Download LiteratureMaretron RIM100-01 Network AccessoriesRIM100 Run Indicator ModulePart #: RIM100-01Maretron's Run Indicator Module monitors both AC and DC electrical circuits and reports, over an NMEA 2000 network, whether or not the electrical circuit is energized and running. The RIM100 works equally as well for monitoring manually switched loads (running lights, anchor lights, or deck lights) as it does for automatically switched loads. Monitoring automatically switched loads (bilge pumps, engine exhaust/intake fans, and transfer pumps) via the RIM100 is especially useful because you know exactly when equipment is, or isn't running.Features: Monitors and reports the running status of connected devices Works with both AC and DC loads Works with both automatically and manually switched loads Can indicate the status of a wide variety of loads: Bilge bumps, Winches, Running lights, Transfer pumps, Exhaust/intake fans WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. MARETRON RUN INDICATOR MODULE RIM100Normalized SKU: RIM10001UPC Code: 873804000206Maretron RIM100-01 Literature Download  Quick Reference Guide  Owners Manual

Maretron TFTDBE-5H Network AccessoriesSAE 5-Bolt Pattern Focus Tube w/Dead Band EliminatorFocus tubes allow the TLM100/TLM150 ultrasonic tank level monitors to be used for level measurement on vessels with non-displacement hulls at up to 15° of pitch or roll, compared to 6° pitch or roll for the sensor alone. Additionally, the focus tube with deadband eliminator raises the TLM100/TLM150 2" above the top of the tank, allowing accurate level measurement with fluid levels all the way to the top of the tank, and eliminating the 2" deadband of the TLM100/TLM150.WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Specifications:Load Equivalence # (LEN) = NONENormalized SKU: TFTDBE5HUPC Code: 873804003689

  Download LiteratureMaretron SMS100 Network AccessoriesSMS100 Short Message Service (Text) ModuleMust be used with a GSM band cell provider, not compatible with Verizon WirelessMaretron's SMS100 is a mobile or cellular modem that automatically sends text message alerts from your vessel to your phone. The SMS100 works together with Maretron's dedicated displays (DSM150/DSM250) or N2KView software (with the optional N2KView-Alerts module) to detect programmable alert conditions from sensors interconnected on an NMEA 2000 network. The displays or N2KView software instruct the SMS100 to connect to the cellular network and transmit an alert message to selected telephone numbers. Whether it is high bilge water, low battery voltage, unplugged shore power, or an opened hatch or door, the SMS100 quickly alerts you to conditions onboard your vessel that require attention anywhere you have cellular network coverage. You can also send a text message to your vessel and with the proper sensors installed, the SMS100 will respond with status information including the vessels position, bilge status, battery and shore power voltage, wind speed, inside and outside temperature.Applications: Programmable alerts (Alarms or Warnings) from Maretron installed displays and sensors on the vessel automatically triggers text message(s) sent to your phone User can text vessel for status (Position, Bilge Status, Battery and Shore Power Voltage, Wind Speed, Inside and Outside Temp) which also double checks communication path to ensure alerts get through Six band GSM modem with easily interchangeable mini-SIM Card (SIM Card is user supplied) Dipole terminal antenna with hinged SMA Connector with versatile mounting options Weatherproof (IP65) enclosure WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications:Load Equivalence # (LEN) = NONENormalized SKU: SMS100UPC Code: 873804003382Maretron SMS100 Literature Download  Owners Manual  Product Brochure

  Download LiteratureMaretron SH-449CSTE VHF Handheld RadiosSmoke/Heat DetectorPart #: SH-449CSTEFeatures: Attaches to Maretron SIM100 for NMEA 2000 network monitoring Automatically reports trouble when dirty Integral power supervision Intelligent, self-diagnostic Field replaceable optical chamber Low profile design Plug-in terminal block Advance false alarm immunity Normalized SKU: SH449CSTEUPC Code: 873804002491Maretron SH-449CSTE Literature Download   Owners Manual

  Download LiteratureMaretron SH-002 Fume & FireSmoke/Heat Detector for SIM100Maretron's Smoke and Heat Detector is made for use specifically with Maretron's SIM100 Switch Indicator Module.WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Normalized SKU: SH002UPC Code: 873804003634Maretron SH-002 Literature Download  Product Brochure

