Download LiteratureRaymarine E70347 Navigation CamerasCAM220 Day & Night IP Marine Eyeball CameraRuggedised, High Definition, Day and Night network dome video camera suitable for above or below deck applications. Dome design provides all round selected viability whilst the small frame size allows for rapid installation. Stylised to blend in with your boat's aesthetic design. Ruggedised, High Definition, Day and Night network dome video camera suitable for above or below deck applications.Dome design provides all round selected viability whilst the small frame size allows for rapid installation. Stylised to blend in with your boat's aesthetic design. Plug and play integration with Raymarine MFD's running Lighthouse II Power over Ethernet (PoE) or direct 12V DC power supply High bright IR LEDs for operation in total darkness Simple mechanical frame allows the camera to be locked, rock steady, into position Specifications: CPU: 32-bit ARM9 RISC CPU up to 432MHz Flash / SDRAM: 128MB / 128MB Image Sensor: 2.0 Megapixel 1/2.8" SONY progressive scan CMOS(Exmor) Total Pixels: 1952(H) x 1116(V) 2.18 Megapixel Effective Pixels: 1944(H) x 1104(V) 2.15 Megapixel S/N Ratio: More than 50dB Minimum Illumination: 0Lux (IR On) IR Distance: 20M (4 Built-in High Power LED's) Day & Night: ICR Lens: 3.6mm Wide angle Megapixel Board Lens Field of View: Horizontal = 51.0° +/- 3°Vertical = 93.0° +/- 3° Video Compression: H.264 High Profile@4.0, MJPEG Image quality: 3 Steps Resolution: Up to 1920 x 1080 (Full HD) Frame Rate: H.264 Up to 30fps with 1920x1080 | MJPEG Up to 30fps with VGA resolution Video Streaming: Support multi stream with H.264, MJPEG Adjustable frame rate CVBR/CBR in H.264 Pan / Tilt / Zoom: Digital Pan, Tilt and Zoom Image Setting: Day & NightAuto White BalanceShutter Speed (1/41/2,000)DSSBLCBrightness, Contrast, Sharpness, Mirror Security: Password protection, User access log, HTTPS encryption Supported Protocol: HTTP, HTTPS, FTP, SMTP, UPnP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP Intelligent Video: Motion detection up to 1920x1080 with 12x12 blocks Power Source: DC12V/1.5A, PoE(Power over Ethernet): 802.3af Power Consumption: Max. 5.4W, with IR Net Weight: 230g(Camera Only) LED's: Power, Network Connection Dimensions: 178mm(D) x 66 Diameter General Operation Temperature: -10°50° Celsius(14F122F) Storage Temperature: -20°60° Celsius(4F140F) Specifications:Reverse Image = NONE Waterproof Rating = NONENormalized SKU: E70347UPC Code: 723193813270Raymarine E70347 Literature Download  Owners Manual

  Download LiteratureRaymarine E03016 Navigation CamerasCAM50 Normal View CameraFor Any Monitoring NeedsRaymarine CAM50 is the ideal camera for interior installations. Its unobtrusive dome design is ideal for mounting in the salon, wheel house or engine room.Features: Indoor camera designed for wheelhouse, salon, or engine room monitoring High quality Sony CCD (380 TVL) IR sensitive for use in low-light conditions Manual pan and tilt adjustments Compatibility with E-Series, G170 & G190 Marine Monitors, H6 and other applications utilizing composite video Low profile wall or ceiling mount Standard image model NTSC video output model Ceiling or Wall Mount Plug and Play Adjustable field of view High quality imager Excellent color reproduction Ideal For Monitoring: Blind spots Decks Engine room Salon Crew Specifications:Reverse Image = No Waterproof Rating = WaterproofRAYMARINE CAM50 DOME CAMERA Normalized SKU: E03016UPC Code: 723193030165Raymarine E03016 Literature Download  Owners Manual

Raymarine D031 AutopilotsCantilever Mounting SocketUsed to mount the fixed end of the tiller autopilot to a vertical surface such as a cockpit sidewall. Specifications:Drive Type = NONE Feedback Type = NONE Pilot Type = NONE Remote Capable = NONE Turn Patterns = NONE Vessel Displacement - Max (Pounds) = NONE Boat Length - Max (Feet) = NONE Capacity - Max Ram (CU) = NONERAYMARINE CANTILEVER SOCKET FOR TILLER PILOTSNormalized SKU: D031UPC Code: 723193102046

  Download LiteratureRaymarine T909 Navigational Instruments Only 95g (0.21 lbs) Heel and pitch angle 30 degrees Calibration at the displays Normalized SKU: T909UPC Code: 5037707009093Raymarine T909 Literature Download   Quick Reference Guide  Owners Manual

