Simrad 000-15749-001 AutopilotsNAC-2 Core Pack with SteadySteer - Includes NAC-2, Precision-9, RF25N, SteadySteer Flow Switch & N2k Starter KitComprising of the medium-current NAC-2 autopilot computer, Precision-9 compass and RF-25 rudder feedback unit ideal for smaller vessels, designed to run small hydraulic drives and mechanical drives for vessels up to 10M (33') in length.The NAC-2 Autopilot Computer is the brains behind your autopilot system. NAC-2 contains the control algorithms developed to helm a yacht across a broad range of weather conditions and sea-states, alongside the electronics needed to operate a hydraulic or mechanical drive unit, while also interfacing with other components including heading sensors and rudder feedback units. The NAC-2 was designed for boats up to 10M (33') in length and is suitable for low-current hydraulic drives, mechanical drives, or solenoid valves with a current rating of 8 Amps continuous (12 Amps peak).SteadySteer Flow SwitchNavigate safely with SteadySteer, a new functionality for autopilot systems that allows boaters to take immediate, manual control of the vessel through turns without having to disengage the autopilot. Coming out of turns, SteadySteer automatically reengages the autopilot once a new heading is established.Control the autopilot with the helmSteadySteer automatically disengages the autopilot when you turn the vessel manually and then reengages the autopilot when you have established a new heading.  No key-presses, no alarms – just turn the helm.Less distractions – Just driveNo need to look at a display or push buttons to change course, merely point the bow to your destination.Full compatibilitySteadySteer is compatible with NAC-2, NAC-3 autopilot computers (sw version 1.1.01.00 and newer), AP44, IS42, and AP48 (sw version 57.3.163 and newer) and Simrad multifunction displays (sw version 20.2 and newer).Suitable for vessels with hydraulic steering, SteadySteer will be available to purchase alongside existing Simrad autopilot systems.Precision-9 CompassThe Precision-9 Compass. Outputs Heading (20 hZ), Rate Of Turn (20 hZ), roll, and pitch (10 hZ) over the NMEA 2000® network.RF25N NMEA2000RF25N, Rudder Feedback Unit: With transmission link and 5M (16.5') NMEA2000 Micro-C cableN2k Backbone Starter KitNMEA 2000 Micro-C Network starter kit: Includes Network power cable, 4.5M (15') N2K cable, 3 x T-connectors, 2 x network terminatorsSpecifications: Operating temperature: -25°C to +55°C (13°F to 131°F) Protection: Splashproof, IPx5 Weight: 0.6 kg (1.3 lbs) Overall Dimensions: Width: 7.1" \ 180mm / Height: 2.2" \ 57mm Power supply: 9-31.2 V DC Load: 140 mA + drive unit load Performance: Drive: 8 A cont., 16A for 1s Network: 1xMicroC (NMEA2000) Feedback: Variable voltage/resistive 0-5V Drive output: To PUMP-1 or HELM-1 Power supply: 9-31.2 V DC Solenoid: 12/24V DC, common, load range 10mA to 10A, off current <1mA Clutch: 12/24V DC, min 10mA, max 3A Normalized SKU: 00015749001

Simrad 000-15751-001 AutopilotsNAC-2 VRF Core Pack with SteadySteer - Includes NAC-2, Precision-9, SteadySteer Flow Switch & N2k Starter KitComprising of the medium-current NAC-2 autopilot computer, Precision-9 compass unit ideal for smaller vessels, designed to run small hydraulic drives and mechanical drives for vessels up to 10M (33') in length.The NAC-2 Autopilot Computer is the brains behind your autopilot system. NAC-2 contains the control algorithms developed to helm a yacht across a broad range of weather conditions and sea-states, alongside the electronics needed to operate a hydraulic or mechanical drive unit, while also interfacing with other components including heading sensors and rudder feedback units. The NAC-2 was designed for boats up to 10M (33') in length and is suitable for low-current hydraulic drives, mechanical drives, or solenoid valves with a current rating of 8 Amps continuous (12 Amps peak).SteadySteer Flow SwitchNavigate safely with SteadySteer, a new functionality for autopilot systems that allows boaters to take immediate, manual control of the vessel through turns without having to disengage the autopilot. Coming out of turns, SteadySteer automatically reengages the autopilot once a new heading is established.Control the autopilot with the helmSteadySteer automatically disengages the autopilot when you turn the vessel manually and then reengages the autopilot when you have established a new heading.  