B & G 000-14396-001 AccessoriesWS300 Series 20M Cable - 65'Features: Wired cable for WS310  65' 20M Normalized SKU: 00014396001UPC Code: 9420024171554

Actisense USG-2 Accessories USG-2 Isolated USB To Serial Gateway for use with NMEA0183, RS422, and RS232The USG-2 converts a USB port into a bi-directional serial port suitable forconnecting to a marine standard NMEA 0183 data bus.It provides a much safer connection than standard USB-to-serial converters. Electrical isolation is provided by the ISO-Drive output and OPTO-isolated input, making installation simple and free from ground loops. The input uses the Actisense OPTO-isolation circuitry to protect any connected equipment from the most common system faults. The input can receive very low-level signals that are often too small to be received by a PC serial port.The high-quality, shielded USB lead included with the USG-2 makes connection to a PC simple while providing a high level of water protection when connected to the custom-designed USB socket. The pluggable screwless connector makes installation quick and easy, and the specifically designed DIN rail mount option ensures a reliable, secure bulkhead mount for the USG-2. Multiple LEDs make diagnosing connection issues quick and easy. The blue power LED illuminates solid blue when the USB driver has successfully loaded, and the USG-2 is powered, while a green (receive) LED and an orange (transmit) LED indicate whether data is present.Features: NMEA 0183, RS422 RS232 compatible ISO-Drive technology Isolated input (2500V) Isolated output (1500V) Encapsulated electronics High retention USB socket Diagnostic LEDs Baud rates from 300 to 230400 bps Bulkhead mount, with optional DIN rail mount kit Pluggable screwless connector with locking latch & strain Specifications: Data Interface = NMEA 0183 Normalized SKU: USG2

Download Literature Actisense EMU-1 Accessories Engine Management Unit Analog - NMEA2000Share engine information on the NMEA 2000® bus...The Actisense EMU-1 is a specialized analogue to NMEA 2000 Gateway, which converts data from analogue engine senders into NMEA 2000. The EMU-1 enables NMEA 2000 display devices to monitor the engine on a vessel.The EMU-1 has a PC based configuration tool that allows the settings inside the EMU-1 to be changed to best suit the engine it is working with, making it a flexible solution for many engine makes and models. Capable of measuring a wide range of engine parameters, the EMU-1 reports how the engine is operating and shares the information across the network.Designed to simplify the conversion of analogue engine parameters (e.g., Temperature, pressure, and RPM) into NMEA 2000 engine PGNs, the EMU-1 simplifies processes and reduces the number of input/output wires required at each engine. Additionally, the EMU-1 also supports the conversion of analogue transmission parameters and battery status to the associated NMEA 2000 PGNs.The two-part screw terminal connection system allows for an easy pluggable connection to an engine wiring harness.Multiple engines are supported by setting the engine instance using the EMU-1 configuration tool. Currently, one EMU-1 per engine is supported. Support for multiple engines on a single EMU-1 is currently planned as a future firmware update.The customised case ensures that the electronics are sealed while allowing quick access to the electrical connections.It is recommended that an Actisense NGT-1 NMEA 2000 PC Interface be available for every EMU-1 installation. The NGT-1 can be used to update the Firmware, connect the Configuration Tool, and display data on a PC for diagnostic and information purposes, using NMEA Reader. Please visit the NGT-1 page for product details.Features: 6-gauge inputs 4 alarm inputs 2 tacho inputs Logs total engine time using the tacho inputs 2 auxiliary inputs for additional flexibility Simple single wire gauge connections; common ground referenced Manual measurements are not required when configuring Firmware can be updated over NMEA 2000 network Easy customisation for different installations (requires an NGT-1 and PC software) Waterproof electronics and splash-proof connections Pluggable connectors for quick and easy installation An optional DIN rail mounting kit is available Specifications: Data Interface = NMEA 2000 Normalized SKU: EMU1 Actisense EMU-1 Literature Download Owners Manual Product Brochure

Download LiteratureActisense A2K-SBN-2 AccessoriesA2K-SBN-2 Small Boat 8 Way Self-Contained Boat Network N2KInstalling small NMEA 2000® networks is quicker and easier than it’s ever been with the Self-contained Boat Network (SBN) from Actisense.The equivalent of eight T-pieces in a single case provides a significant time and space saving with no more connecting multiple T-pieces together. Termination resistors are built in which increases the saving on time and space.Once the attached 3 metre cable is connected to the boats power supply, an NMEA 2000 network for up to eight devices is ready to use, taking ‘plug & play’ to the next level.Features: Self-contained NMEA 2000 Network Integrated Termination Resistors 8x NMEA 2000 drops Ruggedized, flame retardant over-moulded housing Metal coupling nuts Integrated EMI Shield Orange, UL Rated, 3M power cable Colour coded wires, stripped and tinned Benefits: Low cost, quick to install, and provides an easy way to connect multiple NMEA 2000 devices Simple installation, fewer components, more reliable, lower cost Accommodates the vast majority of compact NMEA 2000 networks Suitable for wet and harsh conditions- highly desirable in marine environments Reliable, long lasting connections Less likely to be susceptible to interference UL rated cable provide peace of mind. Colour easily differentiates the power cable form drop cables Quick installation, no special tools required Normalized SKU: A2KSBN2Actisense A2K-SBN-2 Literature Download Product Brochure

Actisense A2K-GCM-0.25M AccessoriesN2K Male/Male Gender Changer - 0.25MUse between two cable connectors of the same type and gender. Overcomes the problem of connecting two devices or cables which have the same gender of connector on an NMEA 2000® backbone.Male to Male - 0.25M Specifications:Cable Length (Feet) = 1' Connection Gender = Male-Male Data Interface = NMEA 2000Normalized SKU: A2KGCM025M