Raymarine E25024 Mounting HardwareConsole Mounting Bracket, ST40 InstrumentsAluminum bracket allows for tabletop, console, or overhead mounting of ST40 InstrumentsIncludes bracket and mounting hardware. Specifications:Mounting Style = NONE Usable Face = NONE Cut/Uncut = NONERAYMARINE E25024 ST40 MTG BRK Normalized SKU: E25024UPC Code: 023193250243

  Download LiteratureRaymarine E70205 Network AccessoriesCP100 CHIRP DownVision™ Sonar Module with CPT-100DVSRaymarine's CP100 CHIRP DownVision™ Sonar Module brings powerful sonar imaging capability to Raymarine's full line of networkable multifunction displays.Two sonars in one, the CP100 features Raymarine's CHIRP fish targeting as well as the photo-like CHIRP DownVision™ sonar. The CP100 interfaces to the RayNet (Ethernet) network enabling the CP100 to be accessed from any Raymarine network display. Unlike conventional imaging sonars that transmit on a single frequency with each pulse, the CP100's DownVision™ sonar uses CHIRP technology to transmit across a wide spectrum of sonar frequencies with each pulse - the result is much higher-resolution, life-like sonar images. CP100's fish targeting channel features amazing resolution enabling it to easily separate individual baitfish in a school, and distinguish the bait from predator species. Best of all, the CHIRP fish targeting can be viewed simultaneously with CHIRP DownVision™ for the ultimate view of what is underneath the water.The ultra-compact CP100 CHIRP DownVision™ Sonar Module is compatible with all Raymarine a-Series, c-Series, e-Series and gS-Series multifunction displays. The CP100 is available bundled with the CPT-100 transom mount transducer. The CP100 Sonar module only (no transducer included) can be paired with optional plastic or bronze thru hull transducers. Features: Photo-like imagery of bottom structure using CHIRP DownVision™ CHIRP powered dual channel sonar; view high resolution DownVision™ structure imagery and target fish with CHIRP sonar simultaneously Perfectly matched transom mount and through hull CHIRP transducers available Fast response temperature sensor built into the transducer Maximum depth 600 feet for both channels Simple RayNet Ethernet connection to Raymarine a, c, e and gS Series MFDs CPT-100 transom mount transducer included Optional RayNet network cable required to complete installation: 2 meter RayNet Cable Part #A62361 5 meter RayNet Cable Part #A80005 Specifications:Load Equivalence # (LEN) = NONENormalized SKU: E70205UPC Code: 723193783368Raymarine E70205 Literature Download  Product Brochure

  Download Literature  Watch VideoRaymarine E70256 Black Box ModuleCP200 CHIRP SideVision™ Sonar Module - No TransducerExpand your underwater horizon with the CP200 CHIRP SideVision™ sonarThe CP200 CHIRP SideVision™ Sonar expands your underwater horizon with crystal-clear, bank-to-bank displays of fish, bait and underwater structure. Engineered with the same CHIRP sonar technology as Raymarine's award winning DownVision™ the CP200 uses advanced CHIRP signal processing technology to let you see further, see more clearly, and detect more fish than traditional side scanning sonars.Experience Visionality™CP200 delivers side scan sonar imagery so close to reality we call itVisionality™. See amazing photo-like imagery of underwater terrain andman-made objects. Experience Visonality™ up to 600ft on each side.Superior Range PerformanceRaymarine CHIRP signal processing delivers high resolution and excellentlong range performance. Identify objects and see fish even further, out to600-feet on each side!CHIRP SideVision™ TechnologyDual independent transducer arrays. Best-in-class side scan performance using two high-performance transducer arrays with dedicated CHIRP sonar channels. High-angle setting for shallow water applications or low-angle setting for deep water applications.See FurtherIndependently adjustable transducer arrays enable anglers to preset their SideVision™ transducer angle for either shallow or deep water applications. Left and Right sonar images up to 600'/183m either side of the boat.Easy to NetworkConnect the CP200 with Raymarine LightHouse II powered multifunction displays, including aSeries, cSeries, eSeries and gS Series systems.CHIRP SideVision™ and DownVision™ TogetherCombine the CP200 with CHIRP DownVision™ for the ultimate in sonar intelligence, giving you a full 180 degree view of your underwater surroundings. Add CHIRP DownVision™ to your network with a CP100 sonar or an aSeries multifunction display (DownVision™ models only).Features: Network compatible CHIRP SideVision™ sonar for aSeries, cSeries, eSeries and gS Series MFDs Multi-sonar compatible: view CHIRP SideVision™ alongside other sources, simultaneously Image fish, bait and bottom structure at distances up to 600 feet horizontally per side CHIRP signal processing delivers crystal-clear images with amazing detail Works seamlessly alongside Raymarine Digital, CHIRP and CHIRP DownVision™ sonar Adjustable CPT-200 transducer (not included) optimizes performance for shallow or deep water scanning IN THE BOXSONAR MODULEDOCUMENTATION PACKMOUNTING SCREWS (4)POWER CABLE 1M Specifications:Watts RMS - Max = NONE Waterproof Rating = Waterproof Service Carrier = NONE Load Equivalence # (LEN) = NONE Frequency = NONE Audio Capable = NONENormalized SKU: E70256UPC Code: 723193787410Raymarine E70256 Literature Download  Product BrochureRaymarine E70256 Video

