Download LiteratureIcom M85 21 VHF Handheld RadiosM85 Compact Handheld VHFMarine's Smallest Waterproof Handheld - The M85 is the smallest, lightest, and toughest radio on the market today!The M85 can withstand hazardous and inhospitable environments at sea and on land, as it is built to MIL-STD 810. The IP67 waterproof rating protects the radio, even if dropped in the water. Yacht and commercial customers like the M85 because of the 100 programmable land mobile channels, as well as the easy-to-use built-in voice scrambler for private communications. The M85 is full of the features you need including an automated emergency alarm.Features: Output Power: Marine: 5/3/1W and Land Mobile: 2/1W Battery Life: 2010mAh Li-ion battery, up to 14 hours Typical operation; Tx:Rx: Stand-by duty ratio = 5:5:90 Waterproof Rating: IP67 Full-FeaturedThe M85 user-friendly display includes icons and indicators like transmit power, VOX ON/OFF, battery status, scan, weather channel, and more. These icons and indicators improve the user experience and operation. The M85 also includes a continuous 20-position rotary selector and an ON/OFF volume knob, which is tilted for easy access.For emergency situations, the M85 includes the MOB Alarm, Man Down, and lone worker functions. If one of these functions is activated, the radio automatically makes an emergency alarm.The M85 built-in voice scrambler provides private communications between stations. The multi-function button on the top of the radio can be assigned to the scrambler function for easy activation. Or use the multi-function button to simply change from marine to land mobile frequencies.Land Mobile UseIn addition to VHF marine channels, the M85 covers 136–174MHz land mobile frequencies. Up to 100 programmable channels are available for land mobile use at 2W output power. Each channel is programmable with CTCSS and DTCS tones. Proper licensing is required to operate within the above land mobile frequencies.Additional Features: AquaQuake™ prevents water-logged speaker Internal VOX capability for hands-free operation Weather channel receiving Self check function checks internal temperature and connected battery voltage Priority scan function Dual/tri-watch function for monitoring CH16 and/or call channel Favorite channel function for quick access to often used channels Built-in voice scrambler (32 codes) Normalized SKU: M8521Icom M85 21 Literature Download Owners Manual Product Brochure

Icom M85 21 USA VHF Handheld RadiosIcom M85 Handheld VHFModel: IC-M85 21 USA Built-in voice scrambler (32 codes) AquaQuake™ prevents water-logged speaker Internal VOX capability for hands-free operation Weather channel receiving Self check function checks internal temperature and connected battery voltage Priority scan function Dual/tri-watch function for monitoring CH16 and/or call channel Favorite channel function for quick access to often used channels The M85 is the smallest, lightest and toughest radio on the market today!The M85 can withstand hazardous and inhospitable environments at sea and on land, as it is built to MIL-STD 810. The IP67 waterproof rating protects the radio, even if dropped in the water. Yacht and commercial customers like the M85 because of the 100 programmable land mobile channels, as well as the easy to use built-in voice scrambler for private communications. The M85 is full of the features you need including an automated emergency alarm.The M85 user-friendly display includes icons and indicators like transmit power, VOX ON/OFF, battery status, scan, weather channel and more. These icons and indictors improve the user-experience and operation. The M85 also includes a continuous 20-position rotary selector and ON/OFF volume knob, which is tilted for easy access.For emergency situations the M85 includes the MOB Alarm, Man Down and lone worker functions. If one of these functions is activated, the radio automatically makes an emergency alarm.The M85’s built-in voice scrambler provides private communications between stations. The multi-function button on the top of the radio can be assigned to the scrambler function for easy activation. Or use the multi-function button to simply change from marine to land mobile frequencies.In addition to VHF marine channels, the M85 covers 136—174MHz land mobile frequencies. Up to 100 programmable channels are available for land mobile use at 2W output power. Each channel is programmable with CTCSS and DTCS tone.Specifications Marine channels USA, INT, CAN, WX channels Land mobile frequency 136.000—174.000 MHz Landmobile channels 100 programmable Channel spacing Marine 25 kHz LMR 25/12.5 kHz Current drain Marine Tx 1.5 A @ 5 watts Marine Rx 0.45 A Land mobile TX 0.9A @ 2 watts Land mobile Rx 0.45 A Output power Marine 5/3/1 W Output power land mobile 2/1 W Dimensions 2.2 3.6 1.1 in (With BP-290), projectiocs nto included What's in the Box: IC-M85 BP-290 battery BC-227 Rapid charger BC-123S AC Adapter FA-SC58V Antenna MBB-3 belit clip Hand strap Normalized SKU: M8521USAUPC Code: 731797040138

