Newmar POWER PAC 7AH Battery Chargers" Power-Pac Designed for critical applications such as VHF shore stations that must remain on the air, even during a power outage. The 12 volt supply features built-in back-up batteries which are charged during normal operation and then continue to power radios even when AC power is lost. Highly regulated, low ripple output for noise-free radio operation Battery automatically comes on-line if AC fails Low battery alarm and disconnect, with override switch for emergency power General Specifications Input 115/230 VAC, 50-60 Hz. Output:13.6 VDC @ 5A cont., 10A Int. Regulation: 1% line and load Ripple: 1% P-P Operating Temp: 0-40° C Models: Power-Pac 7 A/H (w/7 amp/hour battery), 18 lbs. Power-Pac 14 A/H (w/14 amp/hour battery), 24 lbs. Dimensions (both models): 5.3? H x 9.0? W x 10.5? D"Normalized SKU: POWERPAC7AHUPC Code: 360-2007-0

Newmar 7AH Batteries The Newmar 7AH Power Pack provides a 12V power supply with built-in 7 amp-hour backup batteries. During normal operation, the internal batteries are charged and remain ready to power connected radios if AC input power is lost. Built-in low-battery alarm and disconnect functions help protect the backup system. Auxiliary input terminals allow additional external batteries to be integrated when more backup capacity is required. Manufacturer: Newmar Model: 7AH Battery capacity: 7 amp-hours System voltage: 12V Power supply output: 13.6V Output current: 10A intermittent; 5A continuous AC input: 115/230 VAC Protection: Low-battery alarm and disconnect Expansion: Auxiliary terminals for additional external batteries Normalized SKU: 7AHUPC Code: 012302330525

Newmar 115-12-20A Components"Heavy Duty Series Designed for powering 12 and 24 VDC communication/navigation equipment aboard commercial vessels where reliability is the primary consideration. Input voltage 115 or 230 VAC selected by slide switch on the front panel. Excellent Regulation and Ripple Spec: Output voltage maintained within 1% under all line and load conditions within rating; Ripple is less than 40 mV P-P. (12 volt) or 70 mV P-P (24-volt) Polyurethane conformal coated PC board and corrosion resistant heavy duty aluminum case with integral shock mounts assures survival in hostile environments Heat generated by semi-conductors is extracted and dissipated by large heat sink fins that maximize air contact for cool operation and long life of components. Supply and Load Circuit Protection: overvoltage, current limit; (set @ 105% of intermittent rating), thermal overload and input/output fusing. Thermally activated cooling fan on ""CD"" units. Specifications 12 Volt Output 115-12-8 Input 115/230 VAC Output 8 amp intermittent 5 amps continuous Dimensions 6.0" h x 4.6" w x 8.5" d wieght 10lbs 115-12-20A Input 115/230 VAC Output 20 amp intermittent 8 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-12-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lbs 24-Volt Output 115-24-10 Input 115/230 VAC Output 10 amp intermittent 4 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-24-18CD Input 115/230 VAC Output 18 amp intermittent 18 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lb 115-24-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 13.0" w x 18.75" d  Weight 60lbs Output Voltage 12 V Models: 13.6 VDC (Internally adjustable 12.6-14.5 VDC) Ripple: 40mV P-P ( @ 110-125 / 220-250 VAC input) 24 V Models: 24.5 VDC (Internally adjustable 21-27.5 VDC) Ripple: 70mV P-P ( @ 110-125 / 220-250 VAC input) Regulation All Models: 1% Line and Load (@ 110-125 / 220-250 VAC input) Input Range 105-125/210-250 VAC (selectable), 50-60 Hz Derate to 50% output below 110 and 220 VAC Operating Temperature 0-50°C, Derate Linearly From 100% @ 40°C To 50% @ 50°C Thermal shutdown @ 85°C Case temperature Duty Cycle Intermittent: 20 minutes max on time, 20% duty Continuous: 24 Hours/Day 100% Duty"Normalized SKU: 1151220AUPC Code: 400-0141-0

