 T-4 T-5 T-7 Case Size Ref. A-1 A-2 A-2 A-3 A-5 Weight; Lbs./Kg. 3.2/1.5 8/4 8.2/4 12/6 15.2/7 Optional Temp.Sensor Model N/A TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 Remote Panel Model N/A RP RP RP RP Equalize Option No Yes Yes Yes Yes Output Indicator Ref. M-1 M-3 M-3 M-3 M-3 Compliance Ref. CG, CE CG, CE CG CG, CE CE    24 Volt Models PT-24-8W PT-24-13W PT-24-20U PT-24-45U PT-24-60W PT-24-95U Input VAC (50-60 Hz.) 85-264 90-132 or 180-264 85-135 or 170-270 90-264 207-253 90-264 Input Amps @ Full Load   @ 115 VAC 2.8 6.5 8.5 12 NA 26 @ 230 VAC 1.4 4 4.3 7 13 14 P.F. Rating .93@230V .98@115V .7 .7 .95@230V .98@115V .7 .95@230V .98@115V Max Output Amps 8 13 20 45 60 95 Output Banks 3 3 3 3 3 3 Battery Capacity (Amp-Hours) 16-80 26-130 40-200 90-450 120-600 180-950 Operating Temp. Rating Reference T-2 T-3 T-5 T-8 T-6 T-8 Case Size Ref. A-2 A-2 A-3 A-5 A-6 A-6 Weight; Lbs./Kg. 8/4 8.2/4 12/6 12.2/6 24.1/11 24.5/11 Optional Temp.Sensor Model TCS-12/24 TCS-12/24 TCS-12/24 TCS-12/24 TP TCS-12/24 Remote Panel Model RP RP RP RP N/A RP Equalize Option Yes Yes Yes Yes No Yes Output Indicator Ref. M-3 M-3 M-3 M-3 M-2 M-3 Compliance Ref. CG, CE CG CG, CE EN, CE EN, CE EN, CE   32 Volt Model  PT-32-25W Input VAC (50-60 Hz.) 104-126 Input Amps @ Full Load    @ 115 VAC 15 @ 230 VAC N/A P.F. Rating .7 Max Output Amps 25 Output Banks 3 Battery Capacity (Amp-Hours) 50-250 Operating Temp. Rating Reference T-6 Case Size Ref. A-4 Weight; Lbs./Kg. 12.2/6 Optional Temp.Sensor Model TP Remote Panel Model N/A Equalize Option No Output Indicator Ref. M-2 Compliance Ref. EN, CE Case Size     Inches Centimeters Ref H W D H W D A-1 10.5 5.0 2.8 26.7 12.7 7.1 A-2 12.5 7.7 4.3 31.8 19.6 10.9 A-3 13.85* 9.5 4.8* 35.2* 24.1 12.2* A-4 13.8A 9.8 5A 35A 24.9 12.7A A-5 14.8B 9.6 5.6B 37.6B 24.4 14.2B A-6 17.5C 12 7.2C 44.5C 30.5 18.3C * Add .75" (1.9 cm) to height and 1.35" (3.4 cm) to depth A Add 1.27" (3.2 cm) to height and 1.1" (2.8 cm) to depth B Add 1" (2.54 cm) to height and .5" (1.27 cm) to depth C Add 2" (5.08 cm) to height and 1" (2.54 cm) to depth Temperature Rating References:   T-1 -10°C to +45°C; Derate linearly from 100% @ 0°C to 80% @ -10°C T-2 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-3 -10°C to +60°C; Derate linearly from 100% @ 50°C to 60% @ 60°C T-4 -10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C T-5 -40°C to +60°C; Derate linearly from 100% @ 50°C to 75% @ 60°C T-6 -20°C to +50°C; Full output T-7 -20°C to +70°C; Derate linearly from 100% @ 45°C to 50% @ 70°C T-8 -20°C to +70°C; Derate linearly from 100% @ 50°C to 50% @ 70°C Output Indicator References   M-1 Total output ammeter M-2 Charge/Float L.E.D. M-3 Total output ammeter and charger status L.E.D.'s/Alarms Compliance References* See matrix for applicable models CG USCG CFR 183.410 (Ignition protected) EN EN 60335-1, EN 60335-2-29 CE Carries the CE Mark * Numerous other Safety and EMC compliances may also apply. Contact factory if further compliance   information is required. Nominal Output Voltages at Gel/Flooded Switch Settings (Without Temperature Compensation option installed or at 22.2˚C (72˚F) with Temperature Compensation option installed.)     12 Volt Models 24 Volt Models 32 Volt Model Charge Float Charge Float Charge Float Setting @ 50% load @ .5 amp load @ 50% load @ .5 amp load @ 50% load @ .5 amp load Gel-Cell 14.0 VDC 13.6 VDC 28.0 VDC 27.2 VDC 37.3 VDC 36.2 VDC Flooded/AGM 14.2 VDC 13.4 VDC 28.4 VDC 26.8 VDC 37.8 VDC 35.7 VDC "Normalized SKU: PT40UUPC Code: 445-5210-0
