Download LiteratureRaymarine E70143 Navigational Instrumentsi40 Depth w/Transom Mount TransducerCompact and feature-packed instruments, the i40 series instruments are smart choice for boaters looking high performance and great value.The i40 series is simple to operate thanks to the use of just three control buttons, i40 has extra-large digits and razor-sharp LCD displays and red backlighting for outstanding visibility in all lighting conditions. These SeaTalk® compatible instruments offer full integration with Raymarine autopilots and navigation equipment. The ultra-sleek design of i40 line is designed to complement our full line of a-Series, c-Series and e-Series Multifunction displays, and looks great on the helm of any boat. All i40 Instruments come with a low-profile surface mounting kit and silicone rubber sun cover. An optional bracket mounting kit is also available separately.i40 Instruments are designed to operate from 12V DC power, and are ultra-efficient drawing less than 0.4 watts for superior run-time and excellent green credentials. The i40 instruments are all covered by Raymarine's industry leading 2-year warranty, upgradeable to 3-years at no charge by registering online with 90 days of purchase. i40 Depth Instrument Raymarine's i40 Depth Instrument is available as a complete system with a thru-hull transducer, transom mount or as a display-only kit enabling you to monitor your boat's depth at a remote location. The i40 Depth Instrument offers easy-to-read displays of current depth, and minimum depth recorded. The unit also offers a convenient shallow depth alarm, deep depth alarm, shallow anchor alarm, and deep anchor alarm. The i40 Depth Instrument offers convenient depth offset controls allowing you to calibrate the readout to compensate for projections (rudders, props, skegs etc.) or to display the depth from the waterline of the vessel.i40 Key Features Ultra-modern design complements Raymarine's latest a-Series, c-Series and e-Series Multifunction display and instrument systems. High contrast LCD displays with large digits for excellent visibility. Red backlighting for outstanding night-time visibility. Simple SeaTalk networking with other Raymarine instruments, autopilots and MFDs. Built-in transducer connections simplify installation. Small form factor saves space at the helm without sacrificing features. Specifications:Depth - Max (Feet) = 400' Frequency = NONE Load Equivalence # (LEN) = NONE Screen Size = 3.7" Shape = NONE Transducer Type = Transom MountNormalized SKU: E70143UPC Code: 723193769256Raymarine E70143 Literature Download  Quick Reference Guide  Owners Manual

  Download LiteratureRaymarine E70064 Navigational Instrumentsi40 Depth DisplayCompact and feature-packed instruments, the i40 series instruments are smart choice for boaters looking high performance and great value.The i40 series is simple to operate thanks to the use of just three control buttons, i40 has extra-large digits and razor-sharp LCD displays and red backlighting for outstanding visibility in all lighting conditions. These SeaTalk® compatible instruments offer full integration with Raymarine autopilots and navigation equipment. The ultra-sleek design of i40 line is designed to complement our full line of a-Series, c-Series and e-Series Multifunction displays, and looks great on the helm of any boat. All i40 Instruments come with a low-profile surface mounting kit and silicone rubber sun cover. An optional bracket mounting kit is also available separately.i40 Instruments are designed to operate from 12V DC power, and are ultra-efficient drawing less than 0.4 watts for superior run-time and excellent green credentials. The i40 instruments are all covered by Raymarine's industry leading 2-year warranty, upgradeable to 3-years at no charge by registering online with 90 days of purchase. i40 Depth Instrument Raymarine's i40 Depth Instrument is available as a complete system with a thru-hull transducer, Transom Mount or as a display-only kit enabling you to monitor your boat's depth at a remote location. The i40 Depth Instrument offers easy-to-read displays of current depth, and minimum depth recorded. The unit also offers a convenient shallow depth alarm, deep depth alarm, shallow anchor alarm, and deep anchor alarm. The i40 Depth Instrument offers convenient depth offset controls allowing you to calibrate the readout to compensate for projections (rudders, props, skegs etc.) or to display the depth from the waterline of the vessel.i40 Key Features Ultra-modern design complements Raymarine's latest a-Series, c-Series and e-Series Multifunction display and instrument systems. High contrast LCD displays with large digits for excellent visibility. Red backlighting for outstanding night-time visibility. Simple SeaTalk networking with other Raymarine instruments, autopilots and MFDs. Built-in transducer connections simplify installation. Small form factor saves space at the helm without sacrificing features. Specifications:Depth - Max (Feet) = 400' Frequency = NONE Load Equivalence # (LEN) = NONE Screen Size = 3.7" Shape = NONE Transducer Type = NONENormalized SKU: E70064UPC Code: 723193730843Raymarine E70064 Literature Download  Quick Reference Guide  Owners Manual

