Powermania
Powermania Powermania Charger 2-Bank 12a #58301
$189.00
$221.75
Powermania 58301 Battery ChargersTurbo M212V3 15 Amp 2-Bank 12/24VDC Waterproof ChargerFeatures:
All aluminum and epoxy seal construction for optimal efficiency
Charge fully drained 0 volt batteries
Allocate more power to weaker bank
100% output at 90V AC
Auto Switching 120/240 AC Input
Three selectable battery type settings
Normalized SKU: 58301UPC Code: 859321002527
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Powermania
Powermania Powermania Charger 3-Bank 20a #58304
$269.00
$299.99
Powermania 58304 Battery ChargersTurbo M320V3 20 Amp 3-Bank 12/24/36VDC Waterproof ChargerFeatures:
All aluminum and epoxy seal construction for optimal efficiency
Charge fully drained 0 volt batteries
Allocate more power to weaker bank
100% output at 90V AC
Auto Switching 120/240 AC Input
Three selectable battery type settings
Normalized SKU: 58304
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Mastervolt
Mastervolt Mass Combi 24v 2600w 60a 230v #36022600
$2,928.24
$3,303.05
Download LiteratureMastervolt 36022600 Battery ChargersMass Combi 24/2600-60 (230V)Continuous power and peace of mind in all conditionsThe renewed Mass Combi offers the best price/quality ratio. Based on the exceptionally reliable Mass Combiseries, the four new models now offer even more power at a highly competitive price. In addition, they arealso available in two customer-friendly variations with remote control or MasterBus.The powerful 3-step+ battery charger guarantees maximum battery life and can simultaneously charge twobattery banks. The inverter with high peak power starts even the heaviest loads, with the Mass Combi12/1600 being easily sufficient for your espresso machine. A built-in distribution system switches betweengrid and inverter power, while two separate AC outputs allow users to connect critical loads to a preferredgroup.Grid connected solar power system with energy storageThe Mass Combi enables the expansion of a grid connected solar power system with energy storage inbatteries. This way the majority of the generated energy is used, and users are less dependent on theelectricity grid. In this setup, the Mass Combi is part of a MasterBus controlled system.The benefits of the improved Mass Combi:
Compact, lightweight and no hum thanks to HF technology
High yield and more power from your batteries
Intelligent 3-step+ battery charger with low DC ripple current for fast charging times and long battery life
Charges two individual battery banks simultaneously
Quiet, powerful inverter with 200 % peak power
Power Assist: extra power assistance from the batteries in case of limited grid or generator power(prevents blown fuses)
Pure sine wave energy prevents failures and damage to sensitive equipment such as adapters
Dual AC outputs to separate critical equipment from heavy loads
Professional connections ensure fast installation and operational security
CE approved and E-marking for mobile applications
SpecificationsSpecifications Sine Wave Inverter
Nomimal DC voltage: 24 V (19-31 V)
Output voltage: 230 V (± 5 %), adjustable 180-250 V 50/60 Hz (± 0.05 %)
Output waveform: true sine, Thd < 2.5 % under standard conditions
Continuous power at 25°C / 77°F, cos phi 1: 2550 W
Max. peak load: 4000 W
Max. efficiency: >= 90 %
Parallel configuration: yes, up to 2 units
Synchronize with mains/generator: yes
Specifications Battery Charger
Input voltage range: 180-265 V
Max. input current: 8.5 A
Max. charge current at 25°C / 77°F: 60 A at 28.5 V
Secondary charger output current: 5 A
Battery temperature sensor: yes, included
Specifications Transfer System
AC output 1: 25 A (short break output)
AC output 2: 50 A (power output)
Transfer speed: half seamless (25 ms max., 10 ms typical)
General Specifications
Display/read-out: LED display
Dimensions, HxWxD: 19.5 x 12.5 x 6.1 inch
Weight: 24.3 lb
Approvals: CE, ABYC, E4
Technical Specifications
Charge characteristic: IUoUo, automatic / 3-step+ for gel/AGM/MLI/wet/spiral/traction
Ground relay: yes, configurable
Temperature range (ambient temp.): -25°C to 60°C, derating > 25°C-13 to 140°F
Protection degree: IP23 (vertical mounting)
Protections: over temperature, overload, short circuit, high/low battery voltage
Cooling: maintenance-free vario fans
MasterBus compatible: yes, in combination with a MasterBus Combi Interface
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications:Amps - Output = NONE Amps Per Bank = NONE Banks = NONE Battery Type = NONE Charger Type = NONE Portable = NONE Voltage - Charger Input = NONE Voltage - Output (Volts) = NONENormalized SKU: 36022600Mastervolt 36022600 Literature Download Owners Manual Product Brochure
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
ProMariner
ProMariner Promar 1 DS 5 Digital 5a 1-Bank Charger #31505
$124.61
$154.69
