Ocean LED 012308W Underwater LightingX-Series X16 - White LEDsThe OceanLED X-Series X16 combines brightness with affordability. Whether cruising or fishing, the X16 gives stunning performance allowing you to enjoy more time on the water with family and friends.The X16 packs a mighty 5,800 Fixture Lumens into its low profile design and utilizes focused optics to produce a 60° circular beam from each LED providing great water penetration, illuminating a large area.Choose either a single color version from either Midnight Blue or Ultra White or pick our Colours option where you can select any color you want from the RGBW spectrum. You can toggle between the colors or with our DMX controller and smartphone app, your choice is virtually limitless.Looking to catch more fish? Switch on the Fish-Strobe mode and the light emits a random strobe pattern that is proven to attract extra bait fish and help catch more fish.The low profile, simple design is easy to install even for the weekend DIYer. A small 12.5mm hole is all that's needed to run the cable through the hull. Fix 4 screws and that's the hard work done! Simply attach to 12V and you are ready to light up your world.Maintenance is virtually zero. Simply wipe the lens with a cloth to remove any marine growth thanks to the special Tritonium coating.Features:5,800 Lumens / 4,500 Fixture Lumens:Outstanding performance from this small, bright light makes it the obvious choice for those who want tostand out from the crowd.60° Beam AngleA wide-angled, focused beam lights up a large area of the water.Compact and simple designMade from a chemically resistant optical polymer with a built in driver, there is a lot packed into this compact light. Installation needs only a small, 12.5mm hole in the hull to feed the cable through and 3 screws in place. No bonding required.Easy to CleanThanks to its Tritonium coating, a simple wipe of the lens removes any underwater growth saving hours ofscrubbing each time you use it.Fish-Strobe ModeExceptionally bright, randomized strobing of the light is proven to attract more fish and catch more bait.Mounting Recommendations Boat size: up to 65' (20M) Transom / Hull spacing: 2-4' (0.5-1.2M) Transom quantity: 2-6 Hull quantity: 4-8" (10-20cm) Maximum hull thickness: N/A Installation depth (to top of fixture): 300mm below water line In water fitting: No Technical Light output equivalent to: 150 Metal Halide Fixture Lumens* (total light output from a finished fixture): 4,500 Lumens: 5,800 Beam angle: 60° circular Typical LED life expectancy: 40,000 hours Minimum-Maximum operating voltage DC: 9 - 32 V DC Minimum-Maximum operating voltage AC (AC/optional) Current / Amp draw (DC): 3.2A @ 12V DC - 1.5A @ 24V DC Approx. light penetration (avg. water quality): 40' (12M) Approx. Light penetration (perfect water quality): 100' (30M) Driver type: Internal Driver size (L x W x H): N/A Color options: Ultra White - Midnight Blue or Colors Correlated Color Temp: 6500 K - 450 nm IP Rating: IP68 Fish strobe: YES Anti fouling properties: Tritonium coated lens LED Manufacturer: CREE Physical Size: 9.84" (250mm) x 4.29" (109mm) Depth: 0.86" (22mm) Total weight including electrical driver: 0.50kg Extension cable length (standard-hard wired to light): 9-7/64' (3M) Hole cut-out for cable entry: 1/2" (12.5mm) Material: Chemically Resistant Optical Polymer Lens material: Pilkington Optiwhite Body construction: Machined (First Release) Bezel material: Plastic Bezel thickness: N/A Bezel options: Stainless Steel Bezel Optional Bezel color: White Drag factor: N/A Optics: Collimator No of LEDs: 16 Certification: EMC Approved CE Approved: Yes Normalized SKU: 012308WUPC Code: 5051803007272

