Pacer Group
Pacer Beige 2 AWG Ferrule 16mm 10-pk #TFRL2-16MM-10
$10.76
$12.84
Download Literature Watch VideoPacer Group TFRL2-16MM-10 Terminals & KitsBeige 2 AWG Wire Ferrule - 16mm Length - 10 PackWire fraying can quickly become a problem when dealing with IEC (European)-style terminal blocks. As the wire frays, the connection becomes weaker, and the problem will need to be addressed. But all that can be prevented. How? By utilizing wire ferrules. Wire ferrules are a type of terminal that prevents wire fraying. It covers the stranded wire and creates a solid, connected piece. In a sense, wire ferrules make stranded wire behave like solid wire. This is important, especially when working with IEC terminal blocks.How are wire ferrules properly used? The first step is to strip the wire to the correct length. Now slide the ferrule over the exposed wire. Make sure that the nylon casing butts up to the wire insulation. Once set, crimp using the proper tool. Using the proper tool is important, as, without the proper pressure, the wire may not create a solid connection. Proper crimping pressure and technique are key to ensuring continued performance. Once properly crimped, users can add heat shrink for added protection if they choose. Features:
Prevent strand separation while minimizing strand breakage
Insulated ferrules provide additional electrical insulation
Increase connection reliability when terminating stranded wire in terminal blocks
Specifications:
Package Size: 10
Wire Size (AWG): 2
Insulation Color: Beige
Ferrule Length: 16mm (0.63 in.)
Stripping Length: 18mm (0.75 in.)
Normalized SKU: TFRL216MM10UPC Code: 840248215282Pacer Group TFRL2-16MM-10 Literature Download Quick Reference GuidePacer Group TFRL2-16MM-10 Video
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer Red 16 AWG Ferrule 8mm 25-pk #TFRL16-8MM-25
$3.50
$4.12
Download Literature Watch VideoPacer Group TFRL16-8MM-25 Terminals & KitsRed 16 AWG Wire Ferrule - 8mm Length - 25 PackWire fraying can quickly become a problem when dealing with IEC (European)-style terminal blocks. As the wire frays, the connection becomes weaker, and the problem will need to be addressed. But all that can be prevented. How? By utilizing wire ferrules. Wire ferrules are a type of terminal that prevents wire fraying. It covers the stranded wire and creates a solid, connected piece. In a sense, wire ferrules make stranded wire behave like solid wire. This is important, especially when working with IEC terminal blocks.How are wire ferrules properly used? The first step is to strip the wire to the correct length. Now slide the ferrule over the exposed wire. Make sure that the nylon casing butts up to the wire insulation. Once set, crimp using the proper tool. Using the proper tool is important, as, without the proper pressure, the wire may not create a solid connection. Proper crimping pressure and technique are key to ensuring continued performance. Once properly crimped, users can add heat shrink for added protection if they choose. Features:
Prevent strand separation while minimizing strand breakage
Insulated ferrules provide additional electrical insulation
Increase connection reliability when terminating stranded wire in terminal blocks
Specifications:
Package Size: 25
Wire Size (AWG): 16
Insulation Color: Red
Ferrule Length: 8mm (0.31 in.)
Stripping Length: 10mm (0.39 in.)
Normalized SKU: TFRL168MM25UPC Code: 840248215657Pacer Group TFRL16-8MM-25 Literature Download Quick Reference GuidePacer Group TFRL16-8MM-25 Video
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer Blue 14 AWG Ferrule 8mm 25-pk #TFRL14-8MM-25
$4.79
$5.64
Download Literature Watch VideoPacer Group TFRL14-8MM-25 Terminals & KitsBlue 14 AWG Wire Ferrule - 8mm Length - 25 PackWire fraying can quickly become a problem when dealing with IEC (European)-style terminal blocks. As the wire frays, the connection becomes weaker, and the problem will need to be addressed. But all that can be prevented. How? By utilizing wire ferrules. Wire ferrules are a type of terminal that prevents wire fraying. It covers the stranded wire and creates a solid, connected piece. In a sense, wire ferrules make stranded wire behave like solid wire. This is important, especially when working with IEC terminal blocks.How are wire ferrules properly used? The first step is to strip the wire to the correct length. Now slide the ferrule over the exposed wire. Make sure that the nylon casing butts up to the wire insulation. Once set, crimp using the proper tool. Using the proper tool is important, as, without the proper pressure, the wire may not create a solid connection. Proper crimping pressure and technique are key to ensuring continued performance. Once properly crimped, users can add heat shrink for added protection if they choose. Features:
Prevent strand separation while minimizing strand breakage
Insulated ferrules provide additional electrical insulation
Increase connection reliability when terminating stranded wire in terminal blocks
Specifications:
Package Size: 25
Wire Size (AWG): 14
Insulation Color: Blue
Ferrule Length: 8mm (0.31 in.)
