Download LiteratureSI-TEX TRAWLPLOT 12 ChartplottersTRAWLPLOT 1212.1" Color LCD GPS/WAAS Charting SystemAdvanced C-MAP MAX/NT+ Charting System for the Professional features High-speed Intel Xscale Processor, Easy Operation, Unlimited Storage, GPS WAAS Positioning, Large 12.1" Daylight Viewable Display and expands to an all-in-one GPS Chart/Fishfinder/Radar with optional sensors. 12.1" XVGA Color LCD TFT display with 800 x 600 pixels for high-definition. GPS WAAS 18-channel receiver will put your boat within 3 meters of your waypoint in most situations. Newly designed high-speed processor with INTEL XSCALE Architecture gives you instant screen changes. Zoom level changes appear in the blink of an eye, regardless of the amount of screen detail. Compatible with the new C-MAP MAX charts, technically the most innovative C-MAP charts ever designed. System operates as a C-MAP MAX based chart plotter with four C-Card slots, or as a track plotter without map display. Guardian™ Programmable Anti-Grounding feature* lets you know if your current course takes you within preset distance of charted shoals, obstructions or other areas where the water is too shallow for your vessel's draft.ES502 Fishfinder Module and optional 2kW to 4kW MDS Radar Sensors. Depth Graph feature accepts input from onboard sounder or optional Active Transducer to display graphic presentation of vessel's current depth and recent depth history. Operates in North-Up or Track-Up modes. Coordinates displayed in Lat/Lon, Loran TD's, or UTM. Displays Loran TD's even when position data is supplied in Lat/Lon coordinates. Alphanumeric designations for easy identification of waypoints and marks. "One-Touch" event markfor easy storage and retrieval of gear marks. Unlimited amount of fishing-ground track and route data can be downloaded and stored on standard 3.5" floppy disks. Can read disks from many previous SI-TEX plotters. Each disk can store up to 80,000 track plots and up to 40,000 user points of track and route data for quick recall and display as desired. Tide Info feature uses local C-Card information to calculate tide graph for local ports. Find Function uses local C-Card to locate nearest boatyard, bank, even the closest shower. Joystick control of on-screen cursor to plot, scroll, pan, zoom and place waypoints, events and marks, and to control on-screen VRM and EBL. GOTO and MOB functions. Fourteen selectable languages. Route Data Page displays waypoint position, distance and bearing between the previous waypoint and the current one, fuel consumption, fuel consumption between the waypoint and the first waypoint of the route, estimated time enroute, and total distance. Data information window displays digital route navigation data, and a wealth of other information. Two NMEA-0183 dataports for interfacing data with other on-board electronics. Zoom into as little as 180' across screen. Optional ES502 Fishfinder Module adds full-featured fishfinder capabilities. Specifications:Internal/External Antenna = External Resolution (VxH) = 800 x 600 Routes = NONE Screen Size = 12.1" Touchscreen = No Waypoints = NONE Weather Capable = No Cartography Type = MAX Basemap = Yes Card Format = C-Card Cartography - Preloaded = No Cartography Brand = C-MapSITEX TRAWLPLOT 12 12" COL LCD CHARTPLOTTER W/ WAASNormalized SKU: TRAWLPLOT12UPC Code: 010407100920SI-TEX TRAWLPLOT 12 Literature Download  Quick Reference Guide  Owners Manual