  Download LiteratureRaymarine E70066 Navigational Instrumentsi40 Bidata DisplayCompact and feature-packed instruments, the i40 series instruments are smart choice for boaters looking high performance and great value.The i40 series is simple to operate thanks to the use of just three control buttons, i40 has extra-large digits and razor-sharp LCD displays and red backlighting for outstanding visibility in all lighting conditions. These SeaTalk® compatible instruments offer full integration with Raymarine autopilots and navigation equipment. The ultra-sleek design of i40 line is designed to complement our full line of a-Series, c-Series and e-Series Multifunction displays, and looks great on the helm of any boat. All i40 Instruments come with a low-profile surface mounting kit and silicone rubber sun cover. An optional bracket mounting kit is also available separately.i40 Instruments are designed to operate from 12V DC power, and are ultra-efficient drawing less than 0.4 watts for superior run-time and excellent green credentials. The i40 instruments are all covered by Raymarine's industry leading 2-year warranty, upgradeable to 3-years at no charge by registering online with 90 days of purchase. i40 Bidata Instrument The Raymarine i40 Bidata offers all of the functionality of the Depth and Speed instruments combined in a single space-saving display. Like the other i40 Instruments, the Bidata is available as a complete system with depth and speed transducers or as a display-only solution for remote readout of depth and speed at another location.The i40 Bidata's depth capabilities include easy-to-read displays of current speed, maximum speed, average speed, distance log, trip log as well as water temperature. Bidata also offers depth-related alarms and adjustments including shallow depth alarm, deep depth alarm, shallow anchor alarm, and deep anchor alarm, and depth offset controls. Its speed capabilities include displays of current speed, maximum speed, average speed, distance log, trip log as well as water temperature.i40 Key Features Ultra-modern design complements Raymarine's latest a-Series, c-Series and e-Series Multifunction display and instrument systems. High contrast LCD displays with large digits for excellent visibility. Red backlighting for outstanding night-time visibility. Simple SeaTalk networking with other Raymarine instruments, autopilots and MFDs. Built-in transducer connections simplify installation. Small form factor saves space at the helm without sacrificing features. Specifications:Digital/Analog = Digital Load Equivalence # (LEN) = NONE Screen Size = 3.7" Shape = NONENormalized SKU: E70066UPC Code: 723193730867Raymarine E70066 Literature Download  Quick Reference Guide  Owners Manual