Icom FASC59V VHF Handheld RadiosStandard AntennaSoft, flexible replacement antenna f/M92D Specifications:Weather Alert = NONE Waterproof Rating = NONE Speaker Mic = NONE Power - Output (Watts) = NONE IPX Rating = NONE Channels - Other = NONE Channels - Available = NONE Capacity - Battery (mAH) = NONE Battery Type = NONENormalized SKU: FASC59VUPC Code: 731797013170

Icom M94D 21 USA VHF Handheld RadiosIcom M94D 6 Watt hand Held VHF with AIS and DSCModel: M94D 21 USA Simpli ed AIS and Class-H DSC 6 W RF Output Power Class-Leading 1500 mW Audio Output Simpli ed Navigation Function 10 Hours (approx.) of Long Operating Time* Float'n Flash and MOB Auto Set Functions IPX7 submersible (1 m depth of water for 30 minutes) Active noise canceling technology Integrated GPS receiver AquaQuake™ prevents audio degradation from a water-logged speaker Dual watch and Tri-watch functions Weather channel receive ( for USA version) The simplified AIS and DSC functions add further assurance for safety at sea. With the integrated AIS receiver, real-time AIS vessel traffic information are shown on the display. The AIS target call function allows you to easily set up a DSC individual call. Distress calls can be made with the rear panel button.The IC-M94D’s 6 watts of transmit power provides extended communication range for the user. Supplied 2400 mAh (typical) high capacity Li-ion battery, BP-306 provides 10 hours of operating time, under normal conditions* .Icom’s custom high-power capacity speaker delivers a loud 1500 mW (typical) audio output with improved acoustic sound clarity for noisy maritime environments.The Navigation function guides you to a specified waypoint. You can assign a maximum of 50 favorite fishing spots or destinations as waypointsThe radio floats with a flashing LED light to help you retrieve it from the water. Pressing the distress button while Float’n Flash is working will transmit the MOB distress signal, rather than the plain undesignated one for better protection of sailors*Approximate, typical operation with 5:5:90 duty ratio.What's in the Box: M94D BP-306 battery pack BC-251 battery charger AC adapter CP-26 cigarette lighter cable MB-133 belt clip Antenna Hand strap Normalized SKU: M94D21USAUPC Code: 731797039682

Download LiteratureIcom M94D 21 VHF Handheld RadiosM94D VHF Marine Radio with AIS & DSCSimplified AIS and DSC in One PackageThe simplified AIS and DSC functions add further assurance for safety at sea. With the integrated AIS receiver, real-time AIS vessel traffic information is shown on the display. The AIS target call function allows you to easily set up a DSC individual call. Distress calls can be made with the rear panel button.6W RF Output Power and 10 Hours of Operating TimeThe IC-M94D’s 6 watts *1 of transmit power provides an extended communication range for the user. Supplied 2400 mAh (typical) high capacity Li-ion battery, BP-306 provides 10 hours of operating time, under normal conditions *2.*1 5 W for AUS version/*2 Approximate, typical operation with 5:5:90 duty ratio.Class-Leading 1500 mW Audio OutputIcom’s custom high-power capacity speaker delivers a loud 1500 mW (typical) audio output with improved acoustic sound clarity for noisy maritime environments.Simplified Navigation FunctionThe Navigation function guides you to a specified waypoint. You can assign a maximum of 50 favorite fishing spots or destinations as waypoints.Float’n Flash and MOB Auto Set FunctionsThe radio floats with a flashing LED light to help you retrieve it from the water. Pressing the distress button while Float’n Flash is working will transmit the MOB distress signal, rather than the plain undesignated one for better protection of sailors.Features: Class-H DSC VHF marine handheld transceiver with simplified AIS Built-in AIS and DSC combination adds further assurance for safety at sea 6 W output power for reliable long-distance communication Significantly increased audio output power to 1500 mW (crystal clear communications even in any maritime environment) Icom common UI offers intuitive operation Simplified navigation function to a specified waypoint or MOB waypoint 11 hours (approx.) of long battery life with the supplied 2400 mAh (typ.) high capacity Li-ion battery pack Float’ n Flash: The radio floats with a flashing red LED light for easier retrieval from the water IPX7 waterproof construction Integrated GPS Normalized SKU: M94D21Icom M94D 21 Literature Download Product Brochure

