Lumitec 101684 Wiring & AccessoriesLumitec Pico S8 ModuleModel: 101684Provides the ability to assign Poco virtual switch commands to physical mechanical switches (8 max). This means that your MFD can remain on a dedicated screen, or even be turned off, and a physical switch will activate the virtual switch command through the Poco module.The S8 Pico Module can be installed at point of use (upper station, salon, helm) with single wire running back to digital system. Illumination of switches is synchronized with digital control via App or MFD.Pico S8 is compatible with: Momentary switches (pushbutton, toggle, rocker). Latching switches (illumination will require use of one additional channel for each latching switch).Normalized SKU: 101684UPC Code: 089300016843

Download Literature Watch VideoLumitec 101699 Wiring & AccessoriesPoco Digital Lighting Control 3.0Poco Digital Lighting Control is a low-cost, easy-to-install, and set up onboard digital lighting control system that offers full dimming and color control over all your Lumitec PLI-enabled lights at the touch of a button via any compatible MFD or connected smart device. Poco 3.0 adds enhanced wireless security, an external API for compatibility with networked third-party automation systems, and a "Triggers" feature which allows for the triggering of Poco virtual switches by external inputs - all packaged within a responsive user interface for better mobile device usability.Features: PWR: Positive 10-30 VDC POCO supply power. Line must be fused prior to connecting to POCO with 3 Amp ATC blade fuse or equivalent (Constant ON or Switched with ACC Line) GRND: Negative 10-30 VDC POCO supply power ACC: Positive 10-30 VDC, Low current enable line to turn POCO on from remote device (i.e. MFD) (Must be powered to enable Poco) 1-4 IN: Channel Input power. Line must be fused prior to connecting to POCO with 10 Amp ATC blade fuse or equivalent (14 AWG 300V 16 inch long cable) 1-4 OUT: Channel Output power to the lighting circuit. Maximum 10 Amp load per channel. The maximum total load across all channels is limited to 40 Amps. Load on the channel must be only one of the following (Lumitec PLI enabled lighting/lighting capable of dimming (through PWM) / device requiring a standard ON-OFF circuit) (14 AWG 300V 16 inch long cable) LAN: Local Area Network connection. 10/100 Base T data connection to POCO. Standard CAT-5 cable with RJ45 connector required to plug into sealed network cable adapter. (18 inch long cable with Link light) POWER: Indicator - Illuminates Green if POCO is powered on, both PWR and ACC lines must have supply voltage between 10 and 30 VDC CH1-4: Indicator - Illuminates Red if power is supplied to Channel from fuse/breaker panel: - Illuminates Green if power is supplied to Channel input and the channel is turned on inside of POCO controller; PLI enabled lights may be OFF: - Flashes Orange if PLI data is transmitted: - Illuminates Orange if the channel is dimmed through a PWM signal. STATUS: Green blinking light indicates WiFi connection status: - 0 blinks: WiFi disabled - 1 blink: WiFi-enabled but not connected to any peers - 2 blinks: WiFi is connected to one or more peers Blue blinking light indicates Bluetooth-LE connection status: - 0 blinks: Bluetooth-LE is disabled - 1 blink: Bluetooth-LE enabled but not connected - 2 blinks: Bluetooth-LE is connected Normalized SKU: 101699UPC Code: 089300016997Lumitec 101699 Literature Download Quick Reference GuideLumitec 101699 Video

Lumitec 101925 Wiring & AccessoriesPoco™ 4 Digital Light Control ModulePoco Digital Lighting Control delivers powerful, low-cost, on-board lighting control through a compatible MFD or connected smart device in a simple, easy-to-install control module.Poco 4 is the latest iteration of the award-winning Poco system and introduces innovative features such as intelligent sound-to-light, NMEA 2000 compatibility, and CAN bus integration. When installed with Lumitec’s PLIenabled lights, even more functionality is unleashed – precise control over color selection and intensity, custom lighting scene creation with interactive sound-to-light, and the ability to add ‘virtual circuits’ on a single channel, allowing aftermarket installers to add lights and improve on-board lighting designs without adding any additional wire runs.Specifications: Power Line Instruction IP Rated 3-Year Warranty *The Poco Digital Control Module can be controlled through a compatible MFD or connected smart device (not included). Normalized SKU: 101925