Ocean LED 012302B Underwater LightingX-Series X4 - Midnight Blue LEDsThe OceanLED X-Series X4 combines brightness with affordability. Whether cruising or fishing, the X4 gives stunning performance allowing you to enjoy more time on the water with family and friends.The X4 outputs an impressive 1,150 Fixture lumens from its low profile design and utilizes focused optics to produce a 60° circular beam from each LED providing great water penetration, illuminating a large area. Choose Midnight Blue or Ultra White color options. one app, your choice is virtually limitless.Looking to catch more fish? Switch on the Fish-Strobe mode and the light emits a random strobe pattern that is proven to attract extra bait fish and help catch more fish.The low profile, simple design is easy to install even for the weekend DIYer. A small 12.5mm hole is all that's needed to run the cable through the hull. Fix 4 screws and that's the hard work done! Simply attach to 12V and you are ready to light up your world.Maintenance is virtually zero. Simply wipe the lens with a cloth to remove any marine growth thanks to the special Tritonium coating.Features:1,450 Lumens / 1,150 Fixture Lumens:Outstanding performance from this small, bright light makes it the obvious choice for those who want tostand out from the crowd.60° Beam AngleA wide-angled, focused beam lights up a large area of the water.Compact and simple designMade from a chemically resistant optical polymer with a built in driver, there is a lot packed into this compact light. Installation needs only a small, 12mm hole in the hull to feed the cable through and 3 screws in place. No bonding required.Easy to CleanThanks to its Tritonium coating, a simple wipe of the lens removes any underwater growth saving hours ofscrubbing each time you use it.Fish-Strobe ModeExceptionally bright, randomized strobing of the light is proven to attract more fish and catch more bait.Mounting Recommendations Boat size: up to 30' (9M) Transom / Hull spacing: 2-3' (0.5-1.0M) Transom quantity: 2-4 Hull quantity: 4-8" (10-20cm) Maximum hull thickness: N/A Installation depth (to top of fixture): 300mm below water line In water fitting: No Technical Light output equivalent to: 150W metal halide Fixture Lumens* (total light output from a finished fixture): 1,150 Lumens: 1,450 Beam angle: 60° circular Typical LED life expectancy: 40,000 hours Minimum-Maximum operating voltage DC: 9 - 32 V DC Minimum-Maximum operating voltage AC (AC/optional) Current / Amp draw (DC): 0.8A @ 12V DC - 0.4A @ 24V DC Approx. light penetration (avg. water quality): 20' (6M) Approx. Light penetration (perfect water quality): 45' (13+M) Driver type: Internal Driver size (L x W x H): N/A Color options: Ultra White - Midnight Blue Correlated Color Temp: 6500 K - 450 nm IP Rating: IP68 Fish strobe: YES Anti fouling properties: Tritonium coated lens LED Manufacturer: CREE Physical Size: 5.4" (137mm) x 2.91" (74mm) Depth: 0.86" (22mm) Total weight including electrical driver: 0.70kg Extension cable length (standard-hard wired to light): 9-7/64' (3M) Hole cut-out for cable entry: 1/2" (12.5mm) Material: AB2 Lens material: Pilkington Optiwhite Body construction: Chemically resistant optical polymer Bezel material: Plastic Bezel thickness: N/A Bezel options: Stainless Steel Bezel Optional Bezel color: White Drag factor: N/A Optics: Collimator No of LEDs: 4 Certification: EMC Approved CE Approved: Yes Normalized SKU: 012302BUPC Code: 5051803007210