ProMariner 31505 Battery ChargersProMar1 DS Digital - 5 Amp - 1 Bank ChargerProMar1 DS Generation 3 reflects a new outward design taken to the next level in performance with its all Digital Charging Technology. Fully Automatic with a 4-Stage Digital Charging algorithm proven to extend battery life. Sequential modes of Analyzing, Charging, Conditioning and a built-in Auto Maintain mode, safe for short and long term storage periods ensures your batteries are fully charged and maintained.Features:
Fully Automatic 4-Stage Chargin
Dual Mode Charge Status Indicator
Battery & Wiring Fault Detection
Rugged Shockproof Construction
Auto Maintain/Energy Save Mode Extends Battery Life
Safe for Long and Short Term Storage
Pre-Wired with Waterproof Inline DC Fuses and Nickel Plated Copper Ring Terminals
Built-in Safety
Quiet EMI Design meets US FCC Emissions Requirements
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 31505UPC Code: 031669315051
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
ProMariner
ProMariner Promar 1 DS Digital 10a 2-Bank Charger #31510
$183.16
$232.62
ProMariner 31510 Battery ChargersProMar1 DS Digital - 10 Amp - 2 Bank ChargerProMar1 DS Generation 3 reflects a new outward design taken to the next level in performance with its all Digital Charging Technology. Fully Automatic with a 4-Stage Digital Charging algorithm proven to extend battery life. Sequential modes of Analyzing, Charging, Conditioning and a built-in Auto Maintain mode, safe for short and long term storage periods ensures your batteries are fully charged and maintained.Features:
Fully Automatic 4-Stage Charging
Dual Mode Charge Status Indicator
Battery & Wiring Fault Detection
Rugged Shockproof Construction
Auto Maintain/Energy Saver Mode Extends Battery Life
Safe for Long and Short Term Storage
Pre-Wired with Waterproof Inline DC Fuses and Nickel Plated Copper Ring Terminals
Built-in Safety
Quiet EMI Design Meets US FCC Emissions Requirements
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 31510UPC Code: 031669315105
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Mastervolt
Mastervolt Mass Combi 12/1600-60 12v/230v #36011600
$2,047.58
$2,375.19
Download LiteratureMastervolt 36011600 Battery ChargersMass Combi 12/1600-60 (12V/230V)Continuous power and peace of mind in all conditionsThe renewed Mass Combi offers the best price/quality ratio. Based on the exceptionally reliable Mass Combiseries, the four new models now offer even more power at a highly competitive price. In addition, they arealso available in two customer-friendly variations with remote control or MasterBus.The powerful 3-step+ battery charger guarantees maximum battery life and can simultaneously charge twobattery banks. The inverter with high peak power starts even the heaviest loads, with the Mass Combi12/1600 being easily sufficient for your espresso machine. A built-in distribution system switches betweengrid and inverter power, while two separate AC outputs allow users to connect critical loads to a preferredgroup.Grid connected solar power system with energy storageThe Mass Combi enables the expansion of a grid connected solar power system with energy storage inbatteries. This way the majority of the generated energy is used, and users are less dependent on theelectricity grid. In this setup, the Mass Combi is part of a MasterBus controlled system.The benefits of the improved Mass Combi:
Compact, lightweight and no hum thanks to HF technology
High yield and more power from your batteries
Intelligent 3-step+ battery charger with low DC ripple current for fast charging times and long battery life
Charges two individual battery banks simultaneously
Quiet, powerful inverter with 200 % peak power
Power Assist: extra power assistance from the batteries in case of limited grid or generator power(prevents blown fuses)
Pure sine wave energy prevents failures and damage to sensitive equipment such as adapters
Dual AC outputs to separate critical equipment from heavy loads
Professional connections ensure fast installation and operational security
CE approved and E-marking for mobile applications
SpecificationsSpecifications Sine Wave Inverter
Nomimal DC voltage: 12 V (10-15 V)
Output voltage: 230 V (± 5 %), adjustable 180-250 V
Output frequency: 50/60 Hz (± 0.05 %), configurable
Output waveform: true sine, Thd < 2.5 % under standard conditions
Continuous power at 25°C / 77°F, cos phi 1: 1600 W
Max. peak load: 3000 W
Max. efficiency: >= 90 %
Max. ripple on DC (battery at full load): < 5 %
No-load power consumption on DC (ON/inverterOFF/OFF/energy saving): 9 W / 0.1 W / 0 W / 0.5 W
Parallel configuration: no
3-Phase configuration: no
Synchronize with mains/generator: yes
Specifications Battery Charger
Input voltage range: 180-265 V
Max. input current: 4.5 A
Max. charge current at 25°C / 77°F: 60 A at 14.25 V, adjustable
