Download LiteratureVictron Energy SCC115110411 Solar PowerSmartSolar MPPT 150/100-TR VE.CanThe MPPT VE.Can SmartSolar charger uses the latest and fastest technology to convert energy from a solar array into energy that optimally charges battery banks.The SmartSolar charge controller will even recharge a severely depleted battery. It can operate with a battery voltage as low as 0 Volts, provided the cells are not permanently sulfated or otherwise damaged.MPPT: Ultra Fast Maximum Power Point TrackingThe MPPT VE.Can SmartSolar charger connects to a PV array of 150 or 250 Volt Voc and will automatically detect and charge your 12, 24, or 48V battery bank with current ranging from 70 to 100A depending on the model.The charge settings are fully programmable and can even be set up for different battery chemistries, like lead-acid, lithium, and others.Control Your Charger RemotelyThe MPPT VE.Can SmartSolar charger can be remotely controlled and configured over Bluetooth via the VictronConnect App. This allows device set-up, management, and at-a-glance information, such as battery voltage and current, PV voltage and current, and historical data.Daisy Chain Additional UnitsThe VE.Can SmartSolar charger is equipped with CAN bus ports. This allows for communication with additional VE.Can SmartSolar chargers. The additional units are simply "daisy-chained" to each other with a single RJ45 cable between the individual units.When connected to each other, all individual VE.Can SmartSolar chargers, will synchronize their charge stages. They can also send their data, via a single cable, to a GX monitoring device.Remote Monitoring and ControlIf the GX device is connected to the internet, the Victron Remote Management Portal (VRM) provides access to the full power of your solar charger(s).SmartSolar Control DisplayThe VE.Can SmartSolar charger is also equipped with a VE.Direct port like our other MPPT solar chargers. This port can be for single-unit monitoring or for streetlight control. The remote on/off connector can be externally controlled by a third-party device like a lithium battery. An optional plug-in LCD display/control provides live data, setup, and management, straight from the face of the device.Please contact your dealer for any returns, repairs or support issues related to this product. Normalized SKU: SCC115110411UPC Code: 8719076050353Victron Energy SCC115110411 Literature Download Owners Manual Product Brochure

Download LiteratureSamlex America SCC-1208L Solar PowerCharge Controller - 12V - 8AThe SCC-1208L Charge Controller is Micro-controller based for automatic, intelligent operation designed for 12 V nominal solar panels and 12 V battery systems. It has 3 Stage charging (Bulk, Absorption, Float) for 100% return of capacity and long battery life. It can be used with 2 types of batteries: Flooded/Web Cell or Sealed AGM. The SCC-1208L can manage up to 150 Watts of Solar Power.Features: Micro-controller based for automatic, intelligent operation Designed for 12V nominal solar panels and 12V battery systems 3 Stage charging (Bulk, Absorption, Float) for 100% return of capacity and long battery life For use with 2 types of batteries: Flooded/Wet Cell or Sealed AGM Totally sealed, splash proof weather resistant design (Ingress Protection Rating IP65) Automatically turns on lights when dark and turns off during the day Mosfet based reverse current blocking prevents night-time battery discharge and lowers power loss Protections: Overload, Over-Temperature, Battery Under/Over Voltage, Reverse Polarity Wide operating temperature range of -40°C to + 60°C Specifications: Input: 12V Amps: 8 Amps Weight: 0.28 (lbs) / 0.13 (kg) Dimensions: 3.8 x 1.8 x 1.0 (in) Dimensions: 9.65 x 4.57 x 2.54 (cm) Safety: FCC, CE, IP65 Warranty: 5 Year Limited Applications: Off-grid mobile rural systems Rural electrification Power supply for remote equipment Monitoring systems for the oil & gas industry Traffic, security, environment, and other remote monitoring and signaling systems Water pumping systems WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: SCC1208LUPC Code: 622988086939Samlex America SCC-1208L Literature Download Owners Manual Product Brochure

