Download Literature  Watch VideoRaymarine T70160 AutopilotsEV-300 Power Solenoid Evolution Autopilot*Requires addition of a 12V or 24V Constant Running Variable PumpFeatures: For vessels with solenoid controlled hydraulic steering Evolution Ai for superior performance No calibration required SeaTalkng Network Compatible ACU-300 auxiliary power to SeaTalkng network Includes p70R Autopilot Controller Includes: EV-1 Sensor Core p70RS Autopilot Control Head ACU-300 Actuator Control Unit (Includes the M81105 Rotary Rudder Reference) Evolution Cabling Kit EV Unit O-Ring Pack (set of 2) Wall Mounting Bracket The EV-1 Sensor CoreAt the center of every Evolution system is the intelligent EV sensor core, a 9-axis sensor that monitors vessel motion in all three dimensions. The innovative EV sensor core combines advanced solid-state sensors with the Evolution autopilot processor into a single easy-toinstall housing.Mount the EV sensor core above or below decks, the rugged enclosure is fully sealed and built to IPX6 and IPX7 waterproofing and submersion standards.The EV-1 is designed for Evolution mechanical and hydraulic autopilot systems. SeaTalkng networking enables a single cable connection for power and data to the Evolution ACU (actuator control unit) and extended SeaTalkng and NMEA2000 networks.Features: Precision monitoring of heading, pitch, roll, and yaw allowing the autopilot to evolve instantly as sea conditions and vessel dynamics change Flexible installation options Mount above or below deck Simple SeaTalkng connectivity to the control head and ACU Solid state sensor technology delivers dynamic accuracy to within 2 degrees in all conditions Fast and reliable heading data for MARPA, radar overlay, and heading modes on Raymarine multifunction displays p70R Autopilot Control HeadThe p70R has a convenient rotary control knob and support for multiple autopilot modes including Auto, standby, trolling patterns, and track mode from your GPS or chartplotter. Features: LightHouse user interface is simple and quick to use Wide 160° viewing angles Start up wizard helps you configure the pilot quickly and easily Anti-reflective coating for improved visibility in bright sunlight Low power - typically 132mA/1.6W - 27% less than ST70 at x4 measured brightness Supported autopilot modes: Auto; Standby; Pattern; Track; Wind Vane; Power Steer and Jog Steer Simple system and group dimming/illumination Support for multiple data sources SeaTalkng/NMEA2000 and SeaTalk1 connectivity (no bridging required) ACU-300 Autopilot Control Unit (ACU)The rugged ACU (Actuator Control Unit) delivers reliable autopilot drive power and also provides power to the SeaTalkng bus. Choose the ACU that fits your steering system type.Evolution Cabling Kit 1 x SeaTalkng Power Cable (0.4m) 1 x SeaTalkng Backbone Cable (5m) 1 x SeaTalkng Spur Cable (0.4m) 1 x SeaTalkng 5-way Connector Block 2 x SeaTalkng T-piece Connector 2 x SeaTalkng Terminator Specifications:Boat Length - Max (Feet) = NONE Capacity - Max Ram (CU) = NONE Drive Type = NONE Feedback Type = NONE Pilot Type = NONE Remote Capable = NONE Turn Patterns = NONE Vessel Displacement - Max (Pounds) = NONENormalized SKU: T70160UPC Code: 723193774342Raymarine T70160 Literature Download  Product BrochureRaymarine T70160 Video