No key-presses, no alarms – just turn the helm.Less distractions – Just driveNo need to look at a display or push buttons to change course, merely point the bow to your destination.Full compatibilitySteadySteer is compatible with NAC-2, NAC-3 autopilot computers (sw version 1.1.01.00 and newer), AP44, IS42, and AP48 (sw version 57.3.163 and newer) and Simrad multifunction displays (sw version 20.2 and newer).Suitable for vessels with hydraulic steering, SteadySteer will be available to purchase alongside existing Simrad autopilot systems.Precision-9 CompassThe Precision-9 Compass. Outputs Heading (20 hZ), Rate Of Turn (20 hZ), roll, and pitch (10 hZ) over the NMEA 2000® network.N2k Backbone Starter KitNMEA 2000 Micro-C Network starter kit: Includes Network power cable, 4.5M (15') N2K cable, 3 x T-connectors, 2 x network terminatorsSpecifications: Operating temperature: -25°C to +55°C (13°F to 131°F) Protection: Splashproof, IPx5 Weight: 0.6 kg (1.3 lbs) Overall Dimensions: Width: 7.1" \ 180mm / Height: 2.2" \ 57mm Power supply: 9-31.2 V DC Load: 140 mA + drive unit load Performance: Drive: 8 A cont., 16A for 1s Network: 1xMicroC (NMEA2000) Feedback: Variable voltage/resistive 0-5V Drive output: To PUMP-1 or HELM-1 Power supply: 9-31.2 V DC Solenoid: 12/24V DC, common, load range 10mA to 10A, off current <1mA Clutch: 12/24V DC, min 10mA, max 3A Normalized SKU: 00015751001

Simrad 000-15750-001 AutopilotsNAC-3 Autopilot Core Pack with SteadySteer - Includes SteadySteer Flow Switch, NAC-3, Precision-9, RF25N & N2k Starter KitComprising of the high-current NAC-3 autopilot computer, Precision-9 compass, RF-25 rudder feedback unit & N2k Starter Kit.The NAC-3 Autopilot Computer is the brains behind your autopilot system. NAC-3 contains the control algorithms developed to helm a yacht across a broad range of weather conditions and sea-states, alongside the electronics needed to operate a hydraulic or mechanical drive unit, while also interfacing with other components including heading sensors and rudder feedback units. The NAC-3 was designed for boats 10M (33') or greater in length and is rated to operate high-current hydraulic drives, mechanical drive units, and solenoid valves with a current rating of 30 Amps continuous (50 Amps peak).SteadySteer Flow SwitchNavigate safely with SteadySteer, a new functionality for autopilot systems that allows boaters to take immediate, manual control of the vessel through turns without having to disengage the autopilot. Coming out of turns, SteadySteer automatically reengages the autopilot once a new heading is established.Control the autopilot with the helmSteadySteer automatically disengages the autopilot when you turn the vessel manually and then reengages the autopilot when you have established a new heading.  No key-presses, no alarms – just turn the helm.Less distractions – Just driveNo need to look at a display or push buttons to change course, merely point the bow to your destination.Full compatibilitySteadySteer is compatible with NAC-2, NAC-3 autopilot computers (sw version 1.1.01.00 and newer), AP44, IS42, and AP48 (sw version 57.3.163 and newer) and Simrad multifunction displays (sw version 20.2 and newer).Suitable for vessels with hydraulic steering, SteadySteer will be available to purchase alongside existing Simrad autopilot systems.Precision-9 CompassThe Precision-9 Compass. Outputs Heading (20 hZ), Rate Of Turn (20 hZ), roll, and pitch (10 hZ) over the NMEA 2000® network.RF25N NMEA2000RF25N, Rudder Feedback Unit: With transmission link and 5M (16.5') NMEA2000 Micro-C cableN2k Backbone Starter KitNMEA 2000 Micro-C Network starter kit: Includes Network