Secondary charger output voltage: 12 V
Secondary charger output current: 5 A
No-load consumption on AC: < 15 W
Battery temperature sensor: yes, included
Battery voltage sense: automatic compensation
Specifications Transfer System
AC input 1: 50 A (25 A switched, to short break output)
AC output 1: 25 A (short break output)
AC output 2: 50 A (power output)
AC input fuse: yes, resettable
Transfer speed: half seamless (25 ms max., 10 ms typical)
Transfer voltage range: 180-265 V
Transfer frequency range: 45-65 Hz
General Specifications
Display/read-out: LED display
Dimensions, HxWxD: 14.6 x 12.5 x 5.6 inch
Weight: 17.2 lb
Approvals: CE, ABYC, E4
Technical Specifications
Charge characteristic: 3-step+ (IUoUo, fully automatic), Equalize
Battery types: AGM/gel/MLI/flooded/spiral/traction
Recommended battery capacity: 120-360 Ah (based on gel batteries, may differ for othertypes)
Ground relay: yes, configurable
Temperature range (ambient temp.): -25°C to 60°C, derating > 25°C-13 to 140°F
Protection degree: IP23 (vertical mounting)
Safety class: IEC protection class I
Humidity protection: conformal coating, max. 95 % relative humidity, non condensing
Protections: over temperature, overload, short circuit, high/low battery voltage
Cooling: maintenance-free vario fans
Power Assist: yes
MasterBus compatible: yes, in combination with a MasterBus Combi Interface
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications:Amps - Output = NONE Amps Per Bank = NONE Banks = NONE Battery Type = NONE Charger Type = NONE Portable = NONE Voltage - Charger Input = NONE Voltage - Output (Volts) = NONENormalized SKU: 36011600Mastervolt 36011600 Literature Download Owners Manual Product Brochure
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
ProMariner
ProMariner Battery Isolator 2 Alternator 3 battery 70a #02-70-3
$258.30
$328.06
Download LiteratureProMariner 02-70-3 Battery ChargersBattery IsolatorMax Current: 70 AmpConfiguration: 2 alt., 3 batt.ProMariner Battery Isolator, improved efficiency, provide enhanced chargingWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications:Lockable = NONE AFD = NONE Positions = NONE Amps - Max = NONEPROMARINER 2 ALTERNATOR 3 BATTERY ISOLATOR 70 AMPNormalized SKU: 02703UPC Code: 2-70-3ProMariner 02-70-3 Literature Download Quick Reference Guide
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Newmar
Newmar 24v 20a #PT24-20U
$1,351.15
$1,567.33
Newmar PT24-20U Battery Chargers"Three Stage "Smart" Chargers Phase Three "Smart" battery charging technology is now available in a wide range of power levels, allowing you to select the right size, features and flexibility you require for virtually any application from small recreational craft to large live-aboards, workboats and other commercial vessels. These chargers interact with batteries to put them through the optimum three stage charge process which provides for fastest recovery and ideal conditioning, maximizing battery performance and extending battery life. A selector switch adjusts output voltage to adapt for gel-cell/flooded lead-acid/AGM battery types. An optional temperature compensation sensor also adjusts output for ideal voltage based on changes in the batteries' ambient temperature. All models are housed in a rugged stainless steel case with a durable white powder coat finish, and the internal circuitry is polyurethane coated for maximum corrosion resistance. Features "Smart" circuitry provides three stage charging?bulk, absorption, float.
Wide model range covers battery system ratings from 14-950 amp-hours
Gel-Cell/Flooded Lead-acid/AGM battery type switch selects optimum charge/float voltages.
Multiple isolated output banks; ammeter indicates total output current. (except PT-7)
Optional sensor adjusts output voltage based on battery temperature. (except PT-7)
Current limiting-prevents damage from overloading.
Charger status clearly displayed with L.E.D. and/or audible indicators or optional remote panel.
Use as a power supply; can power loads without a battery in line.
Built to last?rugged stainless steel case with a durable white powder coat finish with an optional drip shield and marinized internal circuitry.
Numerous Safety and EMC CompliancesTwo year parts and labor warranty
Models 12 Volt
24 Volt
32 Volt
PT-7
PT-24-8W
PT-32-25W
PT-14W
PT-24-13W
PT-25W
PT-24-20U
PT-40U
PT-24-45U
PT-80
PT-24-60W
PT-24-95U
Detailed specifications below.
Specifications 12 Volt Models
PT-7
PT-14W
PT-25W
PT-40W
PT-80
Input VAC (50-60 Hz.)
88-132 or 176-264
85-264
90-132 or 180-264
85-135 or 170-270
90-264
Input Amps @ Full Load
@ 115 VAC
2
2.8
6.5
8.5
12
@ 230 VAC
1
1.4
4
4.3
7
P.F. Rating
>.65
.93@230V .98@115V
.7
.7
.95@230V .98@115V
Max Output Amps
7
14
25
40
80
Output Banks
2
3
3
3
3
Battery Capacity (Amp-Hours)
14-70
28-140
50-250
80-400
160-800
Operating Temp. Rating Reference
T-1
T-2
T-4
T-5
T-7
Case Size Ref.