  Download Literature  Watch VideoRaymarine E70257 Black Box ModuleCP200 CHIRP SideVision™ Sonar Module with CPT-200 Transom Mount TransducerExpand your underwater horizon with the CP200 CHIRP SideVision™ sonarThe CP200 CHIRP SideVision™ Sonar expands your underwater horizon with crystal-clear, bank-to-bank displays of fish, bait and underwater structure. Engineered with the same CHIRP sonar technology as Raymarine's award winning DownVisionT the CP200 uses advanced CHIRP signal processing technology to let you see further, see more clearly, and detect more fish than traditional side scanning sonars.Experience Visonality™CP200 delivers side scan sonar imagery so close to reality we call itVisionality™. See amazing photo-like imagery of underwater terrain andman-made objects. Experience Visonality™ up to 600ft on each side.Superior Range PerformanceRaymarine CHIRP signal processing delivers high resolution and excellentlong range performance. Identify objects and see fish even further, out to600-feet on each side!CHIRP SideVision™ TechnologyDual independent transducer arrays. Best-in-class side scan performance using two high-performance transducer arrays with dedicated CHIRP sonar channels. High-angle setting for shallow water applications or low-angle setting for deep water applications.See FurtherIndependently adjustable transducer arrays enable anglers to preset their SideVision™ transducer angle for either shallow or deep water applications. Left and Right sonar images up to 600'/183m either side of the boat.Easy to NetworkConnect the CP200 with Raymarine LightHouse II powered multifunction displays, including aSeries, cSeries, eSeries and gS Series systems.CHIRP SideVision™ and DownVision™ TogetherCombine the CP200 with CHIRP DownVision™ for the ultimate in sonar intelligence, giving you a full 180 degree view of your underwater surroundings. Add CHIRP DownVision™ to your network with a CP100 sonar or an aSeries multifunction display (DownVision™ models only).Features: Network compatible CHIRP SideVision™ sonar for aSeries, cSeries, eSeries and gS Series MFDs Multi-sonar compatible: view CHIRP SideVision™ alongside other sources, simultaneously Image fish, bait and bottom structure at distances up to 600 feet horizontally per side CHIRP signal processing delivers crystal-clear images with amazing detail Works seamlessly alongside Raymarine Digital, CHIRP and CHIRP DownVision™ sonar Adjustable CPT-200 transducer optimizes performance for shallow or deep water scanning CPT-200 CHIRP SideVision™ TransducerFeatures: Transom mount CHIRP SideVision™ sonar array for the CP200 Independently adjustable port and starboard arrays for shallow, mid or deep-water scanning Rugged, stainless carrier with kick-up strike protection IN THE BOXSONAR MODULECPT-200 TRANSOM MOUNT TRANSDUCERDOCUMENTATION PACKMOUNTING SCREWS (4)POWER CABLE 1M Specifications:Watts RMS - Max = NONE Waterproof Rating = Waterproof Service Carrier = NONE Load Equivalence # (LEN) = NONE Frequency = NONE Audio Capable = NONENormalized SKU: E70257UPC Code: 723193787427Raymarine E70257 Literature Download  Owners Manual  Product BrochureRaymarine E70257 Video

Raymarine A80277 TransducersCPT-110Plastic Thru-Hull Transducer for CP100 Sonar ModuleContains two elements, one for the conical beam CHIRP sonar (center frequency 200kHz) the other for the DownVision CHIRP sonar (center frequency 350kHZ)Contains a temperture sensor10M Cable Specifications:Beam Width = NONE Cable Length (Feet) = 10M Fairing Block Included = NONE Frequency = NONE Load Equivalence # (LEN) = NONE Mounting Style = NONE Pins = NONE Speed Included = NONE Temperature = YesNormalized SKU: A80277UPC Code: 723193784655

Raymarine A80305 TransducersCPT-200 Transducer Extensions Cable - 4MFeatures: Transducer Extension Cable Length: 4M Normalized SKU: A80305UPC Code: 723193792803

Raymarine A80281 TransducersCPT-200 Transom Mount CHIRP SideVision™ TransducerFeatures: Transom mount CHIRP SideVision™ sonar array for the CP200 Independently adjustable port and starboard arrays for shallow, mid or deep-water scanning Rugged, stainless carrier with kick-up strike protection Adjustable beam angle conforms to a variety of preferences Integrated kick-up positioning guide ensures consistent returns to desired installation angle Specifications:Beam Width = NONE Cable Length (Feet) = NONE Temperature = NONE Speed Included = NONE Pins = NONE Mounting Style = Transom Load Equivalence # (LEN) = NONE Frequency = NONE Fairing Block Included = NONENormalized SKU: A80281UPC Code: 723193787434