SI-TEX VECTORCOMPACTN Navigational InstrumentsVector Compact - N Worlds Smallest GPS Compass, NMEA 2000 CapableThe Vector Compact GPS Compass offers superior navigation including accuratepositioning and heading performance. V104 uses SBAS (WAAS, EGNOS, MSAS,etc.) for differential GPS position allowing Hemisphere GNSS to provide alow cost and highly effective positioning and heading based smart antenna.The rugged and low-profile enclosure combines Hemisphere GNSS' CrescentVector technology and two multi-path resistant antennas for accuracy,portability and simple installation. The smart antenna, measuring in lessthan a half meter in length, mounts easily to a flat surface or pole. Thestability and maintenace-free design of Vector Compact provides traditionalGPS position and heading at a low cost, replacing the combination oflow-accuracy GPS and fluxgate compass.GPS Receiver Specifications: Receiver Type: Vector GPS L1 Compass Signals Received: GPS Channels: 24 GPS Sensitivity: -142 dBm SBAS Tracking: 2-channel, parallel tracking Update Rate: 10Hz standard (position and heading) Rate of Turn: 90x/s maximum Compass Safe Distance: 30 cm (11.8 in) Cold Start: <60 s (no almanac or RTC) Warm Start: <20 s typical (almanac and RTC) Hot Start: <5 s typical (almanac, RTC and position) Heading Fix: <20 s typical (valid position) Maximum Speed: 1,850 kph (999 kts) Maximum Altitude: 18.288 m (60,000 ft) PowerInput Voltage: 8-36 VDC Power Consumption 2.0 W nom.Current Consumption: 0.16 A @ 12VDCPower Isolation: Isolated to enclosureReverse Polarity Protection: YesMechanicalDimensions Not including mount: 29.9 L x 12.9 W x 4.5 H (cm)10.2 L x 5.1 W x 1.8 H (in)Dimenstions Including mount: 25.9 L x 12.9 W x12.8 (cm)10.2 L x 5.1 W x 5.0 H (in) Provides position,heading,pitch,roll and heave Excellent in-band and out-of-band interference rejection 2° (RMS) heading accuracy in an amazingly small form factor Integrated gyro and tilt sensors deliver fast star-up times and provide heading updates during temporary loss of GPS and Satellites Differential position accuracy of 1m, 95% of the time Accurate heading for up to 3 minutes during GNSS outages COAST technology maintains differentially corrected positioning for 40minutes or more after loss of differential signal Normalized SKU: VECTORCOMPACTNUPC Code: 010407510552

SI-TEX VECTORCOMPACTS Navigational InstrumentsVector Compact - S Worlds Smallest GPS Compass with NMEA 0183Interconnect CableThe Vector Compact GPS Compass offers superior navigation including accurate positioning and heading performance. V104 uses SBAS (WAAS, EGNOS, MSAS, etc.) for differential GPS position allowing Hemisphere GNSS to provide a low cost and highly effective positioning and heading based smart antenna.The rugged and low-profile enclosure combines Hemisphere GNSS' Crescent Vector technology and two multi-path resistant antennas for accuracy, portability and simple installation. The smart antenna, measuring in less than a half meter in length, mounts easily to a flat surface or pole. The stability and maintenace-free design of Vector Compact provides traditional GPS position and heading at a low cost, replacing the combination oflow-accuracy GPS and fluxgate compass.GPS Receiver Specifications: Receiver Type: Vector GPS L1 Compass Signals Received: GPS Channels: 24 GPS Sensitivity: -142 dBm SBAS Tracking: 2-channel, parallel tracking Update Rate: 10Hz standard (position and heading) Rate of Turn: 90x/s maximum Compass Safe Distance: 30 cm (11.8 in) Cold Start: <60 s (no almanac or RTC) Warm Start: <20 s typical (almanac and RTC) Hot Start: <5 s typical (almanac, RTC and position) Heading Fix: <20 s typical (valid position) Maximum Speed: 1,850 kph (999 kts) Maximum Altitude: 18.288M (60,000') Interconnect Cable 15M(49') Power Input Voltage: 8-36 VDC Power Consumption Power Consumption: 2.0 W nom. Current Consumption: 0.16 A @ 12VDC Power Isolation: Isolated to enclosure Reverse Polarity Protection: Yes Mechanical Dimensions Not including mount: 29.9 L x 12.9 W x 4.5 H (cm) 10.2 L x 5.1 W x 1.8 H (in) Dimensions Including mount: 25.9 L x 12.9 W x12.8 (cm) 10.2 L x 5.1 W x 5.0 H (in) Provides position,heading,pitch,roll and heave Excellent in-band and out-of-band interference rejection 2° (RMS) heading accuracy in an amazingly small form factor Integrated gyro and tilt sensors deliver fast star-up times and provide heading updates during temporary loss of GPS and Satellites Differential position accuracy of 1m, 95% of the time Accurate heading for up to 3 minutes during GNSS outages COAST technology maintains differentially corrected positioning for 40 minutes or more after loss of differential signal Offered as a Serial or NMEA 2000 Version Normalized SKU: VECTORCOMPACTSUPC Code: 010407510545