power cable, 4.5M (15') N2K cable, 3 x T-connectors, 2 x network terminatorsSpecifications: Temperature, operation: 0 to +55°C Temperature, storage: -32 to +70°C Protection: IPx7 Weight in Kg: 0.7kg, 1.6lbs Dimmension Max size, mm (length x width x height): 211 x 196 x 65.5mm, 8.31" x 7,72" x 2.58" Mounting: Bulkhead Construction: Plastic Color: Black Cable inlet: Grommet (Spare Incl) Local Power supply: 12/24 V DC +10-30% NMEA 2000 Load Equivalent number (50mA): 1 Reversible motor control of rudder: Max continious load 30A, peak 50A for 1s On/off solenoid control of rudder: 12/24V DC, common, load range 10mA to 10A, off current <1mA Engage output for bypass/clutch: 12/24V DC, min 10mA, max 3A Rudder angle, frequency input: 15V, 1.4 to 5kHz, resol. 20Hz/x OR NMEA2000 NFU port/stbd input and mode indicator output: External open/close contact, common ret, contact current max 30mA Mode input: External open/close or pulse contact for SYSTEM SELECT, common ret, close to activate, contact current max 30mA External alarm output for buzzer/relay: Max 100mA, voltage level as local supply IEC 61162-1 input (NMEA0183 In): 1 ch IEC 61162-1 output (NMEA0183 Out): 1 ch IEC 61162-1 speed: 4.8 & 38.4 kbaud NMEA2000: Certified (pending) Normalized SKU: 00015750001

Simrad 000-15752-001 AutopilotsNAC-3 VRF Autopilot Core Pack with SteadySteer - Includes SteadySteer Flow Switch, NAC-3, Precision-9 & N2k Starter KitComprising of the high-current NAC-3 autopilot computer, Precision-9 compass, RF-25 rudder feedback unit & N2k Starter Kit.The NAC-3 Autopilot Computer is the brains behind your autopilot system. NAC-3 contains the control algorithms developed to helm a yacht across a broad range of weather conditions and sea-states, alongside the electronics needed to operate a hydraulic or mechanical drive unit, while also interfacing with other components including heading sensors and rudder feedback units. The NAC-3 was designed for boats 10M (33') or greater in length and is rated to operate high-current hydraulic drives, mechanical drive units, and solenoid valves with a current rating of 30 Amps continuous (50 Amps peak).SteadySteer Flow SwitchNavigate safely with SteadySteer, a new functionality for autopilot systems that allows boaters to take immediate, manual control of the vessel through turns without having to disengage the autopilot. Coming out of turns, SteadySteer automatically reengages the autopilot once a new heading is established.Control the autopilot with the helmSteadySteer automatically disengages the autopilot when you turn the vessel manually and then reengages the autopilot when you have established a new heading.  No key-presses, no alarms – just turn the helm.Less distractions – Just driveNo need to look at a display or push buttons to change course, merely point the bow to your destination.Full compatibilitySteadySteer is compatible with NAC-2, NAC-3 autopilot computers (sw version 1.1.01.00 and newer), AP44, IS42, and AP48 (sw version 57.3.163 and newer) and Simrad multifunction displays (sw version 20.2 and newer).Suitable for vessels with hydraulic steering, SteadySteer will be available to purchase alongside existing Simrad autopilot systems.Precision-9 CompassThe Precision-9 Compass. Outputs Heading (20 hZ), Rate Of Turn (20 hZ), roll, and pitch (10 hZ) over the NMEA 2000® network.N2k Backbone Starter KitNMEA 2000 Micro-C Network starter kit: Includes Network power cable, 4.5M (15') N2K cable, 3 x T-connectors, 2 x network terminatorsSpecifications: Temperature, operation: 0 to +55°C Temperature, storage: -32 to +70°C Protection: IPx7 Weight in Kg: 0.7kg, 1.6lbs Dimmension Max size, mm (length x width x height): 211 x 196 x 65.5mm, 8.31" x 7,72" x 2.58" Mounting: Bulkhead Construction: Plastic Color: Black Cable inlet: Grommet (Spare Incl) Local Power supply: 12/24 V DC +10-30% NMEA 2000 Load Equivalent number (50mA): 1 Reversible motor control of rudder: Max continious load 30A, peak 50A for 1s On/off solenoid control of rudder: 12/24V DC, common, load range 10mA to 10A, off current <1mA Engage output for bypass/clutch: 12/24V DC, min 10mA, max 3A Rudder angle, frequency input: 15V, 1.4 to 5kHz, resol. 