Newmar PA-60 Hailers & Hailer Horns"Hailer Horns Clear, distortion free, waterproof deck horns are ideal for shipboard paging, hailing, fog horn and alarm systems. High impact plastic construction and assembled with stainless steel hardware. 8 Ohm.   Model Output Nominal / Peak PA-8W 8 watts / 12 watts PA-30/20 30 watts / 20 watts PA-40/30 40 watts / 30 watts PA-60/40 60 watts / 40 watts Note: Model PA-60/40 is a commercial grade horn which also features excellent sensitivity as a microphone for use in talk-back systems. "Normalized SKU: PA60

Newmar PI-10B Intercom & Phones"The Phone-Com intercom system provides direct, wired, point-to-point communication anywhere on the vessel. Voice contact to any phone in the system is as easy as lifting the receiver and pressing the call button. Phone-Com operates on 12 VDC. They are constructed of high-impact plastic and are available in either bright white or traditional black. Bulkhead mounting bracket is provided. Two versions are available: PI-2: Designed for communication between only two points. A single call button sounds a buzzer and illuminates an indicator lamp on the companion phone. Available singly or as a set with 40' of interconnect wire, fuse, terminal lugs and mounting hardware. PI-2 SET: Two station phone set, 40' interconnect wire, fuse, lugs, mounting hardware; 5 lbs. PI-10:For multiple station calling capability. Up to 10 phones may be interconnected, and each phone has 10 call buttons. Sold individually-- see wiring requirements below. Phone-Com Wiring: For PI-2, use 5 conductor wire. For PI-10, add 3 to the total number of stations to determine minimum number of conductors required. Note: Phones are not waterproof and should be installed in a protected location"Normalized SKU: PI10B

Newmar 1-2-120A Battery Isolators"These heavy duty isolators allow charging multiple batteries automatically from one or two alternators, and prevent discharge or 'dumping"" of one battery into another. Each battery is charged according to its need without overcharging. rated for 12-48 volt negative ground DC systems. feature conservatively rated diodes and a rustproof anodized aluminum heat sink case. Models are available for 70, 120 and 165 amp alternators. Features: Heavy duty construction Rated for systems up to 48 volts DC, negative ground Rust-proof anodized aluminum case Stainless steel mounting hardware provided Protective covers provided for terminals Performance Specifications Operating temperature: -40° to +80° C Duty cycle: Continuous rating to 50° C Derate linearly to 70% @ 80° C Temp. rise: 5° C at full rated current (mount vertically for optimum cooling) Voltage drop: 0.7V @ 50% load, 0.9V @ full load Note: These battery isolators are not compatible with self exciting alternators. Please consult the manufacturer of your alternator if you are unsure of your configuration.  "Normalized SKU: 12120A

Newmar 1-2-70A Battery Isolators" These heavy duty isolators allow charging multiple batteries automatically from one or two alternators, and prevent discharge or "dumping" of one battery into another. Each battery is charged according to its need without overcharging. Rated for 12-48 volt negative ground DC systems. Feature conservatively rated diodes and a rustproof anodized aluminum heat sink case. Models are available for 70, 120 and 165 amp alternators. Features: Heavy duty construction Rated for systems up to 48 volts DC Rust-proof anodized aluminum case Stainless steel mounting hardware provided Protective covers provided for terminals Performance Specifications Operating temper ature: -40 to +80°C Duty cycle: Continuous rating to 50° C Derate linearly to 70% @ 80° C Temp. rise: 95° C at full rated current (mount vertically for optimum cooling) Voltage drop: At 50% load 0.7V - At full load 0.9V Model Alternator Battery Max Amperage Weight Dimensions   Sources Bank Input Capacity Lbs Kg L W H   1/2/70 1 2 70 2 0.9 3.25 4.5 3.1 in "Normalized SKU: 1270A