  Download LiteratureSI-TEX VECTORG1 Navigational InstrumentsVector 3D SystemPart #: VECTORG1Features: Small compact all-in-one maintenance free unit Full compatible with NMEA 0183 and 2000 equipment: Autopilots, Radar, AIS, Plotters, etc. (Comnav adapter #3121011 sku 69522 is need for NMEA 2000 application ) Accurate 2D heading and positioning data Better than 0.60 degree Heading sensor 90 degree Rate of Turn tracking (ROT) Provides Heave, Pitch and Roll information DGPS provides sub-meter positioning accuracy Differential Correction source SBAS (WAAS, EGNOS and MSAS) and RTCM SC-104 data (External Source) COASTTM technology maintains differentially-corrected position for 40 minutes or more with loss of differential signal Integrated Gyro & Tilt sensors provide fast start up times and Heading updates during temporary loss of GPS 20 Hz position and Heading update rates (10 Hz standard) Multiple BAUD rate selections CE certified for EMI and RFI immunity Pre-programmed default setting for Heading, Rate of Turn, Course over Ground, Lat/Long Geographic position, Time & Date 2 year warranty Worldwide service Specifications:Backlight = NONE Mounting Style = NONE Output Frequency (mHz) = NONE Output Type = NONENormalized SKU: VECTORG1UPC Code: 010407510538SI-TEX VECTORG1 Literature Download  Owners Manual

Download LiteratureSI-TEX VECTORG2 Navigational InstrumentsVector Pro GPS CompassThe Vector Pro G2 GPS Compass is a state-of-the-art electronic navigation data device. It is capable of providing highly accurate, high-precision position and heading data to a wide variety of marine Navigation equipment, such as autopilots, sonar, radar, chartplotters, AIS receivers & transponders, and many other types of marine devices & systems. The Vector Pro G2 features fast start-up and signal re-acquisition times, heading & position updates at up to 20 times per second, and can operate at sustained turn rates up to 90 degrees per second. The Vector Pro G2 is a complete GPS Compass in a single rugged, marine-grade enclosure. Precise 2D heading and positioning data Heading accuracy of better than 0.5 degrees Rate of turn tracking rates up to 90'/sec Provides Heave, Pitch & Roll information Pitch and roll accuracy of better than 1 degree Fully compatible with Autopilot, Radar, AIS, PC, Sonar Better than 1 meter differential position accuracy (DGPS/G2B) Differential Correction source options include SBAS (WAAS, EGNOSand MSAS) and RTCM SC-104 data (External Source) G2B can also use terrestrial DGPS Radio beacon signals Integrated Gyro & Tilt sensors provide heading during momentary lossof satellite signals and speed up GPS signal reacquisition Heading Position Updates up to 20 Hz Multiple BAUD rate selections: 4800/9600/19200/38400 Pre-programmed default settings for Heading, Rate of TurnCourse over Ground, Lat/Long Geographic position, Time & Date Heading solution for steel vessels Waterproof-commercial grade IP67 standards CE certified for EMI and RFI immunity Optional 15m or 30m cable IMO Compliant Worldwide Service Single power/data cable, which greatly simplifies installation. Power Input 9 to 36 VDC <360 mA@ 12 VDC, <5 w Dimensions 23.6"L x 6.3"W x 7.1"H Weight 3.3lbs Normalized SKU: VECTORG2UPC Code: 010407510422SI-TEX VECTORG2 Literature Download Owners Manual

  Download LiteratureSI-TEX MDA-4 VHF Fixed Mount RadiosVHF-FM DSC Radio w/Built-In AISThe SI-TEX MDA-4 is type approved and ready for action on recreational and commercial fishing boats,  workboats and more. This rugged package combines an advanced VHF-FM/DSC radiotelephone with a quality built-in Dual Channel AIS Receiver.All the features professionals expect — at an unexpectedly low price: Ruggedized to Military Specifi cation (MIL-STD-801G*), to stand up to tough conditions and years of hard professional use  Dual Watch, Tri-Watch and Programmable Scanning Modes Robust 25W loud hailer/foghorn with eight selectable modes and listen back Optional full-function Remote Command microphone and GNSS 66-channel smart GPS antenna High-performance dual-channel AIS receiver Standard 2-year warranty The large LCD display provides important AIS data like MMSI, Call Sign, Ship’s Name, Bearing, Distance,  Speed Over Ground and Course Over Ground, along with alerts for Closest Point of Approach and Time to Closest Point of Approach. The MDA-4 can also provide important navigation data like Lat/Lon, Date, SpeedOver Ground and Course Over Ground. The MDA-4 delivers a boatload of advanced features for an affordable priceSpecifications:GENERAL: Dimensions (LWH): 8" x 4.25" x 2.25" Dims w/Bracket (LWH): 8.5" x 5.25" x 2.25" Weight: 3.3lbs Connectivity: NMEA2000, NMEA0183 Power Supply: 13.8V DC Environmental: MIL-STD-810G*, ITU Standards, IPX7 Waterproof AIS RECEIVER Frequency: 161.975MHz/162.025MHz No. of Channels: (2) Dual Channels Local Oscillator Mode: PLL Ambient Operating Temperature: -15° C to +55° C VHF RADIO TX Frequency: 156.025-157.425 MHz RX Frequency: 156.050-162.025 MHz Channels: All USA, Canada and INT channels, plus private channels Microphone: Wired handheld channel up/down, power high/low and quick 16/9 channel access, extra-long mic cord for commercial wheelhouses Modulation Mode: FM (16K0G3E/DSC (16K0G2B) Antenna Impedance: 50 Ω nominal Receiver Sensitivity: 0.22 micro-volts (SINAD-12 dB) Spurious Response Rejection: 70 dB Adjacent Channel Rejection: 70 dB Audio Output Power: 5W @ 4 Ohm Hailer/Fog Horn Audio Output Power: 25W @ 8 Ohm Audio Distortion: 5% RF Output Power: High 25W/Low 1W Harmonic Emissions: 0.25 µ W * Meets MIL-STD-810G specifi cations for Altitude, High Temperature,Low Temperature, Temperature Shock, Contamination by Fluids,Solar Radiation, Rain, Humidity, Salt Fog, Sand & Dust, Immersion,Vibration, Shock) Specifications:Channels - Available = All US, Canadian, International DSC Class = D Hailer/Intercom = NONE Power - Output (Watts) = 25W Remote Mic Capable = Yes Scrambler Capable = NONE Waterproof Rating = NONE Weather Alert = NONENormalized SKU: MDA4UPC Code: 010407510613SI-TEX MDA-4 Literature Download  Owners Manual  Product Brochure