20Hz/x OR NMEA2000 NFU port/stbd input and mode indicator output: External open/close contact, common ret, contact current max 30mA Mode input: External open/close or pulse contact for SYSTEM SELECT, common ret, close to activate, contact current max 30mA External alarm output for buzzer/relay: Max 100mA, voltage level as local supply IEC 61162-1 input (NMEA0183 In): 1 ch IEC 61162-1 output (NMEA0183 Out): 1 ch IEC 61162-1 speed: 4.8 & 38.4 kbaud NMEA2000: Certified (pending) Normalized SKU: 00015752001

Simrad 000-15621-001 AutopilotsSimrad NAC-D Autopilot ComputerModel: 000-15621-001 SeaStar Solutions®, Volvo®, Yanmar® and Yamaha® approved control system interface Control via AP™ 44, AP 48 or easily integrate with your Simrad® multifunction display No need for an additional hydraulic pump, rudder sensor, or dockside calibration SteadySteer™ feature included Steer to a waypoint, heading or set turn pattern, such as a U turn, Spiral turn and many more — the NAC™ -D can even initiate a zigzag turn CAN-bus data connectivity - connection to Optimus® steering systems via the CAN-bus data network Full system integration with Simrad® navigation systems via NSS™ and NSO™ multifunction display ranges NAC™ -D is a steer-by-wire autopilot solution for Electronic Vessel Control Systems (steering systems with a digital interface).With NAC -D, boaters with SeaStar® Optimus®, Yanmar® VC10/JC10, Volvo® IPS/EVC or Yamaha® helm master/single engine control systems can benefit from all the full features and performance of Simrad® autopilots.Requires only the connection of two Micro-C connectors — there is no requirement for an additional hydraulic pump, rudder sensor installation or dockside rudder calibration. This saves boaters’ time and money.Featuring Continuum® steering and support for the new SteadySteer™, the NAC -D allows automatic switching between two speed profiles delivering optimal steering performance at both low and high speeds. Choose the controller to suit your preference from dedicated controllers like the AP™ 44 or AP 48, or simply integrate with your Simrad® multifunction display.Simrad® autopilot systems incorporate state-of-the-art electronics and represent over 70 years of experience and development. Simrad® autopilots can reduce your workload and fatigue and improve your situational awareness and safety, helping you arrive fresher at your destination.Specifications Autopilot Compass sensor support NMEA 2000 Drive output EVC Engine Drive systems integration Volvo EVC, Yamaha, Yanmar, Optimus Manouevres / Turn Patterns C-turn, U-turn, Zigzag turn, Square turn, S-turn, Depth counter tracking (DCT) Connectivity NMEA 2000 2 x NME2000 Micro-C port, 2 LEN Electrical Power Consumption, max. 40mA Power Consumption, typical 40mA Supply Voltage 9-16V via CAN Environment Operating Temperature Range 0C to +55C (+32F to +131F) Storage Temperature Range -30C to +70C (-22F to +131F) Waterproof rating IP44 Compass Safe Distance - Metric, imperial 0,5m (19,7") Physical Dimensions (W x H x D) 86,5 x 20,0 x 11,5mm (3,4 x 0,8 x 0,45") Mounting Type Inline with cable What's in the Box: NAC-D Micro-C T-Connector Normalized SKU: 00015621001UPC Code: 9420064115747

Simrad 000-10185-001 AutopilotsNF80 Non Follow Up RemoteThe NF80 works with your Simrad autopilot system, adding a dedicated lever for heading adjustments, course changes, or hand steering. Non Follow Up control means the rudder turns while the lever is held to port or starboard, and remains at its current angle when the lever is released.Dedicated Autopilot ControlOur steering remotes offer intuitive controls and a 1.7-inch display that can be used to make course, heading rudder angle, or autopilot mode changes from anywhere onboard. Adding a remote to your system can provide dedicated steering controls for your fully integrated autopilot system, complementing the touchscreen controls on