Newmar 115-12-35CD Components Heavy Duty Series Designed for powering 12 and 24 VDC communication/navigation equipment aboard commercial vessels where reliability is the primary consideration. Input voltage 115 or 230 VAC selected by slide switch on the front panel. Excellent Regulation and Ripple Spec: Output voltage maintained within 1% under all line and load conditions within rating; Ripple is less than 40 mV P-P. (12 volt) or 70 mV P-P (24-volt) Polyurethane conformal coated PC board and corrosion resistant heavy duty aluminum case with integral shock mounts assures survival in hostile environments Heat generated by semi-conductors is extracted and dissipated by large heat sink fins that maximize air contact for cool operation and long life of components. Supply and Load Circuit Protection: overvoltage, current limit; (set @ 105% of intermittent rating), thermal overload and input/output fusing. Thermally activated cooling fan on ""CD"" units. Specifications 12 Volt Output 115-12-8 Input 115/230 VAC Output 8 amp intermittent 5 amps continuous Dimensions 6.0" h x 4.6" w x 8.5" d wieght 10lbs115-12-20A Input 115/230 VAC Output 20 amp intermittent 8 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-12-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lbs 24-Volt Output 115-24-10 Input 115/230 VAC Output 10 amp intermittent 4 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs115-24-18CD Input 115/230 VAC Output 18 amp intermittent 18 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lb115-24-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 13.0" w x 18.75" d  Weight 60lbs Output Voltage 12 V Models:13.6 VDC (Internally adjustable 12.6-14.5 VDC) Ripple: 40mV P-P ( @ 110-125 / 220-250 VAC input) 24 V Models:24.5 VDC (Internally adjustable 21-27.5 VDC)Ripple: 70mV P-P ( @ 110-125 / 220-250 VAC input) Regulation All Models: 1% Line and Load (@ 110-125 / 220-250 VAC input) Input Range 105-125/210-250 VAC (selectable), 50-60 Hz Derate to 50% output below 110 and 220 VAC Operating Temperature 0-50°C, Derate Linearly From 100% @ 40°C To 50% @ 50°C Thermal shutdown @ 85°C Case temperature Duty Cycle Intermittent: 20 minutes max on time, 20% dutyContinuous: 24 Hours/Day 100% Duty Normalized SKU: 1151235CDUPC Code: 400-0154-0

Newmar 115-12-8 Components"Heavy Duty Series Designed for powering 12 and 24 VDC communication/navigation equipment aboard commercial vessels where reliability is the primary consideration. Input voltage 115 or 230 VAC selected by slide switch on the front panel. Excellent Regulation and Ripple Spec: Output voltage maintained within 1% under all line and load conditions within rating; Ripple is less than 40 mV P-P. (12 volt) or 70 mV P-P (24-volt) Polyurethane conformal coated PC board and corrosion resistant heavy duty aluminum case with integral shock mounts assures survival in hostile environments Heat generated by semi-conductors is extracted and dissipated by large heat sink fins that maximize air contact for cool operation and long life of components. Supply and Load Circuit Protection: overvoltage, current limit; (set @ 105% of intermittent rating), thermal overload and input/output fusing. Thermally activated cooling fan on ""CD"" units. Specifications 12 Volt Output 115-12-8 Input 115/230 VAC Output 8 amp intermittent 5 amps continuous Dimensions 6.0" h x 4.6" w x 8.5" d wieght 10lbs 115-12-20A Input 115/230 VAC Output 20 amp intermittent 8 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-12-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lbs 24-Volt Output 115-24-10 Input 115/230 VAC Output 10 amp intermittent 4 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-24-18CD Input 115/230 VAC Output 18 amp intermittent 18 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lb 115-24-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 13.0" w x 18.75" d  Weight 60lbs Output Voltage 12 V Models: 13.6 VDC (Internally adjustable 12.6-14.5 VDC) Ripple: 40mV P-P ( @ 110-125 / 220-250 VAC input) 24 V Models: 24.5 VDC (Internally adjustable 21-27.5 VDC) Ripple: 70mV P-P ( @ 110-125 / 220-250 VAC input) Regulation All Models: 1% Line and Load (@ 110-125 / 220-250 VAC input) Input Range 105-125/210-250 VAC (selectable), 50-60 Hz Derate to 50% output below 110 and 220 VAC Operating Temperature 0-50°C, Derate Linearly From 100% @ 40°C To 50% @ 50°C Thermal shutdown @ 85°C Case temperature Duty Cycle Intermittent: 20 minutes max on time, 20% duty Continuous: 24 Hours/Day 100% Duty"Normalized SKU: 115128