SI-TEX T2010A-4 Radar ArraySi-Tex T2010A-4 10.4" Display 12kW Open Array Radar with 4.5' AntennaModel: T2010A-4 Dual-Speed antenna with 48-rpm capability for high speed/river operations Split-screen display of long- and short-range targets simultaneously True-Trail Function identifies moving targets Features include Interference Rejection, Target Expansion, Parallel Index, True/Relative Bearing Standard AIS Interface module capable of tracking 200 targets***** Optional 50-target Automatic Tracking Aid (ATA). Specifications Scanner 4.5' Open Array Peak Power Output 12kW Output Frequency 9410 +/- 30MHz Beam Width 1.8° Horzontal, 22° Vertical Rotation 24 or 48 RPM Pulse width .08, 0.15, 0.3, 0.5, 1 usec IF Frequency 60MHz Range Accuracy Better than 8m or 1% of range scale selected, whichever is greaer Minimum Detecting Distance 25m Display Unit Size/Type 10.4" TFT Color LCD Resolution 480 x 640 Display modes Heads up, North up*, Course Up*, WPT up** Dimensions 12 19/32" x12 19/32" x 5 39/64" Power 10.8 - 31.2vDC Power Consumption 130 watts or less *Requires heading, speed, and/or position signal input from external equipment including GPS Compass depending on application of user. **Requires waypoint data input. What's in the Box: MRD-104 Display RB718A - Pedestal 12kW RW701A-04 - 4.5' Antenna 242J159098A ?15M Cable DC Power Cable Quick Reference guide Operation manual Normalized SKU: T2010A4UPC Code: 010407320861

SI-TEX T2010A-6 Radar ArraySi-Tex T2010A-6 10.4" Display 12kW Open Array Radar with 6.5' AntennaModel: T2010A-6 Dual-Speed antenna with 48-rpm capability for high speed/river operations Split-screen display of long- and short-range targets simultaneously True-Trail Function identifies moving targets Features include Interference Rejection, Target Expansion, Parallel Index, True/Relative Bearing Standard AIS Interface module capable of tracking 200 targets***** Optional 50-target Automatic Tracking Aid (ATA). Specifications Scanner 6.5' Open Array Peak Power Output 12kW Output Frequency 9410 +/- 30MHz Beam Width 1.2° Horzontal, 22° Vertical Rotation 24 or 48 RPM Pulse width .08, 0.15, 0.3, 0.5, 1 usec IF Frequency 60MHz Range Accuracy Better than 8m or 1% of range scale selected, whichever is greaer Minimum Detecting Distance 25m Display Unit Size/Type 10.4" TFT Color LCD Resolution 480 x 640 Display modes Heads up, North up*, Course Up*, WPT up** Dimensions 12 19/32" x12 19/32" x 5 39/64" Power 10.8 - 31.2vDC Power Consumption 130 watts or less *Requires heading, speed, and/or position signal input from external equipment including GPS Compass depending on application of user. **Requires waypoint data input. What's in the Box: MRD-104 Display RB718A - Pedestal 12kW RW701A-06 - 6.5' Antenna 242J159098A ?15M Cable DC Power Cable Quick Reference guide Operation manual Normalized SKU: T2010A6UPC Code: 0104073208678

