Perko 0211MB0DPW Anchor-Masthead Lights New High-Tech design with self-contained LED modules White Polymer Quality components designed for harsh marine environments Meets Global Specs for: ABYC C-5, NMMA Type Accepted, EN/ISO 19009:2015, ABYC A-16 (2016), 1972 COLREGS, RCD 2013/53/EU, USCG 33 CFR - 3nm NMMA Type Accepted Number: 2619845 Technical Information: Voltage: 12 Volt LED Wattage: 2.2 watts Amperage: 0.20 amps Visibility: 3nm Visibility Arc: 225° Height: 2-1/4" Base Dimensions: 3-3/8" O.D. Normalized SKU: 0211MB0DPWUPC Code: 085226790720

Perko 0655DP1BLK Bow LightsLED BiColor Light - 12 Volt. For use on power driven vessels under 20 m (65.6 Ft.). ABYC C-5 Compliant. Horizontal Mount. Dimensions: 3-7/8” (L) x 3-1/4” (W) x 7/8”(H). High tech, self contained LED modules. For use on power driven vessels under 20 m (65.6 Ft.) ABYC C-5 Compliant Horizontal Mount Dimensions: 3-7/8” (L) x 3-1/4” (W) x 7/8”(H) High tech, self contained LED modules Normalized SKU: 0655DP1BLKUPC Code: 085226787607

Perko 0655DP1WHT Bow LightsLED BiColor Light - 12 Volt. For use on power driven vessels under 20 m (65.6 Ft.). ABYC C-5 Compliant. Horizontal Mount. Dimensions: 3-7/8”(L) x 3”(W) x 1-3/16”(H). High tech, self contained LED modules. For use on power driven vessels under 20 m (65.6 Ft.) ABYC C-5 Compliant Horizontal Mount Dimensions: 3-7/8”(L) x 3”(W) x 1-3/16”(H) High tech, self contained LED modules Normalized SKU: 0655DP1WHTUPC Code: 085226787645

Perko 0655DP2WHT Bow LightsLED BiColor Light - 12 Volt Rounded Top. For use on power driven vessels under 20 m (65.6 Ft.). ABYC C-5 Compliant. Horizontal Mount. Dimensions: 3-7/8”(L) x 3”(W) x 1-3/16”(H). High tech, self contained LED modules. For use on power driven vessels under 20 m (65.6 Ft.) ABYC C-5 Compliant Horizontal Mount Dimensions: 3-7/8”(L) x 3”(W) x 1-3/16”(H) High tech, self contained LED modules Normalized SKU: 0655DP2WHTUPC Code: 085226787706

Perko 1683DP0CHR Bow Lights The Perko 1683DP0CHR is a fixed-mount LED combination bow and anchor light certified to USCG 3nm (3-mile) visibility standards, built for boats that need a single fixture to handle both underway navigation lighting and at-anchor all-around white light. The chrome-plated zinc alloy insert gives it a polished look against the black polymer top and base, with a clear polymer lens that keeps the LED output clean and unobstructed. Each light compartment draws just 2.2W and 0.2A at 12V, making this one of the lowest-draw navigation light options available while still meeting federal visibility requirements. The fixed mount uses a 3/4 in. diameter anodized aluminum pole with a base footprint of 1 in. by 2-5/8 in. and a total height of 3-3/8 in., keeping the profile compact on the bow without sacrificing the visibility range required by USCG regulations. Gold-plated contacts resist corrosion at the electrical connection points, which is a detail that matters on a light that lives on the bow and takes spray on every run. Mounting hardware uses #8 screws. This is a direct replacement for existing Perko bow and anchor light installations and fits the same pole and base dimensions as other fixed-mount Perko navigation lights in the same series. Confirm your pole diameter and base footprint before ordering if replacing an existing fixture. USCG certified: 3nm (3-mile) visibility Voltage: 12V LED Power: 2.2W / 0.2A per compartment Pole: 3/4 in. diameter anodized aluminum Height: 3-3/8 in. Base dimensions: 1 in. x 2-5/8 in. Mounting screw: #8 Gold-plated contacts Housing: black polymer with chrome-plated zinc alloy insert and clear polymer lens Wiring Note: When choosing LED upgrades to replace existing incandescent combination masthead/all-round lights, optional Cat. No. 1680DP012V Converter Module is available to avoid re-wiring the navigation light switch.Because direct wire-to-wire substitution of an older style incandescent light with this new style L.E.D. light will not work, there are two installation alternatives:1) Rewire the existing switch to match the diagram supplied in the L.E.D. light instructions or,2) Use the optional converter module (Cat. No 1680DP012V) and follow the wiring in the instructions provided with the new L.E.D. light so that no rewiring of the switch is necessary. Normalized SKU: 1683DP0CHRUPC Code: 085226782138