Xantrex 710-3024-01 Solar Power30A MPPT Charge ControllerDesigned to charge lithium-ion batteries including LIFePO4, the 30 A MPPT (Maximum Power Point Tracking) charge controller features an industry-leading 98% charging efficiency and dual bank output to charge and maintain house and starter batteries. The Xantrex Solar MPPT Charge Controller 30 features advanced Maximum Power Point Tracking (MPPT) technology, providing an instant upgrade to your solar system with up to 30% more power compared to PWM charge controllers. Offering greater flexibility, simplicity, and efficiency in PV array designs, higher voltage PV arrays can be used up to 72V (nominal). Equipped with dual-battery bank charging ports ideal for simultaneously charging and maintaining 12V house and starter batteries, best-in-class PV array and battery protection, and a built-in LCD display providing real-time system data. Optional accessories include a remote battery temperature sensor and remote panel. The Xantrex Solar Charge Controllers are compatible with all types and makes of solar panels from all manufacturers. Below is a list of available Xantrex Solar Panel Kits and Expansion Kits. Consider pairing this MPPT charge controller with Xantrex Solar Panels. Features: Advanced Maximum Power Point Tracking (MPPT) technology increasing daily energy harvest by 20-30% compared to PWM technology Dual-battery bank charging to simultaneously charge house and starter batteries Best-in-class PV array and battery protections House battery types supported: Sealed (AGM), Gel, Flooded, Lithium Iron Phosphate(LiFePO4) 5-year warranty Normalized SKU: 710302401UPC Code: 715535906917

Xantrex 709-3024-01 Solar Power30A PWM Charge ControllerDesigned to charge lithium-ion batteries including LIFePO4, the 30 A PWM (Pulse Width Modulation) charge controller features a flush mount industrial design for a clean finish. The Xantrex Solar PWM Charge Controller 30 features a highly-efficient PWM charging mode, designed specifically for an aesthetically clean and integrated look in an RV, boat, and truck. Intuitive and easy-to-program to get your solar system harvesting energy as quickly as possible. Equipped with best-in-class PV array and battery protections and a built-in LCD display providing real-time system data. Optional accessories include a remote battery temperature sensor.Features: Advanced multi-stage charging technology, Bulk, Absorption, Float, Equalization Battery types supported: Sealed (AGM), Gel, Flooded, Lithium Iron Phosphate (LiFePO4) Best-in-class PV array and battery protections Aesthetic flush-mount industrial design 5-year warranty Normalized SKU: 709302401UPC Code: 715535906870

Xantrex 710-0010 Solar PowerMPPT Charge Controller Remote Panel with 25' Cable PPT Remote DisplayProvides real-time data about your solar system. Designed for quick and easy installation. Includes 25' cable. Normalized SKU: 7100010UPC Code: 715535906993

Samlex America SBC-2 Solar PowerMC4 Connector Systems used to connect Samlex Solar Panels consist of male and female MC4 connectors and branch connectors. This type of connector system is easy to install and uses “snap-in” safety locking tabs to lock two mating connectors, thereby avoiding unintentional disconnection. Also, the mating contacts are sealed against an ingress of dust and water. Pair of male and female connectors Mating contacts are sealed against an ingress of dust and water Easy to install Two-year limited warranty Normalized SKU: SBC2UPC Code: 622988180712

Samlex America SM5-KIT Solar PowerThe SM5-KIT includes four sturdy 5-hole Aluminum mounting brackets with stainless steel hardware required to securely fasten a solar panel to the roof of your Recreational Vehicle or any other flat surface. Installation requires a 7/16" wrench, a hand drill, pliers, a 3/8" wrench, a 1/2" drill bit, and a punch or awl. Includes limited two-year warranty. Flat mount solar panel kit Includes brackets and hardware Panels sold separately Two-year limited warranty Normalized SKU: SM5KITUPC Code: 622988180637

Victron Energy SCA520300000 Solar PowerMC4 Solar Connect Pair - 1 x Male & 1 x FemaleMC4 connectors are single-contact electrical connectors commonly used for connecting solar panels. Normalized SKU: SCA520300000

Download LiteratureSamlex America ADJ-28 Solar Power28" Adjustable Solar Panel Tilt MountSamlex Solar RV panel ADJ-28, tilt mounts are adjustable to fit any of the Samlex solar panels from the off-grid Solar Charging Kits. Features: Convenient - Adjustable Solar Mounts Light - Aluminum Specifications: Weight - 4.8 (lbs) Weight - 2.17 (kg) Dimensions - 28 x 1 x 1 (in) Dimensions - 71.1 x 2.5 x 2.5 (cm) Warranty - 2 Year Limited Normalized SKU: ADJ28UPC Code: 622988180620Samlex America ADJ-28 Literature Download Owners Manual Product Brochure
