Raritan
Raritan Vortex Vac Replacement Flush Control #AV600W
$258.49
$328.30
Raritan AV600W Toilet Accessories
The Raritan AV600W is a replacement flush control unit for the Raritan Vortex Vac marine vacuum toilet system. The flush control is the electronic brain of the Vortex Vac, managing the timing and sequencing of the vacuum flush cycle. When this component fails, the toilet either will not flush at all, flushes erratically, or runs continuously, none of which are situations you want to deal with on the water.
The Vortex Vac is a vacuum-assisted marine toilet designed for below-waterline installations and long hose runs where gravity-assist or macerator systems are not practical. The system relies on a controlled vacuum cycle to move waste efficiently through the discharge line, and the flush control unit is what initiates and manages that cycle every time the flush button is pressed. A faulty control unit disrupts the entire sequence.
The AV600W is a direct replacement for the flush control on compatible Vortex Vac installations. Because Raritan has produced the Vortex Vac in multiple configurations over the years, confirming that your specific Vortex Vac model uses the AV600W flush control before ordering is important. Raritan's parts documentation or the model label on your existing unit will confirm compatibility.
Replacing the flush control is a straightforward service procedure for anyone comfortable with basic marine electrical work. The unit connects to the toilet's wiring harness and mounts in the control housing. No specialized tools are required beyond standard hand tools and basic familiarity with 12V marine wiring connections.
At this price point, the AV600W is a targeted repair rather than a full system replacement, which makes it the right call when the rest of the Vortex Vac system is in good working order and only the control unit has failed.
Normalized SKU: AV600W
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Raritan
Raritan Water Heater 20 Gallon 4500w 240v #17201203
$1,486.28
$1,724.08
Raritan 17201203 Water Heaters20-Gallon Hot Water Heater with Heat Exchanger - 4500w/240vThe "1700 Series" water heater provides hot water for galley and shower. Dense foam insulation provides better and longer heat retention than traditional fiberglass. The tank itself is protected by a 75 PSI T& P (temperature and pressure) relief valve. The cylindrical design of the tank enables it to withstand more pressure than a cube shaped tank.Heat exchanger models can be connected to the engine cooling system. This provides the added convenience of hot water when underway or generator power is not available. The innovative heat exchanger is over seven feet in length and is evenly coiled throughout the interior of the tank, providing hot water rapidly and efficiently.Raritan's water heaters use an ignition protected thermostat. Although it is factory set to 120°F, it is adjustable from 110° to 160°F and has a safety shut down limit of 190°F. All models and sizes have the plumbing connections on the same side to simplify installation. Hot and cold water connections are 3/4" male NPT (National Pipe Thread). Heat exchanger connections are 3/4" female NPT.Benefits:
Simple installation - retrofits to most on-board pressure systems
Proven long-life design
Withstands the rigors of the marine environment
Glass-lined steel tank is more durable than stainless steel
Attractive polymer jacket resists corrosion from dampness
Ignition-protected, adjustable thermostat
Round tanks are designed to withstand more pressure than square tanks
Glass-lined steel tank for long life and high efficiency
Environmentally friendly CFC-free foam insulation
Replaceable magnesium anode to protect tank and neutralize acids in the water
The tank is covered by a five-year Limited Warranty
Each unit is assembled by hand, individually tested and backed by Raritan's two-year Limited Warranty and legendary technical support team
Normalized SKU: 17201203
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Raritan
Raritan Water Heater Thermostat Assembly #WH16
$101.56
$126.07
Raritan WH16 Water HeatersWater Head Thermostat AssemblyRaritan's WH16 Water Head Thermostat is located behind the rectangular electrical panel. Raritan manufactures equipment for pleasure boats throughout the world. Products include marine toilets, waste treatment systems, icemakers and water heaters. Committed to the environment and preserving sea life, Raritan designs products to help maintain an environmental balance and ensure the quality of marine waters. RARITAN WATER HEAT THERMOSTAT ASSEMBLYNormalized SKU: WH16UPC Code: 085462011245
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Raritan
Raritan Water Solenoid D60 12v #221353
$74.40
$89.28
Raritan 221353 Toilet AccessoriesRaritan Water Solenoid D60 12v #221353Normalized SKU: 221353
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Raritan
Raritan Water Solenoid Valve 12v #221351
$49.17
$59.00
Raritan 221351 Toilet AccessoriesRaritan Water Solenoid Valve 12v #221351Normalized SKU: 221351
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Raritan
Raritan Water Valve 120v #872111
$85.36
$105.97
Raritan 872111 Appliance Service Parts
The Raritan 872111 is a 120-volt AC water valve used in compatible Raritan marine toilet and sanitation appliance systems. The water valve controls the flow of flush water into the toilet bowl during the flush cycle. When this valve fails, the most common symptoms are a toilet that will not take on water during flushing, a valve that stays open and allows water to run continuously into the bowl, or a valve that leaks around the body or connections.
The 120V AC rating means this valve is designed for vessels with shore power or an onboard AC generator supplying 120-volt alternating current to the sanitation system. It is not compatible with 12V DC toilet systems. If your vessel runs a 12V DC Raritan toilet, a different valve part number applies.
Water valves in marine toilet systems are exposed to a combination of freshwater, saltwater, and the minerals and debris that come with both. Over time the solenoid coil can burn out, the valve seat can wear or accumulate scale buildup, or the body can develop cracks from freeze damage or age. Any of these conditions warrants replacement rather than repair.
The 872111 is a genuine Raritan service part, designed to fit the specific port sizing, electrical connections, and mounting configuration of compatible Raritan appliances. Confirm your Raritan toilet or sanitation unit's model number against Raritan's parts documentation to verify this valve is the correct replacement for your specific installation before ordering.
Replacing a water valve is a manageable service task for anyone comfortable with basic marine plumbing and 120V AC wiring. Turn off shore power or the generator and close the water supply before beginning. The valve connects to the water supply line on the inlet side and the toilet body on the outlet side, with the solenoid wiring connecting to the toilet's control circuit.
Normalized SKU: 872111
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Raritan
Raritan Wear Plate #G2M
$14.04
$16.76
Raritan G2M Service KitsRaritan Wear Plate #G2MNormalized SKU: G2M
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Raritan
Raritan White Press Fresh Water Smart Toilet 12v #230HF012
$1,241.01
$1,489.22
Raritan 230HF012 Toilet AccessoriesRaritan White Press Fresh Water Smart Toilet 12v #230HF012Normalized SKU: 230HF012
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Raritan
Raritan White Remote Intake Pump 12v #230HR012
$1,286.73
$1,492.60
Raritan 230HR012 Toilet AccessoriesRaritan White Remote Intake Pump 12v #230HR012Normalized SKU: 230HR012
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Raritan
Raritan White Vinyl Cap #VCAP
$1.19
$1.40
Raritan VCAP Toilet AccessoriesRaritan White Vinyl Cap #VCAPNormalized SKU: VCAP