A-1
A-2
A-2
A-3
A-5
Weight; Lbs./Kg.
3.2/1.5
8/4
8.2/4
12/6
15.2/7
Optional Temp.Sensor Model
N/A
TCS-12/24
TCS-12/24
TCS-12/24
TCS-12/24
Remote Panel Model
N/A
RP
RP
RP
RP
Equalize Option
No
Yes
Yes
Yes
Yes
Output Indicator Ref.
M-1
M-3
M-3
M-3
M-3
Compliance Ref.
CG, CE
CG, CE
CG
CG, CE
CE
24 Volt Models
PT-24-8W
PT-24-13W
PT-24-20U
PT-24-45U
PT-24-60W
PT-24-95U
Input VAC (50-60 Hz.)
85-264
90-132 or 180-264
85-135 or 170-270
90-264
207-253
90-264
Input Amps @ Full Load
@ 115 VAC
2.8
6.5
8.5
12
NA
26
@ 230 VAC
1.4
4
4.3
7
13
14
P.F. Rating
.93@230V .98@115V
.7
.7
.95@230V .98@115V
.7
.95@230V .98@115V
Max Output Amps
8
13
20
45
60
95
Output Banks
3
3
3
3
3
3
Battery Capacity (Amp-Hours)
16-80
26-130
40-200
90-450
120-600
180-950
Operating Temp. Rating Reference
T-2
T-3
T-5
T-8
T-6
T-8
Case Size Ref.
A-2
A-2
A-3
A-5
A-6
A-6
Weight; Lbs./Kg.
8/4
8.2/4
12/6
12.2/6
24.1/11
24.5/11
Optional Temp.Sensor Model
TCS-12/24
TCS-12/24
TCS-12/24
TCS-12/24
TP
TCS-12/24
Remote Panel Model
RP
RP
RP
RP
N/A
RP
Equalize Option
Yes
Yes
Yes
Yes
No
Yes
Output Indicator Ref.
M-3
M-3
M-3
M-3
M-2
M-3
Compliance Ref.
CG, CE
CG
CG, CE
EN, CE
EN, CE
EN, CE
32 Volt Model
PT-32-25W
Input VAC (50-60 Hz.)
104-126
Input Amps @ Full Load
@ 115 VAC
15
@ 230 VAC
N/A
P.F. Rating
.7
Max Output Amps
25
Output Banks
3
Battery Capacity (Amp-Hours)
50-250
Operating Temp. Rating Reference
T-6
Case Size Ref.
A-4
Weight; Lbs./Kg.
12.2/6
Optional Temp.Sensor Model
TP
Remote Panel Model
N/A
Equalize Option
No
Output Indicator Ref.
M-2
Compliance Ref.
EN, CE
Case Size Inches
Centimeters
Ref
H
W
D
H
W
D
A-1
10.5
5.0
2.8
26.7
12.7
7.1
A-2
12.5
7.7
4.3
31.8
19.6
10.9
A-3
13.85*
9.5
4.8*
35.2*
24.1
12.2*
A-4
13.8A
9.8
5A
35A
24.9
12.7A
A-5
14.8B
9.6
5.6B
37.6B
24.4
14.2B
A-6
17.5C
12
7.2C
44.5C
30.5
18.3C
* Add .75" (1.9 cm) to height and 1.35" (3.4 cm) to depth A Add 1.27" (3.2 cm) to height and 1.1" (2.8 cm) to depth B Add 1" (2.54 cm) to height and .5" (1.27 cm) to depth C Add 2" (5.08 cm) to height and 1" (2.54 cm) to depth
Temperature Rating References: T-1
-10°C to +45°C; Derate linearly from 100% @ 0°C to 80% @ -10°C
T-2
-10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C
T-3
-10°C to +60°C; Derate linearly from 100% @ 50°C to 60% @ 60°C
T-4
-10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C
T-5
-40°C to +60°C; Derate linearly from 100% @ 50°C to 75% @ 60°C
T-6
-20°C to +50°C; Full output
T-7
-20°C to +70°C; Derate linearly from 100% @ 45°C to 50% @ 70°C
T-8
-20°C to +70°C; Derate linearly from 100% @ 50°C to 50% @ 70°C
Output Indicator References M-1 Total output ammeter M-2 Charge/Float L.E.D. M-3 Total output ammeter and charger status L.E.D.'s/Alarms Compliance References* See matrix for applicable models CG USCG CFR 183.410 (Ignition protected) EN EN 60335-1, EN 60335-2-29 CE Carries the CE Mark * Numerous other Safety and EMC compliances may also apply. Contact factory if further compliance information is required. Nominal Output Voltages at Gel/Flooded Switch Settings (Without Temperature Compensation option installed or at 22.2˚C (72˚F) with Temperature Compensation option installed.) 12 Volt Models 24 Volt Models 32 Volt Model Charge Float Charge Float Charge Float Setting @ 50% load @ .5 amp load @ 50% load @ .5 amp load @ 50% load @ .5 amp load Gel-Cell 14.0 VDC 13.6 VDC 28.0 VDC 27.2 VDC 37.3 VDC 36.2 VDC Flooded/AGM 14.2 VDC 13.4 VDC 28.4 VDC 26.8 VDC 37.8 VDC 35.7 VDC "Normalized SKU: PT2420UUPC Code: 445-5210-1
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Newmar
Newmar 12v 80a Charger #PT80
$2,336.66
$2,710.53
Newmar PT80 Battery Chargers"Three Stage "Smart" Chargers Phase Three "Smart" battery charging technology is now available in a wide range of power levels, allowing you to select the right size, features and flexibility you require for virtually any application from small recreational craft to large live-aboards, workboats and other commercial vessels. These chargers interact with batteries to put them through the optimum three stage charge process which provides for fastest recovery and ideal conditioning, maximizing battery performance and extending battery life. A selector switch adjusts output voltage to adapt for gel-cell/flooded lead-acid/AGM battery types. An optional temperature compensation sensor also adjusts output for ideal voltage based on changes in the batteries' ambient temperature. All models are housed in a rugged stainless steel case with a durable white powder coat finish, and the internal circuitry is polyurethane coated for maximum corrosion resistance. Features "Smart" circuitry provides three stage charging?bulk, absorption, float.
