Furuno 520-5MSD TransducersBronze Thru-Hull Transducer, 600w (10-Pin) 600 Watts 50/200 kHz 46/10 degree Beam Angles Bronze Thru-Hull 8-Meter Cable with 10-Pin Connector WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications:Fairing Block Included = NONE Frequency = 50/200 Mounting Style = Thru-Hull Pins = NONE Speed Included = No Temperature = No Beam Width = 46°/10° Cable Length (Feet) = NONEFURUNO 520-5MSD BT DEPTH ONLY F/ 6000/600L/582L/16&1850DFNormalized SKU: 5205MSDUPC Code: 611679101013

  Download LiteratureFuruno 525T-BSD TransducersBronze Thru-Hull Transducer w/ Temp, 600w (10-Pin) 600 Watts 50/200 kHz 45/15 degree Beam Angles Bronze Thru-Hull with Temperature 30 Foot Cable with 10-Pin Connector WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications:Fairing Block Included = NONE Frequency = 50/200 Mounting Style = Thru-Hull Pins = NONE Speed Included = No Temperature = Yes Beam Width = 45°/15° Cable Length (Feet) = NONEFURUNO 525T-BSD BT W/ TEMP F/ 600L/582L/1650&1850Normalized SKU: 525TBSDUPC Code: 611679247063Furuno 525T-BSD Literature Download  Product Brochure

Furuno 000-197-069-10 AccessoriesFuruno Cable 12 to 10-Pin Transducer Adapter #000-197-069-10Normalized SKU: 00019706910

Furuno FCV600 Fishfinders FCV600 CHIRP Fishfinder The 5.7” FCV600 is capable of driving either a CHIRP or dual-frequency CW (continuous wave) transducer, allowing users to configure the Fish Finder to suit almost any need. With a sleek, piano-black presentation, comfortable rubber keys, and a robust rotary knob controller, the FCV600 gives users the freedom to choose from a wide variety of transducers. The soft-touch keys are inclined at the top and bottom, making them comfortable to press while creating an easy-to-operate and intuitive system. Sunlight and yellow color palettes offer greatly improved visibility in daylight and for those who deal with color blindness. The Color Range Expansion feature broadens the range of discrete signal intensities that can be detected and paints them in different colors. With color range expansion, the range of identifiable echoes is expanded, so you can intuitively identify bottom fish from the seabed. Furuno’s RezBoost™ signal processing technology produces a picture that is up to 8 times clearer, breathing life into the standard CW transducer users may already have installed. A second FCV600 display can be installed to show the echoes and nav data from the FCV600 via the built-in wireless network. This simple yet powerful solution allows for continuous monitoring of the underwater situation from the stern or bow while fishing with a simplified installation. Features: 5.6” (FCV600) TruEcho CHIRP/CW Fish Finder Drives either a CHIRP or CW transducer Color palettes offer unbeatable daylight visibility Color Range Expansion displays returns from more discreet signal frequencies for unbeatable target separation RezBoost™ signal processing produces a picture up to 8 times clearer Wireless 2nd display capability Heave correction with the satellite compass What's in the box: FCV600 Display FCV600 Display Cover FCV600 Display Bracket FCV600 Knob for Bracket (2) 2M Power/Data cable Self-Tapping Screws 5x20 (4) LCD Cleaning Cloth Glass Fuse 3A (2) Installation Manual Normalized SKU: FCV600UPC Code: 611679401649

Furuno FCV800 Fishfinders FCV800 CHIRP Fishfinder The 8.4” FCV800 includes all of the functionality of the FCV600 but features dual transducer ports, allowing for the simultaneous use of both CHIRP and CW channels. The dual transducer ports of the FCV800 offer the best of both worlds. Features such as Furuno’s Accu-Fish fish size assessment tool and Bottom Discrimination to display what kind of material the bottom is composed of require a dual-frequency CW transducer, while Furuno’s TruEcho CHIRP delivers greater detail and target separation for baitfish, game fish, and structure. With the FCV800’s ability to drive both TruEcho CHIRP and CW options at the same time, those sought-after CW-only features can be combined with TruEcho CHIRP’s frequency-modulated signal to deliver those exclusive Furuno features while providing better resolution for targets on the screen.  Features: 8.4” (FCV800) TruEcho CHIRP/CW Fish Finder Drives either a CHIRP or CW transducer Drive a CHIRP and CW Transducer simultaneously (FCV800 only) Color palettes offer unbeatable daylight visibility Color Range Expansion displays returns from more discreet signal frequencies for unbeatable target separation RezBoost™ signal processing produces a picture up to 8 times clearer Wireless 2nd display capability Heave correction with Satellite Compass TLL Output (FCV800 Only)  Bottom Hardness Output (FCV800 Only) What's in the Box: FCV800 Display Display Cover Display Bracket Mounting knobs - pair 2M Power/Data cable Self Tapping Screws 5x20 x 4 LCD Cleaning Cloth Glass Fuse 3A Installation Manual Normalized SKU: FCV800