Icom MA510TR 13 Auto ID Systems MA-510TR AIS Transponder with Antenna & 4.3" Display This Class B AIS Transponder with GPS navigation function and NMEA 2000™ actively notifies other vessels of your exact position and as a Dual channel receiver, provides AIS information (both Class A and Class B signals) of other AIS-equipped vessels simultaneously.  Large 4.3" color TFT LCD, the backlit screen gives real-time vessel traffic information for navigation and collision avoidance. The compact size means that it can be installed in a convenient place. Key collision-risk management functions simplify AIS operation and a collision alarm with an external alarm connection gives extra warning of potential impacts.  Leisure, fishing, or cruising vessels can stay safe and informed on the open sea with this feature-packed transponder.  Features: Large color display - 4.3" Individual DSC (Digital Select Call) calling with a compatible VHF radio USB connectivity Multi-lingual user interface (English, French, Indonesian, Spanish, and Vietnamese)  Built-in GPS Navigation function guides users to waypoints or AIS targets Silent mode allows the radio to operate securely and privately with the silent mode function.  Switch off the AIS transmitter to temporarily stop sending out position location.  Other AIS signal reports art still received when silent mode is on.  Keep fishing spots private from other vessels by utilizing silent mode. Collision Alarm Function - When vessels come into the CPA or TCPA range, the vessel's icon blinks and a warning sound is emitted on the plotter display (when connected to external audio equipment). Anchor Watch Alarm - an alarm is set off when the vessel is drifting when anchored. Man Overboard - when users receive a Man Overboard (MOB) signal, the MA-510TR can set the MOB as a destination. NMEA Connectivity - The MA-510TR can connect to both NMEA 2000™ and NMEA 0183 End-user programmable with MMSI and ship information. Technical Specifications: AIS Class - Class B  Frequency Coverage - 161.500 to 162.025 MHz Power Supply - 12 to 24 V Dimensions (W x H x D) - 6.5" 4.3" x 3.6" (16.6 x 11 x 9.25 cm) Weight - 1.5 lb (700 g) Output Power - 2 W Data Connection - USB (Type-B Mini), NEMA 2000™ and NMEA 0183 In the Box: MA-510TR AIS Transponder GPS antenna with 32.8' (10 M) cable DC power cable Mounting bracket kit Connectors Instruction manual  *Sold as an Individual Normalized SKU: MA510TR13UPC Code: 731797034793 Icom MA510TR 13 Literature Download Owners Manual Product Brochure

Icom MB75 VHF AccessoriesMB-75 Flush Mount KitFor flush-mounting to a flat surface, such as a control panel.Compatible Devices: M424 M502 M504 M506 M602 M604 M605 M802 MA500TR Normalized SKU: MB75UPC Code: 731797808752

Download LiteratureIcom MBF9 VHF AccessoriesMBF9 Flush Mount Kit for M510 & M510 EVOThis mount is a flush mount kit for Icom's M510 and M510 EVO marine transceivers.Compatible Devices: M510 Marine Transceiver  M510 EVO Transceiver Normalized SKU: MBF9UPC Code: 731797045461Icom MBF9 Literature Download Quick Reference Guide

Icom MBZ1 VHF AccessoriesMBZ1 Screen Cover for M510Icom's MBZ1 screen/sun cover specifically for the M510. Normalized SKU: MBZ1UPC Code: 731797036957

Icom HM-180 VHF Accessories"Icom HM180 Microphone Repalcement For M710Model: HM180Water-resistant, remote function microphone. Same as original supplied microphone.Specifications Microphone impedance 600 Ohm "Normalized SKU: HM180UPC Code: 731797002174