  Download LiteratureRaymarine E70145 Navigational Instrumentsi40 Bidata Display w/Thru-Hull TransducersCompact and feature-packed instruments, the i40 series instruments are smart choice for boaters looking high performance and great value.The i40 series is simple to operate thanks to the use of just three control buttons, i40 has extra-large digits and razor-sharp LCD displays and red backlighting for outstanding visibility in all lighting conditions. These SeaTalk® compatible instruments offer full integration with Raymarine autopilots and navigation equipment. The ultra-sleek design of i40 line is designed to complement our full line of a-Series, c-Series and e-Series Multifunction displays, and looks great on the helm of any boat. All i40 Instruments come with a low-profile surface mounting kit and silicone rubber sun cover. An optional bracket mounting kit is also available separately.i40 Instruments are designed to operate from 12V DC power, and are ultra-efficient drawing less than 0.4 watts for superior run-time and excellent green credentials. The i40 instruments are all covered by Raymarine's industry leading 2-year warranty, upgradeable to 3-years at no charge by registering online with 90 days of purchase. i40 Bidata Instrument The Raymarine i40 Bidata offers all of the functionality of the Depth and Speed instruments combined in a single space-saving display. Like the other i40 Instruments, the Bidata is available as a complete system with depth and speed transducers or as a display-only solution for remote readout of depth and speed at another location.The i40 Bidata's depth capabilities include easy-to-read displays of current speed, maximum speed, average speed, distance log, trip log as well as water temperature. Bidata also offers depth-related alarms and adjustments including shallow depth alarm, deep depth alarm, shallow anchor alarm, and deep anchor alarm, and depth offset controls. Its speed capabilities include displays of current speed, maximum speed, average speed, distance log, trip log as well as water temperature.i40 Key Features Ultra-modern design complements Raymarine's latest a-Series, c-Series and e-Series Multifunction display and instrument systems. High contrast LCD displays with large digits for excellent visibility. Red backlighting for outstanding night-time visibility. Simple SeaTalk networking with other Raymarine instruments, autopilots and MFDs. Built-in transducer connections simplify installation. Small form factor saves space at the helm without sacrificing features. Supplied with:i40 Bidata displayE26009 Low profile thru-hull depth transducerE26008 Low profile thru-hull speed and temp transduceri40 Suncover Specifications:Digital/Analog = Digital Load Equivalence # (LEN) = NONE Screen Size = 3.7" Shape = NONENormalized SKU: E70145UPC Code: 723193769164Raymarine E70145 Literature Download  Quick Reference Guide  Owners Manual

  Download LiteratureDavis Instruments 3155 Navigational InstrumentsJ-BASE for Windex 15This optional mount for Windex 15 provides more versatility and reduces overall weight aloft by 15 grams when substituted for standard Windex 15 mounting base.The J-Base comes with two #10 (5 mm) selftapping screws. Drill a pilot hole in mast, apply silicone sealant or Locktite® and screw into mast. Installation of J-Base can also be accomplished by tapping the mast for 3/16" (5 mm) machine screws or by using epoxy putty to affix base to the mast Specifications:Load Equivalence # (LEN) = NONE Screen Size = NONE Shape = NONE Transducer Type = NONENormalized SKU: 3155UPC Code: 011698001958Davis Instruments 3155 Literature Download  Quick Reference Guide

  Download LiteratureDavis Instruments 1705 Navigational InstrumentsUniversal Masthead MountExtend your Windex 10.Sport or Windex 15 vane away from masthead obstructions and turbulence. The 13" (33 cm) arm comes with hardware allowing side or top mounting and offset angles up to ±20 degrees. May be attached securely to flat, curved, vertical, horizontal, or inclined surfaces. Gain space aloft and improve mounting position of wind finders and other equipment. Mount on the back of the mast for easier viewing from the cockpit. The mount adapts to virtually every masthead situation.Length 13" (33 cm)Weight 3.2 oz (90 g) Boom can be shortened if necessary; complete instructions includedCan be used with Windex Light #3200. Also accommodates Davis J-Base Mounts (using #10 stainless steel screws and nuts, not included) Specifications:Load Equivalence # (LEN) = NONE Screen Size = NONE Shape = NONE Transducer Type = NONENormalized SKU: 1705UPC Code: 011698170500Davis Instruments 1705 Literature Download  Owners Manual

  Download LiteratureDavis Instruments 3150 Navigational InstrumentsWindex 15Windex wind vanes continue to offer exceptional performance at the best value of any wind indicator worldwide. The secret is in the sapphire jewel suspension bearing, large fin-low inertia vane, and easy-to-read, fully adjustable tacking tab system. Windex is the perfect choice for all cruising and racing boats 15' (4.6 meters) and bigger.Reflector tape on the vane and tacking tabs make Windex 15 easy to see day and night. Windex vanes are sturdy and when installed properly, offer many years of use. They have been wind tunnel tested to wind speeds of 80 knots!Windex 15 has a 15" (38 cm) vane. Includes through-bolt or drill and tap mounting socket; 5/16" -18 stainless stud, washers and nut. Stands 12.75" (32 cm) tall and weighs just 3.6 ounces (101 g).A bird-proof spike extends another 10" (24 cm) above the vane to discourage birds from landing. Specifications:Load Equivalence # (LEN) = NONE Screen Size = NONE Shape = NONE Transducer Type = NONENormalized SKU: 3150UPC Code: 011698315000Davis Instruments 3150 Literature Download  Quick Reference Guide  Owners Manual

