Scanstrut APT-F-250-01 Mounting HardwarePowerTower® 10" Aluminum Forward Leaning 2kW/4kW for Raymarine, Garmin & Navico BR24, 3G & 4GFor Radomes, Open Array and Small SatCom/TV AntennaExpertly designed to install your antenna on the cabin roof, flybridge or radar arch of your powerboat, providing a clear view of the horizon for maximum antenna performance.Features: Choice of Heights: 150mm (6”) for low level clearance of smaller obstacles or 250mm (10”) for greater clearance and increased radar horizon. Ease of Install: Pre-drilled mounting holes, the antenna fastens to PowerTower top plate using its own mounting bolts. Features of the PowerTower® Range: Internally Mounted Scanstrut DS30 cable seal Marine Sealant not required No need to cut cable of remove plugs Inserts included to fit cables from all major radomes Specifications:Light/GPS Bracket = Optional Lean (FWD/Aft) = FWD Construction = Powder Coated AluminumNormalized SKU: APTF25001UPC Code: 5060114796492

Download LiteratureScanstrut APT-250-02 Radar MountAPT-250-02 - Aluminum PowerTower® Radar Mount - 10" Aft LeaningThe Scanstrut Aluminum PowerTower is engineered for outstanding strength and with an unparalleled surface finish. Manufactured using the best marine grade Aluminium, PowerTower® is molded as a single 'monocoque' structure with no joints, offering unparalleled strength and durability.Designed to install your radar on the roof, T-top, flybridge, or radar arch of your powerboat, providing the clearest view of the horizon allowing you to get the best performance from your radar in all conditions. By elevating your antenna clear of obstructions, PowerTower® maximizes the performance of your radar.There is a PowerTower® to fit pretty much every modern radar.Compatible with: Furuno - 1621, 1622, 1623, 1715, 1724, 1734, 1815, 1824, 1832, 1834, 1835, DRS2D, DRS2D-NXT, DRS42DL, DRS42DL+, DRS4D/DRSD4D-NXT, DRS4W, NavNet (18" and 24") radars Humminbird - AS 21 RD4KW radar Intellian - i1 radars Interphase - Mini RE-1, RE-8 radars JRC - 1000, 1000mk2, 1066, 1500, 1500mk2, 1800, 2000, JMA 2343 / 5104 (Radome: NKE-2042) radars Koden - 2kW 12" radar KVH - TracVision M1 and TV1 radars Lowrance - 3G/4G, LRA-1800, RB714A, DX42, LRA-2400 HD radars Majestic - SATMAR32 radar Navman - 8000 Series (8084 and 8120) 18" radars Nobletec - 2kW - 20" radars Northstar - M Series 18" and 24"  8000i radars Raymarine - 33STV radars Seiwa - SWR-1, 8, 9 radars Simrad - 3G/4G, GB40, NX40/45, NSE8/12, RB712A, DX42S, DX64S radars Sitex - MDS-1, 8, 12, NKE-1066 radars Techmarine - T-72.01, 72.02, 72.04 Radars Features: Designed to fit the most up to date radars Pre-drilled mounting holes allow the radar to fasten straight to the PowerTower® No need to cut the radar’s connectors off for installation  Constructed from the best Marine grade Aluminium A range of accessories light bars can be bolted to the back of the PowerTower® Technical Specifications: Radar Type - Dome Material - Aluminium Height - 9.84" (250mm) Mounting Type - Aft leaning - 25° In the Box: Mount Mounting hardware (excluding screws/bolts)  Installation manual *Sold as an Individual Normalized SKU: APT25002UPC Code: 5060114797734Scanstrut APT-250-02 Literature Download Quick Reference Guide

  Download LiteratureScanstrut APT-150-01 Mounting Hardware6" Aluminum PowerTower® for 2kW/4kW Raymarine; Garmin & Navico 3G/4G RadomesFeatures: Central Accessory Bar with Easy-Fit Mount System for Fast Installation 100% Watertight Installation; No Sealant Required No Visible Cables Specifications:Construction = NONE Lean (FWD/Aft) = NONE Light/GPS Bracket = NONENormalized SKU: APT15001UPC Code: 5060114795402Scanstrut APT-150-01 Literature Download  Quick Reference Guide  Product Brochure

Download LiteratureScanstrut APT-150-01-BLK Antenna MountsPowerTower 6" Aluminum 2kW/4kW Raymarine, Garmin, Navico BR24/3G/4G Radomes Aft Lean - BlackBlack Scanstrut APT-150-01-BLK 150mm (6”) Aluminium PowerTower for 2kW/4Kw Raymarine: Garmin and Navico BR24/3G/4G radomesFOR RADOMES AND SMALL SATCOM/TV ANTENNAExpertly designed to install your antenna on the cabin roof, flybridge or radar arch of your powerboat, providing a clear view of the horizon for maximum antenna performance.FEATURES:150mm (6”) for low level clearance of smaller obstaclesEASE OF INSTALLPre-drilled mounting holes, the antenna fastens to PowerTower top plate using its own mounting bolts.FEATURES OF THE POWERTOWER RANGE: Internally Mounted Scanstrut DS30-BLK cable seal Marine Sealant not required No need to cut cable or remove plugs  Inserts included to fit cables from all major radomes Normalized SKU: APT15001BLKUPC Code: 5060114797680Scanstrut APT-150-01-BLK Literature Download Quick Reference Guide