Ocean LED 012301W Underwater LightingX-Series X4 - White LEDsThe OceanLED X-Series X4 combines brightness with affordability. Whether cruising or fishing, the X4 gives stunning performance allowing you to enjoy more time on the water with family and friends.The X4 outputs an impressive 1,150 Fixture lumens from its low profile design and utilizes focused optics to produce a 60° circular beam from each LED providing great water penetration, illuminating a large area. Choose Midnight Blue or Ultra White color options. one app, your choice is virtually limitless.Looking to catch more fish? Switch on the Fish-Strobe mode and the light emits a random strobe pattern that is proven to attract extra bait fish and help catch more fish.The low profile, simple design is easy to install even for the weekend DIYer. A small 12.5mm hole is all that's needed to run the cable through the hull. Fix 4 screws and that's the hard work done! Simply attach to 12V and you are ready to light up your world.Maintenance is virtually zero. Simply wipe the lens with a cloth to remove any marine growth thanks to the special Tritonium coating.Features:1,450 Lumens / 1,150 Fixture Lumens:Outstanding performance from this small, bright light makes it the obvious choice for those who want tostand out from the crowd.60° Beam AngleA wide-angled, focused beam lights up a large area of the water.Compact and simple designMade from a chemically resistant optical polymer with a built in driver, there is a lot packed into this compact light. Installation needs only a small, 12mm hole in the hull to feed the cable through and 3 screws in place. No bonding required.Easy to CleanThanks to its Tritonium coating, a simple wipe of the lens removes any underwater growth saving hours ofscrubbing each time you use it.Fish-Strobe ModeExceptionally bright, randomized strobing of the light is proven to attract more fish and catch more bait.Mounting Recommendations Boat size: up to 30' (9M) Transom / Hull spacing: 2-3' (0.5-1.0M) Transom quantity: 2-4 Hull quantity: 4-8" (10-20cm) Maximum hull thickness: N/A Installation depth (to top of fixture): 300mm below water line In water fitting: No Technical Light output equivalent to: 150W metal halide Fixture Lumens* (total light output from a finished fixture): 1,150 Lumens: 1,450 Beam angle: 60° circular Typical LED life expectancy: 40,000 hours Minimum-Maximum operating voltage DC: 9 - 32 V DC Minimum-Maximum operating voltage AC (AC/optional) Current / Amp draw (DC): 0.8A @ 12V DC - 0.4A @ 24V DC Approx. light penetration (avg. water quality): 20' (6M) Approx. Light penetration (perfect water quality): 45' (13+M) Driver type: Internal Driver size (L x W x H): N/A Color options: Ultra White - Midnight Blue Correlated Color Temp: 6500 K - 450 nm IP Rating: IP68 Fish strobe: YES Anti fouling properties: Tritonium coated lens LED Manufacturer: CREE Physical Size: 5.4" (137mm) x 2.91" (74mm) Depth: 0.86" (22mm) Total weight including electrical driver: 0.70kg Extension cable length (standard-hard wired to light): 9-7/64' (3M) Hole cut-out for cable entry: 1/2" (12.5mm) Material: AB2 Lens material: Pilkington Optiwhite Body construction: Chemically resistant optical polymer Bezel material: Plastic Bezel thickness: N/A Bezel options: Stainless Steel Bezel Optional Bezel color: White Drag factor: N/A Optics: Collimator No of LEDs: 4 Certification: EMC Approved CE Approved: Yes Normalized SKU: 012301WUPC Code: 5051803007203