Furuno TM275LHW TransducersAirmar TM275-LHW Transom Mount Low/High Wide CHIRP Transducer with No ConnectorModel: TM275LHW Depth & fast-response water-temperature sensor Low - CHIRPS from 42 kHz to 65 kHz - 25° to 16° beamwidth High - CHIRPS from 150 kHz to 250 kHz - 25° constant beamwidth 123 kHz of total bandwidth from one transducer Covers popular fishing frequencies of 50 and 200 kHz plus everything else in the bandwidth Get more coverage under the boat with Airmar's new wide beam Chirp product line. Offering a high frequency range of 150-250 kHz and a constant 25° Beamwidth, these transducers are truly broadband at its best. In addition to improving the performance of Chirp-ready echosounders, anglers using the new wide beam transducers will achieve twice the coverage under the boat compared to our current high frequency Chirp transducers.A unique property of the new high frequency transducers is that the Beamwidth is a constant 25° angle across the entire frequency band. Now, in addition to providing vast bottom coverage and precise fish detection in the upper water column that can sometimes go unseen with our narrow beam transducers, Airmar's new wide beam format also creates crisper and larger return images on the display. We've got you covered.Specifications Hull deadrise up to 28° Acoustic window Urethane What's in the Box: TM-275 LHW Transom Mount Bracket and Hardware 3 - 3deg Shims Normalized SKU: TM275LHWUPC Code: 6116793595518

Furuno TM185M TransducersTM185M Medium-Frequency CHIRP Transducer with Temperature - Urethane Transom Mount with Stainless BracketFeatures: Frequency: Chirp 85 - 135 kHz Power Rating: 1KW Connector: 10 Pin This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Normalized SKU: TM185MUPC Code: 611679381033

Furuno B285M TransducersB285M Medium-Frequency CHIRP Transducer with Temperature - Bronze Thru-Hull with High Speed Fairing BlockFeatures: Frequency: Chirp 85 - 135 kHz Power Rating: 1 KW Connector: 10 Pin Fairing Block: High Speed Fairing Block Included Normalized SKU: B285M

Furuno DFF1UHD+ Black Box ModuleDFF1UHD+ TruEcho CHIRP™ Fishfinder with Side-Scan Black Box SounderAdvanced CHIRP Technology Meets Maximum VersatilityThe DFF1UHD+ succeeds the BBDS1 and DFF1-UHD, offering superior performance, modern connectivity, and capabilities not found in previous generations.Combining TruEcho CHIRP™ technology, CHIRP Side-Scan capability, and broad transducer compatibility, the DFF1UHD+ sets a new benchmark for high-performance fish finding. Its compact design and seamless integration with NavNet TZtouchXL make it an ideal solution for both new installations and system upgrades. Built for versatility and future expansion, the DFF1UHD+ delivers the clarity, range, and flexibility professional anglers and serious boaters demand from their marine electronics.Next Generation Fishing And Navigation Solution for NavNet TZtouchXLThe DFF1UHD+ is a powerful multi-channel network Fish Finder designed for seamless integration with NavNet TZtouchXL, the perfect addition for helms featuring the TZT22X, TZT24X, or Black Box TZTBBX. The DFF1UHD+ combines up to 1 kW of CW and CHIRP Fish Finder power with 230 kHz or 455 kHz CHIRP Side-Scan in a single compact unit, delivering enhanced performance and versatility. Color-coded, waterproof connectors and a compact design allow for a simple installation.Advanced Fishfinder Features: Compatible with 300/600 W or 1 kW Transducer (Matching box MB1100 required for some CW transducers) Display Range from 6 to 4,000 feet Modes: ACCU-FISH™*, A-Scope, Manual Gain, Auto Gain (Fishing/Cruising), TruEcho CHIRP™, Bottom Discrimination (Compatible transducer required) 8-Step Picture Advance: x4, x2, x1, 1/2, 1/4, 1/8, 1/16, stop Fish Finder Alarms: Fish School, Fish School for bottom lock CHIRP Side-Scan Features: CHIRP at 230 kHz or 455 kHz center frequency Display range up to 750 feet to each side View CHIRP Side-Scan in full screen, 1/2 screen, 1/3 screen, 1/4 screen, and 1/6 screen Eight CHIRP Side-Scan display colors Features: Combines CW, TruEcho CHIRP™, and CHIRP Side-Scan into a single compact black box solution. Features CHIRP Side-Scan capability at either 230 kHz or 455 kHz (depending on transducer), with a range of up to 750 feet. Offers advanced modes: ACCU-FISH™*, Bottom Discrimination*, Manual and Auto Gain, and A-Scope, delivering exceptional clarity and definition *(feature compatible transducer required)  Flexible Display Layouts: Choose from full screen, split screen, and multi-pane layouts: 1/2, 1/3, 1/4, and 1/6 screen formats, with eight CHIRP Side-Scan color options. Over 60% smaller than the DFF1-UHD and nearly 50% smaller than the BBDS1, making it ideal for installations in tight spaces. Specifications: Display Size: Black Box Display Type: Black Box Power Usage: 12-24 VDC Range: 4,000' Power Output: 150 W or 300 W or 600 W or 1 kW Sonar connectors: Blue sonar connector - 12 pin, Yellow Sonar connector for Chirp Side Scan 12 pin Frequency: CW 50-200 kHz and CHIRP 40-225 kHz and CHIRP Side-Scan 230 or 455 kHz A Variety of Transducer Combinations:There are a variety of available transducer combinations to meet the needs of any vessel:Without Side-Scan: Single CHIRP Dual CHIRP Single CW Single Mid-CHIRP and CW With Side-Scan: Single CHIRP and CHIRP Side-Scan Single CW and CHIRP Side-Scan Normalized SKU: DFF1UHD+