  Download LiteratureLumitec 101243 Courtesy LightsRail2 12" Light - 3-Color Red/Blue Non Dimming w/White DimmingLumitec's original rail light amazed customers when it was first introduced in 2008. With up to 3 times greater output than its predecessor and a sleek new look, Rail2 raises the bar. The integrated microprocessor controls dimming and color change from two wires, with no external control modules. As with all Lumitec luminaires, the Rail2 is IP67 compliant, which means despite its great looks it is just at home on a spray-drenched hard top as a teak-adorned salon. Proudly made in the USA. Specifications: Voltage: 10 - 30vDC 12vDC Amps: 920mA 24vDC Amps: 430mA Correlated Color Temperature: 5000 Color Rendering Index: 70+ Lumens(White):490 Rated Watts: 12 Operating Temp (°F): -31 to + 131 F Operating Temp (°C): -35 to +55 C Width: 11.72" (29.76cm) Height: 1.11" (2.82cm) Depth: 0.60" (1.53cm) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 101243UPC Code: 089300012432Lumitec 101243 Literature Download  Quick Reference Guide

Lumitec 101283 Courtesy LightsRail2 12" Light - Spectrum RGBW Full-ColorLumitec's original rail light amazed customers when it was first introduced in 2008. With up to 3 times greater output than its predecessor and a sleek new look, Rail2 raises the bar. The integrated microprocessor controls dimming and color change from two wires, with no external control modules. As with all Lumitec luminaires, the Rail2 is IP67 compliant, which means despite its great looks it is just at home on a spray-drenched hard top as a teak-adorned salon. Proudly made in the USA. Specifications: Voltage: 10 - 30vDC 12vDC Amps: 920mA 24vDC Amps: 430mA Correlated Color Temperature: 5000 Color Rendering Index: 70+ Lumens(White):490 Rated Watts: 12 Operating Temp (°F): -31 to + 131 F Operating Temp (°C): -35 to +55 C Width: 11.72" (29.76cm) Height: 1.11" (2.82cm) Depth: 0.60" (1.53cm) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 101283UPC Code: 089300001283

  Download LiteratureLumitec 101242 Courtesy LightsRail2 12" Light - Warm White DimmingLumitec's original rail light amazed customers when it was first introduced in 2008. With up to 3 times greater output than its predecessor and a sleek new look, Rail2 raises the bar. The integrated microprocessor controls dimming and color change from two wires, with no external control modules. As with all Lumitec luminaires, the Rail2 is IP67 compliant, which means despite its great looks it is just at home on a spray-drenched hard top as a teak-adorned salon. Proudly made in the USA. Specifications: Voltage: 10 - 30vDC 12vDC Amps: 920mA 24vDC Amps: 430mA Correlated Color Temperature: 3000 Color Rendering Index: 80+ Lumens(White):360 Rated Watts: 95 Operating Temp (°F): -31 to + 131 F Operating Temp (°C): -35 to +55 C Width: 11.72" (29.76cm) Height: 1.11" (2.82cm) Depth: 0.60" (1.53cm) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 101242UPC Code: 089300012425Lumitec 101242 Literature Download  Quick Reference Guide

  Download Literature  Watch VideoLumitec 101081 Courtesy LightsRail2 12" Light - White/Blue DimmingLumitec's original rail light amazed customers when it was first introduced in 2008. With up to 3 times greater output than its predecessor and a sleek new look, Rail2 raises the bar. The integrated microprocessor controls dimming and color change from two wires, with no external control modules. As with all Lumitec luminaires, the Rail2 is IP67 compliant, which means despite its great looks it is just at home on a spray-drenched hard top as a teak-adorned salon. Proudly made in the USA.Specifications: Voltage: 10 - 30vDC 12vDC Amps: 920mA 24vDC Amps: 430mA Correlated Color Temperature: 5000 Color Rendering Index: 70+ Rated Watts: 12 Lumens (White): 490 Operating Temp (°F): -31 to + 131 F Operating Temp (°C): -35 to +55 C Width: 11.72" (29.76cm) Height: 1.11" (2.82cm) Depth: 0.60" (1.53cm) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 101081UPC Code: 089300103444Lumitec 101081 Literature Download  Quick Reference Guide  Product BrochureLumitec 101081 Video

  Download Literature  Watch VideoLumitec 101082 Courtesy LightsRail2 12" Light - White/Red DimmingLumitec's original rail light amazed customers when it was first introduced in 2008. With up to 3 times greater output than its predecessor and a sleek new look, Rail2 raises the bar. The integrated microprocessor controls dimming and color change from two wires, with no external control modules. As with all Lumitec luminaires, the Rail2 is IP67 compliant, which means despite its great looks it is just at home on a spray-drenched hard top as a teak-adorned salon. Proudly made in the USA.Specifications: Voltage: 10 - 30vDC 12vDC Amps: 920mA 24vDC Amps: 430mA Correlated Color Temperature: 5000 Color Rendering Index: 70+ Rated Watts: 12 Lumens (White): 490 Operating Temp (°F): -31 to + 131 F Operating Temp (°C): -35 to +55 C Width: 11.72" (29.76cm) Height: 1.11" (2.82cm) Depth: 0.60" (1.53cm) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 101082UPC Code: 089300103451Lumitec 101082 Literature Download  Quick Reference Guide  Product BrochureLumitec 101082 Video

