Download LiteratureRaritan 220AHR012 ToiletsMarine Elegance - Household Style - Bone - Remote Intake - Smart Controller - 12VMatching Seat & Lid IncludedHousehold StyleProgrammable Smart Switch ControlBoneRemote Saltwater Intake12vRaritan's new Vortex Vac Flush Technology eliminates the need for vacuum pumps and tanks as well as foot pedals and other mechanical components that can fail. This results in a system that is easier to install with significant cost savings.The vacuum is created directly in the bowl eliminating "old style" below deck componentsThis unmatched flushing action is the quietest and most efficient in its class yet uses only a small amount of water extending the useful capacity of most holding tanks.All discharge components are located within the bowl reducing installation time and costsA solenoid valve is conveniently located within the bowl to provide for use with onboard pressurized water along with a vaccuum break for added security of your fresh water supplyFeatures: Low water consumption DB level less than 63 with newly designed Pancake motor coated with an epoxy paint to withstand the vigors of the harsh marine environment. Built-in discharge loop contained within the bowl Small footprint One piece vitreous china bowl with concealed mounting Built in "shredder" Specifications:Amps - Draw = NONE Volts = 12v Operation = NONE Outlet Size = NONE Gallons Per Hour = NONE Inlet Size = NONE Gallons Per Minute = NONE Rinse Water = RAW Quick Flush = NONE Back Design = NONE Suction Lift (ft.) = NONERARITAN MARINE ELEGANCE 12VDC HH BOWL REMOTE INTAKE BONENormalized SKU: 220AHR012UPC Code: 085462024627Raritan 220AHR012 Literature Download  Quick Reference Guide  Owners Manual

Raritan 221357 Fittings Marine Elegance Hose Adapter Straight for Solenoid Normalized SKU: 221357

Raritan 221024 Toilet AccessoriesMarine Elegance Pancake Motor Replacement - 24VMarine Elegance Motor Pancake E-Coated 24 Volt replacement. Normalized SKU: 221024UPC Code: 085462034220

Raritan 230AHF012 ToiletsMarine Elegance Tall Angle Back Almond HH Style Fresh Water 12V with Smart Toilet Control Household Style Programmable Smart Switch Control Almond Freshwater 12V Raritan's Vortex Vac Flush Technology eliminates the need for vacuum pumps and tanks as well as foot pedals and other mechanical components that can fail. This results in a system that is easier to install with significant cost savings.The vacuum is created directly in the bowl eliminating "old style" below deck components.This unmatched flushing action is the quietest and most efficient in its class yet uses only a small amount of water extending the useful capacity of most holding tanks.All discharge components are located within the bowl reducing installation time and costs.A solenoid valve is conveniently located within the bowl to provide for use with onboard pressurized water along with a vaccuum break for added security of your fresh water supply.The Marine Elegance Toilet Features: Quiet operation Unmatched rinsing capabilities Low Water consumption Built in shredder reduces clogs Can pump 10' vertically, or 100' horizontally The Raritan Smart Flush Control is a fully programmable flush control. The control allows users to flush the toilet with no water, a small amount of water or a fully timed flush. the timed flush feature can be adjusted on the panel without having to remove any components.The Raritan Smart Flush Control Offers: Fully programmable, easy to use control Attractive wall mount design Flush using no water, little water, or timed flush Optional lock out feature when tank is full Specifications:Amps - Draw = NONE Back Design = NONE Gallons Per Hour = NONE Gallons Per Minute = NONE Inlet Size = NONE Operation = NONE Outlet Size = NONE Quick Flush = NONE Rinse Water = Fresh Suction Lift (ft.) = NONE Volts = 12VNormalized SKU: 230AHF012UPC Code: 085462025488

