Kuuma Products 11841 Water Heaters Built from a marine-quality aluminum alloy. A large diameter dual-loop heat exchanger is standard. 120V 1500-watt heater element. Marine UL listed. The high temp limiter with manual reset is at the circuit breaker panel, not inside the heater itself. 11 Gallon Capacity 120V Operation at 60Hz Amp Draw 12.5A Suggested Breaker 15A Suggested Wire Size: Stranded #12-3 Tank and Exterior Jacket are Composed of Aluminum Alloy 1500 watt Heating Element (MFG# 02858) Thermostat (MFG# 11930) High Temp Limiter (MFG# 11920) Anode (MFG# 11916 or 11919) T & P Valve (MFG# 10473) Cold Water Inlet 1/2” Female NPT Warm Water Outlet 1/2” Female NPT Engine Water Inlet/Outlet 5/8" O.D. Unit Dimensions: 16.25” High X 16.25” Wide X 23.25” Deep 1-Year Limited Warranty Normalized SKU: 11841UPC Code: 202400001100

Kuuma Products 11811 Water HeatersBuilt from a marine quality aluminum alloy. Large diameter dual loop heat exchanger is standard. 120V 1500 watt heater element. Marine UL listed. The high temp limiter with manual reset is at the circuit breaker panel, not inside the heater itself.Normalized SKU: 11811UPC Code: 202400001001

  Download Literature Raritan 170601 Water Heaters 1700 Series Water Heater120v6 GallonW/O Engine Heat ExchangerThe "1700 Series" water heater provides hot water for the galley and shower. Dense foam insulation provides better and longer heat retention than traditional fiberglass. The tank itself is protected by a 75 PSI T& P ( temperature and pressure) relief valve. The cylindrical design of the tank enables it to withstand more pressure than a cube-shaped tank.Heat exchanger models can be connected to the engine cooling system. This provides the added convenience of hot water when underway or generator power is not available. The innovative heat exchanger is over seven feet in length and is evenly coiled throughout the interior of the tank, providing hot water rapidly and efficiently.Raritan's water heaters use an ignition-protected thermostat. Although it is factory set to 120°F, it is adjustable from 110° to 160°F and has a safety shut-down limit of 190°F. All models and sizes have the plumbing connections on the same side to simplify installation. Hot and cold water connections are 3/4" male NPT (National Pipe Thread). Heat exchanger connections are 3/4" female NPT.Benefits: Simple installation - retrofits to most on-board pressure systems Proven long-life design Withstands the rigors of the marine environment Glass-lined steel tank is more durable than stainless steel Attractive polymer jacket resists corrosion from dampness Ignition-protected, adjustable thermostat Round tanks are designed to withstand more pressure than square tanks Glass-lined steel tank for long life and high efficiency Environmentally friendly CFC-free foam insulation Replaceable magnesium anode to protect tank and neutralize acids in the water The tank is covered by a five-year Limited Warranty Each unit is assembled by hand, individually tested, and backed by Raritan's two-year Limited Warranty and legendary technical support team Specifications: Volts = 120v Heat Exchanger = No Gallons = 6 Normalized SKU: 170601UPC Code: 085462001475 Raritan 170601 Literature Download   Owners Manual  Product Brochure

Download LiteratureWhale WX1599B Water HeatersSeaward Thermostatic Mixer ValvePlumbing "safety fitting" for the Whale "Quick Connect" system. Thermostatic mixer valve using three 1/2" BSP Male threaded ports.Constructed of nickel-plated brass including non-return valve. Each BSP running thread is fittted with O-ring.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: WX1599BUPC Code: 766478941558Whale WX1599B Literature Download Product Brochure

  Download LiteratureWhale S700E Water HeatersSeaward 6 Gallon Hot Water Heater - Stainless Steel - 120V - 1500WWhale Electric Water Heaters includes model with the very latest technology. All heaters are manufactured from the highest quality materials and designed to specifically withstand harsh marine conditions.Water Heaters with a Stainless Steel cover offer high levels of corrosion resistance with a modern stainless steel finish. These heaters are a bit lighter than those wearing the galvanized outer cover and heavier than the epoxy coated versions.Features and Benefits: Horizontal Mounting only   Robust Manufacturing Hold down brackets welded to inner tank Double wall heat exchangers   Safety controls   Integrated pressure relief valve Temperature and pressure drain tube included   Magnesium anodes available separately Recommended to prevent corrosion and ensure a longer Water Heater life   Sturdy, robust exteriors Ignition protected WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: S700EUPC Code: 766478948267Whale S700E Literature Download  Product Brochure

  Download LiteratureWhale S650 Water HeatersSeaward 6 Gallon Hot Water Heater with Rear Heat Exchanger - Galvanized Steel - 240V - 1500WWhale Electric Water Heaters includes model with the very latest technology. All heaters are manufactured from the highest quality materials and designed to specifically withstand harsh marine conditions.The Marine Galvanized Steel Cover offers corrosion resistance at an affordable price. This material weighs more than the other case options but is made from a strong and robust material  Features and Benefits Horizontal Mounting only Robust Manufacturing Hold down brackets welded to inner tank Double wall heat exchangers Safety controls Integrated pressure relief valve Temperature and pressure drain tube included Magnesium anodes available separately Recommended to prevent corrosion and ensure a longer Water Heater life Sturdy, robust exteriors Ignition protected. WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: S650UPC Code: 766478948229Whale S650 Literature Download  Owners Manual  Product Brochure

  Download LiteratureWhale S600EW Water HeatersSeaward 6 Gallon Hot Water Heater - White Epoxy - 120V - 1500WWhale Electric Water Heaters includes model with the very latest technology. All heaters are manufactured from the highest quality materials and designed to specifically withstand harsh marine conditions.The White Epoxy Coated Aluminium cases are well-suited to installation in many of today’s engine rooms. Their white appearance blends in well with existing equipment and the coated aluminium material offers corrosion resistance.Features and Benefits:  Horizontal Mounting only   Robust Manufacturing Hold down brackets welded to inner tank Double wall heat exchangers Safety controls   Integrated pressure relief valve Temperature and pressure drain tube included Magnesium anodes available separately Recommended to prevent corrosion and ensure a longer Water Heater life Sturdy, robust exteriors Ignition protected WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: S600EWUPC Code: 766478948212Whale S600EW Literature Download  Owners Manual  Product Brochure
