Download LiteratureGarmin 010-11937-22 TransducersAirmar B175Hw/20° Tilt1kWFlush-mounted bronze housing protrudes less than 1/4" outside hull and can sit on trailer rollers/bunks without damage. Tilted element inside the transducer accommodates all hull deadrises and eliminates the need for a fairing block. Low, medium, and high frequency versions provide maximum flexibility for the choice of frequencies. Excellent for fiberglass and wood hulls.Max Depth - 3,000'Suppoarted Deadrise/Transom Angles - 16-24° DeadriseWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0101193722UPC Code: 753759995706Garmin 010-11937-22 Literature Download Owners Manual Product Brochure

Garmin 010-12181-22 TransducersBronze Thru-hull Wide Beam Transducer w/Depth & Temp - 20° Tilt, 8-Pin - Airmar B175HWStep up to 1 kW without a fairing with this flush-mounted bronze housing that protrudes less than 1/4-inch outside the hull and can sit on the trailer rollers/bunks without damage.The tilted element inside the transducer accommodates all hull deadrises and eliminates the need for a fairing block. Low, medium, high, and high wide versions provide maximum flexibility for the choice of frequencies.An excellent choice for fiberglass and wood hulls, this 8-pin transducer has a depth of 600'; an operating frequency of 150-250 kHz; a beamwidth of 25°; and a 16 to 24° deadrise.Transducer kit comes with installation instructions. Follow the instructions carefully to avoid damaging your boat.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0101218122UPC Code: 753759123550

Download LiteratureGarmin 010-11938-20 TransducersAirmar B175Lw/0° Tilt1kWFlush-mounted bronze housing protrudes less than 1/4" outside hull and can sit on trailer rollers/bunks without damage. Tilted element inside the transducer accommodates all hull deadrises and eliminates the need for a fairing block. Low, medium, and high frequency versions provide maximum flexibility for the choice of frequencies. Excellent for fiberglass and wood hulls.Max Depth - 3,000'Suppoarted Deadrise/Transom Angles - 0-7° DeadriseWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0101193820UPC Code: 753759995713Garmin 010-11938-20 Literature Download Owners Manual Product Brochure

Download LiteratureGarmin 010-11938-21 TransducersAirmar B175Lw/12° Tilt1kWFlush-mounted bronze housing protrudes less than 1/4" outside hull and can sit on trailer rollers/bunks without damage. Tilted element inside the transducer accommodates all hull deadrises and eliminates the need for a fairing block. Low, medium, and high frequency versions provide maximum flexibility for the choice of frequencies. Excellent for fiberglass and wood hulls.Max Depth - 3,000'Suppoarted Deadrise/Transom Angles - 8-15° DeadriseWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0101193821UPC Code: 753759995720Garmin 010-11938-21 Literature Download Owners Manual Product Brochure

Download LiteratureGarmin 010-11938-22 TransducersAirmar B175Lw/20° Tilt1kWFlush-mounted bronze housing protrudes less than 1/4" outside hull and can sit on trailer rollers/bunks without damage. Tilted element inside the transducer accommodates all hull deadrises and eliminates the need for a fairing block. Low, medium, and high frequency versions provide maximum flexibility for the choice of frequencies. Excellent for fiberglass and wood hulls.Max Depth - 3,000'Suppoarted Deadrise/Transom Angles - 16-24° DeadriseWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0101193822UPC Code: 753759995737Garmin 010-11938-22 Literature Download Owners Manual Product Brochure

Download LiteratureGarmin 010-11939-20 TransducersAirmar B175Mw/0° Tilt1kWFlush-mounted bronze housing protrudes less than 1/4" outside hull and can sit on trailer rollers/bunks without damage. Tilted element inside the transducer accommodates all hull deadrises and eliminates the need for a fairing block. Low, medium, and high frequency versions provide maximum flexibility for the choice of frequencies. Excellent for fiberglass and wood hulls.Max Depth - 3,000'Suppoarted Deadrise/Transom Angles - 0-7° DeadriseWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0101193920UPC Code: 753759995744Garmin 010-11939-20 Literature Download Owners Manual Product Brochure

Download LiteratureGarmin 010-10703-20 TransducersB258 1kW Bronze Thru-Hull Depth/Temp w/FB - 8-PinGarmin's bronze, thru-hull mount transducer with fairing provides depth and temperature data. This transducer has an operating frequency of 50 or 200 kHz and mounts on a 0-25° deadrise angle.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0101070320UPC Code: 753759971892Garmin 010-10703-20 Literature Download Owners Manual Product Brochure

Download Literature Garmin 010-10640-20 Transducers B258 1kW Bronze Thru-Hull Depth/Temp with FB - 8-PinGarmin's bronze, thru-hull mount transducer with fairing provides depth and temperature data. Garmin's transducer has an operating frequency of 50 or 200 kHz and mounts on a 0-22° deadrise angle. General FREQUENCY:  50/200 kHzPOWER:  1 kWBEAMWIDTH:  19°/6°MAXIMUM DEPTH:  1,800-2,500 ft.DEPTH/SPEED/TEMPERATURE:  Depth and TemperatureNUMBER OF PINS:  8-pinCABLE LENGTH:  39 ft.SUPPORTED DEADRISE/TRANSOM ANGLES:  0°-20°degree deadrise WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0101064020UPC Code: 753759971854 Garmin 010-10640-20 Literature Download Owners Manual Product Brochure