SI-TEX T2060A-6 Radar ArraySi-Tex T2060A-6 10.4" Display 6kW Open Array Radar with 6.5' AntennaModel: T2060A-6 Dual-Speed antenna with 48-rpm capability for high speed/river operations Split-screen display of long- and short-range targets simultaneously True-Trail Function identifies moving targets Features include Interference Rejection, Target Expansion, Parallel Index, True/Relative Bearing Standard AIS Interface module capable of tracking 200 targets***** Optional 50-target Automatic Tracking Aid (ATA). Specifications Scanner 6.5' Open Array Peak Power Output 6kW Output Frequency 9410 +/- 30MHz Beam Width 1.2° Horzontal, 22° Vertical Rotation 24 or 48 RPM Pulse width .08, 0.15, 0.3, 0.5, 1 usec IF Frequency 60MHz Range Accuracy Better than 8m or 1% of range scale selected, whichever is greaer Minimum Detecting Distance 25m Display Unit Size/Type 10.4" TFT Color LCD Resolution 480 x 640 Display modes Heads up, North up*, Course Up*, WPT up** Dimensions 12 19/32" x12 19/32" x 5 39/64" Power 10.8 - 31.2vDC Power Consumption 110 watts or less *Requires heading, speed, and/or position signal input from external equipment including GPS Compass depending on application of user. **Requires waypoint data input. What's in the Box: MRD-104 Display RB717A - Pedestal 6kW RW701A-06 - 6.5' Antenna 242J159098A ?15M Cable DC Power Cable Quick Reference guide Operation manual Normalized SKU: T2060A6

SI-TEX 223346R2 AutopilotsSitex 12vDC Variable Flow Solenoid Valve System #223346R2Normalized SKU: 223346R2

Download LiteratureSI-TEX MDS-15WIFI Radar Dome4kW 20" Digital Radome Radar with Internal WiFi Module for all NavPro Units and 15M CableFeatures: High-Performance Digital Signal Processing Compatible with All SI-TEX NavPro Units Multi-Speed Antenna 4kW High Power Output Ranges from 1/8th of a mile to 36 miles Compact Light Weight 20” Radome WiFi Connectivity 2-Year Warranty Normalized SKU: MDS15WIFIUPC Code: 010407340029SI-TEX MDS-15WIFI Literature Download Quick Reference Guide

SI-TEX MDS-12WIFI Navigational Instruments4kW Hi-Res 24" Digital Radome Radar with Internal WiFi Module & 10M Cable for All NavPro UnitsFeatures: Adjustable VRM and EBL function provides precise range and bearing information to any target displayed Target intensity is shown in color shades to assist the operator in differentiating between large and small vessels and weather severity Other features include interference rejection caused by other radars operating nearby, FTC to reduce Rain Clutter and STC to pick out targets hidden by high seas and spray 24" 4kW Hi-Res Radome Radar Includes Internal WiFi Module Specifically made for SI-TEX NavPro Units Normalized SKU: MDS12WIFIUPC Code: 010407340012

SI-TEX 710-0162-10 Mounting HardwareSitex 710-0162-10 Surface Mount for V200 #710-0162-10Normalized SKU: 710016210

SI-TEX SVS-880CFE ChartplottersSI-TEX SVS-880CFE 8" Color Plotter Sonar With External Antenna Model: SVS-880CFE 10.1" high-resolution color LCD 52-channel GPS "Dual fuel" charting the C-MAP and Navionics cartography Pre-loaded w/Navionics Gold North American Chart Card Global GPS compatibility Brilliant LED backlighting for daylight readability Easy, intuitive operation and control Video input for underwater and on-deck cameras Specifications Display type 8" Color Resolution SVGA 800 x 600 GPS Channels 52 Support DGPS, SBAS(EGNOS,WAAS, MASA, GAGAN) Nav update 1Hz, 5Hz Chartplotter Display modes True motion / N/S/E/W up / Course up / Head up Map scale 0.05nm to 1500nm Waypoints 20,000 Track points 50,000 Routes 100 Cartography Standard w/Navionics Gold C-MAP MAX optional Output data NMEA-0183 Input data NMEA-0183 Alarms Arrival, Anchor, XTE, Interval timer, Userline Sonar Specifications Display mode Normal (single/dual-frequency), Bottom-lock. Bottom-zoom, A-scope frequency 50 and 200 KHz (single or dual) Output power 600W Input Voltage 12-36vdc Input Draw 6W Normalized SKU: SVS880CFEUPC Code: 010407102207