Raritan 221HF01201 Toilets Marine Elegance 12 volt toilet with straight-back bowl designed for use with onboard pressurized fresh water, featuring a multifunction momentary flush control. Raritan Marine Elegance Toilet with Vortex-Vac Flush technology adds a clean and sophisticated look to any marine bathroom  Multifunction Momentary Flush Control Included (221551) Rinse Water Source: Onboard Pressurized Fresh Water Bowl Size: Household Bowl with Compact Footprint Bowl Height: 14 in. Standard height (12 in. high from floor to bottom of seat) see attachments for additional detail Bowl Back: Straight Bowl Color: White Overall Bowl Dimensions: 14 in. H x 14 in. W x 18.375 in. D< >- See attached for more details Compact Footprint Dimensions< >- 12.25 in. deep from front base to base of straight back< >- 8.5 in. Wide< >- see attached for more details Voltage: 12 Volt DC Operation Amp Draw: 18 amps Circuit Breaker/Fuse size: 30 amp Inlet Hose: 1/2 in. Inside Diameter Discharge: 1 in. or 1-1/2 in. Inside Diameter (Sani/Flex Odor Shield Hose Recommended) Vortex-Vac Flush Technology< >- Raritan's vortex pump creates an on-demand instantaneous vacuum and eliminates the need for external vacuum pumps, tanks, foot pedals and other mechanical components that can fail resulting in a system that is easier to install and maintain with a significant cost savings< >- Raritan's Vortex-Vac flushing technology is also the quietest and most efficient in its class. Its low water usage also extends the useful capacity of your holding tank Slow Close Seat and Lid Designed for Marine Use (1245SC)< >- Seat Construction includes unique locking tabs which hold the seat in place while boat is rocking. Multifunction Momentary Control provides momentary operation and independent momentary control of water and discharge:< >- Water Only option brings inlet water to the bowl when pressed< >- Empty Only option evacuates the bowl < >- Both buttons may be pressed simultaneously for momentary operation of inlet water and evacuation Multifunction Momentary Wall Mount Panel measures 3 in. High X 1.5 in. Wide and includes a 7' wiring harness Quiet operation Unmatched rinsing capabilities Built in macerator shredder reduces clogs 10 ft. pump head One piece vitreous china bowl for easy cleaning Unique 3-Point Mounting System makes the installation simple and eliminates unnecessary nooks and crannies which makes cleaning simple and easy Normalized SKU: 221HF01201

Raritan 221HF01202 Toilets Marine Elegance 12 volt toilet with straight-back bowl designed for use with onboard pressurized fresh water, featuring a momentary push button flush control. Raritan Marine Elegance Toilet with Vortex-Vac Flush technology adds a clean and sophisticated look to any marine bathroom  Heavy Duty Momentary Push Button Flush Control Included (164000BR) Rinse Water Source: Onboard Pressurized Fresh Water Bowl Size: Household Bowl with Compact Footprint Bowl Height: 14 in. Standard height (12 in. high from floor to bottom of seat) see attachments for additional detail Bowl Back: Straight Bowl Color: White Overall Bowl Dimensions: 14 in. H x 14 in. W x 18.375 in. D< >- See attached for more details Compact Footprint Dimensions< >- 12.25 in. deep from front base to base of straight back< >- 8.5 in. Wide< >- see attached for more details Voltage: 12 Volt DC Operation Amp Draw: 18 amps Circuit Breaker/Fuse size: 30 amp Inlet Hose: 1/2 in. Inside Diameter Discharge: 1 in. or 1-1/2 in. Inside Diameter (Sani/Flex Odor Shield Hose Recommended) Vortex-Vac Flush Technology< >- Raritan's vortex pump creates an on-demand instantaneous vacuum and eliminates the need for external vacuum pumps, tanks, foot pedals and other mechanical components that can fail resulting in a system that is easier to install and maintain with a significant cost savings< >- Raritan's Vortex-Vac flushing technology is also the quietest and most efficient in its class. Its low water usage also extends the useful capacity of your holding tank Slow Close Seat and Lid Designed for Marine Use (1245SC)< >- Seat Construction includes unique locking tabs which hold the seat in place while boat is rocking. Heavy Duty Momentary Push Button Control provides the ability to flush with no independent control of water and discharge Quiet operation Built in macerator shredder reduces clogs 10 ft. pump head One piece vitreous china bowl for easy cleaning Unique 3-Point Mounting System makes the installation simple and eliminates unnecessary nooks and crannies which makes cleaning simple and easy Normalized SKU: 221HF01202