Newmar 115-24-10 Components"Heavy Duty Series Designed for powering 12 and 24 VDC communication/navigation equipment aboard commercial vessels where reliability is the primary consideration. Input voltage 115 or 230 VAC selected by slide switch on the front panel. Excellent Regulation and Ripple Spec: Output voltage maintained within 1% under all line and load conditions within rating; Ripple is less than 40 mV P-P. (12 volt) or 70 mV P-P (24-volt) Polyurethane conformal coated PC board and corrosion resistant heavy duty aluminum case with integral shock mounts assures survival in hostile environments Heat generated by semi-conductors is extracted and dissipated by large heat sink fins that maximize air contact for cool operation and long life of components. Supply and Load Circuit Protection: overvoltage, current limit; (set @ 105% of intermittent rating), thermal overload and input/output fusing. Thermally activated cooling fan on ""CD"" units. Specifications 12 Volt Output 115-12-8 Input 115/230 VAC Output 8 amp intermittent 5 amps continuous Dimensions 6.0" h x 4.6" w x 8.5" d wieght 10lbs 115-12-20A Input 115/230 VAC Output 20 amp intermittent 8 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-12-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lbs 24-Volt Output 115-24-10 Input 115/230 VAC Output 10 amp intermittent 4 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-24-18CD Input 115/230 VAC Output 18 amp intermittent 18 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lb 115-24-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 13.0" w x 18.75" d  Weight 60lbs Output Voltage 12 V Models: 13.6 VDC (Internally adjustable 12.6-14.5 VDC) Ripple: 40mV P-P ( @ 110-125 / 220-250 VAC input) 24 V Models: 24.5 VDC (Internally adjustable 21-27.5 VDC) Ripple: 70mV P-P ( @ 110-125 / 220-250 VAC input) Regulation All Models: 1% Line and Load (@ 110-125 / 220-250 VAC input) Input Range 105-125/210-250 VAC (selectable), 50-60 Hz Derate to 50% output below 110 and 220 VAC Operating Temperature 0-50°C, Derate Linearly From 100% @ 40°C To 50% @ 50°C Thermal shutdown @ 85°C Case temperature Duty Cycle Intermittent: 20 minutes max on time, 20% duty Continuous: 24 Hours/Day 100% Duty"Normalized SKU: 1152410UPC Code: 400-2115-0

