Optifuse F3T-400A Fuses & Fuse Panels 400a Class T Fuse 300v AC 160v DC Normalized SKU: F3T400A

Download LiteratureVictron Energy LYN040102110 Fuses & Fuse PanelsLynx Shunt VE.Can (M10)Busbar Integrated Battery Monitoring The Lynx Shunt VE.Can contain a positive and negative busbar, a battery monitor, and a fuse holder for the main system fuse. It is part of the Lynx Distribution system. The Lynx Distributor has a power LED. The Lynx Shunt VE.Can can communicate via VE.Can with a GX device. The Lynx Shunt VE.Can ship with two RJ45 VE.Can terminators, be used when connecting to a GX device.  The Lynx Shunt VE.Can is designed to hold a CNN fuse. The fuse needs to be purchased separately. The Lynx Distribution System The Lynx Distribution System is a modular busbar system incorporating DC connections, distribution, fusing, battery monitoring, and Lithium battery management. The Lynx Distribution System Consists of the Following Parts:  Lynx Power In - A positive and negative busbar with 4 batteries or DC equipment connections. Lynx Distributor - A positive and negative busbar with 4 fused connections for batteries or DC equipment together with fuse monitoring Lynx Shunt VE.Can - A positive busbar with a space for a main system fuse and a negative busbar with a shunt for battery monitoring. It has VE.Can communication for monitoring and setup with a GX device Lynx Smart BMS - For use together with Victron Energy Smart Lithium batteries. It contains a positive busbar with a contactor that is driven by a battery management system (BMS) and a negative busbar with a shunt for battery monitoring. It has Bluetooth communication for monitoring and setup via the VictronConnect App and VE.Can communication for monitoring with a GX device and the VRM portal Specifications:Power: Supply Voltage Range: 9 - 70 Vdc Supported System Voltages: 12, 24 or 48V  Reverse Polarity Protection: No  Current Rating: 1000Adc continuous  Power Consumption: 60mA @ 12V, 33mA @ 24V, 20mA @ 48V  Potential Free Alarm Contact 3A, 30Vdc, 250Vac Connections: Busbar: M8 Fuse: M8  VE.Can: RJ45 and RJ45 terminator  Power Supply Connection to Lynx Distributor: RJ10 (an RJ10 cable ships with each Lynx Distributor) Temperature Sensor: Screw terminal  Relay: Screw terminal  Physical: Enclosure Material: ABS Enclosure Dimensions (H x W x D): 190 x 180 x 80 mm  Unit Weight: 1.4 kg  Busbar Material: Tinned copper  Busbar Dimensions (H x W): 8 x 30 mm Environmental Operating Temperature Range: -40°C to +60°  Storage Temperature Range: -40°C to +60°  Humidity: Max. 95% (non-condensing)  Protection Class: IP22 Please contact your dealer for any returns, repairs or support issues related to this product. Normalized SKU: LYN040102110UPC Code: 8719076065487Victron Energy LYN040102110 Literature Download Quick Reference Guide Owners Manual Product Brochure

Download LiteratureVictron Energy CIP143400020 Fuses & Fuse PanelsANL-Fuse 400A/80V for 48V Products (Package of 5)Victron Energy's ANL fuses are bolt-down fast-acting and have a higher short-circuit breaking capability than MEGA fuses. This particular pack of Victron ANL fuses contains FIVE 400-amp fuses.Features:For 48V productsSpecifications: Max Current Rating: 400 amps Max Voltage Rating: 80 volts Approximate Voltage Drop: 125 mV Cold Resistance: 0.3 mΩ Please contact your dealer for any returns, repairs or support issues related to this product. Normalized SKU: CIP143400020UPC Code: 8719076061786Victron Energy CIP143400020 Literature Download Quick Reference Guide Owners Manual

Download LiteratureVictron Energy CIP138150020 Fuses & Fuse PanelsMEGA-Fuse 150A/80V Ceramic (Package of 5 Pieces)Victron Energy supplies a range of fuse holders and fuses to suit a wide range of installations, and the MEGA fuses are frequently used in Victron Energy DC distribution systems. This particular pack of ceramic Victron MEGA fuses contains FIVE 150-amp fuses.Features:For 48V productsSpecifications: Max Current Rating: 150 amps Max Voltage Rating: 80 volts Please contact your dealer for any returns, repairs or support issues related to this product. Normalized SKU: CIP138150020UPC Code: 8719076061687Victron Energy CIP138150020 Literature Download Quick Reference Guide Owners Manual

Download LiteratureVictron Energy CIP138125020 Fuses & Fuse PanelsMEGA-Fuse 125A/80V Ceramic (Package of 5 Pieces)Victron Energy supplies a range of fuse holders and fuses to suit a wide range of installations, and the MEGA fuses are frequently used in Victron Energy DC distribution systems. This particular pack of ceramic Victron MEGA fuses contains FIVE 125-amp fuses.Specifications: Max Current Rating: 125 amps Max Voltage Rating: 80 volts Please contact your dealer for any returns, repairs or support issues related to this product. Normalized SKU: CIP138125020UPC Code: 8719076061670Victron Energy CIP138125020 Literature Download Quick Reference Guide Owners Manual

Download LiteratureVictron Energy LYN060404010 Fuses & Fuse PanelsLynx Power-In Class-T M10 TerminalsThe Lynx Class-T Power In connects and fuses up to two strings of lithium batteries. It features a positive and negative busbar, connections for two Class-T fuses, and a connection to ground the DC system. The Class T-fuses, are available in 225A, 250A, 350A, and 400A (must be purchased separately).For installations using three or more strings of lithium batteries, use multiple Lynx Class-T modules. As a core component of the Lynx Distribution system, the Lynx Class-T seamlessly integrates with all other M10 Lynx products.The Lynx Distribution SystemThe Lynx Distribution System is a modular busbar system that incorporates DC connections, distribution, fusing, and battery monitoring and/or lithium battery management. The Lynx Distribution System Consists of the Following PartsLynx Power InA positive and negative busbar with four batteries or DC equipment connections.Lynx DistributorA positive and negative busbar with four fused connections for batteries or DC equipment and fuse monitoring is available in two versions.Lynx Shunt VE.CanA positive busbar with a space for a main system fuse and a negative busbar with a shunt for battery monitoring. It has VE.Can communication for monitoring and setup with a GX device.Lynx Smart BMSFor use together with Victron Energy Smart Lithium batteries. It contains a positive busbar with a contactor driven by a battery management system (BMS) and a negative busbar with a shunt for battery monitoring.It has Bluetooth communication for monitoring and setup via the VictronConnect App and VE.Can communication for monitoring with a GX device and the VRM portal. Available as a 1000A model with M10 busbars.SpecificationsPower: Voltage Range: 9 - 60Vdc Current Rating: 1000Adc continuous  Connections: M10 Busbar: 3/8” Physical: Enclosure Material: ABS Enclosure Dimensions (H x W x D): 279 x 169 x 97mm Unit Weight: 2.1 kg Busbar Material: Tinned copper Busbar Dimensions (H x W): 8 x 30mm Environmental: Operating Temperature Range: -40°C to +60° Storage Temperature Range: -40°C to +60° Humidity: Max. 95% (non-condensing) Protection Class: IP20 Please contact your dealer for any returns, repairs or support issues related to this product. Normalized SKU: LYN060404010UPC Code: 8719076062967Victron Energy LYN060404010 Literature Download Quick Reference Guide Owners Manual Product Brochure