Stripping Length: 10mm (0.39 in.)
Normalized SKU: TFRL148MM25UPC Code: 840248215664Pacer Group TFRL14-8MM-25 Literature Download Quick Reference GuidePacer Group TFRL14-8MM-25 Video
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer Grey 12 AWG Ferrule 10mm 25-pk #TFRL12-10MM-25
$5.56
$6.54
Download Literature Watch VideoPacer Group TFRL12-10MM-25 Terminals & KitsGrey 12 AWG Wire Ferrule - 10mm Length - 25 PackWire fraying can quickly become a problem when dealing with IEC (European)-style terminal blocks. As the wire frays, the connection becomes weaker, and the problem will need to be addressed. But all that can be prevented. How? By utilizing wire ferrules. Wire ferrules are a type of terminal that prevents wire fraying. It covers the stranded wire and creates a solid, connected piece. In a sense, wire ferrules make stranded wire behave like solid wire. This is important, especially when working with IEC terminal blocks.How are wire ferrules properly used? The first step is to strip the wire to the correct length. Now slide the ferrule over the exposed wire. Make sure that the nylon casing butts up to the wire insulation. Once set, crimp using the proper tool. Using the proper tool is important, as, without the proper pressure, the wire may not create a solid connection. Proper crimping pressure and technique are key to ensuring continued performance. Once properly crimped, users can add heat shrink for added protection if they choose. Features:
Prevent strand separation while minimizing strand breakage
Insulated ferrules provide additional electrical insulation
Increase connection reliability when terminating stranded wire in terminal blocks
Specifications:
Package Size: 25
Wire Size (AWG): 12
Insulation Color: Grey
Ferrule Length: 10mm (0.39 in.)
Stripping Length: 12mm (0.47 in.)
Normalized SKU: TFRL1210MM25UPC Code: 840248215671Pacer Group TFRL12-10MM-25 Literature Download Quick Reference GuidePacer Group TFRL12-10MM-25 Video
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer Black 10 AWG Ferrule 10mm 25-pk #TFRL10-12MM-25
$7.58
$8.92
Download Literature Watch VideoPacer Group TFRL10-12MM-25 Terminals & KitsBlack 10 AWG Wire Ferrule - 10mm Length - 25 PackWire fraying can quickly become a problem when dealing with IEC (European)-style terminal blocks. As the wire frays, the connection becomes weaker, and the problem will need to be addressed. But all that can be prevented. How? By utilizing wire ferrules. Wire ferrules are a type of terminal that prevents wire fraying. It covers the stranded wire and creates a solid, connected piece. In a sense, wire ferrules make stranded wire behave like solid wire. This is important, especially when working with IEC terminal blocks.How are wire ferrules properly used? The first step is to strip the wire to the correct length. Now slide the ferrule over the exposed wire. Make sure that the nylon casing butts up to the wire insulation. Once set, crimp using the proper tool. Using the proper tool is important, as, without the proper pressure, the wire may not create a solid connection. Proper crimping pressure and technique are key to ensuring continued performance. Once properly crimped, users can add heat shrink for added protection if they choose. Features:
Prevent strand separation while minimizing strand breakage
Insulated ferrules provide additional electrical insulation
Increase connection reliability when terminating stranded wire in terminal blocks
Specifications:
Package Size: 25
Wire Size (AWG): 10
Insulation Color: Black
Ferrule Length: 12mm (0.47 in.)