Perko 1681DP0CHR Anchor-Masthead Lights The Perko 1681DP0CHR is a 13-1/2 in. folding horizontal-mount LED combination masthead and anchor light, certified to USCG 3nm (3-mile) visibility standards. The horizontal mount design positions the light parallel to the deck surface rather than vertical, which suits low-profile bow rails, T-tops, and hardtop mounting points where a vertical pole would interfere with clearance or storage. The pole folds down 90 degrees in either direction opposite the attachment plate, making it easy to lower the light for trailering, bridge clearance, or storage without removing the fixture entirely. Two light compartments handle masthead and anchor functions in a single fixture. Each compartment draws 2.2W and 0.2A at 12V, keeping the total electrical load minimal on a 12V house circuit. The 3/4 in. diameter anodized aluminum pole stands 13-1/2 in. tall when deployed, with a base footprint of 2 in. by 1-1/2 in. and a center-to-center base dimension of 1-3/8 in. for mounting hole layout. Gold-plated contacts at the electrical connection resist corrosion from spray and moisture exposure. Mounting uses #8 screws. The housing is black polymer with a chrome-plated zinc alloy insert and a clear polymer lens, matching the same construction as other Perko navigation lights in the series. This is a direct replacement for existing horizontal-mount Perko masthead and anchor light installations. Confirm your base dimensions and pole diameter before ordering if replacing an existing fixture. USCG certified: 3nm (3-mile) visibility Mount type: horizontal, folding 90 degrees in either direction Voltage: 12V LED Power: 2.2W / 0.2A per compartment Pole: 3/4 in. diameter anodized aluminum Height: 13-1/2 in. Base dimensions: 2 in. x 1-1/2 in., center-to-center 1-3/8 in. Mounting screw: #8 Gold-plated contacts Housing: black polymer with chrome-plated zinc alloy insert and clear polymer lens Wiring Note: When choosing LED upgrades to replace existing incandescent combination masthead/all-round lights, optional Cat. No. 1680DP012V Converter Module is available to avoid re-wiring the navigation light switch.Because direct wire-to-wire substitution of an older style incandescent light with this new style L.E.D. light will not work, there are two installation alternatives:1) Rewire the existing switch to match the diagram supplied in the L.E.D. light instructions or,2) Use the optional converter module (Cat. No 1680DP012V) and follow the wiring in the instructions provided with the new L.E.D. light so that no rewiring of the switch is necessary. Normalized SKU: 1681DP0CHRUPC Code: 085226782251

Perko 1684DP0CHR All-Round LightsFolding Masthead Light Vertical Combo Mast/All-Round 12-13/16" High Sail or Power <20MFeatures: Black polymer top and base with clear polymer lens and chrome plated zinc alloy insert 3/4" diameter anodized aluminum tube <20M Vertical Combo Mast/All-Round Normalized SKU: 1684DP0CHRUPC Code: 085226782282

Perko 0170BM012L Anchor-Masthead Lights LED Masthead Light - 12 volt. Replaces Perko 0170BM0DP3 Normalized SKU: 0170BM012L

Perko 0170BP012L Sidelights Red LED Side Light - 12 volt Replaces Perko 0170BP0DP3 Normalized SKU: 0170BP012L

  Download Literature Perko 0170WSDDP3 Sidelights European Style L.E.D. Navigation LightsCertified for use on sail or power drivenVessels under 20 meters in lengthDescription Green Side Light White Plastic Housing 112-1/2° Visibility Arc 2 Mile Visibility L.E.D Features Uses less than half the energy The draw of standard lights Low heat Long life Specifications: Visible Range (Miles) = 2 Housing = White Visibility Arc (Degree) = 112-1/2 Lens Color = Green Matching Red Sidelight Model 0170WP0DP3 Normalized SKU: 0170WSDDP3UPC Code: 085226348235 Perko 0170WSDDP3 Literature Download   Quick Reference Guide