your multifunction display. Remotes can also enable autopilot control from multiple stations: perfect for fly-bridges and other dual-helm setups.Direct Rudder Control with Non Follow Up SteeringYour Simrad autopilot not only keeps you on the course but lets you hand-steer from any autopilot station on board. The NF80 offers Non Follow Up steering, which puts you in direct control of your boat’s rudder. Move the spring-loaded steering lever to port or starboard, and the rudder will begin to turn in the same direction. The rudder will continue to turn until the lever is released, then hold its current angle until a new angle is set.Easy InstallationThis wired remote can be mounted almost anywhere. A simple design allows flush-mount installation using the included accessories, or external mounting to a desktop or bulkhead via an optional mounting kit. The remote connects to your Simrad autopilot system via a single NMEA 2000® cable into your existing network, offering plug-and-play installation with no complex wiring required.Features: Non Follow Up steering (rudder turns while the lever is held to port or starboard) Rudder stops at its current position when the lever is released Integrated 1.7-inch display enables remote autopilot control Easy desktop/bulkhead or flush-mount installation Simple plug-and-play NMEA 2000® connectivity Specifications: Compass Safe: 0,4m (15,75") Weight: 0,5kg (1,1lbs) Power Consumption Max: 110mA Viewing Angles: 12 o'clock Supply Voltage: 12-16V via CAN Display Resolution: 128 x 64 NMEA 2000 Connectivity: 1x CAN Micro-C port, 1 LEN Warranty Period: 2 years Operating Temperature Range: -25C to +55C (-13F to +131F) Storage Temperature Range: -30C to +70C (-22F to +158F) Dimensions W x H x D: 80 x 144 x 40mm (3,15 x 5,67 x 1,55") Languages: English Mounting Type: Flush, Bulkhead Waterproof Rating: IPx6 Interface: Keypad and lever Steering Modes: Non Follow Up (NFU), Auto, NoDrift, Nav Backlight Color: White Normalized SKU: 00010185001UPC Code: 9420024108147

Simrad 000-15940-001 Network AccessoriesSimrad NMEA2000 Remote MOB ButtonModel: 000-15940-001 Easy to install with plug ‘n play installation Compatible with NMEA2000® (MOB) Notification standard - PGN 127233 Compatible with Lowrance®, Simard® and B&G® MFD’s & instrument displays Automatically creates a MOB waypoint and provides navigation data to the MOB position Dedicated graphical MOB pages on Triton™ 2, H5000 Graphic & Nemesis® displays When combined with an H5000 CPU, the CPU will calculate a dead reckoned position of the MOB Conforms with World Sailing Offshore Safety Requirements [4.22.2] This simple to install remote button allows for convenient placement for an emergency Man-Over-Board (MOB) button, which will trigger alerts across a NMEA2000® system and devices. Pressing the button will automatically create a MOB waypoint and provide navigation data to reach the MOB position.The button is compatible with Lowrance HDS® Live, EliteFS® and HDS® Carbon Chartplotters/Fishfinders. Simrad® NSO™, NSSevo3™ and NSSevo3S™, GO™ and NSX™ Chartplotters and Multifunction Displays, B&G Zeus® 3 and 3S, Vulcan™ chartplotters, and Triton™ 2, H5000 and Nemesis® instrument displays, which also feature a dedicated graphical MOB page. When combined with a B&G H5000 Sailing Processor, the Processor will calculate a dead reckoned position of the MOB position. This safety accessory also conforms with the World Sailing Offshore Safety requirements.Specifications Operating temperature -15°C to +55°C (5°F to 131°F) Waterproof rating IP67 Power supply voltage 12 V DC Operating voltage 9 V DC - 18 V DC Power consumption 1 LEN, 0.39 W (28 mA at 13.8 V) Reverse polarity protection Yes NMEA 2000 PGN TX 127233 What's in the Box: MOB Button N2K-T-RD - Micro-C T-connector Normalized SKU: 00015940001UPC Code: 9420064127665

