VDO B00070501 Charger AccessoriesLinkUp Intelligent Temperature & PressureThis Sensor measures simultaneously the engine oil's temperature and pressure while providing the data to the LinkUp, which translates it to the NMEA 2000® standard.Features: Interface to the new electronic 2-in-1 sensor Oil Temperature and Pressure in a single sensor Rugged and reliable design derived from the automotive field ASIC-controlled sensor PWM (Pulse Width Modulated) output to transmit both pressure and temperature Technical Specifications: M12 mounting thread IP 69/K protection class 5V power feed provided by the LinkUp Temperature accuracy ± 1°K in the 135 °C – 160 °C range Pressure accuracy ± 0.2 bar (range 0.5 –3 bar), ± 0.1 bar below and ± 0.3 bar above Temperature range: -40 °C + 160 °C Pressure range: 0.5 to 10.5 bar 1M cable length This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: B00070501UPC Code: 7640178729674

� Download Literature� Watch VideoVDO B00042201 Senders & AccessoriesLinkUp Analog to NMEA 2000 GatewayThe resistive-type LinkUp gateway provides an easy method to convert vessel and engine information to NMEA 2000.Easily installed, the LinkUp Gateway replaces the original wiring, delivering power to both the LinkUp device and sensor from the NMEA 2000 backbone while still being complaint with the NMEA 2000 certification requirements. Configuring the LinkUp Gateway is simple using a mobile device and the companion LinkUp Configuration App for Android or IOS.Each device has a built-in passive NFC antenna, so the parameters of the sensors are wirelessly configured to type, instance and warning threshold on the mobile device which is then "tapped" against the LinkUp device for instant data download. Features: User-friendly configuration through wireless interface and companion smartphone App Sensor Cable length - 25cm NMEA 2000 Cable length - 25 cm Tap to download parameters Mobile App for Android or IOS No power required to program No certification required Bi-directional communication, programming interface or data recovery Supported Sensors: Fuel Level Oil/Boost Pressure Fresh/Waste Water Level Oil/Gear Oil/Coolant Temperature Trim Tabs Rudder Angle Technical Specifications: Standard M12 NMEA 2000 plug LED Notification  Operating Voltage - 6 - 16.5V Nominal Voltage - 12 V (from NMEA 2000 network) IPX7 Rated Sensor Plug - Superseal Female 2 Pin Counterpart Sensor Plug - - Superseal Male 2 Pin *Sold as an Individual  Normalized SKU: B00042201UPC Code: 7640178729490VDO B00042201 Literature Download� Product BrochureVDO B00042201 Video

Watch VideoVDO B00042401 Navigational InstrumentsLinkUp J1939 to NMEA 2000 GatewayThis single-sensor gateway is designed to upgrade your vessel sensors to NMEA 2000®. Can be easily configured through either the embedded wireless interface or NMEA 2000® by means of our Configuration Tool. The ISO 8846:1990 compliance completes the devices by allowing their installation into compartments.Features: Waterproof sensor connection No external power supply required Wireless configuration through companion mobile App Explosion-proof housing body for engine room installation Standard DeviceNet M12 plug to interface NMEA 2000 Input signal - SAE J1939 Nominal Voltage - 12V *Sold as an Individual Normalized SKU: B00042401VDO B00042401 Video

� Watch VideoVDO B00042301 Senders & AccessoriesLinkUp - Pyrometer KitThe system includes a Veratron LinkUp Gateway Module that enables the Pyrometer Sensor to be connected to and compatible with the NMEA 2000 network.  Its internal galvanic isolation decouples the backbone power from the LinkUp power supply, per NMEA requirement. Configuring a LinkUp gateway is simple using a mobile device and the companion Veratron app available from the App Store and Google Play.  Each module has a built-in passive wireless antenna. The parameters of the sensor are configured to type, instance and warning threshold on the mobile device and then tapped against the LinkUp device for instant data download.Alternatively, LinkUp devices can be configured via NMEA 2000 with the PC Configuration Tool. This method additionally allows for real-time reading of the analog signal. An LED on the device will illuminate, notifying the user that the LinkUp is being configured.*Includes sensor and Link Up Gateway.Features: NMEA 2000® certified Wireless configuration through companion mobile App Status LED Plug-and-Play installation and configuration Input Signal - LIN bus Nominal Voltage - 12V *Sold as an Individual Specifications:Series = LinkUp Gauge Type = Pyrometer Gauge Size = N/A Voltage - Input Range (Volts) = 12V Box Set = NoNormalized SKU: B00042301UPC Code: 7640178729506VDO B00042301 Video