Lumitec 101588 Light BarsLumitec Razor Light Bar Flood Light Black HousingModel: 101588 Die-Cast Aluminum Housing Sleek Low Profile Design Advanced Thermal Management Sleek. Streamlined. Powerful. Introducing Razor - The World’s FIRST flush-mount light bar. Razor was carefully designed to be easily integrated into most existing hardtop, arch, and pilothouse designs — typically with only minor modification to production tooling. When mounted facing forward, Razor’s long-throw and high position are invaluable for spotting markers and obstructions. When positioned downward and aft, Razor floods cockpits, gunIn addition to clean lines and a low profile, following Lumitec’s thermally-vetted reference designs allows OEMs to avoid the overheating and subsequent damage to hardtops that can be caused by enclosing other manufacturer’s light bars in a ‘pod’. Razor is also available in a surface-mount configuration, which mounts directly to un-modified hardtop surfaces and allows for an equally clean look and similar thermal performance. Available with two beam patterns (spot or flood) ensures the light goes where you need it most.wales and surrounding areas with more than 10,000 night-piercing lumens.In addition to clean lines and a low profile, following Lumitec’s thermally-vetted reference designs allows OEMs to avoid the overheating and subsequent damage to hardtops that can be caused by enclosing other manufacturer’s light bars in a ‘pod’. Razor is also available in a surface-mount configuration, which mounts directly to un-modified hardtop surfaces and allows for an equally clean look and similar thermal performance. Two beam patterns ensure the light goes where you need it.Specifications COLOR OUTPUT White, Dimming LUMENS 10,000 VOLTAGE 10-30vDC 12VDC Amps 9A 24VDC Amps 4.2A CCT 5000 CRI 70+ Op. Temp F/C -31/35 to + 131/55 Timed Toggled Protocol (TTP Yes Third Party Dimmer Compatibility (3PD) No Color Match Commitment (CM) Yes Mounting Hole Diameter N/A Height 1.5in (3.81 cm) Width 18in (45.72cm) Depth 3.5in (8.89 cm) Housing Black PLI Enabled Yes What's in the Box: Razor Flood Light Surface mount Normalized SKU: 101588UPC Code: 089300015884

  Download LiteratureLumitec 101586 Light BarsRazor Light Bar - Flood - Flush Mount - WhiteThe World’s FIRST flush-mount light bar. Razor was carefully designed to be easily integrated into most existing hardtop, arch, and pilothouse designs – typically with little or no modification to production tooling.Razor is designed to drop into a contoured pocket molded into a hardtop, radar arch, brow, or other surface. Alternatively, use Razor’s surface mount kit for a sleek, low profile installation on existing flat or slightly crowned tops. Mount forward or aft, horizontal or downward facing. In all installations Lumitec’s careful thermal analysis and self-venting design puts an end to ‘pod’ mounted lightbars, which can overheat and damage surrounding composites in hard tops. Flood and spot/flood beam patterns ensure the light goes where you need it.Advanced Thermal ManagementRazor has been designed and analyzed as a complete system – with careful consideration of the top in which it is mounted. This means that Razor delivers maximum performance while protecting hardtops and pods from dangerously high temperatures.80% Lower Profile Than Most Other Light Bars On The MarketRazor’s integrated design delivers more power with a cleaner, more streamlined look. Up to 80% more streamlined in fact. As the images to the right demonstrate Razor allows builders to eliminate light pods which must be molded and added separately, saving many hours of costly finishing labor. Razor simply drops into an as-molded recess. CAD models of mold plugs or tooling inserts may be provided upon request.Features: 10,000+ TRUE lumens output Surface mountable on top or inverted Dimmable with no additional dimmer switch required Available with two beam patterns (spot or flood) Low profile (1.5") with sleek streamline design Powder-coated die-cast aluminum construction Voltage: 10-30VDC Specifications:Housing = NONE Length (Inches) = NONENormalized SKU: 101586UPC Code: 089300015860Lumitec 101586 Literature Download  Product Brochure