Newmar 115-24-18CD Components"Heavy Duty Series Designed for powering 12 and 24 VDC communication/navigation equipment aboard commercial vessels where reliability is the primary consideration. Input voltage 115 or 230 VAC selected by slide switch on the front panel. Excellent Regulation and Ripple Spec: Output voltage maintained within 1% under all line and load conditions within rating; Ripple is less than 40 mV P-P. (12 volt) or 70 mV P-P (24-volt) Polyurethane conformal coated PC board and corrosion resistant heavy duty aluminum case with integral shock mounts assures survival in hostile environments Heat generated by semi-conductors is extracted and dissipated by large heat sink fins that maximize air contact for cool operation and long life of components. Supply and Load Circuit Protection: overvoltage, current limit; (set @ 105% of intermittent rating), thermal overload and input/output fusing. Thermally activated cooling fan on ""CD"" units. Specifications 12 Volt Output 115-12-8 Input 115/230 VAC Output 8 amp intermittent 5 amps continuous Dimensions 6.0" h x 4.6" w x 8.5" d wieght 10lbs 115-12-20A Input 115/230 VAC Output 20 amp intermittent 8 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-12-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lbs 24-Volt Output 115-24-10 Input 115/230 VAC Output 10 amp intermittent 4 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-24-18CD Input 115/230 VAC Output 18 amp intermittent 18 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lb 115-24-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 13.0" w x 18.75" d  Weight 60lbs Output Voltage 12 V Models: 13.6 VDC (Internally adjustable 12.6-14.5 VDC) Ripple: 40mV P-P ( @ 110-125 / 220-250 VAC input) 24 V Models: 24.5 VDC (Internally adjustable 21-27.5 VDC) Ripple: 70mV P-P ( @ 110-125 / 220-250 VAC input) Regulation All Models: 1% Line and Load (@ 110-125 / 220-250 VAC input) Input Range 105-125/210-250 VAC (selectable), 50-60 Hz Derate to 50% output below 110 and 220 VAC Operating Temperature 0-50°C, Derate Linearly From 100% @ 40°C To 50% @ 50°C Thermal shutdown @ 85°C Case temperature Duty Cycle Intermittent: 20 minutes max on time, 20% duty Continuous: 24 Hours/Day 100% Duty"Normalized SKU: 1152418CD

Newmar 115-24-35CD Components"Heavy Duty Series Designed for powering 12 and 24 VDC communication/navigation equipment aboard commercial vessels where reliability is the primary consideration. Input voltage 115 or 230 VAC selected by slide switch on the front panel. Excellent Regulation and Ripple Spec: Output voltage maintained within 1% under all line and load conditions within rating; Ripple is less than 40 mV P-P. (12 volt) or 70 mV P-P (24-volt) Polyurethane conformal coated PC board and corrosion resistant heavy duty aluminum case with integral shock mounts assures survival in hostile environments Heat generated by semi-conductors is extracted and dissipated by large heat sink fins that maximize air contact for cool operation and long life of components. Supply and Load Circuit Protection: overvoltage, current limit; (set @ 105% of intermittent rating), thermal overload and input/output fusing. Thermally activated cooling fan on ""CD"" units. Specifications 12 Volt Output 115-12-8 Input 115/230 VAC Output 8 amp intermittent 5 amps continuous Dimensions 6.0" h x 4.6" w x 8.5" d wieght 10lbs 115-12-20A Input 115/230 VAC Output 20 amp intermittent 8 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-12-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lbs 24-Volt Output 115-24-10 Input 115/230 VAC Output 10 amp intermittent 4 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-24-18CD Input 115/230 VAC Output 18 amp intermittent 18 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lb 115-24-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 13.0" w x 18.75" d  Weight 60lbs Output Voltage 12 V Models: 13.6 VDC (Internally adjustable 12.6-14.5 VDC) Ripple: 40mV P-P ( @ 110-125 / 220-250 VAC input) 24 V Models: 24.5 VDC (Internally adjustable 21-27.5 VDC) Ripple: 70mV P-P ( @ 110-125 / 220-250 VAC input) Regulation All Models: 1% Line and Load (@ 110-125 / 220-250 VAC input) Input Range 105-125/210-250 VAC (selectable), 50-60 Hz Derate to 50% output below 110 and 220 VAC Operating Temperature 0-50°C, Derate Linearly From 100% @ 40°C To 50% @ 50°C Thermal shutdown @ 85°C Case temperature Duty Cycle Intermittent: 20 minutes max on time, 20% duty Continuous: 24 Hours/Day 100% Duty"Normalized SKU: 1152435CD

