Download LiteratureRaymarine E26028-PZ TransducersRaymarine P66 Transom mount Transducer with 10m cableCompatible with the following: ST60+ Instruments ST290 Instruments ST70 Instruments*Compatible hull material: metal, wood and fiberglassCable: 30ft (10m) CableDepth, Speed & Temperature*Using with ST70 requires purchase of ST70 Depth Pod, sold separately Specifications:Fairing Block Included = NONE Frequency = 200 kHz Mounting Style = Transom Pins = NONE Speed Included = Yes Temperature = Yes Beam Width = NONE Cable Length (Feet) = 10 mRAYMARINE TRANSOM MOUNT TRI DUCER FOR ST40Normalized SKU: E26028PZUPC Code: 723193260425Raymarine E26028-PZ Literature Download  Owners Manual  Product Brochure

Raymarine A80804 TransducersRaymarine TM185HW 1Kw Depth and Temperature CHIRP Transom MountModel: A80804 Depth and fast-response water-temperature sensing 1 kW of power High frequency: 150 to 250 kHz - Constant 25° beamwidth - Maximum depth of 152 m (500') 100 kHz of total bandwidth from one transducer Covers popular fishing frequency of 200 kHz plus everything else in the bandwidth Stainless steel bracket for installation on outboard or inboard/outboard powered boats Recommended for use on planing and displacement hulls SEALCAST™, seamless, urethane housing for long life in the water Also available as thru-hull Tilted™ Element (B175HW)(SS175HW), thru-hull with fairing (B285HW), and in-hull (M285HW) mounts Patented Xducer ID® technology Get more coverage under your boat with Airmar’s unique, wide-beam, high-frequency, Chirp-ready TM185HW. The high-frequency band operates across a range of 150 to 250 kHz and has a fixed 25° beam. The high-frequency band yields superior shallow-water performance, bottom detail, and fish-target separation. The constantly wide beam provides twice the coverage for detecting fish in the upper-water column and clear fish arches on the display compared to most high-frequency, narrow-beam transducers. The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage are essential down to 152 m (500').Specifications Power Rating 1 kW Transom Angle 3° to 21° Functions Depth, Temperature Max Vessel LOA Up to 10 m (33') Acoustic Window Urethane Common Use Leisure/Yachting, Fishing Freq Hi Wide 150-250 kHz High-Wide Beamwidth 25° Housing Urethane/Stainless Bracket Hull Material Compatible w/ all hull materials Max Depth 150 m (500') Mounting Style Transom Retractable housing No Single or Dual Frequency CHIRP-Ready Single-Band Tilted Element No Weight: 4.2 kg (9.2 lb.) Normalized SKU: A80804UPC Code: 723193862544

Raymarine A80803 TransducersRaymarine TM185MW 1Kw Depth and Temperature CHIRP Transom MountModel: A80803 Depth and fast-response water-temperature sensor 1 kW with depth tracking down to 400 m (1,300') Medium frequency: 60-100 kHz - 57° to 73° beamwidth (port/starboard) - 16° average fore/aft 40 kHz of total bandwidth from one transducer Medium frequency for superior mid-depth performance and excellent fish-target separation Simple installation on transom of the boat Great performance at boat speeds below 30 knots Easy maintenance and low-cost replacement Exclusive Xducer ID® technology AIRMAR’s innovative transducer designs have revolutionized the fishing world, and they continue to do so with the NEW Chirp-ready TM185 Medium Ultra-Wide (MW) Transom Mount transducer. The TM185MW takes transducer design and performance to a whole new level by using medium frequency (60-100 kHz) with an incredible ultra-wide beamwidth ranging from 57-73° port-starboard to 16° average fore-aft. Maximum coverage under the boat is achieved with this medium-frequency transducer, serving anglers who target pelagic species in the upper water column. Airmar’s new Medium Ultra-Wide models are perfect for seeking deeper species with a frequency band from 60?100 kHz.The TM185MW Transom Mount is a 1 kW transducer housed in one of AIRMAR’s most popular housings. Transom models are best suited for small and trailered vessels where a thruhull installation is not practical. Simple to install and ideal for small trailered vessels where a thru-hull may interfere with loading.Specifications Power Rating 1 kW Transom Angle 2° to 22° Functions Depth, Temperature Acoustic Window Urethane Cable-Length 9 m (30') Common Use Leisure/Yachting, Fishing Country of Origin USA Freq Med Wide 60-100 kHz Housing Urethane/Stainless Bracket Hull Material Compatible w/ all hull materials Max Depth 400 m (1300') Medium Frequency 60-100 kHz Medium-Wide Beamwidth 57° to 73° beam p/s 16° average f/a Mounting Style Transom Power Rating 1 kW Retractable housing No Single or Dual Frequency CHIRP-Ready Single-Band Tilted Element No Weight 4.2 kg (9.2 lb.) Normalized SKU: A80803UPC Code: 723193862537