Garmin 010-11647-20 TransducersB265LM Bronze Thru-Hull Mount Transducer with Depth & TemperatureGarmin's best performing 1 kW thru-hull transducer, this bare wire mount performs well in deep water and has exceptional bottom and water column detail.This transducer has a depth of 3,000 ft; an operating frequency of 42 to 65 kHz and 85 to 135 kHz; a beamwidth of 16 to 25 degrees and 11 to 16 degrees; and a 0 to 20 degree deadrise.Transducer kit comes with installation instructions. Follow the instructions carefully to avoid damaging your boat.Compatible Devices:GSD™ 26 CHIRP Professional Sonar ModuleWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0101164720UPC Code: 753759972141

Garmin 010-12379-20 TransducersB265LH Bronze Thru-Hull Mount Transducer w/Depth & Temp - 12-PinGarmin's best performing 1 kW thru-hull transducer, this mount performs well in deep water and has exceptional bottom and water column detail.This transducer has a depth of 3,000 feet; an operating frequency of 42 to 65 kHz and 130 to 210 kHz; a beamwidth of 16 to 25 degrees and 6 to 10 degrees; and a 0 to 20 degree deadrise.Transducer kit comes with installation instructions. Follow the instructions carefully to avoid damaging your boat.Compatible Devices: GPSMAP® 7607xsv, 7608xsv, 7610xsv, 7612xsv, 7616xsv GSD™ 25 Premium Sonar Module WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0101237920UPC Code: 753759142414

Garmin 010-12183-20 TransducersB275LH-W Bronze Thru-Hull Transducer - 12-PinGet more coverage under your boat with Airmar’s unique wide beam, high frequency Chirp-ready transducers. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high frequency band results in superior resolution. The constant wide beamwidth provides twice the coverage under the boat and excellent fish arches on the display compared to most high frequency narrow beam transducer options.The included high-performance fairing improves broadband performance at speeds over 30 knots (34 MPH).The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 500'.The low frequency band and 1 kW of power also provides great deeper water performance. Get the best of both worlds with Airmar’s dual frequency Chirp-ready transducers with wide beam coverage.Features: Depth and fast-response water-temperature sensor 1 kW for great deep water performance from the low frequency Low Frequency: 42 kHz to 65 kHz with maximum depth of 914 m (3000') 25° to 16° beamwidth High Frequency: 150 kHz to 250 kHz with maximum depth of 152 m (500')25° constant beamwidth 123 kHz of total bandwidth from one transducer Covers popular fishing frequencies of 50 and 200 kHz plus everything else in the bandwidth High frequency provides superior shallow water performance, bottom detail and fish target separation High wide beamwidth provides more coverage under the boat for detecting fish in the upper water column Bronze transducer housing with high-performance fairing for optimal performance at higher speeds Recommended boat size: 8 m (25') and above Hull Type: Fiberglass or wood Exclusive Xducer ID® technology WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0101218320UPC Code: 753759123574

Download Literature Garmin 010-10982-21 Transducers B60 600W Tilted Element 12° - 8-PinThis entry-level tilted bronze transducer accommodates deadrise angles of 8 to 15 degrees without a fairing.An excellent choice for fiberglass and wood hulls, this 600W 8-pin transducer has a depth of 800' to 1,200'; an operating frequency of 50 to 200 kHz; and a beamwidth of 45 to 12 degrees.The Transducer kit comes with installation instructions. Follow the instructions carefully to avoid damaging your boat.*Do not use on metal hulls. When using with a 6-pin Garmin sounder, a transducer adapter cable is required.   WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0101098221UPC Code: 753759971830 Garmin 010-10982-21 Literature Download Owners Manual Product Brochure

Download Literature Garmin 010-10982-20 Transducers B60 600W Tilted Element - 8-PinGarmin's bronze, thru-hull mount transducer with 20° tilt provides depth and temperature data. Garmin's transducer has an operating frequency of 50 or 200 kHz and mounts on a 16-24° deadrise angle. Style: Thru-hull Cable Length: 39' Connector: 8-pin Maximum Deadrise Angle: 16°-24° degree deadrise Monitors: Depth & Temperature Transmit Power: 600W Frequency: 50/200kHz Max. Depth: 800'-1,200' Beamwidths: 45°/12° WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0101098220UPC Code: 753759971823 Garmin 010-10982-20 Literature Download Owners Manual Product Brochure

Download LiteratureGarmin 010-10217-21 TransducersTilted Element™ Thru-HullMinimize Your DragThe B619 model have been the standard in low-profile models for many years. Their large sensitive ceramics allow deep echosounding up to 206M (700'). These nearly flush units minimize drag as only 5mm (2/10") of the housing extends outside of the hull. The bronze B619 provides a vertical beam without a fairing. Inside the housing, the ceramic element is tilted to provide built-in deadrise compensation. The resulting vertical beam provides excellent echo returns for moreaccurate depth readings.Applications Cruising powerboats and sailboats Sailboats Features Depth only or Depth and temperature Fixed 12° tilted versions for 8° to 15° hull deadrise Right angle cable exit offers low headroom and protection when transducer is stepped on Included rubber washer allows tightening of the hull nut to irregular hull surfaces Housings are ABYC H-27 compliant Optional temperature sensor Bronze housing Boat Size: Up to 9M (30') WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0101021721UPC Code: 753759971724Garmin 010-10217-21 Literature Download Quick Reference Guide Owners Manual Product Brochure
