Download LiteratureMaretron NBE100-01 Network AccessoriesNetwork Bus ExtenderPart #: NBE100-01Maretron's NBE100 (Network Bus Extender) allows you to extend the maximum node count, network trunk length and cumulative drop length of any NMEA 2000 network. The NBE100 solves bus errors and other electrical issues caused by exceeding any of these limitations and makes design of large networks easier. NMEA 2000 networks have a maximum of 50 nodes allowed on a single network, a maximum network trunk length of 200m and a maximum cumulative drop length of 78m. If you have a network that exceeds any of these specifications, you can simply disconnect the network trunk in the middle and connect the ends to the NBE100, along with additional termination resistors. This will split the network into two electrical segments, each of which can have up to 50 nodes, for a total of 100 nodes on the logical network. The NBE100 will transparently route NMEA 2000 messages between the two network segments, making them work as a single logical NMEA 2000 network. Advanced priority-based message routing ensures that higher-priority messages are always prioritized over lower-priority messages, enabling predictable and reliable network operation.Features: Segments a single large NMEA 2000 network into two smaller electrical segments Allows you to exceed the 50 node limitation on a NMEA 2000 network Allows you to exceed the 200m trunk length limitation on a NMEA 2000 network Allows you to exceed the 78m cumulative drop length limitation on a NMEA 2000 network Allows all NMEA 2000 devices to operate as if they were still on a single NMEA 2000 network Priority-based message routing ensures higher-priority messages get through the bus extender first Optically isolates network segments, increasing signal integrity and network reliabilityWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: NBE10001UPC Code: 873804003078Maretron NBE100-01 Literature Download   Owners Manual

Maretron MN2KKIT Network AccessoriesMaretron NMEA 2000 Starter KitBuilding a New NMEA 2000 Network onboard? Save when buying this Maretron NMEA 2000 Starter Kit. Everything you need for a basic NMEA 2000 Bus/Network or to start a complex one. Please see the ACCESSORIES tab above if additional equipment is neededThe Kit Includes: One Micro/Mid Powertap Tee CF-SPWR05-CF Two Micro Tee CM-CF-CF Two Micro Terminators TR-CM One 3 meter Cordset CM-CG1-CF-03.0 Specifications:Load Equivalence # (LEN) = NONENormalized SKU: MN2KKIT

Maretron CABLE-STARTER-2 Network AccessoriesNMEA 2000 Starter Kit 2 Maretron's deluxe starter kit provides all the necessary cables and connectors necessary to connect two products together on an NMEA 2000® network.   Contacts are gold-plated brass and couplings are nickel-plated brass for durability and reliability.Included in the Box: (1) 5-Meter Micro Powertap Cable (CF-SPWR05-CF) (1) 10-Meter Micro Trunk/Backbone Cable (CM-CG1-CF-10.0) (2) Micro Tees (CM-CF-CF) (2) 2-Meter Micro Drop Cables (CM-CG1-CF-02.0) (2) Micro Terminators (TR-CM) *Sold as a Kit Normalized SKU: CABLESTARTER2

Maretron CABLE-STARTER-KIT Network AccessoriesCable-Starter-KitMaretron's Cable-Starter-Kit provides all the necessary cables and connectors necessary to connect two products together on an NMEA 2000® network. Includes: Powertap for powering the products (1) 10M trunk or backbone cable (2) tees (2) 2M cables for crating branch or stub connections to the individual products (2) terminators for proper termination of the NMEA 2000® network. The network is easily expanded by adding a tee and branch cable for each additional product that is added to an NMEA 2000® network. Specifications:Load Equivalence # (LEN) = NONENormalized SKU: CABLESTARTERKITUPC Code: 873804003573

  Download LiteratureMaretron J2K100-01 Network AccessoriesJ2K100 NMEA 2000® / J1939 Bridge (Engine/Transmission/Genset Gateway)Maretron's J2K100 attaches directly into J1939 networks of compatible engines, transmissions, and gensets and converts the J1939 engine data to the NMEA 2000® marine digital interface. Critical engine, transmission, and genset data is then distributed throughout the vessel over a single cable where it can be monitored by any NMEA 2000® compatible display. All the information you need is available anywhere and everywhere you need it.The J2K100 only listens to the J1939 network and draws no power from it (power is derived from the NMEA 2000® interface). The J2K100 does not transmit any information over the J1939 network so it will not interfere with existing engine control or status data in any way. The J2K100 can also be used as part of a complete fuel computer. Simply connect the J2K100 together with the Maretron universal display (DSM200) and GPS antenna/receiver (GPS100) and you have a system capable of displaying gallons per hour and/or miles per gallon. Features: AC Generator Current AC Generator Frequency AC Generator Voltage Tachometer Engine Hours Coolant Pressure Coolant Water Temperature Engine Oil Pressure Engine Oil Temperature Boost Pressure Fuel Rate Monitoring Percent Engine Torque Rated Engine Speed VIN Software ID Transmission Gear Transmission Oil Pressure Transmission Oil Temperature WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. MARETRON J2K100-01 J1939 TO NMEA 2000 BRIDGENormalized SKU: J2K10001UPC Code: 873804000077Maretron J2K100-01 Literature Download  Quick Reference Guide  Owners Manual

Maretron QCM-CG1-QCF-01 Network AccessoriesNylon to Metal Connector CableSome products use inexpensive nylon connectors and when connected with metal connectors, the nylon threads can be damaged. This cable eliminates the problem by allowing nylon to nylon connections and metal to metal connections. NMEA 2000® Approved Waterproof rated to IP67 Specifications:Load Equivalence # (LEN) = NONENormalized SKU: QCMCG1QCF01UPC Code: 873804700267

Maretron DSM250CVR2PK-02 Network Accessories2 Covers for Maretron's DSM250 Multi-Function Color DisplayCovers are used to protect the DSM250 from the harsh marine environment.Maretron's DSM250 is a high-resolution sunlight viewable color display that allows easy interpretation of NMEA 2000r instrument and navigation data through custom display configurations, featuring an easy-to-use five-key illuminated keypad. Normalized SKU: DSM250CVR2PK02UPC Code: 873804002811

Maretron PT-0-1.5PSI-01 Network AccessoriesPressure Transducer 0 to 1.5 PSIFor use with FPM100 Fluid Pressure MonitorWARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Specifications:Load Equivalence # (LEN) = NONENormalized SKU: PT015PSI01UPC Code: 873804003740

Maretron PT-0-50PSI-01 Network AccessoriesPressure Transducer 0 to 50 PSIAll Maretron pressure transducer assemblies are equipped with a 1/4” NPT male threaded fitting. Install the pressure transducer to a ¼” NPT female fitting on the system or tank to be monitored with a maximum torque of 150 in-lbs (16.95 Nm). If you are monitoring a system where pressure spikes or transients will occur, or where the pressure will exceed the maximum pressure rating of the pressure transducer, install a Pressure Snubber (PT-SNUB-01) onto the system being monitored first, then install the pressure transducer to the female port on the pressure snubber.WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Specifications:Load Equivalence # (LEN) = NONENormalized SKU: PT050PSI01UPC Code: 873804002927