Stripping Length: 14mm (0.59 in.)
Normalized SKU: TFRL1012MM25UPC Code: 840248215688Pacer Group TFRL10-12MM-25 Literature Download Quick Reference GuidePacer Group TFRL10-12MM-25 Video
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer DT Deutsch Plug Repair Kit 14-18 AWG 8-Position #TDT06F-8RS
$19.47
$23.24
Download LiteraturePacer Group TDT06F-8RS Terminals & KitsDT Deutsch Plug Repair Kit - 14-18 AWG (8 Position)Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 20-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (20-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.Features:
Packs include all parts needed to assemble a connector
One to two extra terminals
Cavity plugs to seal open circuits
Applications:
Wire-to-wire applications
Enclosed connectors offer field-proven reliability and rugged quality
Compliances:
Ingress Protection (IP) Level: IP68 and IP6K9K
EU RoHS/ELV
Standard UL-94 Recognized
Characteristics:
Wedge locks ensure contact alignment and retention
Redundant Silicone Seals
Hand-insertable and removable contacts
Technical Specifications:
Number of Cavities: 8
Housing: Rectangular receptacle, plastic reinforced with glass fiber
Contact Size: 16 (13 amp)
Wire Size: 14 AWG
Holds Pin/Socket: Sockets
Operating Temperature: -55°C to 125°C
Contents:
(1) 8 pos. plug
(1) 8 pos. wedge lock
(10) sockets
(4) cavity plugs
Normalized SKU: TDT06F8RSUPC Code: 840248215039Pacer Group TDT06F-8RS Literature Download Quick Reference Guide
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer DT Deutsch Plug Repair Kit 14-18 AWG 4-Position #TDT06F-4RS
$8.46
$10.10
Download LiteraturePacer Group TDT06F-4RS Terminals & KitsDT Deutsch Plug Repair Kit - 14-18 AWG (4 Position)Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 20-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (20-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.Features:
Packs include all parts needed to assemble a connector
One to two extra terminals
Cavity plugs to seal open circuits
Applications:
Wire-to-wire applications
Enclosed connectors offer field-proven reliability and rugged quality
Compliances:
Ingress Protection (IP) Level: IP68 and IP6K9K
EU RoHS/ELV
Standard UL-94 Recognized
Characteristics:
Wedge locks ensure contact alignment and retention
Redundant Silicone Seals
Hand-insertable and removable contacts
Technical Specifications:
Number of Cavities: 4
Housing: Rectangular receptacle, plastic reinforced with glass fiber
Contact Size: 16 (13 amp)
Wire Size: 14 AWG
Holds Pin/Socket: Sockets
Operating Temperature: -55°C to 125°C
Contents:
(1) 4 pos. plug
(1) 4 pos. wedge lock
(5) sockets
(2) cavity plugs
Normalized SKU: TDT06F4RSUPC Code: 840248214995Pacer Group TDT06F-4RS Literature Download Quick Reference Guide
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer DT Deutsch Plug Repair Kit 14-18 AWG 6-Position #TDT06F-6RS
$17.17
$20.50
Download LiteraturePacer Group TDT06F-6RS Terminals & KitsDT Deutsch Plug Repair Kit - 14-18 AWG (6 Position)Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 20-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (20-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.Features:
Packs include all parts needed to assemble a connector
One to two extra terminals
Cavity plugs to seal open circuits
Applications:
Wire-to-wire applications
Enclosed connectors offer field-proven reliability and rugged quality
Compliances:
Ingress Protection (IP) Level: IP68 and IP6K9K
EU RoHS/ELV
Standard UL-94 Recognized
Characteristics:
Wedge locks ensure contact alignment and retention
Redundant Silicone Seals
Hand-insertable and removable contacts
Technical Specifications:
Number of Cavities: 6
Housing: Rectangular receptacle, plastic reinforced with glass fiber
Contact Size: 16 (13 amp)
Wire Size: 14 AWG
Holds Pin/Socket: Sockets
Operating Temperature: -55°C to 125°C
Contents:
(1) 6 pos. plug
(1) 6 pos. wedge lock
(8) sockets
(3) cavity plugs
Normalized SKU: TDT06F6RSUPC Code: 840248215015Pacer Group TDT06F-6RS Literature Download Quick Reference Guide