  Download Literature  Watch VideoRaymarine T70157 AutopilotsEV-200 Power Hydraulic Evolution AutopilotFeatures: A complete autopilot-in-a-box Evolution Ai for superior performance No calibration required Includes Type 1 Hydraulic Drive Unit SeaTalkng Network Compatible ACU-200 auxiliary power to SeaTalkng network Includes p70R Autopilot Controller Includes: EV-1 Sensor Core p70RS Autopilot Control Head ACU-200 Actuator Control Unit (Includes the M81105 Rotary Rudder Reference) Type 1 Hydraulic Pump Evolution Cabling Kit EV Unit O-Ring Pack (set of 2) Wall Mounting Bracket The EV Sensor CoreAt the center of every Evolution system is the intelligent EV sensor core, a 9-axis sensor that monitors vessel motion in all three dimensions. The innovative EV sensor core combines advanced solid-state sensors with the Evolution autopilot processor into a single easy-toinstall housing.Mount the EV sensor core above or below decks, the rugged enclosure is fully sealed and built to IPX6 and IPX7 waterproofing and submersion standards.The EV-1 is designed for Evolution mechanical and hydraulic autopilot systems. SeaTalkng networking enables a single cable connection for power and data to the Evolution ACU (actuator control unit) and extended SeaTalkngand NMEA2000 networks.Features: Precision monitoring of heading, pitch, roll, and yaw allowing the autopilot to evolve instantly as sea conditions and vessel dynamics change Flexible installation options Mount above or below deck Simple SeaTalkng connectivity to the control head and ACU Solid state sensor technology delivers dynamic accuracy to within 2 degrees in all conditions Fast and reliable heading data for MARPA, radar overlay, and heading modes on Raymarine multifunction displays p70R Autopilot Control HeadThe p70R has a convenient rotary control knob and support for multiple autopilot modes including Auto, standby, trolling patterns, and track mode from your GPS or chartplotter. Features: LightHouse user interface is simple and quick to use Wide 160° viewing angles Start up wizard helps you configure the pilot quickly and easily Anti-reflective coating for improved visibility in bright sunlight Low power - typically 132mA/1.6W - 27% less than ST70 at x4 measured brightness Supported autopilot modes: Auto; Standby; Pattern; Track; Wind Vane; Power Steer and Jog Steer Simple system and group dimming/illumination Support for multiple data sources SeaTalkng/NMEA2000 and SeaTalk1 connectivity (no bridging required) ACU-200 Autopilot Control Unit (ACU)The rugged ACU (Actuator Control Unit) delivers reliable autopilot drive power and also provides power to the SeaTalkng bus. Choose the ACU that fits your steering system type.Type 1 Hydraulic PumpThe reversing 12V hydraulic pump is for use with steering systems equipped with 4.914 cubic inch (80cc - 230cc) hydraulic steering rams. The Type 1 hydraulic drive is compatible with both S1/S1G and S2/S2G corepacks.Evolution Cabling Kit 1 x SeaTalkng Power Cable (0.4m) 1 x SeaTalkng Backbone Cable (5m) 1 x SeaTalkng Spur Cable (0.4m) 1 x SeaTalkng 5-way Connector Block 2 x SeaTalkng T-piece Connector 2 x SeaTalkng Terminator Specifications:Boat Length - Max (Feet) = NONE Capacity - Max Ram (CU) = NONE Drive Type = NONE Feedback Type = NONE Pilot Type = NONE Remote Capable = NONE Turn Patterns = NONE Vessel Displacement - Max (Pounds) = NONENormalized SKU: T70157UPC Code: 723193774311Raymarine T70157 Literature Download  Quick Reference Guide  Product BrochureRaymarine T70157 Video

