Teleflex HC5375-3 Hydraulic Steering SeaStar Front Mount Pivot Cylinder for Catamaran designs Internal o-ring designed to limit the amount of fluid bypass decreasing the amount of re-alignment Best used in applications that require a liquid tie bar Not recommended for single engine applications Normalized SKU: HC53753UPC Code: 731957918253

Teleflex HC5358-3 Hydraulic Steering Current model SeaStar and SeaStar Pro pivot plate cylinder for single and dual outboards up to 300HP or (600HP combined for counter-rotating duals) 21-3/4" wide. Front Mount Hydraulic Outboard Steering Cylinder For Yamaha applications where it's necessary to mount the steering cylinder under the steering arm State-of-the-Art Proprietary Sealing System Superior resistance to repeated compression set Note: Not recommended for boats that exceed 75 mph or run surface-piercing props Robust Barrel design and NEW graphics compliment new boats and motor packages Positionable Stainless Steel O-Ring (ORB) Fittings for easy hose routing 8 hole end gland design for improved serviceability Meets ABYC and NMMA certification standards Independent engine tilt for twin/triple engine installations Normalized SKU: HC53583UPC Code: 731957916846

Teleflex HC5348-3 Hydraulic Steering Hydraulic steering cylinders for SeaStar and BayStar systems. Balanced stroke, 1" shaft. Features state of the art proprietary seal material, similar to Tournament 2 cylinders, with excellent resistance to compression set. 8-hole end gland design for improved serviceability. Adjustable stainless steel O-ring seal (ORB) fittings. Fits Honda engines and old OMC '77-'90 and others SeaStar pivot cylinder, alternate pivot plate Normalized SKU: HC53483UPC Code: 731957917850

Teleflex HC5345-3 Hydraulic SteeringSeaStar Front Mount Outboard Steering Systems feature an independent engine tilt for twin installations and a five turns lock-to-lock steering response (1.7 standard system). They are intended for general purpose use with single and multiple engine capability, whit typical applications including center console fishing boats and cruisers. Not recommended for installations where a chopper, cleaver, or surface piercing propeller is used, instances where the engine is highly elevated on the transom, the engine tabs have been removed, the boat speed exceeds 75 mph, or the power exceeds the maximum Coast Guard or M.O.T. recommendations for the boat. Independent engine tilt for twin/triple engine installations Five turns lock-to-lock steering response (1.7 standard system) Single and multiple engine capability Typical applications include center console fishing boats and cruisers Provides easy steering Normalized SKU: HC53453UPC Code: 731957916754

Teleflex HF6009 Hydraulic Steering These fittings are made of corrosion-resistant stainless steel and now thread into the cylinders/helms via positionable O-ring hose ports. Fittings can be easily orientated in any direction to accommodate tube routing. For use with -3 helms and cylinders only. ORB Fitting-Straight 2Pk Tube Thread: 3/8" .5 ORB Thread Normalized SKU: HF6009UPC Code: 731957919106

Teleflex HF6006 Hydraulic SteeringTeleflex HF6006 Orb Fitting Kit Vertical Tee SS. Tube Thread: 3/8". Sold as pack of two. Refer to manufacturer recommendations to ensure a proper fit. Tube Thread: 3/8" Sold as pack of two Refer to manufacturer recommendations to ensure a proper fit Quick and easy installation Normalized SKU: HF6006UPC Code: 731957919083

Teleflex HF6010 Hydraulic Steering These fittings are made of corrosion-resistant stainless steel and now thread into the cylinders/helms via positionable O-ring hose ports. Fittings can be easily orientated in any direction to accommodate tube routing. For use with -3 helms and cylinders only.Includes: 12 Tube Nut 3/8" 2 Connector Fitting 3/8" - 5 ORB 2 Tee Fitting 3 Ends - 3/8" Tube 1 Non-Vented Filler Plug 3 Straight Fitting 14 NPT to 3/8" Tube (not for use in -3 helms) 2 Elbow 3/8" Tube - 5 ORB (supplied with -3 Helm Pump) Normalized SKU: HF6010UPC Code: 731957919113