  Download Literature Maretron SSC300-01 Navigational Instruments Solid-State Rate/Gyro Compass without CablesMaretron's SSC300, implementing the second generation of Maretron's award-winning compass technology, is a solid-state, rate gyro electronic compass that provides better than 0.7x heading accuracy through q45x of roll and pitch angle, and better than 1x roll and pitch accuracy in static conditions. Each SSC300 is factory calibrated for maximum accuracy. It delivers precise, reliable heading information ten times per second, plus vessel attitude including pitch and roll readings once per second. A micromachined 3-axis rate gyro is used, in conjunction with a 3-axis accelerometer, by advanced stabilization algorithms to provide accurate, stable readings during dynamically changing conditions such as hard turns or rough seas, making it an ideal heading sensor for autopilot or radar overlay applications.Maretron's SSC300 is certified to the NMEA 2000 network standard and compatible with the NMEA 0183 digital interface standard. It connects directly with any NMEA 2000 network and with the optional NMEA 0183 cable accessory, with NMEA 0183 listeners to share information with navigational software, chart plotters, autopilots, and dedicated instrument displays - including Maretron's N2KView vessel monitoring system, or Maretron's DSM150 /DSM250 color graphics displays.The SSC300 can be automatically calibrated for deviation. Its dynamic accuracy is improved with advanced digital filtering of the 3-axis magnetometer, 3-axis accelerometer and rate gyro.Features: Better than 0.7x heading accuracy in static conditions Better than 1.5x heading accuracy in dynamic conditions Better than 1x/second rate of turn in Better than 1x pitch/roll accuracy Three axis magnetometer, three axis rate gyro, and three axis accelerometer Outputs NMEA 0183 and NMEA 2000 data simultanously IP67 waterproof enclosure Applications: Navigation Autopilot Radar stabilization Satellite antenna stabilization Swing meter WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Backlight = NONE Load Equivalence # (LEN) = NONE Mounting Style = NONE Output Frequency (mHz) = NONE Output Type = NONE Normalized SKU: SSC30001UPC Code: 873804003641 Maretron SSC300-01 Literature Download   Owners Manual  Product Brochure

  Download LiteratureMaretron SSC300-01-KIT Navigational InstrumentsSolid-State Rate/Gyro Compass w/10m Cable & ConnectorMaretron's SSC300, implementing the second generation of Maretron's award-wining compass technology, is a solid state, rate gyro electronic compass that provides better than 0.7x heading accuracy through q45x of roll and pitch angle, and better than 1x roll and pitch accuracy in static conditions. Each SSC300 is factory calibrated for maximum accuracy. It delivers precise, reliable heading information ten times per second, plus vessel attitude including pitch and roll readings once per second. A micromachined 3-axis rate gyro is used, in conjunction with a 3-axis accelerometer, by advanced stabilization algorithms to provide accurate, stable readings during dynamically changing conditions such as hard turns or rough seas, making it an ideal heading sensor for autopilot or radar overlay applications.Maretron's SSC300 is certified to the NMEA 2000 network standard and compatible with the NMEA 0183 digital interface standard. It connects directly with any NMEA 2000 network and with the optional NMEA 0183 cable accessory, with NMEA 0183 listeners to share information with navigational software, chart plotters, autopilots, and dedicated instrument displays - including Maretron's N2KView vessel monitoring system, or Maretron's DSM150 /DSM250 color graphics displays.The SSC300 can be automatically calibrated for deviation. Its dynamic accuracy is improved with advanced digital filtering of the 3-axis magnetometer, 3-axis accelerometer and rate gyro.Features: Better than 0.7x heading accuracy in static conditions Better than 1.5x heading accuracy in dynamic conditions Better than 1x/second rate of turn in Better than 1x pitch/roll accuracy Three axis magnetometer, three axis rate gyro, and three axis accelerometer Outputs NMEA 0183 and NMEA 2000 data simultanously IP67 waterproof enclosure Applications: Navigation Autopilot Radar stabilization Satellite antenna stabilization Swing meter WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Specifications:Backlight = NONE Load Equivalence # (LEN) = NONE Mounting Style = NONE Output Frequency (mHz) = NONE Output Type = NONENormalized SKU: SSC30001KITMaretron SSC300-01-KIT Literature Download  Owners Manual  Product Brochure

Maretron PTS-0-1.5PSI-01 Network AccessoriesSubmersible Pressure Transducer - 0 to 1.5 PSIUsed for tanks up to 40" or 1M in depthThe submersible pressure transducers are used together with Maretron's Fluid Pressure Monitor (FPM100), whichallows tank fluid level to be broadcast over an NMEA 2000® network where it can be monitored from any compatible NMEA 2000® display. When used together with Maretron displays, alerts can be set so the user can be informed of low or high tank levels. And when not on-board the vessel, users can be notified through emails or text messages about theirtank levels. Additionally, the tank levels can be stored using Maretron's data recorder (VDR100) for later analysis.WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Specifications:Load Equivalence # (LEN) = NONENormalized SKU: PTS015PSI01UPC Code: 873804003696