Newmar BX-2 Components"BX Series Provides for secure, protected below-deck wiring connections, IP rating 54 Rugged cast aluminum box with white enamel finish Easy wiring access through multiple grommeted cable entries Supplied with high quality connector strips Secure wires w/compression fittings ? no terminals required. Specifications Model BX-2 BX-3 Number of Connector Strips 1 2 Positions per Strip 12 11 Max Wire Gauge 16 14 Max amps (per Position) 6 10 Cable Entries 8 2 Max Cable Diameter .37" .59" Box Sizes - Inches 4.4" x 2.4" x 1.2" 4.7" x 3.7" x 1.3" Box Sizes - Centimeters 11.2 x 6.1 x 3.1 11.9 x 9.4 x 3.3 "Normalized SKU: BX2

Newmar PX-1 Terminal Blocks"Waterproof Junction Boxes Ideal for making wiring connections above or below decks, even in areas subject to occasional spray Similar to BX Series junction boxes, but made from rugged, non-corrosive, high impact polypropylene Snap-on cover provides watertight seal ""Universal"" cut-to-fit (see diagram) graduated diameter cable entries accommodate wide cable range Multiple position connector strips with ""captive"" screw compression wire terminals installed - meets ABYC standards Multiple knockouts provided for conduit access (in addition to cable entries) IEC Waterproof Rating: IP54 - ""Water projected in jets against the enclosure from any direction shall have no harmful effects."" Specifications Model PX-1 PX-2 PX-3 Number of Connector Strips 1 2 2 Positions per Strip 6 6 9 Max Wire Gauge 16 16 16 Number of Cable Entry Ports 5 7 7 Number of Cable Entries Installed 3 7 7 Spare Cable Entries Provided 2 0 0 Cable Diameter Range (inches) .14-.81 .14-.81 .14-1.0 Cable Diameter Range (mm) 3.5-20.5 3.5-20.5 3.5-25.5 Box Size Inches 2.95 x 2.95 x 1.66 3.35" x 3.35 x 1.66 4.45 x 4.45 x 2.29 Box Size Centimeters 7.5 x 7.5 x 4.2 8.5 x 8.5 x 4.2 11.3 x 11.3 x 5.8 "Normalized SKU: PX1UPC Code: 007-3001-0

Newmar PX-2 Components"Waterproof Junction Boxes Ideal for making wiring connections above or below decks, even in areas subject to occasional spray Similar to BX Series junction boxes, but made from rugged, non-corrosive, high impact polypropylene Snap-on cover provides watertight seal ""Universal"" cut-to-fit (see diagram) graduated diameter cable entries accommodate wide cable range Multiple position connector strips with ""captive"" screw compression wire terminals installed - meets ABYC standards Multiple knockouts provided for conduit access (in addition to cable entries) IEC Waterproof Rating: IP54 - ""Water projected in jets against the enclosure from any direction shall have no harmful effects."" Specifications Model PX-1 PX-2 PX-3 Number of Connector Strips 1 2 2 Positions per Strip 6 6 9 Max Wire Gauge 16 16 16 Number of Cable Entry Ports 5 7 7 Number of Cable Entries Installed 3 7 7 Spare Cable Entries Provided 2 0 0 Cable Diameter Range (inches) .14-.81 .14-.81 .14-1.0 Cable Diameter Range (mm) 3.5-20.5 3.5-20.5 3.5-25.5 Box Size Inches 2.95 x 2.95 x 1.66 3.35" x 3.35 x 1.66 4.45 x 4.45 x 2.29 Box Size Centimeters 7.5 x 7.5 x 4.2 8.5 x 8.5 x 4.2 11.3 x 11.3 x 5.8 "Normalized SKU: PX2

