Lowrance Qualifies for Free Shipping Lowrance Elite-5 Ti Touch Med-High-455-800 Totalscan #000-12423-001

Lowrance Elite-5 Ti Touch Med-High-455-800 Totalscan #000-12423-001

$645.38 $781.51 -18% OFF

Lowrance Elite-5 Ti Touch Med-High-455-800 Totalscan #000-12423-001

$645.38 $781.51 -18% OFF

Lowrance Elite-5 Ti Touch Med-High-455-800 Totalscan #000-12423-001

$645.38 $781.51 -18% OFF
Brand: Lowrance

SKU: LOW-000-12423-001

UPC: 9420024143179

Category: Fishfinders

More about this item
  Download Literature

Lowrance 000-12423-001 Fishfinders

Elite-5 Ti Touch Combo w/TotalScan Transom Mount Transducer

The Lowrance® Elite-5 Ti is a touchscreen fishfinder/chartplotter that matches high-end functions and features with powerful performance - all at an affordable price.

Sporting a 5", high-resolution touchscreen display, the Elite-5 Ti has your sonar needs covered with StructureScan® HD compatibility and support for Low/Mid/High CHIRP and 83/200 /455/800kHz frequencies. It has a built-in GPS antenna and trusted Lowrance navigation features, allowing you to navigate with ease.The Elite-5 Ti also features integrated Bluetooth® and wireless connectivity that not only allows you to download software updates directly to the unit, but gives you the capability to download Insight Genesis custom maps to the unit - for immediate use - directly from the water.

Features:
  • High resolution display:Lowrance-exclusive, high-resolution, 5", LED-backlit color display
  • Easy-to-use touchscreen:Touchscreen provides fast, fingertip access to all Elite-5 Ti features
  • CHIRP Sonar, StructureScan®and DownScan Imaging™:Top-of-the line sonar technologies provide the best possible view of the environment beneath your boat. StructureScan requires TotalScan transducer
  • TrackBack™:Scroll back through your sonar, SideScan or DownScan history to review structure or fish targets and mark the location with a waypoint
  • Internal GPS antenna:Highly accurate, built-in GPS antenna plus a detailed U.S. map
  • Optional chart upgrades:Optional Americas chart upgrades include Lake Insight™ and Nautic Insight™ PRO and HD, Navionics HotMaps® Premium and Fishing Hotspots® PRO. Global chart upgrade options include Navionics + and Jeppesen C-MAP MAX-N
  • Built-in wireless connectivity:Provides access to the GoFree Cloud where you can shop, purchase, download and immediately use Insight maps, and third-party maps from GoFree partners
  • microSD card slot
  • Quick Release bracket


Specifications:

Overview:
  • Display:5"/ 127mm (16:9)
  • Resolution:480W x 480H
  • Backlighting:LED
  • Power Output:Max 500W RMS
  • Languages:31 - Available in regional language packs
  • Media Port:1 microSD slot
  • Power Supply (Supply voltage):12 VDC (10-17 VDC min-max)
  • Current Draw [kW]: 12 W (0.9 A @ 13 vDC)


Sonar
  • DownScan Imaging™ at 455 kHz: Max 300' / 91M
  • SideScan Imaging at 455kHz: Max 300' /91M to each side
  • CHIRP Sonar High Range/200 kHz: 1000' / 305M
  • CHIRP Sonar Med Range/83 kHz: 1000' / 305M

Available Sonar Frequencies
  • Low/Mid/High CHIRP
  • 50/83/200 kHz Broadband
  • 455/800 kHz SideScan/DownScan imaging
  • Depth Alarm:Yes
  • Shallow Alarm:Yes
  • Temperature Readings:Yes
  • Transducer Type: Multiple Selections Lowrance and Airmar


GPS Navigation
  • Navigation: Routes:100
  • Navigation: Waypoint Storage:3000
  • Plot Trails:Up to 100 trails with up to 10,000 points per trail
  • GPS Antenna Type:10kHz Internal high-sensitivity WAAS/EGNOS/MSAS
  • GPS Alarms:Yes
  • Custom Mapping:Lake Insight™ and Nautic Insight™ PRO and HD, Insight Genesis™, Navionics® Gold and HotMaps® Premium, Fishing Hotspots® PRO (US Models) and Jeppessen C-Map Max-N
  • Networking:NMEA 0183 and NMEA 2000®


Comes with
  • Display
  • Mounting Bracket (QRB-5)
  • Power Cable (000-0127-49)
  • Med/High/455/800 TotalScan Transom Mount Transducer
    (000-12568-001)

Specifications:

Basemap = Yes
Card Format = Micro SD
Cartography - Preloaded = No
Cartography Brand = Navionics/C-Map-N
Cartography Type = Gold/HotMaps Premium/C-Map-N
Frequency = 83/200/455/800
Included Transducer = 000-12568-001
Internal/External Antenna = Internal
Resolution (VxH) = 480 x 480
Screen Size = 5"
Screen Type = Color
Speed/Temp = Temp Only
Touchscreen = Yes
Transducer Type = Transom Mount
Waterproof Rating = Waterproof
Watts RMS - Max = 500W
Waypoints/Routes = 3,000/100
Weather Capable = No


Normalized SKU: 00012423001
UPC Code: 9420024143179

Lowrance 000-12423-001 Literature Download

  Quick Reference Guide
  Owners Manual
Qualifies for Free Shipping
This item qualifies for free shipping when the order is over $149
$645.38 $781.51 -18% OFF