  Download LiteratureDavis Instruments 3200 Navigational InstrumentsWindex Light (for 3100/3150)Light up the reflector tabs and vane on your Windex for easy viewing at night with Windex Light. Waterproof and non-corroding silver parts give long-life at just 120 ma current draw. Fits under Windex 15, Windex 10 or J-Base™ mounting socket. Specifications:Load Equivalence # (LEN) = NONE Screen Size = NONE Shape = NONE Transducer Type = NONENormalized SKU: 3200UPC Code: 011698320004Davis Instruments 3200 Literature Download  Quick Reference Guide

  Download LiteratureRaymarine E70010 Navigational InstrumentsiTC-5 Instrument Transducer ConverterThe iTC5 Instrument Transducer Converter enables the use of common analog transducer signals with new digital instrument displays like Raymarine's i70 and ST70 Plus. The ultra-compact iTC5 has connections to host the five most common analog transducers; depth, speed/temperature, wind, compass and rudder. The iTC5 instantly converts these 5 analog signals to digital SeaTalkng protocol.In addition to providing analog-to-digital conversion, the iTC5 provides all of the necessary power and communications connections to the transducers. This greatly simplifies the installation of new systems, and also provides a simple and cost-effective means for owners of older analog instrument displays to upgrade to the latest digital display technology. The iTC5 eliminates the need for expensive "smart" transducers or individual instrument pods. Complete control for calibration and alarms is performed through the i70 or ST70 Plus instruments.The iTC5 connects to Raymarine's SeaTalkng network and works with most analog transducers from legacy Raymarine ST30, ST40, ST50, ST60, ST80 and ST290 series instruments. Additionally the iTC5 works with Raymarine fluxgate compass modules as well as rotary and linear rudder feedback transducers to support compass heading and rudder angle instruments.Features: All-in-one analog to digital converter for depth, speed/temperature, wind, compass and rudder transducers Outputs SeaTalkng and NMEA2000 data to digital instruments, MFDs and more Enables easy upgrade of legacy analog instrument displays without replacing transducers SeaTalkng network provides all necessary power and data connections Ideal for use with Raymarine i70 and ST70 Plus digital instrument systems Normalized SKU: E70010UPC Code: 723193701164Raymarine E70010 Literature Download  Quick Reference Guide

  Download LiteratureDavis Instruments 026 Navigational InstrumentsMark 15 Sextant#026This model has many great features including seven large sunshades, a 3 mm x 27 mm star scope, and easy-to-read micrometer drum vernier scale that reads to 2/10 of a minute. The Mark 15 has a 7" (18 cm) frame radius graduated from 120° to -5° and comes with a traditional half-silvered mirror.Comes with instruction booklet. Normalized SKU: 026UPC Code: 011698002603Davis Instruments 026 Literature Download  Owners Manual

  Download LiteratureDavis Instruments 025 Navigational InstrumentsMark 25 Sextant#025The top of the line Davis plastic sextant, the Mark 25 features our Beam Converger™ mirror, sometimes referred to as a "full horizon mirror". A special coating is applied to high quality optical glass to allow the user to see through this mirror, yet still pick up images as faint as low-light stars.The Mark 25 is illuminated by a long-life LED and made of an upgraded plastic that is very stable.Comes with instruction booklet. Normalized SKU: 025UPC Code: 011698002511Davis Instruments 025 Literature Download  Owners Manual