Wide model range covers battery system ratings from 14-950 amp-hours
Gel-Cell/Flooded Lead-acid/AGM battery type switch selects optimum charge/float voltages.
Multiple isolated output banks; ammeter indicates total output current. (except PT-7)
Optional sensor adjusts output voltage based on battery temperature. (except PT-7)
Current limiting-prevents damage from overloading.
Charger status clearly displayed with L.E.D. and/or audible indicators or optional remote panel.
Use as a power supply; can power loads without a battery in line.
Built to last?rugged stainless steel case with a durable white powder coat finish with an optional drip shield and marinized internal circuitry.
Numerous Safety and EMC CompliancesTwo year parts and labor warranty
Models 12 Volt
24 Volt
32 Volt
PT-7
PT-24-8W
PT-32-25W
PT-14W
PT-24-13W
PT-25W
PT-24-20U
PT-40U
PT-24-45U
PT-80
PT-24-60W
PT-24-95U
Detailed specifications below.
Specifications 12 Volt Models
PT-7
PT-14W
PT-25W
PT-40W
PT-80
Input VAC (50-60 Hz.)
88-132 or 176-264
85-264
90-132 or 180-264
85-135 or 170-270
90-264
Input Amps @ Full Load
@ 115 VAC
2
2.8
6.5
8.5
12
@ 230 VAC
1
1.4
4
4.3
7
P.F. Rating
>.65
.93@230V .98@115V
.7
.7
.95@230V .98@115V
Max Output Amps
7
14
25
40
80
Output Banks
2
3
3
3
3
Battery Capacity (Amp-Hours)
14-70
28-140
50-250
80-400
160-800
Operating Temp. Rating Reference
T-1
T-2
T-4
T-5
T-7
Case Size Ref.
A-1
A-2
A-2
A-3
A-5
Weight; Lbs./Kg.
3.2/1.5
8/4
8.2/4
12/6
15.2/7
Optional Temp.Sensor Model
N/A
TCS-12/24
TCS-12/24
TCS-12/24
TCS-12/24
Remote Panel Model
N/A
RP
RP
RP
RP
Equalize Option
No
Yes
Yes
Yes
Yes
Output Indicator Ref.
M-1
M-3
M-3
M-3
M-3
Compliance Ref.
CG, CE
CG, CE
CG
CG, CE
CE
24 Volt Models
PT-24-8W
PT-24-13W
PT-24-20U
PT-24-45U
PT-24-60W
PT-24-95U
Input VAC (50-60 Hz.)
85-264
90-132 or 180-264
85-135 or 170-270
90-264
207-253
90-264
Input Amps @ Full Load
@ 115 VAC
2.8
6.5
8.5
12
NA
26
@ 230 VAC
1.4
4
4.3
7
13
14
P.F. Rating
.93@230V .98@115V
.7
.7
.95@230V .98@115V
.7
.95@230V .98@115V
Max Output Amps
8
13
20
45
60
95
Output Banks
3
3
3
3
3
3
Battery Capacity (Amp-Hours)
16-80
26-130
40-200
90-450
120-600
180-950
Operating Temp. Rating Reference
T-2
T-3
T-5
T-8
T-6
T-8
Case Size Ref.
A-2
A-2
A-3
A-5
A-6
A-6
Weight; Lbs./Kg.
8/4
8.2/4
12/6
12.2/6
24.1/11
24.5/11
Optional Temp.Sensor Model
TCS-12/24
TCS-12/24
TCS-12/24
TCS-12/24
TP
TCS-12/24
Remote Panel Model
RP
RP
RP
RP
N/A
RP
Equalize Option
Yes
Yes
Yes
Yes
No
Yes
Output Indicator Ref.