Maretron PTS-0-1.5PSI-02 TransducersSubmersible Pressure Transducer - 0-1.5 PSIThe submersible pressure transducers are used together with Maretron's Fluid Pressure Monitor (FPM100), which allows tank fluid level to be broadcast over an NMEA 2000® network where it can be monitored from any compatible NMEA 2000® display. When used together with Maretron displays, alerts can be set to inform the user of low or high tank levels. Users can be notified through emails or text messages about their tank levels when not onboard the vessel. Additionally, the tank levels can be stored using Maretron's data recorder (VDR100) for later analysis. Normalized SKU: PTS015PSI02UPC Code: 873804004549

Maretron PTS-0-3.0PSI-01 Network AccessoriesSubmersible Pressure Transducer - 0 to 3 PSIUsed for tanks up to 80" or 2M in depthThe submersible pressure transducers are used together with Maretron's Fluid Pressure Monitor (FPM100), whichallows tank fluid level to be broadcast over an NMEA 2000® network where it can be monitored from any compatible NMEA 2000® display. When used together with Maretron displays, alerts can be set so the user can be informed of low or high tank levels. And when not on-board the vessel, users can be notified through emails or text messages about theirtank levels. Additionally, the tank levels can be stored using Maretron's data recorder (VDR100) for later analysis.WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Specifications:Load Equivalence # (LEN) = NONENormalized SKU: PTS030PSI01UPC Code: 873804003702

Download LiteratureMaretron PTS-0-3PSI-02 Navigational InstrumentsSubmersible Pressure Transducer 0-3 PSIMaretron’s submersible pressure transducers indicate tank levels and can be installed directly in the tank. Please follow these instructions to mount and connect a submersible pressure transducer to an NMEA 2000® network via a Maretron FPM100 Fluid Pressure Monitor. Maretron recommends one of two methods for mounting a submersible pressure transducer in a tank: 1) without a restraining tube, and 2) with a restraining tube.The submersible pressure transducers are designed for a tank with a 5-hole SAE J1810 fitting at the top. Install the mounting plate with cord grip onto the transducer cable, with the rounded hex section of the cord grip facing away from the transducer.Lower the pressure transducer into the tank such that the transducer lies at the lowest point of the tank and tighten the cord grip to secure the cable. On a tank with a flat bottom, the transducer may slide from side to side with the motion of the vessel but will not rotate due to the stiffness of the cable. It is also possible to mount the pressure transducer inside a restraining or focus tube (sold separately, Maretron part number TFT-5H).Pressure Transducer MountingConnect the two wires of the pressure transducer to a free pressure monitoring channel. Connect the red wire from the pressure transducer to the channel's positive (+) terminal and connect the black wire from the pressure transducer to the negative (-) terminal of the channel. The example in Figure 1 shows the pressure transducer connected to switch channel 0, with the white wire connected to "P0+" and the brown wire connected to "P0-." Submersible pressure transducers have a small plastic vent tube in the connecting cable.Use a Maretron DSM Series Display (firmware 1.4.7 or higher) or a PC running Maretron’s N2KAnalyzer software (version 1.4.19 or higher) to configure the connected channel(s) on the FPM100.Supply power to the NMEA 2000 network and verify that the pressure channel indicates a valid pressure reading.Specifications: Operating Range: 0 to 3 PSI (0.207 bar) Depth Range (Water): 83.1” (2.11 m) Depth Range Diesel (820 kg/m3): 101.3” (2.57 m) Depth Range Gasoline/Petrol (750 kg/m3): 110.8” (2.81 m) Cable Length: 17 ft (5.18 m) Sensor Type: Gauge (Vent Tube) Output: 4 – 20 mA current loop, loop powered Excitation Voltage: 8 VDC to 28 VDC Compatible Fluids / Gases: Diesel, Diesel Exhaust Fluid (DEF), Gasoline/Petrol, Hydraulic Fluid, Kerosene, Motor Oil, Fresh Water, Sea Water, Waste Water Operating Temperature: 14 degrees F to 158 degrees F (-10 degrees C to 80 degrees C) Storage Temperature: -4 degrees F to 176 degrees F (-20 degrees C to 80 degrees C) Accuracy: ±0.3% Full Scale typ. at 25°C Total Error Band (TEB): ±1.0% Full Scale typ. (-10 degrees C to 70 degrees C) Non-Linearity, Hysteresis (NLH): ±0.2% Full-Scale typ. Best Straight Line (BSL) at 25°C Temperature Compensation: 23 degrees F to 122 degrees F (0 degrees C to 50 degrees C) Accuracy: ±1% Full Scale Linearity: 0.5% Full Scale Repeatability: 0.05% Full Scale Full-Scale Thermal Error: 0.04% Full Scale/°F (0.07% Full Scale/degrees C) Long-Term Stability: 0.2% Full Scale/year Response Time: 150ms Proof Pressure: 2 × Full Scale Burst Pressure: 3 × Full Scale Reverse Voltage Protection: ± 30V for 3 minutes Construction: 316L stainless steel body and diaphragm, polyether polyurethane cable, chloroprene boot EMC Compatibility: 10 Volts/meter per EN 61000-4-3 Weight: 24.8oz (703g) Normalized SKU: PTS03PSI02UPC Code: 873804004556Maretron PTS-0-3PSI-02 Literature Download Owners Manual