  Download LiteratureDavis Instruments 385 Navigational InstrumentsRudder Position IndicatorAwareness of the rudder angle is an important safety factor. This is especially true while moving in and out of your berth, drawing alongside another boat, picking up a skier, mooring, or any other "close call" situation. Davis' Rudder Position Indicator gives instant visual reference of rudder angle.The pointer swings a full thirty degrees with each revolution of the wheel. Mounts directly to your hub (approximately 2" (5 cm) in diameter) with a self-adhesive pad . Rugged, hermetically sealed, weatherproof, and sunproof housing ensures long life. No cables, adjustments, or electricity required; gravity power makes it simple and service-free. Suitable for boats with mechanical and single station hydraulic steering systems. Normalized SKU: 385UPC Code: 011698038503Davis Instruments 385 Literature Download  Owners Manual

  Download LiteratureSI-TEX SST-110 Navigational InstrumentsSST-110 Sea Temp GaugeThe right tool at the right price for all saltwater anglers, both inshore and offshore.An affordable, waterproof, analog sea surface temp instrument with LARGE digital numbers that can literally be seen from 15 to 20 feet away. With its large four-digit LCD display (measuring 4.3 inchesx 4.3 inches x 3.5 inches), rugged water-resistant construction and advanced features, Si-Tex's SST-110 is ideal for a wide range of recreational and commercial fishing vessels. It can be easily installed on the flybridge of a large sportfisherman or on the instrument panel of a 17-foot open center console. It has the ability to view water temperature at a glance (in 0.01-degree Fahrenheit/Celsius resolution), find favorable temperature zones and pinpoint critical off-shore temp breaks. For maximum accuracy and to compensate for slight differences in transducers, the displayed temperature can be easily calibrated by the operator using the SST-110's front panel keys. Boaters can also set high and low temperature alarms for audible alerts to temperature fl uctuations or hard temperature edges. A temperature trend arrow on the display tells the user at a glance if sea temperatures are getting warmer, cooler or remaining constant.For operation in any onboard environment or ambient light conditions, the SST-110 offers five levels of backlighting that can be selected and remotely switched On/Off . All set up and calibration constants are saved to a nonvolatile memory, retaining settings for the next time the unit is powered up. For easy integration on most professional fishing vessels, the SST-110 outputs standard NMEA 0183 water temperature data and works on both 12 and 24 VDC systems. Even with its large digital display, the SST-110 draws only 0.35 amps (0.55 amps with full backlighting).Features: 0.01 Degree Resolution Easy Calibration Temperature Alarms Trend Indicators Specifications:Frequency = NONE Screen Size = 4.3" LCD Display Shape = Square Transducer Type = Not Included Depth - Max (Feet) = NONENormalized SKU: SST110UPC Code: 010407320663SI-TEX SST-110 Literature Download  Owners Manual

  Download LiteratureFaria 12850 Navigational InstrumentsEuro Black 2" Depth Sounder w/Transom Mount TransducerThe Depth Sounders from Faria offer a 3-199 foot (61m) depth capability, with an automatic gain control, backlighting for maximum night vision, keel offset, and deep and shallow water alarms.Depth can be read in meters, and feet. With its oversized back-lit display depth can be easily read in any condition. Audible and Visual alarms let the boater know when a shallow or deep water condition exist. A programmable keel offset lets you adjust the offset from the keel at the display.Features & Benefits: Depth Range: 1- 61 meters (3 -199 feet) Deep and Shallow water alarms Programmable Keel off-set Automatic Gain control Back lighting for maximum night vision; Metric or US standard units Easy to installDual Temp Depth Sounder displays Outside Air temperatures and Water temperatures from 0°C to 100°C (32°F to 200°F). Faria Euro Depth Sounder with Transom Mounted Transducer 12850Normalized SKU: 12850UPC Code: 759266128507Faria 12850 Literature Download  Quick Reference Guide

Raymarine Z195 Navigational InstrumentsRotaVecta Wind TransducerSupplied w/20M (65') CableCompatible Models: ST60+ ST40 RAYMARINE Z195 ROTAVECTA MASTHEAD UNITNormalized SKU: Z195UPC Code: 723193100509