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer DT Deutsch Plug Repair Kit 14-18 AWG 3-Position #TDT06F-3RS
$10.73
$12.80
Download LiteraturePacer Group TDT06F-3RS Terminals & KitsDT Deutsch Plug Repair Kit - 14-18 AWG (3 Position)Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 20-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (20-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.Features:
Packs include all parts needed to assemble a connector
One to two extra terminals
Cavity plugs to seal open circuits
Applications:
Wire-to-wire applications
Enclosed connectors offer field-proven reliability and rugged quality
Compliances:
Ingress Protection (IP) Level: IP68 and IP6K9K
EU RoHS/ELV
Standard UL-94 Recognized
Characteristics:
Wedge locks ensure contact alignment and retention
Redundant Silicone Seals
Hand-insertable and removable contacts
Technical Specifications:
Number of Cavities: 3
Housing: Rectangular receptacle, plastic reinforced with glass fiber
Contact Size: 16 (13 amp)
Wire Size: 14 AWG
Holds Pin/Socket: Sockets
Operating Temperature: -55°C to 125°C
Contents:
(1) 3 pos. plug
(1) 3 pos. wedge lock
(4) sockets
(1) cavity plug
Normalized SKU: TDT06F3RSUPC Code: 840248214971Pacer Group TDT06F-3RS Literature Download Quick Reference Guide
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer DT Deutsch Plug Repair Kit 14-18 AWG 2-Position #TDT06F-2RS
$7.87
$9.26
Pacer Group TDT06F-2RS Terminals & KitsDT Deutsch Plug Repair Kit - 14-18 AWG (2 Position)Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 20-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (20-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.Features:
Packs include all parts needed to assemble a connector
One to two extra terminals
Cavity plugs to seal open circuits
Applications:
Wire-to-wire applications
Enclosed connectors offer field-proven reliability and rugged quality
Compliances:
Ingress Protection (IP) Level: IP68 and IP6K9K
EU RoHS/ELV
Standard UL-94 Recognized
Characteristics:
Wedge locks ensure contact alignment and retention
Redundant Silicone Seals
Hand-insertable and removable contacts
Technical Specifications:
Number of Cavities: 2
Housing: Rectangular receptacle, plastic reinforced with glass fiber
Contact Size: 16 (13 amp)
Wire Size: 14 AWG
Holds Pin/Socket: Sockets
Operating Temperature: -55°C to 125°C
Contents:
(1) 2 pos. plug
(1) 2 pos. wedge lock
(3) sockets
Normalized SKU: TDT06F2RSUPC Code: 840248214957
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer DT Deutsch Plug Repair Kit 14-18 AWG 12-Position #TDT06F-12RS
$23.54
$28.10
Download LiteraturePacer Group TDT06F-12RS Terminals & KitsDT Deutsch Plug Repair Kit - 14-18 AWG (12 Position)Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 20-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (20-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.Features:
Packs include all parts needed to assemble a connector
One to two extra terminals
Cavity plugs to seal open circuits
Applications:
Wire-to-wire applications
Enclosed connectors offer field-proven reliability and rugged quality
Compliances:
Ingress Protection (IP) Level: IP68 and IP6K9K
EU RoHS/ELV
Standard UL-94 Recognized
Characteristics:
Wedge locks ensure contact alignment and retention
Redundant Silicone Seals
Hand-insertable and removable contacts
Technical Specifications:
Number of Cavities: 12
Housing: Rectangular receptacle, plastic reinforced with glass fiber
Contact Size: 16 (13 amp)
Wire Size: 14 AWG
Holds Pin/Socket: Sockets
Operating Temperature: -55°C to 125°C
Contents:
(1) 12 pos. plug
(1) 12 pos. wedge lock
(14) sockets
(6) cavity plugs
Normalized SKU: TDT06F12RSUPC Code: 840248214933Pacer Group TDT06F-12RS Literature Download Quick Reference Guide
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer DT Deutsch Receptacle Repair Kit 14-18 AWG 8-Position #TDT04F-8RP
$15.05
$17.96
Download LiteraturePacer Group TDT04F-8RP Terminals & KitsDT Deutsch Receptacle Repair Kit - 14-18 AWG (8 Position)Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 18-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (18-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.Features:
Packs include all parts needed to assemble a connector
One to two extra terminals
Cavity plugs to seal open circuits
Applications:
Wire-to-wire applications
Enclosed connectors offer field-proven reliability and rugged quality
Compliances:
Ingress Protection (IP) Level: IP68 and IP6K9K
EU RoHS/ELV
Standard UL-94 Recognized
Characteristics:
Wedge locks ensure contact alignment and retention
Redundant Silicone Seals
Hand-insertable and removable contacts
Technical Specifications:
Number of Cavities: 8
Housing: Rectangular receptacle, plastic reinforced with glass fiber
Contact Size: 16 (13 amp)
Wire Size: 14 AWG
Holds Pin/Socket: Pins
Operating Temperature: -55°C to 125°C
Contents:
(1) 8 pos. receptacle
(1) 8 pos. wedge lock
(10) pins
(4) cavity plugs
Normalized SKU: TDT04F8RPUPC Code: 840248214926Pacer Group TDT04F-8RP Literature Download Quick Reference Guide
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer DT Deutsch Receptacle Repair Kit 14-18 AWG 6-Position #TDT04F-6RP
$10.52
$12.56
Download LiteraturePacer Group TDT04F-6RP Terminals & KitsDT Deutsch Receptacle Repair Kit - 14-18 AWG (6 Position)Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 18-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (18-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.Features:
Packs include all parts needed to assemble a connector
One to two extra terminals
Cavity plugs to seal open circuits
Applications:
Wire-to-wire applications
Enclosed connectors offer field-proven reliability and rugged quality
Compliances:
Ingress Protection (IP) Level: IP68 and IP6K9K
EU RoHS/ELV
Standard UL-94 Recognized
Characteristics:
Wedge locks ensure contact alignment and retention
Redundant Silicone Seals
Hand-insertable and removable contacts
Technical Specifications:
Number of Cavities: 6
Housing: Rectangular receptacle, plastic reinforced with glass fiber
Contact Size: 16 (13 amp)
Wire Size: 14 AWG
Holds Pin/Socket: Pins
Operating Temperature: -55°C to 125°C
Contents:
(1) 6 pos. receptacle
(1) 6 pos. wedge lock
(8) pins
(3) cavity plugs
Normalized SKU: TDT04F6RPUPC Code: 840248214902Pacer Group TDT04F-6RP Literature Download Quick Reference Guide
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer DT Deutsch Receptacle Repair Kit 14-18 AWG 3-Position #TDT04F-3RP
$6.99
$8.22
Download LiteraturePacer Group TDT04F-3RP Terminals & KitsDT Deutsch Receptacle Repair Kit - 14-18 AWG (3 Position)Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 18-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (18-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.Features:
Packs include all parts needed to assemble a connector
One to two extra terminals
Cavity plugs to seal open circuits
Applications:
Wire-to-wire applications
Enclosed connectors offer field-proven reliability and rugged quality
Compliances:
Ingress Protection (IP) Level: IP68 and IP6K9K
EU RoHS/ELV
Standard UL-94 Recognized
Characteristics:
Wedge locks ensure contact alignment and retention
Redundant Silicone Seals
Hand-insertable and removable contacts
Technical Specifications:
Number of Cavities: 3
Housing: Rectangular receptacle, plastic reinforced with glass fiber
Contact Size: 16 (13 amp)
Wire Size: 14 AWG
Holds Pin/Socket: Pins
Operating Temperature: -55°C to 125°C
Contents:
(1) 3 pos. receptacle
(1) 3 pos. wedge lock
(4) pins
(1) cavity plug
Normalized SKU: TDT04F3RPUPC Code: 840248214865Pacer Group TDT04F-3RP Literature Download Quick Reference Guide
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer DT Deutsch Receptacle Repair Kit 14-18 AWG 4-Position #TDT04F-4RP
$8.35
$9.97
Download LiteraturePacer Group TDT04F-4RP Terminals & KitsDT Deutsch Receptacle Repair Kit - 14-18 AWG (4 Position)Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 18-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (18-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.Features:
Packs include all parts needed to assemble a connector
One to two extra terminals
Cavity plugs to seal open circuits
Applications:
Wire-to-wire applications
Enclosed connectors offer field-proven reliability and rugged quality
Compliances:
Ingress Protection (IP) Level: IP68 and IP6K9K
EU RoHS/ELV
Standard UL-94 Recognized
Characteristics:
Wedge locks ensure contact alignment and retention
Redundant Silicone Seals
Hand-insertable and removable contacts
Technical Specifications:
Number of Cavities: 4
Housing: Rectangular receptacle, plastic reinforced with glass fiber
Contact Size: 16 (13 amp)
Wire Size: 14 AWG
Holds Pin/Socket: Pins
Operating Temperature: -55°C to 125°C
Contents:
(1) 4 pos. receptacle
(1) 4 pos. wedge lock
(5) pins
(2) cavity plugs
Normalized SKU: TDT04F4RPUPC Code: 840248214889Pacer Group TDT04F-4RP Literature Download Quick Reference Guide
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer DT Deutsch Receptacle Repair Kit 14-18 AWG 2-Position #TDT04F-2RP
$5.32
$6.26
Download LiteraturePacer Group TDT04F-2RP Terminals & KitsDT Deutsch Receptacle Repair Kit - 14-18 AWG (2 Position)Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wire. However, DT series connectors are designed for 18-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (18-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.Features:
Packs include all parts needed to assemble a connector
One to two extra terminals
Cavity plugs to seal open circuits
Applications:
Wire-to-wire applications
Enclosed connectors offer field-proven reliability and rugged quality
Compliances:
Ingress Protection (IP) Level: IP68 and IP6K9K
EU RoHS/ELV
Standard UL-94 Recognized
Characteristics:
Wedge locks ensure contact alignment and retention
Redundant Silicone Seals
Hand-insertable and removable contacts
Technical Specifications:
Number of Cavities: 2
Housing: Rectangular receptacle, plastic reinforced with glass fiber
Contact Size: 16 (13 amp)
Wire Size: 14 AWG
Holds Pin/Socket: Pins
Operating Temperature: -55°C to 125°C
Contents:
(1) 2 pos. receptacle
(1) 2 pos. wedge lock
(3) pins
Normalized SKU: TDT04F2RPUPC Code: 840248214841Pacer Group TDT04F-2RP Literature Download Quick Reference Guide
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer DT Deutsch Receptacle Repair Kit 14-18 AWG 12-Position #TDT04F-12RP
$18.48
$22.05
Download LiteraturePacer Group TDT04F-12RP Terminals & KitsDT Deutsch Receptacle Repair Kit - 14-18 AWG (12 Position)Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 18-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (18-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.Features:
Packs include all parts needed to assemble a connector
One to two extra terminals
Cavity plugs to seal open circuits
Applications:
Wire-to-wire applications
Enclosed connectors offer field-proven reliability and rugged quality
Compliances:
Ingress Protection (IP) Level: IP68 and IP6K9K
EU RoHS/ELV
Standard UL-94 Recognized
Characteristics:
Wedge locks ensure contact alignment and retention
Redundant Silicone Seals
Hand-insertable and removable contacts
Technical Specifications:
Number of Cavities: 12
Housing: Rectangular receptacle, plastic reinforced with glass fiber
Contact Size: 16 (13 amp)
Wire Size: 14 AWG
Holds Pin/Socket: Pins
Operating Temperature: -55°C to 125°C
Contents:
(1) 12 pos. receptacle
(1) 12 pos. wedge lock
(14) pins
(6) cavity plugs
Normalized SKU: TDT04F12RPUPC Code: 840248214827Pacer Group TDT04F-12RP Literature Download Quick Reference Guide
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer DT Deutsch Socket for 14-18 AWG Plug Size 16 25-pk #T14DT-S-25
$22.57
$26.94
Pacer Group T14DT-S-25 Terminals & KitsDT Deutsch Socket for 14-18 AWG Plug - Size 16 Contact (25 Pack)Deutsch machined contacts are for use with almost the entire line of Deutsch connectors and are ideal for marine conditions. They are known for their reliability and durability, which are just a few of the reasons that professionals turn to these contacts for repeatable and reliable results. Another benefit of these contacts is that they are simple to use and require little time for installation.Features:
Easy to install
Field serviceable
Applications:
Cable-to-cable applications
Enclosed connectors offer field-proven reliability and rugged quality
Compliances:
Ingress Protection (IP) Level: IP68 and IP6K9K
RoHS
UL Recognized
Characteristics:Hand-insertable contactsSpecifications:
Package Size: 25 sockets
Contact Size: 16
Wire Size: 14
Operating Temperature: -55°C to 125°C
Current Rating: 7.5-25
Normalized SKU: T14DTS25UPC Code: 840248215183
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Pacer Group
Pacer DT Deutsch Pin for 14-18 AWG Receptacle 25-pk #T14DT-P-25
$15.61
$18.63
Pacer Group T14DT-P-25 Terminals & KitsDT Deutsch Pin for 14-18 AWG Receptacle - Size 16 Contact (25 Pack)Deutsch machined contacts are for use with almost the entire line of Deutsch connectors and are ideal for marine conditions. They are known for their reliability and durability, which are just a few of the reasons that professionals turn to these contacts for repeatable and reliable results. Another benefit of these contacts is that they are simple to use and require little time for installation.Features:
Easy to install
Field serviceable
Applications:
Cable-to-cable applications
Enclosed connectors offer field-proven reliability and rugged quality
Compliances:
Ingress Protection (IP) Level: IP68 and IP6K9K
RoHS
UL Recognized
Characteristics:Hand-insertable contactsSpecifications:
Package Size: 25 pins
Contact Size: 16
Wire Size: 14
Operating Temperature: -55°C to 125°C
Current Rating: 7.5-25
Normalized SKU: T14DTP25UPC Code: 840248215169
00
DAYS 00
HRS 00
MIN 00
SEC
DAYS 00
HRS 00
MIN 00
SEC
Sierra
Sierra Terminal #EC04670-100
$13.24
$15.80
Sierra EC04670-100 Terminals & Kits
Red, Stud Size 5/16", Wire gauge 22-18
This product replaces:
808282190873, 11-EC04670-100
Normalized SKU: EC04670100UPC Code: 808282190873
Frequently Asked Questions
First Choice Marine is an online marine retailer carrying a diverse line of marine parts and accessories and related items from industry-respected and demanded manufacturers and suppliers. Through our diverse distributor network, we are able to access over 150,000 items, including our current site inventory, new products being added, and special order items. If you need it on your boat... we are your one-stop shop!
Yes, we offer FREE Shipping on most orders over $149 to US-48*.
Each product displays a shipping status message, just above the item price. Below is the meaning for each of these codes.
- Qualifies for Free Shipping: This item qualifies for free shipping when the order is $149+
- Qualifies for Free Ground Shipping: This item qualifies for free ground shipping when the order is $149+.
- Oversized - Not Qualified for Free Shipping: This item is too large/heavy to qualify for free shipping
- Hazardous Item - Not Qualified for Free Shipping: This item is hazardous and does not qualify for free shipping
- Truck Freight - Not Qualified for Free Shipping: This item has to be shipped via truck freight. Please contact us for a quote
- In-Store Pickup Only: This item can only be picked up in our Grain Valley, MO retail store
Below the price of the item, on the product page, there is a message indicating the availability of the product.
The quantity on hand is updated as inventory events happen and matches what we have available. If you have urgent needs and we are close to what you need, contact us, and we can confirm stock.
We offer a hassle-free return policy. If you're not completely satisfied with your purchase, you can return it within 30 days for a full refund or exchange.
If you need to return an item, please follow the guidelines here so we can process a prompt refund and assist you in finding the correct item.
Free Shipping
On most orders $149+ to the continental 48 US states.Secure Shopping
Fast, secure checkout with a variety of payment methods.Shop with confidence
25+ years serving the marine industry.Support center
Need help? Contact us via live chat, phone, or email.