  Download Literature  Watch VideoRaymarine T70156 AutopilotsEV-200 Power Evolution AutopilotFeatures: Evolution Ai for superior performance No calibration required Use with any Type 1 Hydraulic Pump (sold separately) 12V or 24V DC operation SeaTalkng Network Capable ACU-200 auxiliary power to SeaTalkng network Includes p70R Autopilot Controller Includes: EV-1 Sensor Core p70RS Autopilot Control Head ACU-200 Actuator Control Unit (Includes the M81105 Rotary Rudder Reference) Evolution Cabling Kit EV Unit O-Ring Pack (set of 2) Wall Mounting Bracket The EV Sensor CoreAt the center of every Evolution system is the intelligent EV sensor core, a 9-axis sensor that monitors vessel motion in all three dimensions. The innovative EV sensor core combines advanced solid-state sensors with the Evolution autopilot processor into a single easy-toinstall housing.Mount the EV sensor core above or below decks, the rugged enclosure is fully sealed and built to IPX6 and IPX7 waterproofing and submersion standards.The EV-1 is designed for Evolution mechanical and hydraulic autopilot systems. SeaTalkng networking enables a single cable connection for power and data to the Evolution ACU (actuator control unit) and extended SeaTalkng and NMEA2000 networks.Features: Precision monitoring of heading, pitch, roll, and yaw allowing the autopilot to evolve instantly as sea conditions and vessel dynamics change Flexible installation options Mount above or below deck Simple SeaTalkng connectivity to the control head and ACU Solid state sensor technology delivers dynamic accuracy to within 2 degrees in all conditions Fast and reliable heading data for MARPA, radar overlay, and heading modes on Raymarine multifunction displays p70R Autopilot Control HeadThe p70R has a convenient rotary control knob and support for multiple autopilot modes including Auto, standby, trolling patterns, and track mode from your GPS or chartplotter. Features: LightHouse user interface is simple and quick to use Wide 160° viewing angles Start up wizard helps you configure the pilot quickly and easily Anti-reflective coating for improved visibility in bright sunlight Low power - typically 132mA/1.6W - 27% less than ST70 at x4 measured brightness Supported autopilot modes: Auto; Standby; Pattern; Track; Wind Vane; Power Steer and Jog Steer Simple system and group dimming/illumination Support for multiple data sources SeaTalkng/NMEA2000 and SeaTalk1 connectivity (no bridging required) ACU-200 Autopilot Control Unit (ACU)The rugged ACU (Actuator Control Unit) delivers reliable autopilot drive power and also provides power to the SeaTalkng bus. Choose the ACU that fits your steering system type.Support Drive UnitsType 1 Drive Unit (sold separately)Evolution Cabling Kit 1 x SeaTalkng Power Cable (0.4m) 1 x SeaTalkngg Backbone Cable (5m) 1 x SeaTalkng Spur Cable (0.4m) 1 x SeaTalkng 5-way Connector Block 2 x SeaTalkng T-piece Connector 2 x SeaTalkng Terminator Specifications:Capacity - Max Ram (CU) = NONE Boat Length - Max (Feet) = NONE Drive Type = NONE Feedback Type = NONE Pilot Type = NONE Remote Capable = NONE Turn Patterns = NONE Vessel Displacement - Max (Pounds) = NONENormalized SKU: T70156UPC Code: 723193774304Raymarine T70156 Literature Download  Quick Reference Guide  Product BrochureRaymarine T70156 Video

  Download Literature  Watch VideoRaymarine T70155 AutopilotsEV-200 Sail Evolution AutopilotFeatures: Evolution Ai for superior performance No calibration required Use with any Type 1 Linear or Rotary Drive Unit (sold separately) 12V or 24V DC operation SeaTalkng Network Compatible ACU-200 auxiliary power to SeaTalkng network Includes p70 Autopilot Controller Includes: EV-1 Sensor Core p70s Autopilot Control Head ACU-200 Actuator Control Unit (Includes the M81105 Rotary Rudder Reference) Evolution Cabling Kit EV Unit O-Ring Pack (set of 2) Wall Mounting Bracket The EV Sensor CoreAt the center of every Evolution system is the intelligent EV sensor core, a 9-axis sensor that monitors vessel motion in all three dimensions. The innovative EV sensor core combines advanced solid-state sensors with the Evolution autopilot processor into a single easy-toinstall housing.Mount the EV sensor core above or below decks, the rugged enclosure is fully sealed and built to IPX6 and IPX7 waterproofing and submersion standards.The EV-1 is designed for Evolution mechanical and hydraulic autopilot systems. SeaTalkng networking enables a single cable connection for power and data to the Evolution ACU (actuator control unit) and extended SeaTalkng and NMEA2000 networks.Features: Precision monitoring of heading, pitch, roll, and yaw allowing the autopilot to evolve instantly as sea conditions and vessel dynamics change Flexible installation options Mount above or below deck Simple SeaTalkng connectivity to the control head and ACU Solid state sensor technology delivers dynamic accuracy to within 2 degrees in all conditions Fast and reliable heading data for MARPA, radar overlay, and heading modes on Raymarine multifunction displays p70s Autopilot Control HeadThe p70s is a push-button operation controller designed primarily for sailboats.Superior ViewingAdvanced LED backlighting offers low power consumption and delivers vibrant color and contrast. Wide horizontal and vertical viewing angles ensure the display can be seen clearly from acute positions.Features: LightHouse user interface is simple and quick to use Wide 160° viewing angles Start up wizard helps you configure the pilot quickly and easily Anti-reflective coating for improved visibility in bright sunlight Low power - typically 132mA/1.6W - 27% less than ST70 at x4 measured brightness Supported autopilot modes: Auto; Standby; Pattern; Track; Wind Vane; Power Steer and Jog Steer Simple system and group dimming/illumination Support for multiple data sources SeaTalkng/NMEA2000 and SeaTalk1 connectivity (no bridging required) ACU-200 Autopilot Control Unit (ACU)The rugged ACU (Actuator Control Unit) delivers reliable autopilot drive power and also provides power to the SeaTalkng bus. Choose the ACU that fits your steering system type.Supported Drive UnitsType 1 Linear or Rotary Drive Units (sold separately)Evolution Cabling Kit 1 x SeaTalkng Power Cable (0.4m) 1 x SeaTalkng Backbone Cable (5m) 1 x SeaTalkng Spur Cable (0.4m) 1 x SeaTalkng 5-way Connector Block 2 x SeaTalkng T-piece Connector 2 x SeaTalkng Terminator Specifications:Boat Length - Max (Feet) = NONE Capacity - Max Ram (CU) = NONE Drive Type = NONE Feedback Type = NONE Pilot Type = NONE Remote Capable = NONE Turn Patterns = NONE Vessel Displacement - Max (Pounds) = NONENormalized SKU: T70155UPC Code: 723193774298Raymarine T70155 Literature Download  Quick Reference Guide  Product BrochureRaymarine T70155 Video