M-3
M-3
M-3
M-3
M-2
M-3
Compliance Ref.
CG, CE
CG
CG, CE
EN, CE
EN, CE
EN, CE
32 Volt Model
PT-32-25W
Input VAC (50-60 Hz.)
104-126
Input Amps @ Full Load
@ 115 VAC
15
@ 230 VAC
N/A
P.F. Rating
.7
Max Output Amps
25
Output Banks
3
Battery Capacity (Amp-Hours)
50-250
Operating Temp. Rating Reference
T-6
Case Size Ref.
A-4
Weight; Lbs./Kg.
12.2/6
Optional Temp.Sensor Model
TP
Remote Panel Model
N/A
Equalize Option
No
Output Indicator Ref.
M-2
Compliance Ref.
EN, CE
Case Size Inches
Centimeters
Ref
H
W
D
H
W
D
A-1
10.5
5.0
2.8
26.7
12.7
7.1
A-2
12.5
7.7
4.3
31.8
19.6
10.9
A-3
13.85*
9.5
4.8*
35.2*
24.1
12.2*
A-4
13.8A
9.8
5A
35A
24.9
12.7A
A-5
14.8B
9.6
5.6B
37.6B
24.4
14.2B
A-6
17.5C
12
7.2C
44.5C
30.5
18.3C
* Add .75" (1.9 cm) to height and 1.35" (3.4 cm) to depth A Add 1.27" (3.2 cm) to height and 1.1" (2.8 cm) to depth B Add 1" (2.54 cm) to height and .5" (1.27 cm) to depth C Add 2" (5.08 cm) to height and 1" (2.54 cm) to depth
Temperature Rating References: T-1
-10°C to +45°C; Derate linearly from 100% @ 0°C to 80% @ -10°C
T-2
-10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C
T-3
-10°C to +60°C; Derate linearly from 100% @ 50°C to 60% @ 60°C
T-4
-10°C to +60°C; Derate linearly from 100% @ 40°C to 60% @ 60°C
T-5
-40°C to +60°C; Derate linearly from 100% @ 50°C to 75% @ 60°C
T-6
-20°C to +50°C; Full output
T-7
-20°C to +70°C; Derate linearly from 100% @ 45°C to 50% @ 70°C
T-8
-20°C to +70°C; Derate linearly from 100% @ 50°C to 50% @ 70°C
Output Indicator References M-1 Total output ammeter M-2 Charge/Float L.E.D. M-3 Total output ammeter and charger status L.E.D.'s/Alarms Compliance References* See matrix for applicable models CG USCG CFR 183.410 (Ignition protected) EN EN 60335-1, EN 60335-2-29 CE Carries the CE Mark * Numerous other Safety and EMC compliances may also apply. Contact factory if further compliance information is required. Nominal Output Voltages at Gel/Flooded Switch Settings (Without Temperature Compensation option installed or at 22.2˚C (72˚F) with Temperature Compensation option installed.) 12 Volt Models 24 Volt Models 32 Volt Model Charge Float Charge Float Charge Float Setting @ 50% load @ .5 amp load @ 50% load @ .5 amp load @ 50% load @ .5 amp load Gel-Cell 14.0 VDC 13.6 VDC 28.0 VDC 27.2 VDC 37.3 VDC 36.2 VDC Flooded/AGM 14.2 VDC 13.4 VDC 28.4 VDC 26.8 VDC 37.8 VDC 35.7 VDC "Normalized SKU: PT80UPC Code: 445-4785-0
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Analytic Systems
Analytic Systems Non-ISO DC/DC Converter 13a 24v Out 11-15v #VTC305-12-24
$543.12
$677.88
Analytic Systems VTC305-12-24 Battery ChargersNon Iso DC/DC Converter 13A, 24V Out, 11-15V InStep up a 12 VDC battery to between 13.5 and 17.0 or 24.0 and 27.5 VDC in 0.5 VDC increments (via 3 position DIP switch), or stabilize a 12 or 24 VDC power system. Safety features include reverse input protection, low input voltage alarm, low output voltage alarm, over temperature shutdown and alarm, and output overvoltage crowbar. If the input voltage exceeds the regulated output voltage, the unit simply passes the voltage through with full LC filtering and a single schottky diode drop (0.5 VDC or less). Optional features include a dry contact alarm relay output, and remote panel monitoring with On/Off control. Applications include temporarily brightening 12 volt headlights or work lights, increasing voltage into an automotive or marine ignition system for hotter spark and/or prevention of failures due to voltage drop during engine start, stabilizing 12 and 24 VDC power systems in marine, automotive or aeronautical environments and more. Features:
Ultra-quiet
Rugged and reliable to ensure years of safe and trouble free operation
Simple operation
Current limiting protection
Paralleling Diodes
European ROHS Compliant (Lead Free Manufactured)
Electric Fork Lift (Filtering and Surge Suppression)
Open Frame (No chassis just heat sink bars)
Safety Special Inspection (CSA/UL)
Heavy duty ruggedization with wide temperature range
Custom input/output available
Three year parts and labour warranty
Specifications:Amps Per Bank = NONE Battery Type = NONE Charger Input - Voltage = 11-15 VDC Charger Output - Amps = 13 Charger Output Voltage = 24 VDC Charger Type = NONE Charging Banks = NONE Portable = NONENormalized SKU: VTC3051224
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Battery Tender
Battery Tender Jr 12v 50 State #021-0123
$41.97
$50.36
Battery Tender 021-0123 Battery ChargersThe Battery Tender Junior offers much more than a trickle charger could offer. It has a brain. All Battery Tender battery chargers automatically switch from a full charge to a float charge. The Battery Tender Junior will fully charger your power sport or vintage vehicle. It's lightweight, compact, and fully automatic; very easy to use, especially in small spaces. Battery maintenance has never been easier with smart charger technology. Perfect for all lead-acid, flooded or sealed maintenance free batteries (AGM and gel cell). Complete 4-step charging program (Initialization, Bulk Charge, Absorption Mode, Float Mode). Automatically switches to float / maintenance voltage after fully charging the battery. If the battery voltage drops too far under load, full charger output power resumes. Solid state two color LED indicates stage of charger. Includes a 5 year warranty.