Ocean LED 012305B Underwater LightingX-Series X8 - Midnight Blue LEDsThe X8 packs a mighty 2,300 Fixture Lumens into its low profile design and utilizes focused optics to produce a 60x circular beam from each LED providing great water penetration, illuminating a large area.Choose either a single color version from either Midnight Blue or Ultra White or pick our Colours option where you can select any color you want from the RGBW spectrum. You can toggle between the colors or with our DMX controller and smartphone app, your choice is virtually limitless.Looking to catch more fish? Switch on the Fish-Strobe mode and the light emits a random strobe pattern that is proven to attract extra bait fish and help catch more fish.The low profile, simple design is easy to install even for the weekend DIYer. A small 12.5mm hole is all that's needed to run the cable through the hull. Fix 4 screws and that's the hard work done! Simply attach to 12V and you are ready to light up your world.Maintenance is virtually zero. Simply wipe the lens with a cloth to remove any marine growth thanks to the special Tritonium coating.Features:2,900 Lumens / 2,300 Fixture Lumens:Outstanding performance from this small, bright light makes it the obvious choice for those who want tostand out from the crowd.60° Beam AngleA wide-angled, focused beam lights up a large area of the water.Compact and simple designMade from a chemically resistant optical polymer with a built in driver, there is a lot packed into this compact light. Installation needs only a small, 12.5mm hole in the hull to feed the cable through and 3 screws in place. No bonding required.Easy to CleanThanks to its Tritonium coating, a simple wipe of the lens removes any underwater growth saving hours ofscrubbing each time you use it.Fish-Strobe ModeExceptionally bright, randomized strobing of the light is proven to attract more fish and catch more bait.Mounting Recommendations Boat size: up to 50' (15M) Transom / Hull spacing: 2-4' (0.5-1.2M) Transom quantity: 2-6 Hull quantity: 4-8" (10-20cm) Maximum hull thickness: N/A Installation depth (to top of fixture): 300mm below water line In water fitting: No Technical Light output equivalent to: 50W Xenon Fixture Lumens* (total light output from a finished fixture): 2,300 Lumens: 2,900 Beam angle: 60° circular Typical LED life expectancy: 40,000 hours Minimum-Maximum operating voltage DC: 9 - 32 V DC Minimum-Maximum operating voltage AC (AC/optional) Current / Amp draw (DC): 1.65A @ 12V DC - 0.75A @ 24V DC Approx. light penetration (avg. water quality): 26' (8M) Approx. Light penetration (perfect water quality): 72' (21+M) Driver type: Internal Driver size (L x W x H): N/A Color options: Ultra White - Midnight Blue or Colors Correlated Color Temp: 6500 K - 450 nm IP Rating: IP68 Fish strobe: YES Anti fouling properties: Tritonium coated lens LED Manufacturer: CREE Physical Size: 8.62" (219mm) x 3.07" (78mm) Depth: 0.86" (22mm) Total weight including electrical driver: 0.34kg Extension cable length (standard-hard wired to light): 9-7/64' (3M) Hole cut-out for cable entry: 1/2" (12.5mm) Material: Chemically Resistant Optical Polymer Lens material: Pilkington Optiwhite= Body construction: Machined (First Release) Bezel material: Plastic Bezel thickness: N/A Bezel options: Stainless Steel Bezel Optional Bezel color: White Drag factor: N/A Optics: Collimator No of LEDs: 8 Certification: EMC Approved CE Approved: Yes Normalized SKU: 012305BUPC Code: 5051803007241

Ocean LED 012307C Underwater LightingX-Series X8 - Colours LEDsThe X8 packs a mighty 2,300 Fixture Lumens into its low profile design and utilizes focused optics to produce a 60x circular beam from each LED providing great water penetration, illuminating a large area.Choose either a single color version from either Midnight Blue or Ultra White or pick our Colours option where you can select any color you want from the RGBW spectrum. You can toggle between the colors or with our DMX controller and smartphone app, your choice is virtually limitless.Looking to catch more fish? Switch on the Fish-Strobe mode and the light emits a random strobe pattern that is proven to attract extra bait fish and help catch more fish.The low profile, simple design is easy to install even for the weekend DIYer. A small 12.5mm hole is all that's needed to run the cable through the hull. Fix 4 screws and that's the hard work done! Simply attach to 12V and you are ready to light up your world.Maintenance is virtually zero. Simply wipe the lens with a cloth to remove any marine growth thanks to the special Tritonium coating.Features:2,900 Lumens / 2,300 Fixture Lumens:Outstanding performance from this small, bright light makes it the obvious choice for those who want tostand out from the crowd.60° Beam AngleA wide-angled, focused beam lights up a large area of the water.Compact and simple designMade from a chemically resistant optical polymer with a built in driver, there is a lot packed into this compact light. Installation needs only a small, 12.5mm hole in the hull to feed the cable through and 3 screws in place. No bonding required.Easy to CleanThanks to its Tritonium coating, a simple wipe of the lens removes any underwater growth saving hours ofscrubbing each time you use it.Fish-Strobe ModeExceptionally bright, randomized strobing of the light is proven to attract more fish and catch more bait.Mounting Recommendations Boat size: up to 50' (15M) Transom / Hull spacing: 2-4' (0.5-1.2M) Transom quantity: 2-6 Hull quantity: 4-8" (10-20cm) Maximum hull thickness: N/A Installation depth (to top of fixture): 300mm below water line In water fitting: No Technical Light output equivalent to: 50W Xenon Fixture Lumens* (total light output from a finished fixture): 2,300 Lumens: 2,900 Beam angle: 60° circular Typical LED life expectancy: 40,000 hours Minimum-Maximum operating voltage DC: 9 - 32 V DC Minimum-Maximum operating voltage AC (AC/optional) Current / Amp draw (DC): 1.65A @ 12V DC - 0.75A @ 24V DC Approx. light penetration (avg. water quality): 26' (8M) Approx. Light penetration (perfect water quality): 72' (21+M) Driver type: Internal Driver size (L x W x H): N/A Color options: Ultra White - Midnight Blue or Colors Correlated Color Temp: 6500 K - 450 nm IP Rating: IP68 Fish strobe: YES Anti fouling properties: Tritonium coated lens LED Manufacturer: CREE Physical Size: 8.62" (219mm) x 3.07" (78mm) Depth: 0.86" (22mm) Total weight including electrical driver: 0.34kg Extension cable length (standard-hard wired to light): 9-7/64' (3M) Hole cut-out for cable entry: 1/2" (12.5mm) Material: Chemically Resistant Optical Polymer Lens material: Pilkington Optiwhite Body construction: Machined (First Release) Bezel material: Plastic Bezel thickness: N/A Bezel options: Stainless Steel Bezel Optional Bezel color: White Drag factor: N/A Optics: Collimator No of LEDs: 8 Certification: EMC Approved CE Approved: Yes Normalized SKU: 012307CUPC Code: 5051803007265