Raritan 231HS012 Toilets Marine Elegance 12V toilet with tall straight back bowl equipped with a SeaFresh rinse water kit and smart toilet flush control. The SeaFresh rinse water kit enables the captain to toggle back and forth from onboard pressurized fresh water or raw water as the flush water source depending on preference and or the water type that is available at any given point. Raritan Marine Elegance Toilet with Vortex-Vac Flush technology adds a clean and sophisticated look to any marine bathroom  Smart Toilet Flush Control Included (STC) Rinse Water Source: SeaFresh - The SeaFresh Rinse water package includes the main components needed to enable the user to utilize Onboard Pressurized Fresh Water or Raw Sea/Lake Water depending on the available resources and or preference. This option allows the captain to change the rinse water source from raw to fresh water quickly and easily with a quick flip of the SeaFresh selector switch. Bowl Size: Household Bowl with Compact Footprint Bowl Height: 17 in. Overall (15 in. high from floor to bottom of seat) see attachments for additional detail Bowl Back: Straight Bowl Color: White Overall Bowl Dimensions: 17 in. H x 14 in. W x 18.375 in. D< >- See attached for more details Compact Footprint Dimensions< >- 12.25 in. deep from front base to base of straight back< >- 8.5 in. Wide< >- see attached for more details Voltage: 12 Volt DC Operation Amp Draw: 18 amps (toilet only) and 10 amps (remote pump) Circuit Breaker/Fuse size: 30 amp Inlet Hose: 1/2 in. Inside Diameter Discharge: 1in. or 1-1/2 in. Inside Diameter (Sani/Flex Odor Shield Hose Recommended) Vortex-Vac Flush Technology< >- Raritan's vortex pump creates an on-demand instantaneous vacuum and eliminates the need for external vacuum pumps, tanks, foot pedals and other mechanical components that can fail resulting in a system that is easier to install and maintain with a significant cost savings< >- Raritan's Vortex-Vac flushing technology is also the quietest and most efficient in its class. Its low water usage also extends the useful capacity of your holding tank Slow Close Seat and Lid Designed for Marine Use (1245SC)< >- Seat Construction includes unique locking tabs which hold the seat in place while boat is rocking. Fully programmable STC Smart Toilet Flush Control features the following 4 options:< >- Normal flush option utilizes just 3.5 pints (55oz.) of water per flush cylce< >- Water Saver flush option utilizes just 2.5 pints (40oz.) of water per flush cycle< >- Water Only option brings inlet water to the bowl when pressed< >- Empty Only option evacuates the bowl STC Wall Mount Panel measures 3.25 in. High X 4.75 in. Wide and includes a 7 ft. wiring harness STC Panel features an LED Holding Tank Full indicator light, which can be engaged if paired with one of the following optional tank sensors:< >- Optional Stick On tank sensor is designed for use with non-metallic waste tanks up to 3/8 in. thick (STCSA)< >- Optional Float Switch tank sensor (STCFL) Quiet operation Unmatched rinsing capabilities Low water consumption Built-in macerator shredder reduces clogs 10 ft. pump head One piece vitreous china bowl for easy cleaning Unique 3-Point Mounting System makes the installation simple and eliminates unnecessary nooks and crannies, which makes cleaning simple and easy Normalized SKU: 231HS012

Raritan 241EF012 ToiletsRaritan Marine Elegance White Fresh Water Toilet & Smart Contro #241EF012Normalized SKU: 241EF012

Raritan 231HR01201 Toilets Marine Elegance 12V toilet with a tall straight back bowl equipped with a remote intake water pump for raw water flushing, featuring a multifunction momentary flush control. Raritan Marine Elegance Toilet with Vortex-Vac Flush technology adds a clean and sophisticated look to any marine bathroom  Multifunction Momentary Flush Control Included (221551) Rinse Water Source: Raw Sea/Lake Water (Remote Intake Pump) Bowl Size: Household Bowl with Compact Footprint Bowl Height: 17" Overall (15" high from floor to bottom of seat) see attachments for additional detail Bowl Back: Straight Bowl Color: White Overall Bowl Dimensions: 17" H x 14" W x 18.375" D Compact Footprint Dimensions 12.25" deep from front base to base of straight back 8.5" Wide Voltage: 12 Volt DC Operation Amp Draw: 18 amps (toilet only) and 10 amps (remote pump) Circuit Breaker/Fuse size: 30 amp Inlet Hose: 1/2 in. Inside Diameter Discharge: 1" or 1-1/2" Inside Diameter (Sani/Flex Odor Shield Hose Recommended) Vortex-Vac Flush Technology Raritan's vortex pump creates an on-demand instantaneous vacuum and eliminates the need for external vacuum pumps, tanks, foot pedals, and other mechanical components that can fail resulting in a system that is easier to install and maintain with significant cost savings Raritan's Vortex-Vac flushing technology is also the quietest and most efficient in its class. Its low water usage also extends the useful capacity of your holding tank Slow Close Seat and Lid Designed for Marine Use (1245SC) Seat Construction includes unique locking tabs that hold the seat in place while the boat is rocking. Multifunction Momentary Control provides momentary operation and independent momentary control of water and discharge: The water-only option brings inlet water to the bowl when pressed Empty Only option evacuates the bowl Both buttons may be pressed simultaneously for momentary operation of inlet water and evacuation The multifunction Momentary Wall Mount Panel measures 3" High x 1.5" Wide and includes a 7' wiring harness Quiet operation Unmatched rinsing capabilities Built-in macerator shredder reduces clogs 10' pump head One piece vitreous china bowl for easy cleaning Unique 3-Point Mounting System makes the installation simple and eliminates unnecessary nooks and crannies which makes cleaning simple and easy Normalized SKU: 231HR01201