Simrad 000-16559-001 FishfindersNSO 4 16" MFD with C-MAP Discover X North America ChartRedesigned from the ground up, responsive & intuitive control, unmatched situational awareness, and wide-ranging compatibility are the cornerstones of NSO 4, making it the only choice for serious offshore adventures.Features: 3 Sizes available: 16” / 22” / 24” Powerful 8 Core processor delivering fast boot, instantaneous chart redraw, and fast page transitions Full-HD, Sunlight Viewable display Edge-glass aesthetic, optimized for premium teak isle Rear-mount for a clean, flush, trouble-free fit Rugged waterproof design for the harshest marine environment New branding, out of sight lines for a cleaner, more sophisticated look More Ethernet Ports, making integration a breeze Wide-ranging compatibility now with Plug-and-Play CZONE App High-definition Video In & Out with built-in Audio Splitter, so you can keep an eye on the game or the kids entertained Updated Aesthetics Edge-to-edge glass and rounded corners deliver a modern, refined look. Subtle branding and a power button keep the display clean and uninterrupted. Designed to integrate flawlessly with high-end vessels, enhancing helm style and fit. Screen calibration provides more consistent white point across sizes and batches. Built for the Elements Durable waterproof design with active cooling for improved performance in high ambient temperatures. Sunlight viewable SolarMax HD Display suitable for use with Polarized Sunglasses. Individual galvanically isolated connectors provide ground loop mitigation. Vibration and shock tested to simulate the harshest marine conditions. Simplified Installation Rear-mount system simplifies installation with assembly or tools required - simply cut, fit, twist, and turn. Designed to reduce stress points and improve serviceability for teak isle installations. Twist-fit, lockable connectors ensure a watertight connection. Up to 20% lighter than competitor models. Unmatched Simplicity, Finally ScaledNow in the format that larger boats have been waiting for, NSO 4 delivers the most intuitive and modern OS on the market today.Enjoy a familiar experience with intuitive touch and swipe controls that put you instantly at ease, so you can feel confident and ready for your next adventure.Symbolic of the leap into the future, the modern UI is refined yet powerful – a focus on usability ensures that the most common features and functions are at your fingertipsSpeed isn’t just a number; it’s a feeling, and from the moment you power the unit, you know the difference – ultra-fast boot, instantaneous chart redraw, and seamless page transitions elevate your on-water experience.NSO 4 is the control center of your smart vessel, connecting and controlling everything from engines and radar to lighting, AV, and entertainment. Take full control with a system built for total vessel integration.Wide Range CompatibilityWhether you are fishing, cruising, or anything in between, Simrad® makes it easy to build the boat of your dreams by being designed to support large multi-helm systems with up to 10 NEON™ Displays.Plug-and-play connectivity with a variety of 3rd party products, including RGB Lighting, Audio control, HTML5 integration, and more.Control at your FingertipsFlexible integration tools for OEM customization, including branded interfaces and custom graphics.Capable of delivering different levels of integration to suit your customer needs, from digital switching with CZONE® to rich custom graphics through an OP Box.External controller support with the updated OP 55 Remote Control for greater flexibility and a custom key to suit your style.Your AV CenterProviding total awareness, NSO 4 features 4-way IP video support, high-definition video in with limited sharing across Ethernet, and out to keep you connected and aware.Never miss a moment by connecting a streaming device to view live sports or keep the kids entertained with their favorite TV show or movie. The optional audio out cable allows you to connect to your vessel's audio system with easeIn the Box: Simrad NSO 4 MFD Magnetic sun cover Rear mount kit and dash gasket Power cable Documentation pack C-MAP Discover X Card Normalized SKU: 00016559001UPC Code: 9420064140978