Spark proof
Perfect for all lead-acid, flooded or sealed maintenance free batteries (AGM and GEL cell)
Complete 4-step charging program (Initialization, Bulk Charge, Absorption Mode, Float Mode)
Plugs directly in to the wall; Safety Timer: 80 hours
12 foot output cord
Normalized SKU: 0210123UPC Code: 734357000078
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Battery Tender
Battery Tender 12v/6v 1.25a Lead Acid Only #022-0211-DL-WH
$84.10
$104.40
Battery Tender 022-0211-DL-WH Battery ChargersInfinite Sequential Monitoring (ISM™) by Battery Tender®, makes sure the charger is delivering the correct charge process at any given time. Utilizing advanced software to continually monitor the battery condition assures you are charging and maintaining your battery correctly, leading to longer life and more engine starts. If it wont start you cant use it! Input: 120VAC Output: Switchable from 6 Volts or 12 Volts DC @ 1.25 amps Reverse Polarity Protection to ensure user safety. Complete 4-step charging program (Initialization, Bulk Charge, Absorption Mode, Float Mode). Safety timer: 72 hours Perfect for all lead-acid, flooded or sealed maintenance free batteries (AGM and gel cell). 5 year warranty Listed in California Appliance Efficiency Database Agency Approvals: UL/ BCNormalized SKU: 0220211DLWHUPC Code: 734357221107
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Battery Tender
Battery Tender 12v/6v 4a Lithium/Lead Acid Selectable #022-0209-DL-WH
$77.29
$95.94
Battery Tender 022-0209-DL-WH Battery Chargers
The Battery Tender® 4 Amp Power Tender Selectable 12- or 6-volt options, as well as battery type selection, has you covered. It's lightweight, compact, and fully automatic; very easy to use, especially in small spaces. It will keep your battery fully charged so that it is ready to go when you are!
12V or 6V switchable @ 4A
AGM/Standard or GEL/Lithium Iron switchable
ISM™ (Infinite Sequential Monitoring) of the fully automatic 4-step charge process (qualification, bulk charge, absorption, float)
Microprocessor controlled
Spark proof even when output leads touch.
Reverse Polarity Protection - no charge or battery damage
State of charge LED indicator
Includes Rings & Clips
Shipping Weight: 3.15lbs
Dimensions: 6.8" x 3.68" x 1.96" (charger only)
5 Year Warranty
Normalized SKU: 0220209DLWHUPC Code: 734357220902
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Battery Tender
Battery Tender Junior 12v 0.8a Lithium-Lead Acid Select #022-0199-DL-WH
$43.07
$51.68
Battery Tender 022-0199-DL-WH Battery Chargers
The Battery Tender® Junior 800 is much more than a trickle charger. It has a brain. It's lightweight, compact, and very easy to use, especially in small spaces. With selectable battery type, It will keep your battery fully charged so that it is ready to go when you are!