Scanstrut APT-F-150-01 Mounting HardwarePowerTower® 6" Aluminum 2kW/4kW Raymarine, Garmin & Navico BR24/3G/4G - Forward LeaningFor Radomes, Open Array & Small Satcom/TV AntennaExpertly designed to install your antenna on the cabin roof, flybridge or radar arch of your powerboat, providing a clear view of the horizon for maximum antenna performance.Features:Choice of Heights: 150mm (6”) for low level clearance of smaller obstacles or 250mm (10”) for greater clearance and increased radar horizon.Ease of Install: Pre-drilled mounting holes, the antenna fastens to PowerTower top plate using its own mounting bolts.Additional Features: Internally Mounted Scanstrut DS30 cable seal Marine Sealant not required No need to cut cable of remove plugs Inserts included to fit cables from all major radomes Specifications:Construction = Aluminum Lean (FWD/Aft) = FWD Light/GPS Bracket = NONENormalized SKU: APTF15001UPC Code: 5060114796485

Scanstrut APT-150-02 Mounting HardwareAluminum PowerTower® for Furuno DomesThe Scanstrut PowerTower has been designed and engineered to install your radar on the roof, T-top, flybridge, or radar arch of your powerboat, providing the clearest view of the horizon allowing you to get the best performance from your radar in all conditions.Maximize your Radar's performance150mm (6”) high and constructed from the best marine-grade aluminum, designed to fit the most up-to-date radars from Furuno.Features: Pre-drilled mounting holes allow the radar to fasten straight to the PowerTower with it’s own mounting bolts. Marine sealant not required Paint finishes comply with our unique 4 step marine paint system Available in Aft or Forward leaning designs with a 25-degree rake for the ultimate performance look Range of accessorizing light bars can be bolted to the back of the PowerTower for different GPS, VHS and Navlight configurations An accessory PowerTower Wedge is available to improve the pitch of the Radar while the boat is up on the plane. Normalized SKU: APT15002UPC Code: 5060114797710

Scanstrut APT-F-150-02 Mounting HardwareAluminum PowerTower® 6" Forward Leaning for Furuno RadomesThe Scanstrut PowerTower has been designed and engineered to install your radar on the roof, T-top, flybridge, or radar arch of your powerboat, providing the clearest view of the horizon allowing you to get the best performance from your radar in all conditions.Maximize your Radar's performance150mm (6”) high, forward learning, and constructed from the best marine-grade aluminum, designed to fit the most up-to-date radars from Garmin, Lowrance, Raymarine, and Simrad.Features: Pre-drilled mounting holes allow the radar to fasten straight to the PowerTower with its own mounting bolts. No need to cut the radar’s plugs off to install, simply use the Scanstrut DS30 Cable Seal to ensure a waterproof seal around the radars cables. Marine sealant not required Paint finishes comply with our unique 4 step marine paint system Available in Aft or Forward leaning designs with a 25-degree rake for the ultimate performance look Range of accessorizing light bars can be bolted to the back of the PowerTower for different GPS, VHS, and Navlight configurations An accessory PowerTower Wedge is available to improve the pitch of the Radar while the boat is up on the plane. Normalized SKU: APTF15002UPC Code: 5060114797741

  Download LiteratureScanstrut APT6003 Mounting Hardware6" Aluminum PowerTower® for Open Array Raymarine (4'), Furuno (2') & Navico HALO™ (3', 4', 6')Features: Expertly designed to install your antenna on the cabin roof, flybridge or radar arch of your powerboat Achieve a clear view of the horizon for maximum antenna performance 150mm (6") tall Compatible with Raymarine, Furuno and Navico Open Array Specifications:Construction = NONE Lean (FWD/Aft) = NONE Light/GPS Bracket = NONENormalized SKU: APT6003UPC Code: 5060114795372Scanstrut APT6003 Literature Download  Quick Reference Guide

Scanstrut PT3010 Mounting HardwareBenefitsDesigned to provide a level horizon for your radar when your boat is bows up and on the plane, maximizing the performance of your antenna.Simple to install and supplied with our excellent pre-fitted watertight base seal, our base wedges can be stacked on top of one another to compensate for greater trim angles.Part numbersPT3010 - Made from marine grade polymer. Fits below all Composite and Aluminium PowerTower bases Specifications:Lean (FWD/Aft) = NONE Light/GPS Bracket = NONE Construction = NONESCANSTRUT POWERTOWER BASE WEDGE 4 DEGREE FOR COMP. AND Normalized SKU: PT3010UPC Code: 5060114790438

Scanstrut SC27 Mounting HardwareSC27 Radar GuardPolished Stainless Steel Guards Protect Radome from damage and reduce wear on the sails.Features: Mounting using radome bolts, no extra fastenings required Easy to fit - between mast mount and radar antenna Manufactured from marine grade 316 stainless steel Compatible Devices: SC20 M92722 Specifications:Construction = Stainless Steel Lean (FWD/Aft) = NONE Light/GPS Bracket = NONENormalized SKU: SC27UPC Code: 5060114790193