  Download LiteratureMaretron MS-1055-N Network AccessoriesMS-1055-N Magenetic Switch Cylinder for Indoor/OutdoorApplications: Economical Versatile Fits in limited space Specifications: ABS Plastic Enclosure IP67 Natural color Hermetically sealed reed switch encapsulated in polyurethane WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Specifications:Load Equivalence # (LEN) = NONENormalized SKU: MS1055NUPC Code: 873804002569Maretron MS-1055-N Literature Download  Quick Reference Guide  Owners Manual

  Download LiteratureMaretron SIM100-01 Network AccessoriesSIM100 Switch Indicator ModuleMaretron's Switch Indicator Module monitors switch closure devices including, but not limited to, safety equipment (heat, smoke, carbon monoxide, explosive vapor detectors), security systems (motion, vibration, glass break, door and port hole magnetic switches), and vessel monitoring equipment (valve closed/open, high water bilge). The SIM100 continually monitors these switch closure devices and broadcasts information of the NMEA 2000 network about the switch state so the crew can be alerted to potential conditions or problems that warrant further investigation. Advanced features of the SIM100 include the ability to detect whether or not power has been disconnected frmo the monitored device or if the signal wires have been disconnected due to either corrosion, tampering, or for any other reason (if the monitored device is so equipped). With the SIM100, you can rest assured that ciritcal sensors are receiving power, signal wires are connected, and all the safety, security, and vessel functions are under constant supervision.Features: Monitors and reports switch status Can detect and report problems like opens and shorts in switch circuits Compatible with Maretron Supplied: Heat detectors, Smoke detectors, Carbon monoxide detectors, Bilge water detectors Also compatible with : Magnetic switches, Glass break detectors, Door, hatch, and porthole magnetic switchesSpecifications: Heat Detectors Smoke Detectors Carbon Monoxide Detectors Gas Detectors Bilge Water Detectors Magnetic Switches Glass Break Detectors Clogged Fuel Filter Detection (Excessive vacuum) Door, Hatch, and Porthole Magnetic Switches WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. MARETRON SWITCH INDICATOR MODULE SIM100Normalized SKU: SIM10001UPC Code: 873804000190Maretron SIM100-01 Literature Download  Quick Reference Guide  Owners Manual

  Download LiteratureMaretron TLM200-01 Network AccessoriesTLM200 Tank Level Monitor (104" Depth) Maretron's TLM200 is used to sense fluid levels of tanks using ultrasonic technology. Ultrasonic, or sound waves, are transmitted via the TLM200 mounted at the top of the tank and the flight times of the sound waves to and from the fluid are measured much like a depth sensor. What this means for you is that there are no difficult to handle long probes protruding into the tank, which often foul and/or corrode. Once the TLM200 calculates and broadcast the fluid level over the NMEA 2000 network, you can observe tank levels anywhere on the vessel where there is an NMEA 2000 compatible display such as the Maretron DSM250.The TLM200 is capable of sensing fluid levels in tanks up to 104" in depth. It can be used for diesel, fresh water, waste water, black water, and oil tanks. Unlike most tank senders that only work with rectangular tanks, the TLM200 can be calibrated for irregular tank shapes so you can know the true fluid level in your tanks.The TLM200 is mounted directly to the top of tanks using the industry standard SAE J1810 5-hole mounting pattern. The TLM200 can also be mounted to tanks with threaded tank openings using optional adapters that include both a 1.5" NPT and a 1.25" BSP adapter.Most importantly, the TLM200 is NMEA 2000 certified so you can view any and all tank levels anywhere on the vessel when using a compatible NMEA 2000 display. The TLM200 is another key component of Maretron's N2KView vessel monitoring and control system. Normalized SKU: TLM20001UPC Code: 873804000244Maretron TLM200-01 Literature Download  Owners Manual

  Download LiteratureMaretron TR3K Network AccessoriesThe TR3K temperature probe is for use with the Maretron TMP100 Temperature Module (optional extra) or the DCM100 DC Monitor (it is included with the DCM100). This probe ends in a ring terminal and can be used to measure battery temperature or any other under-bolt temperature. The temperature range is -4 deg. F to 176 deg. F (-20 deg C to 80 deg C).WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. MARETRON TEMPERATURE SENSOR F/ DCM100Normalized SKU: TR3KUPC Code: 873804001432Maretron TR3K Literature Download  Owners Manual
