EGIS 6152 Bus BarsEGIS Cover-BusBar Com 6150-210 / 6150-400 Retail PackModel: 6152Includes Protective Transparent Cover to protect against accidental electrical shock.Normalized SKU: 6152UPC Code: 850067590361

EGIS 6104 Bus BarsEGIS Cover for 6100-205 & 6100-400 Retail PackModel: 6104Includes Proctive Transparent Cover to protect against accidental electrical shock.Normalized SKU: 6104UPC Code: 850067590293

EGIS 6103 Bus BarsEGIS Cover for Dual Bus 10 Circuits Retail PackModel: 6103 Intergrated Protective Transparent Cover the snaps on & off. Breakwaway tabs the allow terminal entry. Normalized SKU: 6103UPC Code: 850074331292

Egis 4731 Circuit BreakersCircuit Breaker Cover, Short Stop - BlackFeatures: Compatible with Egis Mobile Electric's Shorts Stop Circuit Breakers Protects terminal studs from inadvertent contact shorts to ground or other positive terminals. Normalized SKU: 4731UPC Code: 850053879944

EGIS 6254 Bus BarsEGIS Cover MaxiBus 6250-208 / 6250-404 and PowerBar 6600-404 / 6600-804 Retail PackModel: 6254 Intergrated Protective Transparent Cover that snaps on & off. Breakaway tabs that allow terminal entry. Normalized SKU: 6254UPC Code: 850074331483

Download LiteratureEgis 7614 Charger AccessoriesDual Battery Charge Manager - 12VOne Product Handles Two Functions for both auxiliary battery charge management and timed load shedding for add-on circuits.Prevents add-on equipment from draining batteries / maximizes and extends operational readinessProtects sensitive on-board electronics via optional under/over voltage shutdown and start event isolation.Features: Monitors battery voltage and disconnects the load from the battery to prevent further discharge. Lowest off-state current draw (1.3 mA) available. Flexible Control Options via Ignition Key, alternator voltage sense, or both.  Simple & Robust Installation: Sealed plug with optional long wire leads. A single device reduces installation time and costs, and points of potential failure Kill Switch control input options for service technicians, emergency OFF Adjustable OFF Time Delay & Low Voltage Cut-Off: 0 Seconds to 4 hours, Switch only mode, LVD only mode, 11.0, 11.5, 12.0 Vdc cutoff levels. Remote and on-board diagnosis indicators to simplify troubleshooting Bullet-proof Construction: Sealed unit, high-temperature materials allow mounting anywhere. Internal temperature overload protection Start Isolation input protects sensitive add-on equipment from the engine starting event. Meets Stringent OEM Standards for electrical transient self-protection 4 Year Industry-Leading Warranty Normalized SKU: 7614UPC Code: 850035199657Egis 7614 Literature Download Product Brochure

EGIS 6200-225 Bus BarsEGIS Dual Busbar 2x5 Circuit Dual Level 200 A w-Cover Retail PackModel: 6200-225 Dual Level Busbars allow wires and cables to approach from the same direction. Stainless Steel Self-Locking Hardware ensures long term reliablity. Includes Protective Cover with break-away tabs for easy inspection. Normalized SKU: 6200225UPC Code: 850074331308

EGIS 6200-229 Bus BarsEGIS Dual Busbar 2x9 Circuit Dual Level 200 A w-Cover Retail PackModel: 6200-229 Dual Level Busbars allow wires and cables to approach from the same direction. Stainless Steel Self-Locking Hardware ensures long term reliablity. Includes Protective cover with break-away tabs for easy inspection. Normalized SKU: 6200229UPC Code: 850074331315

Download LiteratureEgis 7422 RelaysTH3 Dual Relay 2 x 80A - 12VFeatures: Replaces Manual Battery Switches: Reduces battery cable run lengths and resulting voltage drop Connect to the Ignition Signal for simple battery charge management between two batteries or for simple auxiliary load disconnection. Connect to TH Series Automatic Charging Relays or Time Delay Relays to provide an additional isolated/switched output or to extend current-carrying capability Simple & Robust Installation: Sealed MX-150 plug/harness with 2ft control wires included. Reduces install time/costs. The optional output bus bar provides a simple, compact connection to the RT or CT fuse block product families. Bullet-proof Construction: Sealed unit, high-temperature materials allow mounting anywhere on the vehicle. Stainless steel self-locking hardware Single or Dual Split Output Options provide flexibility for different electrical system requirements Integral Diode Suppression reduces voltage spikes on control lines during switching Normalized SKU: 7422UPC Code: 850035199909Egis 7422 Literature Download Product Brochure

Download LiteratureEgis 7422-24 RelaysTH3 Dual Relay 2 x 80A - 24VFeatures: Replaces Manual Battery Switches: Reduces battery cable run lengths and resulting voltage drop Connect to the Ignition Signal for simple battery charge management between two batteries or for simple auxiliary load disconnection. Connect to TH Series Automatic Charging Relays or Time Delay Relays to provide an additional isolated/switched output or to extend current-carrying capability Simple & Robust Installation: Sealed MX-150 plug/harness with 2ft control wires included. Reduces install time/costs. The optional output bus bar provides a simple, compact connection to the RT or CT fuse block product families. Bullet-proof Construction: Sealed unit, high-temperature materials allow mounting anywhere on the vehicle. Stainless steel self-locking hardware Single or Dual Split Output Options provide flexibility for different electrical system requirements Integral Diode Suppression reduces voltage spikes on control lines during switching Normalized SKU: 742224UPC Code: 850035199923Egis 7422-24 Literature Download Product Brochure