Ocean LED 012304W Underwater LightingX-Series X8 - White LEDsThe X8 packs a mighty 2,300 Fixture Lumens into its low profile design and utilizes focused optics to produce a 60x circular beam from each LED providing great water penetration, illuminating a large area.Choose either a single color version from either Midnight Blue or Ultra White or pick our Colours option where you can select any color you want from the RGBW spectrum. You can toggle between the colors or with our DMX controller and smartphone app, your choice is virtually limitless.Looking to catch more fish? Switch on the Fish-Strobe mode and the light emits a random strobe pattern that is proven to attract extra bait fish and help catch more fish.The low profile, simple design is easy to install even for the weekend DIYer. A small 12.5mm hole is all that's needed to run the cable through the hull. Fix 4 screws and that's the hard work done! Simply attach to 12V and you are ready to light up your world.Maintenance is virtually zero. Simply wipe the lens with a cloth to remove any marine growth thanks to the special Tritonium coating.Features:2,900 Lumens / 2,300 Fixture Lumens:Outstanding performance from this small, bright light makes it the obvious choice for those who want tostand out from the crowd.60° Beam AngleA wide-angled, focused beam lights up a large area of the water.Compact and simple designMade from a chemically resistant optical polymer with a built in driver, there is a lot packed into this compact light. Installation needs only a small, 12.5mm hole in the hull to feed the cable through and 3 screws in place. No bonding required.Easy to CleanThanks to its Tritonium coating, a simple wipe of the lens removes any underwater growth saving hours ofscrubbing each time you use it.Fish-Strobe ModeExceptionally bright, randomized strobing of the light is proven to attract more fish and catch more bait.Mounting Recommendations Boat size: up to 50' (15M) Transom / Hull spacing: 2-4' (0.5-1.2M) Transom quantity: 2-6 Hull quantity: 4-8" (10-20cm) Maximum hull thickness: N/A Installation depth (to top of fixture): 300mm below water line In water fitting: No Technical Light output equivalent to: 50W Xenon Fixture Lumens* (total light output from a finished fixture): 2,300 Lumens: 2,900 Beam angle: 60° circular Typical LED life expectancy: 40,000 hours Minimum-Maximum operating voltage DC: 9 - 32 V DC Minimum-Maximum operating voltage AC (AC/optional) Current / Amp draw (DC): 1.65A @ 12V DC - 0.75A @ 24V DC Approx. light penetration (avg. water quality): 26' (8M) Approx. Light penetration (perfect water quality): 72' (21+M) Driver type: Internal Driver size (L x W x H): N/A Color options: Ultra White - Midnight Blue or Colors Correlated Color Temp: 6500 K - 450 nm IP Rating: IP68 Fish strobe: YES Anti fouling properties: Tritonium coated lens LED Manufacturer: CREE Physical Size: 8.62" (219mm) x 3.07" (78mm) Depth: 0.86" (22mm) Total weight including electrical driver: 0.34kg Extension cable length (standard-hard wired to light): 9-7/64' (3M) Hole cut-out for cable entry: 1/2" (12.5mm) Material: Chemically Resistant Optical Polymer Lens material: Pilkington Optiwhite Body construction: Machined (First Release) Bezel material: Plastic Bezel thickness: N/A Bezel options: Stainless Steel Bezel Optional Bezel color: White Drag factor: N/A Optics: Collimator No of LEDs: 8 Certification: EMC Approved CE Approved: Yes Normalized SKU: 012304WUPC Code: 5051803007234