Download LiteratureVDO B002008 Senders & AccessoriesOil Pressure Sensor - 1/8"-27NPT Thread - 10 Bar Veratron’s Pressure Sensors deliver a stable quality reading during a long lifespan. They have excellent anti-vibration performance and a wide operating temperature range. The sensors can be used in a wide range of applications.All sensors come with a sensor output and an insulated ground pin.Features: Function - Engine oil pressure, transmission oil pressure Thread - 1/8"-27NPT Calibration - 10-184 Ohm Measurement Range - 10 bar Output Signals - Resistive Wide Operating Range - -25 to 120°C Insulated ground pin Normalized SKU: B002008VDO B002008 Literature Download Quick Reference Guide Owners Manual

Download LiteratureVDO B002007 Senders & AccessoriesOil Pressure Sensor - 1/8"-27NPT Thread - 5 Bar Veratron’s Pressure Sensors deliver a stable quality reading during a long lifespan. They have excellent anti-vibration performance and a wide operating temperature range.The sensors can be used in a wide range of applications.All sensors come with a sensor output and an insulated ground pin.Features: Function - Engine oil pressure, transmission oil pressure Thread - 1/8"-27NPT Calibration - 10-184 Ohm Measurement Range - 5 bar Output Signals - Resistive Wide Operating Range - -25 to 120°C Insulated ground pin Normalized SKU: B002007VDO B002007 Literature Download Quick Reference Guide Owners Manual

Download LiteratureVDO B00204101 GaugesSuzuki VMH-35 PWM Display with Sumitomo ConnectorsEnjoy the Plug and Play installation thanks to the dedicated harness equipped with mating Suzuki connectors. A sleek, high-tech digital display for performance monitoring of your Suzuki-powered boat.The Digital sun-readable display with analog inputs, alarm inputs, and the NMEA 2000® converter makes this the perfect stand-alone solution for your boat cockpit.The elegant black-glass design displays a wealth of critical boat system data in a compact package that's perfect for dashboards, consoles, and bulkheads on smaller vessels with limited space. The Veratron VMH 35-Suzuki is designed with a mineral glass front that's optically bonded to the sun-readable hybrid display. A sleek, brushed stainless steel bezel surrounds the device and fits into classic and modern marine décors.As small boat consoles are often fully exposed, the round display is waterproof to IPX7 criteria, both front and back, and it fits a standard 85mm (3-3/8’’) panel cutout size.Features: Works effortlessly with multiple Suzuki engines Dedicated configurable inputs for engine sensors and alarms NMEA 2000® converter included Sunlight-readable display with mineral glass lens IPX7 front/rear protection class Intelligent battery sensor (IBS) compatible Full NMEA 2000 Integration -  The embedded NMEA 2000® gateway distributes sensor data inputs such as fuel, trim, and tachometer to other devices like chartplotters, saving the need for an additional external converter. Highly adaptable to a wide range of onboard networks, it's equipped with analog inputs, making it ideal for refitting with older engines. Embedded GNSS Receiver - The integrated GPS makes the VMH 35-Suzuki the perfect standalone navigation solution by enhancing the engine data information with speed, compass, and position. Powerful Multifunction Display - Powered by the latest microprocessor, the Veratron VMH 35-Suzuki is blazingly fast. Yet even when set at full brightness, it draws a mere 170mA of power—a fraction of what comparably-sized TFT screens use. The VMH 35-Suzuki has the capacity to provide 30 types of data, including engine, EcoMode pop-up screen, RPMs up to 8'000 with a programmable overspeed alarm, tank levels, battery status, GPS, and vessel information. It's easily configured using the embedded on-screen menu and soft-touch buttons. *This product is designed to be compatible with Suzuki engines. However, it is not manufactured, endorsed, or approved by Suzuki Motor Corporation. Veratron AG is an independent company with no affiliation or relationship with Suzuki Motor Corporation. Normalized SKU: B00204101VDO B00204101 Literature Download Owners Manual