Download LiteratureNewmar POWER-PAC14AH InvertersPower-Pac 14AH Power Supply  The 12V DC power supply features built-in backup batteries, which are charged during normal operation and then continue to power radios and critical navigation equipment when AC power is lost. The Power-Pac is ideal for commercial vessels, work boats, and yachts.The Power-Pac’s highly regulated, low-rising 10-amp output powers radios and other sensitive communications equipment without causing RF or audio interference. At the same time, it floats and charges one or two (depending on the model) built-in 7-amp/hour backup batteries. These are kept at peak charge during the normal functioning of the unit when AC is being supplied. In the event of a loss of AC power, the internal batteries automatically take over to power communication equipment, providing a true uninterruptible DC source.Features: Highly regulated, low ripple, noise-free 12-volt output Built-in, “on-line” stand-by battery provides immediate backup power in case of AC power loss Internal mounting space and terminals for conversion of the 7 A/H model into the 14 A/H model Output “Normal” indicator L.E.D. “Back-up power only” warning light Audible and visual low battery (10.7 VDC) voltage indicators Low battery warning buzzer mute switch Automatic low battery (10.3 VDC) voltage disconnect Low voltage disconnect override button Over-voltage protection Current limit protection Input/output fused Separate output terminals are provided for charging external batteries 115/230 50-60 Hz input, selected by a slide switch on the rear panel Specifications: Battery Capacity: 14 amp/hour   Case Size (H x W x D): 5.3 x 9.0 x 10.5 inches (13.3 x 22.9 x 26.7 centimeters)   Weight: 24 lbs. (10.9 kg) Input: 115/230 VAC, 50-60 Hz. Output: 13.6 VDC @ 5A cont., 10A Int. Regulation: 1% line and load Ripple: 1% P-P Operating Temp: 0-40 degrees C With a 14 Amp/Hour Battery Installed, the Unit Provides Approximately the Following Power: 7 amps for 100 min. 10 amps for 60 min. 15 amps for 30 min. 20 amps for 15 min *Assuming battery at full charge when a.c. power failed.The Power-Pac 7 A/H (single battery model) can power a 25-watt transceiver for up to 3 hours, based on a 20% transmit/receive duty cycle. Power-Pac 14 A/H can provide the same service for up to 6 hours. Provision is made for expanding backup power up to twelve hours (in this example, longer under lesser loads) with the installation of additional externally wired batteries (total 28 amps/hours max.). Batteries are automatically recharged when the AC is restored.The operator is kept informed of all important functions, such as AC input, DC output, and battery status, with front panel indicator lights and a low battery warning buzzer.Protection: AC Input fuse Internal and external Battery fuses Over Voltage Current Limit Automatic Thermal Shutdown Low Battery Disconnect Mechanical Details: Vinyl Laminated aluminum case 6’ standard AC power cord Ac input selector switch Battery Details: Sealed Lead Acid, Deep-cycle. Certified by DOT and IATA for shipment by Air Weight per 7 AH Battery: 6 lbs. Size (inch): 6” x 3.75” x 2.5” Options: Form C AC Failure Contacts (Contact factory for details) Extra batteries, sold separately 7 A/H increments; each Power Pac will accommodate 28 A/H max. (14 internal, 14 external) This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: POWERPAC14AHNewmar POWER-PAC14AH Literature Download Quick Reference Guide Owners Manual