OceanLED 012309BI Underwater LightingOceanLED X16 Midnight #012309BINormalized SKU: 012309BI

OceanLED PLS-000017 Underwater LightingOceanLED X16 Plastic Bezel Black #PLS-000017Normalized SKU: PLS000017

OceanLED 012302BI Underwater LightingOceanLED X4 Midnight Blue #012302BINormalized SKU: 012302BI

OceanLED 012301WI Underwater LightingOceanLED X4 Ultra White #012301WINormalized SKU: 012301WI

OceanLED 012312B Underwater LightingOceanLED C4 Colours Underwater LightModel: 012312C Use X-Series X4 Colours for a dramatic spectacle on the move. Choose how you control your lights from the options below: Fantastic for fishing or having fun with family and friends. With a choice of sizes and colours, the X-Series range is simple to install and use allowing you to enjoy more time on the water. Made from a chemically resistant optical polymer with a built in driver, there is a lot packed into this compact light. As part of our continuous strive for delivering the highest quality products to our customers, the X-Series is now certified to the highest achievable rating of protection against water ingress, also known as IP69k. IP69k goes one step further than the industry standard IP68, the rating for continuous immersion in water. IP69k gives our customers total peace of mind when choosing the best possible solution for their yacht. The X-Series can also be used as an exterior light for your cockpit, deck or trailer. 60° circular beam angle allows for a variety of mounting orientations maintaining light spread Built-in driver, ultra low power draw, no start-up current required, reverse polarity protection Specifications Lumens Up to 1150 Fixture Lumens Up to 1150 Fixture Lumens beam Angles 60° Side Beam Angle 60° Side Beam Angle60° Top Beam Angle 60° Top Beam Angle Normalized SKU: 012312B

OceanLED 012302B-BLK Underwater LightingOceanLED X4 X-Series Midnight Blue LED Black HousingModel: 012302BBLK 60° Beam Angle Up to 1150 Fixture Lumens Circular Beam Angle Compact and simple design Simple to install Easy to clean Fish-Strobe Mode Active Thermal Control OceanLED X-Series is a superb uderwater LED light range for small and medium sized fishing and cruising boats.The OceanLED X-Series X4 combines brightness with affordability. Whether cruising or fishing, the X4 gives stunning performance allowing you to enjoy more time on the water with family and friends.The X4 outputs an impressive 1,150 fixture lumens from its low profile design and utilises focused optics to produce a 60° circular beam from each LED providing great water penetration, illuminating a large area. Choose Midnight Blue or Ultra White colour options.Looking to catch more fish? Switch on the Fish-Strobe mode and the light emits a random strobe pattern that is proven to attract extra bait fish and help catch more fish.Specifications Fixture lumens 1150 Life span 40,000 hours Beam Angle 60° LED Color Midnight Blue Drive Type Internal Cable length 3 meter Input Voltage 12 or 24 vDC Input Draw 0.8A @12vDC, 0.4A @ 24vDC Normalized SKU: 012302BBLK

OceanLED PLS-000107 Underwater LightingOceanLED X8 Plastic Bezel Black #PLS-000107Normalized SKU: PLS000107