Battery Tender Junior 12v 0.8a Lithium-Lead Acid Select #022-0199-DL-WHNormalized SKU: 0220199DLWHUPC Code: 734357219906
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Battery Tender
Battery Tender Dual Port USB Charger #021-0161
$8.50
$10.00
Battery Tender 021-0161 Battery Chargers
Car charger for: iPad, tablets, and all cell phones. Use your existing USB cord to charge any electronic device in the car. Can charge 2 devices at the same time. INPUT: 12-24V. OUTPUT: 2.1A for iPad/Tablets, and 1A for all cell phones. Use existing USB charge/sync cable for charging (not included).Normalized SKU: 0210161
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Battery Tender
Battery Tender Junior 6v CA #022-0196
$44.25
$53.10
Battery Tender 022-0196 Battery ChargersThe Battery Tender® Junior High Efficiency is much more than a trickle charger. It has a brain. It's lightweight, compact, and fully automatic; very easy to use, especially in small spaces. It will keep your battery fully charged so that it is ready to go when you are! Perfect for all lead-acid, flooded or sealed maintenance free batteries (AGM and gel cell). Solid state two color LED indicates stage of charger. Listed in California Appliance Efficiency Database.Normalized SKU: 0220196
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Battery Tender
Battery Tender Quick Disconnect Plug USB Charger #081-0158
$11.63
$13.88
Battery Tender 081-0158 Battery Chargers
Battery Tender Quick Disconnect Plug with USB Charger 12V Input and Maximum 2.1 Amps Output it's Quite Portable and Perfect for Charging your iPhone, iPad, iPod, GPS, Camera or any Smartphone or Device that be Charged via USB. It's Designed for Use on Most 12-Volt Batteries on Your Motorcycle, Golf Cart, ATV, etc. It Attaches to Existing Battery Tender Quick Disconnect. The Rubber Flap will Protect the Charger Connectors.
Battery Tender accessories.Normalized SKU: 0810158
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Battery Tender
Battery Tender Junior 8v CA #022-0197
$44.25
$53.10
Battery Tender 022-0197 Battery Chargers
The Battery Tender® Junior High Efficiency is much more than a trickle charger. It has a brain. It's lightweight, compact, and fully automatic; very easy to use, especially in small spaces. It will keep your battery fully charged so that it is ready to go when you are! Perfect for all lead-acid, flooded or sealed maintenance free batteries (AGM and gel cell). Solid state two color LED indicates stage of charger. Listed in California Appliance Efficiency Database.Normalized SKU: 0220197
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Battery Tender
Battery Tender 12v California Model #022-0185G-DL-WH
$73.59
$91.35
Battery Tender 022-0185G-DL-WH Battery ChargersThe Battery Tender is a 1.25 amp battery charger that automatically switches from full charge to a float charging mode, and then monitors the battery. When the battery is accepting only 0.5 amps, the Battery Tender switches into a float charging mode. At this point, both the current and the voltage are held at 13.2. The gassing point of a battery is 13.8 volts, therefore applying voltage greater than 13.8 for an extended period of time will damage the battery. Trickle chargers decrease current, but increase voltage to upwards of 15.5 volts, and continue the excessive gassing action that is most detrimental to the life of batteries.Normalized SKU: 0220185GDLWHUPC Code: 734357218565
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Battery Tender
Battery Tender 5 Station #021-0133
$638.40
$796.80
Battery Tender 021-0133-DL-WH Battery Chargers
Fully automatic, constant-current battery charger designed to charge and/ or maintain up to 5 12-volt batteries simultaneously @ 2 amps. Safe, No Spark Charging! To avoid dangerous dead-short sparking, microchip circuitry will not activate output voltage until clips are correctly connected to the battery. Maintains batteries at full charge. 2 amps per output charging current.Normalized SKU: 0210133DLWHUPC Code: 203300003003
Frequently Asked Questions
First Choice Marine is an online marine retailer carrying a diverse line of marine parts and accessories and related items from industry-respected and demanded manufacturers and suppliers. Through our diverse distributor network, we are able to access over 150,000 items, including our current site inventory, new products being added, and special order items. If you need it on your boat... we are your one-stop shop!
Yes, we offer FREE Shipping on most orders over $149 to US-48*.
Each product displays a shipping status message, just above the item price. Below is the meaning for each of these codes.
- Qualifies for Free Shipping: This item qualifies for free shipping when the order is $149+
- Qualifies for Free Ground Shipping: This item qualifies for free ground shipping when the order is $149+.
- Oversized - Not Qualified for Free Shipping: This item is too large/heavy to qualify for free shipping
- Hazardous Item - Not Qualified for Free Shipping: This item is hazardous and does not qualify for free shipping
- Truck Freight - Not Qualified for Free Shipping: This item has to be shipped via truck freight. Please contact us for a quote
- In-Store Pickup Only: This item can only be picked up in our Grain Valley, MO retail store
Below the price of the item, on the product page, there is a message indicating the availability of the product.
The quantity on hand is updated as inventory events happen and matches what we have available. If you have urgent needs and we are close to what you need, contact us, and we can confirm stock.
We offer a hassle-free return policy. If you're not completely satisfied with your purchase, you can return it within 30 days for a full refund or exchange.
If you need to return an item, please follow the guidelines here so we can process a prompt refund and assist you in finding the correct item.
Free Shipping
On most orders $149+ to the continental 48 US states.Secure Shopping
Fast, secure checkout with a variety of payment methods.Shop with confidence
25+ years serving the marine industry.Support center
Need help? Contact us via live chat, phone, or email.