Teleflex HF6007 Hydraulic Steering These fittings are made of corrosion-resistant stainless steel and now thread into the cylinders/helms via positionable O-ring hose ports. Fittings can be easily orientated in any direction to accommodate tube routing. For use with -3 helms and cylinders only. Add-A-Starion/Autopilot Outboard Fitting Kit with Tubing Normalized SKU: HF6007UPC Code: 731957919090

Teleflex AP1233 Hydraulic Steering The Seastar Autopilot pump is a fixed flow, reversible pump set that uses an internal hydraulic gear pump, producing very little vibration or noise. It is offered in two different pump sizes (type 1 & type 2). AUTOPILOT KEY FEATURES Long-life DC Motor (i.e. long-life brushes) Compact design Simplified installation Low power consumption ABYC, CE's and J1171 compliant Superior corrosion resistance Quiet operation All mounting bracket displacement included       Voltage   12 volt       Fittings     Compatible w/ Standard Seastar Hose - Thread 9/16" X 24 UNEF       Wire Details     Length   24" Gauge   12 AWG Connector   None - Bare Leads       Oil Compatibility   Seastar Steering Fluid (MIL 5606)       Weight   4.9 lbs (2.2 kg)       Pump Sizes   Type 1: 60 in3/min (no-load)   Type 2: 100 in3/min (no-load)       Maximum Pressure   1000 PSI       Typical Current Draw   12V Type 1: 4 @ 8 amps (Depending on Application)   12V Type 2: 5 @ 11 amps               Ram Capacity     Type 1   4.9 in3 - 14 in3 Type 2   14 in3 - 21 in3 "Normalized SKU: AP1233UPC Code: 731957898005

Teleflex AP1219 Hydraulic Steering Dometic's high efficiency, fixed flow, reversible type autopilot pump produces very little vibration or noise. It is typically used as a plug-and-play stand alone pilot pump but can also be retrofitted to Dometic's Seastar power assist unit. AUTOPILOT KEY FEATURES Long-life DC Motor Compact design - 4.61 (width) x 6.63 (height) inches Simplified installation that can be used in most hydraulic steering systems Low power consumption ABYC, CE, and J1171 compliant Marine grade engineering - corrosion-resistant exterior Extremely quiet Mounting bracket included Stand-alone or will mount to SeaStar power assist unit Direct replacement for other 12-volt and 24-volt autopilot pumps Input Voltage: 12 volts DC Max PSI Rating: 1000 PSI Flow Rate: 60 cubic inches per minute with no load Port type: 3/8 compression fitting Typical Current Draw: 4-8 Amps (Up to 300PSI) Cylinder Capacity: 4.9-12.5 cubic inch displacement Fluid Compatibility: SeaStar steering fluid HA5430H or MIL Spec H5606QT Applications: inboard, outboard, and I/O steering systems 2 year limited warranty 24-inch 12 AWG wire (no connectors provided)       Voltage   12 volt       Fittings     Compatible w/ Standard Seastar Hose - Thread 9/16" X 24 UNEF       Wire Details     Length   24" Gauge   12 AWG Connector   None - Bare Leads       Oil Compatibility   Seastar Steering Fluid (MIL 5606)       Weight   4.9 lbs (2.2 kg)       Pump Sizes   Type 1: 60 in3/min (no-load)   Type 2: 100 in3/min (no-load)       Maximum Pressure   1000 psi       Typical Current Draw   12V Type 1: 4 ? 8 amps (Depending on Application)   12V Type 2: 5 ? 11 amps               Ram Capacity     Type 1   4.9 in3 - 14 in3 Type 2   14 in3 - 21 in3 Normalized SKU: AP1219UPC Code: 731957897817

Teleflex HF6004 Hydraulic Steering These fittings are made of corrosion-resistant stainless steel and now thread into the cylinders/helms via positionable O-ring hose ports. Fittings can be easily orientated in any direction to accommodate tube routing. For use with -3 helms and cylinders only. 90° Elbow Hose Fitting 2/pk Tube Thread: 3/8" .5 ORB Thread Normalized SKU: HF6004UPC Code: 731957911681