Simrad 000-10438-001 AutopilotsSimrad Ethernet adapter Straight RJ45 M to yellow 5 pin F 0.2m (8") Model: 000-10438-001 UPC: 9420024111277 Normalized SKU: 00010438001UPC Code: 9420024111277

Raymarine M81167 Autopilots12v solenoid valve.Normalized SKU: M81167UPC Code: 023193811673

Raymarine M81135 AutopilotsRotary Drive Type 1 - 12VThe rotary drive is designed for power and sailboat systems that can be driven from the helm position through a chain and sprocket (e.g. cable and rod steering system). The outstanding design of the Raymarine rotary drive unit provides smooth, powerful autopilot controlled steering with quiet operation.Optional drive sprockets and modification to the steering chain may be required.Features: Rotary Drive Type 1 12V Specifications: Maximum Boat Displacement: 11,000 kg Peak Output Torque: 20 nm Maximum Shaft Speed: 33 rpm Recommended Hard-Over Time (no load): 10 seconds Power Consumption: 24-48w Corepack Used: ACU-200 Normalized SKU: M81135UPC Code: 723193811351

Raymarine M81134 AutopilotsM81134 Type 2 Long Mechanical Linear Drive - 24VRaymarine's most commonly used drive types for sailing vessels. Raymarine mechanical linear drives provide powerful thrust, fast hard-over times and quiet operation. Mounted below decks, the linear drive moves the rudder directly by pushing the tiller arm or a rudder quadrant.A linear drive unit connects to the rudder stock via an independent tiller arm. Accessory fittings from your steering manufacturer may be required. Must be able to back-drive steering system from the rudder.Features Drive Type: Type 2 Long Maximum boat displacement: 20,000kg (44,000 lb) Peak thrust: 480 kg (1050 lb) Maximum stroke: 400 mm (16") Hard-over to hard-over times: 14 seconds Maximum rudder torque: 1,660 nm (14,700 lb.in) Power consumption: 48-72W Corepack used: ACU-400 Normalized SKU: M81134UPC Code: 023193811345

Raymarine M81136 AutopilotsRotary Drive Type 2 - 12VThe rotary drive is designed for power and sailboat systems that can be driven from the helm position through a chain and sprocket (e.g. cable and rod steering system). The outstanding design of the Raymarine rotary drive unit provides smooth, powerful autopilot controlled steering with quiet operation.Optional drive sprockets and modification to the steering chain may be required.Features: Rotary Drive Type 2 12V Specifications: Maximum Boat Displacement: 20,000 kg Peak Output Torque: 34 nm Maximum Shaft Speed: 33 rpm Recommended Hard-Over Time (no load): 10 seconds Power Consumption: 60-84w Corepack Used: ACU-400 Normalized SKU: M81136UPC Code: 723193811368

Raymarine M81166 AutopilotsDouble Pilot check valve.Normalized SKU: M81166UPC Code: 023193811666

Raymarine M81122 AutopilotsReversing hydraulic pump for use with steering systems equipped with 21-30.5 cubic inch (350-500 cc)hydraulic steering rams. Compatible with S3 Series corepacks.Normalized SKU: M81122UPC Code: 023193811222