  Download LiteratureLumitec 101587 Light BarsRazor Light Bar - Spot - Flush Mount - WhiteThe World’s FIRST flush-mount light bar. Razor was carefully designed to be easily integrated into most existing hardtop, arch, and pilothouse designs – typically with little or no modification to production tooling.Razor is designed to drop into a contoured pocket molded into a hardtop, radar arch, brow, or other surface. Alternatively, use Razor’s surface mount kit for a sleek, low profile installation on existing flat or slightly crowned tops. Mount forward or aft, horizontal or downward facing. In all installations Lumitec’s careful thermal analysis and self-venting design puts an end to ‘pod’ mounted lightbars, which can overheat and damage surrounding composites in hard tops. Flood and spot/flood beam patterns ensure the light goes where you need it.Advanced Thermal ManagementRazor has been designed and analyzed as a complete system – with careful consideration of the top in which it is mounted. This means that Razor delivers maximum performance while protecting hardtops and pods from dangerously high temperatures.80% Lower Profile Than Most Other Light Bars On The MarketRazor’s integrated design delivers more power with a cleaner, more streamlined look. Up to 80% more streamlined in fact. As the images to the right demonstrate Razor allows builders to eliminate light pods which must be molded and added separately, saving many hours of costly finishing labor. Razor simply drops into an as-molded recess. CAD models of mold plugs or tooling inserts may be provided upon request.Features: 10,000+ TRUE lumens output Surface mountable on top or inverted Dimmable with no additional dimmer switch required Available with two beam patterns (spot or flood) Low profile (1.5") with sleek streamline design Powder-coated die-cast aluminum construction Voltage: 10-30VDC Specifications:Housing = NONE Length (Inches) = NONENormalized SKU: 101587UPC Code: 089300015877Lumitec 101587 Literature Download  Product Brochure

Lumitec 101603 Light BarsRazor Light Bar - Spot - White Housing with Inverted Logo Flush MountFeatures: 10,000+ TRUE lumens output Surface mountable on top or inverted Dimmable with no additional dimmer switch required Available with two beam patterns (spot or flood) Low profile (1.5”) with a sleek streamlined design Powder-coated die-cast aluminum construction Voltage: 10-30VDC Normalized SKU: 101603UPC Code: 089300016034

Lumitec 101589 Light BarsLumitec Razor Light Bar Spot Light, Black HousingModel: 101589 Die-Cast Aluminum Housing Sleek Low Profile Design Advanced Thermal Management Sleek. Streamlined. Powerful. Introducing Razor - The World’s FIRST flush-mount light bar. Razor was carefully designed to be easily integrated into most existing hardtop, arch, and pilothouse designs — typically with only minor modification to production tooling. When mounted facing forward, Razor’s long-throw and high position are invaluable for spotting markers and obstructions. When positioned downward and aft, Razor floods cockpits, gunIn addition to clean lines and a low profile, following Lumitec’s thermally-vetted reference designs allows OEMs to avoid the overheating and subsequent damage to hardtops that can be caused by enclosing other manufacturer’s light bars in a ‘pod’. Razor is also available in a surface-mount configuration, which mounts directly to un-modified hardtop surfaces and allows for an equally clean look and similar thermal performance. Available with two beam patterns (spot or flood) ensures the light goes where you need it most.wales and surrounding areas with more than 10,000 night-piercing lumens.In addition to clean lines and a low profile, following Lumitec’s thermally-vetted reference designs allows OEMs to avoid the overheating and subsequent damage to hardtops that can be caused by enclosing other manufacturer’s light bars in a ‘pod’. Razor is also available in a surface-mount configuration, which mounts directly to un-modified hardtop surfaces and allows for an equally clean look and similar thermal performance. Two beam patterns ensure the light goes where you need it.Specifications COLOR OUTPUT White Dimming LUMENS 10,000 VOLTAGE 10-30vDC 12VDC Amps 9A 24VDC Amps 4.2A Rated Watts 108W CCT 5000 CRI 70+ Op. Temp F/C -31/35 to + 131/55 Timed Toggled Protocol (TTP No Third Party Dimmer Compatibility (3PD) No Color Match Commitment (CM) Yes Mounting Hole Diameter N/A Height 1.5in (3.81 cm) Width 18in (45.72cm) Depth 3.5in (8.89 cm) Diameter N/A Housing Black PLI Enabled Yes What's in the Box: Razor Spot Light Surface Mount Normalized SKU: 101589UPC Code: 089300015891

Lumitec 101627 Courtesy LightsScallop Pathway Light - Spectrum RGBW - Stainless Steel Housing With a sleek, low profile design Lumitec’s Scallop Pathway Light is the world’s first ADA-compliant, PLI-compatible, dock and pathway light. The carefully engineered beam-angle minimizes glare while cleanly illuminating walkway surfaces. Scallop is available in a hand-polished 316 stainless steel or hand-polished bronze finish. Choose from warm white or RGBW full-color output. The Scallop light is PLI and TTP enabled, meaning it can be used with any standard 12v-24v DC power supply; added to a Mantis dock light kit; or designed in to a Kraken dock light system. Completely water sealed and IP67 compliant. Normalized SKU: 101627UPC Code: 089300016270