Download LiteratureEgis 8720-1390 RelaysXD Series Dual Flex 2 (ACR-Mech Only) with Knobs - Flying WiresFeatures Replaces Two Individual High Amp Relays with One Compact Module reducing space significantly, eliminating the cost of external link cable connections, eliminating the risk of link cable connections vibrating loose, and providing clear unambiguous awareness of how to operate manual controls and what state the manual controls have forced the relay into.. Designed to Replicate Common Multi-Battery Switching and Charge Management Functions:  Common dual battery load switching via the outer relays and a central automatic charging relay to share charge current is easily implemented. Multiple Automatic Charging Relay (ACR) Into One Device: For 2-3 Battery Systems that require 1 or 2 ACRs, a single three-relay ACR provides a drastic improvement in off-state quiescent current draw, space used, and reduces unnecessary interconnection cables. Expandable with Link and Cross-Link Busbars to Additional Dual, Triple, or Single XD Relays: Supports 2 or 3 battery systems with standard busbar interconnect accessories. Bullet-proof Construction: Sealed to IP67/IP6K9K, high-temperature electronics and materials allow mounting anywhere. Stainless steel cable lug studs. Large mounting holes accept 1/4-20 / M6 attachment hardware. Intuitive Manual Control option simplifies operation and awareness of the state of manual override and whether the device is being left in a locked off or locked on state (not available on competitive solutions) Simple Programmability via simple dip switches allows each relay function significant flexibility for OEMs and installers.  35-75% Reduction in Mounting Space & Product Weight via advanced bi-stable solenoid design and multiple solenoid assemblies that replace common electrical system layouts. Plug & Play Compatible with Legacy Competitor Products:   Single, dual, and triple relays options available with DTM/ATM connectors pin for pin compatible with ML Series Bi-stable Relays. 90-95% Less Off-State Current: Compared to competitive products and system solutions that require multiple devices for similar functionality Specifications: Total Continuous Current Amps: 500 Max Cranking Current (Amps): 1500 Mechanical Switching Life: 1,000,000 Cycles Voltage Range (VDC): 8-36 Off-State Current Draw (mA): 1.3 State Change Current: 5A @ 12 VDC; 3A @ 24 VDC Focal Features:LED Status DisplayEasy to see front facing LED indicator provides visual device status, remote LED replicates local on-device LED3-Position Manual OverrideForce each individual relay Open or Closed and optionally leave knob in either position to lock relay in either condition. 40 Circuit Label Sheet IncludedConvenient recesses for included weatherproof label set makes circuit and relay identification easy. Blank labels for custom applications.Protective Cover IncludedProtects terminal studs and cable terminal edges from inadvertent shorts to each other or ground.Stainless HardwareCorrosion is no issue with quality stainless steel studs and self locking flanged nuts.ProgrammableVia dip switches located under protective cover. An easy to use configuration guide on reverse make custom settings a breeze to configure for a wide variety of applications.Smaller FootprintXD Relays offers high Amp rating in a smaller package than competitive solutions, reducing install space requirements to a minimum.Integrated VentHigh quality Gortex vent regulates internal device pressure to eliminate moisture entry across seals and ensure long product life in harsh environments. Normalized SKU: 87201390UPC Code: 850053879494Egis 8720-1390 Literature Download Quick Reference Guide

Download LiteratureEgis 2403 Battery AccessoriesE-Series 350A Battery Switch Off/OnSealed Against Dust & Water Intrusion - To ensure reliable circuit protection for the life of the electrical system installation.Ignition Protected - Safe for installation in closed compartments with potential explosive gases.Serrated Flange Lock Nuts - Improves resistance to cable terminal loosening in high-vibration environments.Flexible Mounting Options - Allow for multiple mounting configurations and a variety of installation types.Harsh Environment Design - With stainless steel hardware, serrated flange nuts, and high-temperature materials.Specifications: Maximum Voltage (Single Circuit): 48 Vdc Maximum Voltage (Selector / Dual Circuit): 32 Vdc Stud Size And Thread: 3/8”-16 Terminal Stud Torque: 140 in-lbs (15.8 N-m) Ring Terminal Size Acceptance: 3/8” (M10) Mounting Holes: #1/4" (M6) Screw Live Switching Rating: 25 Amps Ignition Protection Rating: SAE J1171 / ISO 8846 Bulkhead / Panel - Mounting Hole Size: 3-5/8" Diameter Cable Size to Meet Rating: 4/0 AWG Normalized SKU: 2403UPC Code: 850067590569Egis 2403 Literature Download Quick Reference Guide

Download LiteratureEgis 2410 Battery AccessoriesE-Series 350A Dual Circuit Battery Switch Off/OnSealed Against Dust & Water Intrusion - To ensure reliable circuit protection for the life of the electrical system installation.Ignition Protected - Safe for installation in closed compartments with potential explosive gases.Serrated Flange Lock Nuts - Improves resistance to cable terminal loosening in high-vibration environments.Flexible Mounting Options - Allow for multiple mounting configurations and a variety of installation types.Harsh Environment Design - With stainless steel hardware, serrated flange nuts, and high-temperature materials.Specifications: Maximum Voltage (Single Circuit): 48 Vdc Maximum Voltage (Selector / Dual Circuit): 32 Vdc Stud Size And Thread: 3/8”-16 Terminal Stud Torque: 140 in-lbs (15.8 N-m) Ring Terminal Size Acceptance: 3/8” (M10) Mounting Holes: #1/4" (M6) Screw Live Switching Rating: 25 Amps Ignition Protection Rating: SAE J1171 / ISO 8846 Bulkhead / Panel - Mounting Hole Size: 3-5/8" Diameter Cable Size to Meet Rating: 4/0 AWG Normalized SKU: 2410UPC Code: 850067590576Egis 2410 Literature Download Quick Reference Guide