Download LiteratureNewmar POWER-PAC7AH InvertersPower-Pac 7AH Power SupplyThe 12V DC power supply features built-in backup batteries, which are charged during normal operation and then continue to power radios and critical navigation equipment when AC power is lost. The Power-Pac is ideal for commercial vessels, work boats, and yachts.The Power-Pac’s highly regulated, low-rising 10-amp output powers radios and other sensitive communications equipment without causing RF or audio interference. At the same time, it floats and charges one or two (depending on the model) built-in 7-amp/hour backup batteries. These are kept at peak charge during the normal functioning of the unit when AC is being supplied. In the event of a loss of AC power, the internal batteries automatically take over to power communication equipment, providing a true uninterruptible DC source.Features: Highly regulated, low ripple, noise-free 12-volt output Built-in, “on-line” stand-by battery provides immediate backup power in case of AC power loss Internal mounting space and terminals for conversion of the 7 A/H model into the 14 A/H model Output “Normal” indicator L.E.D. “Back-up power only” warning light Audible and visual low battery (10.7 VDC) voltage indicators Low battery warning buzzer mute switch Automatic low battery (10.3 VDC) voltage disconnect Low voltage disconnect override button Over-voltage protection Current limit protection Input/output fused Separate output terminals are provided for charging external batteries 115/230 50-60 Hz input, selected by a slide switch on the rear panel Specifications: Battery Capacity: 7 amp/hour   Case Size (H x W x D): 5.3 x 9.0 x 10.5 inches (13.3 x 22.9 x 26.7 centimeters)   Weight: 18 lbs. (8.2 kg) Input: 115/230 VAC, 50-60 Hz. Output: 13.6 VDC @ 5A cont., 10A Int. Regulation: 1% line and load Ripple: 1% P-P Operating Temp: 0-40 degrees C With a 7 Amp/Hour Battery Installed, the Unit Provides Approximately the Following Power. *7 Amps for 40 Min. 10 amps for 20 min. 15 amps for 10 min. 20 amps for 4 min. *Assuming battery at full charge when a.c. power failed.The Power-Pac 7 A/H (single battery model) can power a 25-watt transceiver for up to 3 hours, based on a 20% transmit/receive duty cycle. Power-Pac 14 A/H can provide the same service for up to 6 hours. Provision is made for expanding backup power up to twelve hours (in this example, longer under lesser loads) with the installation of additional externally wired batteries (total 28 amps/hours max.). Batteries are automatically recharged when the AC is restored.The operator is kept informed of all important functions, such as AC input, DC output, and battery status, with front panel indicator lights and a low battery warning buzzer.Protection: AC Input fuse Internal and external Battery fuses Over Voltage Current Limit Automatic Thermal Shutdown Low Battery Disconnect Mechanical Details: Vinyl Laminated aluminum case 6’ standard AC power cord Ac input selector switch Battery Details: Sealed Lead Acid, Deep-cycle. Certified by DOT and IATA for shipment by Air Weight per 7 AH Battery; 6 lbs. Size (inch): 6” x 3.75” x 2.5” Options: Form C AC Failure Contacts (Contact factory for details) Extra batteries, sold separately 7 A/H increments; each Power Pac will accommodate 28 A/H max. (14 internal, 14 external) This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: POWERPAC7AHNewmar POWER-PAC7AH Literature Download Quick Reference Guide Owners Manual

Newmar RP Switch Panels"Remote Panel, model RP, for use with all models except PT-7 LED's indicate charger output stage. Manual re-initialization of three stage charge cycle. With 25"" of cable. Panel dimensions: 3"" H x 4.75"" W"Normalized SKU: RP

Newmar 5ASB Circuit Breakers"All circuit breakers offered by NEWMAR are UL recognized and CSA listed for AC and DC systems and meet USCG requirements as a qualified circuit protection device. Single and Double Pole Fit all NEWMAR electrical panels, as well as most other brands Feature magnetic-hydraulic ""trip-free"" mechanism 5-30 amp rated to 65 VDC or 277 VAC; 40, 50 amp rated to 32 VDC or 120 VAC (See rating note below). Mounting scrws not provide order separatly #10 screw terminals on rear for wiring Options Red, white or black toggle handles Single pole values: 5, 10, 15, 20, 25, 30, 40 or 50 amp. Double pole values: 15, 20, 30 or 50 amp Important Circuit Breaker Rating Note: Standard series breakers shown on this page which are rated higher than 30 amps are acceptable for use in 230 VAC Line-to-Line systems (where each leg is 115 VAC - to - neutral), but are not rated for 230 VAC line-to-neutral systems."Normalized SKU: 5ASB

Newmar BX-1 ComponentsBX-1 Junction BoxThis BX Series splashproof box provides secure, protected wiring connections in wheelhouses or below decks and engine rooms. Features: IP rating 54 – “Splashproof” Rugged cast aluminum box with white enamel finish Metal box reduces electrical interference Easy wiring access through multiple grommeted cable entries Supplied with high-quality connector strips – secure wires with compression fittings – no terminals required – see matrix below for connector strips specifications per box Specifications: Number of Connector Strips: 1 Positions per Strip: 6 Max Wire Gauge: 16 Max Amps (per position): 6  Cable Entries: 2  Cable Diameter: 0.25 in. Box Size: 2 x 2 x 1.2 in. Box Size: 5.1 x 5.1 x 3.1 cm Normalized SKU: BX1

