Garmin Qualifies for Free Shipping Garmin ECHOMAP UHD 72sv Reman WorldWide Basemap GT56 Ducer #010-N2518-01

Garmin ECHOMAP UHD 72sv Reman WorldWide Basemap GT56 Ducer #010-N2518-01

$475.48 $593.45 -20% OFF

Garmin ECHOMAP UHD 72sv Reman WorldWide Basemap GT56 Ducer #010-N2518-01

$475.48 $593.45 -20% OFF

Garmin ECHOMAP UHD 72sv Reman WorldWide Basemap GT56 Ducer #010-N2518-01

$475.48 $593.45 -20% OFF
Brand: Garmin

SKU: GAR-010-N2518-01

Category: Fishfinders

More about this item

Garmin 010-N2518-01 Fishfinders

Garmin ECHOMAP™ UHD 72sv with GT56UHD-TM Transducer

Model: 010-N2518-01
  • See below and around your boat in incredible detail with optional transducer
  • Navigate any waters with preloaded BlueChart® g3 coastal charts
  • Share data with other devices on your network (7" and 9" models only)
  • Manage your marine experience from nearly anywhere
  • Control the most powerful trolling motor available
  • Create your own maps on the fly and tailor them to fit your needs

The sunlight-readable 7" touchscreen chartplotter features a quick-release bail mount, and the transducer bundle adds Ultra High-Definition scanning sonar and CHIRP traditional sonar.

This chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time.

High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.

Select the transducer bundle to add a GT56 transducer for Garmin CHIRP traditional sonar and Ultra High-Definition ClearVü and SideVü scanning sonars. With three scanning sonar frequencies and 20% greater range for our UHD SideVü sonar, you’ll get top performance at all depths.

Experience unparalleled coverage and detail with support for optional BlueChart® g3 Vision coastal charts featuring integrated Garmin and Navionics® content.

Create personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on the Garmin Connect™ app3.

If you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, the 7" and 9" models can share information — such as sonar, user data and charts — with them.

Connect to your compatible autopilots, digital switching, weather, Fusion-Link™ audio system, media, VHF, AIS, engine data, heading sensors — such as the SteadyCast™ sensor — and more from one screen.

Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications, software updates, Garmin Quickdraw™ Community data and more1.

Take control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter.

Connect this chartplotter to different kinds of engines — including select Mercury and Yamaha® models — to see RPMs, fuel flow, temperature, trim and other important information at a glance. You may need additional hardware, so be sure to check with your engine manufacturer.

Specifications
General
Physical dimensions 9.8" x 5.5" x 2.0" (25 x 13.9 x 5.1 cm)
WEIGHT 1.7lbs
WATERPROOF IPX7
TOUCHSCREEN Yes
DISPLAY TYPE WVGA, NP
DISPLAY SIZE 6.1" x 3.4"; 7.0" diagonal (15.5 x 8.6 cm; 17.8 cm diagonal)
DISPLAY RESOLUTION 800 x 480 pixels
MOUNTING OPTIONS MOUNTING OPTIONS
INPUT Touchscreen with Keyed Assist
Maps & Memory
ACCEPTS DATA CARDS 1 microSD card; 32 GB maximum size
WAYPOINTS 5000
TRACK POINTS 50,000
TRACKS 50 saved tracks
NAVIGATION ROUTES 100
Sensors
GPS Yes
HAS BUILT-IN RECEIVER Yes
RECEIVER 5 Hz
NMEA 2000 COMPATIBLE Yes
NMEA 0183 COMPATIBLE Yes
SUPPORTS WAAS Yes
Built-in Maps
TIDE TABLES Yes
Optional Map Support
BLUECHART G3 Yes
BLUECHART G3 VISION Yes
LAKEVü G3 Yes
LAKEVü G3 ULTRA Yes
GARMIN NAVIONICS+™ Yes
GARMIN NAVIONICS VISION+™ Yes
TOPO 100K Yes
STANDARD MAPPING Yes
GARMIN QUICKDRAW CONTOURS Yes
Chartplotter Features
AIS Yes
DSC Yes
SUPPORTS FUSION-LINK™ COMPATIBLE RADIOS Yes
ACTIVECAPTAIN® COMPATIBLE Yes
WIRELESS REMOTE COMPATIBLE Yes
SAILING FEATURES Yes
Sonar Features
TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)
POWER OUTPUT 500 W
CLEARVü built-in 260/455/800/1000/1200 kHz
SIDEVü built-in 260/455/800/1000/1200 kHz
PANOPTIX™ SONAR Yes
LIVESCOPE Yes
Connections
NMEA 2000® PORTS 1
CONNECTIONS NMEA0183 INPUT PORTS 1
NMEA 0183 INPUT (TX) PORTS 1
GARMIN MARINE NETWORK PORTS 1 Panoptix™ port
12-PIN TRANSDUCER PORTS 1

What's in the Box:
  • ECHOMAP UHD 72sv with worldwide basemap
  • GT56UHD-TM transducer
  • Power/data cable
  • Tilt/swivel mount with quick release cradle
  • Flush mount
  • Protective cover
  • Hardware
  • Documentation

  • Normalized SKU: 010N251801