Newmar PX-3 Components"Waterproof Junction Boxes Ideal for making wiring connections above or below decks, even in areas subject to occasional spray Similar to BX Series junction boxes, but made from rugged, non-corrosive, high impact polypropylene Snap-on cover provides watertight seal ""Universal"" cut-to-fit (see diagram) graduated diameter cable entries accommodate wide cable range Multiple position connector strips with ""captive"" screw compression wire terminals installed - meets ABYC standards Multiple knockouts provided for conduit access (in addition to cable entries) IEC Waterproof Rating: IP54 - ""Water projected in jets against the enclosure from any direction shall have no harmful effects."" Specifications Model PX-1 PX-2 PX-3 Number of Connector Strips 1 2 2 Positions per Strip 6 6 9 Max Wire Gauge 16 16 16 Number of Cable Entry Ports 5 7 7 Number of Cable Entries Installed 3 7 7 Spare Cable Entries Provided 2 0 0 Cable Diameter Range (inches) .14-.81 .14-.81 .14-1.0 Cable Diameter Range (mm) 3.5-20.5 3.5-20.5 3.5-25.5 Box Size Inches 2.95 x 2.95 x 1.66 3.35" x 3.35 x 1.66 4.45 x 4.45 x 2.29 Box Size Centimeters 7.5 x 7.5 x 4.2 8.5 x 8.5 x 4.2 11.3 x 11.3 x 5.8 "Normalized SKU: PX3UPC Code: 007-3003-0

Newmar LS-I DecalsLS-I Standard Set-22 Labels ACCESSORY CABIN LIGHTS NAV/COM SUMP PUMP AFT CABIN ENGINE ROOM OUTLETS WATER HEATER ANCHOR FORE CABIN REFRIGERATOR WATER PRESSURE BILGE PUMP MAIN CABIN RUNNING WINDLASS BOW MAST SPARE SPREADER WINDSHIELD Normalized SKU: LSI

Newmar LS-III Decals"LS-III Deluxe Set - 182 Labels    Note: LS-III Set Sold with a LS-I and LS-II included AC POWER CABIN LIGHTS STBD FRESH WATER PUMP  OUTLETS GALLEY SPARE AIR COMPRESSOR COCKPIT LIGHTS FUEL PUMP MACERATOR STBD AIR COND COCKPIT OUTLETS FWD. AFT. MAIN BREAKER STEAMING LIGHTS AIR COND AFT. COCKPIT SUPPLY GALLEY BLOWER MAST HEAD STOP-START AIR COND FWD. COMPASS LIGHT GALLEY LIGHTS MICROWAVE OVEN SYNCHRO AIR COND MAIN COURTESY LIGHTS GARBAGE DISPOSAL NAVIGATION LIGHTS STROBE AIR COND PUMP CREWS QUARTERS GENERATOR OIL CHANGE PUMP TRASH COMPACTOR ALARM SYSTEM DAVIT WINCH GENERATOR 1 OUTLETS AFT TRANSFER PUMP AFT DECK DC POWER GENERATOR 2 OUTLETS DECK TRI-COLORED LIGHTS AFT DECK LIGHTS DC REFRIGERATION HEAD OUTLET ENG. ROOM TRIM TABS AUTO PILOT DECCA HEAD AFT. OUTLETS FWD WASH DOWN BAIT PUMP DECK LIGHTS HEAD FWD OUTLETS PORT WASHER BEVERAGE DISPENSER DISH WASHER HEATER OUTLETS SALON WASHER/DRYER BILGE LIGHTS DOCKING LIGHTS HOLDING TANK OUTLETS STBD  WATER MAKER BILGE PUMP DRYER HORN PORT WIPERS AFT. BILGE PUMP EMERGENCY LIGHTS HYDRAULICS POWER #1 FWD BILGE PUMP ENGINE CONTROL HULL LIGHTS RANGE #2 MID BLOWER ENG ROOM BLOWER ICE MAKER RAW WATER PUMP 12 VDC BOW THRUSTER ENG ROOM LIGHTS IGNITION REFRIGERATOR 24 VDC BRIDGE SUPPLY ENG ROOM OUTLETS INSTRUMENTS SALT WATER PUMP 32 VDC BURGLAR ALARM FANS INVERTER SEARCH LIGHTS 12 VDC OUTLETS CABIN LIGHTS AFT. FIRE EXT. LOAD GROUP 1 SHIP 12V CHARGER CABIN LIGHTS FWD. FLOOD LIGHTS LOAD GROUP 2 SHORE 24V CHARGER CABIN LIGHTS MID. FOREDECK LIGHTS LOUD HAILER SHOWER PUMP 110 VAC CABIN LIGHTS PORT FREEZER LPG CONTROL SPARE 220 VAC "Normalized SKU: LSIIIUPC Code: 020-0660-1