Icom 8930112380 VHF AccessoriesIcom Mounting Gasket for M510 #8930112380Normalized SKU: 8930112380

Download LiteratureIcom MR1010R2 23 Radar SystemsMR1010RII 4kW Marine Radar Color LCDSimplified ARPA (Automatic Radar Plotting Aids) Function*The simplified ARPA function helps to prevent a collision risk with other vessels or objects. Up to five targets can be automatically tracked on the radar echo, when a target enters within the set watch area, (or up to ten targets can be tracked when manually set). By selecting one of the targets, the target information such as position, course, speed, CPA, TCPA, bearing, and distance is shown on the lower side of the display. When the target enters within the CPA and TCPA limits, an alarm message is displayed with a beep alarm.* External bearing, speed, and position data required.DSC (Digital Selective Calling) Information Function*When connected to a DSC radio and a DSC call is received, the received message is transferred to the MR-1010RII. Up to 20 DSC messages can be plotted on the radar echo. If a MOB position information is transmitted from a DSC handheld transceiver (including Icom IC-M94D), the MR-1010RII can show the MOB waypoint on the radar echo to assist in search and rescue operation.* External bearing, position, and DSC data required.AIS (Automatic Identification System) Overlay Function*When connected to an external AIS device (including Icom IC-M605, IC-M510 AIS, and, IC-M506 AIS), up to 100 AIS target icons are overlaid on the radar echo. By selecting an AIS icon, vessel information such as AIS class, MMSI number, vessel name, course, speed, CPA, TCPA, bearing, and distance are shown on the lower side of the display.* External bearing, position, and DSC data required.Wide Viewing Angle Color TFT LCDThe wide viewing angle color TFT LCD offers bright, vivid echoes with 16-step gradient intensity. The screen intensity and screen color (day, night, and user settings) can be instantly adjusted with the "BRILL" button. In addition, the auto-hide information function enlarges radar echoes to full size.Multi-Lingual Intuitive User InterfaceThe language setting of the MR-1010RII is selectable from multiple languages.* The large eight-direction cursor key provides smooth operation even when wearing gloves. Various settings can be configured through the visually intuitive operation.* EXP version: English, Indonesian, Korean, Portuguese, Spanish, Thai, and Vietnamese/EUR version: Arabic, English, French, Italian, Portuguese, Spanish, and TurkishOptional Video Output UnitWith an optional video output unit, UX-252*, the MR-1010RII can be connected to an external display. The same radar echoes can be observed on the main unit and external display at the same time. *Except for the EUR version.TLL (Target Latitude Longitude) Function*The MR-1010RII can mark points with icons and transfer the position data with NMEA TLL sentences to other NMEA 0183 devices such as an external plotter.* External bearing and position data required.True Trail Function*The true trail function cancels its ship movement and shows true moving objects with trails, while static objects are not trailed.* External bearing and position data required.Features: 10.2–42 V wide DC input to prevent over-voltage damage Two-user programmable alarm zones Waypoint indication* Designed, engineered, and Made in Japan *External bearing, position, and waypoint data required.Specifications: Display Type: 10.4-inch Color TFT LCD Resolution: 480 × 640 dots Minimum range: 25 m; 82 ft (at 1⁄8 NM range) Maximum range: 36 NM Range scales     NM: 1⁄8, 1⁄4, 1⁄2, 3⁄4, 1, 1.5, 2, 3, 4, & 6, 8, 12, 16, 24, 32, 36 km: 1⁄4, 1⁄2, 3⁄4, 1, 1.5, 2, 3, 4, & 6, 8, 12, 16, 24, 32, 36, 48 Preheat time: 90 seconds Power supply: 0.2–42 V DC Power consumption (at zero wind velocity): 55 W (approximately) Usable temperature range: −15°C to +55°C; +5°F to +131°F Input data format: NMEA 0183, N+1, AUX, IEC61162-2 Output data format: NMEA 0183 Normalized SKU: MR1010R223UPC Code: 731797043887Icom MR1010R2 23 Literature Download Quick Reference Guide