Raymarine A80013 TransducersTransom Mount TM265LH 1kw Chirp Transducer for CP450CFeatures: Depth/Temp Transom Mount Urethane CP450C Plug on Cable Frequency: L=42-65 kHz, H=130-210 kHz Power 1kW Specifications:Beam Width = NONE Cable Length (Feet) = NONE Fairing Block Included = NONE Frequency = NONE Load Equivalence # (LEN) = NONE Mounting Style = NONE Pins = NONE Speed Included = NONE Temperature = NONENormalized SKU: A80013UPC Code: 723193704189

Raymarine A80041 TransducersRaymarine TM265LM Transom #A80041Normalized SKU: A80041UPC Code: 723193729045

Raymarine E66066 Network AccessoriesDSM30 & DSM300 Transducer Adapter CableThe DSM30/DSM300 Transducer Adapter Cable allows you to utilize Raymarine's wide offering of specialty and high performance in-hull, through-hull or transom mount transducers with our new MFDs with built-in sounder. This adapter is also perfect for occaisions where a new sounder-equipped Raymarine MFD is replacing both an old display and DSM.Adapter cable adapts DSM30/DSM300 transducers to A series Transducers Electrical: CableRAYMARINE E66066 ADAPTER CABLE FOR DSM250/300Normalized SKU: E66066UPC Code: 723193660669

Raymarine E66074 Network AccessoriesTransducer Extension Cable, 3MTransducer extension cable for DS400x, DS500x, DS600x and DSM25 (A65) fishfinders.3 meter extension cable extends the length of your stock transducer cable for extra-long runs on larger vessels. Plug-together connections for fast and easy installation. Note: For optimum performance Raymarine recommends adding no more than 3 extension cables to any given transducer cable. RAYMARINE E66074 3ME XDUCER EXT F/ DS400/500/600Normalized SKU: E66074UPC Code: 723193660744

Raymarine E66010 Network AccessoriesTransducer Extension Cable, 5 meterAdds 5 meters of length to the stock transducer cable.Works with the L755, L760, L770, L1250, L1260, and DSM compatible systems. Electrical: CableRAYMARINE 5M TRANSDUCER EXT CABLENormalized SKU: E66010UPC Code: 023193660103

Raymarine R70651 TransducersTransom Mount Bracket for HV-100Raymarine Transom Mount Bracket specifically for Raymairne's HV-100. Normalized SKU: R70651UPC Code: 723193824610

Raymarine R70387 AccessoriesTrim Kit for Axiom Pro 12/eS12Raymarine Multifunction Display eS Series and Axiom Pro accessories trim kit. Normalized SKU: R70387UPC Code: 723193794449

Raymarine A80330 TransducersTrolling Motor BracketTrolling Motor Bracket specifically designed for the Dragonfly CPT-DV and CPT-DVS transom mount transducers. Normalized SKU: A80330UPC Code: 723193796177

Raymarine A80557 TransducersTrolling Motor Mount for HV-100Raymarine's Trolling Motor Mount bracket for the HV-100 transducer.  Normalized SKU: A80557