Newmar SS SWITCH15 SwitchesSS Switch - 15 AC Selector SwitchThis AC source selector switch is an essential item for any vessel with an onboard AC generator and/or inverter. By isolating power source inputs, the switch eliminates the safety hazard and/or damage that can occur if two AC sources are applied to the same circuit simultaneously.The switch is fitted with a compact escutcheon plate with engraved switch position nomenclature.The switches carry cUL approval, are CE-marked, and feature heavy-duty contacts and a positive step cam mechanism for low-resistance contact closure. Features: Maybe rear-mounted in a panel with a thickness of up to 1/4” May be configured as a 63 amp, 4 pole switch Specifications: Amperage @ 115/230V: 126     Number of Poles: 2 Switch Positions: 2 + “OFF” Standard Plate Markings: SHIP-OFF-SHORE     Depth Dimensions: 4 in. Normalized SKU: SSSWITCH15

Newmar S.S. SWITCH 15 Switch Panels"An Ac source selector switch is an essential item for any boat with an on-board AC generator and/or inverter. The switch eliminates the safety hazard and/or damage that can occur if two AC sources are applied to the same circuit simultaneously. These switches are fitted with a compact escutcheon plate with engraved switch position nomenclature (mounting dimensions below). The switches carry UL, CSA and VDE approval and feature heavy duty contacts and a positive step cam mechanism for low resistance contact closure. May be installed in panel with thickness up to 1/4". "Normalized SKU: SSSWITCH15

Newmar SS SWITCH3 SwitchesSS Switch - 3 AC Selector SwitchThis AC source selector switch is an essential item for any vessel with an on-board AC generator and/or inverter. By isolating power source inputs, the switch eliminates the safety hazard and/or damage that can occur if two AC sources are applied to the same circuit simultaneously.The switch is fitted with a compact escutcheon plate with engraved switch position nomenclature.The switches carry cUL approval, are CE-marked, and feature heavy-duty contacts and a positive step cam mechanism for low-resistance contact closure. Features:May be rear-mounted in a panel with a thickness up to 1/4”Specifications: Amperage @ 115/230V: 30   Number of Poles: 2 Switch Positions: 2 + “OFF” Standard Plate Markings: SHIP-OFF-SHORE     Depth Dimensions: 2-1/8 in. Normalized SKU: SSSWITCH3

Newmar S.S. SWITCH 3.0 Switch Panels"An Ac source selector switch is an essential item for any boat with an on-board AC generator and/or inverter. The switch eliminates the safety hazard and/or damage that can occur if two AC sources are applied to the same circuit simultaneously. These switches are fitted with a compact escutcheon plate with engraved switch position nomenclature (mounting dimensions below). The switches carry UL, CSA and VDE approval and feature heavy duty contacts and a positive step cam mechanism for low resistance contact closure. May be installed in panel with thickness up to 1/4". "Normalized SKU: SSSWITCH30

Newmar SS SWITCH7.5 SwitchesSS Switch - 7.5 AC Selector SwitchThis AC source selector switch is an essential item for any vessel with an onboard AC generator and/or inverter. By isolating power source inputs, the switch eliminates the safety hazard and/or damage that can occur if two AC sources are applied to the same circuit simultaneously.The switch is fitted with a compact escutcheon plate with engraved switch position nomenclature.The switches carry cUL approval, are CE-marked, and feature heavy-duty contacts and a positive step cam mechanism for low-resistance contact closure. Features:Maybe rear-mounted in a panel with a thickness of up to 1/4”Specifications: Amperage @ 115/230V: 63 Number of Poles: 2 Switch Positions: 2 + “OFF” Standard Plate Markings: SHIP-OFF-SHORE     Depth Dimensions: 2-3/8 in. Normalized SKU: SSSWITCH75
